InterReach Spectrum

™

Main and Secondary Remote Access Unit

Installation Guide

D-620731-0-20 Rev A

Main Remote Access Unit

Secondary Remote Access Unit

ADCP-77-168  Issue 2  07/2011

ADC Telecommunications, Inc. P.O. Box 1101, Minneapolis, Minnesota 55440-1101 In U.S.A. and Canada: 1-800-366-3891 Outside U.S.A. and Canada: (952) 938-8080 Fax: (952) 917-1717

shall not be modified, used, copied, reproduced or disclosed in whole or in part without the written consent of ADC.

Trademark Information

ADC is a registered trademark and InterReach Spectrum is a trademark of ADC Telecommunications, Inc. No right, license, or interest to such trademarks is granted hereunder, and you agree that no such right, license, or interest shall be asserted by you with respect to such trademark.

Other product names mentioned in this practice are for identification purposes only and may be trademarks or registered trademarks of their respective companies.

Disclaimer of Liability

Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. Should the content of printed user documentation shipped with product differ from documentation provided on a product CD (inclusive of the associated Help modules), the printed user documentation supersedes the documentation on the product CD. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits, and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages. This disclaimer of liability applies to all products, publications and services during and after the warranty period.

Specific Disclaimer for High-Risk Activities

This Product is not specifically designed, manufactured, tested or intended for use in high-risk activities including, without restricting the generality of the foregoing, on-line control of aircraft, air traffic, aircraft navigation or aircraft communications; or in the design, construction, operation or maintenance of any nuclear facility. ADC (including its affiliates) and its suppliers specifically disclaim any express or implied warranty of fitness for such purposes or any other purposes.

TABLE OF CONTENTS

Preface.................................................................................................................... 1

InterReach Spectrum User Documentation .................................... .......................... 2

Document Cautions and Notes............................................................................... 2

General Safety Precautions ......................................................... .......................... 2

Standards Certification ........................... .............................................................. 3

Product Overview ..................................................................................................... 4

Main Remote Access Units.....................................................................................5

MRAU Ports, Cable, and Connectors................................................................... 5

MRAU LEDs.................................................................................................... 6

Secondary Remote Access Units.............................................................................7

SRAU Ports, Cable, and Connectors...................................................................7

SRAU LEDs .................................................................................................... 8

Install the RAUs and Antennas....................................................................................8

Mount the RAUs and Antennas ............................................................................... 8

Connect the IFEU to the MRAU ............................................ ................................ 10

Connect the MRAU to SRAUs ............................................................................... 12

Configure the MRAUs and SRAUs ........................... .............................................. 13

Appendix A: Specifications....................................................................................... 14

Spectrum System Specifications .......................................................................... 14

Remote Access Unit Specifications........................................................................ 15

Composite Power Out of RAU............................................................................... 15

Appendix B: 75-Ohm CATV Cable.............................................................................. 16

CATV Cable Requirements.................................. ................................................. 16

Belden 1695A Coax Specifications........................................................................ 17

Description .................................................................................................. 17

Overall Physical Characteristics....................................................................... 17

Overall Nominal Electrical Characteristics......................................................... 18

Belden 7732A Coax Specifications........................................................................ 19

Description .................................................................................................. 19

Overall Physical Characteristics....................................................................... 19

Overall Nominal Electrical Characteristics......................................................... 19

Appendix C: Omni Antenna ........................................................ .............................. 21

Appendix D: Contacting ADC/TE Connectivity ............................................................. 22

PREFACE

This manual provides installation instructions for ADC® InterReach Spectrum Remote Access Units.

™

Preface

InterReach Spectrum User Documentation

The InterReach Spectrum user documentation is intended for system administrators, engineers and installers responsible for planning, administering, configuring, and maintaining ADC InterReach Spectrum systems.

Table 1 lists the

manuals that correspond to this InterReach Spectrum release.

Table 1. InterReach Spectrum User Documentation

Title ADCP Number

InterReach Spectrum Quick Start Guide ADCP-77-165

InterReach Spectrum Host Unit Installation Guide ADCP-77-166

InterReach Spectrum Expansion Module Group Installation Guide ADCP-77-167

InterReach Spectrum Remote Access Unit Installation Guide ADCP-77-168

InterReach Spectrum™ Element Management System 7.2 User Manual ADCP-77-189

FlexWave Prism OADM Splice Box Installation Guide ADCP-77-151

Document Cautions and Notes

Two types of messages, identified below, appear in the text:

CAUTION! Caution text indicates operations or steps that could cause personal injury, induce a

safety problem in a managed device, destroy or corrupt information, or interrupt or stop

services.

