Acu-Rite 00891A User Manual
Instruction Manual
Thermometer with Probe
model 00891A
CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Product Registration ............... 2
Features & Benets ................. 3
Setup .................................... 4
Temperature Units .................. 4
Placement Guidelines ............. 4
Troubleshooting ..................... 5
Specications ......................... 5
FCC Information .................... 6
Customer Support .................. 6
Warranty............................... 7
Questions? Contact Customer Support at
(877) 221-1252 or visit www.AcuRite.com.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Congratulations on your new AcuRite product. To ensure the best
possible product performance, please read this manual in its entirety
and retain it for future reference.
Unpacking Instructions
Remove the protective lm that is applied to the LCD screen prior to using this
product. Locate the tab and peel off to remove.
Package Contents
1. Display unit
2. Probe Temperature Sensor
3. Instruction Manual
IMPORTANT
PRODUCT REGISTRATION
Register online
to receive 1 year
warranty protection
www.AcuRite.com
PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE
Register a Product
►
2
Features & Benets
1
2
3
14
15
4
13
5 12
6 11
8 109
7
FRONT
1. Current Time/Indoor Temperature
Displays current time or current indoor
(display) temperature.
2. Current Temperature
Displays current outdoor (probe)
temperature.
3. Current Indoor Humidity
4. MAX/MIN TEMP Button
Displays high & low records.
5. HR Button
Setup hours.
6. MIN Button
Setup minutes.
7. Probe Temperature Sensor
8. 24HR / 12HR Switch
Slide to change between 12-hour and
24-hour clock (#1).
9. Momentary Backlight Button
10. LOCK/TIME SET Switch
Slide to lock clock settings or set time.
16
17
11. TEMP/CLOCK Button
Toggle between current time or current
indoor (display) temperature (#1).
12. CLEAR Button
Press to clear high & low records.
13. MAX/MIN HUMIDITY Button
Displays high & low records.
BACK
14. Battery Compartment
15. Integrated Hang Hole
for easy placement.
16. °F/°C Switch
Slide to select °F or °C temperature units.
17. Fold-out Tabletop Stand
3
