Actiontec electronic GT704 User Manual

USB/Ethernet
DSL Gateway
Model #: GT704
Firmware Version: 3.0.1.0.5.6d-GT704-WG
User Manual
Ver 2.0
Solutions for the Digital Life
™
1

Introduction

Thank you for purchasing the Actiontec USB/Ethernet DSL Gateway. The Gateway is the simplest way to connect computers to a high-speed broadband connection. This easy-to-use product is perfect for the home office or small business. If you want to take your computing to the next level, the Actiontec USB/Ethernet DSL Gateway is sure to be one of the keys to your success.

Package Contents

s Actiontec USB/Ethernet DSL Gateway
s Power cord
s Phone filters
s DSL cable
s Yellow (Ethernet) cable
s Blue (USB) cable
s Installation CD (includes user manual)
s Quick start guide
1
2
Actiontec USB/Ethernet DSL Gateway User Manual
3
Chapter 1 Introduction

Minimum System Requirements

s Internet DSL service
s Compatible laptop, desktop, or Macintosh computer with an available
Ethernet or USB (USB compatible with PCs only)
s Microsoft Windows 98, 98 Second Edition (SE), Millennium Edition (Me), NT
4.0, 2000, XP; Mac OS 7.1 and above
☞
Note: USB LAN port is not supported with Microsoft Windows
95 and NT 4.0, or any Mac OS.
s Internet Explorer 4.0 or higher (5.x recommended) or Netscape Navigator
4.0 or higher (4.7 recommended)
s TCP/IP network protocol installed

Features

s Plug-and-Play installation support for systems with Windows operating
systems (98, 98SE, Me, 2000, and XP)
s ADSL WAN port (RJ-11)
s Compliant with full-rate ANSI T1.413 Issue 2, ITU G.992.1 (G.dmt) and
G.992.2 (G.lite) standard
s Auto-handshake for different ADSL flavors
s USB 1.1 device specification compliance
s 11 Mbps USB data rate (full speed)
s Bridged Ethernet over ATM, PPP over ATM, PPP over Ethernet
s Precise ATM traffic shaping
s IP packet routing and transparent bridge
s Routing protocol supports RIP-1, RIP-2, static routing
3
Chapter 1 Introduction
s Built-in NAT, DHCP server
s DNS relay support
s PAP/CHAP authentication, administrative passwords through Telnet
s Compliant with IEEE 802.3 Ethernet standard
s 10/100 Base-T Ethernet ports (4)
s Flow control support for Fast Ethernet
s Web-based configuration setup
s Default configuration backup restore
s FTP firmware upgradeable
s Web download support
4
Actiontec USB/Ethernet DSL Gateway User Manual
5
Chapter 1 Introduction

Getting to Know the Gateway

This section contains a quick description of the Gateway’s lights, ports, etc. The Gateway contains several indicator lights (LEDs) on its front panel and a series of ports on its rear panel.
Front Panel
The front panel of the Gateway features eight lights: Power, DSL, Internet, Ethernet (4), and USB.
Powe
r
DSL
Internet
Etherne
t
USB
Power
DSL
Internet
Ethernet
1
2
3
4
USB
1
2
3
4
Power Light
The Power light displays the Gateway’s current status. If the Power light glows steadily green, the Gateway is receiving power and fully operational. When the Power light flashes rapidly, the Gateway is initializing. If the Power light is not illuminated when the Power cord is plugged in and the Power switch is turned on, the Gateway has suffered a critical error and technical support should be contacted.
DSL Light
The DSL light illuminates when the Gateway is connected to a DSL line.
5
Chapter 1 Introduction
Internet Light
When the Internet light glows steadily, the Gateway is connected to the DSL provider. When it flashes, the Gateway’s built-in DSL modem is training for your
DSL service.
Ethernet Lights
The Ethernet lights illuminate when the Gateway is connected via one or more of its Ethernet ports.
USB Light
The USB light illuminates when the Gateway is connected via its USB port.
Rear Panel
The rear panel of the Gateway contains seven ports (Ethernet [4], Phone, USB, and Power), as well as Reset and Power switches.
Power
USB
Ethernet 4
Reset
Phone
Ethernet 3
Ethernet 2
Ethernet 1
Phone Port
The Phone port is used to connect the Gateway to a DSL (Digital Subscriber Line) connection.
6
Actiontec USB/Ethernet DSL Gateway User Manual
USB Port
The USB port is used to connect a computer to the Gateway via USB cable.
☞
Note: It is not recommended to perform a recovery or update
for the Gateway from a computer connected via USB.
Ethernet Ports
The Ethernet ports are used to connect computers to the Gateway via Ethernet cable. The Ethernet ports are 10/100 Mbps auto-sensing ports, and either a straight-through or crossover Ethernet cable can be used when connecting to the ports.
Reset Switch
Depressing the Reset switch for one or two seconds will power cycle the Gateway (similar to unplugging and then plugging in the Gateway’s Power cord). To restore the Gateway’s factory default settings, depress and hold the Reset switch for approximately 15 seconds. The reset process will start about 10 seconds after releasing the switch.
Power Port
The Power port is used to connect the Power cord to the Gateway.
N
Warning: Do not unplug the Power cord from the Gateway
during the reset process. Doing so may result in permanent damage to the Gateway.
Power Switch
The Power switch is used to power the Gateway on and off.
N
Warning: Do not click the Power switch to its “off” postion
during the reset process. Doing so may result in permanent damage to the Gateway.
7

