TrueNet Workstation Solutions
Workstation Faceplates and Surface Mount Boxes
Spec Sheet
As a part of the work area solution products from ADC’s TrueNet structured cabling system, ADC
offers a variety of traditional faceplates, modular furniture faceplates and surface mount boxes
to provide the basis for a wide range of possible information outlet combinations. With a singlegang faceplate capacity up to six-ports, a dual-gang faceplate capacity of 12-ports, and up to a
12-port surface mount box, ADC can provide the density for the most demanding installation.
The TrueNet Workstation faceplates and surface mount boxes accept any combination of ADC’s
keystone modular jacks and connectors. The variety of reversible-icon and color ID tabs for
labeling provides a versatile and highly visible information outlet system.
Applications
Workstation mounting platform for voice, video and data keystone modular connectors.
Features
• Made of durable ABS Plastic
• All faceplates fit standard NEMA single- or dual-gang faceplates as indicated
w w w . a d c . c o m • + 1 - 9 5 2 - 9 3 8 - 8 0 8 0 • 1 - 8 0 0 - 3 6 6 - 3 8 9 1
TrueNet Workstation Solutions
Workstation Faceplates and Surface Mount Boxes
SPECIFICATIONS
Operating Temperature Range: -10º TO 70 ºC (14º TO 158 ºF)
Material Construction:
Flammability Rating:
Safety Rating:
Single-Gang Faceplates
All single-gang faceplates fit standard, single-gang box; include 2 blank paper labels, 2 clear plastic label
protectors, 1 logo insert, reversible-icon ID tabs numbered 1-6 (icon colors match faceplate), mounting
screws (#6-32x15/16")
O r d e r i n g I n f o r m a t i o n
Description Dimensions Catalog Number
2-port flush mount single-gang faceplate
2 outlet labeling areas and 2 individual port ID areas
4-port flush mount single-gang faceplate
2 outlet labeling areas and 4 individual port ID areas
6-port flush mount single-gang faceplate
2 outlet labeling areas and 6 individual port ID areas
4-port angled single-gang faceplate
2 outlet labeling areas and 4 individual port ID areas
1
Replace XX in catalog number to indicate color:
01 = White 02 = Ivory 03 = Gray 04 = Black 22 = Electrical Ivory
ABS PLASTIC
UL 94-V0
UL 1863
4.5" x 2.75" x 0.25"
(114.5 x 70.0 x 6.35 mm)
4.5" x 2.75" x 0.25"
(114.5 x 70.0 x 6.35 mm)
4.5" x 2.75" x 0.25"
(114.5 x 70.0 x 6.35 mm)
4.5" x 2.75" x 0.25"
(114.5 x 70.0 x 6.35 mm)
1
6644 1 152-XX
6644 1 154-XX
6644 1 156-XX
6644 1 174-XX
Dual-Gang Faceplates
Dual-gang faceplates require standard NEMA dual-gang opening of at least 3.563" x 2.75"; include
TrueNet Workstation Solutions
3 / 0 7 • 1 0 4 2 2 2 A E
4 blank paper labels, 4 clear plastic label protectors, logo inserts, reversible-icon ID tabs numbered 1-6
(icon colors match faceplate), 4 mounting screws (#6-32x15/16")
O r d e r i n g I n f o r m a t i o n
Description Dimensions Catalog Number
4-port flush mount dual-gang faceplate
4 outlet labeling areas and 4 individual port ID areas
8-port flush mount dual-gang faceplate
4 outlet labeling areas and 8 individual port ID areas
12-port flush mount dual-gang faceplate
4 outlet labeling areas and 12 individual port ID areas
numbered consecutively left to right, top to bottom.
8-port angled dual-gang faceplate
4 outlet labeling areas and 8 individual port ID areas;
Not compatible with dual-gang mud rings.
2
Replace XX in catalog number to indicate color:
01 = White 02 = Ivory 03 = Gray 04 = Black 22 = Electrical Ivory
4.5" x 4.94" x 0.25"
(114.5 x 125.48 x 6.35 mm)
4.5" x 4.94" x 0.25"
(114.5 x 125.48 x 6.35 mm)
4.5" x 4.94" x 0.25"
(114.5 x 125.48 x 6.35 mm)
4.5" x 4.94" x 0.25"
(114.5 x 125.48 x 6.35 mm)
6644 1 164-XX
6644 1 168-XX
6644 1 157-XX
6644 1 178-XX
2
w w w . a d c . c o m • + 1 - 9 5 2 - 9 3 8 - 8 0 8 0 • 1 - 8 0 0 - 3 6 6 - 3 8 9 1
2
TrueNet Workstation Solutions
TrueNet Workstation Solutions
Workstation Faceplates and Surface Mount Boxes
Modular Furniture Faceplates
TrueNet modular furniture faceplates are compatible with leading office furniture and accept TrueNet
modular jacks and connectors. Contact ADC Technical Assistance Center for specific model compatibility.
