Active Key AK-C7000 User Manual

Features & Benefits:

The AK-C7000 is a high quality, high performance, and reliable hygiene keyboard. The purification and
disinfection capacity makes it a perfect fit at hospitals, practitioners and microbiological laboratories. The
silicone membrane protects keyboard and key field against ingress of dirt and fluids. The AK-C7000
impresses with congenial key actuation and precise key guidance. With its full PC key layout, the wireless
AK-C7000 is highly recommendable for heavy duty type writing in hygiene critical environments.
The AK-C7000 increases protection against infection and limits risk and liability of the health care provider:

• Safe wipe disinfection of key field and keyboard reduces bio burden in the hospital

• Silicone key membrane with low profile and contained, seamless surface offers effective protection

against cross contamination, proliferation of microbes and formation of biofilms

 No vector for nosocomial pathogens by building an effective germ barrier at the workplace
 No microbial growth on debris and residues from disinfectants in hollow spaces
 No spread of germs and surface recontamination by leakage of polluted cleaning suds

• CleanFunction allows to switch off keys while cleaning (“Fn”+”Clean on/off”)

• Approved for clinical wipe disinfection according to VAH-List (Germany)

• Machine reprocessing of exchange membrane at 93°C and 134°C (in addition to wipe disinfection)

or: Fully Sealed membrane for protection class IP68 (Option)

Specification

Compatibility

All Operating Systems that support Standard USB Keyboards

Temperature Range

Storage –20º to +60º C, Operation 0º to +50º C

Key Membrane

Exchangeable Silicone Membrane (Standard) or Fully Sealed IP68 (Option)

Chemical Resistance

Wipe Disinfection according to Guidelines Cleaning and Disinfection DGHM/VAH

Interface

USB 1.1 (1.2 MBit/s)

Supply Voltage

6V by 4x AAA Batteries

Current Consumption

Typ. 10 mA (USB: Low Power Device)

Connector

USB Type A (Nano Dongle), Range approx. 10m (2,4 GHz RF)

Dimensions (incl. Membrane)

Approx. 372x137x37 mm

LED Status Indicators

Caps Lock, Num Lock, Scroll Lock, CleanFunction

Key Switch Technology

Scissors Balancing. Conducted Standard Key up to 10 Million Actuations

Key Travel

Approx. 2,5 +/- 0,5 mm

Key Actuation Force

Approx. 60 grams (similar to Notebook style Keyboards)

Agency Approvals

CE, RoHS, FCC Certification, EN60601-1-2:2015 (IEC 4th Edition)

Highlights:

- Hygiene Keyboard for Clinical Wipe Disinfection

- 2.4GHz RF Transmission with USB Nano-Dongle

- Full PC Key Layout with 103/104 Keys

- 360° Safeguard against Dirt and Fluid

- Flat Keys for Safe Routine Disinfection

- Contained Key Membrane Made of Silicone

- Seamless Surface for Complete Wipe Disinfection

- Easy Key Actuation for Perfect Typing

- Effective Usability and Ergonomics

- Minimum Life Cycle Cost by Efficient Data Entry

- Exchange Membrane for Machine Reprocessing

- Protection Class IP68 as OPTION

Compact Wireless Keyboard
for Medical and Hygiene

AK-C7000 Series Medical Key*

www.activekey.de

20-02-07

All trademarks are the property of their respective companies.
Technical data is subject to change without notice.
Errors and omissions excepted. Warranties excluded.
AK is a trademark of Active Key GmbH & Co. KG.

Part# / Keyboard: AK-C7000F-FUz-y/xx
Part# / Exchange Membrane: AK-C7000-y/xx

Identifier z = Version/Option
1 = Wipe Disinfection (Standard)

S = Fully Sealed / IP68 with Locked Battery

Compartment, USB Connection (Option)

Identifier y = Color
W = White (Standard)

WB = White Housing,
Black Membrane

Identifier xx = Country Version
FR = French GE = German IT = Italian NOR = Nordic

SP = Spanish UK = UK English US = US English
Other Versions upon Request

*No Medical Device according to MDR 2017/745 EU

Active Key GmbH & Co. KG
Brunnenäcker 6
D-91257 Pegnitz, Germany
