ADC AD-295, ADG-15D, AD-540, WDA-540, ADG-25D User Manual

...

Download

PHASE 5

COIN

USER’S MANUAL

American Dryer Corporation

88 Currant Road

Fall River MA 02720-4781 USA

T elephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447

e-mail: techsupport@amdry.com

www.amdry.com

ADC Part No. 112146-56

Retain This Manual In A Safe Place For

Future Reference

Please read this manual carefully to thoroughly familiarize yourself with the Phase 5 Coin computer system features, operational instructions, and programming characteristics. This manual contains important information on how to use ALL the features of your new ADC dryer in the safest and fastest way .

American Dryer Corporation products embody advanced concepts in engineering, design, and safety . If this product is properly maintained, it will provide many years of safe, efficient, and trouble free operation.

W e have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models.

▲ WARNING

Proposition 65

Use of this product could expose you to substances

from fuel combustion that contain chemicals known

to the State of California to cause cancer, birth defects

and other reproductive harm.

“IMPORT ANT NOTE TO PURCHASER”

Information must be obtained from your local gas supplier on the instructions to be followed if the user smells gas. These instructions must be posted in a prominent location near the dryer.

Table Of Contents

SECTION I

INTRODUCTION.......................................................................................................4

Phase 5 Coin Microprocessor Controller (Computer) Features.......................................................... 4

SECTION II

L.E.D. DISPLAY AND CODES................................................................................. 8

SECTION III

OPERATING INSTRUCTIONS .............................................................................10

A. Timed Mode............................................................................................................................. 10

B. Automatic Mode (Patent No. 4,827,627) ................................................................................. 1 1

C. Free Dry Mode ........................................................................................................................ 12

SECTION IV

PROGRAM SELECTION ....................................................................................... 13

T emperature Display Mode............................................................................................................. 13

Right Coin Count (rCC)/Left Coin Count (LCC) ............................................................................. 13

Automatic Review of Program Location .......................................................................................... 14

PL01 - T emperature Conversion Status........................................................................................... 15

Automatic Mode (Auto) Patent No. 4,827,627 ............................................................................... 15

Timed Mode (tInE) ......................................................................................................................... 15

Anti-Wrinkle Program (Grd) ........................................................................................................... 16

Buzz/T one (bUZ) ............................................................................................................................ 16

Free Dry Mode Cycle (FrEE) ......................................................................................................... 16

Coin Mode (Coin) .......................................................................................................................... 17

Flash Display Status (FLS) ............................................................................................................. 17

Bad Coin Lockout Status (bCLO) ..................................................................................................17

Bad Coin Reset (bCrS) .................................................................................................................. 17

Accumulative Time (AtIn) ............................................................................................................... 18

Accumulative Coin (ACOn) ............................................................................................................ 20

Rotational Safe Guard - OPTIONAL (nSEn) .................................................................................. 21

PL02 - Percent Dry (PdrY) ............................................................................................................ 21

PL03 - High T emperature (HI° F) ................................................................................................... 21

PL04 - High Cool Down T emperature/Time (HIcd)......................................................................... 22

PL05 - Low T emperature (LO° F)..................................................................................................22

PL06 - Low Cool Down T emperature/Time (LOcd)........................................................................ 22

PL07 - Permanent Press (PP° F) .................................................................................................... 22

PL08 - Permanent Press Cool Down T emperature /Time (PPCd) .................................................... 22

PL09 - Left Coin Slot Denomination (LCdE) .................................................................................. 22

PL10 - Right Coin Slot Denomination (rCdE).................................................................................. 23

PL11 - T ime For Amount To Start (tF AS) ....................................................................................... 23

PL12 - Amount T o Start (AtSt)....................................................................................................... 23

PL13 - Minimum Amount For Additional Time (AF AT).................................................................... 23

PL14 - Maximum Time For Automatic Dry (Adrt) ........................................................................... 23

PL15 - Anti-Wrinkle T iming ............................................................................................................ 24

Guard Delay Time (GdL Y).............................................................................................................. 24

Guard On Time (Gont).................................................................................................................... 24

PL16 - Active Guard Time (AGt).................................................................................................... 24

PL17 - “A” and “b” Factors ........................................................................................................... 24

SECTION V

PROGRAMMING INSTRUCTIONS ....................................................................25

A. Introduction To Programming.................................................................................................... 25

B. Programming (Flowcharts) ........................................................................................................ 26

SECTION VI

PROGRAMMING ....................................................................................................29

A. T emperature Display Mode....................................................................................................... 29

B. Left Coin Count ........................................................................................................................ 30

C. Right Coin Count ...................................................................................................................... 31

D. Program Location 01 (PL01).................................................................................................... 32

E. Program Location 02 (PL02) .................................................................................................... 36

F. Program Location 03 (PL03) .................................................................................................... 37

G. Program Location 04 (PL04) .................................................................................................... 38

H. Program Location 05 (PL05).................................................................................................... 39

I. Program Location 06 (PL06) .................................................................................................... 40

J. Program Location 07 (PL07) .................................................................................................... 41

K. Program Location 08 (PL08).................................................................................................... 42

L. Program Location 09 (PL09) .................................................................................................... 43

M. Program Location 10 (PL10) .................................................................................................... 44

N. Program Location 11 (PL1 1) .................................................................................................... 45

O. Program Location 12 (PL12).................................................................................................... 46

P . Program Location 13 (PL13) .................................................................................................... 47

Q. Program Location 14 (PL14).................................................................................................... 48

R. Program Location 15 (PL15) .................................................................................................... 49

S. Program Location 16 (PL16) and Program Location 17 (PL17) ................................................ 50

SECTION VII

FACTORY PRESET PROGRAMS/PARAMETERS ..........................................51

A. Single Coin Only

For all dryer models except AD-26/AD-295 and AD-540/WDA-540....................................... 52

B. Dual Coin Only

For all dryer models except AD-26/AD-295 and AD-540/WDA-540....................................... 53

C. Single Coin Only

For dryer models AD-26/AD-295 Only .................................................................................... 54

D. Dual Coin Only

For dryer models AD-26/AD-295 Only .................................................................................... 55

SECTION VIII

PHASE 5 COIN SYSTEM DIAGNOSTICS ......................................................... 5 6

A. Diagnostic (L.E.D) Failure Codes ............................................................................................. 56

1. “door” .................................................................................................................................. 56

2. “dSFL” ................................................................................................................................56

3. “SEFL” ................................................................................................................................57

4. “Hot” ................................................................................................................................... 57

B. L.E.D. Display Indicators/Dots ................................................................................................. 57

1. Heat Circuit Indicator ........................................................................................................... 57

2. Motor Circuit Indicator ......................................................................................................... 57

C. Phase 5 Microprocessor Controller (Computer) Relay Output L.E.D. Indicators........................ 58

1. “DOOR” .............................................................................................................................. 58

2. “HEA T”................................................................................................................................59

3. “MTR” (motor) .................................................................................................................... 59

SECTION IX PHASE 5 AUTO CYCLE (PATENT NO. 4,827,267)

“A” AND “B” FACTOR PARAMETERS............................................................. 6 0

SECTION X

OPTIONAL 9 VOLT BATTERY BACKUP...........................................................6 2

SECTION I

INTRODUCTION

The Phase 5 Coin Computer System is a fully programmable, highly sophisticated dryer control system. American Dryer Corporation has designed the Phase 5 coin microprocessor controller (computer) to be the most versatile and reliable coin-operated control system available.

To eliminate as many moving parts as possible, ALL Phase 5 coin microprocessor controller (computer) programming is done through the membrane switch on the front of the control panel. The Program Switch (PS) that puts microprocessor controller (computer) into the program mode is a single program switch. This program switch eliminates the possibility of switch failure due to an accumulation of lint or moisture.

Phase 5 Coin Microprocessor Controller (Computer) Features

AUTOMATIC PROGRAM REVIEW

In the program mode, the Phase 5 coin microprocessor controller (computer) will show ALL settings by one (1) touch of the low temperature keyboard (touch pad) selection.

PROGRAMMABLE

Changes in the programs are made at the temperature keyboard (touch pad) selection and actual programs are displayed for verification.

ADJUSTABLE TIME

Programmable from a minimum of 1 minute to a maximum of 99 minutes in 1 minute increments.

COIN ACCEPTOR DENOMINA TIONS

Values of coin acceptors are programmable from a minimum of 1 to a maximum value of 9999 for any U.S. or foreign coin denomination.

AMOUNT TO ST ART

Programmable from a minimum value 1 to a maximum value of 9999 in increments of one (1).

ACCUMULA TIVE TIME

This program yields a specific value of time for any coin entry made after the “Amount To Start” has been inserted.

TIME FOR AMOUNT TO START

This program retains the time the owner wishes to vend. The feature allows any additional purchase that is made to be calculated to the second. There is no calculation necessary by the owner. The Phase 5 coin microprocessor controller (computer) calculates the vended time.

ACCUMULA TIVE COIN

This program selection requires that a specific value of coin(s) be inserted for additional time, programmable for any minimum amount.

COIN COUNT

The number of coins inserted, including a separate display program for optional dual coin acceptors, can be viewed through the Phase 5 computer’s light emitting diode (L.E.D.) display .

BAD COIN LOCKOUT

Each coin is monitored. Should someone tamper with the coin acceptor or attempt to insert a foreign object, the microprocessor controller (computer) will “LOCKOUT” and will not accept any entries until the reset time has elapsed (approximately 15-seconds). Once the reset time has expired, the microprocessor controller (computer) will automatically reset itself for the next coin entry .

TEMPERATURE CONVERSION

When the temperature conversion status is changed (i.e. from °F to °C), the Phase 5 coin microprocessor controller (computer) will automatically convert ALL temperature related programs/parameters from Fahrenheit to Celsius and vice versa. The Phase 5 coin microprocessor controller (computer) will perform this conversion within 1° F (2° C). The programs affected are:

1. Temperature Display Mode

2. Temperature Selections

3. Cool Down Temperatures

DRYING TEMPERATURES

Any of the three (3) temperature selections (HI/LO/PP) are programmable from a minimum of 100° F to a maximum of 190° F in ten-degree increments or from a minimum of 38° C to a maximum of 88° C in five-degree increments. Actual temperature programs are displayed at time of programming for verification.

For the AD-26 and AD-295 any three (3) of the selections (HI/LO/PP) are programmable from a minimum of 100° F to a maximum of 170° F in ten-degree increments, or from a minimum of 38° C to a maximum of 77° C in five-degree increments.

For the AD-540 and WDA-540 any three (3) of the selections (HI/LO/PP) are programmable from a minimum of 100° F to a maximum of 160° F in ten-degree increments or from a minimum of 38° C to a maximum of 71° C in five-degree increments.

