Acura RL 2009 User Manual

2009 RL

Owner’s Manual

(Unlinked)

This document does not contain hyperlinks and may be formatted for printing instead of web use. This is due to changes in content and specifications of the vehicle that happen throughout the model year. This manual will be replaced with a hyperlinked version at the end of the model year.

Owner’s Identif ication

OWNER

ADDRESS

STREET

CITY STATE/PROVINCE ZIP CODE/

POSTAL CODE

V. I. N.

DELIVERY DATE

(Date sold to original retail purchaser)

DEALER NAME DEALER NO.

ADDRESS

STREET

CITY STATE/PROVINCE ZIP CODE/

POSTAL CODE

OWNER’S SIGNATURE

DEALER’S SIGNATURE

This owner’s manual should be considered a permanent part of the vehicle and should remain with the vehicle when it is sold.

This owner’s manual covers all models of the Acura RL. You may find descriptions of equipment and features that are not on your particular model.

The information and specifications included in this publication were in effect at the time of approval for printing. Honda Motor Co., Ltd. reserves the right, however, to discontinue or change specifications or design at any time without notice and without incurring any obligation whatsoever.

Introduction

Congratulations on your selection of the 2009 Acura RL. We are certain you will be pleased with your purchase of one of the finest luxury vehicles in the world.

One of the best ways to enhance the enjoyment of your new vehicle is to read this manual. In it, you will learn how to operate its driving controls and convenience items. Afterwards, keep this owner’s manual in your vehicle so youcanrefertoitatanytime.

Several warranties protect your new vehicle. Read the warranty booklet thoroughly so you understand the coverages and are aware of your rights and responsibilities.

Maintaining your vehicle according to the maintenance minder shown in the instrument panel helps to keep your driving trouble-free while it preserves your investment. When your vehicle needs maintenance, keep in mind that your dealer’s staff is specially trained in servicing the many systems unique to your vehicle. Your dealer is dedicated to your satisfaction and will be pleased to answer any questions and concerns.

As you read this manual, you will find information that is preceded by a symbol. This information is intended to help you avoid damage to your vehicle, other property, or the environment.

Introduction

California Proposition 65 Warning

WARNING:

defects or other reproductive harm.

Event Data Recorders

This vehicle is equipped with one or more devices commonly referred to as event data recorders. These devices record f ront seat belt use, front passenger seat occupancy, airbag deployment data, and the failure of any airbag system component.

except as legally required or with the permission of the vehicle owner.

Service Diagnostic Recorders This vehicle is equipped with service-related devices that record information about powertrain performance. The data can be used to verify emissions law requirements and/or help technicians diagnose and solve service problems. It may also be combined with data from other sources for research purposes, but it remains confidential.

This product contains or emits chemicals known to the State of California to cause cancer and birth

This data belongs to the vehicle owner and may not be accessed by anyone else

AFewWordsAboutSafety

Your safety, and the safety of others, is very important. And operating this vehicle safely is an important responsibility.

To help you make informed decisions about safety, we have provided operating procedures and other information on labels and in this manual. This information alerts you to potential hazards that could hurt you or others.

Of course, it is not practical or possible to warn you about all the hazards associated with operating or maintaining your vehicle. You must use your own good judgement.

You will find this important safety information in a variety of forms, including:

−

Safety Labels Safety Messages

three signal words: , , or . These signal words mean:

Safety Headings

Safety Precautions.

Safety Section Instructions

This entire book is filled with important safety information please read it carefully.

on the vehicle.

−

preceded by a safety alert symbol and one of

DANGER WARNING CAUTION

You WILL be KILLED or SERIOUSLY HURT if you don’t follow instructions.

You CAN be KILLED or SERIOUSLY HURT if you don’t follow instructions.

You CAN be HURT if you don’t follow instructions.

−

such as Important Safety Reminders or Important

−

such as Driver and Passenger Safety.

−

how to use this vehicle correctly and safely.

