Ademco 8DLLYNXPLUS Users Manual

PLEASE GO TO PAGE 73 FOR FCC & IC STATEMENTS OR GO TO THE BOOKMARKS

Lynx Plus Series

Security Systems

Installation and Setup Guide

Installation and Setup GuideInstallation and Setup Guide

ARMED READY

OFF

ESCAPE

AWAY

ADD

LIGHTS ON

LIGHTS OFF

STATUS

132

RECORD

4 65

CODE

NO DELAY

VOLUME

TEST

BYPASS

CHIME

FUNCTION

STAY

DELETE

PLAY

AUX

SELECT

800-03857 9/09 Rev. A

RECOMMENDATIONS FOR PROPER PROTECTION

The Following Recommendations for the Location of Fire and Burglary Detection Devices Help Provide Proper Coverage for the Protected Premises.

Recommendations for Smoke and Heat Detectors

With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.

• Early warning fire detection is best achieved by the installation of fire detection equipment in all rooms and areas of the household as follows: For minimum protection a smoke detector should be installed outside of each separate sleeping area, and on each additional floor of a multi-floor family living unit, including basements. The installation of smoke detectors recommended.

• For additional protection the NFPA recommends that you install heat dining room, bedroom(s), kitchen, hallway(s), attic, furnace room, utility and storage rooms, basements and attached garages.

In addition, we recommend the following:

• Install a smoke detector inside every bedroom where a smoker sleeps.

• Install a smoke detector inside every bedroom where someone sleeps with the door partly or completely

closed. Smoke could be blocked by the closed door. Also, an alarm in the hallway outside may not wake up the sleeper if the door is closed.

• Install a smoke detector inside bedrooms where electrical appliances (such as portable heaters, air conditioners or humidifiers) are used.

• Install a smoke detector at both ends of a hallway if the hallway is more than 40 feet (12 meters) long.

• Install smoke detectors in any room where an alarm control is located, or in any room where alarm control

connections to an AC source or phone lines are made. If detectors are not so located, a fire within the room could prevent the control from reporting a fire or an intrusion.

THIS CONTROL COMPLIES WITH NFPA REQUIREMENTS FOR TEMPORAL PULSE

in kitchens, attics (finished or unfinished), or in garages is not normally

or smoke detectors in the living room,

SOUNDING OF FIRE NOTIFICATION APPLIANCES.

DINING

KITCHEN

BEDROOM

TV ROOM

KITCHEN

LIVING ROOM

DINING

BDRM

BEDROOM

Smoke Detectors for Minimum Protection

Smoke Detectors for Additional Protection

Heat-Activated Detectors

GARAGE

floor_plan-001-V1

BEDROOM

TO BR

BEDROOM

KTCHN

CLOSED

DOOR

LIVING ROOM

BEDROOM

LVNG RM

BASEMENT

Recommendations For Proper Intrusion Protection

• For proper intrusion coverage, sensors should be located at every possible point of entry to a home or premises. This would include any skylights that may be present, and the upper windows in a multi-level building.

• In addition, we recommend that radio backup be used in a security system. This will ensure that alarm signals can be sent to the alarm monitoring station in the event that the telephone lines are out of order (alarm signals are normally sent over the phone lines, if connected to an alarm monitoring station).

- 2 -

Table of Contents

SYSTEM FEATURES ..................................................................................................................................5

MOUNTING THE CONTROL.....................................................................................................................6

WIRING CONNECTIONS...........................................................................................................................7

CONNECTING/CONFIGURING COMMUNICATIONS DEVICES ........................................................9

AC POWER AND BACKUP BATTERY....................................................................................................11

INSTALLING WIRELESS ZONES...........................................................................................................13

MECHANICS OF PROGRAMMING ........................................................................................................16

ZONE RESPONSE TYPE DEFINITIONS ...............................................................................................18

DATA FIELD DESCRIPTIONS ................................................................................................................20

✻56 ENHANCED ZONE PROGRAMMING MODE ................................................................................38

✻80 DEVICE PROGRAMMING MENU MODE ......................................................................................43

✻81 ZONE LIST MENU MODE................................................................................................................47

✻83 ENHANCED SEQUENTIAL MODE ................................................................................................49

✻84 ASSIGN ZONE VOICE DESCRIPTORS ..........................................................................................52

✻85 RECORD CUSTOM VOICE DESCRIPTORS...................................................................................54

REMOTE PROGRAMMING/CONTROL (DOWNLOADING) ................................................................55

SYSTEM OPERATION ..............................................................................................................................56

TESTING THE SYSTEM ..........................................................................................................................62

SYSTEM COMMUNICATION ..................................................................................................................63

TROUBLESHOOTING GUIDE ................................................................................................................65

PROGRAMMING DEFAULT TABLES ....................................................................................................67

LYNX PLUS CONTROL DEFAULTS ................................................................................................67

LYNXSIA PLUS CONTROL DEFAULTS .........................................................................................69

REGULATORY AGENCY STATEMENTS ..............................................................................................73

LIMITATIONS OF THIS SYSTEM STATEMENT..................................................................................75

UL NOTICES..............................................................................................................................................75

SIA QUICK REFERENCE GUDE ............................................................................................................75

SPECIFICATIONS.....................................................................................................................................76

CONTACTING TECHNICAL SUPPORT.................................................................................................76

WARRANTY INFORMATION .................................................................................................................76

INDEX.........................................................................................................................................................77

SUMMARY OF CONNECTIONS DIAGRAM ...........................................................................Rear Cover

-3-

Lynx Plus Series Installation and Setup Guide

System Features

The Lynx Plus Series control is a self-contained, rechargeable wireless control/communicator that features easy installation and usage. A built-in speaker provides voice annunciation of system status along with voice descriptors of each zone. An internal module (if provided) allows the Lynx Plus Series to communicate with the Central Station via the Internet.

Lynx Plus Series is not intended for UL985 Household Fire applications unless a 24-hour backup battery

ULUL

Features

(P/N LYNXRCHKIT-HC or LYNXRCHKIT-SHA) is installed. Powerline Carrier Devices have not been evaluated by UL.

System Features

• Real-time clock display and 2 line by 16 character alpha display

• Message center (for user recorded messages)

• Voice announcement of system and zone status

• Voice chime

• Alarm clock

• Reminder

• X10 scheduling

• Latch key reports

• Automatic stay arming

• Remote phone control

• Speaker phone operation

• “Follow me” reminder and system announcements

• 8 User Codes (Installer, Master, 5 Secondary,

Duress)

• 3 Panic Functions

Zones and Devices

• 1 Hardwire zone

• Up to 24 Wireless zones (5800 Series

transmitters)

• Up to 16 Wireless button zones

• Up to 8 Powerline carrier devices

• Supports wireless keypads

Communication

• Ademco Low Speed

• Sescoa/Radionics

• Ademco Express

• Ademco Contact ID

• Internet central station communication

• GSM cellular central station communication

• Two-way voice communication Supports

AlarmNet remote services

Alarm Output

• Built-in sounder

• Piezo output (30mA max.)

• Bell output (120mA max.)

• Steady output for burglary/panic

• Temporal pulse output for fire and carbon

monoxide alarms

• Long range radio/audio alarm verification

Programming

• Options stored in EEROM

• Can be uploaded, downloaded or controlled via

IBM-compatible computer using Compass downloader software and specified HAYES modem or via capable GSM or IP communications module

• Voice prompt programming mode

Other Features

• Exit error feature (detects difference between an actual alarm and exit alarm caused by leaving a door open after the exit delay expires)

• Event log stores up to 84 events

• Macro/ 1-button paging

• RF jam detection

• Compatible with encrypted (high-security)

devices

System Power

• Primary Power: K10145WH or K10145X10 plugin transformer, 110VAC to 9VAC, 25VA output (K10145CN in Canada)

• Backup battery: Rechargeable nickel-metal hydride battery pack rated at 7.7Vdc.

Mounting the Control

- 5 -

Lynx Plus Series Installation and Setup Guide

Wall Mounting

1. Release the front assembly from the back case by depressing the two locking tabs at the top of the unit with the blade of a medium size screwdriver.

2. Separate the front and back case assemblies by rotating the front case so that it is perpendicular to the back case and unsnapping (releasing) the two hooks from the back case.