NOTE: Note text contains information about special circumstances.

General Safety Precautions

CAUTION! Wet conditions increase the potential for receiving an electrical shock when installing or

using electrically powered equipment. To prevent electrical shock, never install or use

electrical equipment in a wet location or during a lightning storm.

CAUTION! This equipment uses a Class 1 Laser according to FDA/CDRH rules. Laser radiation can

seriously damage the retina of the eye. Do not look into the ends of any optical fiber. Do

not look directly into the optical transceiver of any digital unit or exposure to laser

radiation may result. Use an optical power meter to verify active fibers. Immediately

place a protective cap or hood over any radiating transceiver or optical fiber connector to

avoid the potential of dangerous amounts of radiation exposure. This practice also

prevents dirt particles from entering the adapter or connector.

CAUTION! This system is a RF Transmitter and continuously emits RF energy. Maintain a minimum

clearance of three feet (91.4 cm) from the antenna while the system is operating.

Wherever possible, shut down the RAN before servicing the antenna.

Page 2 InterReach Spectrum Remote Access Unit Installation Guide

2011 ADC Telecommunications, Inc ADCP-77-168 • Issue 2 • 07/2011

Standards Certification

FCC: This equipment complies with the applicable sections of Title 47 CFR, Part 22 (800 MHz Cellular), Part 24 (1900 MHz - PCS), Part 90 (800/900 - SMR), and Part 27 (700 MHz, 2100 MHz - AWS).

IC: This equipment complies with the applicable sections of RSS-131 (800/900 – SMR), RSS-132 (800 - Cellular), and RSS-133 (1900 – PCS). The term “IC:” before the radio certification number only signifies that Industry Canada Technical Specifications were met.

The Manufacturer's rated output power of this equipment is for single carrier operation. For situations when multiple carrier signals are present, the rating would have to be reduced by 3.5 dB, especially where the output signal is re-radiated and can cause interference to adjacent band users. This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device.

NOTE: The U.S. Federal Communications Commission (FCC) has developed guidelines for

evaluation of human exposure to RF emissions. The guidelines incorporate limits for Maximum Permissible Exposure (MPE) for power density of transmitter operating at frequencies between 300 kHz and 100 GHz. Limits have been set for portable, mobile, and fixed equipment. ADC products fall in the category of fixed equipment; products intended to be permanently secured and exposures are evaluated for distances greater than 20cm (7-7/8”). Portable devices fall into exposures of less than 20cm, where SAR evaluations are used.

Preface

Antenna gain is restricted to 1.5 W ERP (2.49 W EIRP) in order to satisfy RF exposure compliance requirements. If higher than 1.5 W ERP, routine MPE evaluation is needed. The antennas should be installed to provide at least 20cm from all persons to satisfy MPE requirements of FCC Part 2, 2.1091.

UL/CUL: This will be installed in a restricted access location. This equipment complies, per UL and CUL 50, Standard for Enclosures for Electrical Equipment.

UL/CUL: This equipment complies with UL and CUL 60950-1 Standard for Safety for Information Technology Equipment, including Electrical Business Equipment.

UL: This equipment is UL Plenum rated under UL 2043.

CAUTION! Modifications not expressly approved by the party responsible for compliance could void

the user's authority to operate the equipment.

Product Overview

Omni Antenna

Host

Power Supply

IF Expansion Unit

DART Remote Unit

Expansion Module Group

Secondary Remote Access Unit

Main Remote Access Unit

Reverse (REV)

Forward (FWD)

Key to Signal Path

PRODUCT OVERVIEW

InterReach Spectrum supports up to eight frequency bands in a single system. Each antenna location supports those bands in modular, group pairings. Each location includes a Main Remote Access Unit (MRAU), which can power up to three additional Secondary Remote Access Units (SRAUs). An MRAU supports two frequency bands, and each SRAU can support up to two frequency bands, for a total of up to eight frequency bands. MRAUs and SRAUs are grouped logically, based on common service provider groupings and include, as an example:

• 850/1900

• 700/700 MIMO

• 800/900 SMR

• 1900/AWS.

