BluetoothModule
USER GUIDE
FCC ID: S6OBLUEFRUIT
The purpose of this manual is to explain the correct way to integrate module model number:
Bluefruit to the end product. It includes procedures that shall assist you to avoid unforeseen
problems.
This manual presents information that shows how module and OEM product, where module
integrated, complies with regulations in certain regions. Any modifications, not expressly
approved by the manufacturer could void the authority to operate in these regions.
Content
1 General
2 Labeling
3 Other Regulatory Notes for OEM
4 Antenna Specification
5 Separate Approval
6 Integration Instruction
7 FCC Regulatory Information and Notes.
1. General
This Bluetooth Module has to be installed and used in accordance with the
technical description/installation instructions provided by the manufacturer.
This radio module has been certified under FCC Part 15.247 for use in the United
States.
For detailed information concerning certification of this please contact the
authorized local distributor or the manufacturer.
The system may only be implemented in the configuration that was certified. Note that any
changes or modifications to this equipment not expressly approved by the manufacturer
could void the user’s authority to operate this equipment.
FCC RF Radiation Exposure Statement: This device complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This transceiver must not be co-located or
operating in conjunction with any other antenna, transmitter, or external amplifiers.
Unauthorized modification could void authority to use this equipment.
2. Labeling.
AdafruitIndustries BluetoothModule
Model number: Bluefruit
labeled as below.
NOTE: Host device must be labeled with:
FCC Regulatory Information. OEM device should contain labeling that:
Approved in accordance to FCC rules transmitter module marked by FCC ID:
S6OBLUEFRUIT, manufactured by CIXI INTEC ELECTRONIC CO., LTD. to OEM product.
When it’s not possible, user manual should include such information.
For example:
“This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.” This device contains FCC ID: S6OBLUEFRUIT.
Bluetooth Module, model number: Bluefruit can be incorporated into many different devices.
The modules generally consist of a completely self-contained
radiofrequency transceiver missing only a power source to make
it functional. Once the modules are authorized by the
Commission under our certification procedure, they may be
incorporated into a number of mobile devices.The completed
product generally is not subject to requirements for further
certification by the FCC.
3. Other regulatory notes for OEM.
Modular transmitters save manufacturers the time and any related expenses that would be
incurred if a new equipment authorization were needed for the same transmitter when it is
installed in a new device. This means that it can be integrated into end products without
further testing or approval listing. The manufacturer must state the CIXI INTEC ELECTRONIC
CO., LTD. part number and product reference in his literature in order to meet the module
requirements and regulatory. This should be clearly indicated in the OEM manuals.
The purchaser / integrator (developer) must satisfy all relevant FCC, SAR, EMC and Radio
regulations which apply to their finished product. We believe such parties have the technical
competence to ensure that the systems they deploy continue to comply with all those rules.
It is illegal to use amplifiers or higher gain antennas with this module. Maximum supply
voltage allowed is 3.7Vdc
4. Antenna Specification
Antenna Manufacturer:
Dimension: 11.85mm x 3.2mm
Center frequency 2452MHz
Antenna gain-2.215dBi max.
Impedance 50Ω VSWR 2max.
Temperature range
Operating 0°C to +40°C
Storage –40 to +70°C
5. Separate Approval.
A separate approval of the device into which the module is incorporated is only required
when it cannot be insured that the conditions on the module grant will be met. The
purchaser must satisfy all relevant FCC, EMC and Radio regulations R&TTE directive
which apply to their finished product.
CIXI INTEC ELECTRONIC CO., LTD.
6. Integration Instruction
7. FCC Regulatory Information.
Adherence to the following is required:
IMPORTANT: OEMs must test their final product to comply with unintentional radiators (FCC
section 15.107 and 15.109) before declaring compliance of their final product to Part 15 of
the FCC Rules.
