Acson ACK20E, ACK25E, ACK28E, ACK40E, ACK50E user guide manual

Models:

ACK/A5CK 20E/ER
ACK/A5CK 25E/ER
ACK/A5CK 28E/ER
ACK/A5CK 40E/ER
ACK/A5CK 50E/ER

ACK - E - 2009

Ceiling Cassette Split Systems

ACK-E-2009 Table of Contents

Table of Contents

Nomenclature......................................................................................................................1

Indoor Unit .....................................................................................................................1

Outdoor Unit ..................................................................................................................2

Product Line-Up .............................................................................................................3

Features.............................................................................................................................10

Application Information ................................................................................................... 11

Operating Range ......................................................................................................... 11

Refrigerant Circuit Diagram .........................................................................................12

Controller ....................................................................................................................17

Installation Guideline ...................................................................................................20

Sound Data ........................................................................................................................33

Sound Pressure Level .................................................................................................33

NC Curve .....................................................................................................................34

Engineering & Physical Data ........................................................................................... 37

General Data ...............................................................................................................37

Component Data .........................................................................................................53

Safety Devices ............................................................................................................69

Performance Data ............................................................................................................. 74

Calculation Steps .........................................................................................................75

Performance Table ......................................................................................................78

Outline and Dimension ..................................................................................................102

Electrical Data ................................................................................................................. 104

Wiring Diagram ............................................................................................................... 112

Service and Maintenance...............................................................................................121

Troubleshooting .............................................................................................................123

Exploded View and Part List .........................................................................................129

“Acson” is a registered trademark of Acson International. All rights reserved.

© 2009 Acson International. All rights reserved throughout the world.

Bulletin illustrations cover the general appearance of Acson International products at the time of publication.

We reserve the right to change design and construction specifi cations at any time without notice.

Nomenclature ACK-E-2009

Nomenclature

Indoor

A 5 CK 20 E R

Brand

A : Acson

Refrigerant

“ “

4

5

Model Name

CK : Ceiling Cassette

: Omitted if R22

: R407C

: R410A

Capacity Index

20 : 20,000 Btu/h

Chassis

E : E Series

Model Type

“ “

R

: Omitted if cooling only

: Heatpump

1

ACK-E-2009 Nomenclature

Outdoor

A 5 LC 20 C R

Brand

A : Acson

Refrigerant

“ “

4

5

Model Name

LC : Single Split Condensing Unit

Capacity Index

20 : 20,000 Btu/h

: Omitted if R22

: R407C

: R410A

Chassis

E : E Series

Model Type

“ “

R

: Omitted if cooling only

: Heatpump

2

Product Line-Up ACK-E-2009

Product Line-Up

Indoor Unit
ACK-E Series

Classifi cation

Model

Nomenclature

20E ACOBA X X X X X X

25E ACOBA X X X X X X

28E ACOBA X X X X X X

40E ACOBA X X X X X X

COOLING ONLY

50E ACOBA X X X X X X

20ER ACOBA X X X X X X

25ER ACOBA X X X X X X

28ER ACOBA X X X X X X

40ER ACOBA X X X X X X

HEATPUMP

50ER ACOBA X X X X X X

PCB

L2 08A

G18

Handset

Fin

Refrigerant Control

Bare

Cap Tube

W/out Cap Tube

Air Purifi cation

Marking

CE

Others

Auto Air Swing

3

ACK-E-2009 Product Line-Up

Indoor Unit
A5CK-E Series

Classifi cation

Model

Nomenclature

20E ACOBA X X X X X X

25E ACOBA X X X X X X

28E ACOBA X X X X X X

40E ACOBA X X X X X X

COOLING ONLY

50E ACOBA X X X X X X

20ER ACOBA X X X X X X

25ER ACOBA X X X X X X

28ER ACOBA X X X X X X

40ER ACOBA X X X X X X

HEATPUMP

50ER ACOBA X X X X X X

PCB

L2 08A

G18

Handset

Fin

Refrigerant Control

Bare

W/out Cap Tube

Air Purifi cation

Marking

CE

Others

Auto Air Swing

4

Product Line-Up ACK-E-2009

Indoor Unit
ACK Panel Product Line Up

Classifi cation

Model

COOLING

Handset

Nomenclature

G18

PLCKE-NG18 X X X

ONLY

PLCKER-NG18 X X X

HEATPUMP

CE

Marking

Others

Auto Air Swing

5

ACK-E-2009 Product Line-Up

Outdoor Unit
ALC

Classifi cation

Model

20C

25C

Refrigerant Control

Nomenclature

TXV

Cap Tube

ACPOD X X X X

ACPID X X X X

ACPHB X X X X X

ACPBD X X X X X

ACPOD X X X X

ACPID X X X X

ACPBD X X X X X

ACPHB X X X X X

ACPSD X X X X X

ACHOB X X X

Fin

Gold Coated

Bare

Compressor

Scroll / Digital Scroll

Rotary / Fixed Scroll

Contactor

High Pressure Switch

Safety Devices

Low Pressure Switch

Phase SequencerCEHigh Ambient Kit

Marking

Others

Drain Elbow

28C

35C

COOLING ONLY

40C

50C

ACHIB X X X

ACHBB X X X X

AFGE X X X X X X

AFGG X X X X X X

AFGE X X X X X X

AFGG X X X X X X

FFGE X X X X X X X

FFGF X X X X X X X X

FFGG X X X X X X X

FFGL X X X X X X X

AUCOA X X X X X X

FUDOA X X X X X X

FFGN X X X X X

FFGP X X X X X X X X

FFGQ X X X X X X X

FFGT X X X X X X X X

FUDOA X X X X X X

6

Product Line-Up ACK-E-2009

Outdoor Unit
ALC

Classifi cation

Model

20CR

25CR

28CR

35CR

HEATPUMP

Refrigerant Control

Nomenclature

TXV

Cap Tube

ACPOD X X X X

ACPID X X X X

ACPHB X X X X X

ACPOD X X X X

ACPID X X X X

ACPHB X X X X X

ACHOB X X X

ACHIB X X X

AFFB X X X X X X X X

AFFD X X X X X X X X

Fin

Gold Coated

Bare

Compressor

Scroll/ Digital Scroll

Rotary/ Fixed Scroll

Contactor

High Pressure Switch

Safety Devices

Low Pressure Switch

Phase SequencerCEHigh Ambient Kit

Marking

Others

Drain Elbow

AFFB X X X X X X X X

AFFD X X X X X X X X

40CR

FFFB X X X X X X X X X

FFFD X X X X X X X X X

FFFF X X X X X X X X X

50CR

FFFG X X X X X X X X X

7

ACK-E-2009 Product Line-Up

Outdoor Unit
A5LC

Classifi cation

Model

20C

25C

28C

Refrigerant Control

Nomenclature

TXV

Cap Tube

ACPIC X X X X

ACPOC X X X X

FCPOC X X X X X X

ACPIC X X X X

ACPOC X X X X

FCPOC X X X X X X

ACPOA X X X X

ACPIA X X X X

FCPOA X X X X X X

ACCOB X X X X X X X

Fin

Gold Coated

Bare

Compressor

Scroll/ Digital Scroll

Rotary/ Fixed Scroll

Contactor

High Pressure Switch

Safety Devices

Low Pressure Switch

Phase Sequencer

Marking

CE

Others

Drain Elbow

ACCGB X X X X X X X

35C

COOLING ONLY

FCCOB X X X X X X X X

FCCGB X X X X X X X X

FCCGB X X X X X X X X

FCCOB X X X X X X X X

40C

ACCOB X X X X X X X

ACCGB X X X X X X X

FCCOB X X X X X X X X

50C

FCCGB X X X X X X X X

8

Product Line-Up ACK-E-2009

Outdoor Unit
A5LC

Classifi cation

Model

20CR

25CR

28CR

Refrigerant Control

Nomenclature

TXV

Cap Tube

ACPIC X X X X

ACPOC X X X X

FCPOC X X X X X X

ACPIC X X X X

ACPOC X X X X

FCPOC X X X X X X

ACPOA X X X X

ACPIA X X X X

FCPOA X X X X X X

ACCOB X X X X X X X

Fin

Gold Coated

Bare

Compressor

Scroll / Digital Scroll

Rotary / Fixed Scroll

Contactor

High Pressure Switch

Safety Devices

Low Pressure Switch

Phase Sequencer

Marking

CE

Others

Drain Elbow

HEATPUMP

35CR

40CR

50CR

ACCGB X X X X X X X

FCCOB X X X X X X X X

FCCGB X X X X X X X X

ACCGB X X X X X X X

ACCOB X X X X X X X

FCCOB X X X X X X X X

FCCGB X X X X X X X X

FCCOB X X X X X X X X

FCCGB X X X X X X X X

9

ACK-E-2009 Features

Features

Improved Sound Level

The new ACK-E series is equipped with a newly-developed turbo fan, which has improved the sound pressure
level of the unit signifi cantly.

Lower Height Model

To ease installation, the overall height of the ACK-E series has been greatly reduces. (350mm for ACK-E,
290mm for ACK 20-28E/ER, 325mm for ACK 40-50E/ER).

Multi-Comfort – 3 Air Swing Pattern Control

To increase the comfort level of the air conditioned area of ACK-E series, the system had been built in with 3
different type of the air fl ow pattern to suit different requirement.

Built-in High Head Drain Pump

The unit has a built-in high head drain pump (with 700 mm drain head) to provide and ensure smoothness
drainage of condensate water.

Wireless Remote Controller

The compact LCD transmitter is able to operate the air conditioner unit within the distance of 8 meters.

•
Fan speed can be set at high / medium / low / super low or automatic.

•
Sleep mode auto control will gradually increase or decrease the setting temperature to provide a

•
comfortable surrounding for sleeping.
Air fl ow direction can be controlled automatically.

•
Room temperature is controlled by electronic thermostat.

•
The real time timer allows the air conditioner to be switched On and Off automatically based on user

•
settings.
Turbo mode function is available to enables the required set temperature to be achieved in a short time.

•
Personalized Setting allows user to preset and store 2 groups of personal settings (including timer setting)

•
in the handset.

10

Application Information ACK-E-2009

Application Information

Operating Range

Ensure the operating temperature is in allowable range.

Cooling only

46

35

19

Outdoor temp. (°CDB)

Standard

point

! Caution :

The use of your air conditioner
outside the range of working
temperature and humidity can
result in serious failure.

Heat Pump

Outdoor temp. (°CWB)

15

Indoor temp. (°CWB)

Heating

18

6

-9

Standard

15 21

Indoor temp. (°CDB)

Note :

Standard operating range.

point

24

Cooling

46

35

19

Standard

point

Outdoor temp. (°CDB)

37

15

24

Indoor temp. (°CWB)

11

ACK-E-2009 Application Information

Refrigerant Circuit Diagram

Model: ACK 20E - ALC 20C A5CK 25E - A5LC 25C
A5CK 20E - A5LC 20C

Model: ACK 25E - ALC 25C
A5CK 28E - A5LC 28C

70034 095231

70034 049972

12

Application Information ACK-E-2009

Model: ACK 28E - ALC 28C

Model: ACK 40E - ALC 35/40C
ACK 50E - ALC 50C

70034 049972

13

70034 049181

ACK-E-2009 Application Information

Model: A5CK 40E - A5LC 35/40C
A5CK 50E - A5LC 50C

Model: ACK/A5CK 20ER - ALC/A5LC 20CR
A5CK 25ER - A5LC 25CR

70034 097007

70034 095238

14

Application Information ACK-E-2009

Model: ACK 28ER - ALC 28CR

Model: ACK/A5CK 28ER - ALC/A5LC 28CR

70034 049972

15

70034 049181

ACK-E-2009 Application Information

Model: ACK 30ER - ALC 30CR
ACK 40ER - ALC 35/40CR
ACK 50ER - ALC 50CR

Model: A5CK 40ER - A5LC 35/40CR
A5CK 50ER - A5LC 50CR

70034 095246

08014 085116

16

Application Information ACK-E-2009

Controller

G18

1

2

3

4

15

14

13
12

11
10

5
6

7
8

9

Operation Guide

1 Transmission Source

The source where the signal will be transmitted.•

2 Signal Transmission Indication

Blink to confi rm that the last setting has been transmitted

•
to the unit.

3 Temperature Setting

To set the desired room temperature, press the ▲ or ▼

•
button to increase or decrease the set temperature.
The temperature setting range is from 16°C to 30°C

•
(optional setting 20°C to 30°C).

4 Personalize Setting

Press

•

•

•

•

5 Automatic Air Swing (optional)

•

•

6 Silent Function

•

•

•

7 Sleep Mode Setting

•

•

•

and hold for 3s, then will blink. Press again to
cycle between and .
Set the desire setting, then leave the handset for 4s
without pressing any key and it will save the setting into the
programme.
Press once to activate the P1 setting, press again to
cycle between P1 and P2.
Press any key to deactivate the personalize setting.

Press the SWING

button to activate the automatic air

swing function.
To distribute the air to a specifi c direction, press the
SWING button and wait until the louver move to the
desired direction and press the button once again.

Press

for quiet operation.
Fan speed turn to minimum speed.
Press again to deactivate the function.

Press the SLEEP button will activate the sleep mode
function. This function is available under COOL, HEAT and
AUTO mode.
When the unit is operating under cooling mode, the set
temperature is increased by 0.5°C after 30 minutes, 1°C
after an hour, and 2°C after 2 hours.
When the unit is operating under heating mode, the set
temperature is decreased by 1°C after 30 minutes, 2°C
after an hour, and 3°C after 2 hours.

8 Operating Mode

Press the MODE button to select the type of operating

•
mode.
For cooling only unit, the available modes are: COOL (7),

•
DRY (6) and FAN (

).

9 Fan Speed Selection

Press the

•

button continuously will toggle the fan speed
in the following order:
Low B Med B High B Auto
Stop pressing when the desired fan speed appears on the

•
display screen.

10 “ON/OFF” Button

Press one to start the air conditioner unit.

•
Press again to stop the unit.

•

11 Timer Cancel

Press the TIMER CANCEL button to cancel the on timer

•
setting.

12 OFF Timer Setting

Press the OFF TIMER button will activate the off timer

•
function.
Set the desired off time by pressing the OFF TIMER button

•
continuously.

13 ON Timer Setting

Press the ON TIMER button will activate the on timer

•
function.
Set the desired on time by pressing the ON TIMER

•
button continuously. If the timer is set to 7.30am, the air
conditioner will turn on at 7.30am sharp.

14 Turbo Function

Press

•
Fan speed turn to maximum speed.

•
Press again to deactivate the function.

•

for fast cooling.

15 Clock Time Setting

Press

and hold to set the clock time.•

17

ACK-E-2009 Application Information

Operating State and Fault Table

Wireless Remote Control
Cooling : LED Indicator Light Display Heatpump : LED Indicator Light Display

POWER TIMER SLEEP

POWER TIMER SLEEP

1 Time

2 Times

3 Times

1 Time

HEAT

POWER

Operation / Faulty Indication

Cool Mode

Time On

Sleep Mode On

Heat Mode

Auto Mode - Cool

Auto Mode - Heat

Compressor Overload

Pump Fault

Gas Leak

Room Sensor Open or Short

TIMER HEAT

2 Times

3 Times

ON

Indoor Coil Sensor Open or Short

Outdoor Coil Sensor Open or Short

ON or OFF Blinking

18

Application Information ACK-E-2009

Water Pump

The water pump will on if compressor is on during cooling cycle. The pump will remain on for at least 5 minutes
after the compressor is off.
During mode change from cooling to non-cooling mode, the pump will on for minimum 5 minutes. During
defrost cycle, the pump will on and will on for another 5 minutes once the defrost cycle is terminated.

Water Level Switch

This normally close switch is to detect faults in water pump system. It will confi rm for 30 seconds for switch
open and 60 seconds for switch close.
Once switch is confi rmed open, it will force compressor to cut off. If the switch is closed within 5 minutes, the
compressor is allowed to cut in. If the switch does not close for more than 5 minutes, the system will warn user
regarding the fault, the compressor is not allowed to cut in. If the switch is confi rmed opened twice within 30
minutes, the system assumes there are faults.

Phase Sequencer

The unit with Scroll Compressor can only rotate in one direction. For this reason, a protective device (phase
sequencer) is fi tted to prevent incorrect wiring of the electrical phases. When the three phases are not connected
correctly, the phase sequencer operates, and the unit will not start. This devise is located in the control box of
the outdoor unit.

The following table shows the LED indicator light for phase sequencer under normal operation and fault
conditions.

LED_P

(Red)

Normal Operation On - - -

Reverse Phase Blink Blink Blink Blink

S & T Phase Missing Blink - Blink Blink

T Phase Missing Blink - - Blink

S Phase Missing Blink - Blink -

R Phase Missing - - - -

Overload Blink - - -

Sensor Missing Blink On On On

Notes: 1. “-” means LED off.

2. When R phase missing, no LED or buzzer will indicate the error, but relay 71 (Common) and 81
(NO) will cut off.

3. The unit will check the discharge sensor availability only during power up.

4. All errors can only recover through manually reset.

LED_R

(Yellow)

LED_S

(Yellow)

LED_T

(Yellow)

19

ACK-E-2009 Application Information

Installation Guideline

Caution

Sharp edges and coil surfaces are potential injury hazard. Avoid from contact with them.•

(1) Installation Of Indoor Unit

Preliminary Site Survey

Electrical supply and installation is to confi rm to local authority’s (e.g. National Electrical Board) codes and

•

regulations.
Voltage supply fl uctuation must not exceed ± 10% of rated voltage. Electricity supply lines must be

•

independent of welding transformers which can cause high supply fl uctuation.
Ensure that the location is convenient for wiring, piping and drainage.

•

The indoor unit must be installed in such that free from any obstacles in path of cool air discharge and

•

warm air return, and must allow spreading or air throughout the room (near the centre of the room).
Clearance must be provided for the indoor unit from the wall and obstacles as shown in the fi gure.

•

maeB

m0.1.niM

m0.3.xaM

Obstacle

Floor

The installation place must be strong enough to support a load of 4 times the indoor unit weight to avoid

•

m5.0.niMm5.0.niMm5.0.niM

m3.0.xaM

amplifying noise and vibration.
The installation place (handling ceiling surface) must be level and the height in the ceiling is 350mm or

•

more.

Unit Installation

770.0 mm (Hanging rod)

)dorgnignaH(mm0.226

Piping Direction

The indoor unit must be away from heat and steam sources (avoid installing it near an entrance).

•

Measure and mark the position for the hanging rod. Drill the hole for the angle nut on the ceiling and fi x

•

the hanging rod.
The installation template is extended according to temperature and humidity. Check on dimensions in

•

using.
The dimensions of the installation template are same as those of the ceiling opening dimensions.

•

Before ceiling laminating work is completed, be sure to fi t the installation template to the indoor unit.

•

Note: Be sure to discuss the ceiling drilling work with the installers concerned.

20

Application Information ACK-E-2009

Unit Hanging

Ceiling
Board

35.0mm

ACK-E

Confi rm the pitch of the hanging rod is 770mm x 622mm sharp.

•

Hold the unit and hand it on the hanging rod with the nut and washer.

•

Adjust the unit height to 35.0mm between the indoor unit bottom surface and the ceiling surface.

•

Confi rm with a level gauge that the unit is installed horizontally and tighten the nut and bol to prevent unit

•

falling and vibration.
Open the ceiling board along the outer edge of the paper installation template.

•

Drain Piping Work

Drain Test

Drain pipe must be downward gradient for smooth drainage.

•
Avoid the drain pipe from up and down slope to prevent

•
reversal fl ow.
During the drain piping connection, be careful not to exert extra

•
force on the drain connector at indoor unit.
The outside diameter of the drain connection at the fl exible

•
drain hose is 20mm.
Be sure to provide heat insulation (polyethylene foam with

•
thickness more than 8.0mm) on the drain piping to avoid the
condensed water dripping inside the room.

Connect the main drain pipe to the fl exible drain hose.

•
Feed water from fl exible drain hose and check the piping for

•
leakage.
When the test is completed, connect the fl exible drain hose to

•
the drain connector on the indoor unit.

Note: This indoor unit use drain pump for condensed water drainage. Install the unit horizontally to

prevent water leakage or condensation around the air outlet.

21

ACK-E-2009 Application Information

Panel Installation

The front panel can only be fi tted in one direction, follow the piping direction. (Follow piping arrow sticker

•
on the front panel).
Be sure to remove the installation template before installing the front panel.

•

Open the air intake grille by pulling back the catchers and remove it together with fi lter from panel.

•
Install the front frame panel onto the indoor unit by using 4 screws and tighten it completely to prevent cool

•
air leakage.
Connect the LED wire and air swing wire to the indoor unit (Optional).

•

Note: Install the front frame panel fi rmly to prevent cool air leakage which will cause condensation

and water dripping.

22

Application Information ACK-E-2009

Short Duct Specifi cation

The indoor unit is provided with air discharge and air intake “knock-out” hole for duct connection. However

•
the connection of the short duct for air discharge is possible on only one side.
The use of short duct for air discharge will improve air fl ow distribution if there is an obstruction (such as

•
alighting fi xture) or in a long, narrow room or an L-shaped room. It is also used for air-conditioning of two

rooms simultaneously.

Possible Direction For Air Discharge and Air Intake

Air DischargeAir Discharge

Air Intake

egrahcsiDriAegrahcsiDriA

Possible Opening Dimension for Duct Connection

Note: 1. Avoid to use the short duct on which the air discharge grille can be completely closed, to

prevent evaporator freezing.

2. In order to prevent condensation forming, be sure that there is suffi cient thermal insulation

and no leakage of cool air when installing the short duct.

3. Keep the introduction of fresh air intake within 20% of total air fl ow. Also provide a chamber

and use a booster fan.

23

ACK-E-2009 Application Information

(2) Installation Of Outdoor Unit

As condensing temperature rises, evaporating temperature rises and cooling capacity drops. In order to achieve
maximum cooling capacity, the location selected for outdoor unit should fulfi ll the following requirements:

Install the condensing (outdoor) unit in a way such that hot air distributed by the outdoor condensing unit

•
cannot be drawn in again (as in the case of short circuit of hot discharge air). Allow suffi cient space for
maintenance around the unit.

Ensure that there is no obstruction of air fl ow into or out of the unit. Remove obstacles which block air

•
intake or discharge.

The location must be well ventilated, so that the unit can draw in and distribute plenty of air thus lowering

•
the condensing temperature.

A place capable of bearing the weight of the outdoor unit and isolating noise and vibration.

•
A place protected from direct sunlight. Otherwise use an awning for protection, if necessary.

•

The location must not be susceptible to dust or oil mist.

•

Installation Clearance

Outdoor units must be installed such that there is no short circuit of the hot discharge air or obstruction to

•
smooth air fl ow. Select the coolest possible place where intake air should not be hotter than the outside
temperature (max. 45˚C).

ALL MODELS A B C D

Minimum Distance 300 mm 1000 mm 300 mm 500 mm

CAUTION : If the condensing unit is operated in an atmosphere containing oils (including machine oils), salt (coastal area),
sulphide gas (near hot spring, oil refi nery plant), such substances may lead to failure of the unit.

24

Application Information ACK-E-2009

(3) Refrigerant Piping

Maximum Piping Length and Maximum Number of Bends

When the pipe length becomes too long, both the capacity and reliability drop. As the number of bends
increases, system piping resistance to the refrigerant fl ow increases, thus lowering the cooling capacity,
and as the result the compressor may become defective. Always choose the shortest path and follow the
recommendation as tabulated below:

Model

Maximum Length, m 15 15 15 45 45

Maximum Elevation, m 8 8 8 25 25

Maximum No. of Bends 10 10 10 10 10

Indoor 20E/ER 25E/ER 28E/ER 40E/ER 50E/ER

Outdoor 20C/CR 25C/CR 28C/CR 35/40C/CR 50C/CR

Piping Sizes (Flare Connection Type)

Piping sizes are as follows:

R22

Model ALC 20C/CR ALC 25C/CR

Liquid (mm/in) 6.35 / 1/4 9.52 / 3/8

Suction (mm/in) 15.88 / 5/8 15.88 / 5/8

Model ALC 28C/CR ALC 35/ 40C/CR ALC 50C/CR

Liquid (mm/in) 9.52 / 3/8 9.52 / 3/8 9.52 / 3/8

Suction (mm/in) 15.88 / 5/8 19.05 / 3/4 19.05 / 3/4

R410A

Model A5LC 20C/CR A5LC 25C/CR

Liquid (mm/in) 6.35 / 1/4 6.35 / 1/4

Suction (mm/in) 12.70 / 1/2 15.88 / 5/8

Model A5LC 28C/CR A5LC 35C/CR A5LC 40C/CR A5LC 50C/CR

Liquid (mm/in) 9.52 / 3/8 9.52 / 3/8 9.52 / 3/8 9.52 / 3/8

Suction (mm/in) 15.88 / 5/8 15.88 / 5/8 15.88 / 5/8 15.88 / 5/8

25

ACK-E-2009 Application Information

Piping Connection To The Units

Align the centre of the piping and tighten the fl are nut suffi ciently with fi ngers.

•
Finally tighten the fl are nut with torque wrench unit the wrench clicks.