To add more frequency bands, you connect an SRAU to the existing MRAU.

Figure 1 illustrates how RF and IF signals are sent between Spectrum units and

modules.

Page 4 InterReach Spectrum Remote Access Unit Installation Guide

2011 ADC Telecommunications, Inc ADCP-77-168 • Issue 2 • 07/2011

Figure 1. REV and FWD Signals for the RAU

NOTE: This book refers to the Omni Antenna (4214-M727), which is the antenna that ADC

recommends. Other antennas may be used. For further information on the Omni Antenna,

see

“Appendix C: Omni Antenna” on page 21.

Product Overview

Main Remote Access Units

The Main Remote Access Unit (MRAU) receives FWD IF signals from an IF Expansion Unit (IFEU), which is part of the Spectrum Expansion Module Group, using 75 a passive RF antenna using 50 configuration information and power from and sends its status information to the IFEU.

The MRAU receives REV RF signals from a passive RF antenna using 50 coaxial cable. It converts the signals to IF and sends them to the IFEU using 75 cable.

MRAU Ports, Cable, and Connectors

 CATV cable. The MRAU converts the IF signals to RF and sends them to

 coaxial cable. The MRAU also receives

 CATV

1 2

REV IF OUT REV SECONDARY PORTS

Ref # Component Device Function

RF SubMiniature version A

(SMA) cable

2 Antenna port 50 N-type connector Connects to an antenna.

3 FWD IF IN connector F connector port

4 FWD SECONDARY PORTS (1 - 3) F connector ports

5 REV SECONDARY PORTS (1 - 3) F connector ports

8 REV IF OUT connector F connector port

(1) The AWS/PCS MRAUs does NOT have an RF SMA cable, and has two Antenna ports.

(1)

1 2 3

50 RF SMA-to-SMA cable

LINK STATUS

FWD SECONDARY PORTS 1 2 3

Connects two RF bands together when there is only one N-type connector on the RAU. For cases when there is an N-type connector for each RF band (700MIMO or PCS/AWS), there will not be an SMA cable.

Connects to the IFEU FWD Module IF OUT connector via CATV cable.

Connect to a SRAU SECONDARY FWD connector via CATV cable.

Connect to a SRAU SECONDARY REV connector via CATV cable.

Connects to the IFEU REV Module IF IN connector via CATV cable.

FWD IF IN

Product Overview

MRAU LEDs

REV IF OUT REV SECONDARY PORTS

1 2 3

LINK STATUS

2 3

Ref # LED LED Color Description

• Green • Downstream unit correctly connected; unit has no alarms or a Minor alarm is active.

• Blinking Green • SRAU or band is set out-of-service.

FWD SECONDARY PORT 

(1 - 3)

2 LINK

3 STATUS

REV SECONDARY PORT

(1 - 3)

5 FWD IF IN

• Yellow • FWD cable connected to SRAU, no REV cable connected.

• Blinking Yellow • FWD and REV cables are not connected to the same port number (incorrectly paired).

• Red • Major alarm in downstream unit, fault lockout, or SRAU disconnected.

• Off • No SRAU previously connected.

• Green • MRAU receiving communications from the IFEU.

• Red • MRAU has not received communications from the IFEU for more than 90 seconds.

• Off • During initial power up, MRAU is powering up and waiting for IFEU communications.

• Green • Unit has no alarms or a Minor alarm is active.

• Blinking Green • Unit or band is set out-of-service.

• Red • Major alarm detected.

• Green • Downstream unit correctly connected, unit has no alarms or minor alarm

• Blinking Green • SRAU or band is set out-of-service.

• Blinking Yellow • FWD and REV cables are not connected to the same port number (incorrectly paired).

• Red • Major alarm in downstream unit, fault lockout, or SRAU disconnected.

• Off • No SRAU previously connected.

• Green • MRAU is powered on correctly.

•Yellow or

Blinking Yellow

• There is an IFEU FWD connection, but there is no IFEU REV connection or the IFEU REV connection is paired incorrectly.

• Off • Cable is not connected to the IFEU FWD port.

FWD SECONDARY PORTS 1 2 3

FWD IF IN

Page 6 InterReach Spectrum Remote Access Unit Installation Guide

2011 ADC Telecommunications, Inc ADCP-77-168 • Issue 2 • 07/2011

Product Overview

LINK STATUS

SECONDARY

REV

SECONDARY

FWD

Secondary Remote Access Units

A Secondary Remote Access Unit (SRAU) receives FWD IF signals from the MRAU, using 75 a passive RF antenna using 50 receives configuration information and power from and sends its status information to the IFEU.

