ADC WDA-540, AD-295, AD-26, AD-540 User Manual
PHASE 5
COIN
USER’S MANUAL
American Dryer Corporation
88 Currant Road
Fall River MA 02720-4781 USA
T elephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447
e-mail: techsupport@amdry.com
www.amdry.com
ADC Part No. 112146-56
Retain This Manual In A Safe Place For
Future Reference
Please read this manual carefully to thoroughly familiarize yourself with the Phase 5 Coin computer system
features, operational instructions, and programming characteristics. This manual contains important
information on how to use ALL the features of your new ADC dryer in the safest and fastest way .
American Dryer Corporation products embody advanced concepts in engineering, design, and safety . If
this product is properly maintained, it will provide many years of safe, efficient, and trouble free operation.
W e have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the
right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and
material, and to change or discontinue models.
!
▲ WARNING
Proposition 65
Use of this product could expose you to substances
from fuel combustion that contain chemicals known
to the State of California to cause cancer, birth defects
and other reproductive harm.
“IMPORT ANT NOTE TO PURCHASER”
Information must be obtained from your local gas supplier on the
instructions to be followed if the user smells gas. These instructions
must be posted in a prominent location near the dryer.
Table Of Contents
SECTION I
INTRODUCTION.......................................................................................................4
Phase 5 Coin Microprocessor Controller (Computer) Features.......................................................... 4
SECTION II
L.E.D. DISPLAY AND CODES................................................................................. 8
SECTION III
OPERATING INSTRUCTIONS .............................................................................10
A. Timed Mode............................................................................................................................. 10
B. Automatic Mode (Patent No. 4,827,627) ................................................................................. 1 1
C. Free Dry Mode ........................................................................................................................ 12
SECTION IV
PROGRAM SELECTION ....................................................................................... 13
T emperature Display Mode............................................................................................................. 13
Right Coin Count (rCC)/Left Coin Count (LCC) ............................................................................. 13
Automatic Review of Program Location .......................................................................................... 14
PL01 - T emperature Conversion Status........................................................................................... 15
Automatic Mode (Auto) Patent No. 4,827,627 ............................................................................... 15
Timed Mode (tInE) ......................................................................................................................... 15
Anti-Wrinkle Program (Grd) ........................................................................................................... 16
Buzz/T one (bUZ) ............................................................................................................................ 16
Free Dry Mode Cycle (FrEE) ......................................................................................................... 16
Coin Mode (Coin) .......................................................................................................................... 17
Flash Display Status (FLS) ............................................................................................................. 17
Bad Coin Lockout Status (bCLO) ..................................................................................................17
Bad Coin Reset (bCrS) .................................................................................................................. 17
Accumulative Time (AtIn) ............................................................................................................... 18
Accumulative Coin (ACOn) ............................................................................................................ 20
Rotational Safe Guard - OPTIONAL (nSEn) .................................................................................. 21
PL02 - Percent Dry (PdrY) ............................................................................................................ 21
PL03 - High T emperature (HI° F) ................................................................................................... 21
PL04 - High Cool Down T emperature/Time (HIcd)......................................................................... 22
PL05 - Low T emperature (LO° F)..................................................................................................22
PL06 - Low Cool Down T emperature/Time (LOcd)........................................................................ 22
PL07 - Permanent Press (PP° F) .................................................................................................... 22
PL08 - Permanent Press Cool Down T emperature /Time (PPCd) .................................................... 22
PL09 - Left Coin Slot Denomination (LCdE) .................................................................................. 22
PL10 - Right Coin Slot Denomination (rCdE).................................................................................. 23
PL11 - T ime For Amount To Start (tF AS) ....................................................................................... 23
PL12 - Amount T o Start (AtSt)....................................................................................................... 23
PL13 - Minimum Amount For Additional Time (AF AT).................................................................... 23
PL14 - Maximum Time For Automatic Dry (Adrt) ........................................................................... 23
PL15 - Anti-Wrinkle T iming ............................................................................................................ 24
Guard Delay Time (GdL Y).............................................................................................................. 24
Guard On Time (Gont).................................................................................................................... 24
PL16 - Active Guard Time (AGt).................................................................................................... 24
