Additel 928
Hydraulic Pressure Test Pump

Pressurize large-volume workload
Generate to 15,000 psi (1,000 bar) pressure
Portable only 8.6 lbs (3.9 kg)
Increase and decrease pressure smoothly
Hand-tight quick connectors

Pressure / Process Calibration EquipmentAdditel Datasheet 2015

OVERVIEW

The Additel 928 Hydraulic Pressure Test Pump is a hand operated pressure pump designed to generate pressure to
15,000 psi (1,000 bar). This pump incorporates a dual-piston system which is ideal for filling large volume workload

with the hand pump and providing smooth increase and decrease of pressure with the ne adjustment. The 928 Test

Pump incorporates an isolation valve which isolates the calibration volume from the check valve associated with the
hand pump. Because the check valve can often be a source of leaks and maintenance, the isolation valve provides
more stable measurements and reduces potential maintenance of the pump. Two hand-tight quick connectors installed
on the pump allow easy connecting and disconnecting to the test pump without the need for PTFE tape or wrenches.
The Additel 928 is an ideal comparison test pump for calibrating pressure measuring instruments such as test gauges,

indicators or transducers in the eld or laboratory.

FEATURES

Hand pump to fill large volume systems

Portable at 8.6 lbs (3.9 kg)

Durable and minimal maintenance

Isolation valve provides stable pressures while
reducing maintenance on the hand pump check valve

Easy to use

15,000 psi (1,000 bar) can be generated easily with
the dual-piston system

Hand-tight quick connectors

Allows easy connection and disconnection to the test
pump without the need for PTFE tape or wrenches

ORDERING INFORMATION

Model Number

ADT928 N

Model

Accessories included

9202 Mineral oil,1 bottle (250 ml)*
O-ring: 20 pcs
Manual: 1 pc

* When water media is not requested

Pressure port type:

N-

NPT female

1/4

N2-1/2NPT female
B-1/4BSP female
M-M20X1.5 female

SPECIFICATIONS

Media: Mineral oil or deionized water.

liquid. Pump with water as media to be ordered specically)

Generated Pressure Range

0 to 15,000 psi (1,000bar) gauge pressure

Material: Ram/adapters: SS
Body: SS/aluminum/Copper
Seals: Buna-N

Connection

Hand-tight connectors for both test gauge and
reference gauge.
Test Gauge Connection: 1/4NPT female, 1/4BSP
female, or M20X1.5 female
Reference Gauge Connection: 1/4NPT female,
1/4BSP female, or M20X1.5 female

Dimensions: Height: 6.38'' (162 mm)
Base: 13.58'' (345 mm) x 8.46'' (215 mm)

Weight: 8.6 lb (3.9 kg)

Warranty: 1 year

Piston Volume: Fine adjust piston: 0.9ml (0.05 in

Optional Accessories

Model number Description

9202 Oil, Mineral oil, 1 liter (1 quart)

ADT102

ADT103

ADT100-HTK

9904-928 Carrying Case for one 928 pump and two pressure test gauges

ADT928-MK Maintenance kit for Additel 928 pump

ADT100-928-HK Hose Kit, External Reservoir Expansion Hose Kit for ADT928

Adapters and ttings, 1/4NPT male to various male and female connection

(25 pcs). More information shown on page 53.

Adapters and ttings, 1/4NPT (1/4BSP, or M20X1.5) male to various

female hand-tight quick connectors (10 pcs). More information shown on
page 54.

Hose test kit, 5 feet exible hose, 15,000 psi, 1/4NPT male to 1/4NPT

(1/8NPT, 1/2NPT, 1/4BSP, or M20X1.5) female hand-tight quick
connector. More information shown on page 55.

(Oil is default media

3

)