3. Feed the field wiring through the appropriate openings in the back case. Use tie-wraps to secure the wiring to the built-in wire loops as needed.

4. Mount the back case to a sturdy wall.

5. Attach the front and back cases by connecting the hooks on the front case to the attachments on the rear case. Once attached, the hooks will support the front case and allow you to make the wiring connections.

6. After all wiring connections have been made, snap the front case and back case closed and ensure that the control is secured by the locking tabs.

MOUNTING

HOOKS

LOCKING TABS

FRONT CASE

BACK CASE

ROTATE

FRONT CASE

UPWARD

TO RELEASE

HOOKS

1000-300-009-V1

Desktop Mounting

For desktop mounting, the optional mounting base (model LYNXPLUSDM, purchased separately) must be used.

1. Slide the control panel onto the mounting base locking tabs.

2. Bring all wiring through the bottom of the mounting base, using one of the wire entry locations, before making connections to the control panel.

3. Use tie-wraps to secure the wiring to the built-in wire loops as needed.

4. Use the supplied screws to secure the control panel to the mounting base.

AWAY

ADD

STATUS

ESCAPE

LIGHTS OFF

ARMED

OFF

RECORD

LIGHTS ON

TEST

CODE

NO DELAY

FUNCTION

READY

STAY

VOLUME

PLAY

DELETE

AUX

BYPASS

SELECT

CHIME

1000-300-016-V0

- 6 -

Lynx Plus Series Installation and Setup Guide

Wiring Connections

Wiring Overview

The following summarizes the connections required. Refer to the Wiring Connections paragraph and the Summary of Connections diagram on the inside back cover when making connections.

TELEPHONE

CONNECTION

TERMINAL

STRIP

POWERLINE CARRIER

DEVICE CONNECTOR

SUPER HIGH-CAPACITY BATTERY CONNECTOR

STANDARD/HIGH-CAPACITY BATTERY CONNECTOR

GSML/GSMVL COMMUNICATIONS PORT

GSMVL AUDIO CABLE CONNECTOR

1000-300-006-V1

Wiring Connections

1. Make Earth Ground Connection - The designated earth ground terminal (1) must be terminated in a good earth ground

for the lightning transient protective devices in this product to be effective. The following are examples of good earth grounds available at most installations:

Metal Cold Water Pipe - Secure a non-corrosive metal strap (copper is recommended) to the pipe that is electrically connected and secured to which the ground lead is electrically connected and secured.

AC Power Outlet Ground - Available from 3-prong, 120VAC power outlets only. To test the integrity of the ground terminal, use a three-wire circuit tester with neon lamp indicators, such as the UL Listed Ideal Model 61–035, or equivalent, available at most electrical supply stores.

a. Connect terminal 1 to a good earth ground.

2. Make Phone Line Connections - For local or full line seizure follow the appropriate steps below.

Local Seizure

a. Connect the incoming phone line to either the 8-position jack or terminals 2 (TIP) and 3 (RING) on the Lynx Plus.

b. Connect the handset phone lines to terminals 4 (TIP) and 5 (RING).

Full Line Seizure: The control must be placed in series with the incoming phone line. Plugging the Direct Connect Cord directly into the RJ31X jack, allows the control to seize the phone line when an alarm occurs and normal phone line usage by the premises phones if the plug needs to be removed.

c. Cut the incoming RING and TIP phone lines (typically red and green, respectively) and connect them to RJ31X

terminals 4 (red) and 5 (green).

d. Connect the premises end of the cut RING and TIP wires to RJ31X terminals 1 (grey) and 8 (brown) respectively.

e. Wire the flying leads of a Direct Connect Cord to the control’s phone terminals as shown in the diagram or plug into

the 8-position jack.

f. Plug the Direct Connect Cord into the RJ31X jack.

- 7 -

Lynx Plus Series Installation and Setup Guide

Wiring Connections

GREY

2 1

RJ31X

DIRECT CONNECT CORD

INCOMING

PHONE LINE

RING TIP

GREENRED

PREMISES PHONES

RING TIP

BROWN

RED

GREEN

TIP RING TIP RING

}

INCOMING

PHONE LINE

BROWN

}

PREMISES

PHONES

GREY

8-POSITION

JACK

01000-008-V0

Full Line Seizure Connections

ULUL

3. Hardwired Zone Connections

Zone 1 is an EOLR supervised zone that supports both open circuit and closed circuit devices and has a response

Note: The hardwire zone cannot be used as a fire zone.

4. Make External Sounder Connections - The control panel supports either a 6-14VDC piezo sounder (30mA max.) or

5. Disable Local Sounder Option - If required the Master Keypad’s built-in piezo sounder can be disabled.

6. Make Powerline Carrier Device Connections - The control panel supports up to 8 Powerline Carrier Devices. If using

The local sounder disable switch must be set to “ON” position. External sounders and powerline carrier devices have not been evaluated by UL

LOCAL SOUNDER DISABLE: The Master Keypad’s built-in piezo sounder can be disabled by setting the sounder disable switch to OFF. If disabled, however, no sounding will occur upon AC loss, since the external sounder does not operate when AC power is lost.

HARDWIRED ZONE: If the EOLR is not at the end of the loop, the zone will not be properly supervised, and the system may not respond to an open circuit on the zone.

time of 350msec. Maximum zone resistance: 300 ohms, plus EOLR

a. Connect sensors/contacts to the hardwired zone terminals 6 (-) and 7 (+). Refer to the Summary of Connections

diagram.

b. Connect closed circuit devices in series in the high (+) side of the loop. The EOL resistor must be connected in

series with the devices, following the last device.

c. Connect open circuit devices in parallel across the loop. The 2000-ohm EOLR must be connected across the loop

at the last device.

6-14VDC bell (120mA max.; e.g. ADEMCO WAVE2EX). a. Connect a piezo sounder or a bell to terminals 8 (-) and 9 (+).

a. Set the Local Sounder Disable Switch to OFF.

these devices, they must be connected to control via a PL513 Powerline Interface Module. a. Connect the com/data/sync/ lines from the PL513 Powerline Interface Module to the Powerline Carrier Device

Connector using the provided cable.

Refer to the ✻✻✻✻80 Device Programming Menu Mode section to program the Powerline Carrier Devices.

- 8 -

Lynx Plus Series Installation and Setup Guide

Connecting/Configuring Communication Modules

General

This Lynx Plus Series control supports central station reporting via the internet using wireless (GSM) and hardwire (IP) communications modules. It also supports upload/download programming capability via the Internet or a Private local area network (Intranet). This allows site maintenance independent of central station monitoring, and modification to sites globally via the Internet or through a private LAN. Refer to the instructions provided with the LRR/IP Communications Device being installed for additional information regarding its installation, programming, and registration. The control is compatible with the following AlarmNet Communications Modules:

• 7847i-L Internet Communications Module

• GSMVLP GSM Communications Module with 2-Way Voice

Connecting Long Range Radio and Internet Communication Devices

Connect and configure the communications device (refer to the Installation Instructions for device that you are installing for additional information).

LRR/IP Communications Device 24-Hour Standby Power

If you are installing the AlarmNet 7847i-L, and require 24-hour standby, you must install the Super High Capacity battery P/N WALYNX-RCHB-SHA in the control.

Configuring Long Range Radio and Internet Communication Devices

1. Enable the communications device in programming field ✼55 and configure alarm reporting and module supervision in programming field ✼77.

2. Program the device as required using the 7720P programmer (refer to the Installation Instruction for the device that you are installing). Note that the device address must be set to 3.

The device must be registered before downloading or alarm reporting can take place.

LRR Communications Device Diagnostic Mode

This mode provides a method to verify the LRR signal strength.

1. Enter the Installer Code (4112) + 899. The system will initially display “Entering programming mode”.

2. The LRR Communications Module’s Signal Level (Primary Site Received Signal Strength Indication [PriRSSI]) will be displayed in dBm. The system will also display GPRS connection and registration indications (refer to the example that follows).

3. If “FAIL” or “POOR” signal levels are displayed during the test, the control should be relocated to find a location that provides better signal strength.

If a ‘searching for coverage’ message is displayed or the radio is not connected and no signal indication is displayed, the installer should check radio programming, panel programming, etc., before entering this mode again.