The SRAU receives REV RF signals from a passive RF antenna using 50 coaxial cable. It converts the signals to IF and sends them to the MRAU using 75 cable.

SRAU Ports, Cable, and Connectors

 CATV cable. The SRAU converts the IF signals to RF and sends them to

 coaxial cable. The SRAU, through the MRAU, also

 CATV

Ref #Component Device Function

1 SECONDARY REV connector F connector port

2 RF SMA cable

3 Antenna port 50 N-type connector Connects to an antenna.

4 SECONDARY FWD connector F connector port

(1) The 700 MIMO SRAUs does NOT have an RF SMA cable, and has two Antenna ports.

(1)

50 RF SMA-to-SMA cable

Connects to one of the MRAU REV SECONDARY ports (1 - 3) via CATV cable.

Connects two RF bands together when there is only one N-type connector on the RAU. For cases when there is an N-type connector for each RF band (700MIMO or PCS/AWS), there will not be an SMA cable.

Connects to one of the MRAU FWD SECONDARY ports (1 - 3) via CATV cable.

Install the RAUs and Antennas

LINK STATUS

SECONDARY

REV

SECONDARY

FWD

21 3

SRAU LEDs

Ref # LED LED Color Description

•Green •SRAU receiving communications from the IFEU.

• Red • SRAU has not received communications from the IFEU for more than 90

1 LINK

2 STATUS

3 SECONDARY FWD

• Off • During initial power up, SRAU is powering up and waiting for IFEU

• Green • Unit has no alarms or a Minor alarm is active.

• Blinking Green • Unit or band is set out-of-service.

• Red • Major alarm detected.

• Green • MRAU is powered on correctly.

•Yellow or Blinking Yellow

• Off • Cable is not connected to the MRAU FWD port.

seconds.

communications.

• There is an MRAU FWD connection, but there is no MRAU REV connection or the MRAU REV connection is paired incorrectly.

INSTALL THE RAUS AND ANTENNAS

Follow the steps in the order provided to install the RAUs and antennas.

Mount the RAUs and Antennas

CAUTION! Install RAUs in indoor locations only. Do not connect an antenna installed in an outdoor

location to a RAU, unless it is in an approved AOC weatherproof NEMA4 housing.

CAUTION! Attach all RAUs securely to a stationary object (that is, a wall, pole, or ceiling brackets).

To mount a RAU securely to a wall, ceiling bracket, or pole, use #6 diameter fasteners in the four slotted mounting holes.

CAUTION! Do the following to maintain proper ventilation:

• Keep at least 76 mm (3-inch) clearance around the RAU.

• Do not stack RAUs on top of each other.

Page 8 InterReach Spectrum Remote Access Unit Installation Guide

2011 ADC Telecommunications, Inc ADCP-77-168 • Issue 2 • 07/2011

• Always mount the RAU with the solid face (containing the mounting holes) against the mounting surface.

Install the RAUs and Antennas

Omni Antenna

False Ceiling

SRAU

REV IF OUT REV SECONDARY PORTS

1 2 3

FWD SECONDARY PORTS 1 2 3

FWD IF IN

LINK

STATUS

LINK STATUS

SECONDARY

REV

SECONDARY

FWD

MRAU

Coaxial cable

NOTE: RAUs are suitable for use in environmental air space in accordance with Section

300-22(c) of the National Electrical Code, and Sections 2-128, 12-010(3) and 12-100 of the Canadian Electrical Code, Part 1, CSA C22.1.

NOTE: You can place the RAU, without its fastening hardware, on a flat surface, such as a shelf,

desk, cabinet, or any other horizontal surface that allows stable placement, with the mounting base facing down to the mounting surface.

CAUTION! If installing the RAU on a flat surface, the surface must be able to hold a minimum

7-pound load securely.

1 Mount all MRAU and SRAUs in the locations marked on the floor plans. 2 Install the passive antennas according to the manufacturer’s installation

instructions.

NOTE: It is common practice to install passive antennas below the ceiling. If you install a

passive antenna above the ceiling, when estimating the antenna coverage area, account for additional loss due to the ceiling material.

