ADIC FastStor 22 User Manual
FastStor & FastStor 22
Installation and
Operating Guide
Barcode Reader Module
Document 62-0135-01 Rev B, Copyright © ADIC 1998, 1999, 2000
Table of Contents
Equipment Description............................................................................................................................................................................................. 1
FastStor Barcode Reader Module Installation.......................................................................................................................................................... 2
FastStor 22 Barcode Reader Module Installation..................................................................................................................................................... 4
Diagnostic Menu...................................................................................................................................................................................................... 6
Barcode Function.........................................................................................................................................................................6
Barcode Labels.........................................................................................................................................................................................................6
ii
Equipment Description
The user-installable Barcode Reader module option enables your FastStor/FastStor 22 to read cartridge information contained in a
barcode label attached to each of the data cartridges. This information becomes part of the application software’s library cartridge
inventory.
Mounting Bracket
Interface Connector
Barcode Reader
Reader Module, Top View
Thumbscrew
Barcode Reader Module, Bottom View
1