−

iii

Contents

(main controls)

(seat belts, SRS, and child protection)

(indicators, gauges, multi-information display, dashboard, and steering column)

climate control, audio, steering wheel, security, cruise control, HomeLink , and other convenience items

( )

(fuel, vehicle break-in, and cargo loading)

(engine and transmission operation)

(minders, fluid checking, minor services, and vehicle storage)

(flat tire, dead battery, overheating, fuses)

(vehicle specifications, tires, and emissions controls)

(how to order)

................................................................................................................................................Index .I

(fluid capacities and tire pressures)

...............................................................................................Your Vehicle at a Glance .4

............................................................Driver and Passenger Safety .7

.......Instruments and Controls .59

..............Features . 203

.......................................................................Before Driving . 375

.........................................................................................Driving . 393

...............................................Maintenance . 435

...............................................Taking Care of the Unexpected . 485

.............................................Technical Inf ormation . 513

(warranty and contact information)

..................................................................................Authorized Manuals (U.S. only) . 533

..................................................Service Information Summary . last page

.......................Warranty and Client Relations (U.S. and Canada only) . 529

INDEX

Overview of Contents

A convenient reference to the sections in this manual.

Your Vehicle at a Glance

A quick reference to the main controls in your vehicle.

Driver and Passenger Safety

Important information about the proper use and care of your vehicle’s seat belts, an overview of the supplemental restraint system, and valuable information on how to protect children with child restraints.

Instruments and Controls

Explains the purpose of each instrument panel indicator and gauge, and how to use the controls on the dashboard and steering column.

Features

How to operate the climate control system, the audio system, and other convenience features.

Before Driving

What gasoline to use, how to breakin your new vehicle, and how to load luggage and other cargo.

Driving

The proper way to start the engine, shift the transmission, and park; plus what you need to know if you’re planning to tow a trailer.

Maintenance

The maintenance minder shows you when you need to take your vehicle to the dealer for maintenance service. There is also a list of things to check and instructions on how to check them.

Taking Care of the Unexpected

This section covers several problems motorists sometimes experience, and details how to handle them.

Technical InformationContents

ID numbers, dimensions, capacities, and technical information.

Warranty and Client Relations (U.S. and Canada only)

A summary of the warranties covering your new vehicle, and how to contact us for any reason. Refer to your warranty manual for detailed information.

Authorized Manuals (U.S. only)

How to order manuals and other technical literature.

Index

Service Information Summary

A summary of the information you need when you pull up to the fuel pump.

Your Vehicle at a Glance

DRIVER’S FRONT

DRIVING POSITION

AIRBAG

MEMORY SYSTEM (P.163)

POWER DOOR LOCK MASTER SWITCH (P.153)

POWER WINDOW SWITCHES (P.185)

TRUNK RELEASE BUTTON (P.154) FUEL FILL DOOR RELEASE BUTTON (P.377)

＊

1: HOMELINK MOONROOF SWITCH

BUTTONS

(P.334)

(P.188) POWER REAR SUNSHADE BUTTON

(P.198) REAR HEAD RESTRAINT TILT BUTTON

＊＊ Canadian models only

RL models2:

(P.158)

INSTRUMENT PANEL

(P.11, 26)

INDICATORS

HOOD RELEASE LEVER (P.379)

(P.62)

REAR SEAT HEATER SWITCHES (P.184)

CONSOLE

＊

CEILING

＊

MIRROR CONTROL AUTO BUTTON (P.161)

PASSENGER’S FRONT AIRBAG (P.11, 26)

USB ADAPTER CABLE (P.259)

CLIMATE CONTROL SYSTEM (P.204)

AUDIO SYSTEM (P.213)

INTERFACE DIAL (P.205, 213, 282) COMPASS SYSTEM (P.281)

AUTOMATIC TRANSMISSION (P.397)

ACCESSORY POWER SOCKETS (P.197)

AUXILIARY INPUT JACK

(P.277)

＊

Your Vehicle at a Glance

PADDLE SHIFTERS (P.401)

HEADLIGHTS/ TURN SIGNAL/ FOG LIGHTS (P.140, 142)

COLLISION MITIGATION BRAKE SYSTEM (CMBS) OFF SWITCH

＊

(P.414)

VEHICLE STABILITY ASSIST (VSA) SYSTEM OFF SWITCH (P.428)

ADAPTIVE FRONT LIGHTING SYSTEM (AFS) OFF SWITCH (P.145)

HEADLIGHT WASHER SWITCH

＊

(P.138)

MIRROR CONTROLS (P.161)

STEERING WHEEL ADJUSTMENTS

＊＊＊＊

To use the horn, press the center pad of the steering wheel.

If equipped.

2: 3:4:Canadian models only

Refer to the navigation system manual.