PL17 - “A” and “b” Factors ........................................................................................................... 24
SECTION V
PROGRAMMING INSTRUCTIONS ....................................................................25
A. Introduction To Programming.................................................................................................... 25
B. Programming (Flowcharts) ........................................................................................................ 26
SECTION VI
PROGRAMMING ....................................................................................................29
A. T emperature Display Mode....................................................................................................... 29
B. Left Coin Count ........................................................................................................................ 30
C. Right Coin Count ...................................................................................................................... 31
D. Program Location 01 (PL01).................................................................................................... 32
E. Program Location 02 (PL02) .................................................................................................... 36
F. Program Location 03 (PL03) .................................................................................................... 37
G. Program Location 04 (PL04) .................................................................................................... 38
H. Program Location 05 (PL05).................................................................................................... 39
I. Program Location 06 (PL06) .................................................................................................... 40
J. Program Location 07 (PL07) .................................................................................................... 41
K. Program Location 08 (PL08).................................................................................................... 42
L. Program Location 09 (PL09) .................................................................................................... 43
M. Program Location 10 (PL10) .................................................................................................... 44
N. Program Location 11 (PL1 1) .................................................................................................... 45
O. Program Location 12 (PL12).................................................................................................... 46
P . Program Location 13 (PL13) .................................................................................................... 47
Q. Program Location 14 (PL14).................................................................................................... 48
R. Program Location 15 (PL15) .................................................................................................... 49
S. Program Location 16 (PL16) and Program Location 17 (PL17) ................................................ 50
SECTION VII
FACTORY PRESET PROGRAMS/PARAMETERS ..........................................51
A. Single Coin Only
For all dryer models except AD-26/AD-295 and AD-540/WDA-540....................................... 52
B. Dual Coin Only
For all dryer models except AD-26/AD-295 and AD-540/WDA-540....................................... 53
C. Single Coin Only
For dryer models AD-26/AD-295 Only .................................................................................... 54
D. Dual Coin Only
For dryer models AD-26/AD-295 Only .................................................................................... 55
SECTION VIII
PHASE 5 COIN SYSTEM DIAGNOSTICS ......................................................... 5 6
A. Diagnostic (L.E.D) Failure Codes ............................................................................................. 56
1. “door” .................................................................................................................................. 56
2. “dSFL” ................................................................................................................................56
3. “SEFL” ................................................................................................................................57
4. “Hot” ................................................................................................................................... 57
B. L.E.D. Display Indicators/Dots ................................................................................................. 57
1. Heat Circuit Indicator ........................................................................................................... 57
2. Motor Circuit Indicator ......................................................................................................... 57
C. Phase 5 Microprocessor Controller (Computer) Relay Output L.E.D. Indicators........................ 58
1. “DOOR” .............................................................................................................................. 58
2. “HEA T”................................................................................................................................59
3. “MTR” (motor) .................................................................................................................... 59
SECTION IX
PHASE 5 AUTO CYCLE (PATENT NO. 4,827,267)
“A” AND “B” FACTOR PARAMETERS............................................................. 6 0
SECTION X
OPTIONAL 9 VOLT BATTERY BACKUP...........................................................6 2
SECTION I
INTRODUCTION
The Phase 5 Coin Computer System is a fully programmable, highly sophisticated dryer control system.
American Dryer Corporation has designed the Phase 5 coin microprocessor controller (computer) to be the
most versatile and reliable coin-operated control system available.
To eliminate as many moving parts as possible, ALL Phase 5 coin microprocessor controller (computer)
programming is done through the membrane switch on the front of the control panel. The Program Switch (PS)
that puts microprocessor controller (computer) into the program mode is a single program switch. This program
switch eliminates the possibility of switch failure due to an accumulation of lint or moisture.
Phase 5 Coin Microprocessor Controller (Computer) Features
AUTOMATIC PROGRAM REVIEW
In the program mode, the Phase 5 coin microprocessor controller (computer) will show ALL settings by one (1)
touch of the low temperature keyboard (touch pad) selection.
PROGRAMMABLE
Changes in the programs are made at the temperature keyboard (touch pad) selection and actual programs are
displayed for verification.
ADJUSTABLE TIME
Programmable from a minimum of 1 minute to a maximum of 99 minutes in 1 minute increments.