Signal strength may vary

4. The Lynx Plus will automatically exit this mode after approximately 1-minute or if any key is pressed. The system will display “Exiting programming mode” when the test is complete.

- 9 -

Lynx Plus Series Installation and Setup Guide

Connecting/Configuring Communication Modules

Example:

Diagnostic Mode Definitions

SIGNAL = Communications Module’s Signal Level (RSSI) will be displayed in dBm, where:

-01 to -93 GOOD = Good signal level

-94 to -95 POOR = Poor signal level, move unit for better signal level

-96 (and lower) FAIL = Fail signal level, do not install, move unit for better signal level. If “FAIL” condition persists, do

0 or “Searching for Coverage” = Waiting for signal. Try again in a few minutes. If no signal persists, move unit for better

GPRS = GPRS Service availability where: Y = GPRS is available N = GPRS is Not available

REG = Registration status from radio module where N = Not Registered (contact AlarmNet) H = Registered Home (functioning normally) S = Searching (wait or move unit to another location)* D = Registration Denied (contact AlarmNet) R = Registered Roaming (no problem) ? = Unknown Registration State (wait or move unit to another location)*

* If the unit is in an area of known cellular coverage for 3 – 5 min and these conditions do not clear contact AlarmNet for assistance.

SIGNAL GPRS REG

-86 GOOD Y H

not install

signal level, check all connections and SIM activation.

- 10 -

Lynx Plus Series Installation and Setup Guide

AC Power and Backup Battery

The system is powered by a 9VAC, 25VA Plug-in Transformer, K10145WH or K10145X10 (K10145CN in Canada). Refer to the wiring table below for wire gauge and length.

Distance between

Transformer and Control

Up to 75 feet #20

75 to 150 feet #18

150 to 300 feet #16

Use only the provided ADEMCO K10145WH/K10145X10 or K10145CN Transformer. Wiring to the AC Transformer must not exceed 300 feet using 16-gauge wire. The voltage reading between terminals 10 and 11 of the control must not fall below 9.00VAC.

Do not plug the transformer into the AC outlet until after all wiring connections have been made. Ensure the cover is snapped closed prior to applying AC power

Backup battery

In the event of an AC power loss, the system is supported by a long life backup battery that is supervised for connection and for low voltage conditions. If the battery is missing, or a low battery condition is detected, a “low battery” message is displayed and a report is sent to the central station. In addition, the system will beep once every 45 seconds to audibly indicate a low battery condition (press any key to stop the beeping).

AC Power and Rechargeable Backup Battery

Connecting AC Power and backup battery

1. Connect wires from the K10145WH or K10145X10 (K10145CN in Canada) AC Transformer to terminals 10 and 11 as shown on the summary of connections diagram.

2. Remove battery retainer.

3. Insert battery pack into back plate.

4. Install battery retainer.

5. Secure battery retainer with the provided screw.

6. Connect battery pack connector to the receptacle on the PC board.

7. After all wiring connections have been made, snap the case closed and plug the transformer into a 24-hour, 110VAC unswitched outlet.

Note: Rechargeable batteries may take up to 48-hours to fully charge. The “LOW BAT” message should clear within four

hours or by entering Test Mode.

Wire Gauge

SCREW

RETAINER

NOTE

WALYNXRCHKIT-SC

BATTERY PACK SHOWN

- 11 -

LYNXRCHKIT-SC BATTERY PACK

1000-300-027-V0

Lynx Plus Series Installation and Setup Guide

AC Power and Backup Battery

AC Power and Rechargeable Backup Battery

The Lynx Plus Series is equipped with an integral, replaceable, rechargeable battery pack rated at 7.7Vdc. Select the appropriate battery pack, based on the installation’s requirement, and install the battery pack.

Battery Part Number

Battery StandbyTime Low Battery Notification

LYNXRCHKIT-SC 4-hours (minimum) Approximately 1-hour before battery depletion

LYNXRCHKIT-HC 24-hours (minimum) At least 1-hour before battery depletion

LYNXRCHKIT-SHA 24-hours (minimum) At least 1-hour before battery depletion

Replacing the Rechargeable Battery

1. When battery replacement is required, unplug the transformer from the wall outlet, and open the control panel cover.

2. Remove the screw that secures the battery retainer.

3. Remove the battery retainer and disconnect the battery pack connector from the receptacle on the PC board.

4. Remove the battery pack from the back plate.

5. Install a replacement battery pack (P/N LYNXRCHKIT-SC, LYNXRCHKIT-HC or LYNXRCHKIT-SHA) into the back plate.

6. Install the battery retainer.

7. Secure battery retainer with the provided screw as shown below.

8. Connect the battery connector to the appropriate receptacle on the PC board.

9. After the wiring connection has been made, snap the front assembly and the back plate closed.

10. Plug the transformer into a 24-hour, 110VAC unswitched outlet.

11. Rechargeable batteries may take up to 48-hours to fully charge. The “LOW BAT” message should clear within four hours or by entering Test Mode.

RETAINER RETAINER

SCREW

LYNXRCHKIT-SHA/

LYNXRCHKIT-HC

LYNXRCHKIT-SC

Ensure the control panel assembly is snapped closed prior to applying AC power.

1000-300-010-V0

- 12 -

Lynx Plus Series Installation and Setup Guide

Installing Wireless Zones

General Information

Zones: The control supports up to 24 wireless zones using 5800 Series transmitters, and up to 16 wireless buttons.

Range: The built-in RF receiver can detect signals from wireless transmitters within a nominal range of 200 feet.

Transmitters: 5800 Series transmitters have built-in serial numbers that must be entered into the system using the ✻56 or ✻83 interactive mode, or input to the control via the downloader. 5800 Series transmitters (except the 5800RL, which is described separately) do not have DIP switches. Each transmitter's zone number is programmed into the system in ✻56 mode. Some transmitters, such as the 5816 and 5817, can support more than one "zone" (referred to as loops or inputs). On the 5816, for example, the wire connection terminal block is loop 1; the reed contact is loop 2. Each loop must be assigned a different zone number.

The 5816 and 5817 Transmitters do not have EOL supervision of their loop wiring and the loop wiring must

ULUL

For button transmitters (RF "keys") such as the 5804 and 5801, you must assign a unique zone number to each individual button used on the transmitter. Each button on the transmitter also has a pre-designated loop or input number, which is automatically displayed.

House Identification If you are using a 5804BD/5804BDV Wireless Keypad with the system, you must program a House ID Code (01–31) in field ✻24 to establish proper communication, and the keypad must be set to the same ID. House ID 00 disables all wireless keypads. An RF House ID is not necessary for other 5800 Series transmitters; the entry should be left at “00” (default) in those cases.

Transmitter Supervision

Except for some transmitters/keypads that may be carried off-premises (5804, 5804BD, 5804BDV, and 5804E), each transmitter is supervised by a check-in signal that is sent to the receiver at 70–90 minute intervals. If at least one check-in is not received from each supervised transmitter within a 12-hour period, the "missing" transmitter number(s) and "FAULT" will be displayed. The supervision for a particular transmitter in the system that may also be carried off the premises (5801, 5802MN) may be turned off by entering it as a "UR" (unsupervised RF) type, as described in the ✻56 Enhanced Zone Programming Mode section. 5800 Series transmitters have built-in tamper protection and will annunciate as a fault condition if covers are removed.

Transmitter Input Types

Each of the following transmitters has one or more unique factory-assigned input (loop) ID codes. Each of the inputs requires a programming zone be entered as one of the following types

"RF" (Supervised RF)

"UR" (Unsupervised RF)

"BR" (Unsupervised Button RF)

Transmitter Battery Life

• Batteries in the wireless transmitters may last from 4–7 years, depending on the environment, usage,

not exceed 3 feet. The 5800RL, 5802MN, 5802MN2, 5804, 5804BD, 5804BDV, 5804E, 5814, 5816TEMP, 5819, 5819S(WHS &

BRS), 5828/5828V and 5850(GBD) transmitters have not been evaluated by UL.

(e.g., a 5804's four inputs require four button zones). Transmitters can

(see transmitter’s instructions for appropriate input type):

Type Description

Sends periodic check-in signals, as well as fault, restore, and low battery signals. The transmitter must remain within the receiver's range.

Sends all the signals that the "RF" type does, but the control does not supervise the check-in signals. The transmitter may therefore be carried off-premises.