COOL DOWN TIME

ALL three (3) temperature selections are programmable from a minimum of 0 minutes to a maximum of 9

minutes in 1 minute increments.

COOL DOWN TEMPERATURES

In the automatic or free dry modes, the cool down cycle termination is programmable from a minimum of 70° F to a maximum of 190° F in ten-degree increments or from a minimum of 21° C to a maximum of 88° C

five-degree increments.

AUTOMATIC MODE (Patent No. 4,827,627)

This program selection uses ADC’s patented Auto-Dry cycle. The microprocessor controller (computer) will calculate the percent of the dryness and read “donE” when complete. The Phase 5 coin microprocessor controller (computer) can be programmed to have a maximum time for the “Auto Mode.” The Automatic Cycle (mode) can be used in either the “Free Dry” Mode or the “Coin” Mode.

ANTI-WRINKLE

This program selection helps keep permanent press items wrinkle free when they are not removed from the dryer promptly at the end of the drying and cooling cycles. The Anti-W rinkle program settings are:

1. Guard Delay Time ...................... 1 to 9 minutes

2. Guard On Time........................... 1 to 99-seconds

3. Active Guard Time ..................... 1 to 99 minutes

FREE DRY MODE

In this program selection, the dryer can be started without the insertion of coins by simply pressing any one of the three (3) temperature selections. When set in the “Free Dry” Mode, the Phase 5 coin microprocessor controller (computer) can also be programmed to run with an Automatic Cycle (percent of dryness) or with a Timed Cycle. If the “Free Dry” program is utilized, the computer’s light emitting diode (L.E.D.) display will cycle back and forth between “FILL” to “FrEE,” unless otherwise programmed.

L.E.D. FLASH DISPLA Y

Programmable to allow the L.E.D. readout to display a choice of “FILL” (no cycle in progress), “Amount To Start” (i.e., 25¢), or, in the case of free dry, “FrEE.” This program selection also allows the L.E.D. display to flash back and forth every 2-seconds from “FILL” to “Amount T o Start” or , in the case of free dry, from “FILL” to “FrEE.”

AUDIBLE TONE

In this program selection, a tone (buzzer) will sound for each coin inserted, program entry , or at the drying and cooling cycles for a period of 5-seconds to indicate that the cycle is complete. Additionally, when in the Anti-Wrinkle program, the tone (buzzer) will sound for 5-seconds at the end of the “Guard On Time.”

TEMPERATURE DISPLA Y

This program selection enables the temperature in the dryer to be viewed (°F or °C) either while the dryer is off or running. This service feature shows that the dryer is maintaining the selected temperature.

DIAGNOSTICS

ALL major circuits, including door, microprocessor temperature sensor , heat, and motor circuits are monitored.

There are also indicators installed on the outputs of each relay to easily identify failures, and the door switch has an indicator installed on the Phase 5 microprocessor controller (computer) to help indicate failure.

AUTOMATIC DRY TIME

This program selection allows the dryer to run up to a specific time. During the “AUtO” mode or “FrEE” dry mode this program is only designed to limit the dryer’s operation during the drying cycle.

ROTATIONAL SAFE GUARD (Optional)

This program monitors the rotation of the basket (tumbler). If the basket (tumbler) is not rotating, the Phase 5 coin microprocessor controller (computer) will disable ALL outputs, an audible tone (buzzer) will sound, and an error message will be displayed. This program selection can be programmed to be in the inactive mode.

BA TTER Y BACKUP (Optional)

This feature allows the Phase 5 coin microprocessor controller (computer) to maintain its operating status should a momentary power interruption occur while the dryer cycle is in progress.

SECTION II

L.E.D. DISPLAY AND CODES

A Automatic Cycle (Slope Program Factor) ACOn Accumulative Coin Adrt Maximum Auto Dryness Time AF At Amount for Additional Time AGt Active Anti-Wrinkle Guard Time AtIn Accumulative Time AtSt Amount To Start AUtO Automatic Mode (Patent No. 4,827,627) b Automatic Cycle (Heat Loss [offset] Factor) bCLO Bad Coin Lockout bCrS Bad Coin Reset bUZ Buzzer (T one)

CEL Degree in Celsius CLCC Clear Left Coin Count Coin Coin Mode CrCC Clear Right Coin Count donE Drying and Cooling Cycles Complete

Dryer is in Anti-W rinkle Cycle

door Door Circuit is Open* dSFL Dryer Sensor Circuit Failure*

FAr Degree in Fahrenheit FILL No Cycle in Progress FLS Flash Display Active FrEE Free Dry Mode GdL Y Anti-Wrinkle Delay T ime Gont Anti-Wrinkle On Ti me

* Refer to Phase 5 Coin System Diagnostics in Section VIII of this manual for detailed information.

(Continued on Next Page)

Grd Anti-Wrinkle Program Active HICd High Cool Down Hot Overheating Condition* LCC Left Coin Count LCdE Left Coin Denomination LOCd Low Cool Down nbUZ No Buzzer (T one) nFLS No Flash Display nGrd No Anti-Wrinkle nSEn No Rotational Sensor Selected PdrY Percent Dry PL Program Location PLOC Program Location Automation Review PPCd Permanent Press Cool Down PP°F Permanent Press PUSH Amount To Start Has Been Inserted

Make T emperature Selection

rCC Right Coin Count rCdE Right Coin Denomination SEFL Rotational Sensor Circuit Failure* SEn Rotational Sensor Selected tFAS Time For Amount To Start tInE Timed Mode

* Refer to Phase 5 Coin System Diagnostics in Section VIII of this manual for detailed information.

SECTION III

OPERATING INSTRUCTIONS

NOTE: Unless otherwise specified at the time of ordering, the Phase 5 coin microprocessor controller

(computer) has been preprogrammed by the factory with the parameters shown on page 52

page 53 (for ALL dryer models except AD-26/AD-295 and AD-540/WDA-540) and

and page 54 and page 55 (for dryer models AD-26/AD-295 and AD-540/WDA-540 only).

Should program changes be found necessary , please read this Phase 5 Coin User’s Manual carefully to thoroughly familiarize yourself with the Phase 5 coin microprocessor controller (computer) programming characteristics.

A. TIMED MODE

1. When turning on power or when no cycle is in progress, the light emitting diode (L.E.D.) display will read “FILL” and/or “Amount To Start” (“AtSt”).

2. Insert coin(s). Once the correct “Amount T o Start” has been inserted, the L.E.D. display will read “PUSH.”

3. Select temperature by pushing “HI TEMP,” “LO TEMP,” or “PERM PRESS.” The dryer will start and the L.E.D. display will read the temperature cycle selected and the drying time.

4. The dryer will continue through the drying and cooling cycles, showing time counting downward.

NOTE: If the door is opened during a cycle, both the heat and motor will stop. However , the Phase 5

coin microprocessor controller (computer) will continue to count downwards in time. Continuation of the cycle will resume only after the door has been closed and any one (1) of the three (3) temperature selection buttons is again depressed.

5. Upon completion of the drying and cooling cycles, the buzzer (tone) will sound, and the L.E.D. display will read “donE” for 5-seconds, at which time the dryer will shut off.

NOTE: If the Anti-W rinkle Program is active (“Grd”), the L.E.D. display will remain reading “donE,”

and the Phase 5 coin microprocessor (computer) will proceed through the Anti-W rinkle Program until the maximum “Guard On Time” has expired or until the door is opened, whichever comes first. The L.E.D. display will read “FILL” and/or “Amount T o Start” (“AtSt”).

NOTE: If the Anti-W rinkle Program is not active (“nGrd”) the L.E.D. display will read “donE” until

the main door is opened, at which time the L.E.D. display will read “FILL” and/or “Amount T o Start.”

B. AUTOMATIC MODE (PATENT NO. 4,827,627)

1. When turning on power or when no cycle is in progress, the light emitting diode (L.E.D.) display will read

“FILL” and/or “Amount To Start” (“AtSt”).

2. Insert coin(s). Once correct “Amount To Start” has been inserted, the L.E.D. display will read “PUSH.”

3. Select temperature by pushing “HI TEMP,” “LO TEMP,” or “PERM PRESS.” The dryer will start, the

L.E.D. display will read the temperature cycle selected, and the drying time portion of the L.E.D. display will read “00” and count upward as time elapses.

NOTE: If the door is opened during a cycle, both the heat and motor will stop. However , the Phase 5

coin microprocessor controller (computer) will continue to count upwards in time. Continuation of the cycle will resume only after the door has been closed and any one (1) of the three (3) temperature selection buttons is again depressed.

4. Once the preprogrammed dryness level and cool down period have been reached or maximum automatic

time has expired, whichever comes first, the buzzer (tone) will sound, and the L.E.D. display will read “donE” for 5-seconds, at which time the dryer will shut off.

NOTE: If the Anti-W rinkle Program is active (“Grd”), the L.E.D. display will remain reading “donE,”

and the Phase 5 coin microprocessor controller (computer) will proceed through the Anti-Wrinkle Program until the maximum “Guard On Time” has expired or door is opened, whichever comes first. The L.E.D. will read “FILL” and/or “Amount T o Start” (“AtSt”).

NOTE: If the Anti-Wrinkle Program is not active (“nGrd”), the L.E.D. display will read “donE” until

the main door is opened, at which time the L.E.D. display will read “FILL” and/or “Amount T o Start.”

C. FREE DRY MODE

1 When turning on power or when no cycle is in progress, the light emitting diode (L.E.D.) display will read

“FILL” and/or “FrEE.”

2. Select temperature. The dryer will start, the L.E.D. display will read the temperature cycle selected and the drying time portion of the L.E.D. display will read the temperature cycle selected. The drying time portion of the L.E.D. drying will read “00” and count upward as time elapses, or the vended time will count downward, depending on which parameter is programmed.

NOTE: If the door is opened during a cycle, both the heat and motor will stop. However , the Phase 5

coin microprocessor controller (computer) will continue to count the time, either upward or downward, depending on which parameter is programmed. Continuation of the cycle will resume only after the door has been closed and any one (1) of three (3) temperature selection buttons is again depressed.

3. Once the preprogrammed percent dryness level and cool down period has been reached or maximum automatic time has expired, whichever comes first, the tone (buzzer) will sound, and the L.E.D. display will read “donE” for 5-seconds, at which time the dryer will shut off.

NOTE: If the Anti-W rinkle Program is active (“Grd”), the L.E.D. display will remain reading “donE,”

and the Phase 5 coin microprocessor controller (computer) will proceed through the Anti-Wrinkle Program until the maximum “Guard On Time” has expired or door is opened, whichever comes first. The L.E.D. display will read “FILL” and/or “Amount T o Start” (“AtSt”).