COIN ACCEPTOR DENOMINA TIONS
Values of coin acceptors are programmable from a minimum of 1 to a maximum value of 9999 for any U.S. or
foreign coin denomination.
AMOUNT TO ST ART
Programmable from a minimum value 1 to a maximum value of 9999 in increments of one (1).
ACCUMULA TIVE TIME
This program yields a specific value of time for any coin entry made after the “Amount To Start” has been
inserted.
4
TIME FOR AMOUNT TO START
This program retains the time the owner wishes to vend. The feature allows any additional purchase that is
made to be calculated to the second. There is no calculation necessary by the owner. The Phase 5 coin
microprocessor controller (computer) calculates the vended time.
ACCUMULA TIVE COIN
This program selection requires that a specific value of coin(s) be inserted for additional time, programmable for
any minimum amount.
COIN COUNT
The number of coins inserted, including a separate display program for optional dual coin acceptors, can be
viewed through the Phase 5 computer’s light emitting diode (L.E.D.) display .
BAD COIN LOCKOUT
Each coin is monitored. Should someone tamper with the coin acceptor or attempt to insert a foreign object, the
microprocessor controller (computer) will “LOCKOUT” and will not accept any entries until the reset time has
elapsed (approximately 15-seconds). Once the reset time has expired, the microprocessor controller (computer)
will automatically reset itself for the next coin entry .
TEMPERATURE CONVERSION
When the temperature conversion status is changed (i.e. from °F to °C), the Phase 5 coin microprocessor
controller (computer) will automatically convert ALL temperature related programs/parameters from Fahrenheit
to Celsius and vice versa. The Phase 5 coin microprocessor controller (computer) will perform this conversion
within 1° F (2° C). The programs affected are:
1. Temperature Display Mode
2. Temperature Selections
3. Cool Down Temperatures
DRYING TEMPERATURES
Any of the three (3) temperature selections (HI/LO/PP) are programmable from a minimum of 100° F to a
maximum of 190° F in ten-degree increments or from a minimum of 38° C to a maximum of 88° C in five-degree
increments. Actual temperature programs are displayed at time of programming for verification.
For the AD-26 and AD-295 any three (3) of the selections (HI/LO/PP) are programmable from a minimum of
100° F to a maximum of 170° F in ten-degree increments, or from a minimum of 38° C to a maximum of 77° C
in five-degree increments.
For the AD-540 and WDA-540 any three (3) of the selections (HI/LO/PP) are programmable from a minimum
of 100° F to a maximum of 160° F in ten-degree increments or from a minimum of 38° C to a maximum of 71°
C in five-degree increments.
5
COOL DOWN TIME
ALL three (3) temperature selections are programmable from a minimum of 0 minutes to a maximum of 9
minutes in 1 minute increments.
COOL DOWN TEMPERATURES
In the automatic or free dry modes, the cool down cycle termination is programmable from a minimum of 70° F
to a maximum of 190° F in ten-degree increments or from a minimum of 21° C to a maximum of 88° C
five-degree increments.
in
AUTOMATIC MODE (Patent No. 4,827,627)
This program selection uses ADC’s patented Auto-Dry cycle. The microprocessor controller (computer) will
calculate the percent of the dryness and read “donE” when complete. The Phase 5 coin microprocessor
controller (computer) can be programmed to have a maximum time for the “Auto Mode.” The Automatic Cycle
(mode) can be used in either the “Free Dry” Mode or the “Coin” Mode.
ANTI-WRINKLE
This program selection helps keep permanent press items wrinkle free when they are not removed from the
dryer promptly at the end of the drying and cooling cycles. The Anti-W rinkle program settings are:
1. Guard Delay Time ...................... 1 to 9 minutes
2. Guard On Time........................... 1 to 99-seconds
3. Active Guard Time ..................... 1 to 99 minutes
FREE DRY MODE
In this program selection, the dryer can be started without the insertion of coins by simply pressing any one of the
three (3) temperature selections. When set in the “Free Dry” Mode, the Phase 5 coin microprocessor controller
(computer) can also be programmed to run with an Automatic Cycle (percent of dryness) or with a Timed Cycle.
If the “Free Dry” program is utilized, the computer’s light emitting diode (L.E.D.) display will cycle back and
forth between “FILL” to “FrEE,” unless otherwise programmed.