O r d e r i n g I n f o r m a t i o n
Modular
Furniture
Compatibility
Fits standard
NEMA openings in
modular furniture
raceways or
standard singlegang boxes
Steelcase 9000,
Steelcase Avenir,
Steelcase Context,
AllSteel 8000, Knoll
Morrison, Knoll Reff,
Haworth Places and
Unigroup, Haworth
Places, Haworth
Premise, Haworth
Race
Herman Miller
- Action Office 1,
Herman Miller
- Action Office 2,
Herman Miller
- Action Office 3,
Herman Miller
- Ethospace
(baseline), Herman
Miller, Phoenix,
Kimball
Herman Miller Ethospace
Description Dimensions
2-port horizontal faceplate
Designed for horizontal orientation;
features 1 outlet labeling area, 2
individual port ID areas, ID tabs hide
faceplate mounting screws.
Includes 2 blank paper labels, 1 clear
plastic label protectors, reversible-icon
ID tabs numbered 1-6 (icon colors
match faceplate), mounting screws
(#6-32x15/16" with custom head)
3-port modular furniture faceplate
Recommended opening: 2.65"
x 1.377" (67.31 x 34.98 mm).
Maximum thickness: 0.06" (1.52 mm).
Contains 3 individual port ID areas;
includes 6 reversible-icon ID tabs
numbered 1-6 (icon colors match
faceplate)
4-port modular furniture faceplate
Fits openings: 1.890" x 1.920" (48 x
48.77 mm) high. 2.572" to 3.866"
(65.33 to 98.2 mm) wide.
Maximum thickness: 0.08" (2.03 mm).
Features 1 outlet labeling area, 4
individual port ID areas; includes 2
blank paper labels, 1 clear plastic
label protector, 1 logo insert, 6
reversible-icon ID tabs numbered 1-6
(icon colors match faceplate)
4-Port Beltline Adapter for
Herman Miller Ethospace furniture
2.75" x 4.5" x 0.25"
(69.85 x 114.3 x 6.35 mm)
1.61" x 3.13" x 0.38"
(40.9 x 79.5 x 9.65 mm)
2.17" x 3.9" x 0.38"
(55.12 x 99 x 9.65 mm)
2.45” x 4.20“ x 0.36” 6644 3 299-XX
Catalog
Number
6644 1 112-XX
6644 1 143-XX
6644 1 144-XX
1
1
Replace XX in catalog number to indicate color:
01 = White 02 = Ivory 03 = Gray 04 = Black
3 / 0 7 • 1 0 4 2 2 2 A E
w w w . a d c . c o m • + 1 - 9 5 2 - 9 3 8 - 8 0 8 0 • 1 - 8 0 0 - 3 6 6 - 3 8 9 1
3
Surface Mount Boxes
O r d e r i n g I n f o r m a t i o n
Description Dimensions Catalog Number
2-port surface mount box
Features 1 outlet labeling area and 2 individual port
ID areas. Includes 1 blank paper label, 1 clear plastic
label protectors,1 logo insert, reversible-icon ID tabs
numbered 1-6 (icon colors match faceplate), and
hook-and-loop fastener strips. Knockouts allow cable
and raceway access
4-port surface mount box
Features 1 outlet labeling area and 4 individual port
ID areas. Includes 1 blank paper label, 1 clear plastic
label protectors,reversible-icon ID tabs numbered 16 (icon colors match faceplate), 1 screw for locking
down cover and hook-and-loop fastener strips.
Knockouts allow cable and raceway access
6-port surface mount box
Features 2 outlet labeling area and 6 individual port
ID areas. Includes 1 blank paper label, 1 clear plastic
label protectors,reversible-icon ID tabs numbered 16 (icon colors match faceplate), 2 mounting screws
(#6-32x15/16") and hook-and-loop fastener strips.
Knockouts allow cable access from 3 sides
12-port surface mount box
Features discreate port labeling and 6-port cable
guides for cable management.
1
Replace XX in catalog number to indicate color:
01 = White 02 = Ivory 03 = Gray 04 = Black 22 = Electrical Ivory
1" x 2.25" x 2.31"
(25.4 x 57.2 x 58.67 mm)
2.88" x 4.25" x 1"
(73.15 x 107.95 x 25.4 mm)
3.38" x 6" x 1.5"
(85.85 x 152.4 x 38.1 mm)
1.61" x 3.13" x 0.38"
(40.9 x 79.5 x 9.65 mm)
6644 1 222-XX
6644 1 224-XX
6644 2 201-XX
6644 1 460-XX
1
Spec Sheet
Accessories
O r d e r i n g I n f o r m a t i o n
Description Catalog Number
ID tabs with icons numbered 1-6
Set of 6 reversible ID tabs numbered 1-6. Snap into individual port identification area
above jack or connector opening. Data icon on one side, voice icon on other; same
number appears on both sides
Paper labels for faceplates
Adhesive lables come pre-cut on white 8.5" x 11' sheet, 190 lables per sheet.
Accommodates hand or laser printing. Fit in lable area on front of modular faceplates.
2
Replace XX in catalog number to indicate color for ICON's:
01 = White 02 = Ivory 03 = Gray 04 = Black 05 = Red
06 = Blue 07 = Green 08 = Yellow 09 = Purple 10 = Orange
Web Site: www.adc.com
From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080
Fax: +1-952-917-3237 • For a listing of ADC’s global sales office locations, please refer to our web site.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products orfeatures
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
104222AE 3/07 Original © 2007 ADC Telecommunications, Inc. All Rights Reserved
6631 2 125-XX
6631 3 100-06