NOTE: If the Anti-Wrinkle Program is not active (“nGrd”), the L.E.D. display will read “donE” until

the main door is opened, at which time the L.E.D. display will read “FILL” and/or “Amount T o Start.”

SECTION IV

PROGRAM SELECTION

NOTE: Programs are stored in the Phase 5 coin microprocessor controller (computer) memory and

are cataloged as Program Locations (PL).

TEMPERATURE DISPLA Y MODE

By closing the Program Switch (PS) located on the back side of the Phase 5 coin microprocessor controller (computer), the light emitting diode (L.E.D.) display will read the temperature in the dryer in either Fahrenheit (°F) or Celsius (°C), depending on how the temperature conversion status is in PL01. The temperature display mode can be activated while the dryer is in the operating cycle, or off. While in the operating cycle, the circuit indicators are visible for troubleshooting purposes.

NOTE: The dryer cannot be started while the Phase 5 coin microprocessor controller (computer)

Program Switch (PS) is closed, unless the cycle was already in progress.

RIGHT COIN COUNT (rCC)/LEFT COIN COUNT (LCC)

The “HI TEMP” key lets the operator review the coin counters. If the operator presses the “HI TEMP” key, the computer displays “_LCC.” The operator could then press either the “PERM PRESS” key to view the “Left Coin Count” or the “HI TEMP” key and the computer would display “_rCC.” Again, the operator could press the “PERM PRESS” key to view the “Right Coin Count.” While displaying the coin count, if the operator presses the “HI TEMP” key the computer then displays “CxCC” (x = “r” or “L”) to indicate “clearing” the coin count. The operator then presses the “PERM PRESS” key to clear the coin count or the “HI TEMP” or “LO TEMP” key to exit without clearing the coin count.

AUTOMATIC REVIEW OF PROGRAM LOCA TION

This selection allows for the AUT OMATIC REVIEW of what the program locations are set (programmed) for , thereby eliminating the need to go into each and every Program Location (PL) manually for verification. By closing the Programming Switch (PS) with no cycle in progress, the light emitting diode (L.E.D.) display will read the temperature in the dryer. Then, by pressing the “LO TEMP” key , the L.E.D. display will read “PLOC” for 1-second. Then, the Phase 5 coin microprocessor controller (computer) will go into the Automatic Review Mode, the Program Location numbers (i.e., PL01, PL02, etc.) will not be shown and each parameter (i.e., “°F Ar ,” “tInE,” “Grd,” etc.) will be displayed for approximately 1-second each. The Automatic Review can be stopped/exited at any time by simply pressing the “PERM PRESS” key, at which time the L.E.D. display will read “0000” for 1-second and then return to the Temperature Display mode.

PL01 - TEMPERATURE CONVERSION STATUS

This program controls whether the temperature related programs will be operated in Fahrenheit (°F) or Celsius (°C). The programs affected are:

1. Temperature Display Mode

2. Selection Cycling T emperatures

3. Cool Down Temperatures

AUTOMATIC MODE (AUtO) Patent No. 4,827,627

When this parameter (“AUtO”) is selected, the dryer will run for a preset level of dryness (PL02) or until the programmed automatic maximum time (PL14) has expired.

At the end of the drying cycle, the dryer will go into the cool down cycle for the time period programmed (PL04,

PL06, or PL08) or until the temperature has dropped to the programmed cool down temperature (PL04, PL06, or PL08).

NOTE: Due to humidity , atmospheric pressure, percentage of extraction, etc., the desired dryness level

may vary. It is suggested that the owner determine which level of dryness (90% to 100%) is best suited for his/her application by experimenting with a few test loads.

NOTE: When programming, to use the Automatic Mode (“AUtO”) (Patent No. 4,827,627), the

following parameter/programs need to be checked and/or changed accordingly:

PL01 ..............................................“AUt O”

..............................................“FrEE” or “Coin” (coins required to start)

PL02 ..............................................“PdrY” (percent dry from 90% to 100%)

PL14 ..............................................“Adrt” (maximum auto dry time)

PL17 ..............................................“A” and “b” Factors

TIMED MODE (tInE)

When this parameter is selected (‘tInE”) and the Phase 5 coin microprocessor controller (computer) has been activated, the dryer will continue to run until the preset time, including the cool down period (PL04, PL06, or PL08), has elapsed, at which time the dryer will continue to run until the preset time, including the cool down period (PL04, PL06, or PL08), has elapsed, at which time the dryer will cycle off or go into the optional Anti-Wrinkle Program.

ANTI-WRINKLE PROGRAM (Grd)

This feature can be used in conjunction with any of the three (3) operating modes (Coin Mode, Auto Mode, or the Free Dry Mode). In this program (“Grd”), when the drying and cooling cycles are completed, the dryer will shut off, the buzzer (tone) will sound, and the light emitting diode (L.E.D.) display will read “donE.” If the door is not opened, the Phase 5 coin microprocessor controller (computer) will wait until the “Guard Delay Time” (PL15) has expired, at which time the clothes Time” (PL15). The Phase 5 coin microprocessor controller (computer) will repeat this process until the programmed “Active Guard Time” (PL16) has expired or until the dryer door is opened, at which time the L.E.D. display will read “FILL” and/or “Amount To Start” (“AtSt”) or “FILL” and/or “FrEE.”

will be tumbled (without heat) for the programmed ”Guard On

NOTE: When programming the use of the Anti-W rinkle Program (“Grd”), the following parameter/

programs need to be checked and/or changed accordingly:

PL01 ................................ “Grd” (Anti-Wrinkle Program active)

................................ “bUZ” or “nbUZ” (buzzer [tone] active/not active)

PL15 ................................ “GdL Y” (guard delay time)

................................ “Gont” (guard on time)

PL16 ................................ “AGt” (active guard time)

BUZZ/TONE (bUZ)

With the Anti-W rinkle Program active, the option is available to have the buzzer/tone (“bUZ”) sound for a period of 5-seconds at the end of each “Guard On Time” cycle, or, no buzzer (“nbUZ”) sound.

FREE DRY MODE (FrEE)

The Phase 5 coin microprocessor controller (computer) can be programmed to run without the insertion of coins. When the Phase 5 coin microprocessor controller (computer) is in the “FrEE” dry mode, it may be programmed to run in the “AUtO” (Automatic) Mode or the “tInE” (Timed) Mode.

NOTE: When programming the use of the Free Dry Mode (“FrEE”), the following parameters/

programs need to be checked and/or changed accordingly;

PL01 ................................ “AUtO” (automatic drying cycle) or

................................ “tInE” (timed drying cycle) “FrEE”

PL02* .............................. “PdrY” (percent dry)

PL14* .............................. “Adrt” (maximum auto dry time)

PL17* .............................. “A” and “b” factors

* Needs to be programmed only if PL01 “AUtO” Cycle is chosen.

COIN MODE (COIN)

In this program mode (“Coin”), coins are required to start the dryer, even if the Phase 5 coin microprocessor controller (computer) is set in the Automatic Mode (Patent No. 4,827,627).

NOTE: When programming the use of the Coin Mode, (“Coin”), the following parameter/programs

need to be checked and/or changed accordingly:

PL01 ................................ “AUtO” (automatic drying cycle) or

................................ “tInE” (timed drying cycle) “FrEE”

PL02* .............................. “PdrY” (percent dry)

PL11 ................................ “tFAS” (time for amount to start)

PL12 ................................ “AtSt” (amount to start)

PL14* .............................. “Adrt” (maximum auto dry time)

PL17* .............................. “A” and “b” Factors

*Needs to be programmed only if PL01 “AUtO” Cycle is chosen.

FLASH DISPLA Y STATUS (FLS)

When the Phase 5 coin microprocessor controller (computer) is set in this program status (“FLS”) it allows the light emitting diode (L.E.D.) readout to display “FILL” and/or “FrEE” (no cycle in progress), and/or “Amount T o Start” (PL12) or, in the case of free dry, “FrEE.” The programming allows the L.E.D. readout to flip-flop back and forth every 2-seconds from “FILL” to “Amount To Start,” or in the case of free dry, from “FILL” to “FrEE.” If the L.E.D. display is programmed for “No Flash” (“nFLS”), the microprocessor controller (computer) will then prompt you on whether you would like “FILL” displayed or the “Amount To Start” (“AtSt”).

BAD COIN LOCKOUT ST ATUS (bCLO)

In this program status (“bCLO”), each coin entry is monitored. Should someone tamper with the coin acceptor or attempt to insert a foreign object, the Phase 5 coin microprocessor controller (computer) will “LOCKOUT” and not accept any entries until the reset time has elapsed (approximately 15-seconds). Once the reset time has expired, the Phase 5 coin microprocessor controller (computer) will automatically reset itself immediately for the next entry.

BAD COIN RESET (bCrS)

When set in this program (“bCrS”), the Phase 5 coin microprocessor controller (computer) counts in milliseconds the amount of time required for a coin entry signal. If someone should tamper with the coin acceptor or attempt to insert a foreign object, the Phase 5 coin microprocessor controller (computer) will not accept the entry and will automatically reset itself immediately for the next entry.

ACCUMULA TIVE TIME (AtIn)

SINGLE COIN)

(

In this program mode (“AtIn”), each coin inserted has a specific value in time which is determined by the “Time For Amount To Start” (“tFAS”) program (PL11).

Example No. 1: If the dryer is equipped with a 25¢ coin acceptor and the desired time is 30 minutes, each

additional coin inserted would yield 30 minutes.

Settings: PL09 (LCdE) ........................ 2 5

PL11 (tFAS) .......................... 3 0

PL12 (AtSt) ........................... 25

Example No. 2: If the dryer is equipped with a 25¢ coin acceptor and the “Amount To Start” (“AtS t”) is 50¢

for 30 minutes, the insertion of each additional coin would yield 15 minutes. In this application the “Time For Amount To Start” (“tFAS”) is determined by a Phase 5 coin microprocessor controller (computer) calculation. There is no calculation required by the owner .

Formula: (LCdE/AtSt) (tFAS) = Vended Time for “ LCdE” (25¢/50¢) (30) = 15 minutes

Settings: PL09 (LCdE) ........................ 2 5

PL11 (tFAS) .......................... 3 0

PL12 (AtSt) ........................... 50

(DUAL COIN)

In the accumulative time (AtIn) mode, when using a dual coin acceptor, once the “Amount To Start” (“AtSt”) has been inserted, the addition of a coin(s) yields more time. The amount time accumulated for each additional coin inserted is determined by the “Time For Amount To Start” (“tFAS”) program (PL11).

