B1921 | B1923
Reinforcing
Pivots
B1921 | B1923
Reinforcing
Pivots
B1921 | B1923
Reinforcing Pivots
B1921, B1923 Reinforcing Pivots provide an economical way to
transfer load from hinges of sagging hollow metal or wood doors.
Function
This full-surface reinforcing pivot adds years of life to openings where the
hinges or hinge reinforcements have failed. Reinforcing pivots take the load
o the top hinge and transfer it to screws that are in shear so they will not
pull o. The quick and economical way to solve door sag problems.
Features
Type
Full surface reinforcing
pivots for flush doors.
Finish
Zinc plating over steel.
Materials
Heavy duty 3/16" [4.8 mm]
cold-rolled steel.
Cycle Testing
1,500,000 cycles
Capacity
Supports weights up to
300 lbs [136.08 kg]
Hole Pattern
Symmetrically located. Non-handed.
Hinge Size
B1921: designed with 1/2" [12.7 mm]
oset to match the pivot point of
a 4" [101.6 mm] wide butt hinge.
B1923: designed with a 3/4" [19.1mm]
oset to match the pivot point of a
4-1/2" [114.3 mm] wide butt hinge.
Standard Package
Comes complete with all
necessary fasteners. Optional
tamper-proof screw available.
Shipping Weight
1-1/2 lb [0.68 kg]
