Activox 4L Instructions Manual

Page 1

4L Provider Mode Instructions

FOR USE WITH MODEL XYC100B-P4L

The LifeChoice Activox 4L Control Panel allows for simple operation and clearly stated status and alarm conditions for the patient. Additional features are available to the provider for maintenance and technical support. This guide provides instruction for accessing these features.

BASIC UNIT INFORMATION

There are two patient-facing screens available on the Activox 4L model.

Greeting Screen Home Screen

Activox

Serial Number: PF12345

Runtime: 00.0 Hrs

Version: 1234567.1

Press and hold down the “OK” button to display the Serial Number, Patient Runtime and Software Version.

This screen will be visible to the patient after start-up.

PROVIDER MODES

The Activox 4L model includes additional Provider Modes to enable device maintenance and technical support. These modes are accessed by pressing unique combinations of buttons to prevent patients from accidently entering the mode.

Maintenance Mode: This mode allows the provider to set, view and/or adjust the System Time Clock, Total Run Time and Patient Run Time.

Auto Pulse Mode: This mode allows the provider to test the purity of the device.

MAINTENANCE MODE

To enter Maintenance Mode, press the “OK”, left arrow “ .” and plus “+” buttons simultaneousley on the Control Panel.

There will be five screens you can access using the right arrow “ “ button. The screens will appear in the following order: 1. Language Selection, 2. Run Time, 3. Set Time, 4. Clear Patient Run Time and 5. Exit.

1. Language Selection Screen

This screen allows you to choose the language you want displayed on your Activox 4L screen. The default language is English. To continue in English, press the right arrow “ “ button to move to the Run Time Screen.

To select a language other than English, press the minus “ you have found the language you want to use, press the right arrow “ “ button to move to the Run Time Screen.

-” button to search available languages. Once

Page 2

2. Run Time Screen

This screen displays both the total System Run Time and the Patient Run Time. Only the Patient Run Time can be cleared (reference #4 below for instructions to clear this value). Press the right arrow “ “ button to move to the Set Time Screen.

Maintenance Mode

System Run Time

XX.X hrs

Patient Run Time

XX.X hrs

3. Set Time Screen

This screen allows the time and date to be set on the device. Follow the steps below to set.

With “Set Time” displayed, press “OK” to access “Year”. Use the plus “

+” and minus “-” buttons to

change the value of the selected field (“Year”) up or down. Use the right arrow “ “ to sequence to the next display screens (Year, Month, Day, Hour, Minute, Second) and use the plus “

+” and minus “-”

buttons to change the values. Once complete, press the “OK” button. Press the right arrow “ “ button to move to the Clear Patient Run Time Screen.

Maintenance Mode

Set Time

Year/Mon/Day Hr:Mi:Se

20XX/XX/XX XX:XX:XX

Press “OK”

Maintenance Mode

Set Time

Year

Year/Mon/Day Hr:Mi:Se

4. Clear Patient Run Time Screen

To reset the Patient Run Time, press the “OK” button. The display will then show “0.0 hrs”. If you do not want to reset the Patient Run Time, do not press the “OK” button. Press the right arrow “ “ button to move to the Exit Screen.

Maintenance Mode

Clear Patient Run Time

5. Exit Screen

To exit Maintenance Mode, press the “OK” button.

Press OK to Clear

Patient Run Time

0.0 hrs

Maintenance Mode

Press OK to Exit

Page 3

AUTO PULSE MODE

Placing the device into Auto Pulse Mode will initiate the automatic delivery of pulse doses so oxygen purity can be checked. This mode is only accessable to the provider by pressing a combination of buttons on the Control Panel. Follow the steps below to check the device’s purity level.

Recommended Oxygen Purity Measurement Device: PRO2 Check Elite Multifunction Oxygen Indicator by Salter Labs

1. Power on the device.

2. Press and release the “OK”, right arrow “ ” and plus “ will display the following:

+” buttons simultaneously. The Control Panel

The PULSE-WAVE

Running Internal

Breath Detection symbol

will flash as a bolus is

delivered.