The “Time For Amount To Start” (“tFAS”) is determined by a Phase 5 coin microprocessor controller (computer) calculation of additional amounts installed.

Formula: (LCdE/AtSt) (tFAS) = Vended Time

Example No. 1: Using a 10¢/25¢ dual coin acceptor with the desired “Amount To Start” (“AtSt”) being 25¢

for 15 minutes, each additional 10¢ would yield the following:

Formula: (LCdE/AtSt) (tFAS) = Vended Time for “LCdE” (10¢/25¢) (15 minutes) 6 minutes

Settings: PL09 (LCdE) ........................ 1 0

PL10 (rCdE) ......................... 2 5

PL11 (tFAS) .......................... 1 5

PL12 (AtSt) ........................... 25

Example No. 2: If the dryer is equipped with a 10¢/25¢ dual coin acceptor and the desired “Amount To

Start” (“AtSt”) is 35¢ for 14 minutes, each additional 10¢ inserted would yield 4 minutes and each additional 25¢ would yield 10 minutes.

Formula: (LCdE/AtSt) (tFAS) = Vended Time for “LCdE” (10¢/35¢) (14 minutes) 4 minutes

Settings: PL09 (LCdE) ........................ 1 0

PL10 (rCdE) ......................... 2 5

PL11 (tFAS) .......................... 1 4

PL12 (AtSt) ........................... 35

Example No. 3: If the dryer is equipped with a 10¢/25¢ dual coin acceptor and the desired “Amount To

Start” (“AtSt”) is 55¢ for 33 minutes, each additional 10¢ inserted would yield 6 minutes, and each additional 25¢ would yield 15 minutes.

Formula: (LCdE/AtSt) (tFAS) = Vended Time for “LCdE” (10¢/55¢) (33 minutes) 6 minutes

Settings: PL09 (LCdE) ........................ 1 0

PL10 (rCdE) ......................... 2 5

PL11 (tFAS) .......................... 3 3

PL12 (AtSt) ........................... 55

NOTE: If the total V end T ime cannot be divided evenly by the “Amount T o Start” (“AtSt”), the “Tim e

For Amount T o Start” will calculate precisely the amount of the time entitled to the purchaser.

Formula: (LCdE/AtSt) (tFAS) = Vended Time for “LCdE” (10¢/35¢) = 2.85 minutes

(2 minutes and 51-seconds)

Settings: PL09 (LCdE) ........................ 1 0

PL10 (rCdE) ......................... 2 5

PL11 (tFAS) .......................... 1 0

PL12 (AtSt) ........................... 35

ACCUMULA TIVE COIN (ACOn)

When this program mode (“ACOn”) is selected, additional time can only be achieved when the “Amount For Additional Time” (“AFAt”) PL13 has been inserted.

NOTE: When programming, to use the Accumulative Coin Mode (“ACOn”), the following parameters/

programs need to be checked and/or changed accordingly:

Settings: PL01 ................“ACOn” (“Accumulative Coin”)

PL13 ................ “AFAt” (“Amount For Additional Time”)

(SINGLE COIN ACCEPTOR)

Example No. 1: Using a 25¢ coin acceptor with the desired “Amount To Start” (“AtSt”) being 50¢ for 24

minutes, the Phase 5 coin microprocessor controller (computer) would yield more time (24 minutes) only when an additional 50¢ is inserted. For this application, the “Time For Amount To Start” (“tFAS”) program (PL11) is determined as follows:

Formula: (AFAt/AtSt) (tFAS) = Vended Time for “AFAt” (50¢/50¢) (24 minutes) = 24 minutes

Settings: PL09 (LCdE) ........................ 2 5

PL11 (tFAS) .......................... 2 4

PL12 (AtSt) ........................... 50

PL13 (AFAt) ......................... 5 0

(DUAL COIN ACCEPTOR)

With a dual coin acceptor the “T ime For Amount To Start” (“tFAS”) is determined as shown below:

Formula: (AFAt/AtSt) (tFAS) = Vended Time for “AFAt”

Example No. 1: Using a 10¢/25¢ dual coin acceptor the desired “Amount To Start” (“AtSt”) is 50¢ for 20

minutes and the “Amount for Additional T ime” (“AFAt”) is set for 20¢ each additional 20¢ would yield 8 minutes.

Formula: (AFAt/AtSt) (tFAS) = Additional Vended Time (20/50) (20 minutes) = 8 minutes

Settings: PL09 (LCdE) ........................ 1 0

PL10 (rCdE) ......................... 2 5

PL11 (tFAS) .......................... 2 0

PL12 (AtSt) ........................... 50

PL13 (AFAt) ......................... 2 0

Example No. 2: If the dryer is equipped with a 10¢/25¢ dual coin acceptor and the desired “Amount To

Start” (“AtSt”) is 35¢ for 14 minutes and the “Amount For Additional T ime” (“AF At”) is set for 25¢, each additional 25¢ inserted would yield 10 minutes.

Formula: (AFAt/AtSt)(tFAS) = Vended Time for “AFAt” (25¢/35¢) (14 minutes) = 10 minutes

Settings: PL09 (LCdE) ........................ 1 0

PL10 (rCdE) ......................... 2 5

PL11 (tFAS) .......................... 1 4

PL12 (AtSt) ........................... 35

PL13 (AFAt) ......................... 25

ROTATIONAL SAFE GUARD - OPTIONAL (nSEn)

This program monitors the rotation of the basket (tumbler) and works in conjunction with a special sensor (optional) located at the rear basket (tumbler) support area of the dryer. If the basket (tumbler) (i.e., broken belt, failed motor, etc.), the Phase 5 microprocessor controller (computer) will disable ALL outputs (shut the dryer down), the buzzer (tone) will sound (for time programmed), and the light emitting diode (L.E.D.) display will read a failure message “SEFL” (Rotational Sensor Circuit Failure). The failure code must be cancelled manually by opening and closing the Program Switch (PS). This program selection (option) can be programmed to be active (“SEn”) or inactive (“nSEn”).

is not rotating

NOTE: This parameter is programmed by the factory to be inactive (“nSEn’) unless the dryer was

manufactured with optional “rotational sensor.”

PL02 - PERCENT DRY (PdrY)

When in the automatic mode, the dryer will run until the preset level of dryness has been reached or until the Maximum Auto Dryness Time (Adrt) has been reached or until the Maximum Auto Dryness Time (Adrt) has expired. The dryness level is programmable from a minimum of ninety percent (90%) to a maximum of one hundred percent (100%).

NOTE: Due to humidity, atmospheric pressure, water retention in the garment etc., the desired

“Percent Dry” (“PdrY”) may vary . It is suggested that the owner determine which level of dryness (90% to 100%) is best suited for his/her application by experimenting with a few test loads.

PL03 - HIGH TEMPERATURE (HI°F)

The high operating temperature is programmable from a minimum of 100° F to a maximum of 190° F in ten-degree increments or from a minimum of 38° C to a maximum of 88° C in five-degree increments.

For the AD-26 and AD-295 any three (3) of the selections (HI/LO/PP) are programmable from a minimum of 100° F to a maximum of 170° F in ten-degree increments or from a minimum of 38° C to a maximum of 77° C in five-degree increments.

PL04 - HIGH COOL DOWN TEMPERATURE/TIME (HICd)

The first part of this program controls the cool down temperature when the Phase 5 microprocessor controller (computer) is used in the automatic mode. The cool down temperature is programmable from a minimum of 70° F to a maximum of 190° F in ten-degree increments or from a minimum 21° C to a maximum of 88° C in five-degree increments.

The second part of this program controls the cool down time for both the automatic and timed modes. The cool down time can be programmed from a minimum of 0 to a maximum of 9 minutes.

NOTE: When the Phase 5 microprocessor controller (computer) is used in the automatic mode, at the

end of the drying cycle, the Phase 5 microprocessor controller (computer) will start the cooling cycle for the cool down time programmed or until the temperature has dropped to the programmed cool down temperature, whichever of the two (2) comes first.

PL05 - LOW TEMPERATURE (LO°F)

Same as PL03 but for Low Temperature program.

PL06 - LOW COOL DOWN TEMPERATURE/TIME (LOCd)

Same as for PL04 but for Low Cool Down Temperature/Time.

PL07 - PERMANENT PRESS (PP°F)

Same as PL03 but for Permanent Press.

PL08 - PERMANENT PRESS COOL DOWN TEMPERATURE/TIME (PPCd)

Same as PL04 but for Permanent Press Cool Down Temperature/Time.

PL09 - LEFT COIN SLOT DENOMINA TION (LCdE)

In the case of a single coin acceptor, this program setting is determined by the value of the coin acceptor (i.e., 25¢).

When a dual coin acceptor is used, the program setting is determined by the left coin slot coin acceptor value (lower coin value).

Program settings are from a minimum of 1 to a maximum of 9999.

PL10 - RIGHT COIN SLOT DENOMINA TION (rCdE)

This program need only be set when a dual coin acceptor is used. The program setting is determined by the value of the right coin acceptor slot (higher value).

Program settings are from a minimum of 1 to a maximum of 9999.

When used in conjunction with the Left Coin Slot Denomination program, the Phase 5 microprocessor controller (computer) automatically calculates the ratios necessary for coin insertion time values.

PL11 - TIME FOR AMOUNT TO START (tFAS)

This program is set for the specific value in TIME that will be vended for the programmed “Amount To Start” (“AtSt”) the dryer. For example, if 25¢ is required to start the dryer for 10 minutes, the settings would be...

PL11 “Time for Amount To Start” ..........“tFAS” = 10

PL12 “Amount To Start” ......................... “AtSt” = 25

In addition, with the “Time For Amount To Start” (“tFAS”) and the “Amount To Start” (PL12 - “AtSt”) programmed along with the type of coin acceptor (denominations) on the dryer (i.e. 10¢/25¢), the Phase 5 microprocessor controller (computer) will do inserted after the initial “Amount T o Start” has been inserted - including both accumulative coin program settings. For example, if a dryer is equipped with a 10¢/25¢ dual coin acceptor and the desired “Amount To Start” (“AtSt”) is 55¢ for 33 minutes (“tFAS”), with the microprocessor controller (computer) set for accumulative time 10¢/25¢ dual coin acceptor and the desired “Amount To Start” (“AtSt”) is 55¢ for 33 minutes (“tFAS”), with the microprocessor controller (computer) set for accumulative time, after initial “Amount To Start” is inserted (55¢), each additional 10¢ inserted would yield 6 minutes, and each additional 25¢ inserted would yield 15 minutes.