(P.148)

INSTRUMENT PANEL BRIGHTNESS (P.146)

＊

STEERING WHEEL AUDIO CONTROLS

(P.278)

WINDSHIELD WIPER/WASHER (P.137)

BLUETOOTH HANDSFREELINK BUTTONS

(P.356)

HAZARD WARNING BUTTON (P.146)

＊

HORN

DISTANCE BUTTON

＊

(P.328, 333)

VOICE CONTROL BUTTONS (P.304)

PASSENGER AIRBAG

Your Vehicle at a Glance

OFF INDICATOR (P.35)

REAR WINDOW DEFOGGER BUTTON (P.147)/ HEATED MIRROR BUTTON

(P.162)

CRUISE CONTROL BUTTONS

(P.316)/ ADAPTIVE CRUISE CONTROL (ACC) BUTTONS

＊

(P.319, 324)

MULTI-INFORMATION BUTTONS

(P.71)

FRONT SEAT HEATER SWITCHES

(P.181)/ FRONT SEAT HEATER AND SEAT

＊

VENTILATION BUTTONS

＊

(P.182)

Driver and Passenger Safety

This section gives you important information about how to protect yourself and your passengers. It shows you how to use seat belts. It explains how your airbags work. And it tells you how to properly restrain infants and children in your vehicle.

.........Important Safety Precautions . 8

.......Your Vehicle’s Safety Features . 9

.........Protecting Adults and Teens . 13

.....1. Close and Lock the Doors . 13

...........2. Adjust the Front Seats . 15

............3. Adjust the Seat-Backs . 16

...4. Adjust the Head Restraints . 16

5. Fasten and Position the Seat

.....................................Belts . 17

6. Maintain a Proper Sitting

................................Position . 19

.....Advice for Pregnant Women . 19

...Additional Safety Precautions . 20

Additional Information About

.......................Your Seat Belts . 21

..Seat Belt System Components . 21

......................Lap/Shoulder Belt . 22

Automatic Seat Belt

...............................Tensioners . 23

...........Seat Belt e-pretensioners . 24

...............Seat Belt Maintenance . 25

Additional Information About

...........................Your Airbags . 26

How Your Front Airbags

.........................................Work . 29

How Your Side Curtain

..........................Airbags Work . 34

How the Side Airbag Off

......................Indicator Works . 35

How the Passenger Airbag

...............Off Indicator Works . 35

.............................Airbag Service . 36

Protecting Children General

All Children Must Be

All Children Should Sit in a

−

................................Guidelines . 38

...............................Restrained . 38

.................................Back Seat . 39

......Airbag System Components . 26

...How Your Side Airbags Work . 32

..How the SRS Indicator Works . 34

...Additional Safety Precautions . 37

The Passenger’s Front Airbag

If You Must Drive with Several

...................................Children . 41

If a Child Requires Close

..................................Attention . 41

Protecting Infants and Small

...................................Children . 43

.......................Protecting Infants . 43

.....................Selecting a Child Seat . 45

....................Installing a Child Seat . 46

...............................With LATCH . 47

..............................With a Tether . 51

...............Checking Seat Belt Fit . 52

..................Using a Booster Seat . 53

When Can a Larger Child Sit in

.........................................Front . 54

.............Carbon Monoxide Hazard . 56

...................................Safety Labels . 57

.........Can Pose Serious Risks . 39

Driver and Passenger Saf ety

...Additional Safety Precautions . 41

.........Protecting Small Children . 44

.........With a Lap/Shoulder Belt . 49

...........Protecting Larger Children . 52

...Additional Safety Precautions . 55

Important Saf ety Precautions

recommendations throughout this section, and throughout this manual. Therecommendationsonthispage are the ones we consider to be the most important.

Always Wear Your Seat Belt

A seat belt is your best protection in all types of collisions. Airbags are designed to supplement seat belts, not replace them. So even though your vehicle is equipped with airbags, make sure you and your passengers always wear your seat belts, and wear them properly (see page ).

Restrain All Children

Children age 12 and under should ride properly restrained in a back seat, not the front seat. Infants and smallchildrenshouldberestrained in a child seat. Larger children should use a booster seat and a lap/ shoulder belt until they can use the belt properly without a booster seat

(see pages ).