•
When tightening the fl are nut with torque wrench, ensure the direction for tightening follows the arrow on

•
the wrench.

(4) Wiring

Electrical Connections

Wiring regulations on wire diameters differ from country to country. Please refer to your LOCAL ELECTRICAL
CODES for fi eld wiring rules. Be sure that installation is complied with such rules and regulations

.

General Precautions

Ensure that the rated voltage of the unit corresponds to the nameplate before carrying out proper wiring

•
according to the wiring diagram.
Provide a power outlet to be used exclusively for each unit. A power supply disconnects and a circuit

•
breaker for over current protection should be provided in the exclusive line.
All wiring must be GROUNDED to prevent possible hazards due to insulation failures.

•
All wiring must be fi rmly connected.

•
All wiring must not come in contact with the hot refrigerant piping, compressor or any moving parts of fan

•
motors.

Do not use joined and twisted wires for incoming power supply

•

26

Application Information ACK-E-2009

(5) Vacuuming and Charging

The pre-charged outdoor unit does not need any vacuuming or charging. However once it is connected, the
connecting pipe line and the indoor unit need to be vacuumed before releasing the R22/R407C/R410A from
the outdoor unit.

1. Open the service port core cap.

2. Connect pressure gauge to the service port.

3. Connect the line to vacuum pump. Open the charging manifold valve and turn the pump on. Vacuum to -0.1

MPa (-760mmHg) or lower. (Evacuation time varies by the pump but averagely in 1 hour).

Filter Dryer

(Mclecular-Sieve Type

Note : R407C- Fix filter dryer
R22 - Nil
R410A - Nil

4. After evacuation, unscrew the spindle (diagram B) for the gas to run to indoor unit.

Caution For R407C / R410A

Do not top-up when servicing leak, as this will reduce the unit performance. Vacuum the unit thoroughly

•

and then charge the unit with fresh R407C according to the amount recommended in the specifi cation.

27

ACK-E-2009 Application Information

(6) Additional Charge

The refrigerant charge has already charged into the outdoor unit. For the piping length of 7.6m, additional

•
refrigerant charge after vacuuming is not necessary.
When the piping length is more than 7.6m, please use the table below (unit in gram).

•

R22

Model 10m 12m 15m 25m 35m 45m

20C/CR 38 / 53 70 / 96 118 / 162 - - -

25C/CR 94 / 53 172 / 98 289 / 164 - - -

28C/CR 94 / 133 172 / 244 291 / 411 - - -

30C/CR 133 / 133 244 / 243 410 / 409 964 / 961 1518 / 1514 2072 / 2067

35C/CR 130 / 136 238 / 248 400 / 418 940 / 983 1481 / 1547 2021 / 2112

40C/CR 134 / 136 245 / 248 412 / 418 968 / 983 1525 / 1547 2081 / 2112

50C/CR 130 / 134 238 / 245 400 / 412 942 / 968 1483 / 1525 2024 / 2081

R410A

Model 10m 15m 20m 25m 35m 45m

20C/CR 24 / 40 44 / 73 74 / 123 - - -

25C/CR 24 / 23 45 / 43 75 / 72 - - -

28C/CR 58 / 91 106 / 167 178 / 281 - - -

35C/CR 65 / 98 118 / 180 199 / 303 469 / 712 738 / 1122 1007 / 1531

40C/CR 61 / 97 112 / 178 189 / 299 445 / 703 700 / 1107 956 / 1511

50C/CR 50 / 87 92 / 159 155 / 267 363 / 628 572 / 989 781 / 1350

28

Application Information ACK-E-2009

The additional refrigerant charge amount recommended is a guideline for longer piping application. The
actual charge required may be different from the guideline due to different application and variation in site
conditions.

Diagram shows typical charging method:

(Mclecular-Sieve Type)

Note : R407C - Fix filter dryer
R22 - Nil
R410A - Nil

Caution For R407C / R410A

Avoid prolong exposure of an opened compressor, or the internal part of refrigerant piping to moist air.

•
The POE oil in the compressor and piping can absorb moisture from air.

29

ACK-E-2009 Application Information

Special Precautions When Dealing With Refrigerant R410A Unit

(1) What is New Refrigerant R410A?

R410A is a new HFC refrigerant which does not damage the ozone layer. The working pressure of this

new refrigerant is 1.6 times higher than conventional refrigerant (R22), thus proper installation / servicing
is essential.

(2) Components

Mixture weight composition R32(50%) and R125(50%)

(3) Characteristic

R410A liquid and vapor components have different compositions when the fl uid evaporates or

•
condenses. Hence, when leak occurs and only vapor leaks out, the composition of the refrigerant
mixture left in the system will change and subsequently affect the system performance. DO NOT add
new refrigerant to leaked system. It is recommended that the system should be evacuated thoroughly
before recharging with R410A.
When refrigerant R410A is used, the composition will differ depending on whether it is in gaseous or

•
liquid phase. Hence when charging R410A, ensure that only liquid is being withdrawn from the cylinder
or can. This is to make certain that only original composition of R410A is being charged into the system.
POE oil is used as lubricant for R410A compressor, which is different from the mineral oil used for R22

•
compressor. Extra precaution must be taken not to expose the R410A system too long to moist air.

(4) Check List Before Installation / Servicing

Tubing

•
Refrigerant R410A is more easily affected by dust of moisture compared with R22, make sure to
temporarily cover the ends of the tubing prior to installation.
Compressor oil

•
No additional charge of compressor oil is permitted.
Refrigerant

•
No other refrigerant other that R410A
Tools (size of service port is different from R22 system)

•
Tools specifi cally for R410A only (must not be used for R22 or other refrigerant)

i) Gauge manifold and charging hose
ii) Gas leak detector
iii) Refrigerant cylinder/charging cylinder
iv) Vacuum pump c/w adapter
v) Flare tools
vi) Refrigerant recovery machine

(5) Handling and Installation Guidelines

Like R22 system, the handling and installation of R410A system are closely similar. All precautionary

measures; such as ensuring no moisture, no dirt or chips in the system, clean brazing using nitrogen, and
thorough leak check and vacuuming are equally important requirements. However, due to its hydroscopic
POE oil, additional precautions must be taken to ensure optimum and trouble free system operation.

(a) During installation or servicing, avoid prolong exposure of the internal part of the refrigerant system to

moist air. Residual POE oil in the piping and components can absorb moisture from the air.

(b) Ensure that the compressor is not exposed to open air for more than the recommended time specifi ed

by its manufacturer (typically less than 10 minutes). Removed the seal plugs only when the compressor
is about to be brazed.

(c) The system should be thoroughly vacuumed to 1.0 Pa (700mmHg) or lower. This vacuuming level is

more stringent than R22 system so as to ensure no incompressible gas and moisture in the system.

30

Application Information ACK-E-2009

(d) When charging R410A, ensure that only liquid is being withdrawn from the cylinder or can. This is

to ensure that only the original composition of R410A is being delivered into the system. The liquid
composition can be different from the vapor composition.

Invert cylinder

Dip-pipe

without dip-pipe

Liquid
withdrawal

(e) Normally, the R410A cylinder or can is being equipped with a dip pipe for liquid withdrawal. However,

if the dip pipe is not available, invert the cylinder or can so as to withdraw liquid from the valve at the
bottom.

31

ACK-E-2009 Application Information

(7) Overall Checking

Ensure the following, in particular:

•

1. The unit is mounted solidly and rigid in position.

2. Piping and connections are leak proof after charging.

3. Proper wiring has been done.

Drainage check – pour some water into drain pan.

•
Test run

•

1. Conduct a test run after water drainage test and gas leakage test.

2. Watch out for the following:

(a) Is the electric plug fi rmly inserted into the socket?
(b) Is there any abnormal sound from the unit?
(c) Is there any abnormal vibration with regard to the unit itself or piping?
(d) Is there smooth drainage of water?

Check that:

•

1. Outdoor fan is running, with warm air blowing off the outdoor unit (cooling cycle).

2. Indoor blower is running and discharge cool air (cooling cycle).

3. Suction (low side) pressure is as per recommendations.

4. The remote controller has incorporated a 3 minutes delay in the circuit. Thus, it requires about 3 minutes
before the outdoor unit can start up.

(8) Standard Operating Condition

Cooling Only Unit

Temperature

Minimum Indoor Temperature 19.4 / 66.9 13.9 / 57.0

Maximum Indoor Temperature 26.7 / 80.1 19.4 / 66.9

Minimum Outdoor Temperature 19.4 / 66.9 13.9 / 57.0

Maximum Outdoor Temperature 46 / 114.8 24 / 75.2

Heat Pump Unit

Temperature

Minimum Indoor Temperature 10 / 50 -

Maximum Indoor Temperature 26.7 / 80.1 -

Minimum Outdoor Temperature -8 / 17.6 -9 / 15.8

Maximum Outdoor Temperature 24 / 75.2 18/ 64.4

Ts : Dry Bulb Temperature Th : Wet Bulb Temperature

Ts °C / °F Th °C / °F

Ts °C / °F Th °C / °F

32

Sound Data ACK-E-2009

Sound Data

ACK-E/ER

Model

ACK 20E/ER

ACK 25E/ER

ACK 28E/ER

ACK 40E/ER

ACK 50E/ER

Speed

1/1 Octave A-Weighted Sound Pressure (dBA), ref 20μPa

125 Hz 250 Hz 500 Hz 1k Hz 2k Hz 4k Hz 8k Hz

Overall

A (dBA)

Noise

Criteria

High 37 38 35 26 17 8 6 34 30

Medium 34 34 33 21 11 5 6 31 28

Low 32 30 30 17 8 4 5 28 24

Super Low 32 28 29 16 7 4 5 27 23

High 39 40 37 29 22 13 6 37 32

Medium 37 38 35 26 18 9 5 34 30

Low 35 35 32 22 13 6 5 31 26

Super Low 34 34 31 20 10 5 6 30 25

High 45 43 42 35 29 22 11 41 37

Medium 40 41 39 30 24 15 7 38 34

Low 38 38 35 26 19 9 5 35 30

Super Low 35 35 33 23 14 5 4 32 28

High 48 45 44 38 30 28 15 44 39

Medium 49 42 41 34 25 21 8 41 36

Low 48 39 38 31 21 13 6 38 33

Super Low 45 35 36 26 15 5 5 35 31

High 50 48 46 42 33 32 20 47 41

Medium 52 45 43 38 29 27 13 44 38

Low 53 43 42 37 27 24 10 43 37

Super Low 51 41 39 32 23 16 6 39 34

Model Measuring location

ACK/A5CK 20E/ER
ACK/A5CK 25E/ER
ACK/A5CK 28E/ER

ACK/A5CK 40E/ER
ACK/A5CK 50E/ER

1.4m

Microphone

Standard : JIS C 9612

1.5m

Microphone

Standard : JIS B 8615

33

ACK-E-2009 Sound Data

ACK 20E/ER NC Curve

80

70

60

50

40

Sound pressure level (dB, ref 20μPa)

30

Super High Fan

High Fan

20

Medium Fan

Low Fan

10

63 125 250 500 1000 2000 4000 8000

Octave-band frequency (Hz)

NC70

NC65

NC60

NC55

NC50

NC45

NC40

NC35

NC30

NC25

NC20

ACK 25E/ER NC Curve

80

70

60

50

40

30

Sound pressure level (dB, ref 20μPa)

20

10

63 125 250 500 1000 2000 4000 8000

Octave-band frequency (Hz)

Super High Fan

High Fan

Medium Fan

Low Fan

NC70

NC65

NC60

NC55

NC50

NC45

NC40

NC35

NC30

NC25

NC20

34

Sound Data ACK-E-2009

ACK 28E/ER NC Curve

80

70

60

50

40

Super High Fan

30

Sound pressure level (dB, ref 20μPa)

High Fan

Medium Fan

20

Low Fan

10

63 125 250 500 1000 2000 4000 8000

Octave-band frequency (Hz)

NC70

NC65

NC60

NC55

NC50

NC45

NC40

NC35

NC30

NC25

NC20

ACK 40E/ER NC Curve

80

70

60

50

40

30

Sound pressure level (dB, ref 20μPa)

20

10

63 125 250 500 1000 2000 4000 8000

Octave-band frequency (Hz)

Super High Fan

High Fan

Medium Fan

Low Fan

NC70

NC65

NC60

NC55

NC50

NC45

NC40

NC35

NC30

NC25

NC20

35

ACK-E-2009 Sound Data

ACK 50E/ER NC Curve

80

70

60

50

40

Super High Fan

Sound pressure level (dB, ref 20μPa)

30

High Fan

Medium Fan

20

10

63 125 250 500 1000 2000 4000 8000

Low Fan

Octave-band frequency (Hz)

NC70

NC65

NC60

NC55

NC50

NC45

NC40

NC35

NC30

NC25

NC20

36

Engineering & Physical Data ACK-E-2009

Engineering & Physical Data

General Data - Cooling Only (R22)

MODEL

NOMINAL CAPACITY

NOMINAL TOTAL INPUT POWER W 1960 2540

NOMINAL RUNNING CURRENT A 8.8 11.5

POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50

EER W/W 2.91 2.89

REFRIGERANT TYPE R22 R22

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) Pa / in.wg. 00

SOUND PRESSURE LEVEL (H/M/L) dBA 34 / 31 / 28 37 / 34 / 31

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

UNIT WEIGHT (UNIT + PANEL) kg/lb 29+6 / 63.9+13.2 29+6 / 63.9+13.2

CONDENSATE DRAIN SIZE

AIR FLOW l/s / CFM 614 / 1300 755 / 1600

SOUND PRESSURE LEVEL dBA 51 52

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 59 / 130 62 / 137

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 1 / 2.20 1.25 / 2.76

OPERATION WIRELESS OR WIRED MICRO-

HIGH l/s / CFM 280 / 600 320 / 680

MEDIUM l/s / CFM 250 / 530 280 / 600

LOW l/s / CFM 200 / 430 250 / 530

INDOOR UNIT ACK 20E ACK 25E

OUTDOOR UNIT ALC 20C ALC 25C

Btu/h 19500 25000

W 5715 7327

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

COMPUTER REMOTE CONTROL

HEIGHT mm/in 265 (340) /10.43 (13.39) 265 (340) / 10.43 (13.39)

WIDTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

DEPTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

HEIGHT mm/in 300 (110) / 11.8 (4.33) 300 (110) / 11.8 (4.33)

WIDTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

mm/in 19.1 / 0.75 19.1 / 0.75

HEIGHT mm/in 654 / 25.7 756 / 29.8

WIDTH mm/in 855 / 33.7 855 / 33.7

DEPTH mm/in 328 / 12.9 328 / 12.9

HEIGHT

WIDTH mm/in 990 / 39.0 990 / 39.0

DEPTH mm/in 415 / 16.3 415 / 16.3

TYPE FLARE VALVE FLARE VALVE

SIZE

LIQUID mm/in 6.4 / 1/4 9.5 / 3/8

GAS mm/in 15.9 / 5/8 15.9 / 5/8

mm/in 710 / 28.0 810 / 31.9

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS C 9612 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.4m BELOW FASCIA.

37

ACK-E-2009 Engineering & Physical Data

General Data - Cooling Only (R22)

MODEL

NOMINAL CAPACITY

NOMINAL TOTAL INPUT POWER

NOMINAL RUNNING CURRENT A 12.3

POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50

EER W/W 2.91

REFRIGERANT TYPE R22

REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 410 / 860

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) Pa / in.wg. 0

SOUND PRESSURE LEVEL (H/M/L) dBA 41 / 38 / 35

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

UNIT WEIGHT (UNIT + PANEL) kg/lb 29+6 / 63.9+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75

AIR FLOW l/s / CFM 741 / 1570

SOUND PRESSURE LEVEL dBA 54

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 68 / 150

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 2.20 / 4.85

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.5m BELOW FASCIA.

MEDIUM l/s / CFM 340 / 725

LOW l/s / CFM 290 / 620

INDOOR UNIT ACK 28E

OUTDOOR UNIT ALC 28C

Btu/h 27000

W 7913

W 2720

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

HEIGHT mm/in 265 (340) / 10.43 (13.39)

WIDTH mm/in 820 (990) / 32.3 (38.98)

DEPTH mm/in 820 (990) / 32.3 (38.98)

HEIGHT mm/in 300 (110) / 11.8 (4.33)

WIDTH mm/in 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 756 / 29.8

WIDTH mm/in 855 / 33.7

DEPTH mm/in 328 / 12.9

HEIGHT

WIDTH mm/in 990 / 39.0

DEPTH mm/in 415 / 16.3

TYPE FLARE VALVE

SIZE

LIQUID mm/in 9.5 / 3/8

GAS mm/in 15.9 / 5/8

mm/in 810 / 31.9

38

Engineering & Physical Data ACK-E-2009

General Data - Cooling Only (R22)

MODEL

NOMINAL CAPACITY - 1Ø <3Ø>

NOMINAL TOTAL INPUT POWER - 1Ø <3Ø>

NOMINAL RUNNING CURRENT - 1Ø <3Ø> A 14.4 16.7 <5.8>

POWER SOURCE - 1Ø <3Ø>

EER - 1Ø <3Ø> W/W 3.41 3.31 / <3.59>

REFRIGERANT TYPE R22 R22

REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR CAP. TUBE INDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 490 / 1030 490 / 1030

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) Pa / in.wg. 00

SOUND PRESSURE LEVEL (H/M/L) dBA 44 / 41 / 38 44 / 41 / 38

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

UNIT WEIGHT (UNIT + PANEL) kg/lb 42+6 / 92.6+13.2 42+6 / 92.6+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75 19.1 / 0.75

AIR FLOW l/s / CFM 1605 / 3400 1605 / 3400

SOUND PRESSURE LEVEL dBA 58 58

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 95 / 209 100 / 221

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 2.7 / 5.95 2.95 / 6.50

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.5m BELOW FASCIA.

MEDIUM l/s / CFM 410 / 860 410 / 860

LOW l/s / CFM 350 / 740 350 / 740

INDOOR UNIT ACK 40E ACK 40E

OUTDOOR UNIT ALC 35C ALC 40C

Btu/h 35000 39000 <40000>

W 10258 11430 <11723>

W 3010 3450 <3260>

V/Ph/Hz 220 - 240 / 1 / 50

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

HEIGHT mm/in 300 (375) / 11.81 (14.76) 300 (375) / 11.81 (14.76)

WIDTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

DEPTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

HEIGHT mm/in 335 (110) / 13.19 (4.3) 335 (110) / 13.19 (4.3)

WIDTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 850 / 33.5 850 / 33.5

WIDTH mm/in 1030 / 40.6 1030 / 40.6

DEPTH mm/in 400 / 15.8 400 / 15.8

HEIGHT

WIDTH mm/in 1200 / 47.2 1200 / 47.2

DEPTH mm/in 560 / 22.1 560 / 22.1

TYPE FLARE VALVE FLARE VALVE

SIZE

LIQUID mm/in 9.5 / 3/8 9.5 / 3/8

GAS mm/in 19.1 / 3/4 19.1 / 3/4

mm/in 1000 / 39.4 1000 / 39.4

220 - 240 / 1 / 50

<380 - 415 / 3 / 50>

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

39

ACK-E-2009 Engineering & Physical Data

General Data - Cooling Only (R22)

MODEL

NOMINAL CAPACITY

NOMINAL TOTAL INPUT POWER

NOMINAL RUNNING CURRENT A 7.9

POWER SOURCE V/Ph/Hz 380 - 415 / 3 / 50

EER W/W 3.03

REFRIGERANT TYPE R22

REFRIGERANT CONTROL (EXPANSION DEVICE) INDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 570 / 1200

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) Pa / in.wg. 0

SOUND PRESSURE LEVEL (H/M/L) dBA 47 / 44 / 43

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

UNIT WEIGHT (UNIT + PANEL) kg/lb 42+6 / 92.6+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75

AIR FLOW l/s / CFM 1605 / 3400

SOUND PRESSURE LEVEL dBA 58

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 105 / 232

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 2.55 / 5.62

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.5m BELOW FASCIA.

MEDIUM l/s / CFM 490 / 1030

LOW l/s / CFM 440 / 930

INDOOR UNIT ACK 50E

OUTDOOR UNIT ALC 50C

Btu/h 47500

W 13921

W 4600

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

HEIGHT mm/in 300 (375) / 11.81 (14.76)

WIDTH mm/in 820 (990) / 32.3 (38.98)

DEPTH mm/in 820 (990) / 32.3 (38.98)

HEIGHT mm/in 335 (110) / 13.19 (4.3)

WIDTH mm/in 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 850 / 33.5

WIDTH mm/in 1030 / 40.6

DEPTH mm/in 400 / 15.8

HEIGHT

WIDTH mm/in 1200 / 47.2

DEPTH mm/in 560 / 22.1

TYPE FLARE VALVE

SIZE

LIQUID mm/in 9.5 / 3/8

GAS mm/in 19.1 / 3/4

mm/in 1000 / 39.4

40

Engineering & Physical Data ACK-E-2009

General Data - Heat Pump (R22)

MODEL

NOMINAL COOLING CAPACITY

NOMINAL HEATING CAPACITY

NOMINAL TOTAL INPUT POWER (COOLING) W 1960 2540

NOMINAL TOTAL INPUT POWER (HEATING) W 1690 2310

NOMINAL RUNNING CURRENT (COOLING) A 8.8 11.5

NOMINAL RUNNING CURRENT (HEATING) A 7.6 10.4

POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50

EER W/W 2.91 2.89

COP W/W 3.38 3.17

REFRIGERANT TYPE R22 R22

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 280 / 600 320 / 680

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) mmAq 00

SOUND PRESSURE LEVEL (H/M/L) dBA 34 / 31 / 28 37 / 34 / 31

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

UNIT WEIGHT kg/lb 29+6 / 63.9+13.2 29+6 / 63.9+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75 19.1 / 0.75

AIR FLOW l/s / CFM 614 / 1300 755 / 1600

SOUND PRESSURE LEVEL dBA 51 52

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 59 / 130 62 / 137

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 1.8 / 3.97 1.88 / 4.14

MEDIUM l/s / CFM 250 / 530 280 / 600

LOW l/s / CFM 200 / 430 250 / 530

INDOOR UNIT ACK 20ER ACK 25ER

OUTDOOR UNIT ALC 20CR ALC 25CR

Btu/h 19500 25000

W 5715 7327

Btu/h 19500 25000

W 5715 7327

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

HEIGHT mm/in 265 (340) /10.43 (13.39) 265 (340) / 10.43 (13.39)

WIDTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

DEPTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

HEIGHT mm/in 300 (110) / 11.8 (4.33) 300 (110) / 11.8 (4.33)

WIDTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 654 / 25.7 756 / 29.8

WIDTH mm/in 855 / 33.7 855 / 33.7

DEPTH mm/in 328 / 12.9 328 / 12.9

HEIGHT

WIDTH mm/in 990 / 39.0 990 / 39.0

DEPTH mm/in 415 / 16.3 415 / 16.3

TYPE FLARE VALVE FLARE VALVE

SIZE

LIQUID mm/in 6.4 / 1/4 9.5 / 3/8

GAS mm/in 15.9 / 5/8 15.9 / 5/8

mm/in 710 / 28.0 810 / 31.9

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS C 9612 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.4m BELOW FASCIA.

41

ACK-E-2009 Engineering & Physical Data

General Data - Heat Pump (R22)

MODEL

NOMINAL COOLING CAPACITY

NOMINAL HEATING CAPACITY

NOMINAL TOTAL INPUT POWER (COOLING) W 2720

NOMINAL TOTAL INPUT POWER (HEATING) W 2350

NOMINAL RUNNING CURRENT (COOLING) A 12.3

NOMINAL RUNNING CURRENT (HEATING) A 10.9

POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50

EER W/W 2.91

COP W/W 3.50

REFRIGERANT TYPE R22

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 410 / 860

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) mmAq 0

SOUND PRESSURE LEVEL (H/M/L) dBA 41 / 38 / 35

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

UNIT WEIGHT kg/lb 29+6 / 63.9+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75

AIR FLOW l/s / CFM 741 / 1570

SOUND PRESSURE LEVEL dBA 54

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 68 / 150

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 1.85 / 4.08

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.5m BELOW FASCIA.