ALL calculations and vend the correct amount of time for any coin

PL12 - AMOUNT TO START (AtSt)

This program sets the “Amount To Start” the dryer and can be programmed from a minimum of 1 to a maximum of 9999.

PL13 - MINIMUM AMOUNT FOR ADDITIONAL TIME (AFAt)

This program need only be set when the Phase 5 microprocessor controller (computer) is set in the “Accumulative Coin” (“ACOn”) mode (PL01). The value set for this program is what will have to be inserted for more time after the “Amount To Start” (“AtSt”) has been inserted.

Example No. 1: “Amount To Start” (“AtSt”) is 50¢ for 30 minutes and an additional 50¢ is required for more

time. In this example PL13 should be set for 50¢.

PL14 - MAXIMUM TIME FOR AUTOMATIC DRY (Adrt)

This program is used only when the Phase 5 microprocessor controller (computer) is set in the Automatic Mode. This program controls the maximum time the dryer will run even if the Dryness Level program (PL02) has not been reached.

PL15 - ANTI-WRINKLE TIMING

1. Guard Delay Time (GdLY)

This program controls the dwell (stop) time and activation of anti-wrinkle “Guard On T ime” (“Gont”). The dwell (stop) time can be programmed from a minimum of 1 minute to a maximum of 9 minutes in 1 minute increments.

Guard On Time (Gont)

The setting controls the amount of time that the basket (tumbler) will turn, without heat, when the Anti-Wrinkle is active (“Grd”). The “Guard On Time” (“Gont”) is programmable from a minimum of 1-second to a maximum of 99-seconds in 1-second increments.

PL16 - ACTIVE GUARD TIME (AGt)

This program controls the maximum time that the Anti-W rinkle Program will be active and is programmable from a minimum of 1 minute to a maximum of 99 minutes in 1 minute increments.

PL17 - “A” and “b” F ACTORS

This location will include the “Auto-Cycle” parameters. These parameters are necessary to allow the Phase 5 microprocessor controller (computer) to calculate the percentage of dryness in the basket (tumbler). The “A” Factor is adjustable from 1 to 99.

These parameters are the factors that the Phase 5 microprocessor controller (computer) utilizes when programmed for an “Automatic Drying Cycle.” The “A” Factor slope program, pertains to the thermal characteristic of each model dryer. The “b” Factor, heat loss (offset) program, also pertains to the thermal characteristics of each model dryer. This factor setting is dependent upon the model dryer and type of heating unit.

The “A” and “b” Factors have not been preprogrammed by the factory and must be programmed if the Phase 5 microprocessor controller (computer) programming is changed to be used in the Automatic Mode. The “A” and “b” Factors must be programmed for the particular dryer model and heating unit as shown in the “A” and “b” Factor (parameter) table on page 60 of this manual.

SECTION V

PROGRAMMING INSTRUCTIONS

A. INTRODUCTION TO PROGRAMMING

The various program (parameters) dryer selections are stored in the computer memory and are cataloged as “Program Locations” (PL) 1 through 17. These programs (parameters) have been preprogrammed by the factory as noted on and page 54 and page 55 (for dryer models AD-26/AD-295 and AD-540/WDA-540 ONLY) of this manual. The various program selections available are outlined in the proceeding section (Section IV).

ALL programming is done through the keyboard (touch pad) selection buttons on the front of the control panel. T o change programs (parameters) or to put the Phase 5 microprocessor controller (computer) in the temperature display mode or the coin count display mode, the Program Switch (PS) located on the back side of the microprocessor controller (computer) must be put into the (down) position (PSC).

First make sure there is no cycle in progress and the light emitting diode (L.E.D.) display reads “FILL” and/or “Amount To Start,” or “FILL” and/or “FrEE.” Close the Program Switch (PSC). The L.E.D. display will now read the temperature in the dryer (i.e., 72° F [22° C]). From this point, any of the 17 program locations can be accessed by pressing the “PERM PRESS” key once, at which time the L.E.D. display will read “PL01.”

page 52 and page 53 (for ALL models except AD-26/AD-295 and AD-540/WDA-540)

To alter programming, the operator must first locate the program location or parameter to be changed. To advance to the specific program location press the “HI TEMP” key until the desired program location is displayed (i.e. PL01, PL02, etc.). The “LO TEMP” key will advance the program locations downward (i.e., PL11, PL10, etc.). Once the correct program location is displayed and access to change is desired, press the “PERM PRESS” key. The “PERM PRESS” key provides two (2) functions:

1. Allows access into a Program Location (PL).

2. Advances to next bit (part of a program location) or next location.

NOTE: When in a Program Location (PL) and the “PERM PRESS” key is pressed, whatever

parameter is displayed will be stored in the microprocessor controller’s (computer’ s) memory and the programming is now advanced to the next step (bit) or program location.

The “HI TEMP” or “LO TEMP” keys provide the following functions:

1. Change numeric values...“HI TEMP” increases and “LO TEMP” decreases.

2. Flip-flop for status changes...by pressing either key, a status will revert back and forth no matter which of

the two (2) keys is pressed.

If the change to be made is a numerical one (i.e., time or temperature), the operator must now press the “HI TEMP” key to increase the number value, or press the “LO TEMP” key to lower/increase the number value. Pressing the “PERM PRESS” key will store the change and advance to the next step (bit) or program location.

NOTE: To accelerate increase/upward value, press and hold in “HI TEMP” key . T o accelerate

decrease/downward value, press and hold in “LO TEMP” key .

NOTE: When making numerical changes, please keep in mind to stay within the programming limits

shown.

If the change to be made is a status change (i.e., to change from °FAr to °CEL) simply press the “HI TEMP” or “LO TEMP” key and the light emitting diode (L.E.D.) display will revert back and forth between status choices (i.e. “Grd” and “nGrd”). Once the correct status is displayed, pressing the “PERM PRESS” key will store the change and advance to the next step (bit) or program location.

Once the change or changes desired are made, to exit program mode flip up (open) the Program Switch (PS).

NOTE: You can exit the programming mode at any time (even if you are in the middle of a program

location) by simply opening the Program Switch (PS). However, if a change was made be sure the “PERM PRESS” key is pressed before opening the Program Switch (PS) to insure the change was stored in the microprocessor controller’s (computer’s) memory .

B. PROGRAMMING (FLOWCHARTS)

This section explains the programming through the use of flowcharts. A flowchart is nothing more than a diagram of the programming process.

Represents the microprocessor L.E.D. display. For example, if the flowchart shows the symbol “FILL,” the computer L.E.D. display will read the same.

Represents the key on the label that is to be pressed. For example, if flowchart shows “HI TEMP,” you would press that key on the label.

Represents the program path.

On the side of each flowchart is an explanation of the chart procedures, in some cases, the programming limits.

Dryer Off (Power On)

(No cycle in progress)

Display Reads

FILL

To enter temperature display

Display Reads

To enter program locations press the “Perm Press” keyboard (touch pad) selection button.

Display Reads

T o advance to next program location press the “HI Temp” selection button.

Display Reads

and/or

(Close Program Switch)

75F

Perm Press

PL01

HI Temp

PL02

Amount To start

(Dryer Temperature Display)

To accelerate advance, press and hold in “HI Temp” selection button.

Display Reads Program Location and will advance until “HI T emp” selection button is released.

To revert back to lower program locations push “LO T emp” selection button.

Display Reads

HI Temp

PL03

PL04

PL05

LO Temp

PL04

Continued

To accelerate press and hold in “LO Temp” selection button.

Display reads program locations and will advance downward until “LO Temp” selection button is released.

T o enter a specific program location (i.e. PL01) push the “Perm Press” selection button.

Display will read specific program location called up.

LO Temp

PL03

PL02

PL01

Perm Press

°FAr

(Example)

T o exit program mode, open program switch. Display reads.

FILL

and/or

SECTION VI

PROGRAMMING

A. TEMPERATURE DISPLAY MODE

FILL

and/or

(Close Program Switch)

75F

Cycle In Progress

HI°2°0

(Close Program Switch)

13°5°F

(Amount T o Start)

(Dryer Temperature Display)

(T emperature Selection/Time)

HI Temp

(Open Basket [Tumbler] Door-Dryer Shuts Off)

135F

(Close Door - Open Program Switch)

LO Temp Perm Press

LO°2°0

(Dryer Temperature Display)

B. LEFT COIN COUNT

FILL 25

(No Cycle in Progress)

(Amount To Start)

and/or

To cancel or delete left coin count, press “HI Temp” key.

Display will read “CLCC” (cancel left coin count).

Press “Perm Press” key and display will read “0000” (coin count cancelled).

Press “Perm Press” key and display will read “rCC” (right coin count).

(Close Program Switch)

To cancel coin count

HI Temp

CLCC

Perm Press

0000

Perm Press

70F

HI Temp

LCC

Perm Press

0126

To retain coin count

Perm Press

rCC

To Exit

HI Temp

0000

70F

(Dryer Temperature Display)

Press “HI Temp” key.

Display will read “LCC” (left coin count).

Press “Perm Press” key to display coin count.

Display will read actual coin count. I.E. 0126 = 126 units or coins.

T o retain or save existing coin count press “Perm Press.”

Display will read “rCC” (right coin count). T o exit press “HI Temp.”

Display will read “0000” for 1-second and then dryer temperature display .

To review rCC

proceed to flow

chart C

To exit

program

mode open

program

switch

C. RIGHT COIN COUNT

(No Cycle In Progress)

HI Temp

To cancel or delete right coin count, press “HI Temp” key.

Display will read “CrCC (cancel right coin count).

Press “Perm Press” key and display will read “0000” (coin count cancelled).

FILL 25

LCC

To cancel coin count

HI Temp

CrCC

Perm Press

0000

and/or

(Close Program Switch)

70F

rCC

Perm Press

0192

To retain coin count

Perm Press

0000

70F

(Amount T o Start)

(Dryer Temperature Display)

Press “HI Temp” key. Display will read “LCC” (left coin count).

Press “HI Temp” key. Display will read “rCC” (right coin count).

Press “Perm Press” key to display coin count.

Display will read actual coin count. I.E. 0192 = 192 units or coins.

To retain or save existing coin count press “Perm Press.”

Display will read “0000” for 1-second and then dryer temperature display .

Press “Perm Press”

Perm Press

key.

To exit

program

mode open

program

switch

D. PROGRAM LOCATION 01 (PL01)

(No Cycle In Progress)

LO Temp

°FAr

FILL 25

(Close Program Switch)

70F

Perm Press

PL01

Perm Press

and/or

HI Temp

LO Temp

(Amount To Start)

To enter program mode, close program switch.