Be Aware of Airbag Hazards

While airbags can save lives, they can cause serious or fatal injuries to occupants who sit too close to them, or are not properly restrained. Infants, young children, and short adults are at the greatest risk. Be sure to follow all instructions and warnings in this manual.

Don’t Drink and Drive

Alcohol and driving don’t mix. Even one drink can reduce your ability to respond to changing conditions, and your reaction time gets worse with every additional drink. So don’t drink and drive, and don’t let your friends drink and drive, either.

−You’ll find many safety

5538

Control Your Speed

Excessive speed is a major factor in crash injuries and deaths. Generally, the higher the speed, the greater the risk, but serious injuries can also occur at lower speeds. Never drive faster than is safe for current conditions, regardless of the maximum speed posted.

Keep Your Vehicle in Safe Condition

Having a tire blowout or a mechanical failure can be extremely hazardous. To reduce the possibility of such problems, check your tire pressures and condition frequently, and perform all regularly scheduled maintenance (see page ).

437

(10)

(8)

(9)

(3)

(4)

(6)

(9)

Your Vehicle’s Safety Features

Your vehicle is equipped with many features that work together to protect you and your passengers during a crash.

Driver and Passenger Saf ety

(1)

(7)

＊

: On model with Collision Mitigation

Brake System (CMBS)

(2)

(6)

(8)

(7)

(11)

(5)

(1) Safety Cage (2) Crush Zones (3) Seats and Seat-Backs (4) Head Restraints (5) Collapsible Steering Column (6) Seat Belts (7) Front Airbags (8) Side Airbags (9) Side Curtain Airbags (10) Door Locks (11) Front Seat Belt Tensioners/

Seat Belt e-pretensioners

(2)

Some features do not require any action on your part. These include a strong steel framework that forms a safety cage around the passenger compartment; front and rear crush zones; a collapsible steering column; and tensioners that tighten the front seat belts in a crash.

However, you and your passengers can’t take full advantage of these features unless you remain sitting in a proper position and

your seat belts

features can contribute to injuries if they are not used properly.

The following pages explain how you cantakeanactiveroleinprotecting

＊

yourself and your passengers.

. In fact, some safety

always wear

Your Vehicle’s Safety Features

Seat Belts

Your vehicle is equipped with seat belts in all seating positions.

Your seat belt system also includes an indicator on the instrument panel and a beeper to remind you and your passengers to fasten your seat belts.

Why Wear Seat Belts

Seat belts are the single most effectivesafetydeviceforadultsand larger children. (Infants and smaller children must be properly restrained in child seats.)

Not wearing a seat belt properly increases the chance of serious injury or death in a crash, even though your vehicle has airbags.

In addition, most states and all Canadian provinces require you to wear seat belts.

Not wearing a seat belt properly increases the chance of serious injury or death in a crash, even though your vehicle has airbags.

Be sure you and your passengers always wear seat belts and wear them properly.

When properly worn, seat belts:

Keep you connected to the vehicle so you can take advantage of the vehicle’s built-in safety features.

Help protect you in almost every type of crash, including:

−

frontal impacts

−

side impacts

−

rear impacts

−

rollovers

Help keep you from being thrown against the inside of the vehicle and against other occupants.

Keep you from being thrown out of the vehicle.

Help keep you in a good position should the airbags ever deploy. A good position reduces the risk of injury from an inflating airbag and allows you to get the best advantage from the airbag.

Of course, seat belts cannot completely protect you in every crash.Butinmostcases,seatbelts can reduce your risk of serious injury.

What You Should Do:

Always wear your seat belt, and make sure you wear it properly.

Airbags

Your Vehicle’s Safety Features

Driver and Passenger Saf ety

Your vehicle has a supplemental restraint system (SRS) with front airbags to help protect the heads and chests of the driver and a front seat passenger during a moderate to severe frontal collision (see page

for more information on how

your front airbags work).

Your vehicle also has side airbags to help protect the upper torso of the driver or a front seat passenger during a moderate to severe side impact (see page for more information on how your side airbags work).

In addition, your vehicle has side curtain airbags to help protect the heads of the driver, front passenger, and passengers in the outer rear seating positions during a moderate to severe side impact (see page

for more information on how

your side curtain airbags work).

CONTINUED

Your Vehicle’s Safety Features

The most important things you need to know about your airbags are:

Airbags do not replace seat belts.

They are designed to supplement the seat belts.