MEDIUM l/s / CFM 340 / 725

LOW l/s / CFM 290 / 620

INDOOR UNIT ACK 28ER

OUTDOOR UNIT ALC 28CR

Btu/h 27000

W 7913

Btu/h 28000

W 8206

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

HEIGHT mm/in 265 (340) / 10.43 (13.39)

WIDTH mm/in 820 (990) / 32.3 (38.98)

DEPTH mm/in 820 (990) / 32.3 (38.98)

HEIGHT mm/in 300 (110) / 11.8 (4.33)

WIDTH mm/in 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 756 / 29.8

WIDTH mm/in 855 / 33.7

DEPTH mm/in 328 / 12.9

HEIGHT

WIDTH mm/in 990 / 39.0

DEPTH mm/in 415 / 16.3

TYPE FLARE VALVE

SIZE

LIQUID mm/in 9.5 / 3/8

GAS mm/in 15.9 / 5/8

mm/in 810 / 31.9

42

Engineering & Physical Data ACK-E-2009

General Data - Heat Pump (R22)

MODEL

NOMINAL COOLING CAPACITY - 1Ø <3Ø>

NOMINAL HEATING CAPACITY - 1Ø <3Ø>

NOMINAL TOTAL INPUT POWER (COOLING) - 1Ø <3Ø> W 3010 3450 / <3260>

NOMINAL TOTAL INPUT POWER (HEATING) - 1Ø <3Ø> W 2750 3250 / <3200>

NOMINAL RUNNING CURRENT (COOLING) - 1Ø <3Ø> A 14.4 16.7 / <5.8>

NOMINAL RUNNING CURRENT (HEATING) - 1Ø <3Ø> A 13.4 15.9 / <6.0>

POWER SOURCE - 1Ø <3Ø>

EER - 1Ø / <3Ø> W/W 3.41 3.31 / <3.59>

COP - 1Ø / <3Ø> W/W 3.73 3.70 / <3.84>

REFRIGERANT TYPE R22 R22

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE + TXV OUTDOOR CAP. TUBE + TXV

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 490 / 1030 490 / 1030

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) mmAq 00

SOUND PRESSURE LEVEL (H/M/L) dBA 44 / 41 / 38 44 / 41 / 38

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

UNIT WEIGHT kg/lb 42+6 / 92.6+13.2 42+6 / 92.6+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75 19.1 / 0.75

AIR FLOW l/s / CFM 1605 / 3400 1605 / 3400

SOUND PRESSURE LEVEL dBA 58 58

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 95 / 209 100 / 221

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 2.7 / 5.95 2.95 / 6.50

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.5m BELOW FASCIA.

MEDIUM l/s / CFM 410 / 860 410 / 860

LOW l/s / CFM 350 / 740 350 / 740

INDOOR UNIT ACK 40ER ACK 40ER

OUTDOOR UNIT ALC 35CR ALC 40CR

Btu/h 35000 39000 / <40000>

W 10258 11430 / <11723>

Btu/h 35000 41000 / <42000>

W 10258 12010 / <12309>

V/Ph/Hz

HEIGHT mm/in 300 (375) / 11.81 (14.76) 300 (375) / 11.81 (14.76)

WIDTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

DEPTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

HEIGHT mm/in 335 (110) / 13.19 (4.3) 335 (110) / 13.19 (4.3)

WIDTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 850 / 33.5 850 / 33.5

WIDTH mm/in 1030 / 40.6 1030 / 40.6

DEPTH mm/in 400 / 15.8 400 / 15.8

HEIGHT

WIDTH mm/in 1200 / 47.2 1200 / 47.2

DEPTH mm/in 560 / 22.1 560 / 22.1

TYPE FLARE VALVE FLARE VALVE

SIZE

LIQUID mm/in 9.5 / 3/8 9.5 / 3/8

GAS mm/in 19.1 / 3/4 19.1 / 3/4

mm/in 1000 / 39.4 1000 / 39.4

220 - 240 / 1 / 50

<380 - 415 / 3 / 50>

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

220 - 240 / 1 / 50

<380 - 415 / 3 / 50>

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

43

ACK-E-2009 Engineering & Physical Data

General Data - Heat Pump (R22)

MODEL

NOMINAL COOLING CAPACITY

NOMINAL HEATING CAPACITY

NOMINAL TOTAL INPUT POWER (COOLING) W 4600

NOMINAL TOTAL INPUT POWER (HEATING) W 4070

NOMINAL RUNNING CURRENT (COOLING) A 7.9

NOMINAL RUNNING CURRENT (HEATING) A 7.1

POWER SOURCE V/Ph/Hz 380 - 415 / 3 / 50

EER W/W 3.03

COP W/W 3.46

REFRIGERANT TYPE R22

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE + TXV

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 570 / 1200

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) mmAq 0

SOUND PRESSURE LEVEL (H/M/L) dBA 47 / 44 / 43

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

UNIT WEIGHT kg/lb 42+6 / 92.6+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75

AIR FLOW l/s / CFM 1605 / 3400

SOUND PRESSURE LEVEL dBA 58

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 105 / 232

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 2.9 / 6.39

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.5m BELOW FASCIA.

MEDIUM l/s / CFM 490 / 1030

LOW l/s / CFM 440 / 930

INDOOR UNIT ACK 50ER

OUTDOOR UNIT ALC 50CR

Btu/h 47500

W 13921

Btu/h 48000

W 14068

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

HEIGHT mm/in 300 (375) / 11.81 (14.76)

WIDTH mm/in 820 (990) / 32.3 (38.98)

DEPTH mm/in 820 (990) / 32.3 (38.98)

HEIGHT mm/in 335 (110) / 13.19 (4.3)

WIDTH mm/in 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 850 / 33.5

WIDTH mm/in 1030 / 40.6

DEPTH mm/in 400 / 15.8

HEIGHT

WIDTH mm/in 1200 / 47.2

DEPTH mm/in 560 / 22.1

TYPE FLARE VALVE

SIZE

LIQUID mm/in 9.5 / 3/8

GAS mm/in 19.1 / 3/4

mm/in 1000 / 39.4

44

Engineering & Physical Data ACK-E-2009

General Data - Cooling Only (R410A)

MODEL

NOMINAL CAPACITY

NOMINAL TOTAL INPUT POWER W 1740 1940

NOMINAL RUNNING CURRENT W 7.7 8.7

POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50

EER W/W 3.08 3.36

REFRIGERANT TYPE R410A R410A

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 280 / 600 320 / 680

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) Pa (in.wg.) 00

SOUND PRESSURE LEVEL (H/M/L) dBA 34 / 31 / 28 37 / 34 / 31

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

WEIGHT (UNIT + PANEL) kg/lb 29+6 / 63.9+13.2 29+6 / 63.9+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 3/4 19.1 / 3/4

AIR FLOW l/s / CFM 614 / 1300 755 / 1600

SOUND PRESSURE LEVEL dBA 52 52

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 59 / 130 62 / 137

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 1.75 / 3.86 1.85 / 4.08

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS C 9612 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.4m BELOW FASCIA.

MEDIUM l/s / CFM 250 / 530 280 / 600

LOW l/s / CFM 200 / 430 250 / 530

INDOOR UNIT A5CK 20E A5CK 25E

OUTDOOR UNIT A5LC 20C A5LC 25C

Btu/h 18300 22200

W 5363 6506

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

HEIGHT mm/in 265 (340) / 10.43 (13.39) 265 (340) / 10.43 (13.39)

WIDTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

DEPTH mm/in 820(990) / 32.3 (38.98) 820(990) / 32.3 (38.98)

HEIGHT mm/in 300 (110) / 11.8 (4.33) 300 (110) / 11.8 (4.33)

WIDTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 654 / 25.7 756 / 29.8

WIDTH mm/in 855 / 33.7 855 / 33.7

DEPTH mm/in 328 / 12.9 328 / 12.9

HEIGHT

WIDTH mm/in 990 / 39.0 990 / 39.0

DEPTH mm/in 415 / 16.3 415 / 16.3

TYPE FLARE VALVE FLARE VALVE

SIZE

LIQUID mm/in 6.4 / 1/4 6.4 / 1/4

GAS mm/in 12.7 / 1/2 15.9 / 5/8

mm/in 710 / 28.0 810 / 31.9

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

45

ACK-E-2009 Engineering & Physical Data

General Data - Cooling Only (R410A)

MODEL

NOMINAL CAPACITY

NOMINAL TOTAL INPUT POWER W 2790

NOMINAL RUNNING CURRENT A 13.1

POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50

EER W/W 2.84

REFRIGERANT TYPE R410A

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 410 / 860

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) Pa (in.wg.) 0

SOUND PRESSURE LEVEL (H/M/L) dBA 41 / 38 / 35

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

WEIGHT (UNIT + PANEL) kg/lb 29+6 / 63.9+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75

AIR FLOW l/s / CFM 684 / 1450

SOUND PRESSURE LEVEL dBA 54

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 68 / 150

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 2.125 / 4.68

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL SPECIFICATIONS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.5m BELOW FASCIA.

MEDIUM l/s / CFM 340 / 725

LOW l/s / CFM 290 / 620

INDOOR UNIT A5CK 28E

OUTDOOR UNIT A5LC 28C

Btu/h 27000

W 7913

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

HEIGHT mm/in 265 (340) / 10.43 (13.39)

WIDTH mm/in 820 (990) / 32.3 (38.98)

DEPTH mm/in 820 (990) / 32.3 (38.98)

HEIGHT mm/in 300 (110) / 11.8 (4.33)

WIDTH mm/in 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 756 / 29.8

WIDTH mm/in 855 / 33.7

DEPTH mm/in 328 / 12.9

HEIGHT

WIDTH mm/in 990 / 39.0

DEPTH mm/in 415 / 16.3

TYPE FLARE VALVE

SIZE

LIQUID mm/in 9.5 / 3/8

GAS mm/in 15.9 / 5/8

mm/in 810 / 31.9

46

Engineering & Physical Data ACK-E-2009

General Data - Cooling Only (R410A)

MODEL

NOMINAL COOLING CAPACITY - 1Ø / <3Ø>

NOMINAL TOTAL INPUT POWER (COOLING) - 1Ø / <3Ø> W 2820 / <2770> 3920 / <3840>

NOMINAL RUNNING CURRENT - 1Ø / <3Ø> A 13.6 / <5.2> 17.8 / <6.9>

POWER SOURCE - 1Ø <3Ø>

EER - 1Ø / <3Ø> W/W 3.03 / <3.28> 2.92 / <2.98>

REFRIGERANT TYPE R410A R410A

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 490 / 1030 490 / 1030

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) Pa (in.wg.) 00

SOUND PRESSURE LEVEL (H/M/L) dBA 44 / 41 / 38 44 / 41 / 38

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

WEIGHT (UNIT + PANEL) kg/lb 42+6 / 92.6+13.2 42+6 / 92.6+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75 19.1 / 0.75

AIR FLOW l/s / CFM 1605 / 3400 1605 / 3400

SOUND PRESSURE LEVEL dBA 58 58

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 95 / 209 100 / 221

PIPE CONNECTION

REFRIGERANT CHARGE - 1Ø / <3Ø> kg/lb 2.175 / 4.80 / <2.15 / 4.74> 2.45 / 5.40 / <2.425 / 5.35>

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL SPECIFICATIONS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.5m BELOW FASCIA.

MEDIUM l/s / CFM 410 / 860 410 / 860

LOW l/s / CFM 350 / 740 350 / 740

INDOOR UNIT A5CK 40E A5CK 40E

OUTDOOR UNIT A5LC 35C A5LC 40C

Btu/h 29200 / <31000> 39000 / <39000>

W 8558 / <9086> 11430 / <11430>

V/Ph/Hz

HEIGHT mm/in 300 (375) / 11.81 (14.76) 300 (375) / 11.81 (14.76)

WIDTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

DEPTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

HEIGHT mm/in 335 (110) / 13.19 (4.3) 335 (110) / 13.19 (4.3)

WIDTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 850 / 33.5 850 / 33.5

WIDTH mm/in 1030 / 40.6 1030 / 40.6

DEPTH mm/in 400 / 15.8 400 / 15.8

HEIGHT

WIDTH mm/in 1200 / 47.2 1200 / 47.2

DEPTH mm/in 560 / 22.1 560 / 22.1

TYPE FLARE VALVE FLARE VALVE

SIZE

LIQUID mm/in 9.5 / 3/8 9.5 / 3/8

GAS mm/in 15.8 / 5/8 15.9 / 5/8

mm/in 1000 / 39.4 1000 / 39.4

220 - 240 / 1 / 50 /

<380 - 415 / 3 / 50>

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

220 - 240 / 1 / 50 /

<380 - 415 / 3 / 50>

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

47

ACK-E-2009 Engineering & Physical Data

General Data - Cooling Only (R410A)

MODEL

NOMINAL CAPACITY

NOMINAL TOTAL INPUT POWER W 4390

NOMINAL RUNNING CURRENT A 7.6

POWER SOURCE V/Ph/Hz 380 - 415 / 3 / 50

EER W/W 2.87

REFRIGERANT TYPE R410A

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 570 / 1200

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) Pa (in.wg.) 0

SOUND PRESSURE LEVEL (H/M/L) dBA 47 / 44 / 43

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

WEIGHT (UNIT + PANEL) kg/lb 42+6 / 92.6+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75

AIR FLOW l/s / CFM 2171 / 4600

SOUND PRESSURE LEVEL dBA 68

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 105 / 231.5

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 2.3 / 5.07

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL SPECIFICATIONS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS B 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.5m BELOW FASCIA.

MEDIUM l/s / CFM 490 / 1030

LOW l/s / CFM 440 / 930

INDOOR UNIT A5CK 50E

OUTDOOR UNIT A5LC 50C

Btu/h 43000

W 12603

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

HEIGHT mm/in 300 (375) / 11.81 (14.76)

WIDTH mm/in 820 (990) / 32.3 (38.98)

DEPTH mm/in 820(990) / 32.3 (38.98)

HEIGHT mm/in 335 (110) / 13.19 (4.3)

WIDTH mm/in 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 850 / 33.46

WIDTH mm/in 1030 / 40.55

DEPTH mm/in 400 / 15.75

HEIGHT

WIDTH mm/in 1200 / 47.24

DEPTH mm/in 560 / 22.05

TYPE FLARE VALVE

SIZE

LIQUID mm/in 9.5 / 3/8

GAS mm/in 15.9 / 5/8

mm/in 1000 / 39.37

48

Engineering & Physical Data ACK-E-2009

General Data - Heat Pump (R410A)

MODEL

NOMINAL COOLING CAPACITY

NOMINAL HEATING CAPACITY

NOMINAL TOTAL INPUT POWER (COOLING) W 1740 1940

NOMINAL TOTAL INPUT POWER (HEATING) W 1490 1760

NOMINAL RUNNING CURRENT (COOLING) A 7.7 8.7

NOMINAL RUNNING CURRENT (HEATING) A 6.6 7.9

POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 220 - 240 / 1 / 50

EER W/W 3.08 3.36

COP W/W 3.48 3.41

REFRIGERANT TYPE R410A R410A

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 280 / 600 320 / 680

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) Pa (in.wg.) 00

SOUND PRESSURE LEVEL (H/M/L) dBA 34 / 31 / 28 37 / 34 / 31

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

WEIGHT (UNIT + PANEL) kg/lb 29+6 / 63.9+13.2 29+6 / 63.9+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 3/4 19.1 / 3/4

AIR FLOW l/s / CFM 614 / 1300 755 / 1600

SOUND PRESSURE LEVEL dBA 52 52

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 59 / 130 62 / 137

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 1.75 / 3.86 1.85 / 4.08

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS C 9612 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.4m BELOW FASCIA.

MEDIUM l/s / CFM 250 / 530 280 / 600

LOW l/s / CFM 200 / 430 250 / 530

INDOOR UNIT A5CK 20ER A5CK 25ER

OUTDOOR UNIT A5LC 20CR A5LC 25CR

Btu/h 18300 22200

W 5363 6506

Btu/h 17700 20500

W 5188 6008

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

HEIGHT mm/in 265 (340) / 10.43 (13.39) 265 (340) / 10.43 (13.39)

WIDTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

DEPTH mm/in 820(990) / 32.3 (38.98) 820(990) / 32.3 (38.98)

HEIGHT mm/in 300 (110) / 11.8 (4.33) 300 (110) / 11.8 (4.33)

WIDTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 654 / 25.7 756 / 29.8

WIDTH mm/in 855 / 33.7 855 / 33.7

DEPTH mm/in 328 / 12.9 328 / 12.9

HEIGHT

WIDTH mm/in 990 / 39.0 990 / 39.0

DEPTH mm/in 415 / 16.3 415 / 16.3

TYPE FLARE VALVE FLARE VALVE

SIZE

LIQUID mm/in 6.4 / 1/4 6.4 / 1/4

GAS mm/in 12.7 / 1/2 15.9 / 5/8

mm/in 710 / 28.0 810 / 31.9

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

49

ACK-E-2009 Engineering & Physical Data

General Data - Heat Pump (R410A)

MODEL

NOMINAL COOLING CAPACITY

NOMINAL HEATING CAPACITY

NOMINAL TOTAL INPUT POWER (COOLING) W 2790

NOMINAL TOTAL INPUT POWER (HEATING) W 2320

NOMINAL RUNNING CURRENT (COOLING) A 13.1

NOMINAL RUNNING CURRENT (HEATING) A 11. 2

POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50

EER W/W 2.84

COP W/W 3.53

REFRIGERANT TYPE R410A

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 410 / 860

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) Pa (in.wg.) 0

SOUND PRESSURE LEVEL (H/M/L) dBA 41 / 38 / 35

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

WEIGHT (UNIT + PANEL) kg/lb 29+6 / 63.9+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75

AIR FLOW l/s / CFM 684 / 1450

SOUND PRESSURE LEVEL dBA 54

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 68 / 150

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 2.125 / 4.68

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS C 9612 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.4m BELOW FASCIA.

MEDIUM l/s / CFM 340 / 725

LOW l/s / CFM 290 / 620

INDOOR UNIT A5CK 28ER

OUTDOOR UNIT A5LC 28CR

Btu/h 27000

W 7913

Btu/h 28000

W 8206

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

HEIGHT mm/in 265 (340) / 10.43 (13.39)

WIDTH mm/in 820 (990) / 32.3 (38.98)

DEPTH mm/in 820(990) / 32.3 (38.98)

HEIGHT mm/in 300 (110) / 11.8 (4.33)

WIDTH mm/in 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 756 / 29.8

WIDTH mm/in 855 / 33.7

DEPTH mm/in 328 / 12.9

HEIGHT

WIDTH mm/in 990 / 39.0

DEPTH

TYPE FLARE VALVE

SIZE

LIQUID mm/in 9.5 / 3/8

GAS mm/in 15.9 / 5/8

mm/in 810 / 31.9

mm/in 415 / 16.3

50

Engineering & Physical Data ACK-E-2009

General Data - Heat Pump (R410A)

MODEL

NOMINAL COOLING CAPACITY - 1Ø / <3Ø>

NOMINAL HEATING CAPACITY - 1Ø / <3Ø>

NOMINAL TOTAL INPUT POWER (COOLING) - 1Ø / <3Ø> W 2820 / <2770> 3920/ <3840>

NOMINAL TOTAL INPUT POWER (HEATING) - 1Ø / <3Ø> W 2550 / <2550> 3740 / <3610>

NOMINAL RUNNING CURRENT (COOLING) - 1Ø / <3Ø> A 13.6 / <5.2> 17.8 / <6.9>

NOMINAL RUNNING CURRENT (HEATING) - 1Ø / <3Ø> A 12.7 / <5.0> 17.2 / <6.6>

POWER SOURCE - 1Ø <3Ø>

EER - 1Ø / <3Ø> W/W 3.03 / <3.28> 2.92 / <2.98>

COP - 1Ø / <3Ø> W/W 3.66 / <3.84> 3.06 / <3.21>

REFRIGERANT TYPE R410A R410A

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE OUTDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 490 / 1030 490 / 1030

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) Pa (in.wg.) 00

SOUND PRESSURE LEVEL (H/M/L) dBA 44 / 41 / 38 44 / 41 / 38

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

WEIGHT (UNIT + PANEL) kg/lb 42+6 / 92.6+13.2 42+6 / 92.6+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75 19.1 / 0.75

AIR FLOW l/s / CFM 1605 / 3400 1605 / 3400

SOUND PRESSURE LEVEL dBA 58 58

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 95 / 209 100 / 221

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 2.175 / 4.80 / <2.15 / 4.74> 2.45 / 5.40 / <2.425 / 4.35>

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS C 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.5m BELOW FASCIA.

MEDIUM l/s / CFM 410 / 860 410 / 860

LOW l/s / CFM 350 / 740 350 / 740

INDOOR UNIT A5CK 40ER A5CK 40ER

OUTDOOR UNIT A5LC 35CR A5LC 40CR

Btu/h 29200 / <31000> 39000 / <39000>

W 8558 / <9086> 11430 / <11430>

Btu/h 31800 / <33400> 39000 / <39500>

W 9320 / <9789> 11430 / <11577>

V/Ph/Hz

HEIGHT mm/in 300 (375) / 11.81 (14.76) 300 (375) / 11.81 (14.76)

WIDTH mm/in 820 (990) / 32.3 (38.98) 820 (990) / 32.3 (38.98)

DEPTH mm/in 820(990) / 32.3 (38.98) 820(990) / 32.3 (38.98)

HEIGHT mm/in 335 (110) / 13.19 (4.3) 335 (110) / 13.19 (4.3)

WIDTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6) 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 850 / 33.5 850 / 33.5

WIDTH mm/in 1030 / 40.6 1030 / 40.6

DEPTH mm/in 400 / 15.8 400 / 15.8

HEIGHT

WIDTH mm/in 1200 / 47.2 1200 / 47.2

DEPTH mm/in 560 / 22.1 560 / 22.1

TYPE FLARE VALVE FLARE VALVE

SIZE

LIQUID mm/in 9.51 / 3/8 9.5 / 3/8

GAS mm/in 15.9 / 5/8 15.9 / 5/8

mm/in 1000 / 39.4 1000 / 39.4

220 - 240 / 1 / 50 /

<380 - 415 / 3 / 50>

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

220 - 240 / 1 / 50 /

<380 - 415 / 3 / 50>

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

51

ACK-E-2009 Engineering & Physical Data

General Data - Heat Pump (R410A)

MODEL

NOMINAL COOLING CAPACITY

NOMINAL HEATING CAPACITY

NOMINAL TOTAL INPUT POWER (COOLING) W 4390

NOMINAL TOTAL INPUT POWER (HEATING) W 4010

NOMINAL RUNNING CURRENT (COOLING) A 7.6

NOMINAL RUNNING CURRENT (HEATING) A 7.2

POWER SOURCE V/Ph/Hz 380 - 415 / 3 / 50

EER W/W 2.87

COP W/W 3.46

REFRIGERANT TYPE R410A

REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAP. TUBE

AIR DISCHARGE

CONTROL

OPERATION

HIGH l/s / CFM 570 / 1200

AIR FLOW

EXTERNAL STATIC PRESSURE (H/M/L) Pa (in.wg.) 0

SOUND PRESSURE LEVEL (H/M/L) dBA 47 / 44 / 43

UNIT DIMENSION

INDOOR UNIT

( ) - WITH PANEL

PACKING DIMENSION
( ) - PANEL

WEIGHT (UNIT + PANEL) kg/lb 42+6 / 92.6+13.2

CONDENSATE DRAIN SIZE mm/in 19.1 / 0.75

AIR FLOW l/s / CFM 2171 / 4600

SOUND PRESSURE LEVEL dBA 68

UNIT DIMENSION

PACKING DIMENSION

OUTDOOR UNIT

UNIT WEIGHT kg/lb 105 / 232

PIPE CONNECTION

REFRIGERANT CHARGE kg/lb 2.3 / 5.07

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151.

3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 27°C DB / 19°C WB INDOOR AND 35°C DB / 24°C WB OUTDOOR
b) HEATING - 20°C DB INDOOR AND 7°C DB / 6°C WB OUTDOOR

4) SOUND PRESSURE LEVEL ARE ACCORDING TO JIS C 8615 STANDARD. POSITION OF THE MEASUREMENT POINT IS 1.5m BELOW FASCIA.

