Adaptec AHA 29160 Installation Guide

R

NSTALLATION

I

UIDE

G

A

DAPTEC

U

SCSI C

LTRA

160 SCSI C

29160

ARD

ONTROLLER

NTRODUCTION

I

The Adaptec SCSI Card 29160 Ultra160 SCSI controller enables
you to connect up to 15 SCSI devices—such as hard disk drives,
scanners, and CD-ROM drives—to any Intel-based computer
with 32-bit or 64-bit PCI expansion slots. You can connect newer
LVD SCSI devices (includes Ultra160 and Ultra2) to the two
68-pin Low Voltage Differential/Single-Ended (LVD/SE) connec­tors. You can also connect legacy SCSI devices to the 68-pin and
50-pin internal Single-Ended (SE) connectors.

68-pin Internal LVD/SE Connector 68-pin Internal SE Connector

68-pin External
LVD/SE Connector

Adaptec SCSI Card 29160

50-pin Internal SE Connector

Although the Adaptec SCSI Card 29160 is a 64-bit PCI card, it
also works in a 32-bit PCI slot. When installed in a 32-bit PCI
slot, the card automatically runs in the slower 32-bit mode.

This installation guide explains how to

•

Install the Adaptec SCSI Card 29160

•

Set up SCSI devices

•

Connect SCSI devices

3

Installation Guide

Bus Segments on the Adaptec SCSI Card 29160

The Adaptec SCSI Card 29160 features Adaptec SpeedFlex™
technology. SpeedFlex technology ensures that you get the best
performance from your LVD SCSI devices by electronically
isolating the primary LVD/SE segment from the secondary SE
segment on the SCSI bus. This allows the Adaptec SCSI Card
29160 to support LVD SCSI devices at speeds up to 160
MBytes/sec on the primary LVD/SE segment while at the same
time supporting Ultra (legacy) devices at speeds up to 40
MBytes/sec on the secondary SE segment. The following figure
shows the two SCSI segments.

Primary LVD/SE Segment Secondary SE Segment

AIC-3860

AIC-7892

N

OTE

If you attach Wide Ultra or Ultra SCSI devices to the
two connectors on the Primary LVD/SE segment, the data
transfer rate for all attached LVD SCSI devices will drop to
Ultra SCSI performance levels. However, if you attach

only

LVD SCSI devices to the two connectors on the Primary
LVD/SE segment, data will be transferred at the maximum
possible rate (80 MBytes/sec for Ultra2 devices and
160 MBytes/sec for Ultra160 devices).

4

Adaptec SCSI Card 29160

NSTALLING THE ADAPTEC

I

Discharge any static electricity build-up before handling the SCSI

1

card by touching a grounded metal object (like the exposed metal
parts on the back of your computer).

W

ARNING

the power cord.

After you turn off your computer and unplug the power cord,

2

remove the cover from the computer.

Locate an unused 64-bit PCI expansion slot and remove the

3

expansion slot cover. If the computer does not have a 64-bit slot,
you can install the card in a 32-bit PCI slot. (The expansion slot
must be compliant with PCI Rev. 2.1 or higher and must support
Bus Mastering.) Save the slot cover screw for use in Step 4.

Turn OFF power to the computer and disconnect

S

S

S

TEP

TEP

TEP

SCSI C

ARD

29160

Slot Cover Screw

Expansion Slot Cover

64-bit PCI Slot

32-bit PCI Slot

5

Installation Guide

Computers may have vertical or horizontal expansion slots. Refer
to your computer manual to locate the PCI slots. If your com­puter is a tower model, lay it on its side to make it easier to install
the Adaptec SCSI Card 29160.

W

ARNING

29160 in a PCI slot. Some 32-bit slots will not accommodate
it, and the card may break if you force it into the slot.

Be careful when inserting the Adaptec SCSI Card

S

TEP

Insert the Adaptec SCSI Card 29160 into the PCI expansion slot;

4

press down firmly until the card clicks into place, then replace the
slot cover screw. When installed properly, the card should appear
level with the expansion slot, as shown below.

6

Adaptec SCSI Card 29160

ETTING UP

S

SCSI D

There are several things you may need to do to your SCSI devices
before you connect them to the Adaptec SCSI Card 29160:

•

Check the SCSI IDs

•

Te r mi n a te th e E nd s

•

Mount the Devices

Since setup can vary from device to device, always refer to the
device’s documentation for specific instructions.

