Specification
Compatibility
All operating systems supporting standard USB keyboards
LED Backlight
All keys, low current. Green/white backlight for white/black keyboard versions
Dimming Backlight
8 levels, intensity controlled by “Fn” Up/Down cursor keys
Chemical Resistance
Most common cleaning agents and surface disinfectants
Power/Interface
USB 1.1 (1.2Mbit/s)
Temperature Range
Storage –20º to + 60º C. Operation 0º to + 50º C
Supply Voltage
5 V +/- 10% through USB Port, resp. 6 V (4x AAA) Wireless Keyboard
Current Consumption
Backlit: max. 147mA; Non-Backlit: max. 100mA
Dimensions, Weight
Approx. 291x139x25mm; 0,5kg (without packaging)
LED Status Indicators
Num Lock, Caps Lock, Scroll Lock, Clean
Key Switch Technology
Scissors balancing key guidance with contained contact system
Key Travel, Actuation Force
Approx. 2,5 +/- 0,5 mm, 60g (similar to Notebook keyboards)
LED Life Expectancy
Rated 200,000 hours
Agency Approval
CE, RoHS, FCC Test Report, EN60601-1-2:2015 (IEC 4th Edition)
Features & Benefits:
The AK-C4110 is a high quality, highly reliable notebook style PC keyboard. The purification and
disinfection capacity makes it a perfect fit in hospitals and at practitioners, microbiological laboratories as
well as industrial environments. The silicone key membrane protects the key field against ingress of dirt
and fluids. The AK-C4110 impresses with precise key actuation and accurate key guidance. The AK-C4110
is highly recommendable for heavy duty type writing in dirt and hygiene critical operations.
The AK-C4110 provides the following benefits for cleaning and disinfection
• Thorough wipe disinfection of key field and keyboard
• Silicone key membrane with low key profile and self-containing, seamless surface
• CleanFunction allows to disable key field while cleaning (“Fn”+”Clean on/off”)
• Exchangeable key membrane for separate reprocessing (Disinfection, Steam Sterilization)
• Protection class IP68 for submersion cleaning and machine reprocessing (optional)
• Backlit key field for operation in dark environment (optional)
• Suitable for a multitude of hospital cleaning agents and surface disinfectants (VAH)
Disinfectible Compact-Keyboard
for Purity and Hygiene
AK-C4110 Series MedicalKey*
Highlights:
- Compact Hygiene Keyboard with Notebook Layout
- 360° Safeguard against Dirt and Water
- Silicone Membrane for Utmost Hygiene
- Sealed Key Field
- Flat Keys for Thorough Surface Disinfection
- Excellent Tactile Key Feel for Heavy Duty Type
Writing in Hygiene Critical Applications
- Threaded Holes for Vesa Mounting (only cabled
versions)
Options:
- Protection Class IP68 Fully Sealed
- Backlit Key Field
- 2.4 GHz Radio Control / Wireless
www.activekey.de
20-02-05
AK-C4110F-zz-y/xx (Standard)
Identifier xx = Country Version
US = US English GE = German
Other country versions on request
Identifier y = Color
W = White
B = Black
Identifier zz = Version/Option
U1 = Standard (USB). PS/2 on request.
US = IP68 Fully Sealed (optional)
Active Key GmbH & Co. KG
Brunnenäcker 6
D-91257 Pegnitz
Germany
Phone: +49(0)9241/48337-0
FAX: +49(0)9241/48337-29
E-mail: [email protected]
All trademarks are the property of their respective companies.
Technical data is subject to change without notice.
Errors and omissions excepted. Warranties excluded.
AK is a trademark of Active Key GmbH & Co. KG.
AK-CB4110F-zz-y/xx (Backlit)
*No Medical Device acc. to MDR 2017/745 EU
Part#:
AK-C4110F-Fzz-y/xx (RF)