MEDIUM l/s / CFM 490 / 1030

LOW l/s / CFM 440 / 930

INDOOR UNIT A5CK 50ER

OUTDOOR UNIT A5LC 50CR

Btu/h 43000

W 12603

Btu/h 47300

W 13863

4 WAY AUTOMATIC LOUVER

(UP & DOWN)

WIRELESS OR WIRED MICRO-

COMPUTER REMOTE CONTROL

HEIGHT mm/in 300 (375) / 11.81 (14.76)

WIDTH mm/in 820 (990) / 32.3 (38.98)

DEPTH mm/in 820(990) / 32.3 (38.98)

HEIGHT mm/in 335 (110) / 13.19 (4.3)

WIDTH mm/in 916 (1030) / 36.1 (40.6)

DEPTH mm/in 916 (1030) / 36.1 (40.6)

HEIGHT mm/in 850 / 33.5

WIDTH mm/in 1030 / 40.6

DEPTH mm/in 400 / 15.8

HEIGHT

WIDTH mm/in 1200 / 47.2

DEPTH

TYPE FLARE VALVE

SIZE

LIQUID mm/in 9.5 / 3/8

GAS mm/in 15.9 / 5/8

mm/in 1000 / 39.4

mm/in 560 / 22.1

52

Engineering & Physical Data ACK-E-2009

Component Data - Cooling Only (R22)

MODEL

INDOOR UNIT ACK 20E ACK 25E

OUTDOOR UNIT ALC 20C ALC 25C

TYPE BLOWER WHEEL BLOWER WHEEL

QUANTITY 11

INDOOR FAN

MATERIAL ASG 10% ASG 10%

DRIVE DIRECT DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18 462 / 18.18

171 / 6.13 171 / 6.13

TYPE INDUCTION INDUCTION

INDOOR FAN MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) 20 20

TYPE PROPELLER PROPELLER

QUANTITY 11

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT DIRECT

DIAMETER

mm/in

457 / 18 457 / 18

TYPE INDUCTION INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) IP54 IP54

TYPE ROTARY ROTARY

COMPRESSOR

INDOOR COIL

OIL TYPE ATMOS NM56M or SUNISO 4GDID ATMOS NM56M or SUNISO 4GDID

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

670 / 23.6 670 / 23.6

SEAMLESS INNER GROOVED COPPER SEAMLESS INNER GROOVED COPPER

7 / 0.27 7 / 0.27

0.24 / 0.01 0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

2

m

/ft

2

0.11 / 0.004 0.11 / 0.004

0.386 / 4.15 0.386 / 4.15

ROW 22

FIN PER INCH 18 18

SEAMLESS INNER GROOVE COPPER SEAMLESS INNER GROOVE COPPER

7.00 / 0.276 7.00 / 0.276

0.28 / 0.011 0.28 / 0.011

0.10 / 0.004 0.10 / 0.004

2

2

/ft

0.52 / 5.59 0.52 / 5.59

OUTDOOR COIL

TUBE

FIN

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (RAISE LANCE) ALUMINIUM (RAISE LANCE)

THICKNESS

FACE AREA

mm/in

m

ROW 12

FIN PER INCH 20 24

TYPE WASHABLE SARANET FILTER WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL HOT DIP GALVANIZED STEEL

WITH PE INSULATION WITH PE INSULATION

GALVANIZED MILD STEEL GALVANIZED MILD STEEL

POLYESTER POWDER POLYESTER POWDER

11

576.0 / 22.7 576.0 / 22.7

556.0 / 21.9 556.0 / 21.9

2 / 0.078 2 / 0.078

ABS ABS

N/A N/A

LIGHT GREY LIGHT GREY

WITHOUT PAINT WITHOUT PAINT

LIGHT GREY LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

GLASS REINFORCED ACRYL

STYRENE RESIN

53

ACK-E-2009 Engineering & Physical Data

Component Data - Cooling Only (R22)

MODEL

INDOOR UNIT ACK 28E

OUTDOOR UNIT ALC 28C

TYPE BLOWER WHEEL

QUANTITY 1

INDOOR FAN

MATERIAL ASG 10%

DRIVE DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18

171 / 6.13

TYPE INDUCTION

INDOOR FAN MOTOR

QUANTITY 1

INDEX OF PROTECTION (IP) 20

TYPE PROPELLER

QUANTITY 1

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT

DIAMETER

mm/in

457 / 18

TYPE INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 1

INDEX OF PROTECTION (IP) IP54

TYPE ROTARY

COMPRESSOR

INDOOR COIL

OIL TYPE ATMOS M60 or SUNISO 4GDID

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

1130 / 39.8

SEAMLESS INNER GROOVED COPPER

7 / 0.27

0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

2

m

/ft

2

0.11 / 0.004

0.372 / 4.0

ROW 3

FIN PER INCH 18

SEAMLESS INNER GROOVE COPPER

9.52 / 3/8

0.33 / 0.013

0.12 / 0.005

2

2

/ft

0.61 / 6.52

OUTDOOR COIL

TUBE

FIN

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (SLIT FIN)

THICKNESS

FACE AREA

mm/in

m

ROW 2

FIN PER INCH 18

TYPE WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL

WITH PE INSULATION

GALVANIZED MILD STEEL

POLYESTER POWDER

1

576.0 / 22.7

556.0 / 21.9

2 / 0.078

ABS

N/A

LIGHT GREY

WITHOUT PAINT

LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

54

Engineering & Physical Data ACK-E-2009

Component Data - Cooling Only (R22)

MODEL

INDOOR UNIT ACK 40E ACK 40E

OUTDOOR UNIT ALC 35C ALC 40C

TYPE BLOWER WHEEL BLOWER WHEEL

QUANTITY 11

INDOOR FAN

MATERIAL ASG 10% ASG 10%

DRIVE DIRECT DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18 462 / 18.18

171 / 6.13 171 / 6.13

TYPE INDUCTION INDUCTION

INDOOR FAN MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) 20 20

TYPE PROPELLER PROPELLER

QUANTITY 11

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT DIRECT

DIAMETER

mm/in

609.6 / 24 609.6 / 24

TYPE INDUCTION INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) --

TYPE SCROLL SCROLL

COMPRESSOR

INDOOR COIL

OIL TYPE MINERAL (Sontex 200 LT) MINERAL (Sontex 200 LT)

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

1240 / 43.6 1240 / 43.6

SEAMLESS INNER GROOVED COPPER SEAMLESS INNER GROOVED COPPER

7 / 0.27 7 / 0.27

0.24 / 0.01 0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

2

m

/ft

2

0.11 / 0.004 0.11 / 0.004

0.461 / 4.96 0.461 / 4.96

ROW 33

FIN PER INCH 20 20

MATERIAL SEAMLESS COPPER SEAMLESS COPPER

OUTDOOR COIL

TUBE

FIN

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (CORR. FIN)

THICKNESS

FACE AREA

mm/in

m2/ft

2

9.52 / 3/8 9.52 / 3/8

0.35 / 0.014 0.35 / 0.014

0.127 / 0.005 0.127 / 0.005

0.87 / 9.33 0.87 / 9.33

ROW 12

FIN PER INCH 16 14

TYPE WASHABLE SARANET FILTER WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL HOT DIP GALVANIZED STEEL

WITH PE INSULATION WITH PE INSULATION

GALVANIZED MILD STEEL GALVANIZED MILD STEEL

POLYESTER POWDER POLYESTER POWDER

11

576.0 / 22.7 576.0 / 22.7

556.0 / 21.9 556.0 / 21.9

2 / 0.078 2 / 0.078

ABS ABS

N/A N/A

LIGHT GREY LIGHT GREY

WITHOUT PAINT WITHOUT PAINT

LIGHT GREY LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

GLASS REINFORCED ACRYL

STYRENE RESIN

55

ACK-E-2009 Engineering & Physical Data

Component Data - Cooling Only (R22)

MODEL

INDOOR UNIT ACK 50E

OUTDOOR UNIT ALC 50C

TYPE BLOWER WHEEL

QUANTITY 1

INDOOR FAN

MATERIAL ASG 10%

DRIVE DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18

171 / 6.13

TYPE INDUCTION

INDOOR FAN MOTOR

QUANTITY 1

INDEX OF PROTECTION (IP) 20

TYPE PROPELLER

QUANTITY 1

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT

DIAMETER

mm/in

609.6 / 24

TYPE PROPELLER
OUTDOOR FAN
MOTOR

QUANTITY 1

INDEX OF PROTECTION (IP) -

TYPE SCROLL

COMPRESSOR

INDOOR COIL

OIL TYPE MINERAL (Sontex 200 LT)

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

1950 / 68.6

SEAMLESS INNER GROOVED COPPER

7 / 0.27

0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

2

m

/ft

2

0.11 / 0.004

0.464 / 4.988

ROW 3

FIN PER INCH 20

MATERIAL SEAMLESS COPPER

OUTDOOR COIL

TUBE

FIN

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (CORR. FIN)

THICKNESS

FACE AREA

mm/in

m2/ft

2

9.52 / 3/8

0.35 / 0.014

0.127 / 0.005

0.87 / 9.33

ROW 2

FIN PER INCH 16

TYPE WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL

WITH PE INSULATION

GALVANIZED MILD STEEL

POLYESTER POWDER

1

576.0 / 22.7

556.0 / 21.9

2 / 0.078

ABS

N/A

LIGHT GREY

WITHOUT PAINT

LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

56

Engineering & Physical Data ACK-E-2009

Component Data - Heat Pump (R22)

MODEL

INDOOR UNIT ACK 20ER ACK 25ER

OUTDOOR UNIT ALC 20CR ALC 25CR

TYPE BLOWER WHEEL BLOWER WHEEL

QUANTITY 11

INDOOR FAN

MATERIAL ASG 10% ASG 10%

DRIVE DIRECT DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18 462 / 18.18

171 / 6.13 171 / 6.13

TYPE INDUCTION INDUCTION

INDOOR FAN MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) 20 20

TYPE PROPELLER PROPELLER

QUANTITY 11

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT DIRECT

DIAMETER

mm/in

457 / 18 457 / 18

TYPE INDUCTION INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) IP54 IP54

TYPE ROTARY ROTARY

COMPRESSOR

INDOOR COIL

OIL TYPE ATMOS NM56M or SUNISO 4GDID ATMOS NM56M or SUNISO 4GDID

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

670 / 23.6 670 / 23.6

SEAMLESS INNER GROOVED COPPER SEAMLESS INNER GROOVED COPPER

7 / 0.27 7 / 0.27

0.24 / 0.01 0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

2

m

/ft

2

0.11 / 0.004 0.11 / 0.004

0.386 / 4.15 0.386 / 4.15

ROW 22

FIN PER INCH 18 18

SEAMLESS INNER GROOVE COPPER SEAMLESS INNER GROOVE COPPER

7.00 / 0.276 7.00 / 0.276

0.28 / 0.011 0.28 / 0.011

0.10 / 0.004 0.10 / 0.004

2

2

/ft

0.52 / 5.59 0.52 / 5.59

OUTDOOR COIL

TUBE

FIN

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (RAISE LANCE) ALUMINIUM (RAISE LANCE)

THICKNESS

FACE AREA

mm/in

m

ROW 12

FIN PER INCH 20 24

TYPE WASHABLE SARANET FILTER WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL HOT DIP GALVANIZED STEEL

WITH PE INSULATION WITH PE INSULATION

GALVANIZED MILD STEEL GALVANIZED MILD STEEL

POLYESTER POWDER POLYESTER POWDER

11

576.0 / 22.7 576.0 / 22.7

556.0 / 21.9 556.0 / 21.9

2 / 0.078 2 / 0.078

ABS ABS

N/A N/A

LIGHT GREY LIGHT GREY

WITHOUT PAINT WITHOUT PAINT

LIGHT GREY LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

GLASS REINFORCED ACRYL

STYRENE RESIN

57

ACK-E-2009 Engineering & Physical Data

Component Data - Heat Pump (R22)

MODEL

INDOOR UNIT ACK 28ER ACK 28ER

OUTDOOR UNIT ALC 28CR ALC 28CR

TYPE BLOWER WHEEL BLOWER WHEEL

QUANTITY 11

INDOOR FAN

MATERIAL ASG 10% ASG 10%

DRIVE DIRECT DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18 462 / 18.18

171 / 6.13 171 / 6.13

TYPE INDUCTION INDUCTION

INDOOR FAN MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) 20 20

TYPE PROPELLER PROPELLER

QUANTITY 11

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT DIRECT

DIAMETER

mm/in

457 / 18 609.6 / 24

TYPE INDUCTION INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) IP54 IP54

TYPE ROTARY ROTARY

COMPRESSOR

INDOOR COIL

OIL TYPE ATMOS M60 or SUNISO 4GDID ATMOS M60 or SUNISO 4GDID

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

1130 / 39.8 1130 / 39.8

SEAMLESS INNER GROOVED COPPER SEAMLESS INNER GROOVED COPPER

7 / 0.27 7 / 0.27

0.24 / 0.01 0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

2

m

/ft

2

0.11 / 0.004 0.11 / 0.004

0.372 / 4.0 0.372 / 4.0

ROW 33

FIN PER INCH 18 18

SEAMLESS INNER GROOVE COPPER SEAMLESS INNER GROOVE COPPER

9.52 / 3/8 9.52 / 3/8

0.33 / 0.013 0.33 / 0.013

0.12 / 0.005 0.12 / 0.005

2

2

/ft

0.61 / 6.52 0.61 / 6.52

OUTDOOR COIL

TUBE

FIN

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (SLIT FIN)

THICKNESS

FACE AREA

mm/in

m

ROW 22

FIN PER INCH 18 18

TYPE WASHABLE SARANET FILTER WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL HOT DIP GALVANIZED STEEL

WITH PE INSULATION WITH PE INSULATION

GALVANIZED MILD STEEL GALVANIZED MILD STEEL

POLYESTER POWDER POLYESTER POWDER

11

576.0 / 22.7 576.0 / 22.7

556.0 / 21.9 556.0 / 21.9

2 / 0.078 2 / 0.078

ABS ABS

N/A N/A

LIGHT GREY LIGHT GREY

WITHOUT PAINT WITHOUT PAINT

LIGHT GREY LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

GLASS REINFORCED ACRYL

STYRENE RESIN

58

Engineering & Physical Data ACK-E-2009

Component Data - Heat Pump (R22)

MODEL

INDOOR UNIT ACK 40ER ACK 40ER

OUTDOOR UNIT ALC 35CR ALC 40CR

TYPE BLOWER WHEEL BLOWER WHEEL

QUANTITY 11

INDOOR FAN

MATERIAL ASG 10% ASG 10%

DRIVE DIRECT DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18 462 / 18.18

171 / 6.13 171 / 6.13

TYPE INDUCTION INDUCTION

INDOOR FAN MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) 20 20

TYPE PROPELLER PROPELLER

QUANTITY 11

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT DIRECT

DIAMETER

mm/in

609.6 / 24 609.6 / 24

TYPE INDUCTION INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) --

TYPE SCROLL SCROLL

COMPRESSOR

INDOOR COIL

OIL TYPE MINERAL (Sontex 200 LT) MINERAL (Sontex 200 LT)

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

1240 / 43.6 1240 / 43.6

SEAMLESS INNER GROOVED COPPER SEAMLESS INNER GROOVED COPPER

7 / 0.27 7 / 0.27

0.24 / 0.01 0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

2

m

/ft

2

0.11 / 0.004 0.11 / 0.004

0.461 / 4.96 0.461 / 4.96

ROW 33

FIN PER INCH 20 20

SEAMLESS INNER GROOVED COPPER SEAMLESS INNER GROOVED COPPER

9.52 / 3/8 9.52 / 3/8

0.33 / 0.013 0.33 / 0.013

0.127 / 0.005 0.127 / 0.005

2

2

/ft

0.87 / 9.33 0.87 / 9.33

OUTDOOR COIL

TUBE

FIN

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (CORR. FIN) ALUMINIUM (CORR. FIN)

THICKNESS

FACE AREA

mm/in

m

ROW 22

FIN PER INCH 16 16

TYPE WASHABLE SARANET FILTER WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL HOT DIP GALVANIZED STEEL

WITH PE INSULATION WITH PE INSULATION

GALVANIZED MILD STEEL GALVANIZED MILD STEEL

POLYESTER POWDER POLYESTER POWDER

11

576.0 / 22.7 576.0 / 22.7

556.0 / 21.9 556.0 / 21.9

2 / 0.078 2 / 0.078

ABS ABS

N/A N/A

LIGHT GREY LIGHT GREY

WITHOUT PAINT WITHOUT PAINT

LIGHT GREY LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

GLASS REINFORCED ACRYL

STYRENE RESIN

59

ACK-E-2009 Engineering & Physical Data

Component Data - Heat Pump (R22)

MODEL

INDOOR UNIT ACK 50ER

OUTDOOR UNIT ALC 50CR

TYPE BLOWER WHEEL

QUANTITY 1

INDOOR FAN

MATERIAL ASG 10%

DRIVE DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18

171 / 6.13

TYPE INDUCTION

INDOOR FAN MOTOR

QUANTITY 1

INDEX OF PROTECTION (IP) 20

TYPE PROPELLER

QUANTITY 1

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT

DIAMETER

mm/in

609.6 / 24

TYPE INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 1

INDEX OF PROTECTION (IP) -

TYPE SCROLL

COMPRESSOR

INDOOR COIL

OIL TYPE MINERAL (Sontex 200 LT)

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

1950 / 68.6

SEAMLESS INNER GROOVED COPPER

7 / 0.27

0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

2

m

/ft

2

0.11 / 0.004

0.464 / 4.988

ROW 3

FIN PER INCH 20

SEAMLESS INNER GROOVED COPPER

9.52 / 3/8

0.33 / 0.013

0.127 / 0.005

2

2

/ft

0.87 / 9.33

OUTDOOR COIL

TUBE

FIN

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (CORR. FIN)

THICKNESS

FACE AREA

mm/in

m

ROW 2

FIN PER INCH 16

TYPE WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL

WITH PE INSULATION

GALVANIZED MILD STEEL

POLYESTER POWDER

1

576.0 / 22.7

556.0 / 21.9

2 / 0.078

ABS

N/A

LIGHT GREY

WITHOUT PAINT

LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

60

Engineering & Physical Data ACK-E-2009

Component Data - Cooling Only (R410A)

MODEL

INDOOR UNIT A5CK 20E A5CK 25E

OUTDOOR UNIT A5LC 20C A5LC 25C

TYPE BLOWER WHEEL BLOWER WHEEL

QUANTITY 11

INDOOR FAN

MATERIAL ASG 10% ASG 10%

DRIVE DIRECT DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18 462 / 18.18

171 / 6.13 171 / 6.13

TYPE INDUCTION INDUCTION

INDOOR FAN MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) 20 20

TYPE PROPELLER PROPELLER

QUANTITY 11

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT DIRECT

DIAMETER

mm/in

457 / 18 457 / 18

TYPE INDUCTION INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) IP54 IP54

TYPE ROTARY ROTARY

COMPRESSOR

INDOOR COIL

OIL TYPE RB68A or Freol Alpha68M RB68A or Freol Alpha68M

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

670 / 23.6 1130 / 39.8

SEAMLESS INNER GROOVED COPPER SEAMLESS INNER GROOVED COPPER

7 / 0.27 7 / 0.27

0.24 / 0.01 0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

2

m

/ft

2

0.11 / 0.004 0.11 / 0.004

0.386 / 4.15 0.386 / 4.15

ROW 22

FIN PER INCH 18 18

SEAMLESS INNER GROOVE COPPER SEAMLESS INNER GROOVE COPPER

7.00 / 0.276 7.00 / 0.276

0.28 / 0.011 0.28 / 0.011

0.10 / 0.004 0.10 / 0.004

2

2

/ft

0.510 / 5.460 0.620 / 6.630

OUTDOOR COIL

TUBE

FIN

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (RAISE LANCE) ALUMINIUM (RAISE LANCE)

THICKNESS

FACE AREA

mm/in

m

ROW 22

FIN PER INCH 18 18

TYPE WASHABLE SARANET FILTER WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL HOT DIP GALVANIZED STEEL

WITH PE INSULATION WITH PE INSULATION

GALVANIZED MILD STEEL GALVANIZED MILD STEEL

POLYESTER POWDER POLYESTER POWDER

11

576.0 / 22.7 576.0 / 22.7

556.0 / 21.9 556.0 / 21.9

2 / 0.078 2 / 0.078

ABS ABS

N/A N/A

LIGHT GREY LIGHT GREY

WITHOUT PAINT WITHOUT PAINT

LIGHT GREY LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

GLASS REINFORCED ACRYL

STYRENE RESIN

61

ACK-E-2009 Engineering & Physical Data

Component Data - Cooling Only (R410A)

MODEL

INDOOR UNIT A5CK 28E

OUTDOOR UNIT A5LC 28C

TYPE BLOWER WHEEL

QUANTITY 1

INDOOR FAN

MATERIAL ASG 10%

DRIVE DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18

171 / 6.13

TYPE INDUCTION

INDOOR FAN MOTOR

QUANTITY 1

INDEX OF PROTECTION (IP) IP22

TYPE PROPELLER

QUANTITY 1

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT

DIAMETER

mm/in

457 / 18

TYPE INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 1

INDEX OF PROTECTION (IP) IP54

TYPE ROTARY

COMPRESSOR

INDOOR COIL

OIL TYPE RB68A or Freol Alpha68M

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

SEAMLESS INNER GROOVED COPPER

1130 / 39.8

7 / 0.27

0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

m2/ft

2

0.11 / 0.004

0.372 / 4.0

ROW 3

FIN PER INCH 18

SEAMLESS INNER GROOVE COPPER

7.00 / 0.276

0.28 / 0.011

0.11 / 0.0043

2

2

/ft

0.620 / 6.630

OUTDOOR COIL

TUBE

FIN

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (CORR. FIN)

THICKNESS

FACE AREA

mm/in

m

ROW 2

FIN PER INCH 18

TYPE WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL

WITH PE INSULATION

GALVANIZED MILD STEEL

POLYESTER POWDER

1

576.0 / 22.7

556.0 / 21.9

2 / 0.078

ABS

N/A

LIGHT GREY

WITHOUT PAINT

LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

62

Engineering & Physical Data ACK-E-2009

Component Data - Cooling Only (R410A)

MODEL

INDOOR UNIT A5CK 40E A5CK 40E

OUTDOOR UNIT A5LC 35C A5LC 40C

TYPE BLOWER WHEEL BLOWER WHEEL

QUANTITY 11

INDOOR FAN

MATERIAL ASG 10% ASG 10%

DRIVE DIRECT DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18 462 / 18.18

171 / 6.13 171 / 6.13

TYPE INDUCTION INDUCTION

INDOOR FAN MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) IP22 IP22

TYPE PROPELLER PROPELLER

QUANTITY 11

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT DIRECT

DIAMETER

mm/in

609.6 / 24 609.6 / 24

TYPE INDUCTION INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) --

TYPE SCROLL SCROLL

COMPRESSOR

INDOOR COIL

OIL TYPE MOBIL EAL ARCTIC 22CC MOBIL EAL ARCTIC 22CC

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

SEAMLESS INNER GROOVED COPPER SEAMLESS INNER GROOVED COPPER

1242 / 43.7 1951 / 68.7

7 / 0.27 7 / 0.27

0.24 / 0.01 0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

m2/ft

2

0.11 / 0.004 0.11 / 0.004

0.461 / 4.96 0.461 / 4.96

ROW 33

FIN PER INCH 20 20

SEAMLESS INNER GROOVE COPPER SEAMLESS INNER GROOVE COPPER

7.00 / 0.276 7.00 / 0.276

0.28 / 0.011 0.28 / 0.011

0.10 / 0.0039 0.10 / 0.0039

2

2

/ft

0.87 / 9.33 0.87 / 9.33

OUTDOOR COIL

TUBE

FIN

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (CORR. FIN) ALUMINIUM (CORR. FIN)

THICKNESS

FACE AREA

mm/in

m

ROW 22

FIN PER INCH 18 18

TYPE WASHABLE SARANET FILTER WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL HOT DIP GALVANIZED STEEL

WITH PE INSULATION WITH PE INSULATION

GALVANIZED MILD STEEL GALVANIZED MILD STEEL

POLYESTER POWDER POLYESTER POWDER

11

576.0 / 22.7 576.0 / 22.7

556.0 / 21.9 556.0 / 21.9

2 / 0.078 2 / 0.078

ABS ABS

N/A N/A

LIGHT GREY LIGHT GREY

WITHOUT PAINT WITHOUT PAINT

LIGHT GREY LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

GLASS REINFORCED ACRYL

STYRENE RESIN

63

ACK-E-2009 Engineering & Physical Data

Component Data - Cooling Only (R410A)

MODEL

INDOOR FAN

INDOOR FAN MOTOR

OUTDOOR FAN

OUTDOOR FAN
MOTOR

COMPRESSOR

INDOOR COIL

OUTDOOR COIL

AIR QUALITY FILTER

CASING

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

INDOOR UNIT A5CK 50E

OUTDOOR UNIT A5LC 50C

TYPE BLOWER WHEEL

QUANTITY 1

MATERIAL ASG 10%

DRIVE DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18

171 / 6.13

TYPE INDUCTION

QUANTITY 1

INDEX OF PROTECTION (IP) IP22

TYPE PROPELLER

QUANTITY 1

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT

DIAMETER

mm/in

609.6 / 24

TYPE INDUCTION

QUANTITY 1

INDEX OF PROTECTION (IP) -

TYPE SCROLL

OIL TYPE MOBIL EAL ARCTIC 22CC

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

SEAMLESS INNER GROOVED COPPER

1656 / 58.3

7 / 0.27

0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

m2/ft

2

0.11 / 0.004

0.464 / 4.988

ROW 3

FIN PER INCH 20

SEAMLESS INNER GROOVED COPPER

9.52 / 3/8

0.30 / 0.012

TUBE

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (HYDROPHILIC)

FIN

THICKNESS

FACE AREA

mm/in

2

m

/ft

2

0.11 / 0.0043

0.36 / 3.95

ROW 2

FIN PER INCH 18

TYPE WASHABLE SARANET FILTER

QUANTITY

SIZE

PAN EL

INDOOR UNIT

OUTDOOR UNIT

LENGTH

WIDTH

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL

WITH PE INSULATION

GALVANIZED MILD STEEL

POLYESTER POWDER

1

576.0 / 22.7

556.0 / 21.9

2 / 0.078

ABS

N/A

LIGHT GREY

WITHOUT PAINT

LIGHT GREY

64

Engineering & Physical Data ACK-E-2009

Component Data - Heat Pump (R410A)