L.E.D. FLASH DISPLA Y
Programmable to allow the L.E.D. readout to display a choice of “FILL” (no cycle in progress), “Amount To
Start” (i.e., 25¢), or, in the case of free dry, “FrEE.” This program selection also allows the L.E.D. display to
flash back and forth every 2-seconds from “FILL” to “Amount T o Start” or , in the case of free dry, from “FILL”
to “FrEE.”
AUDIBLE TONE
In this program selection, a tone (buzzer) will sound for each coin inserted, program entry , or at the drying and
cooling cycles for a period of 5-seconds to indicate that the cycle is complete. Additionally, when in the
Anti-Wrinkle program, the tone (buzzer) will sound for 5-seconds at the end of the “Guard On Time.”
6
TEMPERATURE DISPLA Y
This program selection enables the temperature in the dryer to be viewed (°F or °C) either while the dryer is off
or running. This service feature shows that the dryer is maintaining the selected temperature.
DIAGNOSTICS
ALL major circuits, including door, microprocessor temperature sensor , heat, and motor circuits are monitored.
There are also indicators installed on the outputs of each relay to easily identify failures, and the door switch has
an indicator installed on the Phase 5 microprocessor controller (computer) to help indicate failure.
AUTOMATIC DRY TIME
This program selection allows the dryer to run up to a specific time. During the “AUtO” mode or “FrEE” dry
mode this program is only designed to limit the dryer’s operation during the drying cycle.
ROTATIONAL SAFE GUARD (Optional)
This program monitors the rotation of the basket (tumbler). If the basket (tumbler) is not rotating, the Phase 5
coin microprocessor controller (computer) will disable ALL outputs, an audible tone (buzzer) will sound, and an
error message will be displayed. This program selection can be programmed to be in the inactive mode.
BA TTER Y BACKUP (Optional)
This feature allows the Phase 5 coin microprocessor controller (computer) to maintain its operating status should
a momentary power interruption occur while the dryer cycle is in progress.
7
SECTION II
L.E.D. DISPLAY AND CODES
A Automatic Cycle (Slope Program Factor)
ACOn Accumulative Coin
Adrt Maximum Auto Dryness Time
AF At Amount for Additional Time
AGt Active Anti-Wrinkle Guard Time
AtIn Accumulative Time
AtSt Amount To Start
AUtO Automatic Mode (Patent No. 4,827,627)
b Automatic Cycle (Heat Loss [offset] Factor)
bCLO Bad Coin Lockout
bCrS Bad Coin Reset
bUZ Buzzer (T one)
o
CEL Degree in Celsius
CLCC Clear Left Coin Count
Coin Coin Mode
CrCC Clear Right Coin Count
donE Drying and Cooling Cycles Complete
or
Dryer is in Anti-W rinkle Cycle
door Door Circuit is Open*
dSFL Dryer Sensor Circuit Failure*
o
FAr Degree in Fahrenheit
FILL No Cycle in Progress
FLS Flash Display Active
FrEE Free Dry Mode
GdL Y Anti-Wrinkle Delay T ime
Gont Anti-Wrinkle On Ti me
* Refer to Phase 5 Coin System Diagnostics in Section VIII of this manual for detailed information.
(Continued on Next Page)
8
Grd Anti-Wrinkle Program Active
HICd High Cool Down
Hot Overheating Condition*
LCC Left Coin Count
LCdE Left Coin Denomination
LOCd Low Cool Down
nbUZ No Buzzer (T one)
nFLS No Flash Display
nGrd No Anti-Wrinkle
nSEn No Rotational Sensor Selected
PdrY Percent Dry
PL Program Location
PLOC Program Location Automation Review
PPCd Permanent Press Cool Down
PP°F Permanent Press
PUSH Amount To Start Has Been Inserted
Make T emperature Selection
rCC Right Coin Count
rCdE Right Coin Denomination
SEFL Rotational Sensor Circuit Failure*
SEn Rotational Sensor Selected
tFAS Time For Amount To Start
tInE Timed Mode
* Refer to Phase 5 Coin System Diagnostics in Section VIII of this manual for detailed information.
