ACCESSORIES
4901, 4902
Deadlatch Strikes
ALUMINUM
HOLLOW
METAL
WOOD
4901, 4902 DEADLATCH STRIKES
4901-01
Standard slat strike includes molded black plastic dust box
and closure of the unused lower strike opening, with steel
mounting plate. Long face is designed to span strike area of
MS® deadlocks with which the deadlatch is interchangeable.
4901-02
Same as 4901-01, except with radiused strike plate, for nose
of opposite door when latching pairs.
4902-01
Standard flat strike furnished with the 4900 Series Heavy
Duty Deadlatches. Includes molded black plastic dust box
and steel mounting plate. Short face design.
A-13
4901, 4902 Deadlatch Strikes add aesthetics and finish to
strike cutouts in jambs.
Function
Designed for use in conjunction with 4300, 4500, 4700, and 4900 Series
Deadlatches, these strikes offer a choice of mounting methods; a backup mounting
plate included with the 4901 and 4902 allows installation flush in a hollow section
jamb. Use 4506-02 ANSI strike for wood or steel jambs. All strikes are unhanded,
suitable for right or left hand doors. Strike plate material is stainless steel.
4902-02
Same as 4902-01, except with radiused strike plate, for nose
of opposite door when latching pairs.
4901-01
4902- 01
Accomodates the 1/2" wide
latchbolt of 4500/4700 latches
and 5/8" wide latchbolt of
the 4900 Series by removing
snap-in nylon insert.
ARM-014-9/14
800.872.3267 • Fax 800.232.7329
10027 S. 51st Street, Ste 102
Phoenix, Arizona 85044
www.adamsrite.com
A-14
All measurements are approximate and are provided for informational purposes only. Refer to the product Installation Instructions.
4901, 4902 DEADLATCH STRIKES
ACCESSORIES
Dimensions
4901 4901
10-32 TAP
9.5mm
4-5/8"
117.5mm
3-7/8"
98.4mm
3/8"
CSK FOR #10
FLAT HEAD
1-1/8"
28.6mm
1-1/8"
28.6mm
1-1/8"
28.6
mm
19.1
19.1
3/4"
3/4"
MOUNTING
PLATE
STRIKE
PLATE
mm
43/64"
17.1mm
mm
3/8"
9.5mm
DUST
BOX
1/8"
3.2mm
5-3/8"
136.5mm
6-1/8"
155.6
11/32"
8.7mm
9/16"
14.3mm
DIM: ‘A’
4901-01 FLAT
WITH DUST BOX &
62.7mm
MOUNTING PLATE
R
1-3/16"
30.2mm
4901-02 RADIUS
WITH DUST BOX &
MOUNTING PLATE
9/16"
14.3mm
mm
2-15/32"
Installation
5-3/8"
136.5mm
4902
4902
2-5/8"
66.7mm
1-7/8"
47.6mm
10-32 TAP
3/8"
9.5mm
CSK FOR #10
FLAT HEAD
1-1/8"
28.6mm
1-1/8"
28.6mm
3/4"
19.1mm
MOUNTING
PLATE
STRIKE
PLATE
43/64"
17.1mm
9.5mm
DUST
BOX
1/8"
3.2mm
3/8"
3-3/8"
85.7mm
4-1/8"
104.8mm
11/32"
8.7mm
2-15/32"
62.7mm
DIM: ‘A’
4902-01 FLAT
WITH DUST BOX &
MOUNTING PLATE
R
1-3/16"
30.2mm
4902-02 RADIUS
WITH DUST BOX &
MOUNTING PLATE
9/16"
14.2mm
9/16"
14.2mm
3-3/8"
85.7mm
1/16"
1.6
2-41/64"
66.2mm
1/16"
1.6
mm
3/8"
9.5mm
4-41/64"
117.9mm
mm
3/8"
9.5mm
DEADLATCH
IN DOOR
37/64"
14.7mm
DEADLATCH
IN DOOR
37/64"
14.7mm
7/64"
2.8mm
CYLINDER
4500, 4900 OR
EXISTING 4700
5/32"
R
4mm
DRILL AND CSK
FOR #10 FLAT
HEAD SCREWS
FURNISHED WITH FOUR
#10-32 X 1/2 FLAT HEAD
MACHINE SCREWS
7/64"
2.8mm
CYLINDER
4500, 4900 OR
EXISTING 4700
5/32"
R
4mm
DRILL AND CSK
FOR #10 FLAT
HEAD SCREWS
FURNISHED WITH FOUR
#10-32 X 1/2 FLAT HEAD
MACHINE SCREWS
4901, 4902 DEADLATCH STRIKES
Specify quantity and the following information. Order related products separately.
STRIKE TYPE FACEPLATE SHAPE
490 1 -02
Standard Lip
Long 01 Flat
1
2 Short 02 Radius
Long Lip for Center Hung Door DIM. 'A'
2-1/4" Wide Jamb 13 3-1/2" Wide Jamb
03
05 2-1/2" Wide Jamb 15 3-3/4" Wide Jamb
07 2-3/4" Wide Jamb 17 4" Wide Jamb
09 3" Wide Jamb 19 4-1/4" Wide Jamb
11 3-1/4" Wide Jamb 21 4-1/2" Wide Jamb
COMPATIBLE PRODUCTS This product is compatible with the following products:
Deadlatches
4300 eLatch Electrified Deadlatch
4500 Series Standard Duty Deadlatch
4900 Series Heavy Duty Deadlatch
Note that 4700 Deadlatch is discontinued and replaced by 4900 Deadlatch.
1-1/8 1-3/4
1-1/4 1-7/8
1-3/8 2
1-1/2 2-1/8
1-5/8 2-1/4