MODEL

INDOOR UNIT A5CK 20ER A5CK 25ER

OUTDOOR UNIT A5LC 20CR A5LC 25CR

TYPE BLOWER WHEEL BLOWER WHEEL

QUANTITY 11

INDOOR FAN

MATERIAL ASG 10% ASG 10%

DRIVE DIRECT DIRECT

DIAMETER mm/in 462 / 18.18 462 / 18.18

LENGTH mm/in 171 / 6.13 171 / 6.13

TYPE INDUCTION INDUCTION

INDOOR FAN MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) 20 20

TYPE PROPELLER PROPELLER

QUANTITY 11

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT DIRECT

DIAMETER mm/in 457 / 18 457 / 18

TYPE INDUCTION INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) IP54 IP54

TYPE ROTARY ROTARY

COMPRESSOR

INDOOR COIL

OIL TYPE RB68A or Freol Alpha68M RB68A or Freol Alpha68M

3

OIL AMOUNT cm

MATERIAL

TUBE

DIAMETER

THICKNESS

/ fl .oz. 670 / 23.6 1130 / 39.8

SEAMLESS INNER GROOVED COPPER SEAMLESS INNER GROOVED COPPER

mm/in

mm/in

7 / 0.27 7 / 0.27

0.24 / 0.01 0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

2

/ft

m

2

0.11 / 0.004 0.11 / 0.004

0.386 / 4.15 0.386 / 4.15

ROW 22

FIN PER INCH 18 18

SEAMLESS INNER GROOVE COPPER SEAMLESS INNER GROOVE COPPER

7.00 / 0.276 7.00 / 0.276

0.28 / 0.011 0.28 / 0.011

0.10 / 0.004 0.10 / 0.004

2

2

/ft

0.510 / 5.460 0.620 / 6.630

OUTDOOR COIL

TUBE

FIN

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (RAISE LANCE) ALUMINIUM (RAISE LANCE)

THICKNESS

FACE AREA

mm/in

m

ROW 22

FIN PER INCH 18 18

TYPE WASHABLE SARANET FILTER WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL HOT DIP GALVANIZED STEEL

WITH PE INSULATION WITH PE INSULATION

GALVANIZED MILD STEEL GALVANIZED MILD STEEL

POLYESTER POWDER POLYESTER POWDER

11

576.0 / 22.7 576.0 / 22.7

556.0 / 21.9 556.0 / 21.9

2 / 0.078 2 / 0.078

ABS ABS

N/A N/A

LIGHT GREY LIGHT GREY

WITHOUT PAINT WITHOUT PAINT

LIGHT GREY LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

GLASS REINFORCED ACRYL

STYRENE RESIN

65

ACK-E-2009 Engineering & Physical Data

Component Data - Heat Pump (R410A)

MODEL

INDOOR UNIT A5CK 28ER A5CK 28ER

OUTDOOR UNIT A5LC 28CR A5LC 28CR

TYPE BLOWER WHEEL BLOWER WHEEL

QUANTITY 11

INDOOR FAN

MATERIAL ASG 10% ASG 10%

DRIVE DIRECT DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18 462 / 18.18

171 / 6.13 171 / 6.13

TYPE INDUCTION INDUCTION

INDOOR FAN MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) IP22 IP22

TYPE PROPELLER PROPELLER

QUANTITY 11

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT DIRECT

DIAMETER

mm/in

457 / 18 609.6 / 24

TYPE INDUCTION INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) IP54 -

TYPE ROTARY SCROLL

COMPRESSOR

INDOOR COIL

OIL TYPE RB68A or Freol Alpha68M MOBIL EAL ARCTIC 22C

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

SEAMLESS INNER GROOVED COPPER SEAMLESS INNER GROOVED COPPER

1130 / 39.8 1242 / 43.7

7 / 0.27 7 / 0.27

0.24 / 0.01 0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

m2/ft

2

0.11 / 0.004 0.11 / 0.004

0.372 / 4.0 0.372 / 4.0

ROW 33

FIN PER INCH 18 18

SEAMLESS INNER GROOVE COPPER SEAMLESS INNER GROOVE COPPER

7.00 / 0.276 7.00 / 0.276

0.28 / 0.011 0.28 / 0.011

0.11 / 0.0043 0.11 / 0.0043

2

2

/ft

0.62 / 6.63 0.87 / 9.33

OUTDOOR COIL

TUBE

FIN

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (CORR. FIN) ALUMINIUM (CORR. FIN)

THICKNESS

FACE AREA

mm/in

m

ROW 22

FIN PER INCH 18 18

TYPE WASHABLE SARANET FILTER WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL HOT DIP GALVANIZED STEEL

WITH PE INSULATION WITH PE INSULATION

GALVANIZED MILD STEEL GALVANIZED MILD STEEL

POLYESTER POWDER POLYESTER POWDER

11

576.0 / 22.7 576.0 / 22.7

556.0 / 21.9 556.0 / 21.9

2 / 0.078 2 / 0.078

ABS ABS

N/A N/A

LIGHT GREY LIGHT GREY

WITHOUT PAINT WITHOUT PAINT

LIGHT GREY LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

GLASS REINFORCED ACRYL

STYRENE RESIN

66

Engineering & Physical Data ACK-E-2009

Component Data - Heat Pump (R410A)

MODEL

INDOOR UNIT A5CK 40ER A5CK 40ER

OUTDOOR UNIT A5LC 35CR A5LC 40CR

TYPE BLOWER WHEEL BLOWER WHEEL

QUANTITY 11

INDOOR FAN

MATERIAL ASG 10% ASG 10%

DRIVE DIRECT DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18 462 / 18.18

171 / 6.13 171 / 6.13

TYPE INDUCTION INDUCTION

INDOOR FAN MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) IP22 IP22

TYPE PROPELLER PROPELLER

QUANTITY 11

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT DIRECT

DIAMETER

mm/in

609.6 / 24 609.6 / 24

TYPE INDUCTION INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 11

INDEX OF PROTECTION (IP) --

TYPE SCROLL SCROLL

COMPRESSOR

INDOOR COIL

OIL TYPE MOBIL EAL ARCTIC 22CC MOBIL EAL ARCTIC 22CC

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

SEAMLESS INNER GROOVED COPPER SEAMLESS INNER GROOVED COPPER

1242 / 43.7 1951 / 68.7

7 / 0.27 7 / 0.27

0.24 / 0.01 0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN) ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

m2/ft

2

0.11 / 0.004 0.11 / 0.004

0.461 / 4.96 0.461 / 4.96

ROW 22

FIN PER INCH 18 18

SEAMLESS INNER GROOVE COPPER SEAMLESS INNER GROOVE COPPER

7.00 / 0.276 7.00 / 0.276

0.28 / 0.011 0.28 / 0.011

0.11 / 0.0043 0.11 / 0.0043

2

2

/ft

0.87 / 9.33 0.87 / 9.33

OUTDOOR COIL

TUBE

FIN

MATERIAL

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (CORR. FIN) ALUMINIUM (CORR. FIN)

THICKNESS

FACE AREA

mm/in

m

ROW 22

FIN PER INCH 18 18

TYPE WASHABLE SARANET FILTER WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL HOT DIP GALVANIZED STEEL

WITH PE INSULATION WITH PE INSULATION

GALVANIZED MILD STEEL GALVANIZED MILD STEEL

POLYESTER POWDER POLYESTER POWDER

11

576.0 / 22.7 576.0 / 22.7

556.0 / 21.9 556.0 / 21.9

2 / 0.078 2 / 0.078

ABS ABS

N/A N/A

LIGHT GREY LIGHT GREY

WITHOUT PAINT WITHOUT PAINT

LIGHT GREY LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

GLASS REINFORCED ACRYL

STYRENE RESIN

67

ACK-E-2009 Engineering & Physical Data

Component Data - Heat Pump (R410A)

MODEL

INDOOR UNIT A5CK 50ER

OUTDOOR UNIT A5LC 50CR

TYPE BLOWER WHEEL

QUANTITY 1

INDOOR FAN

MATERIAL ASG 10%

DRIVE DIRECT

DIAMETER

LENGTH

mm/in

mm/in

462 / 18.18

171 / 6.13

TYPE INDUCTION

INDOOR FAN MOTOR

QUANTITY 1

INDEX OF PROTECTION (IP) IP22

TYPE PROPELLER

QUANTITY 1

OUTDOOR FAN

MATERIAL

GLASS REINFORCED ACRYL

STYRENE RESIN

DRIVE DIRECT

DIAMETER

mm/in

609.6 / 24

TYPE INDUCTION
OUTDOOR FAN
MOTOR

QUANTITY 1

INDEX OF PROTECTION (IP) -

TYPE SCROLL

COMPRESSOR

INDOOR COIL

OIL TYPE MOBIL EAL ARCTIC 22CC

OIL AMOUNT

MATERIAL

TUBE

DIAMETER

THICKNESS

cm

mm/in

mm/in

3

/ fl .oz.

SEAMLESS INNER GROOVED COPPER

1656 / 58.3

7 / 0.27

0.24 / 0.01

MATERIAL ALUMINIUM (SLIT FIN)

FIN

THICKNESS

FACE AREA

mm/in

m2/ft

2

0.11 / 0.004

0.464 / 4.988

ROW 3

FIN PER INCH 20

MATERIAL SEAMLESS COPPER

OUTDOOR COIL

TUBE

FIN

DIAMETER

THICKNESS

mm/in

mm/in

MATERIAL ALUMINIUM (CORR. FIN)

THICKNESS

FACE AREA

mm/in

2

/ft

m

2

7.00 / 0.276

0.28 / 0.011

0.11 / 0.0043

0.87 / 9.33

ROW 2

FIN PER INCH 18

TYPE WASHABLE SARANET FILTER

AIR QUALITY FILTER

PAN EL

CASING

INDOOR UNIT

OUTDOOR UNIT

QUANTITY

LENGTH

WIDTH

SIZE

THICKNESS

pc

mm/in

mm/in

mm/in

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

MATERIAL

FINISHING

COLOUR

HOT DIP GALVANIZED STEEL

WITH PE INSULATION

GALVANIZED MILD STEEL

POLYESTER POWDER

1

576.0 / 22.7

556.0 / 21.9

2 / 0.078

ABS

N/A

LIGHT GREY

WITHOUT PAINT

LIGHT GREY

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

68

Engineering & Physical Data ACK-E-2009

Safety Devices - MCK-E Series

MODEL

SAFETY DEVICE

MODEL

SAFETY DEVICE

INDOOR UNIT ACK 20E

OUTDOOR UNIT ALC 20C

TYPE N/A

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER N/A

DISCHARGE THERMOSTAT SETTING °C / °F N/A

INDOOR UNIT ACK 25E

OUTDOOR UNIT ALC 25C

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER N/A

DISCHARGE THERMOSTAT SETTING °C / °F N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

MODEL

SAFETY DEVICE

MODEL

SAFETY DEVICE

INDOOR UNIT ACK 28E

OUTDOOR UNIT ALC 28C

TYPE N/A

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER - 1Ø / <3Ø> N/A

DISCHARGE THERMOSTAT SETTING - 1Ø / <3Ø> °C / °F N/A

INDOOR UNIT ACK 40E ACK 40E

OUTDOOR UNIT ALC 35C

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER - 1Ø / <3Ø> N/A

DISCHARGE THERMOSTAT SETTING - 1Ø / <3Ø> °C / °F N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

TYPE NC

OPEN kPa / psi 2937 / 426

CLOSE kPa / psi 2413 / 350

TYPE NC

OPEN kPa / psi 124 / 18

CLOSE kPa / psi 193 / 28

ALC 40C

NC

2937 / 426

2413 / 350

NC

124 / 18

193 / 28

N/A / <YES>

N/A / <130 / 266>

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

69

ACK-E-2009 Engineering & Physical Data

Safety Devices - MCK-E Series

MODEL

SAFETY DEVICE

MODEL

SAFETY DEVICE

INDOOR UNIT ACK 50E

OUTDOOR UNIT ALC 50C

TYPE NC

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER YES

DISCHARGE THERMOSTAT SETTING °C / °F 130 / 266

INDOOR UNIT ACK 20ER

OUTDOOR UNIT ALC 20CR

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER N/A

DISCHARGE THERMOSTAT SETTING °C / °F N/A

OPEN kPa / psi 2937 / 426

CLOSE kPa / psi 2413 / 350

TYPE NC

OPEN kPa / psi 124 / 18

CLOSE kPa / psi 193 / 28

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

MODEL

SAFETY DEVICE

MODEL

SAFETY DEVICE

INDOOR UNIT ACK 25ER

OUTDOOR UNIT ALC 25CR

TYPE N/A

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER N/A

DISCHARGE THERMOSTAT SETTING °C / °F N/A

INDOOR UNIT ACK 28ER

OUTDOOR UNIT ALC 28CR

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER - 1Ø / <3Ø> N/A

DISCHARGE THERMOSTAT SETTING - 1Ø / <3Ø> °C / °F N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

70

Engineering & Physical Data ACK-E-2009

Safety Devices - MCK-E Series

MODEL

SAFETY DEVICE

MODEL

SAFETY DEVICE

INDOOR UNIT ACK 40ER ACK 40ER

OUTDOOR UNIT ALC 35CR ALC 40CR

TYPE NC NC

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER - 1Ø / <3Ø> N/A N/A / <YES>

DISCHARGE THERMOSTAT SETTING - 1Ø / <3Ø> °C / °F N/A N/A / <130 / 266>

INDOOR UNIT ACK 50ER

OUTDOOR UNIT ALC 50CR

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER YES

DISCHARGE THERMOSTAT SETTING °C / °F 130 / 266

OPEN kPa / psi 2937 / 426 2937 / 426

CLOSE kPa / psi 2413 / 350 2413 / 350

TYPE N/A N/A

OPEN kPa / psi N/A N/A

CLOSE kPa / psi N/A N/A

TYPE N/A

OPEN kPa / psi 2937 / 426

CLOSE kPa / psi 2413 / 350

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

71

ACK-E-2009 Engineering & Physical Data

Safety Devices - M5CK-E Series

MODEL

SAFETY DEVICE

MODEL

SAFETY DEVICE

INDOOR UNIT A5CK 20E A5CK 25E

OUTDOOR UNIT A5LC 20C A5LC 25C

TYPE N/A N/A

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER - 1Ø / <3Ø> N/A / <YES> N/A / <YES>

DISCHARGE THERMOSTAT SETTING - 1Ø / <3Ø> °C / °F N/A / <130 / 266> N/A / <130 / 266>

INDOOR UNIT A5CK 28E

OUTDOOR UNIT A5LC 28C

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER - 1Ø / <3Ø> N/A / <YES>

DISCHARGE THERMOSTAT SETTING - 1Ø / <3Ø> °C / °F N/A / <130 / 266>

OPEN kPa / psi N/A N/A

CLOSE kPa / psi N/A N/A

TYPE N/A N/A

OPEN kPa / psi N/A N/A

CLOSE kPa / psi N/A N/A

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

MODEL

SAFETY DEVICE

MODEL

SAFETY DEVICE

INDOOR UNIT A5CK 40E A5CK 40E

OUTDOOR UNIT A5LC 35C A5LC 40C

TYPE NC NC

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER - 1Ø / <3Ø> N/A / <YES> N/A / <YES>

DISCHARGE THERMOSTAT SETTING - 1Ø / <3Ø> °C / °F N/A / <130 / 266> N/A / <130 / 266>

INDOOR UNIT A5CK 50E

OUTDOOR UNIT A5LC 50C

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER YES

DISCHARGE THERMOSTAT SETTING °C / °F 130 / 266

OPEN kPa / psi 4137 / 600 4137 / 600

CLOSE kPa / psi 3310 / 480 3310 / 480

TYPE NC NC

OPEN kPa / psi 48 / 7 48 / 7

CLOSE kPa / psi 152 / 22 152 / 22

TYPE NC

OPEN kPa / psi 4137 / 600

CLOSE kPa / psi 3310 / 480

TYPE NC

OPEN kPa / psi 48 / 7

CLOSE kPa / psi 152 / 22

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

72

Engineering & Physical Data ACK-E-2009

Safety Devices - M5CK-E Series

MODEL

SAFETY DEVICE

MODEL

SAFETY DEVICE

INDOOR UNIT A5CK 20ER A5CK 25ER

OUTDOOR UNIT A5LC 20CR A5LC 25CR

TYPE N/A N/A

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER - 1Ø / <3Ø> N/A / <YES> N/A / <YES>

DISCHARGE THERMOSTAT SETTING - 1Ø / <3Ø> °C / °F N/A / <130 / 266> N/A / <130 / 266>

INDOOR UNIT A5CK 28ER

OUTDOOR UNIT A5LC 28CR

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER - 1Ø / <3Ø> N/A / <YES>

DISCHARGE THERMOSTAT SETTING - 1Ø / <3Ø> °C / °F N/A / <130 / 266>

OPEN kPa / psi N/A N/A

CLOSE kPa / psi N/A N/A

TYPE N/A N/A

OPEN kPa / psi N/A N/A

CLOSE kPa / psi N/A N/A

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

TYPE N/A

OPEN kPa / psi N/A

CLOSE kPa / psi N/A

MODEL

SAFETY DEVICE

MODEL

SAFETY DEVICE

INDOOR UNIT A5CK 40ER A5CK 40ER

OUTDOOR UNIT A5LC 35CR A5LC 40CR

TYPE NC NC

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER - 1Ø / <3Ø> N/A / <YES> N/A / <YES>

DISCHARGE THERMOSTAT SETTING - 1Ø / <3Ø> °C / °F N/A / <130 / 266> N/A / <130 / 266>

INDOOR UNIT A5CK 50ER

OUTDOOR UNIT A5LC 50CR

HIGH PRESSURE SWITCH

LOW PRESSURE SWITCH

PHASE SEQUENCER YES

DISCHARGE THERMOSTAT SETTING °C / °F 130 / 266

OPEN kPa / psi 4137 / 600 4137 / 600

CLOSE kPa / psi 3310 / 480 3310 / 480

TYPE NC NC

OPEN kPa / psi 48 / 7 48 / 7

CLOSE kPa / psi 152 / 22 152 / 22

TYPE NC

OPEN kPa / psi 4137 / 600

CLOSE kPa / psi 3310 / 480

TYPE NC

OPEN kPa / psi 48 / 7

CLOSE kPa / psi 152 / 22

1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.

73

ACK-E-2009 Performance Data

Performance Data

Interpolation and Extrapolation method can be used to get the total capacity, TC and sensible capacity, SC at
those temperatures which are not stated out in the table.

Example:

Model: ACK 20E – ALC 20C
Indoor Condition: 23°C DB, 15°C WB
Outdoor Condition: 37°C DB

Solution:

Overall

Based on the Performance table on Pg.56,

1. Refer to the Indoor DB column,

23°C is located between 20°C and 24°C (Thus, Interpolation need to be applied)

-

2. Refer to the Indoor WB column,

15°C only available in the case of Indoor DB = 20°C. (Thus, Extrapolation between 16°C WB and 17°C

­WB during 24°C indoor DB is required)

3. Refer to the Outdoor DB column,

37°C is located between 35°C and 40°C. (Thus, Interpolation need to be applied)

-

Please follow the steps below in order to get the required capacity.

nd

1st Step
Extrapolation of Indoor WB

Find TC, SC for
(a)

Indoor: 24°C DB, 15°C WB

Outdoor: 35°C DB

(b) Indoor: 24°C DB, 15°C WB

Outdoor: 40°C DB

2

Step

Interpolation of Indoor DB

Find TC, SC for
(a)

Indoor: 23°C DB, 15°C WB

Outdoor: 35°C DB

(b)

Indoor: 23°C DB, 15°C WB

Outdoor: 40°C DB

rd

3

Step

Interpolation of Outdoor DB

Find TC, SC for
(a) Indoor: 23°C DB, 15°C WB

Outdoor: 37°C DB

74

Performance Data ACK-E-2009

Details:

1st Step:

To obtain the Total capacity and Sensible capacity for

(a) Indoor Condition: 24°C DB, 15°C WB

Outdoor Condition: 35°C DB

Outdoor DB, ˚C

Indoor DB˚C Indoor WB˚C

35

TC (kW) SC (kW)

24

........

15

...........................................

x

1

16 5.419 3.94

........

y

1

17 5.495 3.71

Total capacity, TC

⇒ x

= 5.343kW (Same as Total capacity at 20°C Indoor DB / 15°C Indoor WB & 35°C Outdoor WB)*

1

Sensible capacity, SC

Extrapolation Method:

17º C – 15º C

⇒

17º C – 16º C 3.71kW – 3.94kW

=

3.71kW – y

1

⇒ y1 = 4.17kW

(b) Indoor Condition: 24°C DB, 15°C WB

Outdoor Condition: 40°C DB

Outdoor DB, ˚C

Indoor DB˚C Indoor WB˚C

40

TC (kW) SC (kW)

24

........

15

...........................................

x

2

16 4.944 3.592

........

y

2

17 5.06 3.463

Total capacity, TC

⇒ x2 = 4.828kW (Same as Total capacity at 20°C Indoor DB / 15°C Indoor WB & 40°C Outdoor WB)*

Sensible capacity, SC

Extrapolation Method:

17º C – 15º C

⇒

17º C – 16º C 3.463kW – 3.592kW

=

3.463kW – y

2

⇒ y2 = 3.721kW

* This is due to 2 different conditions with same WB temperature, will have the same level of enthalpy. For more

details, please refer to psychrometrics chart

75

ACK-E-2009 Performance Data

2nd Step:

To obtain the Total capacity and Sensible capacity for

(a) Indoor Condition: 23°C DB, 15°C WB

Outdoor Condition: 35°C DB

Outdoor DB, ˚C

Indoor DB˚C Indoor WB˚C

35

TC (kW) SC (kW)

20 15

23 15

...........................................

........

5.343 2.925
x

3

........

y

3

24 15 5.343 4.17

Total capacity, TC

⇒ x

= 3.295kW (Same as Total capacity at 20°C Indoor DB / 15°C Indoor WB & 35°C Outdoor WB)*

3

Sensible capacity, SC

Interpolation Method:

24º C – 20º C

⇒

24º C – 23º C 4.17kW – y

4.17kW – 2.925kW

=

3

⇒ y1 = 3.859kW

(b) Indoor Condition: 23°C DB, 15°C WB

Outdoor Condition: 40°C DB

Outdoor DB, ˚C

Indoor DB˚C Indoor WB˚C

40

TC (kW) SC (kW)

20 15

23 15

...........................................

........

4.828 2.477
x

4

........

y

4

24 15 4.828 3.721

Total capacity, TC

⇒ x4 = 4.828kW (Same as Total capacity at 20°C Indoor DB / 15°C Indoor WB & 40°C Outdoor WB)*

Sensible capacity, SC

Interpolation Method:

24º C – 20º C

⇒

24º C – 23º C 3.721kW – y

3.721kW – 2.477kW

=

4

⇒ y2 = 3.41kW

* This is due to 2 different conditions with same WB temperature, will have the same level of enthalpy. For more

details, please refer to psychrometrics chart

76

Performance Data ACK-E-2009

3rd Step:

To obtain the Total capacity and Sensible capacity for

(a) Indoor Condition: 23°C DB, 15°C WB

Outdoor Condition: 37°C DB

Outdoor DB, ˚C

Indoor DB˚C Indoor WB˚C

35 37 40

TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW)

23 15

Total capacity, TC

Interpolation Method:

40º C – 35º C

⇒

40º C – 37º C 4.828kW –

4.828kW – 3.295kW

=

⇒ x = 3.908kW

Sensible capacity, SC

Interpolation Method:

40º C – 35º C

⇒

3.41kW – 3.859kW

=

40º C – 37º C 3.41kW – y

⇒ y = 3.679kW

......................

........

........

........

........

........

3.295 3.859 x y 4.828 3.41

χ

........