Airbags of f er no protection in rear impacts, or minor f rontal or side collisions.

Airbags can pose serious hazards.

To do their job, airbags must inflate with tremendous force. So while airbags help save lives, they can cause minor injuries or more serious or even fatal injuries if occupants are not properly restrained or sitting properly.

What you should do:

your seat belt properly, and sit upright and as far back from the steering wheel as possible while allowing full control of the vehicle. A front passenger should move their seat as far back from the dashboard as possible.

Always wear

The rest of this section gives more detailed information about how you can maximize your safety.

Remember, however, that no safety system can prevent all injuries or deaths that can occur in a severe crash, even when seat belts are properly worn and the airbags deploy.

Protecting Adults and Teens

Introduction

The following pages provide instructions on how to properly protect the driver, adult passengers, and teenage children who are large enough and mature enough to drive or ride in the front.

See pages for important guidelines on how to properly protect infants, small children, and larger children who ride in your vehicle.

Close and Lock the Doors1.

After everyone has entered the vehicle, be sure the doors are closed and locked.

Your vehicle has a programmable auto door locking/unlocking feature. For more information, see page .

−

123

Your vehicle has a door and trunk open indicators on the multiinformation display to indicate when a specific door or the trunk is not tightly closed. You will see the appropriate indicator(s) and the message for each condition.

You will also hear a beep when you turn the ignition switch to the ON (II) position, and each time you open any door or the trunk with the key in the ON (II) position.

Driver and Passenger Saf ety

When one or more doors are not tightly closed, the ‘‘DOOR OPEN’’ indicator will come on.

CONTINUED

Protecting Adults and Teens

Locking the doors reduces the chance of someone being thrown out of the vehicle during a crash, and it helps prevent passengers from accidentally opening a door and falling out.

Locking the doors also helps prevent an outsider from unexpectedly opening a door when you come to a stop.

the ‘‘TRUNK OPEN’’ indicator will come on.

When one or more doors and the trunk lid are not tightly closed, the corresponding indicator for each condition and the ‘‘DOOR & TRUNK OPEN’’ indicator will come on.

See page for how to lock the doors.When the trunk is not tightly closed,

153

Protecting Adults and Teens

Adjust the Front Seats2.

Adjust the driver’s seat as far to the rear as possible while allowing you to maintain full control of the vehicle. Have a front passenger adjust their seat as far to the rear as possible.

If you sit too close to the steering wheel or dashboard, you can be seriously injured by an inflating front airbag, or by striking the steering wheel or dashboard.

The National Highway Traffic Safety Administration and Transport Canada recommend that drivers allow at least 10 inches (25 cm) between the center of the steering wheel and the chest. In addition to adjusting the seat, you can adjust the steering wheel up and down, and in and out (see page ).

If you cannot get far enough away from the steering wheel and still reach the controls, we recommend that you investigate whether some type of adaptive equipment may help.

148

Sitting too close to a front airbag can result in serious injury or death if the front airbags inflate.

Always sit as far back from the front airbags as possible.

See page for how to adjust the front seats.

156

Driver and Passenger Saf ety

Protecting Adults and Teens

Adjust the driver’s seat-back to a comfortable, upright position, leaving ample space between your chest and the airbag cover in the center of the steering wheel.

Passengers with adjustable seatbacks should also adjust their seatback to a comfortable, upright position.

Reclining the seat-back too far can result in serious injury or death in a crash.

Adjust the seat-back to an upright position, and sit well back in the seat.

Reclining a seat-back so that the shoulder part of the belt no longer rests against the occupant’s chest reduces the protective capability of the belt. It also increases the chance of sliding under the belt in a crash and being seriously injured. The farther a seat-back is reclined, the greater the risk of injury.

See page for how to adjust the seat-backs.

156

Adjust the Head RestraintsAdjust the Seat-Backs 4.3.

Adjust the driver’s head restraint so the center of the back of your head rests against the center of the restraint.

Have passengers with adjustable head restraints adjust their restraints properly as well. Taller persons should adjust their restraint as high as possible.

Improperly positioning head restraints reduces their effectiveness and you can be seriously injured in a crash.

Make sure head restraints are in place and positioned properly before driving.

Properly adjusted head restraints will help protect occupants from whiplash and other crash injuries.

See page for how to adjust the head restraints and how the driver’s and front passenger’s active head restraints work.