Below are some guidelines for checking SCSI IDs, setting termi­nation, and mounting devices in your computer. Refer to the

Adaptec SCSI Card 29160 User’s Reference

on these topics.

EVICES

for more information

Check the SCSI IDs

The Adaptec SCSI Card 29160 and each device you connect to it
must have a unique SCSI ID number ranging from 0 to 15. No
two devices can have the same number.

The Adaptec SCSI Card 29160 is preset to SCSI ID 7 and should
not be changed. If your computer will boot from a SCSI hard
disk, make sure the SCSI ID of that hard disk is set to 0. (Most
SCSI hard disks are preset to SCSI ID 0 at the factory.) The SCSI
IDs for internal devices are usually set with jumpers; SCSI IDs for
external devices are usually set with a switch on the back of the
device.

Terminate the Ends

To ensure reliable communication on the SCSI bus, the device at
the end of each cable, or the end of the cable itself, must have a
terminator installed (or enabled). Terminators must be removed,
or termination must be disabled, on devices between the ends of
each cable.

Terminating LVD SCSI Devices

LVD SCSI devices are automatically un-terminated. If you are
using internal LVD SCSI devices, a special 68-pin internal LVD
cable is required to connect the devices. Internal LVD cables

7

Installation Guide

usually have a terminator built into the end of cable. With this
type of cable, it is not necessary to terminate individual internal
Ultra160 and Ultra2 devices.

If you are using external LVD devices, be sure to use an LVD
terminator to terminate the last device in the chain. If you use a
single-ended, active terminator (sometimes called an Ultra SCSI
terminator) the SCSI devices will not operate at their maximum
speed and you will be limited to shorter total cable lengths.

Terminating Ultra SCSI and Fast/Wide SCSI Devices

On most internal Ultra SCSI and Fast/Wide SCSI devices, the ter­mination setting is controlled by setting a jumper or a switch, or
by physically removing or installing a resistor module(s). If you
are using an internal SCSI cable that has a built-in terminator,
you must disable termination on all internal devices connected to
the cable.

On most external Ultra SCSI and Fast/Wide SCSI devices, termi­nation is controlled by installing or removing a terminating plug.
For more information, refer to the documentation for each SCSI
device.

Mount the Devices

If you have internal SCSI devices, mount each device in an avail­able drive bay inside your computer, as shown below. Refer to
your computer and device documentation for instructions on
installing devices inside your computer.

Internal SCSI Device
Mounted in Drive Bay

8

Adaptec SCSI Card 29160

ONNECTING

C

You can connect up to 15 SCSI devices to the Adaptec SCSI Card

29160. Before connecting devices, be sure to review

SCSI Devices

devices, refer to the

Connecting Internal LVD SCSI Devices

Connect internal LVD SCSI devices to the internal LVD/SE
connector on the Adaptec SCSI Card 29160. To do this, use a
68-pin internal LVD cable like the one shown in Step 1 below.

Follow these steps to connect the devices:

S

TEP

Locate a 68-pin internal LVD SCSI cable, which may have either

1

twisted wires as shown below or flat, laminated wires.

SCSI D

on page 7. For additional details on connecting

N

OTE

SCSI devices can be connected to all four SCSI
connectors on the Adaptec SCSI Card 29160 at the same time.

N

OTE

We recommend that you keep your LVD SCSI devices
separate from your SE (Ultra SCSI) devices. This allows LVD
SCSI devices to transfer data at their maximum speed. (See

Bus Segments on the Adaptec SCSI Card 29160

EVICES

Setting Up

Adaptec SCSI Card 29160 User’s Reference

on page 4.)

.

Terminated End Nonterminated End

9

Installation Guide

S

S

TEP

TEP

Plug the nonterminated end of the cable to the internal LVD/SE

2

connector.

68-pin Internal LVD
SCSI Cable

68-pin Internal LVD/SE Connector

Plug the internal LVD SCSI devices to the other cable connectors,

3

starting with the connector at the terminated end of the cable.