77

ACK-E-2009 Performance Data

Cooling Only (R22)

Model: ACK 20E - ALC 20C
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 6.886 4.269 6.371 3.821 5.857 3.373 5.343 2.925 4.828 2.477 4.211 1.939

16 6.843 3.738 6.368 3.391 5.893 3.043 5.419 2.695 4.944 2.347 4.374 1.93

16 6.843 4.983 6.368 4.635 5.893 4.287 5.419 3.94 4.944 3.592 4.374 3.175

17 6.799 4.452 6.365 4.205 5.93 3.957 5.495 3.71 5.06 3.463 4.538 3.166

18 6.756 3.921 6.361 3.774 5.966 3.627 5.571 3.48 5.176 3.333 4.702 3.157

19 6.713 3.39 6.358 3.344 6.002 3.297 5.647 3.25 5.292 3.204 4.865 3.148

20 6.67 2.856 6.351 2.879 6.032 2.902 5.713 2.926 5.394 2.949 5.011 2.977

18 6.756 5.166 6.361 5.019 5.966 4.872 5.571 4.725 5.176 4.578 4.702 4.401

19 6.713 4.635 6.358 4.588 6.002 4.542 5.647 4.495 5.292 4.448 4.865 4.392

20 6.67 4.1 6.351 4.124 6.032 4.147 5.713 4.17 5.394 4.193 5.011 4.221

21 6.626 3.563 6.341 3.636 6.056 3.709 5.771 3.782 5.487 3.855 5.145 3.943

22 6.582 3.026 6.331 3.149 6.081 3.272 5.83 3.395 5.58 3.517 5.279 3.664

23 6.538 2.489 6.322 2.662 6.105 2.834 5.889 3.007 5.673 3.179 5.413 3.386

24 6.494 1.952 6.312 2.175 6.13 2.397 5.948 2.619 5.766 2.841 5.547 3.107

20 6.67 4.723 6.351 4.746 6.032 4.769 5.713 4.793 5.394 4.816 5.011 4.844

21 6.626 4.186 6.341 4.259 6.056 4.332 5.771 4.405 5.487 4.478 5.145 4.565

22 6.582 3.649 6.331 3.771 6.081 3.894 5.83 4.017 5.58 4.14 5.279 4.287

23 6.538 3.112 6.322 3.284 6.105 3.457 5.889 3.629 5.673 3.801 5.413 4.008

24 6.494 2.575 6.312 2.797 6.13 3.019 5.948 3.241 5.766 3.463 5.547 3.73

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: ACK 25E - ALC 25C
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 8.301 5.301 7.8 4.867 7.299 4.433 6.798 3.998 6.297 3.564 5.695 3.043

16 8.436 4.744 7.955 4.391 7.474 4.037 6.992 3.684 6.511 3.33 5.933 2.906

16 8.436 6.081 7.955 5.728 7.474 5.374 6.992 5.021 6.511 4.667 5.933 4.243

17 8.572 5.524 8.11 5.251 7.648 4.979 7.186 4.706 6.725 4.433 6.171 4.106

18 8.707 4.967 8.265 4.775 7.823 4.583 7.381 4.391 6.939 4.199 6.408 3.969

19 8.842 4.411 8.42 4.299 7.997 4.188 7.575 4.077 7.153 3.965 6.646 3.832

20 8.976 3.852 8.565 3.802 8.153 3.753 7.742 3.703 7.331 3.654 6.837 3.594

18 8.707 6.304 8.265 6.112 7.823 5.92 7.381 5.728 6.939 5.536 6.408 5.306

19 8.842 5.748 8.42 5.636 7.997 5.525 7.575 5.413 7.153 5.302 6.646 5.168

20 8.976 5.189 8.565 5.139 8.153 5.09 7.742 5.04 7.331 4.991 6.837 4.931

21 9.109 4.628 8.703 4.628 8.297 4.628 7.891 4.627 7.485 4.627 6.997 4.627

22 9.243 4.067 8.842 4.117 8.441 4.166 8.039 4.215 7.638 4.264 7.157 4.323

23 9.376 3.507 8.98 3.605 8.584 3.704 8.188 3.802 7.792 3.901 7.317 4.019

24 9.509 2.946 9.119 3.094 8.728 3.242 8.337 3.39 7.946 3.538 7.477 3.715

20 8.976 5.857 8.565 5.807 8.153 5.758 7.742 5.708 7.331 5.659 6.837 5.6

21 9.109 5.296 8.703 5.296 8.297 5.296 7.891 5.296 7.485 5.296 6.997 5.296

22 9.243 4.736 8.842 4.785 8.441 4.834 8.039 4.883 7.638 4.933 7.157 4.992

23 9.376 4.175 8.98 4.274 8.584 4.372 8.188 4.471 7.792 4.569 7.317 4.688

24 9.509 3.615 9.119 3.763 8.728 3.91 8.337 4.058 7.946 4.206 7.477 4.384

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

78

Performance Data ACK-E-2009

Model: ACK 28E - ALC 28C
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 9.173 5.692 8.5 5.095 7.827 4.498 7.154 3.901 6.481 3.303 5.673 2.587

16 9.177 5.051 8.542 4.561 7.907 4.071 7.272 3.581 6.637 3.091 5.875 2.503

16 9.177 6.705 8.542 6.215 7.907 5.725 7.272 5.235 6.637 4.745 5.875 4.157

17 9.182 6.065 8.585 5.682 7.988 5.298 7.391 4.915 6.794 4.532 6.078 4.072

18 9.187 5.424 8.628 5.148 8.069 4.872 7.51 4.596 6.951 4.319 6.28 3.988

19 9.192 4.784 8.671 4.614 8.15 4.445 7.629 4.276 7.108 4.107 6.483 3.904

20 9.197 4.14 8.714 4.052 8.231 3.964 7.748 3.877 7.265 3.789 6.686 3.684

18 9.187 7.078 8.628 6.802 8.069 6.526 7.51 6.25 6.951 5.974 6.28 5.642

19 9.192 6.438 8.671 6.269 8.15 6.099 7.629 5.93 7.108 5.761 6.483 5.558

20 9.197 5.794 8.714 5.706 8.231 5.619 7.748 5.531 7.265 5.443 6.686 5.338

21 9.202 5.148 8.757 5.125 8.312 5.102 7.868 5.079 7.423 5.055 6.889 5.028

22 9.206 4.503 8.8 4.544 8.393 4.585 7.987 4.626 7.581 4.668 7.093 4.717

23 9.211 3.857 8.843 3.963 8.475 4.068 8.107 4.174 7.738 4.28 7.296 4.407

24 9.216 3.211 8.886 3.381 8.556 3.552 8.226 3.722 7.896 3.892 7.5 4.097

20 9.197 6.621 8.714 6.533 8.231 6.446 7.748 6.358 7.265 6.27 6.686 6.165

21 9.202 5.975 8.757 5.952 8.312 5.929 7.868 5.906 7.423 5.883 6.889 5.855

22 9.206 5.33 8.8 5.371 8.393 5.412 7.987 5.453 7.581 5.495 7.093 5.544

23 9.211 4.684 8.843 4.79 8.475 4.895 8.107 5.001 7.738 5.107 7.296 5.234

24 9.216 4.038 8.886 4.208 8.556 4.379 8.226 4.549 7.896 4.719 7.5 4.924

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

79

ACK-E-2009 Performance Data

Model: ACK 40E - ALC 35C (1 Phase)
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 11.539 7.064 10.8 6.384 10.061 5.704 9.322 5.024 8.582 4.343 7.696 3.527

16 11.555 6.316 10.883 5.757 10.211 5.197 9.538 4.637 8.866 4.077 8.059 3.405

16 11.555 8.486 10.883 7.926 10.211 7.366 9.538 6.806 8.866 6.246 8.059 5.575

17 11.571 7.738 10.966 7.298 10.36 6.859 9.755 6.419 9.15 5.98 8.423 5.453

18 11.587 6.99 11.049 6.671 10.51 6.352 9.972 6.033 9.433 5.714 8.787 5.331

19 11.603 6.242 11.132 6.044 10.66 5.845 10.188 5.646 9.717 5.448 9.151 5.209

20 11.617 5.491 11.189 5.379 10.762 5.267 10.334 5.155 9.906 5.044 9.393 4.91

18 11.587 9.159 11.049 8.84 10.51 8.521 9.972 8.202 9.433 7.883 8.787 7.5

19 11.603 8.412 11.132 8.213 10.66 8.014 10.188 7.815 9.717 7.617 9.151 7.378

20 11.617 7.66 11.189 7.548 10.762 7.436 10.334 7.325 9.906 7.213 9.393 7.079

21 11.628 6.905 11.23 6.858 10.831 6.811 10.432 6.764 10.033 6.717 9.555 6.661

22 11.64 6.151 11.27 6.169 10.9 6.186 10.53 6.204 10.16 6.222 9.716 6.243

23 11.651 5.397 11.31 5.479 10.969 5.561 10.628 5.644 10.287 5.726 9.877 5.825

24 11.663 4.642 11.351 4.789 11.038 4.936 10.726 5.083 10.414 5.231 10.039 5.407

20 11.617 8.745 11.189 8.633 10.762 8.521 10.334 8.409 9.906 8.298 9.393 8.163

21 11.628 7.99 11.23 7.943 10.831 7.896 10.432 7.849 10.033 7.802 9.555 7.746

22 11.64 7.236 11.27 7.253 10.9 7.271 10.53 7.289 10.16 7.306 9.716 7.328

23 11.651 6.481 11.31 6.564 10.969 6.646 10.628 6.728 10.287 6.811 9.877 6.91

24 11.663 5.727 11.351 5.874 11.038 6.021 10.726 6.168 10.414 6.315 10.039 6.492

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: ACK 40E - ALC 40C (1 Phase)
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 12.509 7.883 11.704 7.151 10.899 6.419 10.094 5.687 9.289 4.955 8.323 4.077

16 12.673 7.135 11.899 6.501 11.125 5.866 10.35 5.231 9.576 4.597 8.647 3.835

16 12.673 9.298 11.899 8.664 11.125 8.029 10.35 7.394 9.576 6.76 8.647 5.998

17 12.837 8.551 12.094 8.014 11.35 7.476 10.607 6.939 9.863 6.401 8.971 5.756

18 13.001 7.804 12.288 7.364 11.576 6.923 10.863 6.483 10.15 6.043 9.295 5.514

19 13.165 7.057 12.483 6.714 11.801 6.37 11.119 6.027 10.437 5.684 9.618 5.272

20 13.328 6.308 12.67 6.047 12.012 5.787 11.354 5.527 10.696 5.266 9.906 4.954

18 13.001 9.967 12.288 9.527 11.576 9.086 10.863 8.646 10.15 8.206 9.295 7.677

19 13.165 9.22 12.483 8.876 11.801 8.533 11.119 8.19 10.437 7.847 9.618 7.435

20 13.328 8.471 12.67 8.21 12.012 7.95 11.354 7.69 10.696 7.429 9.906 7.117

21 13.491 7.721 12.852 7.534 12.214 7.347 11.575 7.159 10.937 6.972 10.171 6.748

22 13.654 6.971 13.035 6.857 12.416 6.743 11.797 6.629 11.178 6.515 10.435 6.379

23 13.816 6.22 13.217 6.18 12.617 6.14 12.018 6.099 11.418 6.059 10.699 6.01

24 13.979 5.47 13.399 5.503 12.819 5.536 12.239 5.569 11.659 5.602 10.963 5.641

20 13.328 9.552 12.67 9.292 12.012 9.031 11.354 8.771 10.696 8.511 9.906 8.198

21 13.491 8.802 12.852 8.615 12.214 8.428 11.575 8.241 10.937 8.054 10.171 7.829

22 13.654 8.052 13.035 7.938 12.416 7.825 11.797 7.711 11.178 7.597 10.435 7.46

23 13.816 7.302 13.217 7.261 12.617 7.221 12.018 7.181 11.418 7.14 10.699 7.091

24 13.979 6.552 13.399 6.585 12.819 6.618 12.239 6.65 11.659 6.683 10.963 6.722

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

80

Performance Data ACK-E-2009

Model: ACK 40E - ALC 40C (3 Phase)
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 12.723 7.926 11.899 7.223 11.074 6.52 10.25 5.817 9.425 5.114 8.436 4.271

16 12.924 7.053 12.12 6.481 11.316 5.91 10.512 5.338 9.708 4.766 8.744 4.08

16 12.924 9.213 12.12 8.642 11.316 8.07 10.512 7.498 9.708 6.926 8.744 6.24

17 13.125 8.34 12.342 7.9 11.558 7.459 10.775 7.018 9.991 6.578 9.051 6.049

18 13.326 7.467 12.563 7.158 11.8 6.848 11.037 6.539 10.274 6.229 9.359 5.858

19 13.527 6.594 12.784 6.416 12.042 6.237 11.3 6.059 10.558 5.881 9.667 5.667

20 13.727 5.717 13.004 5.64 12.281 5.563 11.558 5.486 10.834 5.409 9.966 5.317

18 13.326 9.627 12.563 9.318 11.8 9.008 11.037 8.699 10.274 8.389 9.359 8.018

19 13.527 8.754 12.784 8.576 12.042 8.397 11.3 8.219 10.558 8.041 9.667 7.827

20 13.727 7.877 13.004 7.8 12.281 7.723 11.558 7.646 10.834 7.569 9.966 7.477

21 13.928 6.998 13.223 7.003 12.517 7.007 11.812 7.012 11.107 7.016 10.26 7.021

22 14.129 6.119 13.441 6.205 12.754 6.291 12.067 6.377 11.379 6.463 10.554 6.565

23 14.329 5.24 13.66 5.407 12.99 5.575 12.321 5.742 11.652 5.909 10.848 6.11

24 14.53 4.361 13.878 4.61 13.227 4.858 12.576 5.107 11.924 5.356 11.143 5.654

20 13.727 8.957 13.004 8.88 12.281 8.803 11.558 8.726 10.834 8.649 9.966 8.557

21 13.928 8.078 13.223 8.083 12.517 8.087 11.812 8.092 11.107 8.096 10.26 8.101

22 14.129 7.199 13.441 7.285 12.754 7.371 12.067 7.457 11.379 7.543 10.554 7.646

23 14.329 6.32 13.66 6.488 12.99 6.655 12.321 6.822 11.652 6.989 10.848 7.19

24 14.53 5.441 13.878 5.69 13.227 5.938 12.576 6.187 11.924 6.436 11.143 6.734

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: ACK 50E - ALC 50C
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 14.59 9.052 13.731 8.3 12.872 7.547 12.013 6.794 11.154 6.041 10.124 5.138

16 14.78 8.071 13.973 7.468 13.167 6.864 12.361 6.261 11.554 5.657 10.587 4.933

16 14.78 10.609 13.973 10.006 13.167 9.402 12.361 8.798 11.554 8.195 10.587 7.471

17 14.969 9.628 14.215 9.174 13.462 8.719 12.708 8.265 11.954 7.811 11.05 7.265

18 15.158 8.647 14.457 8.342 13.756 8.037 13.055 7.732 12.354 7.426 11.513 7.06

19 15.347 7.666 14.699 7.51 14.051 7.354 13.402 7.198 12.754 7.042 11.976 6.855

20 15.533 6.68 14.912 6.632 14.29 6.585 13.668 6.538 13.047 6.49 12.301 6.433

18 15.158 11.185 14.457 10.88 13.756 10.574 13.055 10.269 12.354 9.964 11.513 9.598

19 15.347 10.204 14.699 10.048 14.051 9.892 13.402 9.736 12.754 9.58 11.976 9.393

20 15.533 9.218 14.912 9.17 14.29 9.123 13.668 9.075 13.047 9.028 12.301 8.971

21 15.717 8.228 15.105 8.262 14.492 8.296 13.88 8.33 13.268 8.364 12.533 8.404

22 15.901 7.239 15.298 7.354 14.695 7.469 14.092 7.584 13.489 7.7 12.765 7.838

23 16.085 6.25 15.491 6.446 14.898 6.643 14.304 6.839 13.71 7.035 12.998 7.271

24 16.269 5.261 15.685 5.538 15.1 5.816 14.516 6.094 13.931 6.371 13.23 6.704

20 15.533 10.486 14.912 10.439 14.29 10.392 13.668 10.344 13.047 10.297 12.301 10.24

21 15.717 9.497 15.105 9.531 14.492 9.565 13.88 9.599 13.268 9.633 12.533 9.673

22 15.901 8.508 15.298 8.623 14.695 8.738 14.092 8.853 13.489 8.968 12.765 9.107

23 16.085 7.519 15.491 7.715 14.898 7.912 14.304 8.108 13.71 8.304 12.998 8.54

24 16.269 6.529 15.685 6.807 15.1 7.085 14.516 7.362 13.931 7.64 13.23 7.973

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

81

ACK-E-2009 Performance Data

Heat Pump (R22)

Model: ACK 20ER - ALC 20CR
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 6.886 4.269 6.371 3.821 5.857 3.373 5.343 2.925 4.828 2.477 4.211 1.939

16 6.843 3.738 6.368 3.391 5.893 3.043 5.419 2.695 4.944 2.347 4.374 1.93

16 6.843 4.983 6.368 4.635 5.893 4.287 5.419 3.94 4.944 3.592 4.374 3.175

17 6.799 4.452 6.365 4.205 5.93 3.957 5.495 3.71 5.06 3.463 4.538 3.166

18 6.756 3.921 6.361 3.774 5.966 3.627 5.571 3.48 5.176 3.333 4.702 3.157

19 6.713 3.39 6.358 3.344 6.002 3.297 5.647 3.25 5.292 3.204 4.865 3.148

20 6.67 2.856 6.351 2.879 6.032 2.902 5.713 2.926 5.394 2.949 5.011 2.977

18 6.756 5.166 6.361 5.019 5.966 4.872 5.571 4.725 5.176 4.578 4.702 4.401

19 6.713 4.635 6.358 4.588 6.002 4.542 5.647 4.495 5.292 4.448 4.865 4.392

20 6.67 4.1 6.351 4.124 6.032 4.147 5.713 4.17 5.394 4.193 5.011 4.221

21 6.626 3.563 6.341 3.636 6.056 3.709 5.771 3.782 5.487 3.855 5.145 3.943

22 6.582 3.026 6.331 3.149 6.081 3.272 5.83 3.395 5.58 3.517 5.279 3.664

23 6.538 2.489 6.322 2.662 6.105 2.834 5.889 3.007 5.673 3.179 5.413 3.386

24 6.494 1.952 6.312 2.175 6.13 2.397 5.948 2.619 5.766 2.841 5.547 3.107

20 6.67 4.723 6.351 4.746 6.032 4.769 5.713 4.793 5.394 4.816 5.011 4.844

21 6.626 4.186 6.341 4.259 6.056 4.332 5.771 4.405 5.487 4.478 5.145 4.565

22 6.582 3.649 6.331 3.771 6.081 3.894 5.83 4.017 5.58 4.14 5.279 4.287

23 6.538 3.112 6.322 3.284 6.105 3.457 5.889 3.629 5.673 3.801 5.413 4.008

24 6.494 2.575 6.312 2.797 6.13 3.019 5.948 3.241 5.766 3.463 5.547 3.73

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: ACK 20ER - ALC 20CR
Heating Mode

ID

DB°C

15

17

19

21

23

25

27

-9 -6 -5 6 12 15 18

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

2.322 2.322 2.983 2.983 3.204 3.204 5.629 5.629 6.952 6.952 7.614 7.614 8.275 8.275

2.245 2.245 2.917 2.917 3.141 3.141 5.489 5.489 6.762 6.762 7.401 7.401 8.04 8.04

2.167 2.167 2.85 2.85 3.078 3.078 5.349 5.349 6.572 6.572 7.188 7.188 7.805 7.805

2.09 2.09 2.784 2.784 3.015 3.015 5.209 5.209 6.381 6.381 6.975 6.975 7.569 7.569

2.104 2.104 2.74 2.74 2.952 2.952 5.058 5.058 6.191 6.191 6.762 6.762 7.334 7.334

2.118 2.118 2.697 2.697 2.89 2.89 4.907 4.907 6 6 6.549 6.549 7.098 7.098

2.132 2.132 2.653 2.653 2.827 2.827 4.756 4.756 5.81 5.81 6.336 6.336 6.863 6.863

FROST REGION

Outdoor WB°C

82

Performance Data ACK-E-2009

Model: ACK 25ER - ALC 25CR
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 8.301 5.301 7.8 4.867 7.299 4.433 6.798 3.998 6.297 3.564 5.695 3.043

16 8.436 4.744 7.955 4.391 7.474 4.037 6.992 3.684 6.511 3.33 5.933 2.906

16 8.436 6.081 7.955 5.728 7.474 5.374 6.992 5.021 6.511 4.667 5.933 4.243

17 8.572 5.524 8.11 5.251 7.648 4.979 7.186 4.706 6.725 4.433 6.171 4.106

18 8.707 4.967 8.265 4.775 7.823 4.583 7.381 4.391 6.939 4.199 6.408 3.969

19 8.842 4.411 8.42 4.299 7.997 4.188 7.575 4.077 7.153 3.965 6.646 3.832

20 8.976 3.852 8.565 3.802 8.153 3.753 7.742 3.703 7.331 3.654 6.837 3.594

18 8.707 6.304 8.265 6.112 7.823 5.92 7.381 5.728 6.939 5.536 6.408 5.306

19 8.842 5.748 8.42 5.636 7.997 5.525 7.575 5.413 7.153 5.302 6.646 5.168

20 8.976 5.189 8.565 5.139 8.153 5.09 7.742 5.04 7.331 4.991 6.837 4.931

21 9.109 4.628 8.703 4.628 8.297 4.628 7.891 4.627 7.485 4.627 6.997 4.627

22 9.243 4.067 8.842 4.117 8.441 4.166 8.039 4.215 7.638 4.264 7.157 4.323

23 9.376 3.507 8.98 3.605 8.584 3.704 8.188 3.802 7.792 3.901 7.317 4.019

24 9.509 2.946 9.119 3.094 8.728 3.242 8.337 3.39 7.946 3.538 7.477 3.715

20 8.976 5.857 8.565 5.807 8.153 5.758 7.742 5.708 7.331 5.659 6.837 5.6

21 9.109 5.296 8.703 5.296 8.297 5.296 7.891 5.296 7.485 5.296 6.997 5.296

22 9.243 4.736 8.842 4.785 8.441 4.834 8.039 4.883 7.638 4.933 7.157 4.992

23 9.376 4.175 8.98 4.274 8.584 4.372 8.188 4.471 7.792 4.569 7.317 4.688

24 9.509 3.615 9.119 3.763 8.728 3.91 8.337 4.058 7.946 4.206 7.477 4.384

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: ACK 25ER - ALC 25CR
Heating Mode

ID

DB°C

15

17

19

21

23

25

27

-9 -6 -5 6 12 15 18

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

3.626 3.626 4.379 4.379 4.63 4.63 7.39 7.39 8.896 8.896 9.649 9.649 10.402 10.402

3.574 3.574 4.302 4.302 4.545 4.545 7.21 7.21 8.656 8.656 9.381 9.381 10.106 10.106

3.522 3.522 4.226 4.226 4.46 4.46 7.03 7.03 8.415 8.415 9.113 9.113 9.811 9.811

3.471 3.471 4.149 4.149 4.376 4.376 6.85 6.85 8.174 8.174 8.845 8.845 9.515 9.515

3.427 3.427 4.075 4.075 4.291 4.291 6.658 6.658 7.934 7.934 8.576 8.576 9.219 9.219

3.382 3.382 4 4 4.206 4.206 6.467 6.467 7.693 7.693 8.308 8.308 8.923 8.923

3.338 3.338 3.926 3.926 4.121 4.121 6.276 6.276 7.452 7.452 8.04 8.04 8.628 8.628

FROST REGION

Outdoor WB°C

83

ACK-E-2009 Performance Data

Model: ACK 28ER - ALC 28CR
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 9.173 5.692 8.5 5.095 7.827 4.498 7.154 3.901 6.481 3.303 5.673 2.587

16 9.177 5.051 8.542 4.561 7.907 4.071 7.272 3.581 6.637 3.091 5.875 2.503

16 9.177 6.705 8.542 6.215 7.907 5.725 7.272 5.235 6.637 4.745 5.875 4.157

17 9.182 6.065 8.585 5.682 7.988 5.298 7.391 4.915 6.794 4.532 6.078 4.072

18 9.187 5.424 8.628 5.148 8.069 4.872 7.51 4.596 6.951 4.319 6.28 3.988

19 9.192 4.784 8.671 4.614 8.15 4.445 7.629 4.276 7.108 4.107 6.483 3.904

20 9.197 4.14 8.714 4.052 8.231 3.964 7.748 3.877 7.265 3.789 6.686 3.684

18 9.187 7.078 8.628 6.802 8.069 6.526 7.51 6.25 6.951 5.974 6.28 5.642

19 9.192 6.438 8.671 6.269 8.15 6.099 7.629 5.93 7.108 5.761 6.483 5.558

20 9.197 5.794 8.714 5.706 8.231 5.619 7.748 5.531 7.265 5.443 6.686 5.338

21 9.202 5.148 8.757 5.125 8.312 5.102 7.868 5.079 7.423 5.055 6.889 5.028

22 9.206 4.503 8.8 4.544 8.393 4.585 7.987 4.626 7.581 4.668 7.093 4.717

23 9.211 3.857 8.843 3.963 8.475 4.068 8.107 4.174 7.738 4.28 7.296 4.407

24 9.216 3.211 8.886 3.381 8.556 3.552 8.226 3.722 7.896 3.892 7.5 4.097

20 9.197 6.621 8.714 6.533 8.231 6.446 7.748 6.358 7.265 6.27 6.686 6.165

21 9.202 5.975 8.757 5.952 8.312 5.929 7.868 5.906 7.423 5.883 6.889 5.855

22 9.206 5.33 8.8 5.371 8.393 5.412 7.987 5.453 7.581 5.495 7.093 5.544

23 9.211 4.684 8.843 4.79 8.475 4.895 8.107 5.001 7.738 5.107 7.296 5.234

24 9.216 4.038 8.886 4.208 8.556 4.379 8.226 4.549 7.896 4.719 7.5 4.924

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: ACK 28ER - ALC 28CR
Heating Mode

ID

DB°C

15

17

19

21

23

25

27

-9 -6 -5 6 12 15 18

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

3.637 3.637 4.54 4.54 4.841 4.841 8.15 8.15 9.955 9.955 10.858 10.858 11.76 11.76

3.549 3.549 4.449 4.449 4.749 4.749 7.913 7.913 9.684 9.684 10.555 10.555 11.426 11.426

3.461 3.461 4.358 4.358 4.657 4.657 7.677 7.677 9.413 9.413 10.252 10.252 11.091 11.091