9
SECTION III
OPERATING INSTRUCTIONS
NOTE: Unless otherwise specified at the time of ordering, the Phase 5 coin microprocessor controller
(computer) has been preprogrammed by the factory with the parameters shown on page 52
page 53 (for ALL dryer models except AD-26/AD-295 and AD-540/WDA-540) and
and
page 54 and page 55 (for dryer models AD-26/AD-295 and AD-540/WDA-540 only).
Should program changes be found necessary , please read this Phase 5 Coin User’s Manual
carefully to thoroughly familiarize yourself with the Phase 5 coin microprocessor controller
(computer) programming characteristics.
A. TIMED MODE
1. When turning on power or when no cycle is in progress, the light emitting diode (L.E.D.) display will read
“FILL” and/or “Amount To Start” (“AtSt”).
2. Insert coin(s). Once the correct “Amount T o Start” has been inserted, the L.E.D. display will read “PUSH.”
3. Select temperature by pushing “HI TEMP,” “LO TEMP,” or “PERM PRESS.” The dryer will start and the
L.E.D. display will read the temperature cycle selected and the drying time.
4. The dryer will continue through the drying and cooling cycles, showing time counting downward.
NOTE: If the door is opened during a cycle, both the heat and motor will stop. However , the Phase 5
coin microprocessor controller (computer) will continue to count downwards in time.
Continuation of the cycle will resume only after the door has been closed and any one (1) of
the three (3) temperature selection buttons is again depressed.
5. Upon completion of the drying and cooling cycles, the buzzer (tone) will sound, and the L.E.D. display will
read “donE” for 5-seconds, at which time the dryer will shut off.
NOTE: If the Anti-W rinkle Program is active (“Grd”), the L.E.D. display will remain reading “donE,”
and the Phase 5 coin microprocessor (computer) will proceed through the Anti-W rinkle
Program until the maximum “Guard On Time” has expired or until the door is opened,
whichever comes first. The L.E.D. display will read “FILL” and/or “Amount T o Start”
(“AtSt”).
NOTE: If the Anti-W rinkle Program is not active (“nGrd”) the L.E.D. display will read “donE” until
the main door is opened, at which time the L.E.D. display will read “FILL” and/or “Amount T o
Start.”
10
B. AUTOMATIC MODE (PATENT NO. 4,827,627)
1. When turning on power or when no cycle is in progress, the light emitting diode (L.E.D.) display will read
“FILL” and/or “Amount To Start” (“AtSt”).
2. Insert coin(s). Once correct “Amount To Start” has been inserted, the L.E.D. display will read “PUSH.”
3. Select temperature by pushing “HI TEMP,” “LO TEMP,” or “PERM PRESS.” The dryer will start, the
L.E.D. display will read the temperature cycle selected, and the drying time portion of the L.E.D. display
will read “00” and count upward as time elapses.
NOTE: If the door is opened during a cycle, both the heat and motor will stop. However , the Phase 5
coin microprocessor controller (computer) will continue to count upwards in time.
Continuation of the cycle will resume only after the door has been closed and any one (1) of
the three (3) temperature selection buttons is again depressed.
4. Once the preprogrammed dryness level and cool down period have been reached or maximum automatic
time has expired, whichever comes first, the buzzer (tone) will sound, and the L.E.D. display will read
“donE” for 5-seconds, at which time the dryer will shut off.
NOTE: If the Anti-W rinkle Program is active (“Grd”), the L.E.D. display will remain reading “donE,”
and the Phase 5 coin microprocessor controller (computer) will proceed through the
Anti-Wrinkle Program until the maximum “Guard On Time” has expired or door is opened,
whichever comes first. The L.E.D. will read “FILL” and/or “Amount T o Start” (“AtSt”).
NOTE: If the Anti-Wrinkle Program is not active (“nGrd”), the L.E.D. display will read “donE” until
the main door is opened, at which time the L.E.D. display will read “FILL” and/or “Amount T o
Start.”
11
C. FREE DRY MODE
1 When turning on power or when no cycle is in progress, the light emitting diode (L.E.D.) display will read
“FILL” and/or “FrEE.”
2. Select temperature. The dryer will start, the L.E.D. display will read the temperature cycle selected and
the drying time portion of the L.E.D. display will read the temperature cycle selected. The drying time
portion of the L.E.D. drying will read “00” and count upward as time elapses, or the vended time will count
downward, depending on which parameter is programmed.