LVD (e.g., Ultra160 or
Ultra2) SCSI Devices

10

Plug First Device
to this Connector

N

OTE

Internal LVD SCSI devices come from the factory with

Built-in Terminator
on Cable

termination disabled and cannot be changed. Proper SCSI
bus termination is provided by the terminator at the end of
the LVD SCSI cable. See

Terminate the Ends

on page 7 for

more information.

Adaptec SCSI Card 29160

S

S

TEP

TEP

Connect a power cable from your computer’s internal power sup-

4

ply to each internal SCSI device.

Power Cable (From the Power
Supply Inside the Computer)

Power Input Connector on
the Back of the Device

Connecting Internal Ultra/Wide SCSI Devices

Connect internal Ultra/Wide SCSI devices to the 68-pin internal
SE Wide SCSI connector. To do this, use a 68-pin Wide SCSI
cable like the one shown in Step 1 below. Follow these steps to
connect the devices:

Locate a 68-pin internal Wide SCSI cable.

1

11

Installation Guide

S

S

TEP

TEP

Plug one end of the cable to the Wide SCSI connector on the

2

Adaptec SCSI Card 29160.

68-pin Internal Wide
SCSI Cable

68-pin Wide SCSI Connector

Plug the other end of the cable to a

3

SCSI device.

terminated

Ultra/Fast Wide

12

S

TEP

Terminated SCSI Device

If you have other Ultra/Fast Wide SCSI devices, attach them to

4

the connectors between the two ends of the cable. Be sure these
other devices are

un-terminated

Un-terminated SCSI Device

Terminated SCSI Device

.

Adaptec SCSI Card 29160

S

S

TEP

TEP

Connect a power cable from your computer’s internal power

5

supply to each internal device.

Power Cable (From the Power
Supply Inside the Computer)

Power Input Connector on
the Back of the Device

Connecting Internal Ultra/Fast Narrow Devices

Connect internal Ultra/Fast Narrow SCSI devices that have stan­dard 50-pin connectors to the 50-pin internal SE Narrow SCSI
connector. To do this, use a 50-pin internal Ultra Narrow SCSI
cable. Follow these steps to connect the devices:

Locate a 50-pin internal Ultra Narrow SCSI cable.

1

13

Installation Guide

J

S

TEP

S

TEP

Plug one end of the cable to the 50-pin internal SE Narrow SCSI

2

connector on the Adaptec SCSI Card 29160.

50-pin Internal Narrow
SCSI Connector

50-pin Internal
Ultra Narrow SCSI Cable

Plug the other end of the cable to a terminated Ultra/Fast Narrow

3

SCSI device.

Terminated SCSI Device

14

S

TEP

If you have other Ultra/Fast Narrow SCSI devices, attach them to

4

the connectors between the two ends of the cable. Be sure these
other devices are

Terminated SCSI Device

un-terminated

Un-terminated SCSI Device

.

Adaptec SCSI Card 29160

S

TEP

Connect a power cable from your computer’s internal power

5

supply to each internal device.

Power Cable (From the Power
Supply Inside the Computer)

Power Input Connector on
the Back of the Device

Connecting External SCSI Devices

Connect external LVD SCSI devices to the 68-pin external
LVD/SE SCSI connector. Each external device will require a
68-pin external LVD SCSI cable.

N

OTE

We r ec om me nd th at y ou co nn ec t
devices to the external SCSI connector. If you also attach
older Ultra SCSI devices, the data transfer speed of the LVD
SCSI devices will drop to the speed of the older devices. (See

Bus Segments on the Adaptec SCSI Card 29160

only

LVD SCSI

on page 4.)

Follow these steps to connect the external devices:

S

TEP

Connect one end of the external LVD SCSI cable to the external

1

LVD/SE connector on the Adaptec SCSI Card 29160.

68-pin External
LVD/SE SCSI
Connector

68-pin External
LVD SCSI Cable

15

Installation Guide

S

S

TEP

TEP

Connect the other end of the external SCSI cable to a SCSI

2

connector on the back of an external SCSI device.

SCSI Terminator

4

4

If you are installing only one external device, terminate the device
and skip to Step 4.

N

OTE

An LVD terminator must be used for LVD SCSI devices
to ensure optimum performance. See

Terminate the Ends

page 7 for more information.

Connect other external devices by cabling each device to the pre-

3

vious one, as shown below. Terminate only the device at the end
of the chain.

on

16

Un-terminated

Terminated

Adaptec SCSI Card 29160

S

4

TEP

DAPTEC

A

Connect power cables to all external devices and to the computer.