3.373 3.373 4.267 4.267 4.565 4.565 7.44 7.44 9.142 9.142 9.949 9.949 10.757 10.757

3.363 3.363 4.195 4.195 4.473 4.473 7.262 7.262 8.87 8.87 9.646 9.646 10.422 10.422

3.354 3.354 4.124 4.124 4.38 4.38 7.084 7.084 8.599 8.599 9.344 9.344 10.088 10.088

3.344 3.344 4.052 4.052 4.288 4.288 6.907 6.907 8.328 8.328 9.041 9.041 9.754 9.754

FROST REGION

Outdoor WB°C

84

Performance Data ACK-E-2009

Model: ACK 40ER - ALC 35CR (1 Phase)
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 11.539 7.064 10.8 6.384 10.061 5.704 9.322 5.024 8.582 4.343 7.696 3.527

16 11.555 6.316 10.883 5.757 10.211 5.197 9.538 4.637 8.866 4.077 8.059 3.405

16 11.555 8.486 10.883 7.926 10.211 7.366 9.538 6.806 8.866 6.246 8.059 5.575

17 11.571 7.738 10.966 7.298 10.36 6.859 9.755 6.419 9.15 5.98 8.423 5.453

18 11.587 6.99 11.049 6.671 10.51 6.352 9.972 6.033 9.433 5.714 8.787 5.331

19 11.603 6.242 11.132 6.044 10.66 5.845 10.188 5.646 9.717 5.448 9.151 5.209

20 11.617 5.491 11.189 5.379 10.762 5.267 10.334 5.155 9.906 5.044 9.393 4.91

18 11.587 9.159 11.049 8.84 10.51 8.521 9.972 8.202 9.433 7.883 8.787 7.5

19 11.603 8.412 11.132 8.213 10.66 8.014 10.188 7.815 9.717 7.617 9.151 7.378

20 11.617 7.66 11.189 7.548 10.762 7.436 10.334 7.325 9.906 7.213 9.393 7.079

21 11.628 6.905 11.23 6.858 10.831 6.811 10.432 6.764 10.033 6.717 9.555 6.661

22 11.64 6.151 11.27 6.169 10.9 6.186 10.53 6.204 10.16 6.222 9.716 6.243

23 11.651 5.397 11.31 5.479 10.969 5.561 10.628 5.644 10.287 5.726 9.877 5.825

24 11.663 4.642 11.351 4.789 11.038 4.936 10.726 5.083 10.414 5.231 10.039 5.407

20 11.617 8.745 11.189 8.633 10.762 8.521 10.334 8.409 9.906 8.298 9.393 8.163

21 11.628 7.99 11.23 7.943 10.831 7.896 10.432 7.849 10.033 7.802 9.555 7.746

22 11.64 7.236 11.27 7.253 10.9 7.271 10.53 7.289 10.16 7.306 9.716 7.328

23 11.651 6.481 11.31 6.564 10.969 6.646 10.628 6.728 10.287 6.811 9.877 6.91

24 11.663 5.727 11.351 5.874 11.038 6.021 10.726 6.168 10.414 6.315 10.039 6.492

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: ACK 40ER - ALC 35CR (1 Phase)
Heating Mode

ID

DB°C

15

17

19

21

23

25

27

-9 -6 -5 6 12 15 18

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

4.775 4.775 5.847 5.847 6.205 6.205 10.136 10.136 12.28 12.28 13.353 13.353 14.425 14.425

4.687 4.687 5.739 5.739 6.089 6.089 10.165 10.165 11.947 11.947 12.981 12.981 14.015 14.015

4.599 4.599 5.63 5.63 5.974 5.974 10.195 10.195 11.614 11.614 12.609 12.609 13.604 13.604

4.511 4.511 5.522 5.522 5.858 5.858 10.224 10.224 11.281 11.281 12.237 12.237 13.194 13.194

4.472 4.472 5.425 5.425 5.743 5.743 9.667 9.667 10.947 10.947 11.866 11.866 12.784 12.784

4.433 4.433 5.329 5.329 5.627 5.627 9.11 9.11 10.614 10.614 11.494 11.494 12.374 12.374

4.394 4.394 5.232 5.232 5.512 5.512 8.553 8.553 10.281 10.281 11.122 11.122 11.964 11.964

FROST REGION

Outdoor WB°C

85

ACK-E-2009 Performance Data

Model: ACK 40ER - ALC 40CR (1 Phase)
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 12.509 7.883 11.704 7.151 10.899 6.419 10.094 5.687 9.289 4.955 8.323 4.077

16 12.673 7.135 11.899 6.501 11.125 5.866 10.35 5.231 9.576 4.597 8.647 3.835

16 12.673 9.298 11.899 8.664 11.125 8.029 10.35 7.394 9.576 6.76 8.647 5.998

17 12.837 8.551 12.094 8.014 11.35 7.476 10.607 6.939 9.863 6.401 8.971 5.756

18 13.001 7.804 12.288 7.364 11.576 6.923 10.863 6.483 10.15 6.043 9.295 5.514

19 13.165 7.057 12.483 6.714 11.801 6.37 11.119 6.027 10.437 5.684 9.618 5.272

20 13.328 6.308 12.67 6.047 12.012 5.787 11.354 5.527 10.696 5.266 9.906 4.954

18 13.001 9.967 12.288 9.527 11.576 9.086 10.863 8.646 10.15 8.206 9.295 7.677

19 13.165 9.22 12.483 8.876 11.801 8.533 11.119 8.19 10.437 7.847 9.618 7.435

20 13.328 8.471 12.67 8.21 12.012 7.95 11.354 7.69 10.696 7.429 9.906 7.117

21 13.491 7.721 12.852 7.534 12.214 7.347 11.575 7.159 10.937 6.972 10.171 6.748

22 13.654 6.971 13.035 6.857 12.416 6.743 11.797 6.629 11.178 6.515 10.435 6.379

23 13.816 6.22 13.217 6.18 12.617 6.14 12.018 6.099 11.418 6.059 10.699 6.01

24 13.979 5.47 13.399 5.503 12.819 5.536 12.239 5.569 11.659 5.602 10.963 5.641

20 13.328 9.552 12.67 9.292 12.012 9.031 11.354 8.771 10.696 8.511 9.906 8.198

21 13.491 8.802 12.852 8.615 12.214 8.428 11.575 8.241 10.937 8.054 10.171 7.829

22 13.654 8.052 13.035 7.938 12.416 7.825 11.797 7.711 11.178 7.597 10.435 7.46

23 13.816 7.302 13.217 7.261 12.617 7.221 12.018 7.181 11.418 7.14 10.699 7.091

24 13.979 6.552 13.399 6.585 12.819 6.618 12.239 6.65 11.659 6.683 10.963 6.722

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: ACK 40ER - ALC 40CR (1 Phase)
Heating Mode

ID

DB°C

15

17

19

21

23

25

27

-9 -6 -5 6 12 15 18

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

5.47 5.47 6.441 6.441 6.764 6.764 10.325 10.325 12.267 12.267 13.238 13.238 14.209 14.209

5.432 5.432 6.342 6.342 6.645 6.645 10.695 10.695 11.937 11.937 12.871 12.871 13.805 13.805

5.395 5.395 6.242 6.242 6.525 6.525 11.064 11.064 11.607 11.607 12.504 12.504 13.401 13.401

5.358 5.358 6.143 6.143 6.405 6.405 11.434 11.434 11.278 11.278 12.138 12.138 12.997 12.997

5.253 5.253 6.027 6.027 6.285 6.285 10.52 10.52 10.948 10.948 11.771 11.771 12.594 12.594

5.147 5.147 5.91 5.91 6.165 6.165 9.606 9.606 10.618 10.618 11.404 11.404 12.19 12.19

5.041 5.041 5.794 5.794 6.045 6.045 8.692 8.692 10.288 10.288 11.037 11.037 11.786 11.786

FROST REGION

Outdoor WB°C

86

Performance Data ACK-E-2009

Model: ACK 40ER - ALC 40CR (3 Phase)
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 12.723 7.926 11.899 7.223 11.074 6.52 10.25 5.817 9.425 5.114 8.436 4.271

16 12.924 7.053 12.12 6.481 11.316 5.91 10.512 5.338 9.708 4.766 8.744 4.08

16 12.924 9.213 12.12 8.642 11.316 8.07 10.512 7.498 9.708 6.926 8.744 6.24

17 13.125 8.34 12.342 7.9 11.558 7.459 10.775 7.018 9.991 6.578 9.051 6.049

18 13.326 7.467 12.563 7.158 11.8 6.848 11.037 6.539 10.274 6.229 9.359 5.858

19 13.527 6.594 12.784 6.416 12.042 6.237 11.3 6.059 10.558 5.881 9.667 5.667

20 13.727 5.717 13.004 5.64 12.281 5.563 11.558 5.486 10.834 5.409 9.966 5.317

18 13.326 9.627 12.563 9.318 11.8 9.008 11.037 8.699 10.274 8.389 9.359 8.018

19 13.527 8.754 12.784 8.576 12.042 8.397 11.3 8.219 10.558 8.041 9.667 7.827

20 13.727 7.877 13.004 7.8 12.281 7.723 11.558 7.646 10.834 7.569 9.966 7.477

21 13.928 6.998 13.223 7.003 12.517 7.007 11.812 7.012 11.107 7.016 10.26 7.021

22 14.129 6.119 13.441 6.205 12.754 6.291 12.067 6.377 11.379 6.463 10.554 6.565

23 14.329 5.24 13.66 5.407 12.99 5.575 12.321 5.742 11.652 5.909 10.848 6.11

24 14.53 4.361 13.878 4.61 13.227 4.858 12.576 5.107 11.924 5.356 11.143 5.654

20 13.727 8.957 13.004 8.88 12.281 8.803 11.558 8.726 10.834 8.649 9.966 8.557

21 13.928 8.078 13.223 8.083 12.517 8.087 11.812 8.092 11.107 8.096 10.26 8.101

22 14.129 7.199 13.441 7.285 12.754 7.371 12.067 7.457 11.379 7.543 10.554 7.646

23 14.329 6.32 13.66 6.488 12.99 6.655 12.321 6.822 11.652 6.989 10.848 7.19

24 14.53 5.441 13.878 5.69 13.227 5.938 12.576 6.187 11.924 6.436 11.143 6.734

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: ACK 40ER - ALC 40CR (3 Phase)
Heating Mode

ID

DB°C

15

17

19

21

23

25

27

-9 -6 -5 6 12 15 18

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

5.536 5.536 6.635 6.635 7.002 7.002 11.034 11.034 13.233 13.233 14.332 14.332 15.432 15.432

5.469 5.469 6.524 6.524 6.875 6.875 11.156 11.156 12.875 12.875 13.934 13.934 14.993 14.993

5.403 5.403 6.412 6.412 6.748 6.748 11.279 11.279 12.518 12.518 13.536 13.536 14.555 14.555

5.336 5.336 6.3 6.3 6.621 6.621 11.401 11.401 12.161 12.161 13.138 13.138 14.116 14.116

5.257 5.257 6.185 6.185 6.494 6.494 10.706 10.706 11.803 11.803 12.74 12.74 13.677 13.677

5.178 5.178 6.07 6.07 6.367 6.367 10.01 10.01 11.446 11.446 12.342 12.342 13.238 13.238

5.098 5.098 5.955 5.955 6.24 6.24 9.314 9.314 11.089 11.089 11.944 11.944 12.8 12.8

FROST REGION

Outdoor WB°C

87

ACK-E-2009 Performance Data

Model: ACK 50ER - ALC 50CR
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 14.59 9.052 13.731 8.3 12.872 7.547 12.013 6.794 11.154 6.041 10.124 5.138

16 14.78 8.071 13.973 7.468 13.167 6.864 12.361 6.261 11.554 5.657 10.587 4.933

16 14.78 10.609 13.973 10.006 13.167 9.402 12.361 8.798 11.554 8.195 10.587 7.471

17 14.969 9.628 14.215 9.174 13.462 8.719 12.708 8.265 11.954 7.811 11.05 7.265

18 15.158 8.647 14.457 8.342 13.756 8.037 13.055 7.732 12.354 7.426 11.513 7.06

19 15.347 7.666 14.699 7.51 14.051 7.354 13.402 7.198 12.754 7.042 11.976 6.855

20 15.533 6.68 14.912 6.632 14.29 6.585 13.668 6.538 13.047 6.49 12.301 6.433

18 15.158 11.185 14.457 10.88 13.756 10.574 13.055 10.269 12.354 9.964 11.513 9.598

19 15.347 10.204 14.699 10.048 14.051 9.892 13.402 9.736 12.754 9.58 11.976 9.393

20 15.533 9.218 14.912 9.17 14.29 9.123 13.668 9.075 13.047 9.028 12.301 8.971

21 15.717 8.228 15.105 8.262 14.492 8.296 13.88 8.33 13.268 8.364 12.533 8.404

22 15.901 7.239 15.298 7.354 14.695 7.469 14.092 7.584 13.489 7.7 12.765 7.838

23 16.085 6.25 15.491 6.446 14.898 6.643 14.304 6.839 13.71 7.035 12.998 7.271

24 16.269 5.261 15.685 5.538 15.1 5.816 14.516 6.094 13.931 6.371 13.23 6.704

20 15.533 10.486 14.912 10.439 14.29 10.392 13.668 10.344 13.047 10.297 12.301 10.24

21 15.717 9.497 15.105 9.531 14.492 9.565 13.88 9.599 13.268 9.633 12.533 9.673

22 15.901 8.508 15.298 8.623 14.695 8.738 14.092 8.853 13.489 8.968 12.765 9.107

23 16.085 7.519 15.491 7.715 14.898 7.912 14.304 8.108 13.71 8.304 12.998 8.54

24 16.269 6.529 15.685 6.807 15.1 7.085 14.516 7.362 13.931 7.64 13.23 7.973

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: ACK 50ER - ALC 50CR
Heating Mode

ID

DB°C

15

17

19

21

23

25

27

-9 -6 -5 6 12 15 18

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

6.327 6.327 7.575 7.575 7.991 7.991 12.567 12.567 15.062 15.062 16.31 16.31 17.558 17.558

6.253 6.253 7.448 7.448 7.846 7.846 12.643 12.643 14.656 14.656 15.857 15.857 17.059 17.059

6.18 6.18 7.321 7.321 7.702 7.702 12.718 12.718 14.249 14.249 15.404 15.404 16.56 16.56

6.106 6.106 7.194 7.194 7.557 7.557 12.794 12.794 13.842 13.842 14.952 14.952 16.061 16.061

6.013 6.013 7.063 7.063 7.412 7.412 12.069 12.069 13.436 13.436 14.499 14.499 15.562 15.562

5.92 5.92 6.931 6.931 7.268 7.268 11.345 11.345 13.029 13.029 14.046 14.046 15.062 15.062

5.828 5.828 6.799 6.799 7.123 7.123 10.62 10.62 12.622 12.622 13.593 13.593 14.563 14.563

FROST REGION

Outdoor WB°C

88

Performance Data ACK-E-2009

Cooling Only (R410A)

Model: A5CK 20E - A5LC 20C
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 6.043 3.869 5.628 3.454 5.236 3.062 4.844 2.67 4.452 2.277 3.981 1.807

16 6.16 3.597 5.769 3.226 5.389 2.866 5.009 2.507 4.63 2.147 4.174 1.716

16 6.16 4.839 5.769 4.468 5.389 4.109 5.009 3.749 4.63 3.39 4.174 2.958

17 6.282 4.567 5.914 4.24 5.546 3.913 5.179 3.587 4.811 3.26 4.37 2.868

18 6.393 4.284 6.041 3.994 5.69 3.704 5.338 3.415 4.987 3.125 4.565 2.778

19 6.488 3.99 6.077 3.681 5.665 3.373 5.254 3.064 5.03 2.893 4.761 2.687

20 6.611 3.705 6.274 3.426 5.938 3.147 5.601 2.868 5.265 2.589 4.861 2.254

18 6.393 5.526 6.041 5.237 5.69 4.947 5.338 4.657 4.987 4.368 4.565 4.02

19 6.488 5.232 6.077 4.924 5.665 4.615 5.254 4.306 5.03 4.135 4.761 3.929

20 6.611 4.948 6.274 4.669 5.938 4.39 5.601 4.111 5.265 3.832 4.861 3.497

21 6.718 4.652 6.38 4.347 6.042 4.041 5.704 3.736 5.367 3.43 4.961 3.064

22 6.825 4.357 6.486 4.025 6.147 3.693 5.808 3.361 5.468 3.029 5.061 2.631

23 6.933 4.061 6.592 3.703 6.251 3.345 5.911 2.986 5.57 2.628 5.161 2.198

24 7.04 3.766 6.698 3.381 6.356 2.996 6.014 2.612 5.672 2.227 5.261 1.765

20 6.611 5.569 6.274 5.29 5.938 5.011 5.601 4.732 5.265 4.453 4.861 4.118

21 6.718 5.274 6.38 4.968 6.042 4.663 5.704 4.357 5.367 4.052 4.961 3.685

22 6.825 4.978 6.486 4.646 6.147 4.314 5.808 3.982 5.468 3.651 5.061 3.252

23 6.933 4.683 6.592 4.324 6.251 3.966 5.911 3.608 5.57 3.249 5.161 2.819

24 7.04 4.387 6.698 4.002 6.356 3.618 6.014 3.233 5.672 2.848 5.261 2.387

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: A5CK 25E - A5LC 25C
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 6.553 4.344 6.133 3.924 5.745 3.536 5.357 3.148 4.969 2.76 4.504 2.295

16 6.781 4.071 6.35 3.697 5.935 3.339 5.521 2.981 5.106 2.622 4.609 2.193

16 6.781 5.334 6.35 4.959 5.935 4.601 5.521 4.243 5.106 3.885 4.609 3.455

17 7.008 5.061 6.567 4.732 6.125 4.404 5.684 4.075 5.243 3.747 4.713 3.352

18 7.221 4.773 6.759 4.48 6.297 4.187 5.834 3.895 5.372 3.602 4.818 3.25

19 7.458 4.478 7.094 4.182 6.731 3.886 6.367 3.59 5.711 3.389 4.922 3.148

20 7.646 4.184 7.142 3.89 6.638 3.597 6.134 3.304 5.63 3.01 5.026 2.658

18 7.221 6.036 6.759 5.743 6.297 5.45 5.834 5.157 5.372 4.864 4.818 4.512

19 7.458 5.74 7.094 5.444 6.731 5.148 6.367 4.852 5.711 4.651 4.922 4.41

20 7.646 5.446 7.142 5.153 6.638 4.859 6.134 4.566 5.63 4.272 5.026 3.92

21 7.859 5.144 7.334 4.815 6.809 4.485 6.284 4.156 5.759 3.826 5.129 3.431

22 8.072 4.842 7.526 4.477 6.98 4.111 6.434 3.745 5.888 3.38 5.232 2.941

23 8.285 4.54 7.718 4.139 7.15 3.737 6.583 3.335 6.016 2.933 5.336 2.451

24 8.497 4.238 7.909 3.801 7.321 3.363 6.733 2.925 6.145 2.487 5.439 1.962

20 7.646 6.077 7.142 5.784 6.638 5.49 6.134 5.197 5.63 4.904 5.026 4.551

21 7.859 5.775 7.334 5.446 6.809 5.116 6.284 4.787 5.759 4.457 5.129 4.062

22 8.072 5.473 7.526 5.108 6.98 4.742 6.434 4.376 5.888 4.011 5.232 3.572

23 8.285 5.172 7.718 4.77 7.15 4.368 6.583 3.966 6.016 3.564 5.336 3.082

24 8.497 4.87 7.909 4.432 7.321 3.994 6.733 3.556 6.145 3.118 5.439 2.593

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

89

ACK-E-2009 Performance Data

Model: A5CK 28E - A5LC 28C
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 8.526 5.482 7.952 4.908 7.412 4.369 6.873 3.83 6.334 3.291 5.686 2.644

16 8.751 5.113 8.186 4.599 7.639 4.103 7.092 3.607 6.545 3.11 5.888 2.515

16 8.751 6.85 8.186 6.336 7.639 5.84 7.092 5.344 6.545 4.848 5.888 4.252

17 8.976 6.481 8.421 6.027 7.866 5.574 7.311 5.12 6.756 4.667 6.089 4.123

18 9.185 6.095 8.629 5.691 8.072 5.287 7.516 4.883 6.959 4.479 6.291 3.994

19 9.4 5.699 8.867 5.291 8.334 4.883 7.801 4.475 7.206 4.198 6.492 3.864

20 9.602 5.306 9.03 4.91 8.458 4.514 7.887 4.118 7.315 3.722 6.629 3.246

18 9.185 7.832 8.629 7.428 8.072 7.024 7.516 6.62 6.959 6.216 6.291 5.731

19 9.4 7.436 8.867 7.028 8.334 6.62 7.801 6.212 7.206 5.935 6.492 5.602

20 9.602 7.044 9.03 6.647 8.458 6.251 7.887 5.855 7.315 5.459 6.629 4.984

21 9.809 6.64 9.223 6.203 8.638 5.765 8.053 5.328 7.467 4.89 6.765 4.366

22 10.015 6.237 9.417 5.758 8.818 5.279 8.219 4.801 7.62 4.322 6.901 3.748

23 10.222 5.833 9.61 5.313 8.997 4.793 8.385 4.273 7.773 3.753 7.038 3.13

24 10.429 5.43 9.803 4.869 9.177 4.307 8.551 3.746 7.925 3.185 7.174 2.512

20 9.602 7.912 9.03 7.516 8.458 7.12 7.887 6.724 7.315 6.328 6.629 5.852

21 9.809 7.509 9.223 7.071 8.638 6.634 8.053 6.196 7.467 5.759 6.765 5.234

22 10.015 7.105 9.417 6.627 8.818 6.148 8.219 5.669 7.62 5.191 6.901 4.616

23 10.222 6.702 9.61 6.182 8.997 5.662 8.385 5.142 7.773 4.622 7.038 3.998

24 10.429 6.298 9.803 5.737 9.177 5.176 8.551 4.615 7.925 4.054 7.174 3.38

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

90

Performance Data ACK-E-2009

Model: A5CK 40E - A5LC 35C (1 Phase)
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 9.941 6.288 9.131 5.477 8.325 4.672 7.52 3.867 6.715 3.061 5.748 2.095

16 10.082 5.815 9.271 5.073 8.463 4.333 7.655 3.592 6.847 2.852 5.878 1.964

16 10.082 7.903 9.271 7.16 8.463 6.42 7.655 5.68 6.847 4.94 5.878 4.052

17 10.224 7.431 9.413 6.756 8.602 6.081 7.792 5.406 6.981 4.731 6.008 3.921

18 10.364 6.956 9.551 6.348 8.739 5.739 7.926 5.13 7.113 4.521 6.138 3.791

19 10.525 6.485 9.818 5.957 9.11 5.429 8.402 4.901 7.432 4.337 6.269 3.66

20 10.644 5.989 9.828 5.421 9.012 4.853 8.196 4.285 7.38 3.717 6.4 3.035

18 10.364 9.044 9.551 8.435 8.739 7.826 7.926 7.218 7.113 6.609 6.138 5.878

19 10.525 8.572 9.818 8.045 9.11 7.517 8.402 6.989 7.432 6.425 6.269 5.748

20 10.644 8.077 9.828 7.508 9.012 6.94 8.196 6.372 7.38 5.804 6.4 5.123

21 10.784 7.584 9.966 6.99 9.149 6.397 8.331 5.803 7.513 5.21 6.532 4.498

22 10.924 7.091 10.105 6.472 9.285 5.853 8.466 5.234 7.647 4.615 6.664 3.873

23 11.064 6.598 10.243 5.953 9.422 5.309 8.601 4.665 7.78 4.021 6.795 3.248

24 11.204 6.105 10.381 5.435 9.559 4.766 8.736 4.096 7.914 3.426 6.927 2.623

20 10.644 9.12 9.828 8.552 9.012 7.984 8.196 7.416 7.38 6.848 6.4 6.167

21 10.784 8.627 9.966 8.034 9.149 7.441 8.331 6.847 7.513 6.254 6.532 5.542

22 10.924 8.135 10.105 7.516 9.285 6.897 8.466 6.278 7.647 5.659 6.664 4.917

23 11.064 7.642 10.243 6.997 9.422 6.353 8.601 5.709 7.78 5.065 6.795 4.292

24 11.204 7.149 10.381 6.479 9.559 5.809 8.736 5.14 7.914 4.47 6.927 3.667

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: A5CK 40E - A5LC 35C (3 Phase)
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 9.319 5.853 8.669 5.203 8.05 4.584 7.432 3.966 6.813 3.347 6.071 2.605