These only send fault signals. They do not send low battery signals until they are activated. The transmitter may be carried off-premises.

and the specific wireless device being used. Factors such as humidity, high or low temperatures, as well as large swings in temperature may all reduce the actual battery life in a given installation. The wireless system can identify a true low battery situation, thus allowing the dealer or user of the system time to arrange a change of battery and maintain protection for that point within the system.

- 13 -

Lynx Plus Series Installation and Setup Guide

Installing Wireless Zones

• Button-type transmitters should be periodically tested for battery life. The 5801, 5802MN, 5802MN2, 5804, 5804BD, 5804BDV, and 5804E button transmitters have replaceable batteries.

Using the Transmitter Sniffer Mode

Use this mode after all transmitters have been entered to check that all transmitters have been properly programmed.

1. Enter Installer code (4112) + [#] + 3.

Note: If the communicator is in the process of sending a report to the central station, the system will not go into the Sniffer

mode. If so, wait a few minutes and try again.

2. The keypad will display all zone numbers, which have a non-zero Zone Type (even if serial numbers were not learned yet). Fault each transmitter in turn, causing each one to send a signal. As the system receives a signal from each of the transmitters, the zone number of that transmitter will disappear from the display. The transmitters may be checked upon installation, or in an installed system.

3. When all transmitters have been checked, exit Sniffer mode. Enter Installer Code (4112) + OFF.

Notes: (1) Sniffer mode does not automatically expire. You must manually exit (Installer Code + OFF) Sniffer

(2) All BR-type units must physically be activated to clear the display, since they do not automatically send

(3) When one button of a transmitter (RF, UR, or BR) is activated, all zones assigned to other buttons on that

(4) Any transmitter that is not “entered” will not turn off its zone number. (5) For SIA installations, the following devices may be used as specified for panic (24-hour) alarm response:

mode to return to normal operation.

check-in signals.

transmitter are cleared. This also applies to 5816 and 5817 transmitters that have multiple loops (zones).

• wireless keys which have two-button panic pairs available (e.g., 5804BDV), on which only the two-button panic pairs may be programmed for any 24-hour alarm response

• wireless keypads (e.g., 5828/5828V) keypads that have a two-second delay on the special function keys, or two-button panic pairs

• built-in keypad’s two-button panic pairs

Go/No Go Test Mode

5804E encrypted (High-Security) devices must be activated while the system is in Go/No Go Test Mode. Refer to the transmitter’s installation instructions for complete details. The system will confirm enrollment of the encrypted device by beeping two times

The Go/No Go tests will verify adequate RF signal strength from the proposed transmitter location, and allow you to reorient or relocate transmitters if necessary, before mounting the transmitters permanently. This mode is similar to the transmitter Test mode, except that the wireless receiver gain is reduced. This will enable you to make sure that the RF signal from each transmitter is received with sufficient signal amplitude when the system is in the normal operating mode.

1. Enter Installer Code (4112) + [#] + 8.

2. Once you have placed transmitters in their desired locations and the approximate length of wire to be run to sensors is connected to the transmitter's screw terminals (if used), fault each transmitter.

Conducting this test with your hand wrapped around the transmitter will cause inaccurate results. On button type transmitters that have been programmed to set ARM AWAY, ARM STAY, or DISARM, press-

ing a button will take the system out of the Go/No Go Test mode causing the programmed action to occur.

Note: On button type transmitters that have been programmed to set ARM AWAY, ARM STAY, or

DISARM, pressing a button will take the system out of the Go/No Go Test mode and cause the programmed action to occur.

a. The keypad will beep three times indicating signal reception and will display the appropriate zone

number.

b. If the keypad does not beep, reorient or move the transmitter to another location. Usually a few

inches in either direction is all that is required.

3. If each transmitter produces the proper keypad response when it is faulted, you can then permanently mount each of the transmitters according to the instructions provided with them.

4. Exit the Go/No Go Test mode by entering: Installer Code (4112) + OFF.

- 14 -

Lynx Plus Series Installation and Setup Guide

Installing Wireless Zones

5800 Series Transmitter Loop Numbers (Refer to this information when programming transmitters)

The following illustration shows the compatible transmitters, their associated input types and loop

designations.

OFF

LOOP 2 (REED)

LOOP 1 (TERMINALS)

"RF"

AWAY

5878

ENROLL AS

LOOP 1 (LOW SENSITIVITY

LOOP 2 (HIGH SENSITIVITY)

LOOP 3 (TEMP)

LOOP 4 (TAMPER)

LOOP 3

LOOP 2

LOOP 1

LOOP

PROGRAM HOUSE ID

ALTERNATE

FOR LOOP 2

5821

ENROLL AS

SERIAL #1

STAY

LOOP 2

SERIAL #1

LOOP 1

SERIAL #2 LOOP 2

"BR"

LOOP 2

•

5804BD/5804BDV

ENROLL AS

"BR"

LOOP 2 (REED)

LOOP 1 (TERMINALS)

POSITION

5816MN

ENROLL AS

"RF"

A R

M E D

R E

AD Y

"RF"

5828/5828V

5890/5890PI

ENROLL AS

5800RL

SET

HOUSE ID

LOOP 4 YOU MUST ENROLL THIS BUTTON

LOOP 1

PROGRAM

HOUSE ID

LOOP 1 (MOTION)

"RF"

MIC

MESSAGE

LOOP

5800CO

ENROLL AS "RF"

5800SS1

ENROLL AS "RF"

OFF

5805-6

ENROLL AS

"BR"

LOOP 1 (TEMP SENSOR)

5816TEMP

ENROLL AS

"RF"

5849

ENROLL AS

"RF"

5808/5808LST/5808W3

LOOP 1 (SOUND)

5800Micra

ENROLL AS "RF"

5800WAVE

PROGRAM

HOUSE ID

5806/5806W3/5807

ENROLL AS

"RF"

LOOP 1 (PRIMARY)

LOOP 2 (AUX. CENTER)

LOOP 3 (AUX. RIGHT)

5817

ENROLL AS

"RF"

5850 (GBD)

ENROLL AS

LOOP 1

YOU MUST

(Green)

(Red)

(Yellow)

"RF"

LOOP 4

ENROLL

THIS

BUTTON

ENROLL AS

5818

ENROLL AS

5800PIR-RES

ENROLL AS "RF"

5801

ENROLL AS

"UR OR"RF"

5809

"RF"

LOOP 1

"RF"

5853

ENROLL AS

LOOP 1

LOOP 3

LOOP 2 LOOP 1

LOOP 1

LOOP 2

(REED)

LOOP 3

(TERMINALS)

LOOP 1

(TERMINALS)

ENROLL AS

"RF"

5800PIR-COM

ENROLL AS "RF"

5802MN

ENROLL AS

"UR" OR "RF"

5811

ENROLL AS "RF"

5819

"RF"

5870API

ENROLL AS

LOOP 1 (LOW SENSITIVITY

LOOP 2 (HIGH SENSITIVITY)

LOOP 3 (TEMP)

5800PIR/

LOOP 4 (TAMPER)

LOOP 1LOOP 1

LOOP 1

LOOP 2

(REED)

LOOP 3

(TERMINALS)

LOOP 1

(INTERNAL

SHOCK

SENSOR

5819S (WHS & BRS)

ENROLL AS

LOOP 1 (HIGH SECURITY)

LOOP 2 (STANDARD SECURITY)

LOOP 3 (TILT MODE)

LOOP 4 (TAMPER)

"RF"

5802MN2

ENROLL AS

"UR" OR "RF"

5814

ENROLL

"RF"

LOOP 4

YOU MUST

ENROLL

THIS

BUTTON

ENROLL AS

5800PIR-OD

ENROLL AS "RF"

5804/5804E

ENROLL AS "BR"

5816

5820/5820L

SERIAL #1

LOOP 3

SERIAL #1

LOOP 4

SERIAL #2

LOOP 3

5894PI

ENROLL AS

"RF"

5897

ENROLL AS

"RF"

5800-002-V0

Notes: (1) Loop 4 must be enrolled on the 5801, 5804, 5804BD, 5804BDV and 5804E transmitters, whether or not the

loop is used.