Setting Up the Gateway

The instructions that follow parallel the steps contained in the Actiontec Installation Buddy™, which provides a visual guide to setting up the Gateway. It is recommended the user run the Installation Buddy first, before attempting any other procedures.
To set up the Gateway, it must be connected to a computer, and then configured. After connecting this first computer, other computers can be added to the network via USB or Ethernet (see “Setting Up a Network” on page 65).

Connecting a Computer to the Gateway

Connecting a computer to the Gateway for setup involves three basic steps: initial setup, plugging in the Gateway’s power cord, and connecting the Gateway to the computer.
Connecting Via Ethernet
1. Insert the Installation CD in the CD-ROM drive of the computer. The
Installation Buddy starts automatically. Wait until the following screen appears, read the on-screen instructions, then click Next.
2
8
Actiontec USB/Ethernet DSL Gateway User Manual
9
Chapter 2 Setting Up the Gateway
2. Read the instructions, select Initial Setup by clicking on the appropriate check
box, then click Next.
3. Click in the check box next to Ethernet (Recommended), then click Next.
9
Chapter 2 Setting Up the Gateway
4. Make sure the items needed to connect the Gateway to the first computer are
included in the kit, then click Next.
5. Get the Gateway from the kit, then click Next.
10
Actiontec USB/Ethernet DSL Gateway User Manual
11
Chapter 2 Setting Up the Gateway
6. Get the Power cord and plug the smaller end into the black Power port on
the rear panel of the Gateway, then click Next.
7. Plug the larger end of the Power cord into a power outlet, then click Next.
11
Chapter 2 Setting Up the Gateway
8. Click the On/Off switch to its on position (as shown in the picture on-
screen), then click Next.
9. Confirm the Power light on the front of the Gateway glows solid green, then
click Next.
12
Actiontec USB/Ethernet DSL Gateway User Manual
13
Chapter 2 Setting Up the Gateway
10. Get the yellow Ethernet cable from the kit and plug one end into a yellow
Ethernet port on the back of the Gateway, then click Next.
11. Plug the other end of the yellow Ethernet cable into an Ethernet port on
the back of the computer. Click Next.
☞
Note: An Ethernet port looks similar to a phone jack, but is
slightly larger.
13
Chapter 2 Setting Up the Gateway
12. Make sure one of the Ethernet lights on the front of the Gateway glows solid
green. Click Next.
13. Get the black or gray DSL cable from the kit and plug one end into the gray
Line port on the rear panel of the Gateway. Click Next.
14
Actiontec USB/Ethernet DSL Gateway User Manual
15
Chapter 2 Setting Up the Gateway
14. Plug the other end of the black or gray DSL cable into the phone jack clos-
est to the computer. Click Next.
15. Make sure the DSL light on the Gateway glows solid green (this may take a
few moments). Click Next.
The Gateway is connected to a computer via Ethernet. Next, install the filters as described in “Installing Filters” on page 22.
15
Chapter 2 Setting Up the Gateway
Connecting Via USB
1. Insert the Installation CD in the CD-ROM drive of the computer. The
Installation Buddy starts automatically. Wait until the following screen appears, read the on-screen instructions, then click Next.
2. Read the instructions, select Initial Setup by clicking on the appropriate check
box, then click Next.
16
Actiontec USB/Ethernet DSL Gateway User Manual
17
Chapter 2 Setting Up the Gateway
3. Click the check box next to USB, then click Next.
4. Make sure the items needed to connect the Gateway to the first computer are
included in the kit, then click Next.
17
Chapter 2 Setting Up the Gateway
5. Get the Gateway from the kit, then click Next.
6. Get the Power cord and plug the smaller end into the black Power port on
the rear panel of the Gateway, then click Next.
18
Actiontec USB/Ethernet DSL Gateway User Manual
19
Chapter 2 Setting Up the Gateway
7. Plug the larger end of the Power cord into a power outlet, then click Next.
8. Click the On/Off switch to its on position (as shown in the picture on-
screen), then click Next.
19
Chapter 2 Setting Up the Gateway
9. Confirm the Power light on the front of the Gateway glows solid green, then
click Next.
10. Get the blue USB cable from the kit and plug the square end into the blue USB
port on the back of the Gateway, then click Next.
20
Actiontec USB/Ethernet DSL Gateway User Manual
21
Chapter 2 Setting Up the Gateway
11. Plug the rectangular end of the blue USB cable into an USB port on the
front or back of the computer. Click Next.
12. Make sure the USB light on the front of the Gateway glows solid green.
Click Next.
21
Chapter 2 Setting Up the Gateway
13. Get the black or gray DSL cable from the kit and plug one end into the gray
Phone port on the rear panel of the Gateway. Click Next.
14. Plug the other end of the black or gray DSL cable into the phone jack clos-
est to the computer. Click Next.
22
Actiontec USB/Ethernet DSL Gateway User Manual
23
Chapter 2 Setting Up the Gateway
15. Make sure the DSL light on the Gateway glows solid green (this may take a
few moments). Click Next.
The Gateway is connected to a computer via USB. Next, install the filters as described in “Installing Filters,” below.