157

Fasten and Position the Seat

5. Belts

Insert the latch plate into the buckle, then tug on the belt to make sure the belt is securely latched. Check that the belt is not twisted, because a twisted belt can cause serious injuries in a crash.

Protecting Adults and Teens

Driver and Passenger Saf ety

Position the lap part of the belt as low as possible across your hips, then pull up on the shoulder part of the belt so the lap part fits snugly. This lets your strong pelvic bones take the force of a crash and reduces the chance of internal injuries.

If necessary, pull up on the belt again to remove any slack, then check that the belt rests across the center of your chest and over your shoulder.

CONTINUED

Protecting Adults and Teens

This spreads the forces of a crash over the strongest bones in your upper body.

Improperly positioning the seat belts can cause serious injury or death in a crash.

Make sure all seat belts are properly positioned before driving.

If the seat belt touches or crosses your neck, or if it crosses your arm instead of your shoulder, you need to adjust the seat belt anchor height.

RELEASE BUTTON

The front seats have adjustable seat belt anchors. To adjust the height of an anchor, press and hold the release buttons, and slide the anchor up or down as needed (it has four positions).

Never place the shoulder portion of a lap/shoulder belt under your arm or behind your back.

This could cause

very serious injuries in a crash.

If a seat belt does not seem to work properly, it may not protect the occupant in a crash.

No one should sit in a seat with an inoperative seat belt.

Using a seat belt that is not working properly can result in serious injury or death. Have your dealer check the belt as soon as possible.

See page for additional

21 information about your seat belts and how to take care of them.

Protecting Adults and Teens

6. Position

After all occupants have adjusted their seats and head restraints, and put on their seat belts, it is very important that they continue to sit upright, well back in their seats, with their feet on the floor, until the vehicle is parked and the engine is off.

Sitting improperly can increase the chance of injury during a crash. For example, if an occupant slouches, lies down, turns sideways, sits forward, leans forward or sideways, or puts one or both feet up, the chance of injury during a crash is greatly increased.

In addition, an occupant who is out of position in the front seat can be seriously or fatally injured in a crash by striking interior parts of the vehicle or being struck by an inflating front airbag.

Sitting improperly or out of position can result in serious injury or death in a crash.

Always sit upright, well back in the seat, with your feet on the floor.

Advice for Pregnant WomenMaintain a Proper Sitting

Driver and Passenger Saf ety

If you are pregnant, the best way to protect yourself and your unborn child when driving or riding in a vehicle is to always wear a seat belt, and keep the lap part of the belt as low as possible across the hips.

CONTINUED

Protecting Adults and Teens

When driving, remember to sit upright and adjust the seat as far back as possible while allowing full control of the vehicle. When riding as a front passenger, adjust the seat as far back as possible.

This will reduce the risk of injuries to both you and your unborn child that can be caused by a crash or an inflating front airbag.

Each time you have a checkup, ask your doctor if it’s okay for you to drive.

Additional Safety Precautions

Two people should never use the same seat belt.

If they do, they could be very seriously injured in a crash.

Do not put any accessories on seat belts.

Devices intended to improve occupant comfort or reposition the shoulder part of a seat belt can reduce the protective capability of thebeltandincreasethechanceof serious injury in a crash.

Do not place hard or sharp objects between yourself and a front airbag.

Carrying hard or sharp objects on your lap, or driving with a pipe or other sharp object in your mouth, can result in injuries if your front airbag inflates.

Keep your hands and arms away from the airbag covers.

If your hands or arms are close to an airbag cover, they could be injured if the airbag inflates.

Do not attach or place objects on the f ront airbag covers.

Objects on the covers marked ‘‘SRS AIRBAG’’ could interfere with the proper operation of the airbags or be propelled inside the vehicle and hurt someone if the airbags inflate.

Do not attach hard objects on or near a door.

If a side airbag or a side curtain airbag inflates, a cup holder or other hard object attached on or near the door could be propelled inside the vehicle and hurt someone.

Additional Information About Your Seat Belts

Seat Belt System Components

Your seat belt system includes lap/ shoulder belts in all seating positions. The front seat belts are also equipped with automatic seat belt tensioners and, on models with collision mitigation brake system (CMBS), seat belt e-pretensioners.

This system uses the same sensors as the front airbags to monitor whether the front seat belts are latched or unlatched, and how much weight is on the front passenger’s seat (see pages and ).