(2) 5804E encrypted (High-Security) devices must be activated while the system is in Go/No Go Test Mode. Refer

to the transmitter’s installation instructions for complete details. The system will confirm enrollment of the encrypted device by beeping two times.

(3) The 5806 smoke detector must be used in SIA applications.

The 5800PIR, 5800PIR-RES, 5800PIR-COM, 5800PIR-OD, 5800RL, 5802MN, 5802MN2, 5804, 5804BD, 5804BDV,

ULUL

5804E, 5811, 5814, 5816TEMP, 5819, 5819S(WHS & BRS), 5828/5828V, 5850(GBD) and 5870APIwireless transmitters have not been evaluated by UL.

- 15 -

Lynx Plus Series Installation and Setup Guide

Mechanics of Programming

General Programming Information

Programming options are stored in non-removable, electrically erasable, nonvolatile EEROM memory. The system can be programmed at any time, even at the installer's premises prior to the actual installation. Simply apply power temporarily to the Control and then program the unit as desired. There are four programming modes:

• Data field programming (used for setting various system options).

• Interactive menu mode programming (used for programming zone information, programming

Powerline Carrier Devices, and for entering transmitter serial numbers).

• Voice Prompt programming (used for setting various system options).

The system can also be programmed remotely, using an IBM PC compatible Personal Computer, and Compass Downloader and modem or via capable GSM or IP communications modules. See the Remote Programming/Control (Downloading) section.

Note: You may find it convenient to adjust the volume setting before entering the Program Mode. This will allow you to

clearly hear the feedback announcements or system beeps in the Programming Mode, of the system’s built-in speaker. To adjust the volume, press FUNCTION + VOLUME+ [3] or [6]. Upon exiting the Program Mode, the system will reset the volume to the default value (mid level).

Entering Program Mode

Use one of the following methods to enter Programming Mode:

1. Press both the [✻] and [#] keys at the same time, within 50 seconds after power is applied to the Control or from exiting Programming mode, OR

2. After power-up, enter the Installer Code (4112) + 800 to enter Expert Programming mode OR enter Installer Code (4112) + 888 to enter Voice Prompt Programming mode. This method is disabled if Program mode is exited using ✻98.

If a different Installer Code has been programmed, use that code to enter the Programming mode.

3. Upon entering programming mode, the control will initially display “Entering Programming Mode”.

4. Once you have entered the Program mode, data field “20 INSTALLER CODE” (the first data field in the system) will be displayed and both keypad LEDs will flash. If you have entered the Voice Prompt Programming mode. “Pro” will be displayed and the system will announce “Programming, use arrows to scroll choices. Press select to accept, press escape to quit”.

Programming a Data Field

1. Press [✻] + Field No. (for example, ✻21), followed by the required entry.

2. When you have completely programmed a data field, the keypad will “beep” three times and then automatically display the next data field in sequence. To go to a different field, press [✻] plus the desired field number.

3. If the number of digits that will be entered in a data field is less than the maximum number of digits available (e.g. phone number field), enter the desired data, then press [✻] to advance to the next data field.

4. If a nonexistent field has been entered, the keypad will display “EE Invalid Entry”. Simply re-enter [✻] plus a valid field number.

Viewing a data field (without making changes):

Enter [#] + Field No. The system will beep three times and data programmed for that field will be displayed to the

right of the field number. The system will scroll through the data for longer numbers and a beep will sound after each number is displayed or three times after the final digit is displayed.

Deleting an entry in a field

Enter [✻] + Field No. + [✻]. (Applies only to fields ✻40–✻44, ✻88 and ✻94).

- 16 -

Lynx Plus Series Installation and Setup Guide

Mechanics of Programming

Interactive Menu Mode Programming (✻56, ✻80, ✻81, ✻83, ✻84, ✻85)

[✻] + interactive mode No. (i.e., ✻56). The keypad will display the first of a series of prompts. A detailed

Press procedure (with displays of prompts) is provided in later sections of this manual.

✻

56 Enhanced Zone Programming Mode

Interactive menu mode used for programming zone attributes and report codes. Refer to the ✻56

Enhanced Zone Programming Mode section for procedure.

✻

80 Device Programming Menu Mode

Interactive menu mode for programming Powerline Carrier Devices. Refer to the ✻80 Device

Programming Menu Mode section for detailed procedure.

✻

81 Zone Lists Menu Mode

Interactive menu mode for programming zone lists for Powerline Carrier Devices. Refer to the ✻81

Zone List Menu Mode section for detailed procedure.

✻

83 Enhanced Sequential Mode

Interactive menu mode used to enter RF transmitter serial numbers. Refer to the ✻83 Enhanced

Sequential Mode section for detailed procedure.

✻

84 Assign Zone Voice Descriptors

Interactive menu mode used to assign descriptors to each zone. These descriptors will be announced

whenever the system announces an event involving a zone.

✻

85 Record Custom Voice Descriptors

Interactive menu mode used to record custom descriptors for use with each zone.

✻

96 Initialize Download ID and Subscriber Account Number for Downloading

Entering ✻96 resets all subscriber account numbers and CSID in preparation for an initial download.

Loading Factory Defaults

✻

97 To load the factory defaults, enter ✻97, then press number 1, 2, 3, or 4 to select from default tables

or press “0” if you are not selecting a default table. Refer to the Programming Default Tables section of this manual to view the tables.

If a default table is loaded, any data that has already been programmed into the system will be changed according to the default table selected!

1-4,

Exiting Program Mode

✻98 Exits program mode and inhibits re-entry into the Expert or Voice Prompt Programming modes using

the Installer Code.

✻99 Exits program mode but allows re-entry into the Expert Program mode using Installer Code (4112) +

800 or into the Voice Prompt Programming mode using Installer Code (4112) + 888.

Note: After exiting program mode (or upon power-up), the system takes up to a minute to reset. To bypass the reset

delay, press [#] + [0].

- 17 -

Lynx Plus Series Installation and Setup Guide

Zone Response Type Definitions

General Information

During programming, you must assign a zone type to each zone, which defines the way in which the system responds to faults in that zone. Zone types are defined below.

Type 00 Zone Not Used

Type 01 Entry/Exit Burglary #1

Type 02 Entry/Exit Burglary #2

Type 03 Perimeter Burglary

Type 04 Interior, Follower

Type 05 Trouble by Day/ Alarm by Night

Type 06 24-hour Silent Alarm

Type 07 24-hour Audible Alarm

Type 08 24-hour Auxiliary Alarm

Zone type 00 is used to program a zone that is not used.

Zone type 01 is usually assigned to sensors or contacts on primary entry and exit doors.

Zone Characteristics:

• Entry delay #1 is programmable (field

• Exit delay is independently programmable (field

• Exit and entry delays when armed in AWAY or STAY mode.

• No entry delay when armed in STAY NO DELAY or AWAY NO DELAY mode.

• Exit delay regardless of the arming mode selected.

Zone type 02 is usually assigned to sensors or contacts on secondary entry and exit doors that might be further from the keypad (typically used for a garage, loading dock, or basement door).

Zone Characteristics:

• Entry delay #2 is programmable from (field

• Exit delay is independently programmable from (field

• Secondary entry delay, if armed in the AWAY or STAY mode.

• No entry delay when armed in the STAY NO DELAY or AWAY NO DELAY mode.

• Exit delay begins regardless of the arming mode selected.

Zone type 03 is usually assigned to all sensors or contacts on exterior doors and windows.

Zone Characteristics:

• Instant alarm, when armed in AWAY, STAY, STAY NO DELAY, or AWAY NO DELAY mode.

Zone type 04 is usually assigned to a zone covering an entry area (i.e.: foyer, lobby, or hallway) that one must pass upon entry (after faulting the entry/exit zone) to reach the keypad. It provides an instant alarm if the entry/exit zone is not violated first, and protects an area in the event an intruder has hidden on the premises before the system is armed, or gains access to the premises through an unprotected area.

Zone Characteristics:

• Delayed alarm (using the programmed entry/exit time) if entry/exit (types 01 or 02) or interior- with-delay (type 10) zone is faulted first.

• Instant alarm in all other situations.

• Active when armed in AWAY or AWAY NO DELAY mode.

• Bypassed automatically when armed in STAY or STAY NO DELAY mode.

