Acura AcuBrite 15 PNL User Manual

ACUBRITE ™

Preface
Copyright

15-PNL

High Bright Rugged

Touch Screen

The material in this document is the intellectual property
of Acura Embedded Systems Inc. This publication,
including all photographs, illustrations and software, is
protected under international copyright laws, with all
rights reserved. Neither this manual, nor any of the
material contained herein, may be reproduced without
written consent of Acura Embedded Systems Inc.

Version 2.0

Warranty

The Acubrite™ is protected by a standard limited

warranty.

Trademark Recognition

Microsoft, MS-DOS and Windows are registered
trademarks of Microsoft Corp.

IBM PC is a registered trademark of International
Business Machines Corporation.

Intel, MMX, Pentium, Pentium-II, Pentium-III, Pentium-4,
Celeron are registered trademarks of Intel Corporation.

AWARD is a registered trademark of AWARD
International Inc.

Other product names used in this manual are the
properties of their respective owners and are
acknowledged.

ACUBRITE™ 15-PNL Manual ACUBRITE™ 15-PNL Manual

Disclaimer

Acura Embedded Systems Inc. takes every care in the
preparation of this document, but no guarantee is given as
to the correctness of its contents. Our products are under
continual improvement and we reserve the right to make
changes without notice. The manufacturer makes no
representations or warranties with respect to the contents
hereof and specifically disclaim any implied warranties of
merchantability or fitness for any particular purpose. The
manufacturer reserves the right to revise this publication
and to make changes from time to time in the content
hereof without obligation of the manufacturer to notify any
person of such revision or changes.

In general, the manufacturer will not be liable for loss
of data or other direct, indirect, special, incidental or
consequential damages arising from the use or inability
to use the product or documentation, even if advised of
the possibility of such damages.

Content

Introduction................................................................................1

Hardware Installation............….................................................1

The Display Timing.........……....................................................4

The Display Outline Dimensions…............................................5

The Display Controls.....................................….........................6

The Screen Adjustment.............................….........................…8

Installing TouchKit …....................................…........................9

ACUBRITE™ 15-PNL Manual ACUBRI E

Introduction

T ™ 15-PNL Manual

 Cable (VGA, USB, Serial)

Welcome to enjoy the fantastic sightseeing world. This new
technology will bring you the whole new feeling about the
“monitor”. We show here some of the major advantages of the
Acubrite™ touch screen LED monitor.

Hardware Installation

This section will guide you through the correct installation
procedures of the monitor.

Unpacking

After you unpack your LED Monitor, please make sure that the
following items are included in the carton and in good condition.
If you find that any of these items are damaged or missing,
please contact your dealer immediately.

 Power cable

 Acubrite™ touch screen LED monitor

Pin 1& pin 3 --- Power
Pin 2 --- Ground
Pin 4 --- Ignition

Page 1

Page 2
