Active Key AK-C7412 User Manual

Specification

Compatibility

All operating systems supporting standard USB, resp. PS/2 keyboards

Chemical Resistance

Suitable for most common cleaning agents

Power/Interface

USB 1.1 (1.2 Mbit/s)

Temperature Range

Storage: –20º to + 60º C Operation: 0º to + 50º C

Supply Voltage

5 V +/- 10% through USB Interface

Current Consumption

Max.: 100mA (USB Low Power Device)

Dimensions, Weight

Approx. 365 x 140 x 18mm; 604g (without packaging)

LED Status Indicators

Num Lock, Caps Lock, Scroll Lock

Key Switch Technology

Scissors Balancing key guidance with contained contact system

Key Travel, Actuation Force

Approx. 2,0 +/- 0,5 mm

Touchpad

Integrated into keyboard, fully sealed. Active area approx. 73 x 37mm

Agency Approvals

CE, RoHS, FCC Test Report, EN60601-1-2:2015 (IEC 4th Edition)

Features & Benefits:

The AK-C7412 is a high quality, highly reliable notebook style PC keyboard. The purification and disinfection
capacity makes it a perfect fit in hospitals and at practitioners, microbiological laboratories as well as
industrial environments. The silicone key membrane protects the key field against ingress of dirt and fluids.
The AK-C4712 impresses with precise key actuation and accurate key guidance. It is highly recommendable
for heavy duty type writing in dirt and hygiene critical operations.
The AK-C7412 provides the following benefits for cleaning and disinfection:•

 Thorough wipe disinfection of key field and keyboard
 Silicone key membrane with low key profile and self-containing, seamless surface
 CleanFunction allows to disable key field while cleaning („Fn“ + „Clean on/off“)
 Fully sealed Num- and Touchpad with mouse buttions integrated
 Suitable for a multitude of hospital cleaning agents and surface disinfectants (VAH)

Disinfectible Hygiene Keyboard

with Num- and Touchpad

AK-C7412 Serie MedicalKey*

Highlights:

- Compact Hygiene Keyboard (95 Keys) with Notebook­Layout, Num- and Touchpad

- 360° Safeguard against Dirt and Water

- Flat keys for thorough surface Disinfection

- Sealed Key Field and Touchpad

- Excellent Tactile Key Feel in Hygiene Critical
Applications

- 4 Threaded Holes for VESA Mounting

- Protection Class IP68 Fully Sealed

Part#: AK-C7412F-GUS-y/xx

Identifier xx = Country Version
US = US English GE = German
Other Versions on Request

Identifier y = Color
W = White (Standard)
B = Black

AK-C7412F-GUS-y/xx

www.activekey.de

20-02-05

*No Medical Device acc. to MDR 2017/745 EU

Active Key GmbH & Co. KG
Brunnenäcker 6
D-91257 Pegnitz
Germany
Phone: [phone]
FAX: [phone]
E-mail: [e-mail]

All trademarks are the property of their respective companies.
Technical data is subject to change without notice. Errors and
omissions excepted. Warranties excluded. AK is a trademark of
Active Key GmbH & Co. KG.