3 Connect a passive multi-band antenna to the N connector on each RAU using

coaxial cable with the least amount of loss possible. (See

“Appendix C: Omni

Antenna” on page 21 for information on the Omni Antenna ports.)

CAUTION! Firmly hand-tighten the N connector. DO NOT over-tighten the connector.

Install the RAUs and Antennas

Connect the IFEU to the MRAU

NOTE: The IFEU should be powered up before starting this procedure; see the InterReach

Spectrum Expansion Module Group Installation Guide (ADCP-77-167).

4 Follow these rules for the CATV cables when connecting the IFEU to the MRAU:

• The FWD and REV cables should be close to the same length.

• The FWD and REV cables should be the same cable type (both RG6 or both

RG11).

• A pair of CATV cables connects each MRAU to the IFEU. The IFEU REV Module IF IN port and the IFEU FWD Module IF OUT port must match. For example, if IFEU REV Module IF IN Port 3 is used, use IFEU FWD Module IF OUT Port 3.

• Refer to “Appendix B: 75-Ohm CATV Cable” on page 16 for information on maximum RG-6 or RG-11 CATV cable lengths.

5 Test the cable termination for each CATV cable before installing it. 6 Connect F connector CATV cables on the IFEU and MRAU, in the order given

below. If the LEDs do not perform as described in this procedure, refer to “MRAU LEDs”

on page 6.

a Connect a CATV cable from one of the IFEU FWD Module IF OUT connectors

(1 - 8) to the MRAU FWD IF IN connector.

b Confirm that the MRAU FWD IF IN LED is yellow, which indicates a corre ct

physical connection.

c Connect a CATV cable from the IFEU REV Module IF IN connector (1 - 8) to

the MRAU REV IF OUT connector, making sure that you pair the port used to the same port number selected in Step 6a.

If the connection is correct, the MRAU powers up and the MRAU FWD IF IN LED turns green.

Page 10 InterReach Spectrum Remote Access Unit Installation Guide

2011 ADC Telecommunications, Inc ADCP-77-168 • Issue 2 • 07/2011

Install the RAUs and Antennas

IFEU

Step 6a

REV IF OUT

REV SECONDARY PORTS 1 2 3

FWD SECONDARY PORTS 1 2 3

FWD IF IN

LINK STATUS

To an antenna

MRAU

Step 6b

Step 6c

Install the RAUs and Antennas

REV IF OUT REV SECONDARY PORTS

1 2 3

FWD SECONDARY PORTS 1 2 3

FWD IF IN

LINK STATUS

SECONDARY

REV

SECONDARY

FWD

To an IFEU REV Module IF IN connector (1 - 8)

To an IFEU FWD Module IF OUT connector (1 - 8)

MRAU

SRAU

To an antenna

Connect the MRAU to SRAUs

CAUTION! To prevent interference, do not install an 850/1900 MRAU antenna near an 800/900 SRAU.

The 850 MHz band must be 20 feet away from the 800/1900 SRAU’s passive antenna.

7 Use one of the following 6’ and 20’ CATV RG6 jumpers, available for purchase

from ADC, to connect an MRAU to SRAUs.

ADC Part Number Description Note

300469-0 6’ RG-6 Cable; F Male to F Male

300469-1 20’ RG-6 Cable; F Male to F Male

CATV cable that connects the MRAU to SRAUs. Two cables required per SRAU.

8 Test the cable termination for each CATV cable before installing it. 9 Connect F connector CATV cables from the MRAU to an SRAU, in the order

given below. If the LEDs do not perform as described in this procedure, refer to

“SRAU LEDs” on page 8.

a Connect a CATV cable from an MRAU FWD SECONDARY PORT (1, 2, or 3) F

connector to the SRAU SECONDARY FWD F co nnector.

b Confirm that the SRAU SECONDARY FWD LED is yellow, which indicates a

correct physical connection.

c Connect a CATV cable from an MRAU REV SECONDARY PORT (1, 2, or 3) F

connector to the SRAU SECONDARY REV F connector, matching the same port number selected in Step 9a. That is, if in Step 9a you connected an F connector to the MRAU FWD SECONDARY PORT 1, the paired CATV cable must connect to the MRAU REV SECONDARY PORT 1.

If the connection is correct, the SRAU powers up and the SRAU SECONDARY FWD LED turns green.

