Operating manual
Laser level
Model: CUBE 360
Manufacturer: ADAINSTRUMENTS Address: WWW.ADAINSTRUMENTS.COM
CUBE 360
Table of contents
1. Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Technical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. Safety requirements and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
4. Order working . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5. Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
6. Safety precaution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
8. Exceptions from responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Appendix 1- “Certificate of acceptance and sale”
Appendix 2- “Warranty card”
2
CUBE 360
vertical line
horizontal line
90°
1. CAUTIONS
Laser level ADA CUBE 360 model - is an up-to-date functional and multi-prism device designed for indoor and
outdoor performance. The device emits:
one horizontal laser line (beam scan angle of 360°)
one vertical laser line (beam scan angle of 110°);
down point laser.
Do not look at the laser beam!
Do not install the device on the eye level!
Before using the device, do read this operating manual!
2. TECHNICAL REQUIREMENTS
2.1. FUNCTIONAL DESCRIPTION
Emitting a horizontal and vertical laser line.
Quick self-leveling: when line accuracy is out of the range the laser line
flashes and the warning sound is produced. Compensator locking system
for safe transportation. Intermediate compensator locking system for slope operation.
Indoor and outdoor performance function.
3
2
CUBE 360
2.2. FEATURES
1. Laser lines on/off
2. Indoor/outdoor operating mode
3. Battery compartment
4. Tripod mount 1/4’’
5. Compensator switch
(ON/X/OFF)
6. Vertical laser window
7. Horizontal laser window
4
1
2
7
4
3
6
4
5
CUBE 360
2.3. SPECIFICATIONS
Laser Horizontal line 360°/vertical line
Light sources 2 laser diodes with laser emission wave length of 635 nm
Laser safety class Class 2, <1mW
Accuracy ±3 mm/10 m
Self-leveling range ±4°
Operating range with/without receiver 70/20 m
Power source 3 alkaline batteries, AA type
Operation time Approx. 15 hours, if everything is on
Tripod thread 2х1/4”
Operating temperature -5°C +45°C
Weight 390 g
5
CUBE 360
3. SAFETY REQUIREMENTS AND CARE
Follow safety requirements! Don’t face and stare at laser beam!
Laser level is an accurate Instrument, which should be stored and used with care.
Avoid shaking and vibrations! Store the Instrument and It’s accessories only In the carrying case.
In case of high humidity and low temperature, dry out the Instrument and clean It after the usage.
Do not store the Instrument at a temperature below -20°C and above 50°C, otherwise the Instrument can be
out of action.
Don’t put the Instrument Into the carrying case If the Instrument or case are wet. To avoid moisture condensation Inside the Instrument- dry out the case and laser Instrument!
Check regularly Instrument adjustment!
Keep the lens clean and dry. To clean the Instrument use a soft cotton napkin!
4. ORDER WORKING
Cube 360 is a reliable and convenient instrument. It will be irreplaceable instrument for many years.
1. Before use, remove battery compartment cover. Insert three batteries into battery compartment with proper
6
CUBE 360
polarity, the put the cover back.
2. Set the compensator locking grip 5 into ON position, two laser beams will be on.
If the switch is ON,that means the power is on and the compensator is working.
If the switch 5 is in intermediate position, that means the power is opened,the compensation is still locked, but it
will not warn if you issue the slope. It’s the hand-mode.
If the switch 5 is OFF, that means that the instrument is off, the compensator is also locked.
3. Press button 1 only once- horizontal beam will turn on. Press the button 1 one more time - vertical laser beam
will turn on. Again press the button 1 - horizontal and vertical beams will turn on.
4. Press button 2 once. Otdoor mode is activated. Press button 2 one more time. The instrument begins to work
in indoor mode.
7
CUBE 360
To check the accuracy of line laser level
To check the accuracy of line laser level (slope of plane)
Set up the instrument between two walls, the distance is 5m.Turn on the Line Laser, and mark the
point of cross laser line on the wall. Rotate the instrument by 180° and mark the
point of cross laser line on the wall again.
Set up the instrument 0,5-0,7m away from the wall and make, as
described above, the same masrks. If the difference {a1-b2} and
{b1-b2} is less then the value of “accuracy” (see spesifications),
there is no need in calibration.
Example: when you check the accuracy of Cross Line Laser the
difference is {a1-a2}=5 mm and {b1-b2}=7 mm. The
instrument’s error: {b1-b2}-{a1-a2}=7-5=2 mm. Now you can
compare this error with standard error.
If the accuracy of Laser level isn’t corresponding with
claimed accuracy, contact the authorized service center.
8
To check level
Choose a wall and set laser 5m away from the wall. Turn
on the laser and cross laser line is marked A on the wall.
Find another point M on the horizontal line, the distance is
around 2.5m. Swivel the laser, and another cross point of
cross laser line is marked B. Please note the distance of
B to A should be 5m.
Measure the distance between M to cross laser line.
To check plumb
Choose a wall and set laser 5m away from the wall. Hang a
plumb with the length 2.5 m on the wall. Turn on the laser
and make the vertical laser line meet the point of the plumb.
The accuracy of the line is in the range if the vertical line doesn’t
exceed (up or down) the accuracy that is shown in the
spesifications (e.g. ±3mm/10m). If the accuracy isn’t
corresponding with claimed accuracy, contact the authorized service center.
m
m
CUBE 360
9
5. APPLICATION
6. SAFETY PRECAUTION
10
CUBE 360
CUBE 360
CARE AND CLEANING
Please handle measuring instrument with care. Clean with soft cloth only after any use. If necessary damp cloth with some
water. If instrument is wet clean and dry it carefully. Pack it up only if it is perfectly dry. Transport in original container/case only.
Note: During transport On/Off compensator lock (5) must be set to position “OFF”. Disregard may lead to damage of compensator.
SPECIFIC REASONS FOR ERRONEOUS MEASURING RESULTS
Measurements through glass or plastic windows;
•
Dirty laser emitting window;
•
After instrument has been dropped or hit. Please check the accuracy.
•
Large fluctuation of temperature: if instrument will be used in cold areas after it has been stored in warm areas (or the
•
other way round) please wait some minutes before carrying out measurements.
ELECTROMAGNETIC ACCEPTABILITY (EMC)
It cannot be completely excluded that this instrument will disturb other instruments (e.g. navigation systems);
•
will be disturbed by other instruments (e.g. intensive electromagnetic radiation nearby industrial facilities or radio trans-
•
mitters).
11