Zone type 05 is usually assigned to a zone that contains foil-protected doors or windows or covers a sensitive area (i.e.: stock room, drug supply room, etc.) It can also be used on a sensor or contact in an area where immediate notification of an entry is desired.

Zone Characteristics:

• Instant alarm, when armed in AWAY, STAY, STAY NO DELAY, or AWAY NO DELAY (night) mode.

• Provides a latched trouble sounding from the keypad and, if desired, a central station report during the disarmed state (day).

Zone type 06 is usually assigned to a zone containing an Emergency button (silent emergency). Zone Characteristics:

• Sends a report to the central station but provides no keypad display or sounding.

Zone type 07 is usually assigned to a zone containing an Emergency button (audible emergency).

Zone Characteristics:

• Sends a report to the central station, and provides alarm sounds externally and at the keypad.

Zone type 08 is usually assigned to a zone containing a button for use in personal emergencies or to a zone containing monitoring devices (i.e.: water or temperature sensors, etc.).

Zone Characteristics:

• Sends a report to the central station and provides an alarm sound at the keypad. (No bell output is provided and there is no keypad timeout.)

✻35).

✻34).

✻36).

✻34).

- 18 -

Lynx Plus Series Installation and Setup Guide

Zone Response Type Definitions

Type 09 Supervised Fire

Type 10 Interior with Delay

Type 14 24-hour Carbon

Monoxide Monitor

ZT16 is only available on the LynxSIA Plus version of the control panel.

Type 16 Supervised Fire with Verification

Type 20 Arm–Stay

Type 21 Arm–Away

Type 22 Disarm

Type 23 No Alarm Response

Type 24 Silent Burglary

Zone type 09 can be assigned to any wireless zone used as a fire zone. This zone type is always active and cannot be bypassed.

Zone Characteristics:

• Bell output will pulse when this zone type is alarmed.

Zone type 10 is bypassed when the panel is armed in the STAY or STAY NO DELAY mode. Zone Characteristics:

• Entry delay #1 (with programmed entry time) when armed in the AWAY mode.

• Entry delay begins whenever sensors in this zone are violated, regardless of whether an

entry/exit delay zone was tripped first.

• No entry delay when armed in the AWAY NO DELAY mode.

• Exit delay regardless of the arming mode selected.

Zone type 14 can be assigned to any wireless zone with a carbon monoxide detector. This zone type is always active and cannot be bypassed.

Zone Characteristics: Local keypad and detector will sound when this zone type is alarmed.

Zone type 16 can be assigned to any wireless zone. It can not be used with heat detectors, combination heat/smoke detectors, wireless sensors or fire pull stations. This zone type is always active and can not be bypassed.

Zone Characteristics:

• Provides a fire alarm when zone is alarmed, but only after the alarm has been verified.

• System verifies alarm by delaying reporting and control panel alarm sounding for 30 seconds

after alarm is detected. If the zone remains faulted after 30 seconds a fire alarm is provided. If any other fire zone is faulted during the 30 second delay window a fire alarm is immediately provided for that zone. An alarm for original fire zone will also be provided if that zone is still faulted afterward. If there are no fire alarms after the 30 second delay expires, the system will open a 60 second window. If any fire zone is faulted during that window a fire alarm will immediately be provided for that zone.

• Bell output will pulse following alarm verification

Zone type 20 is a special-purpose zone type used with 5800 Series wireless pushbutton units. Zone Characteristics:

• Exit delay regardless of the arming mode selected.

• System is armed in the STAY mode when the zone is activated.

• Zone number is sent to the central station as a user number when arming or disarming.

Zone type 21 is a special-purpose zone type used with 5800 Series wireless pushbutton units. Zone Characteristics:

• System is armed in the AWAY mode when the zone is activated.

• Zone number is sent to the central station as a user number when arming or disarming.

Zone type 22 is a special-purpose zone type used with 5800 series wireless pushbutton. Zone Characteristics:

• Disarms the system when the zone is activated.

Zone type 23 can be used on a zone when a Powerline Carrier Device (e.g., X10) action is desired, but with no accompanying alarm (e.g., front door light).

Zone type 24 is usually assigned sensors or contacts on exterior doors and windows where bells and/or sirens are NOT desired.

Zone Characteristics:

• Instant alarm, with NO audible indication when is armed in the AWAY, STAY, STAY NO DELAY, or AWAY NO DELAY mode.

• Report sent to the central station.

Note: The Keypad beeps if the zone is faulted when system is disarmed and Chime mode is on.

- 19 -

Lynx Plus Series Installation and Setup Guide

Data Field Descriptions

The following pages list all data fields in this Control (in numerical order). Use the blank programming form to record the data for this installation. Specific fields include options for programming that are unique to the LynxSIA Plus version. Note that both keypad LEDs flash while in Programming mode. The LynxSIA Plus version validates the data entry for the Fields listed below. If data entered is not within valid range, the control will emit a long beep indicating that entry is rejected and will substitute the default value for the invalid entry. The default value will be displayed on the keypad, and the control advance to the next field.

Field Name Default Value Valid Range

*34 Exit Delay 60 45-97 *35 Entry Delay 01 30 30-99 *36 Entry Delay 02 30 30-99 *50 Burglary Dial Delay 2 1-3 *57 False Alarm Options 7 0-7 *59 Exit Error Report Code 1 1-F *64 Test Report Code 10 10-FF *68 Cancel Report Code 10 10-FF *69 Recent Closing Report Code 1 1-F *76 Test Restore Report 10 10-FF *92 Swinger Shutdown 1 1-2

Note: Entering a number other than the one specified will give unpredictable results.

2020

INSTALLER

INSTALLER INSTALLER

2121

QUICK

QUICK QUICK

22 KKKKEY

ARM

ARMARM

22 22

EYPPPPAAAADDDD

EYEY

BBBBACKLI

22223333 FORCED

FORCED

FORCED FORCED

24 RF

RF RF

BYPASS

2424 HOUSE

HOUSE

HOUSEHOUSE

CODE

CODECODE

ENABLE

ENABLEENABLE

ACKLIGHT

GHT

ACKLIACKLI

GHTGHT

BYPASS

BYPASS BYPASS

CODE

ID ID

CODE CODE

Installer Code

The Installer Code is used to enter the 4-digit Master Security Code. See "Master Code" in the System Operation section for procedure.

Note: LynxSIA Plus does not allow duplication of Installer code. If a duplicate code is

entered the entry is rejected and LYNX issues single long beep indicating rejection. The old installer code remains unchanged.

SELECTIONS

Enter 4 digits (0-9)

Quick Arm Enable

If enabled, security code is not required to arm the system. The user simply presses and holds down the AWAY or STAY key to arm.

SELECTIONS

0 = do not allow quick arm 1 = allow quick arm

Keypad Backlight Timeout

This option allows the choice of either always backlighting the keypad or turning the backlighting off after 10 seconds of keypad inactivity.

SELECTIONS

0 = no timeout; always backlight keys 1 = turn backlighting off after inactivity

Forced Bypass

All zones bypassed by this function will be displayed after the bypass is initiated.

UL installations: must be 0 (no forced bypass)

SELECTIONS

0 = no forced bypass 1 = provide automatic bypass of all open (faulted) zones

RF House ID Code

The House ID identifies receivers and wireless keypads. If a 5804BD/5804BDV Transmitter is to be used, a House ID Code MUST be entered, and the keypad should be set to the same ID.

SELECTIONS

00 = disable all wireless keypad usage 01-31 = House ID

- 20 -

Lynx Plus Series Installation and Setup Guide

2525

X10

HOUSE

X10X10

HOUSE HOUSE

2626

CHIME

CHIME CHIME

2727

CLOCK

CLOCK CLOCK

2929

DST

MNTH

DST DST

MNTH MNTH

3030

DST

WEEK

DST DST

WEEK WEEK

3131

SINGLE

SINGLE SINGLE

3232

FIRE

SND

FIREFIRE

SND SND

CODE

CODE CODE

ZONE

BY BY

ZONEZONE

DISPLAY

DISPLAYDISPLAY

STR

STR/END

STRSTR

STR

STR/END

STRSTR

ALARM

ALARM ALARM

TTTTIMEOUT

IMEOUT

IMEOUTIMEOUT

END

ENDEND

END

ENDEND

SND

SNDSND

Data Field Descriptions

Powerline Carrier Device (X10) House ID

Powerline Carrier Devices require a House ID. This field identifies this House ID to the Control. The Powerline Carrier Devices are programmed in field ✻80.