Page 12 InterReach Spectrum Remote Access Unit Installation Guide

2011 ADC Telecommunications, Inc ADCP-77-168 • Issue 2 • 07/2011

Install the RAUs and Antennas

REV IF OUT REV SECONDARY PORTS

1 2 3

FWD SECONDARY PORTS 1 2 3

FWD IF IN

LINK STATUS

SECONDARY

REV

SECONDARY

FWD

LINK STATUS

SECONDARY

REV

SECONDARY

FWD

LINK STATUS

SECONDARY

REV

SECONDARY

FWD

MRAU

SRAU1

SRAU2

SRAU3

To an IFEU FWD Module IF OUT connector (1 - 8)

To an IFEU REV Module

IF IN connector (1 - 8)

To an antenna

10 Repeat Step 9 to install up to two more SRAUs, as per system design.

Configure the MRAUs and SRAUs

Refer to the ADC InterReach Spectrum™ Element Management System 7.0 User Manual (ADCP-77-163) for information on how to configure the MRAUs and

SRAUs.

Appendix A: Specifications

APPENDIX A: SPECIFICATIONS

Spectrum System Specifications

RF Specification

Supported Frequency Blocks 2 per Remote Antenna Unit; 1-8 per Host Unit Bandwidth 1.5 to 75 MHz non-contiguous Frequency Band Supported 850 Cellular; 800 iDEN; 900 iDEN; 1900 PCS;

2100 AWS; 700 Upper C Lower ABC

Propagation Delay

System Delay <12 microseconds Delay Management Digital (Manual or Automatic)

Noise Figure

Noise Figure For 1 Host, 1 DRU, 8 RAUs: < 17 dB

For 1 Host, 4 DRUs, 32 RAUs: < 23 dB

Input IP3 >-10 dBm

Optical Specifications

Optical Budget 10 dB (Standard); 26 dB (Optional) Digital Transport Rate 3.072 Gbps

Nominal Passband Gain

Average gain with  190m of CATV  at 25° C (77° F) (dB)

700 - 900 MHz

Typical

TX RX TX RX

40 30 40 30

1900 - 2100 MHz

Typical

Output Power

Output P1dB Power per Band 26 dBm 850MHz Cell

26 dBm 1900MHz PCS 26 dBm 700MHz Upper C Lower ABC 26 dBm 2100MHz AWS

Page 14 InterReach Spectrum Remote Access Unit Installation Guide

2011 ADC Telecommunications, Inc ADCP-77-168 • Issue 2 • 07/2011

Remote Access Unit Specifications

Operating Temp -25°C to +50°C Storage Temperature -40°C to +70°C Humidity 10% to 90% non-condensing Dimensions 11.50" x 9.00" x 3.50" Weight 7.49 Pounds Power Source 54VDC (from IFEU)

Composite Power Out of RAU

RF Frequency Number of RF Carriers

TX RX 1 2 4 8 16

26 23 20 18 17.5 GSM

850 Cell 869-894 824-849

800 SMR 851-869 806-824

900 SMR 935-940 896-901

1900 PCS 1930-1995 1850-1915

2100 AWS 2110-2155 1710-1755 15 14 12.5 WCDMA

700 Upper C 746-756 776-786 15 14 12.5 LTE

700 Lower ABC 728-746 698-716 15 14 12.5 LTE

23 20.5 18 17 17 EDGE

16 16 16 16 CDMA

15 14 12.5 WCDMA

17.5 17 16 15.5 iDEN

26 22.5 19.5 17.5 APCO 25 C4FM

17.5 17 16 15.5 iDEN

26 22.5 19.5 17.5 APCO 25 C4FM

26 23 20 18 17.5 GSM

23 20.5 18 17 17 EDGE

16 16 16 16 CDMA

15 14 12.5 WCDMA

Appendix A: Specifications

Appendix B: 75-Ohm CATV Cable

APPENDIX B: 75-OHM CATV CABLE

The 75-Ohm CATV Cable:

• connects the IFEU to MRAU(s) and the MRAU(s) to the SRAU(s)

• transmits (FWD) multiband and receives (REV) IF signals

• delivers DC electrical power to the RAUs. The Spectrum IFEU DC voltage output

is 54VDC nominal. If the IFEU reaches its current limit, a current-limiting circuit protects it.

• carries configuration and status information

• uses 75 type-F connectors with captive centerpins.

