Acumen CAT21 User Manual

User

Guide

IMPORTANT - Make sure you set up your Personal Identification Number (PIN) read Section 16 on page 8.

IMPORTANT - Make sure you know where your System Fuse and Spare Fuse are located.

Index

1

System overview 2

The remote transmitter 3

Customising the system 4

Section 1. Full Mode

Section 2. Convenience Mode

Section 3. Service Mode

Section 4. Diagnostic Mode

Section 5. Different siren tones

Section 6. Customising Audible warning of Arm/Disarm

Section 7. Hazard (4-way flasher) Mode

Section 8. Customising the nudge sensor

Section 9. Indicator warning

Section 10. Motorcycle Over-voltage

Section 11. Remote Transmitter battery low warning.

Section 12. Torch feature

Section 13. Key Conversion

Section 14. Trigger warning

Section 15. Sleep Mode

Section 16. PIN Override

Troubleshooting 10

Maintenance 11

System Overview

2

The Acumen CAT21 consists of the following main
components;

• Installed CAT21 main unit

• 2 x remote transmitters

• Installed protecting switch

• Installed system fuse and spare fuse

• LED system indicator

Be sure that you know:

11.. WWhheerree tthhee ssyysstteemm ffuussee iiss,, aanndd wwhheerree tthhee ssppaarree ffuussee iiss llooccaatteedd.. IIff
tthhee ffuussee ffaaiillss,, tthhee ssyysstteemm wwiillll nnoott aallllooww tthhee mmoottoorrccyyccllee ttoo ssttaarrtt..

22.. SSeett yyoouurr PPIINN oovveerrrriiddee.. TThhiiss wwiillll eennaabbllee yyoouu ttoo ddiissaarrmm tthhee ssyysstteemm
aanndd ssttiillll ssttaarrtt yyoouurr mmoottoorrccyyccllee iiff tthhee rreemmoottee ttrraannssmmiitttteerr iiss lloosstt oorr
ddooeess nnoott ffuunnccttiioonn ((sseeee SSeeccttiioonn 1166))..

The CAT21 will monitor;

1. The motorcycle battery and associated motorcycle wiring. If the
battery is disconnected or the ignition is switched on the alarm will
trigger. The CAT21 also monitors the state of the motorcycle battery
for ‘sleep’ purposes.

2. The ignition circuit. If the ignition is switched on while the CAT21 is
protecting the system it will trigger an alarm. Also, the CAT21 Uses
the ignition to enter diagnostic and service mode.

3. Nudge and movement, with a liquid filled, state-of-the-art sensor.
Nudge will result in beeps, movement will result in a full alarm.

4. An anti-tamper switch will cause the alarm to trigger if an attempt
is made to gain unauthorised access to the CAT21 system.

The CAT21 also;

1. Has a ‘fully armed’ mode (see section 1)

2. Has a ‘Convenience’ mode (see section 2)

3. Has a service/valet mode (see section 3)

4. Has a diagnostic mode (see section 4)

5. Has 14 different siren tones (see section 5)

6. Can have the audible warning of arming/disarming turned on or off.
(see section 6)

7. Can activate all four indicators in a Hazard warning mode
(see section 7)

8. Can be programmed to have the nudge sensing removed
(see section 8)

9. Can be programmed to act as an indicator or warning system when
riding the motorcycle (see section 9)

10. Will tell you if it senses excess voltage when the engine is running
(see section 10)

11. Will tell you if the remote transmitter batteries are becoming
discharged (see section 11)

12. Has a useful torch in the remote transmitter (see section 12)

13. Has an ignition key conversion feature in the remote transmitter
(see section 13)

14. Will tell you if the alarm has triggered in your absence
(see section 14)

15. Has a user-selectable PIN override number (see section 16)

The Remote Transmitter

3

Ignition key

The system is supplied with 2 transmitter/Ignition keys, if a new
transmitter is supplied, a new key can be attached as shown in the
diagram opposite.

When all three buttons are pressed at once and held
for 5 seconds

WWiitthh iiggnniittiioonn ooffff

- Silent arm/disarm is toggled (14 flashes on/7 off)

WWiitthh ssyysstteemm aarrmmeedd oorr ddiissaarrmmeedd

- on/off

WWiitthh iiggnniittiioonn oonn,, ssyysstteemm ddiissaarrmmeedd

- Nudge sensor toggled on/off

(6 flashes on/3 off)

WWiitthh iiggnniittiioonn ooffff,, ssyysstteemm iinn sseerrvviiccee mmooddee

- Indicators on warning

function is toggled on/off (5 flashes on/10 off)

Standard Settings of the system

When the system arms, immobilisation and hot wire (ignition circuit
becomes live) functions only will be enabled.

The system will arm automatically 50 seconds after the ignition is
switched off. (this time cannot be altered)

You can manually arm the system by pressing the lock button. (You will
get 2 beeps and 2 flashes of the indicators) (see section 6)

To disarm the system, press the lock button. (You will get 1 beep and 1
flash of the indicators) (see section 6)

The system will arm with an audible warning of arming.

TThhiiss bbuuttttoonn wwiillll;;

• Deactivate/activate tilt
and vibration,

• Select siren tone,

• Select number of
digits in PIN

TThhiiss bbuuttttoonn wwiillll;;

• Arm & disarm the system,

• Allow you to enter Diagnostic
and Service Modes.

TThhiiss bbuuttttoonn wwiillll;;

• Activate the torch

TThhiiss bbuuttttoonn wwiillll;;

• Allow the ignition key
to swivel out

These screws (x2)
attach the ignition
key to the transmitter

Undo these screws (x3)
to remove cover and
replace batteries

Replacement battery type CR2016