Installing Phone Filters

Phone filters allow the use of the telephone while online. All telephones and other devices (answering machines, fax machines, etc.) using the same phone line (i.e., using the same phone number) as the DSL line must have a phone filter installed. To install a phone filter:
1. Read the on-screen information, then click Next.
23
Chapter 2 Setting Up the Gateway
2. Read the on-screen information, then unplug all telephones and other devices from
their respective phone jacks. Click Next.
3. Get the phone filters. Click Next.
M
Caution: Do not unplug the black or gray DSL cable from the
phone jack near your computer.
24
Actiontec USB/Ethernet DSL Gateway User Manual
25
Chapter 2 Setting Up the Gateway
4. Plug a phone filter into every phone jack with a telephone or other device con-
nected to it, then click Next.
5. Plug the ends of the phone lines disconnected in step 2 into the phone filters
plugged into phone jacks. Click Next.
M
Caution: Do not plug a phone filter in the phone jack in which
the black or gray DSL cable is plugged.
25
Chapter 2 Setting Up the Gateway
6. Read the on-screen instructions, and make sure the Gateway is connected exactly as
shown, depending on whether the Gateway is connected via Ethernet or USB.
Ethernet connection setup:
USB connection setup:
Click Next.
Next, go to “Setting Up the DSL Connection” on the next page.
26
Actiontec USB/Ethernet DSL Gateway User Manual
27
Chapter 2 Setting Up the Gateway

Setting Up the DSL Connection

After connecting the Gateway and installing phone filters, the DSL connection must be configured. To do this:
1. Select one of the options in the “Select Connection” box: Auto Detect, Select
from the list, or Manual Setup.
Auto Detect - if selected, click Next. The DSL connection is automatically detected, and a series of informational screens will be displayed while the Gateway searches for the connection. If successful, go to step 2. If unsuccess­ful, go to Select from the list, below.
Select from the list - If Auto Detect is not successful, or the user knows which
ISP to connect to, click in the “Select from the list” box, then click Next.
27
Chapter 2 Setting Up the Gateway
In the next window, select the ISP being used from the list box on the left
(scroll down for more choices), then click Next. A series of informational screens will display while the Gateway searches for the connection. If the con­nection is successful, go to step 2. If not, go to “Manual Setup,” below.
Manual Setup - If the Auto Detect and Select from a list are not successful, or
the user knows how to configure VPI/VCI and Encapsulation settings, click in the “Manual Setup” box, then click Next.