CATV Cable Requirements

Belden CATV cable or equivalent is required (see Figure 2).

• For the RG-6 cable, use a Belden 1695A Coax.

• For the RG-11 cable, use a Belden 7732A Coax.

NOTE: ADC requires solid copper center conductor CATV cable for proper DC voltage to the RAU

and maximum distances.

RG-6

Belden 1695A Coax

Belden 7732A Coax

RG-11

Figure 2. Belden 1695A and 7732A Coax Cables

Page 16 InterReach Spectrum Remote Access Unit Installation Guide

2011 ADC Telecommunications, Inc ADCP-77-168 • Issue 2 • 07/2011

Appendix B: 75-Ohm CATV Cable

• Use RG-6 or RG-11 CATV cable between the IFEU and MRAU, the typical

lengths of which are listed below.

Minimum Length Maximum Length

Cable Type

Meters Feet Meters Feet

RG-6 0 0 140 459

RG-11 0 0 200 656

• Use only RG-6 CATV cable between the MRAU and SRAU, the lengths of which

are listed below.

RG-6 Cable Meters Feet

Typical 2 6.56

800/900 iDEN to 850 CELL 6 19.68

800 AWS to 850 CELL 6 19.68

Belden 1695A Coax Specifications

Description

RG-6/U type, 18 AWG solid 0.040-inch bare copper conductor, plenum, foam FEP insulation, Duofoil jacket.

+ tinned copper braid shield (95% coverage), Flamarrest

Overall Physical Characteristics

Conductor One Coax

18 AWG Solid stranding Bare Copper (BC) conductor material

0.040-inch diameter

Insulation Teflon

Foam Fluorinated Ethylene Propylene (FFEP)

0.170-inch diameter

Outer Shield Layer 1 Duofoil

Tape Aluminum Foil-Polyester Tape-Aluminum Foil 100% coverage

Outer Shield Layer 2 Braid

Tinned Copper (TC) 95% coverage

Outer Jacket Flamarrest

Low Smoke Polyvinyl Chloride (LS PVC)



Overall Cabling 0.234-inch overall nominal diameter

Appendix B: 75-Ohm CATV Cable

Overall Nominal Electrical Characteristics

Characteristic Impedance 75.000 Inductance 0.103 H/ft. Capacitance Conductor to Shield 16.100 (pF/ft.) Velocity of Propagation 82 (%) Delay 1.240 (ns/ft.) Conductor DC Resistance 6.400 @ 20°C (/1000 ft.) Outer Shield DC Resistance 2.800 @ 20°C (/1000 ft.) Attenuation

Freq. (MHz) Attenuation (dB/100 ft.)

1.000 0.240

3.580 0.450

5.000 0.550

7.000 0.650

10.000 0.750

67.500 1.740

71.500 1.780

88.500 1.940

100.000 2.100

135.000 2.400

143.000 2.500

180.000 2.800

270.000 3.400

360.000 4.000

540.000 5.200

720.000 6.100

750.000 6.200

1000.000 7.300

1500.000 9.200

2000.000 10.900

2250.000 11.600

3000.000 13.700

Page 18 InterReach Spectrum Remote Access Unit Installation Guide

2011 ADC Telecommunications, Inc ADCP-77-168 • Issue 2 • 07/2011

Belden 7732A Coax Specifications

Description

Appendix B: 75-Ohm CATV Cable

RG-11/U type, 14 AWG solid 0.064-inch bare copper conductor, plenum, foam FEP

insulation, Duofoil

+ tinned copper braid shield (95% coverage), fluorocopolymer

jacket.

Overall Physical Characteristics

Conductor One Coax

18 AWG Solid stranding Bare Copper (BC) conductor material

0.064-inch diameter

Insulation Teflon

Foam Fluorinated Ethylene Propylene (FFEP)

0.274-inch diameter

Outer Shield Layer 1 Duofoil

Tape Aluminum Foil-Polyester Tape-Aluminum Foil 100% coverage

Outer Shield Layer 2 Braid

Tinned Copper (TC) 95% coverage



Outer Jacket Fluorocopolymer (PVDF) Overall Cabling 0.348-inch overall nominal diameter

Overall Nominal Electrical Characteristics

Characteristic Impedance 75.000 Inductance 0.091 H/ft. Capacitance Conductor to Shield 16.300 (pF/ft.) Velocity of Propagation 83 (%) Delay 1.220 (ns/ft.) Conductor DC Resistance 2.500 @ 20°C (/1000 ft.) Outer Shield DC Resistance 1.600 @ 20°C (/1000 ft.)