SELECTIONS

0 = A 3 = D 6 = G 9 = J # + 12 = M # + 15 = P 1 = B 4 = E 7 = H # + 10 = K # + 13 = N 2 = C 5 = F 8 = I # + 11 = L # + 14 = O

Chime by Zone

This option allows the installer to define the specific zones intended to chime when faulted while the system is in Chime mode. If enabled, these zones are defined in zone list 3 (see ✻81 Zone List Menu Mode).

SELECTIONS

0 = no (chimes on fault of any entry/exit or perimeter zone when Chime mode is activated) 1 = yes (chimes on fault of those zones assigned to Zone List 3 when Chime mode on)

Real Time Clock Display

Refer to the User’s Manual for setting the clock time and date.

SELECTIONS

0 = do not display the time 1 = display the time

Daylight Savings Time Start/End Month

Enter # + 10 for 10, # + 11 for 11, and # + 12 for 12.

SELECTIONS

0 = do not display the time 1 = display the time

Daylight Savings Time Start/End Month

Enter the appropriate start and end weekend of the month.

SELECTIONS

0 = disable 4 = fourth weekend 1 = first weekend of month 5 = last weekend 2 = second weekend 6 = next to last 3 = third weekend 7 = 3rd from last

Single Alarm sounding Per Zone (per armed period)

This field applies only to burglary zones (zone response types 1-5, 10), and affects long range radio reporting but does not affect central station reporting. It applies only to the bell and does not affect keypad sounds.

UL installations: must be 0 (no limit)

Lynx Plus SELECTIONS

0 = no limit on alarm sounding per zone 1 = limit alarm sounding to once per arming period for a given zone

LynxSIA Plus SELECTIONS

0 = alarm sounding per zone will be the same as Swinger Shutdown set in field ✻92 1 = limit alarm sounding to once per arming period for a given zone

Sounder Timeout

This Control complies with NFPA requirements for temporal pulse sounding of fire and carbon monoxide (CO) notification appliances. Temporal pulse sounding for a fire alarm consists of the following: 3 pulses – pause – 3 pulses – pause – 3 pulses. . .

Temporal pulse sounding for a CO alarm consists of the following: 4 pulses – pause – 4 pulses – pause – 4 pulses –pause. . .

SELECTIONS

0 = yes, sounder timeout after time programmed in field ✻33 1 = no sounder timeout; continue sounding until manually turned off

- 21 -

Lynx Plus Series Installation and Setup Guide

Data Field Descriptions

3333

ALRM

SND

TIMEOUT

SND SND

DELAY

DELAYDELAY

DELAY

DELAYDELAY

DELAY

DELAY DELAY

TIMEOUT

TIMEOUTTIMEOUT

TIME

TIMETIME

1111

2222

ALRM ALRM

Fields ✻34–✻36: Fields *34, *35 and *36 are used to program different options in the Lynx Plus and LynxSIA Plus

controls. Please be sure that you use the correct field for the control being installed.

Note: The LynxSIA Plus control validates the data entered in fields *34 - *36. If the selection is not valid the control will emit a

single long beep indicating that the selection has been rejected. The control replaces the selection with the default value which is displayed on the keypad and advances to the next field.

34 34

EXIT

DELAY

EXIT EXIT

3535

ENTRY

ENTRY ENTRY

36 36

ENTRY

ENTRY ENTRY

Alarm Bell Timeout

This field determines whether the external sounder will shut off after a selected time, or allowed to continue until manually turned off.

UL installations: must be set for a minimum of 4 min (option 1) SELECTIONS

0 = No timeout 2 = 8 minutes 4 = 16 minutes 1 = 4 minutes 3 = 12 minutes

Exit Delay

The system will wait the time entered before sounding an alarm if the exit door is left open after the system has been armed.

UL installations: Exit Delay must be set for a maximum of 60 seconds SIA: Exit Delay must be set to a minimum of 45 seconds.

Lynx Plus SELECTIONS LynxSIA Plus SELECTIONS (Entries from 45-97)

00-99 = exit delay in seconds

45-96

Entry Delay 01

The system will wait the time entered before sounding alarm upon entering if system is not disarmed.

UL installations: The Entry Delay must be set for a maximum of 45 seconds SIA The Entry delay must be set to a minimum of 30 seconds. The sum of entry delay 1,

entered in Field ✻35, and the burglary abort window, entered in Field ✻50, should not exceed 1 minute.

Lynx Plus SELECTIONS LynxSIA Plus SELECTIONS (Entries from 30-99)

00-99 = entry delay in seconds

30-96

Entry Delay 02

The system will wait the time entered before sounding alarm upon entering if the system is not disarmed.

UL installations: must be set for a maximum of 45 seconds SIA The Entry delay must be set to a minimum of 30 seconds. The sum of entry delay 2

entered in Field ✻36 and the burglary abort window entered in ✻50 should not exceed 1 minute.

Lynx Plus SELECTIONS LynxSIA Plus SELECTIONS (Entries from 30-99)

00-99 = entry delay in seconds

30-96

Entered Value Exit Delay in Seconds

45-96

Entered Value Entry Delay in Seconds

97 98 99

Entered Value Entry Delay in Seconds

97 98 99

120

30-96 120 180 240

- 22 -

Lynx Plus Series Installation and Setup Guide

Data Field Descriptions

Field ✻37-✻39: Field ✻37 is not available on the LynxSIA Plus control. Fields ✻38 and ✻39 are used to program

different features in the Lynx Plus and LynxSIA Plus controls. Please be sure that you use the correct field for the control being installed.

3737

EXIIIIT

SND

SND////QQQQK

EXEX

T T

SNDSND

38 38

CONF

ARM

CONF CONF

(This field applies only to the

Lynx Plus control)

39 39

PWR

PWR PWR

UP UP

K K

ARMING

ING

ARMARM

INGING

PRV

PRV PRV

EXIT

EXITEXIT

DING

DINGDING

STATE

STATESTATE

Audible Exit Warning/Quick Exit

Audible Exit Warning: Sound consists of slow continuous beeps until last 5 seconds, when it changes to fast beeps. The warning sound will end at the termination of exit delay.

Quick Exit: If enabled, the user can restart the exit delay time after arming in STAY mode by entering the User Code and pressing the STAY key, or by pressing the STAY key if Quick Arm is enabled. This avoids having the user disarm then re-arm the system after allowing someone to enter or exit.

SELECTIONS Exit Warning Quick Exit

0 = no exit warning sound 0 = no quick exit 1 = provide exit warning sound when armed AWAY 1 = allow quick exit

Confirmation of Arming Ding

Lynx Plus - Confirmation of arming is provided by a 1/2 second external sounder “ding”

that sounds when closing report is sent, or at the end of exit delay. If Option 2 is selected the external sounder “ding” occurs immediately after the system receives the RF transmission.

LynxSIA Plus - Confirmation of arming is provided by a 1/2 second external sounder “ding”. The ding only sounds when control is Armed Away or disarmed after being Armed Away.

If Option 1 is selected, confirmation of arming is provided by a 1/2 second sounder “ding” that sounds when closing report is sent, or at the end of exit delay. If Option 2 is selected the external sounder “ding” occurs immediately after arming from an RF keypad.

Note: If LynxSIA Plus is armed by RF button (key fob), a confirmation ding occurs

immediately after arming regardless of field *38 settings. If control is disarmed by RF button, an additional disarming confirmation ding is provided. The ding occurs immediately after disarming and is longer than arming confirmation ding.

Lynx Plus SELECTIONS

0 = no ding 1 = confirmation ding after arming

system

2 = confirmation ding after arming from

RF button or RF keypad only

Power Up In Previous State (This field applies only to the Lynx Plus control)

When the system powers up armed, an alarm will occur 1 minute after arming if a zone is faulted, and any bypassed zones will be unbypassed.

Note: If the previous state was Armed Away or Stay, the system will not respond to sensor

changes for 1 minute. This allows time for sensors such as PIRs to stabilize.

