ACTi TCM-1231 H.264 Megapixel Outdoor IP IR D/N PoE Bullet
Camera
Product Name: ACTi TCM-1231 H.264 Megapixel Outdoor IP IR D/N PoE Bullet Camera
Manufacturer: Model Number: TCM-1231
Please Note: This product has been discontinued. For an alternative, we recommend the ACTi
Outdoor Bullet Cameras
ACTi TCM-1231 H.264 Megapixel Outdoor IP IR D/N PoE Bullet Camera
The ACTi TCM-1231 H.264 1.3 Megapixel Outdoor IP IR D/N PoE Bullet Camera features a 1/3",
1.3 megapixel Aptina progressive scan CMOS sensor, a 3.3-12mm (f/1.6) varifocal lens, and an
infrared LED array for day and night surveillance. With the mechanical IR cut filter, the camera
assures good color rendition in up to 0.5 lux illumination, whereas the IR LEDs make for clear
imagery even in total darkness (0 lux). Auto White Balance adjusts the red and blue signals in the
MWB mode by taking a standard white color reference to get the most natural colors. Auto Gain
Control adjusts the signal strength to maintain a constant brightness level.
ACTi TCM-1231 Features
� 1/3" and 1.3 MP Progressive Scan CMOS
� Day/Night Functionality
� Mechanical IR Cut Filter
� IR LED Array for 0 lux Performance
� 3.3-12mm (f/1.6) Varifocal Lens
� SXGA Resolution (1280 x 1024) at 18 fps
� Selectable H.264/MPEG-4SP/MJPEG
� Two-way Audio Support
� Video Motion Detection
� PoE Class 3 / 12 VDC
Technical Specification
Device
� Device Type Bullet Camera
� Image Sensor Progressive Scan CMOS
� Sensor Size 1/3" (4.8 x 3.6 mm)
� Day / Night Yes
� Minimum Illumination Color: 0.5 lux at F1.0 (30 IRE, 2400°K); B/W: 0 lux (IR LED on)
� Color to B/W switch CDS sensor based switch, configurable
� Mechanical IR Cut Filter Yes
� IR Sensitivity Range 700 - 1100 nm
� IR LED IR LED x 24 (850 nm)
� IR Working Distance 30 m (0 lux, 30 IRE, Max Exposure Gain)
� Electronic Shutter 1/30 - 1/1,000 sec (60Hz); 1/25 - 1/1,000 sec (50Hz) (manual mode) 1/5 1/15,000 sec (auto mode)
Lens
� Focal Length / Aperture Vari-focal, f3.3 - 12 mm / F1.6
� Iris Fixed iris
� Focus Manual focus
� Horizontal Viewing Angle 76.5° - 21.7°
www.voipon.co.uk | help@voipon.co.uk | Page 1/3
Created on: Tuesday 27 April, 2021
ACTi TCM-1231 H.264 Megapixel Outdoor IP IR D/N PoE Bullet
Camera
Video
� Compression H.264, MPEG-4 SP, MJPEG
� Maximum Frame Rate vs. Resolution 18 fps at 1280 x 1024 (SXGA); 26 fps at 1280 x 720
(HD 720p); 30 fps at 640 x 480 (VGA); 30 fps at 320 x 240 (QVGA); 30 fps at 160 x 112 (QQVGA)
� Multi-Streaming Simultaneous dual streams based on two configurations
� Bit Rate 28 Kbps - 6 Mbps (per stream)
� Bit Rate Mode Constant, Variable
� S/N Ratio More than 44 dB
� Image Enhancement Wide dynamic range; White balance: automatic, hold, predefined and
manual; Brightness; Saturation; Contrast;
� Sharpness; Automatic gain control; Auto exposure: automatic, predefined and manual;
Flickerless
� Privacy Mask 4 configurable regions
� Text Overlay User defined text on video
Audio
� Compression 8kHz, Mono, PCM, 16 bit encoding
� Audio-In Terminal block
� Audio-Out Terminal block
Network
� Protocol & Service TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS,
DDNS, NTP, ICMP, ARP,IGMP, SMTP, FTP, UPnP, SNMP, Bonjour
� Ethernet Port 1, Ethernet (10/100 Base-T), RJ-45 connector
� Security IP address filtering; HTTPS encryption; Password protected user levels; IEEE
802.1X network access control
Alarm
� Alarm Trigger Video motion detection (3 regions); External device through digital input
� Alarm Response Notify control center; Change camera settings; Command other devices;
E-mail notification with snapshots; Upload video, snapshot to FTP server; Activate external device
through digital output
Interface
� Digital Input 1, terminal block
� Digital Output 1, terminal block
General
� Power Source / Consumption
� PoE Class 3 (IEEE802.3af) / 8.16 W (IR on)
� DC 12V / 6.96 W (IR on) (adapter not included)
� Weight 685 g (1.51 lb)
� Dimensions (Ø x L) 77 mm x 220 mm (3.03"x 8.66")
� Environmental Casing Weatherproof (IP66 rated)
� Operating Temperature -20 °C ~ 50 °c (-4 °F ~ 122 °F)
� Operating Humidity 10% ~ 85% RH