NOTE: If the door is opened during a cycle, both the heat and motor will stop. However , the Phase 5
coin microprocessor controller (computer) will continue to count the time, either upward or
downward, depending on which parameter is programmed. Continuation of the cycle will
resume only after the door has been closed and any one (1) of three (3) temperature selection
buttons is again depressed.
3. Once the preprogrammed percent dryness level and cool down period has been reached or maximum
automatic time has expired, whichever comes first, the tone (buzzer) will sound, and the L.E.D. display will
read “donE” for 5-seconds, at which time the dryer will shut off.
NOTE: If the Anti-W rinkle Program is active (“Grd”), the L.E.D. display will remain reading “donE,”
and the Phase 5 coin microprocessor controller (computer) will proceed through the
Anti-Wrinkle Program until the maximum “Guard On Time” has expired or door is opened,
whichever comes first. The L.E.D. display will read “FILL” and/or “Amount T o Start”
(“AtSt”).
NOTE: If the Anti-Wrinkle Program is not active (“nGrd”), the L.E.D. display will read “donE” until
the main door is opened, at which time the L.E.D. display will read “FILL” and/or “Amount T o
Start.”
12
SECTION IV
PROGRAM SELECTION
NOTE: Programs are stored in the Phase 5 coin microprocessor controller (computer) memory and
are cataloged as Program Locations (PL).
TEMPERATURE DISPLA Y MODE
By closing the Program Switch (PS) located on the back side of the Phase 5 coin microprocessor controller
(computer), the light emitting diode (L.E.D.) display will read the temperature in the dryer in either Fahrenheit
(°F) or Celsius (°C), depending on how the temperature conversion status is in PL01. The temperature display
mode can be activated while the dryer is in the operating cycle, or off. While in the operating cycle, the circuit
indicators are visible for troubleshooting purposes.
NOTE: The dryer cannot be started while the Phase 5 coin microprocessor controller (computer)
Program Switch (PS) is closed, unless the cycle was already in progress.
RIGHT COIN COUNT (rCC)/LEFT COIN COUNT (LCC)
The “HI TEMP” key lets the operator review the coin counters. If the operator presses the “HI TEMP” key,
the computer displays “_LCC.” The operator could then press either the “PERM PRESS” key to view the
“Left Coin Count” or the “HI TEMP” key and the computer would display “_rCC.” Again, the operator could
press the “PERM PRESS” key to view the “Right Coin Count.” While displaying the coin count, if the operator
presses the “HI TEMP” key the computer then displays “CxCC” (x = “r” or “L”) to indicate “clearing” the coin
count. The operator then presses the “PERM PRESS” key to clear the coin count or the “HI TEMP” or “LO
TEMP” key to exit without clearing the coin count.
13
AUTOMATIC REVIEW OF PROGRAM LOCA TION
This selection allows for the AUT OMATIC REVIEW of what the program locations are set (programmed) for ,
thereby eliminating the need to go into each and every Program Location (PL) manually for verification. By
closing the Programming Switch (PS) with no cycle in progress, the light emitting diode (L.E.D.) display will
read the temperature in the dryer. Then, by pressing the “LO TEMP” key , the L.E.D. display will read “PLOC”
for 1-second. Then, the Phase 5 coin microprocessor controller (computer) will go into the Automatic Review
Mode, the Program Location numbers (i.e., PL01, PL02, etc.) will not be shown and each parameter (i.e.,
“°F Ar ,” “tInE,” “Grd,” etc.) will be displayed for approximately 1-second each. The Automatic Review can be
stopped/exited at any time by simply pressing the “PERM PRESS” key, at which time the L.E.D. display will
read “0000” for 1-second and then return to the Temperature Display mode.
14
PL01 - TEMPERATURE CONVERSION STATUS
This program controls whether the temperature related programs will be operated in Fahrenheit (°F) or Celsius
(°C). The programs affected are:
1. Temperature Display Mode
2. Selection Cycling T emperatures
3. Cool Down Temperatures
AUTOMATIC MODE (AUtO) Patent No. 4,827,627
When this parameter (“AUtO”) is selected, the dryer will run for a preset level of dryness (PL02) or until the
programmed automatic maximum time (PL14) has expired.