(Dryer Temperature Display)

Press “Perm Press” key. Display will read “PL01,” program location 01. Press “Perm Press” key. Display will read temperature conversion status, either Fahrenheit or Celsius. If no change, press “Perm Press” key. Should a change be necessary, press “HI” or “LO” key and then press “Perm Press” key.

°CEL

HI Temp

LO Temp

°CEL

tInE

AUtO

HI Temp

Perm Press

Continue

LO Temp

°FAr

Display will read timing status, (timed or automatic). If no change, press “Perm Press” otherwise press “HI” or “LO” key and then “Perm Press” key.

AUtO

HI Temp

tInE

Continue

Perm Press

Display will read anti-wrinkle (guard) program status. If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then “Perm Press.”

LO Temp

nGrd

Grd

bUZ

nbUZ

HI Temp

Perm Press

LO Temp

nbUZ

bUZ

HI Temp

Grd

HI TempLO Temp

nGrd

If guard (Grd) was selected, display will read tone/buzzer status. If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then “Perm Press” key.

FrEE

Perm Press

HI TempLO Temp LO Temp HI Temp

Perm Press

Continue

FrEECoin

Coin

Display will read vend status, either “Coin” (coins required to start) or “FrEE” (no coins required). If no change, press “Perm Press” otherwise press “HI” or “LO” keys and then “Perm Press” key.

Continue

Display will read light emitting diode (L.E.D.) display status. Either no flash (nFLS) or flash (FLS). If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then “Perm Press” keys.

If no flash is selected, display will read “fixed display” status. I.E. “AtSt” amount to start dryer or “Free Dry Mode” or “FILL.” If no change, press “Perm Press” otherwise press “HI” or “LO” keys and then press “Perm Press” key.

nFLS

FLS

LO Temp

AtSt

FILL

Perm Press

HI Temp

Perm Press

FLS

nFLS

HI TempLO TempHI TempLO Temp

LO Temp

FILL

HI Temp

AtSt

Display will read coin monitor status, “bCrS” bad coin reset, or “bCLO” bad coin lockout. If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then “Perm Press” key.

bCLO

HI TempLO Temp LO Temp

Perm Press

Continue

bCLObCrS

HI Temp

bCrS

Continue

LO Temp

AtIn

ACOn

SEn

nSEn

HI Temp

Perm Press

LO Temp

ACOn

HI TempLO TempHI TempLO Temp

AtIn

nSEn

HI Temp

SEn

Perm Press

PL02

To exit

Proceed to

next location

to be changed

program

mode open

program

switch

Display will read coin/time accumulation status. I.E. “AtIn” accumulative time or “ACOn” accumulative coin. If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then press “Perm Press” key.

Display will read basket rotational sensor status. “SEn” sensor active or “nSEn” sensor not active. If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then press “Perm Press” key.

E. PROGRAM LOCATION 02 (PL02)

Percent dry from 90 to 100%

LO Temp

Refer to

Section V

for instructions

on entering program locations.

PL02

Perm Press

Pdry

(Wait 3-Seconds)

100 HI Temp

Location to be viewed/changed.

Display reads “PdrY” percent of dryness and the actual numeric value programmed (90-100%). If no change, press “Perm Press” key, otherwise press the “HI” or “LO” keys and then “Perm Press” key.

Dryness level IncreaseDryness level decrease

("Hold In" to Accelerate) ("Hold In" to Accelerate)

Perm Press

PL03

To exit

Proceed to

next location

to be changed

program

mode open

program

switch

Summary: The percentage of dryness is programmable from a minimum of 90% to a maximum of 100%.

F. PROGRAM LOCATION 03 (PL03)

HI Temp

Refer to

on entering program locations.

Temperature Decrease

LO Temp

Section V

for instructions

PL03

Perm Press

HI°F

(Wait 3-Seconds)

Temperature Increase

180F HI Temp

Location to be viewed/changed.

Press “Perm Press” key.

Display will read “HI°F,” “HI Temp” key status for 3-seconds and then the actual temperature programmed. If no changes, press “Perm Press” key otherwise press “HI” or “LO” keys and then “Perm Press” key.

Perm Press

Automatically goes into PL04

Program without PL04 Display

Mode

Continued on next page

Summary: HI Temp is programmable from a minimum of 100° F to a maximum of 190° F in ten-degree increments

or from a minimum of 38° C to a maximum of 88° C in five-degree increments.

G. PROGRAM LOCATION 04 (PL04)

HI Temp cool down temperature/time

Refer to

Section V

on entering program locations.

for instructions

PL04

Location to be viewed/changed.

Press “Perm Press” key.

Perm Press

Display will read “HICd,” HI Temp cool down status for 3-seconds and then the actual temp and time programmed.

Continued from F.

HICd

If no change press “Perm Press” key twice, otherwise press “HI” or “LO” keys and

(Wait 3-Seconds)

then “Perm Press” key.

Temperature Decrease Temperature Increase

LO Temp

100·2

Perm Press

HI Temp

Time Decrease Time Increase

LO Temp HI Temp

100·2

Perm Press

PL05

Proceed to next location

to be changed

To exit program mode,

open program switch

Summary: Cool down temperature is programmable from a minimum of 70° F to a maximum of 190° F in ten

degree increments or from a minimum of 21° C to a maximum of 88° C in five-degree increments.

For the AD-540 and WDA-540 any three (3) of the selections (HI/LO/PP) are programmable from

a minimum of 100° F to a maximum of 160° F in ten-degree increments or from a minimum of 38° C to a maximum of 71° C in five-degree increments.

Cool down is programmable from 0 to 9 minutes.

H. PROGRAM LOCATION 05 (PL05)

LO Temp

Refer to

Section V

on entering program locations.

Perm Press

for instructions

PL05

Location to be viewed/changed.

Press “Perm Press” key.

Display will read “LO°F,” LO Temp status for 3-seconds and then the

LO°F

actual temperature programmed. If no changes, press “Perm Press” key otherwise press “HI” or “LO”

(Wait 3-Seconds)

keys and then “Perm Press” key.

Temperature Decrease Temperature Increase

LO Temp

120F HI Temp

Perm Press

Automatically goes into PL06

Program without PL06 Display Mode

Continued on next page

Summary: LO T emp is programmable from a minimum of 100° F to a maximum of 190° F in ten-degree increments

or from a minimum of 38° C to a maximum of 88° C in five-degree increments.

I. PROGRAM LOCATION 06 (PL06)

LO Temp cool down temperature/time

Refer to

Section V

on entering program locations.

for instructions

PL06

Perm Press

LOCd

(Wait 3-Seconds)

Temperature Decrease

LO Temp

100·2

Perm Press

Time Decrease

LO Temp HI Temp

100·2

Location to be viewed/changed.

Press “Perm Press” key.

Display will read “LOCd,” LO Temp cool down status for 3-seconds and then the actual temperature and time programmed. If no changes, press “Perm Press” key twice, otherwise press “HI” or “LO” keys and then “Perm Press” key.

Temperature Increase

HI Temp

Time Increase

Perm Press

PL07

Proceed to next location

to be changed

To exit program mode,

open program switch

Summary: Cool down temperature is programmable from a minimum of 70° F to a maximum of 190° F in ten

degree increments or from a minimum 21° C to a maximum of 88° C in five-degree increments.

Cool down is programmable from 0 to 9 minutes.

J. PROGRAM LOCATION 07 (PL07)

Perm Press Temp

Refer to

Section V

for instructions

on entering program locations.

PL07

Location to be viewed/changed.

Press “Perm Press” key.

Perm Press

Display will read “PP°F,” “Perm Press” temperature key status for 3-seconds

PP°F

and then actual temperature programmed. If no change, press “Perm Press” key otherwise press “HI” or “LO” keys

(Wait 3-Seconds)

and then “Perm Press.”

Temperature Decrease Temperature Increase

LO Temp

150F HI Temp

Perm Press

Automatically goes into PL08 Program without PL08 Display Mode

Continued on next page

Summary: Perm Press Temp is programmable from a minimum of 100° F to a maximum of 190° F in

ten-degree increments or from a minimum of 38° C to a maximum of 88° C in five-degree increments. For the AD-26 and AD-295 any three (3) of the selections (HI/LO/PP) are programmable from a minimum of 100° F to a maximum of 170° F in ten-degree increments or from a minimum of 38° C to a maximum of 77° C in five-degree increments.

K. PROGRAM LOCATION 08 (PL08)

Perm Press Cool Down Temperature/Time

Refer to

Section V

on entering program locations.

PL08

for instructions

Location to be viewed/changed.

Press “Perm Press” key.

Continued from J.

Perm Press

Display will read “PPCd,” “Perm Press” key cool down status for 3-seconds and then cool down temperature and time

PPCd

programmed. If no changes, press “Perm Press” key twice. Otherwise, press “HI” or “LO” keys and then “Perm Press” key.

(Wait 3-Seconds)

Temperature Decrease

LO Temp

·100·3 HI Temp

Perm Press

T emperature Increase

Time Decrease Time Increase

100·3LO Temp HI Temp

Perm Press

Proceed to next location

to be changed

Summary: Cool down temperature is programmable from a minimum of 70° F to a maximum of 190° F in

ten-degree increments or from a minimum 21° C to a maximum of 88° C in five-degree increments. For the AD-26 and AD-295 any three (3) of the selections (HI/LO/PP) are programmable from a minimum of 100° F to a maximum of 170° F in ten-degree increments or from a minimum of 38° C to a maximum of 77° C in five-degree increments.

Cool down is programmable from 0 to 9 minutes.

PL09

To exit program mode,

open program switch

L. PROGRAM LOCATION 09 (PL09)

Left Coin Denomination

Refer to

Section V

for instructions

on entering program locations.

PL09

Location to be viewed/changed.

Press “Perm Press” key.

Perm Press

Display will read “LCdE,” left coin denomination for 3-seconds and the left coin acceptor denomination

LCdE

programmed (I.E. 25¢). If no change, press “Perm Press” key, otherwise press “HI” or “LO”

(Wait 3-Seconds)

keys and then “Perm Press” key.

Amount Decrease Amount Increase

LO Temp

10 HI Temp

("Hold In" to Accelerate) ("Hold In" to Accelerate)

Perm Press

PL10

Proceed to next location

to be changed

To exit program mode,

open program switch

Summary: The left coin denomination is programmable from 1 to 9999.

IMPORTANT: When the dryer is equipped with a dual coin acceptor, the value set here is the lower

value denomination, which is not necessarily the left coin portion of the acceptor .

NOTE: For single coin models this parameter must be set for the value of the acceptor . I.E. 25¢

acceptor = 25.