SCSI C

To use the Adaptec SCSI Card 29160, the card’s driver software
must be installed for your operating system (for example,
Windows
Ultra160 Family Manager Set contains driver software for many
of the popular operating systems.

Refer to the

Adaptec SCSI Card 29160 User’s Reference

either installing driver software when installing your operating
system, or installing driver software when the operating system is
already installed.

ARD DRIVER SOFTWARE

®

98, Windows NT®, Novell NetWare, etc.). The

Ultra160 Family Manager Set User’s Guide

for instructions on

and

N

OTE

Operating system versions released after November,
1999, may have embedded driver support for the Adaptec SCSI
Card 29160. To determine if the card is supported by the oper­ating system you are using, read the operating system manual
or contact the operating system vendor for information.

17

Installation Guide

ROUBLESHOOTING

T

If you have any problems while installing the Adaptec SCSI Card
29160, check the following items first:

•

Are all SCSI devices powered on?

•

Are all SCSI cables and power cables properly connected?

•

Does each device on the SCSI bus have a unique SCSI ID?

•

Does the total SCSI cable length exceed the maximum allow­able length? (See the

Reference

•

Is the SCSI bus properly terminated?

If you are still unable to resolve a problem, refer to the

SCSI Card 29160 User’s Reference

http:\\www.adaptec.com

information.

Adaptec SCSI Card 29160 User’s

for more information.)

Adaptec

, or the Adaptec Web site at

for additional troubleshooting

18

Copyright

© 2000 Adaptec, Inc. All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopy­ing, recording or otherwise, without the prior written consent of Adaptec, Inc., 691 South Milpitas
Blvd., Milpitas, CA 95035.

Tr a d e m a r k s

Adaptec, the Adaptec logo, and SpeedFlex are registered trademarks of Adaptec, Inc., which may be
registered in some jurisdictions. Windows, Windows 98, and Windows NT are registered trade­marks of Microsoft Corporation in the U.S. and other countries used under license.

All other trademarks are owned by their respective owners.

Changes

The material in this document is for information only and is subject to change without notice.
While reasonable efforts have been made in the preparation of this document to assure its accu­racy, Adaptec, Inc. assumes no liability resulting from errors or omissions in this document, or
from the use of the information contained herein.

Adaptec reserves the right to make changes in the product design without reservation and without
notification to its users.

Disclaimer

IF THIS PRODUCT DIRECTS YOU TO COPY MATERIALS, YOU MUST HAVE PERMISSION
FROM THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID VIOLATING THE LAW
WHICH COULD RESULT IN DAMAGES OR OTHER REMEDIES.

Regulatory Compliance Statements

20

Federal Communications Commission Radio Frequency Interference Statement

WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compli­ance could void the user’s authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio commu­nications. However, there is no guarantee that interference will not occur in a particular installation. However, if
this equipment does cause interference to radio or television equipment reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/television technician for help.

• Use a shielded and properly grounded I/O cable and power cable to ensure compliance of this unit to the spec­ified limits of the rules.

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference and (2) this device must accept any interference received, including
interference that may cause undesired operation.

Adaptec, Inc. Adapte c SCSI Card 29160

Tes te d t o Co mp ly
With FCC Standards

FOR HOME OR OFFICE USE

European Union Compliance Statement

This Information Technology Equipment has been tested and found to comply with the following
European directives:

EMC Directive 89/336/EEC

EN 50081-1 (1992):

EN55022 (1994) Class B

EN 50082-1 (1992):

EN61000-4-2 (1998)
EN61000-4-3 (1998)
EN61000-4-4 (1995)

Australian/New Zealand Compliance Statement

This device has been tested and found to comply with the limits for a Class B digital device, pursuant
to the Australian/New Zealand standard AS/NZS 3548 set out by the Spectrum Management Agency.

Canadian Compliance Statement

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equip­ment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matérial
brouilleur du Canada.

Japanese Compliance

21

R

We move the information that

moves yo ur world.

™

© 2000 Adaptec, Inc. All rights reserved.

Printed in Singapore

Stock No.: 512520-03, Rev. A RAC 1/00

(SRC: 512520-00, Ver. AA)
