ACTIA I ME COMXS320 User Manual

User Manual
ComXS-320

IR14618B User Manual ComXS-320 11.05.2017 Page 1/12

ACTIA I+ME GmbH
Dresdenstrasse 17/18
38124 Braunschweig
Germany
Tel.: + 49 (0) 531 38701-0
Fax: + 49 (0) 531 38701-88
www.ime-actia.com

User Manual

ComXS-320

User Manual
ComXS-320

IR14618B User Manual ComXS-320 11.05.2017 Page 2/12

Document history

Index

Pages

Date

Reason for amendment

A

All

08.02.2017

Drafting of the document

A

All

07.03.2017

Minor corrections and updates

A915.03.2017

Updated CE declaration

B811.05.2017

Updated Antenna Information and RF
exposure warning added

© 2017 ACTIA I+ME GmbH. All rights reserved

User Manual
ComXS-320

IR14618B User Manual ComXS-320 11.05.2017 Page 3/12

Contents

1. SCOPE OF THIS USER MANUAL ........................................................................... 4

2. GENERAL INSTRUCTIONS ...................................................................................4

3. SAFETY INSTRUCTIONS ......................................................................................5

4. GENERAL PRODUCT DESCRIPTION......................................................................6

4.1 KEY FEATURES..................................................................................................6

4.2 CHARACTERISTICS .............................................................................................7

4.3 ANTENNA INFORMATION.......................................................................................8

5. REGULATORY STATEMENTS.................................................................................9

5.1 CE ...............................................................................................................9

5.2 FCC..............................................................................................................9

5.2.1. FCC END PRODUCT LABELING INSTRUCTION .......................................................... 10

5.3 IC.............................................................................................................. 10

5.3.1. IC END PRODUCT LABELLING............................................................................ 12

5.3.2. IC EN ÉTIQUETAGE DU PRODUIT FINAL CONFORME À IC ............................................ 12

User Manual
ComXS-320

IR14618B User Manual ComXS-320 11.05.2017 Page 4/12

1. SCOPE OF THIS USER MANUAL

This User Manual contains all the information that is required to use the ComXS-320
module in the intended manner. It also provides information about usage and storage
conditions, and gives an overview of the authorisations and certifications.

This User Manual is intended to be used by technical qualified personnel who dispose of
the appropriate know-how in electronics engineering.

Manufacturer:

ACTIA I+ME GmbH
Dresdenstrasse 17/18
38124 Braunschweig
Germany
Tel.: + 49 (0) 531 38701-0
Fax: + 49 (0) 531 38701-88

www.ime-actia.com
Brand: ComXS
Model: ComXS-320

2. GENERAL INSTRUCTIONS

This symbol indicates useful information that facilitates your work
with the system.

This symbol indicates important instructions which you should
follow at all times in order to avoid malfunctions or damage.