M. PROGRAM LOCATION 10 (PL10)

Right Coin Denomination

Amount Decrease

Refer to

Section V

on entering program locations.

Perm Press

(Wait 3-Seconds)

for instructions

PL10

rCdE

Location to be viewed/changed.

Press “Perm Press” key.

Display will read “rCdE,” right coin denomination for 3-seconds and the right coin acceptor denomination programmed (I.E. 25¢). If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then “Perm Press” key.

Amount Increase

LO Temp

("Hold In" to Accelerate) ("Hold In" to Accelerate)

Proceed to next location

to be changed

25 HI Temp

Perm Press

PL11

To exit program mode,

open program switch

Summary: The right coin denomination is programmable from 1 to 9999.

IMPORTANT: When the dryer is equipped with a dual coin acceptor , the value set here is the higher

value denomination, which is not necessarily the right coin portion of the acceptor.

NOTE: For single coin models this parameter need not to be set.

N. PROGRAM LOCATION 11 (PL11)

Time For Amount To Start

Refer to

Section V

for instructions

on entering program locations.

PL11

Perm Press

tFAS

(Wait 3-Seconds)

Location to be viewed/changed.

Press “Perm Press” key.

Upper display will read “tF AS” (Time For Amount To Start) and the lower display will read the actual amount programmed. If no change, press the “PERM PRESS” key, otherwise press the “HI TEMP” key or the “LO TEMP” key and then press the “PERM PRESS” key.

Time Decrease

LO Temp

("Hold In" to Accelerate) ("Hold In" to Accelerate)

4 HI Temp

Time Increase

Perm Press

PL12

Proceed to next location

to be changed

Summary: The time for amount to start is programmable from 1 to 99 minutes.

To exit program mode,

open program switch

O. PROGRAM LOCATION 12 (PL12)

Amount To Start

Refer to

Section V

for instructions

on entering program locations.

PL12

Perm Press

AtSt

Location to be viewed/changed.

Press “Perm Press” key.

Display will read “AtSt,” amount to start for 3-seconds and then time programmed. If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then “Perm

(Wait 3-Seconds)

Press” key.

Amount Decrease Amount Increase

LO Temp

("Hold In" to Accelerate) ("Hold In" to Accelerate)

25 HI Temp

Perm Press

PL13

Proceed to next location

to be changed

To exit program mode,

open program switch

Summary: The amount to start is programmable from 1 to 9999.

P. PROGRAM LOCATION 13 (PL13)

Coin Accumulation Minimum Amount for More Time

Refer to

Section V

for instructions

on entering program locations.

PL13

Perm Press

AFAt

(Wait 3-Seconds)

Location to be viewed/changed.

Press “Perm Press” key.

Display will read “AF At,” amount for additional time (ACOn mode only) for 3-seconds and then amount programmed. If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then “Perm Press” key.

Amount Decrease

LO Temp

("Hold In" to Accelerate) ("Hold In" to Accelerate)

10 HI Temp

Amount Increase

Perm Press

PL14

Proceed to next location

to be changed

To exit program mode,

open program switch

Summary: The amount to start is programmable from 1 to 9999.

Q. PROGRAM LOCATION 14 (PL14)

Maximum Time for Auto Dry

Refer to

Section V

for instructions

on entering program locations.

PL14

Perm Press

Adrt

Location to be viewed/changed.

Press “Perm Press” key.

Display will read “Adrt,” automatic maximum drying time for 3-seconds and then time programmed. If no change, press “Perm Press” key, otherwise press “HI” or “LO”

(Wait 3-Seconds)

keys and then “Perm Press” key.

Time Decrease Time Increase

LO Temp

("Hold In" to Accelerate) ("Hold In" to Accelerate)

25 HI Temp

Perm Press

PL15

Proceed to next location

to be changed

To exit program mode,

open program switch

Summary: The maximum auto dryness time is programmable from 1 to 99 minutes.

R. PROGRAM LOCATION 15 (PL15)

Anti-Wrinkle T iming

Refer to

Section V

on entering program locations.

for instructions

PL15

Location to be viewed/changed.

Press “Perm Press” key.

Perm Press

Display will read “GdL Y,” guard delay time for 3-seconds and then time

GdLY

programmed. If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then “Perm Press” key.

(Wait 3-Seconds)

Time Decrease

LO Temp

("Hold In" to Accelerate) ("Hold In" to Accelerate)

2 HI Temp

Perm Press

Time Increase

Gont

(Wait 3-Seconds)

Time Decrease

LO Temp HI Temp

("Hold In" to Accelerate) ("Hold In" to Accelerate)

Perm Press

Time Increase

Display will read “Gont” anti-wrinkle

Proceed to next location

to be changed

PL16

on time for 3-seconds and then time programmed. If no changes, press “Perm Press” key , otherwise press “HI” or “LO”

To exit program mode,

open program switch

Sum ma ry : Guard delay time is programmable from 1 to 9 minutes. Guard on time is programmable from

1 to 99-seconds.

keys and then “Perm Press” key .

S. PROGRAM LOCATION 16 (PL16) AND PROGRAM LOCATION 17 (PL17)

Maximum Active Anti-Wrinkle Time

Refer to

Section V

on entering program locations.

for instructions

Time Decrease Time Increase

LO Temp

("Hold In" to Accelerate) ("Hold In" to Accelerate)

Refer to

Section V

on entering program locations.

for instructions

Programmable 1 to 9

Factor Decrease

PL16

Perm Press

AGt

(Wait 3-Seconds)

10 HI Temp

Perm Press

PL17

Location to be viewed/changed.

Press “Perm Press” key. Display

Perm Press

will read “A,” and factor programmed for 3-seconds. If no change, press “Perm Press” key, otherwise press

A 6

“HI” or “LO” keys and then “Perm Press” key.

(Wait 3-Seconds)

Location to be viewed/changed.

Press “Perm Press” key. Display will read “AGt,” maximum guard time for 3-seconds and then time programmed. If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then “Perm Press” key.

Factor Increase

LO Temp

("Hold In" to Accelerate) ("Hold In" to Accelerate)

Programmable 1 to 99

Factor Decrease

LO Temp HI Temp

("Hold In" to Accelerate) ("Hold In" to Accelerate)

Proceed to next location

to be changed

To exit program mode,

open program switch

A 6

Perm Press

B 65

Perm Press

70F

HI Temp

Factor Increase

Display will read “B,” and factor programmed for 3-seconds. If no change, press “Perm Press” key, otherwise press “HI” or “LO” keys and then “Perm Press” key.

SECTION VII

FACTORY PRESET

PROGRAMS/PARAMETERS

Unless otherwise specified at the time of ordering, the Phase 5 microprocessor controller (computer) has been preprogrammed by the factory with the following programs/parameters. Should changes be found necessary, please read this microprocessor controller’s (computer’s) programming characteristics.

Phase 5 Coin User’s Manual carefully to thoroughly familiarize yourself with the Phase 5

A. SINGLE COIN ONLY

For ALL dryer models except AD-26/AD-295 and AD-540/WDA-540. (For Single Coin models AD-26/

AD-295 and AD-540/WDA-540 refer to

PL01 - °FAr - Temperatures in Fahrenheit

tInE - Timed mode Grd - Anti-wrinkle guard on bUZ - Anti-wrinkle guard buzzer (tone) on Coin - Coin(s) required to start FLS - Display will flash in intervals between “FILL” and “Amount To Start” bCrS - Bad coin reset AtIn - Accumulative time nSEn - Rotational sensor not selected

PL02 - PdrY - Percent Dry - 97% PL03 - HI°F - 180° PL04 - HICd - Temperature - 100°, Time - 2 minutes PL05 - LO°F - 120° PL06 - LOCd - Temperature - 100°, Time - 2 minutes

PL07 -PP

F - 150°

PL08 - PPCd - Temperature - 100°, Time - 3 minutes PL09 - LCdE - Left coin denomination - 25¢ PL10 - rCdE - Right coin denomination - 25¢ PL11 - tFAS - Time for amount to start -10 minutes PL12 - AtSt - Amount to Start - 25¢ PL13 - AFAt - Amount for additional time - 25¢ PL14 - Adrt - Automatic dry maximum time - 30 minutes PL15 - GdLY - Anti-wrinkle guard off delay time - 2 minutes

Gont - Anti -wrinkle guard on time - 20-seconds

PL16 - AGt - Active anti-wrinkle guard time - 10 minutes PL17 - A and b - “A” is adjustable from 1 to 99 (example: A = 5)

Factors - “b” is adjustable from 1 to 99 (example: B = 75)

page 54).

B. DUAL COIN ONLY

For ALL dryer models except AD-26/AD-295 and AD-540/WDA-540. (For Dual Coin models AD-26/

AD-295 and AD-540/WDA-540 refer to

PL01 - °FAr - Temperatures in Fahrenheit

tInE - Timed mode Grd - Anti-wrinkle guard on bUZ - Anti-wrinkle guard buzzer (tone) on Coin - Coin(s) required to start FLS - Display will flash in intervals between “FILL” and “Amount To start” bCrS - Bad coin reset AtIn - Accumulative time nSEn - Rotational sensor not selected

PL02 - PdrY - Percent Dry - 97% PL03 - HI

F - 180°

PL04 - HICd - Temperature - 100°, Time - 2 minutes PL05 - LO°F - 120° PL06 - LOCd - Temperature - 100°, Time - 2 minutes PL07 -PPOF - 150° PL08 - PPCd - Temperature - 100°, Time - 3 minutes PL09 - LCdE - Left coin denomination - 10¢ PL10 - rCdE - Right coin denomination - 25¢ PL11 - tFAS - Time for amount to start - 10 minutes PL12 - AtSt - Amount To Start - 25¢ PL13 - AFAt - Amount for additional time - 10¢ PL14 - Adrt - Automatic dry maximum time - 30 minutes PL15 - GdLY - Anti-wrinkle guard off delay time - 2 minutes

Gont - Anti-wrinkle guard on time - 20-seconds

PL16 - AGt - Active anti-wrinkle guard time - 10 minutes PL17 - A and b - “A” is adjustable from 1 to 99 (example: A = 5)

Factors - “b” is adjustable from 1 to 99 (example: B = 75)

page 55).

