Adams Rite 3080-01-0-31-00-03, 3080-01-0-31-00-10B, 3080-01-0-31-00-32, 3080-01-0-31-00-32D, 3080-01-0-31-00M32D Specsheet

TRIM

3080 SERIES ENTRY TRIM 3080 SERIES ENTRY TRIM

T-3

3080 Series
Entry Trim

ELECTRIFIED

OPTION

The 3080 Series Entry Trim provides outside activation for
doors with any type of Adams Rite exit device. The locked
handle is protected from vandalism and forced entry with a
breakaway clutching mechanism

3080 Series Entry Trim
Function

The 3080 Series provides outside activation of doors that have any type of Adams
Rite Exit Device. Breakaway clutching mechanism protects the locked handle
from vandalism or forced entry, in either direction. All models share the same core
components, so handles can be changed without having to replace the entire trim.
Solid construction meets Grade 1 standards.

STANDARD SERIES:

DESIGNER SERIES:

3080E Electrified Entry Trim
Function

The 3080E Electrified Entry Trim provides a continuous duty
solenoid mounted to the trim, which enables remote activation
of the locking function without unlatching the door, making this
trim ideal for stairwell and fire doors.

Specifications

STANDARD HANDLES

• The 3080-01, -02, and -03 lever handles are designed to

return within 1/2" of the door face. Handles in the Designer
Series do not have this same feature. Please verify with
local code requirements to ensure compliance.

OPTIONS

• Can be ordered with or without a hole for cylinder. Order

standard mortise cylinder with MS® cam separately. Order
4603 Rectifier, 4605/4606 Transformer or PS-1 Power
Supply separately.

01-CURVE

MD MI

02-ROUND

03-SQUARE

MV

3001 & 3002 Fixed Pulls

US32D Satin Stainless Steel pulls have 2-3/4" x 11-1/2" escutcheon.
Order with or without cylinder hole. For hollow metal and wood doors only.

Dimensions

2-3/4"

69.9mm

3001 3002

HOW TO ORDER 3080 ENTRY TRIM

Specify quantity and the following information. Order related products separately.

PRODUCT

NO.

ELECTRIFIED HANDLE HANDING

CYLINDER

HOLE

EXIT DEVICE VO LTAG E FEAT UR ES

11-1/2"

292.1mm

2-5/16"

58.7mm

3001 3002

2-3/4"

69.9mm

TRIM

COVER

FINISH

11-1/2"

292.1mm

2-1/32"

51.6mm

FINISH

3080 E -01 -0 -3 7 -3 0 M US32D

-

0

(BLANK)

Standard

E Electrified

Tri m

*Handing must be specified for MN and MV Designer Handles

Standard
Handles

01 Curve 8 Left Hand* 4 SCVR 3 12 Volt DC

02 Round 6 CVR 5 24 Volt DC 5 Fail-Safe

03 Square 7 Rim

Designer
Series

MD MJ

ME MN* (Handed)

MG MV* (Handed)

MI MW

No Handing 3 With Hole 1 SVR

7 Right Hand* 9 Without Hole 3 Mortise

U

Universal Kit

Electrified
Tri m On ly

Electrified
Tri m On ly

0 Fail-

Secure

Standard

(Black)

M Matching

Finish

US3 Bright Brass

US4 Satin Brass

US10B Oil-Rubbed

Bronze

US32 Bright

Stainless

US32D Satin

Stainless

ARM-014-9/14

ME MJ

MG MN

MW

800.872.3267 • Fax [phone]

10027 S. 51st Street, Ste 102
Phoenix, Arizona 85044

www.adamsrite.com

RELATED PRODUCTS COMPATIBLE PRODUCTS

When purchasing this product, please consider the following related products,
available separately:

Cylinder Power Deadlatches Exit Devices

3080 Entry Trim is operable
by any standard 1-5/32"
diameter mortise cylinder
with MS® cam.

4605/4606 Transformer, 4603
Rectifier, PS-1 Power Supply and
4612 Power Transfer Device, as
required for the 3080E electrified trim.