Appendix B: 75-Ohm CATV Cable

Attenuation

Freq. (MHz) Attenuation (dB/100 ft.)

1.000 0.150

3.580 0.260

5.000 0.300

7.000 0.340

10.000 0.400

67.500 1.200

71.500 1.240

88.500 1.400

100.000 1.500

135.000 1.780

143.000 1.840

180.000 2.090

270.000 2.600

360.000 3.100

540.000 3.890

720.000 4.570

750.000 4.680

1000.000 5.500

1500.000 6.910

2000.000 8.130

2250.000 9.200

3000.000 10.200

Page 20 InterReach Spectrum Remote Access Unit Installation Guide

2011 ADC Telecommunications, Inc ADCP-77-168 • Issue 2 • 07/2011

Appendix C: Omni Antenna

APPENDIX C: OMNI ANTENNA

The Omni Antenna (4214-M727), shown in Figure 3, is a round radome with the following specifications:

• 8.5-inch diameter

• 1.65-inch height

• 72-inch pigtails that are plenum-rated cables with N (male) connectors

Figure 3. Omni Antenna

NOTE: Two antennas per RAU is required for MIMO performance.

The Omni Antenna supports the following:

• Port 1

– 698-806 MHz (700 Upper C Lower ABC) – 1710-2170 MHz (AWS)

• Port 2

– 806-941 MHz (Cellular/SMR) – 1850-1990 MHz (PCS)

• Port 3

– 2500-2700 MHz (WiMAX)

Appendix D: Contacting ADC/TE Connectivity

PHONE

U.S.A. or CANADA

Sales: 1-800-366-3891 Extension 73000 Technical Assistance: 1-800-530-9960 Connectivity Extension: 73475 Wireless Extension: 73476

EUROPE

Sales Administration: +32-2-712-65 00 Technical Assistance: +32-2-712-65 42

EUROPEAN TOLL FREE NUMBERS

Germany: 0180 2232923 UK: 0800 960236 Spain: 900 983291 France: 0800 914032 Italy: 0800 782374

ASIA/PACIFIC

Sales Administration: +65-6294-9948 Technical Assistance: +65-6393-0739

ELSEWHERE

Sales Administration: +1-952-917-3000 Technical Assistance: +1-952-917-3475

ONLINE ACCESS

Connectivity Products

United States: Connectivity.Tac@te.com Europe: Euro.Tac@te.com Asia/Pacific: AsiaPacific.Tac@te.com

All Wireless Products

WirelessSupport@te.com

Customer Portal

http://www.adc.com/Americas/en_US/1268116693520

Online Customer Support Request

https://nssales.adc.com/ftr/ftrhome1.asp

APPENDIX D: CONTACTING ADC/TE CONNECTIVITY

NOTE: ADC is now TE Connectivity.

Page 22 InterReach Spectrum Remote Access Unit Installation Guide

2011 ADC Telecommunications, Inc ADCP-77-168 • Issue 2 • 07/2011

Website: www.adc.com

ADC S2983 011, S2793 111, S2791 011, S2990 011, S2795 011 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

PREFACE

InterReach Spectrum User Documentation

Document Cautions and Notes

General Safety Precautions

Standards Certification

Product Overview

Main Remote Access Units

MRAU Ports, Cable, and Connectors

MRAU LEDs

Secondary Remote Access Units

SRAU Ports, Cable, and Connectors

Install the RAUs and Antennas

SRAU LEDs

Mount the RAUs and Antennas

Connect the IFEU to the MRAU

Connect the MRAU to SRAUs

Configure the MRAUs and SRAUs

Appendix A: Specifications

Spectrum System Specifications

Remote Access Unit Specifications

Composite Power Out of RAU

Appendix B: 75-Ohm CATV Cable

CATV Cable Requirements

Belden 1695A Coax Specifications

Description

Overall Physical Characteristics

Overall Nominal Electrical Characteristics

Belden 7732A Coax Specifications

Description

Overall Physical Characteristics

Overall Nominal Electrical Characteristics

Appendix C: Omni Antenna

Appendix D: Contacting ADC/TE Connectivity