C. SINGLE COIN ONLY

For dryer models AD-26/AD-295 and AD-540/WDA-540 ONLY

PL01 - °FAr - Temperatures in Fahrenheit

PL02 - PdrY - Percent Dry - 98% PL03 -HIOF - 150° PL04 - HICd - T emperature - 80°, Time - 2 minutes PL05 - LO°F - 120° PL06 - LOCd - Temperature - 80°, Time - 2 minutes PL07 - PP°F - 130° PL08 - PPCd - Temperature - 80°, Time - 3 minutes PL09 - LCdE - Left coin denomination - 25¢ PL10 - rCdE - Right coin denomination - 10¢ PL11 - tFAS - Time for amount to start - 10 minutes PL12 - AtSt - Amount to Start - 25¢ PL13 - AFAt - Amount for additional time - 25¢ PL14 - Adrt - Automatic dry maximum time - 30 minutes PL15 - GdLY - Anti-wrinkle guard off delay time - 2 minutes

Gont - Anti-wrinkle guard on time - 20-seconds

PL16 - AGt - Active anti-wrinkle guard time - 10 minutes PL17 - A and b - “A” is adjustable from 1 to 99 (example: A = 5)

Factors - “b” is adjustable from 1 to 99 (example: B = 70)

D. DUAL COIN ONLY

For dryer models AD-26/AD-295 and AD-540/WDA-540 ONLY

PL01 - ° FAr - Temperatures in Fahrenheit

tInE - Timed mode Grd - Anti-wrinkle guard on bUZ - Anti-wrinkle guard buzzer (tone) on Coin - Coin(s) required to start

FLS - Display will flash in intervals between “FILL” and “Amount To Start” bCrS - Bad coin reset AtIn - Accumulative time

nSEn - Rotational sensor not selected

PL02 - PdrY - Percent Dry - 98% PL03 -HI PL04 - HICd - Temperature - 80°, Time - 2 minutes PL05 - LO°F - 120° PL06 - LOCd - Temperature - 80°, Time - 2 minutes PL07 - PP°F - 130° PL08 - PPCd - Temperature - 80°, Time - 3 minutes PL09 - LCdE - Left coin denomination - 25¢ PL10 - rCdE - Right coin denomination - 10¢ PL11 - tFAS - Time for amount to start - 10 minutes PL12 - AtSt - Amount To Start - 25¢ PL13 - AFAt - Amount for additional time - 25¢ PL14 - Adrt - Automatic dry maximum time - 30 minutes PL15 - GdLY - Anti-wrinkle guard off delay time - 2 minutes

PL16 - AGt - Active anti-wrinkle guard time - 10 minutes PL17 - A and b - “A” is adjustable from 1 to 99 (example: A = 5)

F - 150°

Gont - Anti-wrinkle guard on time - 20-seconds

Factors - “b” is adjustable from 1 to 99 (example: B = 70)

SECTION VIII

PHASE 5 COIN SYSTEM DIAGNOSTICS

ALL major circuits, including door, microprocessor temperature sensor , heat and motor circuits are monitored. The Phase 5 coin microprocessor controller (computer) will inform the user via the light emitting diode (L.E.D.) display of certain failure codes along with indicators both in the L.E.D. display and at the outputs of each relay (and door switch circuit) to easily identify failures.

A. DIAGNOSTIC (L.E.D.) FAILURE CODES

1. “door” - Indicates door switch circuit is open.

a. Keyboard (touch pad) entry was made while main door is open

b. there is a fault in the door switch circuit (external of the microprocessor controller [computer]).

2. “dSFL” - Indicates a fault in the microprocessor temperature sensor circuit. If a fault is detected in the

microprocessor heat sensor circuit, the L.E.D. display will read “dSFL” and the buzzer (tone) will sound for approximately 5-seconds every 30-seconds.

a. the problem is corrected

b. power to dryer is discontinued...and the problem is then corrected.

IMPORTANT: The Phase 5 coin microprocessor controller (computer) has its own internal heat

sensing circuit fuse protection located on the back side of the (computer). If a “dSFL” condition occurs, check to see if this fuse has blown. If it has, DO NOT replace the entire microprocessor controller (computer); replace only the fuse and do so only with a 1/8-Amp (Slo-Blo) type fuse.

NOTE: Once the Phase 5 coin microprocessor controller (computer) detects a problem in the heat

circuit, it updates every 30-seconds so if a problem was a loose connection in this circuit, which corrected itself, the “dSFL” condition would automatically be cancelled.

3. “SEFL” - Indicates rotational sensor circuit failure meaning that there is a fault somewhere in the

basket (tumbler) rotation detection circuit or the microprocessor controller (computer) program related to this circuit (PL01) is set incorrectly in the active mode (“SEn”), where the dryer equipped with optional rotation sensor and should be set in the inactive mode (“nSEn”).

4. “Hot” - Indicates a possible overheating condition. The Phase 5 microprocessor controller (computer)

monitors the temperature in the dryer at ALL times. If the microprocessor controller (computer) detects that the temperature in the dryer has exceeded 220° F (104° C) it will disable ALL outputs (shut the dryer down), the tone (buzzer) will sound for approximately 5-seconds, and the display will read “Hot.” The light emitting diode (L.E.D.) display will continue to read “Hot” until the temperature sensed has dropped to 220° F (104° C) or lower and the microprocessor controller (computer) is manually reset by closing and opening the Program Switch (PS).

is not

B. L.E.D. DISPLAY INDICATORS/DOTS

The L.E.D. indicator dots located at the top portion of the display indicates the various microprocessor controller (computer) output functions while a cycle is in progress. These dots DO NOT necessarily mean that the outputs are functioning. They are only indicating that the function (output) should be active (on).

1. Heat Circuit Indicator - indicator dot is on whenever the microprocessor controller (computer) is calling

for the heating circuit to be active (on).

2. Motor Circuit Indicator - indicator dot is on whenever a cycle is in progress.

C. PHASE 5 MICROPROCESSOR CONTROLLER (COMPUTER) RELAY OUTPUT LIGHT EMITTING DIODE (L.E.D.) INDICATORS

There are three (3) L.E.D. indicators (“red” lights) located at the lower back side area of the microprocessor controller (computer) which are identified/labeled as “DOOR,” “HEAT,” and “MTR” (motor). These L.E.D.s indicate that the outputs of the microprocessor controller (computer), or in the case of the door switch, the inputs are functioning.

1. “DOOR” - L.E.D. SHOULD BE ON ALL THE TIME (even if the dryer is not running) unless the

main door is open or there is a problem (open circuit) in the main door switch circuit.

NOTE: If the dryer is started (the display L.E.D. indicator dots are on) and there are no outputs

(“HEA T” and/or “MTR” output L.E.D. are off) and the “DOOR” input L.E.D. is on, the fault is in the Phase 5 microprocessor controller (computer) itself.

NOTE: If the failure was elsewhere (i.e. dryer’ s door switch circuit) the light emitting diode (L.E.D.)

display would read “door” if a keyboard (touch pad) entry was attempted. If the display L.E.D. indicators are on, and the door L.E.D. indicators are on, and the door L.E.D. input and motor/heat output L.E.D.s are on, yet the motor and/or heat

is not active (on); then the

problem is not the door switch on the Phase 5 microprocessor controller (computer), the problem is elsewhere in the dryer.

2. “HEAT” - Output L.E.D. Indicator - if the dryer is started and there is no heat, yet the microprocessor

controller (computer) L.E.D. display heat indicator dot is on, but the heat output L.E.D. indicator is off, then the fault is in the Phase 5 microprocessor controller (computer) itself. If both the display heat output L.E.D. indicator are on, then the problem is elsewhere (external of the microprocessor controller (computer).

3. “MTR” (motor) - Output L.E.D. Indicator - if the dryer is started and the motor

the microprocessor controller (computer) L.E.D. display motor indicator dot and “DOOR” input L.E.D. indicator are on, but the “MTR” output L.E.D. indicator is off; then the fault is in the Phase 5 microprocessor controller (computer) itself. If the motor is not operating and the “MTR” output indicator is on, then the problem is elsewhere (external of the microprocessor controller [computer]).

is not operating, yet both

SECTION IX

PHASE 5 AUTO CYCLE (PATENT NO. 4,827,627)

“A” and “b” Factor Parameters

GAS ELECTRIC STEAM

Model "A" "b" Model Kw "A" "b" Model Type "A" "b"

ADG-15D 3 80 ADG-25D 5 80 15 2 55 ADS-25

ADG-26D N/A* 18 3 63 ADS-320 ADG-215D 5 67 ADG-220D 5 65 20 3 80 ADS-30S ADG-230D 5 65 24 5 80 ADS-50 ADG-320D 5 75 ADE- 215 15 5 67 UDS-50 ADG-330D 5 75 ADE- 220 15

ADG-285DH 5 65 ADE-230 15

ADG-295D N /A* ADE-320 15

ADG-30DS (A) 5 70 ADE-330 15 ADG- 3 0 DS (b ) N /A*

ADG-30D 5 70 36 (A) 5 70

ADG-50D 5 72 40 (b)

ADG-75D 5 65 48 (A)

ADE-15

ADE-25

ADE-30S

ADE-30

ADE-50

UDE-50

ADE-75

12 2 74 ADS-15

18 2 65 ADS-330

ADS-75

N/A*

30 (b)

N/A*UDG-50D 5 65 42 (A)

20 3 80 24 3 80 30 5 75 20 2 81 24 3 65 30 5 75 20 2 65 24 4 81 30 5 72 20 2 81 24 2 81 30 3 76 36 3 75

Contact factory for models and/or “A” and “b” Factors not listed.

Hig h

Low

N/A*

* “A” and “b” Factors N/A at time of printing.

NOTE: For letter designations refer to the following page (page 61).

(A) For

60 Hz models ONLY

(B) For

50 Hz models ONLY

IMPORTANT: The “A” and “b” Factors have been preprogrammed by the factory and should be

changed in the field unless the Phase 5 coin microprocessor controller (computer) should fail and is replaced. THE REPLACEMENT PHASE 5 COIN

MICROPROCESSOR CONTROLLER (COMPUTER) MUST BE REPROGRAMMED FOR THE SPECIFIC MODEL SHOWN IN THE CHART ON THE PREVIOUS P AGE (page 60).

SECTION X

OPTIONAL 9 VOLT BATTERY

BACKUP

Dryers ordered from the factory with the 9 volt battery backup option (battery is not included) allow the Phase 5 microprocessor controller (computer) to maintain its operating status should a momentary power interruption occur while the dryer cycle is in progress.

It is suggested that the battery be replaced at least once a year or as found necessary. The battery life will depend on the age of the battery, the amount of power interruptions, and the backup time used.

IMPORTANT: For proper operation use alkaline batteries ONLY. Suggest Energizer , Duracell

or equivalent. DO NOT USE CARBON TYPE BATTERIES.

Notes _____________________________________________________________________________________________________________________

___________________________________________________________________________________________________________________________

ADC Part No. 112146 56 - 10/28/08 - 1

ADC AD-295, ADG-15D, AD-540, WDA-540, ADG-25D User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
