AcuRite 01123 Instruction Manual

OCT

Instruction Manual

Weather Station

model 01123

future forecast

OK

CONTENTS

Unpacking Instructions ........... 2

Package Contents .................. 2

Product Registration ............... 2

Features & Benets: Sensor...... 2

Features & Benets: Display ..... 3

Setup .................................... 5

Sensor Setup ......................... 5

Display Setup ........................ 6

Set the Time, Date & Units ...... 7

Backlight Settings ................... 7

Placement Guidelines ............. 8

Using the Weather Station...... 9

Troubleshooting ....................10

Care & Maintenance............. 11

Calibration ...........................11

Specications........................ 11

FCC Information ...................12

Customer Support .................12

Warranty..............................12

Questions? Contact Customer Support at

www.AcuRite.com/support or email support@chaney-inst.com

SAVE THIS MANUAL FOR FUTURE REFERENCE.

Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety

and retain it for future reference.

Unpacking Instructions

Remove the protective lm that is applied to the LCD screen prior to using this product. Locate the tab and peel off to remove.

Package Contents

1. Display with Fold-Out Stand

2. Outdoor Sensor

3. Instruction Manual

4. Power Adapter

PRODUCT MUST BE REGISTERED

IMPORTANT

TO RECEIVE WARRANTY SERVICE

PRODUCT REGISTRATION

Register online to receive 1 year of warranty protection

www.AcuRite.com

Features & Benets

1

2

5

3

4

OUTDOOR SENSOR

1. Integrated Hanger

For easy placement.

2. Wireless Signal Indicator

Flashes when data is being sent to the display.

3. Battery Compartment

4. A-B-C Switch

ID code that must match display’s A-B-C switch to ensure units synchronize.

5. Battery Compartment Cover

2

Features & Benets

17

16

15

1

2

3

4

nrT

UL I

5

-------22

~

1, 1, 1, 1, 1, 1, I J

future forecast

6 7 8 9 10

FRONT OF DISPLAY

1. Current Outdoor Temperature

Arrow icon indicates the direction

temperature is trending.

2. Low Record Indicator

Indicates today's low records are being viewed.

3. Current Outdoor Humidity

Arrow icon indicates the direction humidity is trending.

4. Sensor Low Battery Indicator

5. Date

6. Clock

7. and OK Button

0

For setup preferences.

/\. V

8. and Buttons

For setup preferences and viewing

high & low records.

9. Button

For momentary backlight and dimmer

settings.

10. Display Low Battery Indicator

*

OK

11. Current Barometric Pressure

Displays current barometric pressure and indicates whether pressure is rising

or falling.

12. Current Indoor Humidity

Arrow icon indicates the direction humidity is trending.

13. High Record Indicator

Indicates today's high records are being viewed.

14. Current Indoor Temperature

Arrow icon indicates the direction

temperature is trending.

15.

Icon

AUTO

Indicates display is in auto-dimming brightness mode (see page 7).

16. 12 to 24 Hour Weather Forecast

Self-calibrating forecasting pulls data from the outdoor sensor to generate your personal forecast.

17. Outdoor Sensor Signal Strength

14 13

12

11

3

Features & Benets

•

1

4

-

L

Ir

7

-

---

-

6

3

5

2

BACK OF DISPLAY

1. Integrated Hang Hole

For easy wall mounting.

2. RESET Button

For full reset to factory defaults.

3. Backup Battery Compartment

4. Fold-out Tabletop Stand

5. Power Adapter

6. Plug-in for Power Adapter

7. A-B-C Switch

ID code that must match sensor’s A-B-C switch to ensure units synchronize.

8. Battery Compartment Cover

(not shown)

4