At the end of the drying cycle, the dryer will go into the cool down cycle for the time period programmed (PL04,
PL06, or PL08) or until the temperature has dropped to the programmed cool down temperature (PL04,
PL06, or PL08).
NOTE: Due to humidity , atmospheric pressure, percentage of extraction, etc., the desired dryness level
may vary. It is suggested that the owner determine which level of dryness (90% to 100%) is
best suited for his/her application by experimenting with a few test loads.
NOTE: When programming, to use the Automatic Mode (“AUtO”) (Patent No. 4,827,627), the
following parameter/programs need to be checked and/or changed accordingly:
PL01 ..............................................“AUt O”
..............................................“FrEE” or “Coin” (coins required to start)
PL02 ..............................................“PdrY” (percent dry from 90% to 100%)
PL14 ..............................................“Adrt” (maximum auto dry time)
PL17 ..............................................“A” and “b” Factors
TIMED MODE (tInE)
When this parameter is selected (‘tInE”) and the Phase 5 coin microprocessor controller (computer) has been
activated, the dryer will continue to run until the preset time, including the cool down period (PL04, PL06, or
PL08), has elapsed, at which time the dryer will continue to run until the preset time, including the cool down
period (PL04, PL06, or PL08), has elapsed, at which time the dryer will cycle off or go into the optional
Anti-Wrinkle Program.
15
ANTI-WRINKLE PROGRAM (Grd)
This feature can be used in conjunction with any of the three (3) operating modes (Coin Mode, Auto Mode, or
the Free Dry Mode). In this program (“Grd”), when the drying and cooling cycles are completed, the dryer will
shut off, the buzzer (tone) will sound, and the light emitting diode (L.E.D.) display will read “donE.” If the door
is not opened, the Phase 5 coin microprocessor controller (computer) will wait until the “Guard Delay Time”
(PL15) has expired, at which time the clothes
Time” (PL15). The Phase 5 coin microprocessor controller (computer) will repeat this process until the
programmed “Active Guard Time” (PL16) has expired or until the dryer door is opened, at which time the
L.E.D. display will read “FILL” and/or “Amount To Start” (“AtSt”) or “FILL” and/or “FrEE.”
will be tumbled (without heat) for the programmed ”Guard On
NOTE: When programming the use of the Anti-W rinkle Program (“Grd”), the following parameter/
programs need to be checked and/or changed accordingly:
PL01 ................................ “Grd” (Anti-Wrinkle Program active)
................................ “bUZ” or “nbUZ” (buzzer [tone] active/not active)
PL15 ................................ “GdL Y” (guard delay time)
................................ “Gont” (guard on time)
PL16 ................................ “AGt” (active guard time)
BUZZ/TONE (bUZ)
With the Anti-W rinkle Program active, the option is available to have the buzzer/tone (“bUZ”) sound for a period
of 5-seconds at the end of each “Guard On Time” cycle, or, no buzzer (“nbUZ”) sound.
FREE DRY MODE (FrEE)
The Phase 5 coin microprocessor controller (computer) can be programmed to run without the insertion of
coins. When the Phase 5 coin microprocessor controller (computer) is in the “FrEE” dry mode, it may be
programmed to run in the “AUtO” (Automatic) Mode or the “tInE” (Timed) Mode.
NOTE: When programming the use of the Free Dry Mode (“FrEE”), the following parameters/
programs need to be checked and/or changed accordingly;
PL01 ................................ “AUtO” (automatic drying cycle) or
................................ “tInE” (timed drying cycle) “FrEE”
PL02* .............................. “PdrY” (percent dry)
PL14* .............................. “Adrt” (maximum auto dry time)
PL17* .............................. “A” and “b” factors
* Needs to be programmed only if PL01 “AUtO” Cycle is chosen.
16
COIN MODE (COIN)
In this program mode (“Coin”), coins are required to start the dryer, even if the Phase 5 coin microprocessor
controller (computer) is set in the Automatic Mode (Patent No. 4,827,627).
