Adastra BC5A User Manual
BC5A / BC6A
ACTIVE STEREO SPEAKER SET
Order ref: 170.164UK, 170.165UK, 170.166UK, 170.168UK, 170.169UK
User Manual
Active + satellite stereo pair
Supplied with adjustable wall brackets
Supplied with satellite link cable
RCA or 3.5mm stereo inputs
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC ELECTRIQUE NE
PAS OUVRIR
This symbol indicates that dangerous voltage constituting a risk of electric shock is
present within this unit
This symbol indicates that there are important operating and maintenance instructions
in the literature accompanying this unit.
Introduction
Thank you for choosing the BC-series active speaker set. Please read this manual prior to use to avoid
damage to the item. These compact, self-contained stereo speaker sets are designed to deliver high quality
near-field or perimeter coverage for various monitoring and installed sound applications
Contents
Please take care when unpacking this product. Inspect for any damage and ensure you have the following
components…
BC-series active speaker with built-in amplifier
BC-series passive satellite speaker
2 x wall-mounting brackets with screw caps
Satellite speaker wire – modular connector
Mains lead(s)
Safety Conventions
Warning
To prevent the risk of fire or electric shock, do not expose this appliance to rain or moisture.
To prevent electric shock do not remove the rear cover.
No user serviceable parts inside. Refer servicing to qualified service personnel.
Safety
Prior to connecting the dc adaptor to mains, ensure that the supply voltage is correct.
Avoid ingress of water or particles into the enclosure.
Placement
Keep the unit out of direct sunlight and away from heat sources.
Keep the unit away from moisture or dusty environments.
Allow adequate space for cooling at the rear of the active speaker unit
Cleaning
Use a soft cloth with a neutral detergent to clean the cabinet, panel and controls. Do not use solvents.
BC5A BC6A User Manual