31 32

The seat belt system

includes an indicator on the instrument panel and a beeper to remind you and your passengers to fasten your seat belts.

This system monitors the front seat belts. If you turn the ignition switch to the ON (II) position before your seat belt is fastened, the beeper will sound and the indicator will flash. If your seat belt is not fastened before the beeper stops, the indicator will stop flashing but remain on.

If a front passenger does not fasten their seat belt, the indicator will come on about 6 seconds after the ignition switch is turned to the ON (II) position.

If either the driver or a front passenger does not fasten their seat belt while driving, the beeper will sound and the indicator will flash again at regular intervals.

You will also see a ‘‘FASTEN SEAT BELT’’ or ‘‘FASTEN PASSENGER SEAT BELT’’ message on the multiinformation display (see page ).

When no one is sitting in the front passenger’s seat, or a child or small adult is riding there, the indicator should not come on and the beeper should not sound.

CONTINUED

Driver and Passenger Saf ety

Additional Information About Your Seat Belts

If the indicator comes on or the beeper sounds when the driver’s seat belt is latched and there is no front seat passenger and no items on the front seat, something may be interfering with the monitoring system. Look for and remove:

Any items under the front passenger’s seat.

Any object(s) hanging on the seat or in the seat-back pocket.

Any object(s) touching the rear of the seat-back.

If no obstructions are found, have your vehicle checked by a dealer.

Lap/Shoulder Belt

The lap/shoulder belt goes over your shoulder, across your chest, and across your hips.

To fasten the belt, insert the latch plate into the buckle, then tug on the belt to make sure the buckle is latched (see page for how to properly position the belt).

To unlock the belt, press the red PRESSbuttononthebuckle.Guide the belt across your body so that it retracts completely. After exiting the vehicle, be sure the belt is out of the way and will not get closed in the door.

All seat belts have an emergency locking retractor. In normal driving, the retractor lets you move freely in your seat while it keeps some tension on the belt. During a collision or sudden stop, the retractor automatically locks the belt to help restrain your body.

Additional Information About Your Seat Belts

The seat belts in all positions except the driver’s have a lockable retractor that must be activated to secure a child seat (see page ).

If the shoulder part of the belt is pulled all the way out, the lockable retractor will activate. The belt will retract, but it will not allow the passenger to move freely.

To deactivate the lockable retractor, unlatch the buckle and let the seat belt fully retract. To refasten the seat belt, pull it out only as far as needed.

Automatic Seat Belt Tensioners

For added protection, the front seat belts are equipped with automatic seat belt tensioners. When activated, the tensioners immediately tighten the belts to help hold the driver and a front passenger in position.

The tensioners are designed to activate in any collision severe enough to cause the front airbags to deploy.

If a side curtain airbag deploys during a side impact, the tensioner on that side of the vehicle will also deploy.

The tensioners can also be activated during a collision in which the front airbags . In this case, the airbags would not be needed, but the additional restraint could be helpful.

When the tensioners are activated, the seat belts will remain tight until they are unbuckled.

do not deploy

Driver and Passenger Saf ety

Additional Information About Your Seat Belts

Seat Belt e-pretensioners

On models with Collision Mitigation Brake System

For added safety, the front seat belts are equipped with e-pretensioners that work in combination with the collision mitigation brake system (CMBS) (see page ) and the brake pedal assist function (see page

408

411

If your vehicle gets too close to the vehicle ahead of it in your lane, the driver’s e-pretensioner slightly retracts the seat belt to alert the driver of the approaching vehicle. If a collision with the vehicle in front of you is likely, the e-pretensioners on both front seats retract the seat belts with enough force to properly restrain you and your front passenger. After they activate, the e-pretensioners release the retracted seat belts.

To get the full benefit of the e-pretensioners, you and your front passenger must sit normally in your seats and wear your seat belts properly (see page ).

The e-pretensioners do not activate when the seat belts are not worn or when the vehicle stability assist (VSA) off indicator on the instrument panel is on.

If the automatic seat belt tensioners are activated by a collision, both front seat belts and all related components must be replaced (see page ). If only the e-pretensioners were activated, no components need to be replaced.

In addition, the front passenger’s e-pretensioner does not activate when the passenger’s airbag is automatically turned off because the weight sensor detects a child in the front passenger’s seat.

+ 524 hidden pages