NOTE: When programming the use of the Coin Mode, (“Coin”), the following parameter/programs
need to be checked and/or changed accordingly:
PL01 ................................ “AUtO” (automatic drying cycle) or
................................ “tInE” (timed drying cycle) “FrEE”
PL02* .............................. “PdrY” (percent dry)
PL11 ................................ “tFAS” (time for amount to start)
PL12 ................................ “AtSt” (amount to start)
PL14* .............................. “Adrt” (maximum auto dry time)
PL17* .............................. “A” and “b” Factors
*Needs to be programmed only if PL01 “AUtO” Cycle is chosen.
FLASH DISPLA Y STATUS (FLS)
When the Phase 5 coin microprocessor controller (computer) is set in this program status (“FLS”) it allows the
light emitting diode (L.E.D.) readout to display “FILL” and/or “FrEE” (no cycle in progress), and/or “Amount T o
Start” (PL12) or, in the case of free dry, “FrEE.” The programming allows the L.E.D. readout to flip-flop back
and forth every 2-seconds from “FILL” to “Amount To Start,” or in the case of free dry, from “FILL” to
“FrEE.” If the L.E.D. display is programmed for “No Flash” (“nFLS”), the microprocessor controller (computer)
will then prompt you on whether you would like “FILL” displayed or the “Amount To Start” (“AtSt”).
BAD COIN LOCKOUT ST ATUS (bCLO)
In this program status (“bCLO”), each coin entry is monitored. Should someone tamper with the coin acceptor
or attempt to insert a foreign object, the Phase 5 coin microprocessor controller (computer) will “LOCKOUT”
and not accept any entries until the reset time has elapsed (approximately 15-seconds). Once the reset time has
expired, the Phase 5 coin microprocessor controller (computer) will automatically reset itself immediately for the
next entry.
BAD COIN RESET (bCrS)
When set in this program (“bCrS”), the Phase 5 coin microprocessor controller (computer) counts in milliseconds
the amount of time required for a coin entry signal. If someone should tamper with the coin acceptor or attempt
to insert a foreign object, the Phase 5 coin microprocessor controller (computer) will not accept the entry and
will automatically reset itself immediately for the next entry.
17
ACCUMULA TIVE TIME (AtIn)
SINGLE COIN)
(
In this program mode (“AtIn”), each coin inserted has a specific value in time which is determined by the “Time
For Amount To Start” (“tFAS”) program (PL11).
Example No. 1: If the dryer is equipped with a 25¢ coin acceptor and the desired time is 30 minutes, each
additional coin inserted would yield 30 minutes.
Settings: PL09 (LCdE) ........................ 2 5
PL11 (tFAS) .......................... 3 0
PL12 (AtSt) ........................... 25
Example No. 2: If the dryer is equipped with a 25¢ coin acceptor and the “Amount To Start” (“AtS t”) is 50¢
for 30 minutes, the insertion of each additional coin would yield 15 minutes. In this application
the “Time For Amount To Start” (“tFAS”) is determined by a Phase 5 coin microprocessor
controller (computer) calculation. There is no calculation required by the owner .
Formula: (LCdE/AtSt) (tFAS) = Vended Time for “ LCdE” (25¢/50¢) (30) = 15 minutes
Settings: PL09 (LCdE) ........................ 2 5
PL11 (tFAS) .......................... 3 0
PL12 (AtSt) ........................... 50
(DUAL COIN)
In the accumulative time (AtIn) mode, when using a dual coin acceptor, once the “Amount To Start” (“AtSt”)
has been inserted, the addition of a coin(s) yields more time. The amount time accumulated for each additional
coin inserted is determined by the “Time For Amount To Start” (“tFAS”) program (PL11).
The “Time For Amount To Start” (“tFAS”) is determined by a Phase 5 coin microprocessor controller (computer)
calculation of additional amounts installed.
Formula: (LCdE/AtSt) (tFAS) = Vended Time
Example No. 1: Using a 10¢/25¢ dual coin acceptor with the desired “Amount To Start” (“AtSt”) being 25¢
for 15 minutes, each additional 10¢ would yield the following:
Formula: (LCdE/AtSt) (tFAS) = Vended Time for “LCdE” (10¢/25¢) (15 minutes) 6 minutes
Settings: PL09 (LCdE) ........................ 1 0
PL10 (rCdE) ......................... 2 5
PL11 (tFAS) .......................... 1 5
PL12 (AtSt) ........................... 25
18
Loading...