This product is compatible with the following products:

4300 Electrified Deadlatch.

4500 Series Standard
Duty Deadlatch.

4900 Series Heavy
Duty Deadlatch.

4781 Two-Point Deadlatch
(with paddle).

Adams Rite 8000 Series and
3000 Series Exit Devices

CYLINDER

ESCUTCHEON

SPACER

CYLINDER

RETAINER RING

SOLENOID

ASSEMBLY*

FLAT HEAD

SCREWS (2 PLCS)*

#6-32 X 1/4"

ROTATION

LIMITING

PINS

* ELECTRIFIED TRIM ONLY

1830

2190
2290

MS1837
MS1850S
MS1850SN
MS1861

MS1950

1875
MS+1890

4300
4510
4530
4900
4920AN

8300
8400
8650

DEADLOCK

DEADLATCH

SERIES

SERIES

EXIT

DEVICES

1870
1870HM

FLUSHBOLTS

THIS CAM AVAILABLE FROM:

ADAMS RITE
ARROW
ASSA
BEST
CORBIN RUSSWIN
DORMA
FALCON
KABA-ILCO
MEDECO
SARGENT
SCHLAGE
WEISER
YALE

DIMENSIONS OF CAM TO OPERATE:

T-4

3080 SERIES ENTRY TRIM

All measurements are approximate and are provided for informational purposes only. Refer to the product Installation Instructions.

TRIM

Dimensions

3080-01*
3080E-01*

3080-MD
3080E-MD

3-1/4"

82.6mm

8-3/32"

205.6mm

3-5/16"

84.1mm

8-3/32"

205.6mm

1-29/32"

48.4mm

1-29/32"

48.4mm

5"

127mm

4-29/32"

124.6

Door Preparation & Trim Installation

Door prep and installation will differ depending on the type of exit device being used. Refer to the Adams
Rite templates for 3080 Entry Trim or 3080E Electrified Entry Trim for preparation details.

CYLINDER

ESCUTCHEON

SPACER

3080-02*
3080E-02*

3-15/32"

88.1mm

8-3/32"

205.6mm

1-29/32"

48.4mm

4-9/16"

115.9mm

3080-03*
3080E-03*

2-29/32"

73.8mm

8-3/32"

205.6mm

1-29/32"

48.4mm

4-11/32"

110.3mm

CYLINDER

RETAINER RING

FLAT HEAD

SCREWS (2 PLCS)*

#6-32 X 1/4"

SOLENOID

ASSEMBLY*

3-19/32"

91.3mm

8-3/32"

205.6mm

1-29/32"

48.4mm

5-1/8"

130.2mm

1-29/32"

48.4mm

3-11/16"

3080-ME
3080E-ME

mm

93.7mm

8-3/32"

205.6mm

4-5/16"

109.5mm

3080-MG
3080E-MG

3-5/8"

92.1mm

8-3/32"

205.6mm

1-29/32"

48.4mm

3080-MW
3080E-MW

4-3/8"

111.1mm

3-5/8"

92.1mm

8-3/32"

205.6mm

3080-MN**
3080E-MN**

1-29/32"

48.4mm

4-1/2"

114.3mm

1-29/32"

48.4mm

3080-MI
3080E-MI

3-23/32"

94.5mm

8-3/32"

205.6mm

5"

127

mm

3080-MV**

4"

101.6mm

1-29/32"

48.4mm

3080-MJ
3080E-MJ

3080E-MV**

4-11/16"

119.1mm

8-3/32"

205.6mm

* The 3080-01, -02, and -03 lever handles are designed to return within 1/2" of the door face. Handles in the Designer Series do

not have this same feature. Please verify with local code requirements to ensure compliance.

** Handed

3-1/4"

82.6mm

8-3/32"

205.6mm

1-29/32"

48.4mm

4-3/16"

106.4mm

.120"

3.0mm

* ELECTRIFIED TRIM ONLY

ROTATION

LIMITING

PINS

MORTISE CYLINDER – 4036-01

• Standard diameter five-pin unit with MS cam, suitable

for use with entry trim. Available in quantity all keyed
different (KD), in pairs (KA2), or 50 alike (KA50). Any
other make standard mortise cylinder with MS® cam
can be used to key-in with existing systems.

CYLINDER CAM

• 3080 Series Entry Trim can accept

any standard 1-5/32" diameter mortise
cylinder with MS® cam dimensioned as

.800" ± .005"

“Dim A”

20.3mm ± .127mm

R

.182"

4.6mm

shown. Cylinders with MS® cams can
be readily obtained from most cylinder
manufacturers. See CYLINDERS for
cylinder make, thumbturn and trim
ring information.

©2014, Hanchett Entry Systems, Inc., an ASSA ABLOY Group company.