Rest Mode

3. Select the desired Pulse Setting.

NOTE: This mode delivers a bolus of oxygen at 15 BPM across all Pulse Settings (1, 2, 3 or 4).

4. Connect 1/8” silicon tubing to the oxygen flow port of the measurement device and the Cannula Nozzle Fitting on the POC.

5. Allow approximately five minutes for the device to reach full oxygen concentration and to stabilize. If you change the Pulse Setting, allow the device time to stabilize at the new setting before recording readings.

NOTE: It is normal for oxygen concentration values to cycle up and down. The highest value should be considered final for the device. If the swing is more than 2%, the unit is not yet stable enough to measure.

6. To exit Auto Pulse Mode, press the “OK” button or hold down the “Power” button until the unit turns off. When powered back on, the device will be in normal operating mode.

ELECTRONIC RESET

If the display screen does not appear as described in the Operator’s Manual or if the Reset Required alarm is activated, follow the instructions below to reset the device to default factory settings:

1. Power the device off.

2. After the device has turned off, press and hold the “Power” button until the display screen stops flashing and the display turns blank. Once the display is blank, release the “Power” button.

3. Allow appoximately 15 seconds for the device to cycle through a short sequence. During this time, the device will power on and off.

4. Power the device back on. Verify that the display screen is appearing as described in the Operator’s Manual. If this reset does not resolve the issue, contact Inova Labs Customer Care at 1.512.617.1744 or your Inova Labs Sales Representative.

Page 4

Maintenance FAQ

1. Does the Activox 4L model have scheduled maintenance?

Like all POCs, the Activox 4L will eventually require a sieve bed change. In the Service Life section of the Operator’s Manual, it is suggested that the patient run the device weekly for a few hours if it is has not been used on a regular or daily basis. Frequent Low Oxygen Purity and High Temperature alarms may indicate that the system requires service.

2. What type of rechargeable batteries are in the LifeChoice Activox 4L and what are the recommendations to extend the overall service life of the rechargeable batteries?

All Inova Labs POCs use Lithium-Ion rechargeable batteries. The characteristics of Lithium-Ion rechargeable batteries include: high voltage/light weight, no memory effect, and flat discharge voltage.

• A partial discharge reduces stress and prolongs battery life. It is recommended the battery be recharged, if possible, prior to total discharge. The Operator’s Manual informs the patient to “recharge the battery, even if only partially depleted as often as possible.

• Extreme temperature swings effect the battery’s cycle life. Leaving the device or external battery in a hot car, especially if exposed to the sun, is very stressful and can damage the cells.

• When not in use, store the device and/or External Battery is a cool, dry place. For long-term storage, we recommend keeping the device on a charger full-time so the it will retain sufficient charge to perform Repressurization. This will help extend sieve bed life. For long- term storage of the External Battery, we recommend keeping about a 40% charge on the battery. This allows for some selfdischarge while still retaining sufficient charge to keep the protection circuit active.

3. What is the standard warranty of the LifeChoice Activox 4L?

The basic description of the warranty is that from date of shipment from Inova Labs, the device’s internal hardware is covered for three years while the batteries, sieve bed and accessories are covered for one year. Please refer to the Limited Warranty that is included in the Sales Agreement and in every Operator’s Manual for a complete description.

4. How do I initiate a return for service to Inova Labs?

Prior to requesting a return, please troubleshoot over the phone with Inova Labs Customer Care Team at

1.512.617.1744 or your Territory Manager. You may request an RMA by phone to Customer Care or by

email to [email protected]. Include the serial number of the unit, a detailed description of the problem, your contact information and the return shipment address.

Inova Labs Customer Care

Monday - Friday, 7:00 am - 7:00 pm | 1.512.617.1744

Manufactured & Distributed by

| 3500 Comsouth Drive, Suite 100, Austin, Texas 78744 | Corporate Office 1.512.617.1700