UL installations: must be 1 (power up in previous state)

Lynx Plus SELECTIONS

0 = always power up in a disarmed state 1 = assume the system status prior to power-down

LynxSIA Plus SELECTIONS

0 = no arming confirmation ding after arming

system by Lynx Plus keypad or RF keypad

1 = arming confirmation ding after arming

system by Lynx Plus keypad or RF keypad

2 = arming confirmation ding after arming

from RF keypad only

- 23 -

Lynx Plus Series Installation and Setup Guide

Data Field Descriptions

3939

CROSS

CROSS CROSS

(This field applies only to the

LynxSIA Plus control)

DIALER PROGRAMMING (✻40–✻50) Fields ✻40, ✻41, ✻42: Enter up to the number of digits shown. Enter 0–9, # + 11 for ‘✻’; # + 12 for ‘#’; # + 13

for a pause controls. Please be sure that you use the correct field for the control being installed.

Notes: Whenever AAV is used, primary (Field ✻41) and secondary (Field ✻42) phone numbers should be preceded with the

40 PABX

PABX

PABX PABX

(This field applies only to

the Lynx Plus control)

40 PABX

PABX ACCESS CODE

PABX PABX

(This field applies only to

the LynxSIA Plus control)

ZONE

TIMER

call waiting disable command. Otherwise, there is the possibility of connection of the third party to Lynx Plus Series during AAV mode. The with AAV). However, it is used for dialing on Telco Line.

40 40

ACCESS

ACCESS ACCESS

4040

ACCESS CODE

ACCESS CODE ACCESS CODE

TIMER

ZONE ZONE

TIMERTIMER

(2 seconds).

CODE

CODECODE

Cross Zone Timer (This field applies only to the LynxSIA Plus control)

Sets the maximum amount of time in which two cross zones must be tripped in an armed system to send an alarm message to the Central Station. If only one cross zone is tripped during this time, a trouble message (CID code 380) for that zone is sent to the Central Station. Program Zone list 2 (using *81 Zone List Menu Mode) with the two zones that are to be cross zoned.

Notes: (1) If option ✻39 is set to “0” (no cross zoning), Zone List 2 can be used for other

purposes.

(2) Cross zoning will be disabled during entry and exit delays, if one or both of the 2

cross zones is bypassed and there is already an alarm in the system.

If one of the 2 cross zones faults and remains faulted after the cross zone time

interval, the second cross zone can go into alarm immediately, even after the cross zone time. This is to detect scenarios involving multiple break-ins of a premises.

UL This option is not for use in UL installations.

LynxSIA Plus SELECTIONS

Value Time Window Value Time Window

0 = No Cross Zoning 8 = 2 minutes 1 = 15 seconds 9 = 2 minute, 15 seconds 2 = 30 seconds # + 10 = 2 minute, 30 seconds 3 = 45 seconds # + 11 = 2 minute, 45 seconds 4 = 60 seconds # + 12 = 3 minutes 5 = 1 minute, 15 seconds # + 13 = 3 minute, 15 seconds 6 = 1 minute, 30 seconds # + 14 = 3 minute, 30 seconds 7 = 1 minute, 45 seconds # + 15 = 3 minute, 45 seconds

✻

Field

40 is used to program different features in the Lynx Plus and LynxSIA Plus

PABX phone number entered in field ✻40 is not dialed on GSM/IP (Digital Communication

PABX Access Code (This field applies only to the Lynx Plus control.)

If fewer than 6 digits will be entered, exit by pressing [✻]. To clear entries, press ✻40✻.

Lynx Plus SELECTIONS

PABX Access Code

Enter up to 6 digits if PABX is needed to access an outside line.

PABX Access Code/Call Waiting Disable (This field applies only to the LynxSIA Plus

control)

If fewer than 6 digits need to be entered, exit by pressing [✻]. To clear entries from field, press ✻40✻. If the subscriber does not have “call waiting” and is not using PABX, make no entry in this field.

Call Waiting: If the subscriber’s phone service has “call waiting” (and is not using PABX), enter the touch-tone sequence“✻70” (or similar depending on the phone service). By programming “# + 11 + 7 + 0” as the PABX entry to disable “call waiting” during control panel calls. You must also enable the Call Waiting Cancel option in field ✻47.

Important Note: If Call Wait Cancel is disabled in Field ✻47, and Call Wait Disable command is entered in Field ✻40, this will prevent successful communication to the central station when used on a non-call waiting line.

Note: PABX number and operation of the control panel with a PBX system cannot be used

LynxSIA Plus SELECTIONS

PABX Access Code/Call Waiting Disable

Enter up to 6 digits if PABX is needed to access an outside line. OR Enter“# + 11+ 7+ 0” to program touch-tone sequence “✻70” and cancel call waiting.

if the Call Waiting Cancel Disable option has been enabled in Field ✻47.

- 24 -

Lynx Plus Series Installation and Setup Guide

Data Field Descriptions

If the LRR/IP (Digital Communication with AAV) feature is used (options 5 in ✻55), there may be restrictions when dialing the numbers entered in be dialed, etc) depending on the service provider.

41 41

PRIMARY

PRIMARY PRIMARY

TEL

TEL TEL

NUM

NUM NUM

42 42

SECOND

SECOND SECOND

TEL

TEL TEL

NUM

NUMNUM

All four digits of the Subscriber Account number must be entered in Fields ✻43 and ✻44. If ten-digit format is selected in ✻48 (option 5), all ten digits of the Subscriber Account number must be entered.

Fields ✻43 and ✻44:

Enter [✻] as the fourth digit if a 3-digit account number (for 3+1 dialer reporting format) is used. Enter 0 as the first digit of a 4-digit account number for Nos. 0000–0999. Enter [ number (for 4+1, 4+2 CID®) is used. Exit field by pressing [ Programming Form for examples of account number entries. Enter digits 0–9; # +11=B; # +12=C; # +13=D; # +14=E; or # +15=F.

4343

PRIMARY

PRIMARYPRIMARY

44 44

SECNDRY

SECNDRY ACCOUNT

SECNDRY SECNDRY

ACC

ACCOUN

OUNTTTT#

ACCACC

OUNOUN

ACCOUNT#

ACCOUNTACCOUNT

✻41, ✻42 and ✻46 (i.e.; #, ✻, pause may not be allowed, or phone number extensions may not

Primary Phone Number

Enter the Primary Phone Number If fewer than 20 digits entered, exit by pressing [✻]. To clear entries from field, press

✻41✻.

Note: Backup reporting (8 attempts are made to the secondary phone number if no kissoff

is received after 8 attempts to the primary number) is automatic only if there is a secondary phone number (field ✻42).

SELECTIONS

Enter up to 20 digits.

Secondary Phone Number

Enter the Primary Phone Number If fewer than 24 digits entered, exit by pressing [✻]. To clear entries from field, press

✻42✻. See backup reporting note for field ✻41.

SELECTIONS

Enter up to 24 digits.

Primary Subscriber Account Number

Enter the primary subscriber account number. To clear entries from field, press ✻43✻.

SELECTIONS

Enter a 4 or 10- digit account number

Secondary Subscriber Account Number

Enter the primary subscriber account number. To clear entries from field, press ✻44✻.

SELECTIONS

Enter a 4 or 10- digit account number

✻] as the fifth digit if a 4-digit account

✻] if only 3 digits are used. See blank

Field ✻46: Enter up to 24 digits. Do not fill unused spaces. Enter 0-9, #+11 for ‘✻’; #+12 for’#’; #+13 for a pause (2 seconds).

46 46

FOLLOWFOLLOW

ME ME

PHONE

PHONEPHONE

“Follow Me Reminder” Phone Number

This option allows the user to schedule a time driven message. When activated the system will dial the phone number programmed and deliver a voice message (custom

words 72, 73 and 74). This option is only supported when the follow me feature is enabled in field ✻49 (option 6-9 or 10-13).

If using the Follow Me Reminder feature, enter the phone number here. If fewer than 24 digits are entered, exit by pressing [✻]. To clear entries from the field press ✻46✻.

The telephone message can be terminated (acknowledged) by pressing any key on the telephone keypad. Pressing any key on the local Lynx Plus Series keypad will terminate (acknowledge) both the follow me and the local reminder announcements.

Note: The follow me reminder announcement will be terminated if any other event requires

the system to dial out or if an audible alarm has occurred.

SELECTIONS

Enter up to 24 digits.

- 25 -

+ 55 hidden pages