16 9.616 5.458 8.955 4.87 8.31 4.298 7.666 3.726 7.021 3.154 6.247 2.467

16 9.616 7.439 8.955 6.85 8.31 6.278 7.666 5.706 7.021 5.134 6.247 4.448

17 9.914 7.043 9.243 6.518 8.572 5.992 7.901 5.466 7.23 4.941 6.425 4.31

18 10.198 6.633 9.506 6.16 8.815 5.687 8.123 5.213 7.432 4.74 6.602 4.172

19 10.517 6.223 9.983 5.799 9.449 5.376 8.915 4.952 7.944 4.535 6.78 4.034

20 10.763 5.794 10.025 5.329 9.286 4.863 8.547 4.398 7.808 3.932 6.922 3.374

18 10.198 8.614 9.506 8.141 8.815 7.667 8.123 7.194 7.432 6.72 6.602 6.152

19 10.517 8.204 9.983 7.78 9.449 7.356 8.915 6.933 7.944 6.515 6.78 6.014

20 10.763 7.775 10.025 7.309 9.286 6.844 8.547 6.378 7.808 5.913 6.922 5.354

21 11.046 7.345 10.28 6.836 9.514 6.326 8.749 5.816 7.983 5.306 7.064 4.694

22 11.328 6.916 10.535 6.362 9.743 5.808 8.95 5.253 8.158 4.699 7.207 4.034

23 11.61 6.487 10.791 5.888 9.971 5.29 9.152 4.691 8.332 4.092 7.349 3.374

24 11.892 6.057 11.046 5.414 10.2 4.771 9.353 4.128 8.507 3.485 7.491 2.714

20 10.763 8.765 10.025 8.3 9.286 7.834 8.547 7.369 7.808 6.903 6.922 6.345

21 11.046 8.336 10.28 7.826 9.514 7.316 8.749 6.806 7.983 6.296 7.064 5.684

22 11.328 7.906 10.535 7.352 9.743 6.798 8.95 6.244 8.158 5.689 7.207 5.024

23 11.61 7.477 10.791 6.879 9.971 6.28 9.152 5.681 8.332 5.083 7.349 4.364

24 11.892 7.048 11.046 6.405 10.2 5.762 9.353 5.119 8.507 4.476 7.491 3.704

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

91

ACK-E-2009 Performance Data

Model: A5CK 40E - A5LC 40C (1 Phase)
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 11.252 7.087 10.56 6.396 9.743 5.752 8.927 5.108 8.111 4.464 7.132 3.691

16 11.666 6.645 10.973 6.027 10.219 5.432 9.464 4.837 8.71 4.242 7.804 3.529

16 11.666 8.612 10.973 7.994 10.219 7.399 9.464 6.804 8.71 6.209 7.804 5.495

17 12.079 8.171 11.387 7.625 10.694 7.079 10.001 6.534 9.309 5.988 8.477 5.333

18 12.55 7.707 11.897 7.22 11.243 6.732 10.589 6.244 9.935 5.756 9.151 5.171

19 13.037 7.234 12.501 6.756 11.964 6.278 11.427 5.8 10.698 5.44 9.824 5.009

20 13.475 6.758 12.813 6.273 12.15 5.787 11.488 5.302 10.825 4.816 10.03 4.234

18 12.55 9.674 11.897 9.186 11.243 8.699 10.589 8.211 9.935 7.723 9.151 7.138

19 13.037 9.201 12.501 8.723 11.964 8.245 11.427 7.767 10.698 7.407 9.824 6.976

20 13.475 8.725 12.813 8.239 12.15 7.754 11.488 7.268 10.825 6.783 10.03 6.2

21 13.929 8.239 13.219 7.698 12.509 7.157 11.799 6.615 11.089 6.074 10.236 5.425

22 14.383 7.753 13.625 7.156 12.867 6.559 12.11 5.962 11.352 5.365 10.443 4.649

23 14.837 7.267 14.031 6.614 13.226 5.962 12.421 5.309 11.615 4.657 10.649 3.874

24 15.291 6.781 14.438 6.073 13.585 5.365 12.732 4.656 11.879 3.948 10.855 3.098

20 13.475 9.708 12.813 9.223 12.15 8.737 11.488 8.252 10.825 7.766 10.03 7.184

21 13.929 9.222 13.219 8.681 12.509 8.14 11.799 7.599 11.089 7.057 10.236 6.408

22 14.383 8.736 13.625 8.139 12.867 7.543 12.11 6.946 11.352 6.349 10.443 5.633

23 14.837 8.25 14.031 7.598 13.226 6.945 12.421 6.293 11.615 5.64 10.649 4.857

24 15.291 7.764 14.438 7.056 13.585 6.348 12.732 5.64 11.879 4.931 10.855 4.082

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: A5CK 40E - A5LC 40C (3 Phase)
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 11.313 7.381 10.646 6.707 9.862 6.086 9.079 5.466 8.295 4.846 7.356 4.102

16 11.692 6.931 10.993 6.333 10.235 5.762 9.477 5.191 8.719 4.62 7.81 3.934

16 11.692 8.791 10.993 8.193 10.235 7.622 9.477 7.051 8.719 6.479 7.81 5.794

17 12.072 8.341 11.34 7.819 10.607 7.297 9.875 6.775 9.143 6.253 8.265 5.627

18 12.505 7.867 11.777 7.404 11.05 6.941 10.322 6.478 9.594 6.015 8.72 5.46

19 12.971 7.374 12.404 6.879 11.837 6.383 11.271 5.888 10.318 5.617 9.175 5.292

20 13.363 6.895 12.595 6.433 11.827 5.971 11.058 5.509 10.29 5.047 9.368 4.493

18 12.505 9.727 11.777 9.264 11.05 8.801 10.322 8.338 9.594 7.875 8.72 7.319

19 12.971 9.234 12.404 8.738 11.837 8.243 11.271 7.747 10.318 7.477 9.175 7.152

20 13.363 8.755 12.595 8.293 11.827 7.831 11.058 7.369 10.29 6.907 9.368 6.352

21 13.787 8.257 12.975 7.737 12.162 7.217 11.349 6.697 10.536 6.177 9.561 5.552

22 14.212 7.759 13.354 7.181 12.497 6.603 11.64 6.025 10.782 5.446 9.754 4.753

23 14.636 7.261 13.734 6.625 12.832 5.989 11.93 5.353 11.028 4.716 9.946 3.953

24 15.06 6.764 14.113 6.069 13.167 5.375 12.221 4.681 11.274 3.986 10.139 3.153

20 13.363 9.684 12.595 9.222 11.827 8.76 11.058 8.298 10.29 7.836 9.368 7.282

21 13.787 9.187 12.975 8.667 12.162 8.146 11.349 7.626 10.536 7.106 9.561 6.482

22 14.212 8.689 13.354 8.111 12.497 7.533 11.64 6.954 10.782 6.376 9.754 5.683

23 14.636 8.191 13.734 7.555 12.832 6.919 11.93 6.282 11.028 5.646 9.946 4.883

24 15.06 7.693 14.113 6.999 13.167 6.305 12.221 5.61 11.274 4.916 10.139 4.083

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

92

Performance Data ACK-E-2009

Model: A5CK 50E - A5LC 50C
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 13.022 8.478 12.216 7.672 11.482 6.938 10.747 6.203 10.013 5.469 9.131 4.587

16 13.447 7.897 12.686 7.192 11.961 6.523 11.235 5.853 10.51 5.183 9.639 4.38

16 13.447 10.494 12.686 9.789 11.961 9.119 11.235 8.45 10.51 7.78 9.639 6.976

17 13.872 9.914 13.156 9.309 12.439 8.704 11.723 8.099 11.006 7.494 10.147 6.769

18 14.265 9.301 13.571 8.774 12.876 8.247 12.182 7.72 11.488 7.193 10.654 6.561

19 14.641 8.643 13.883 7.972 13.125 7.301 12.368 6.63 11.82 6.504 11.162 6.354

20 15.04 8.046 14.34 7.529 13.639 7.013 12.938 6.497 12.237 5.98 11.396 5.361

18 14.265 11.897 13.571 11.37 12.876 10.844 12.182 10.317 11.488 9.79 10.654 9.158

19 14.641 11.24 13.883 10.569 13.125 9.897 12.368 9.226 11.82 9.101 11.162 8.95

20 15.04 10.642 14.34 10.126 13.639 9.61 12.938 9.093 12.237 8.577 11.396 7.957

21 15.423 10 14.694 9.416 13.964 8.833 13.235 8.249 12.506 7.665 11.631 6.965

22 15.806 9.358 15.048 8.707 14.29 8.056 13.532 7.404 12.775 6.753 11.865 5.972

23 16.188 8.716 15.402 7.997 14.616 7.279 13.829 6.56 13.043 5.841 12.1 4.979

24 16.571 8.074 15.756 7.288 14.941 6.502 14.127 5.716 13.312 4.93 12.334 3.986

20 15.04 11.941 14.34 11.424 13.639 10.908 12.938 10.392 12.237 9.875 11.396 9.256

21 15.423 11.298 14.694 10.715 13.964 10.131 13.235 9.547 12.506 8.963 11.631 8.263

22 15.806 10.656 15.048 10.005 14.29 9.354 13.532 8.703 12.775 8.052 11.865 7.27

23 16.188 10.014 15.402 9.296 14.616 8.577 13.829 7.858 13.043 7.14 12.1 6.277

24 16.571 9.372 15.756 8.586 14.941 7.8 14.127 7.014 13.312 6.228 12.334 5.284

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

93

ACK-E-2009 Performance Data

Heat Pump (R410A)

Model: A5CK 20ER - A5LC 20CR
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 6.043 3.869 5.628 3.454 5.236 3.062 4.844 2.67 4.452 2.277 3.981 1.807

16 6.16 3.597 5.769 3.226 5.389 2.866 5.009 2.507 4.63 2.147 4.174 1.716

16 6.16 4.839 5.769 4.468 5.389 4.109 5.009 3.749 4.63 3.39 4.174 2.958

17 6.282 4.567 5.914 4.24 5.546 3.913 5.179 3.587 4.811 3.26 4.37 2.868

18 6.393 4.284 6.041 3.994 5.69 3.704 5.338 3.415 4.987 3.125 4.565 2.778

19 6.488 3.99 6.077 3.681 5.665 3.373 5.254 3.064 5.03 2.893 4.761 2.687

20 6.611 3.705 6.274 3.426 5.938 3.147 5.601 2.868 5.265 2.589 4.861 2.254

18 6.393 5.526 6.041 5.237 5.69 4.947 5.338 4.657 4.987 4.368 4.565 4.02

19 6.488 5.232 6.077 4.924 5.665 4.615 5.254 4.306 5.03 4.135 4.761 3.929

20 6.611 4.948 6.274 4.669 5.938 4.39 5.601 4.111 5.265 3.832 4.861 3.497

21 6.718 4.652 6.38 4.347 6.042 4.041 5.704 3.736 5.367 3.43 4.961 3.064

22 6.825 4.357 6.486 4.025 6.147 3.693 5.808 3.361 5.468 3.029 5.061 2.631

23 6.933 4.061 6.592 3.703 6.251 3.345 5.911 2.986 5.57 2.628 5.161 2.198

24 7.04 3.766 6.698 3.381 6.356 2.996 6.014 2.612 5.672 2.227 5.261 1.765

20 6.611 5.569 6.274 5.29 5.938 5.011 5.601 4.732 5.265 4.453 4.861 4.118

21 6.718 5.274 6.38 4.968 6.042 4.663 5.704 4.357 5.367 4.052 4.961 3.685

22 6.825 4.978 6.486 4.646 6.147 4.314 5.808 3.982 5.468 3.651 5.061 3.252

23 6.933 4.683 6.592 4.324 6.251 3.966 5.911 3.608 5.57 3.249 5.161 2.819

24 7.04 4.387 6.698 4.002 6.356 3.618 6.014 3.233 5.672 2.848 5.261 2.387

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: A5CK 20ER - A5LC 20CR
Heating Mode

ID

DB°C

15

17

19

21

23

25

27

-9 -6 -5 6 12 15 18

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

3.075 3.075 3.481 3.481 3.616 3.616 5.103 5.103 5.913 5.913 6.319 6.319 6.724 6.724

2.995 2.995 3.475 3.475 3.538 3.538 5.096 5.096 5.847 5.847 6.255 6.255 6.662 6.662

2.914 2.914 3.47 3.47 3.46 3.46 5.09 5.09 5.781 5.781 6.191 6.191 6.601 6.601

2.834 2.834 3.402 3.402 3.382 3.382 5.029 5.029 5.715 5.715 6.127 6.127 6.539 6.539

2.753 2.753 3.271 3.271 3.305 3.305 4.913 4.913 5.649 5.649 6.063 6.063 6.477 6.477

2.672 2.672 3.14 3.14 3.227 3.227 4.797 4.797 5.583 5.583 5.999 5.999 6.415 6.415

2.592 2.592 3.01 3.01 3.149 3.149 4.682 4.682 5.518 5.518 5.935 5.935 6.353 6.353

FROST REGION

Outdoor WB°C

94

Performance Data ACK-E-2009

Model: A5CK 25ER - A5LC 25CR
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 6.553 4.344 6.133 3.924 5.745 3.536 5.357 3.148 4.969 2.76 4.504 2.295

16 6.781 4.071 6.35 3.697 5.935 3.339 5.521 2.981 5.106 2.622 4.609 2.193

16 6.781 5.334 6.35 4.959 5.935 4.601 5.521 4.243 5.106 3.885 4.609 3.455

17 7.008 5.061 6.567 4.732 6.125 4.404 5.684 4.075 5.243 3.747 4.713 3.352

18 7.221 4.773 6.759 4.48 6.297 4.187 5.834 3.895 5.372 3.602 4.818 3.25

19 7.458 4.478 7.094 4.182 6.731 3.886 6.367 3.59 5.711 3.389 4.922 3.148

20 7.646 4.184 7.142 3.89 6.638 3.597 6.134 3.304 5.63 3.01 5.026 2.658

18 7.221 6.036 6.759 5.743 6.297 5.45 5.834 5.157 5.372 4.864 4.818 4.512

19 7.458 5.74 7.094 5.444 6.731 5.148 6.367 4.852 5.711 4.651 4.922 4.41

20 7.646 5.446 7.142 5.153 6.638 4.859 6.134 4.566 5.63 4.272 5.026 3.92

21 7.859 5.144 7.334 4.815 6.809 4.485 6.284 4.156 5.759 3.826 5.129 3.431

22 8.072 4.842 7.526 4.477 6.98 4.111 6.434 3.745 5.888 3.38 5.232 2.941

23 8.285 4.54 7.718 4.139 7.15 3.737 6.583 3.335 6.016 2.933 5.336 2.451

24 8.497 4.238 7.909 3.801 7.321 3.363 6.733 2.925 6.145 2.487 5.439 1.962

20 7.646 6.077 7.142 5.784 6.638 5.49 6.134 5.197 5.63 4.904 5.026 4.551

21 7.859 5.775 7.334 5.446 6.809 5.116 6.284 4.787 5.759 4.457 5.129 4.062

22 8.072 5.473 7.526 5.108 6.98 4.742 6.434 4.376 5.888 4.011 5.232 3.572

23 8.285 5.172 7.718 4.77 7.15 4.368 6.583 3.966 6.016 3.564 5.336 3.082

24 8.497 4.87 7.909 4.432 7.321 3.994 6.733 3.556 6.145 3.118 5.439 2.593

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: A5CK 25ER - A5LC 25CR
Heating Mode

ID

DB°C

15

17

19

21

23

25

27

-9 -6 -5 6 12 15 18

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

3.497 3.497 3.958 3.958 4.112 4.112 5.802 5.802 6.724 6.724 7.185 7.185 7.646 7.646

3.405 3.405 4.08 4.08 4.016 4.016 5.795 5.795 6.613 6.613 7.071 7.071 7.529 7.529

3.314 3.314 4.201 4.201 3.921 3.921 5.788 5.788 6.501 6.501 6.956 6.956 7.412 7.412

3.222 3.222 4.138 4.138 3.825 3.825 5.697 5.697 6.389 6.389 6.842 6.842 7.294 7.294

3.13 3.13 3.889 3.889 3.73 3.73 5.52 5.52 6.278 6.278 6.727 6.727 7.177 7.177

3.039 3.039 3.64 3.64 3.634 3.634 5.343 5.343 6.166 6.166 6.613 6.613 7.06 7.06

2.947 2.947 3.391 3.391 3.539 3.539 5.167 5.167 6.054 6.054 6.498 6.498 6.942 6.942

FROST REGION

Outdoor WB°C

95

ACK-E-2009 Performance Data

Model: A5CK 28ER - A5LC 28CR
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 8.526 5.482 7.952 4.908 7.412 4.369 6.873 3.83 6.334 3.291 5.686 2.644

16 8.751 5.113 8.186 4.599 7.639 4.103 7.092 3.607 6.545 3.11 5.888 2.515

16 8.751 6.85 8.186 6.336 7.639 5.84 7.092 5.344 6.545 4.848 5.888 4.252

17 8.976 6.481 8.421 6.027 7.866 5.574 7.311 5.12 6.756 4.667 6.089 4.123

18 9.185 6.095 8.629 5.691 8.072 5.287 7.516 4.883 6.959 4.479 6.291 3.994

19 9.4 5.699 8.867 5.291 8.334 4.883 7.801 4.475 7.206 4.198 6.492 3.864

20 9.602 5.306 9.03 4.91 8.458 4.514 7.887 4.118 7.315 3.722 6.629 3.246

18 9.185 7.832 8.629 7.428 8.072 7.024 7.516 6.62 6.959 6.216 6.291 5.731

19 9.4 7.436 8.867 7.028 8.334 6.62 7.801 6.212 7.206 5.935 6.492 5.602

20 9.602 7.044 9.03 6.647 8.458 6.251 7.887 5.855 7.315 5.459 6.629 4.984

21 9.809 6.64 9.223 6.203 8.638 5.765 8.053 5.328 7.467 4.89 6.765 4.366

22 10.015 6.237 9.417 5.758 8.818 5.279 8.219 4.801 7.62 4.322 6.901 3.748

23 10.222 5.833 9.61 5.313 8.997 4.793 8.385 4.273 7.773 3.753 7.038 3.13

24 10.429 5.43 9.803 4.869 9.177 4.307 8.551 3.746 7.925 3.185 7.174 2.512

20 9.602 7.912 9.03 7.516 8.458 7.12 7.887 6.724 7.315 6.328 6.629 5.852

21 9.809 7.509 9.223 7.071 8.638 6.634 8.053 6.196 7.467 5.759 6.765 5.234

22 10.015 7.105 9.417 6.627 8.818 6.148 8.219 5.669 7.62 5.191 6.901 4.616

23 10.222 6.702 9.61 6.182 8.997 5.662 8.385 5.142 7.773 4.622 7.038 3.998

24 10.429 6.298 9.803 5.737 9.177 5.176 8.551 4.615 7.925 4.054 7.174 3.38

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: A5CK 28ER - A5LC 28CR
Heating Mode

ID

DB°C

15

17

19

21

23

25

27

-9 -6 -5 6 12 15 18

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

4.889 4.889 5.534 5.534 5.749 5.749 8.112 8.112 9.401 9.401 10.046 10.046 10.69 10.69

4.761 4.761 5.326 5.326 5.631 5.631 8.102 8.102 9.328 9.328 9.981 9.981 10.633 10.633

4.633 4.633 5.119 5.119 5.513 5.513 8.093 8.093 9.255 9.255 9.915 9.915 10.576 10.576

4.505 4.505 4.986 4.986 5.396 5.396 8.015 8.015 9.182 9.182 9.85 9.85 10.518 10.518

4.377 4.377 4.928 4.928 5.278 5.278 7.87 7.87 9.109 9.109 9.785 9.785 10.461 10.461

4.248 4.248 4.87 4.87 5.16 5.16 7.725 7.725 9.036 9.036 9.72 9.72 10.404 10.404

4.12 4.12 4.812 4.812 5.043 5.043 7.579 7.579 8.963 8.963 9.655 9.655 10.346 10.346

FROST REGION

Outdoor WB°C

96

Performance Data ACK-E-2009

Model: A5CK 40ER - A5LC 35CR (1 Phase)
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 9.941 6.288 9.131 5.477 8.325 4.672 7.52 3.867 6.715 3.061 5.748 2.095

16 10.082 5.815 9.271 5.073 8.463 4.333 7.655 3.592 6.847 2.852 5.878 1.964

16 10.082 7.903 9.271 7.16 8.463 6.42 7.655 5.68 6.847 4.94 5.878 4.052

17 10.224 7.431 9.413 6.756 8.602 6.081 7.792 5.406 6.981 4.731 6.008 3.921

18 10.364 6.956 9.551 6.348 8.739 5.739 7.926 5.13 7.113 4.521 6.138 3.791

19 10.525 6.485 9.818 5.957 9.11 5.429 8.402 4.901 7.432 4.337 6.269 3.66

20 10.644 5.989 9.828 5.421 9.012 4.853 8.196 4.285 7.38 3.717 6.4 3.035

18 10.364 9.044 9.551 8.435 8.739 7.826 7.926 7.218 7.113 6.609 6.138 5.878

19 10.525 8.572 9.818 8.045 9.11 7.517 8.402 6.989 7.432 6.425 6.269 5.748

20 10.644 8.077 9.828 7.508 9.012 6.94 8.196 6.372 7.38 5.804 6.4 5.123

21 10.784 7.584 9.966 6.99 9.149 6.397 8.331 5.803 7.513 5.21 6.532 4.498

22 10.924 7.091 10.105 6.472 9.285 5.853 8.466 5.234 7.647 4.615 6.664 3.873

23 11.064 6.598 10.243 5.953 9.422 5.309 8.601 4.665 7.78 4.021 6.795 3.248

24 11.204 6.105 10.381 5.435 9.559 4.766 8.736 4.096 7.914 3.426 6.927 2.623

20 10.644 9.12 9.828 8.552 9.012 7.984 8.196 7.416 7.38 6.848 6.4 6.167

21 10.784 8.627 9.966 8.034 9.149 7.441 8.331 6.847 7.513 6.254 6.532 5.542

22 10.924 8.135 10.105 7.516 9.285 6.897 8.466 6.278 7.647 5.659 6.664 4.917

23 11.064 7.642 10.243 6.997 9.422 6.353 8.601 5.709 7.78 5.065 6.795 4.292

24 11.204 7.149 10.381 6.479 9.559 5.809 8.736 5.14 7.914 4.47 6.927 3.667

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: A5CK 40ER - A5LC 35CR (1 Phase)
Heating Mode

ID

DB°C

15

17

19

21

23

25

27

-9 -6 -5 6 12 15 18

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

5.527 5.527 6.256 6.256 6.499 6.499 9.171 9.171 10.628 10.628 11.357 11.357 12.085 12.085

5.382 5.382 5.751 5.751 6.383 6.383 9.16 9.16 10.633 10.633 11.383 11.383 12.133 12.133

5.238 5.238 5.247 5.247 6.266 6.266 9.149 9.149 10.637 10.637 11.409 11.409 12.18 12.18

5.093 5.093 5.069 5.069 6.15 6.15 9.115 9.115 10.642 10.642 11.435 11.435 12.228 12.228

4.948 4.948 5.217 5.217 6.033 6.033 9.057 9.057 10.647 10.647 11.461 11.461 12.275 12.275

4.803 4.803 5.366 5.366 5.917 5.917 9 9 10.652 10.652 11.487 11.487 12.323 12.323

4.658 4.658 5.515 5.515 5.801 5.801 8.943 8.943 10.656 10.656 11.513 11.513 12.37 12.37

FROST REGION

Outdoor WB°C

97

ACK-E-2009 Performance Data

Model: A5CK 40ER - A5LC 35CR (3 Phase)
Cooling Mode

ID

DB°C

20

24

28

30

ID

WB°C

15 9.319 5.853 8.669 5.203 8.05 4.584 7.432 3.966 6.813 3.347 6.071 2.605

16 9.616 5.458 8.955 4.87 8.31 4.298 7.666 3.726 7.021 3.154 6.247 2.467

16 9.616 7.439 8.955 6.85 8.31 6.278 7.666 5.706 7.021 5.134 6.247 4.448

17 9.914 7.043 9.243 6.518 8.572 5.992 7.901 5.466 7.23 4.941 6.425 4.31

18 10.198 6.633 9.506 6.16 8.815 5.687 8.123 5.213 7.432 4.74 6.602 4.172

19 10.517 6.223 9.983 5.799 9.449 5.376 8.915 4.952 7.944 4.535 6.78 4.034

20 10.763 5.794 10.025 5.329 9.286 4.863 8.547 4.398 7.808 3.932 6.922 3.374

18 10.198 8.614 9.506 8.141 8.815 7.667 8.123 7.194 7.432 6.72 6.602 6.152

19 10.517 8.204 9.983 7.78 9.449 7.356 8.915 6.933 7.944 6.515 6.78 6.014

20 10.763 7.775 10.025 7.309 9.286 6.844 8.547 6.378 7.808 5.913 6.922 5.354

21 11.046 7.345 10.28 6.836 9.514 6.326 8.749 5.816 7.983 5.306 7.064 4.694

22 11.328 6.916 10.535 6.362 9.743 5.808 8.95 5.253 8.158 4.699 7.207 4.034

23 11.61 6.487 10.791 5.888 9.971 5.29 9.152 4.691 8.332 4.092 7.349 3.374

24 11.892 6.057 11.046 5.414 10.2 4.771 9.353 4.128 8.507 3.485 7.491 2.714

20 10.763 8.765 10.025 8.3 9.286 7.834 8.547 7.369 7.808 6.903 6.922 6.345

21 11.046 8.336 10.28 7.826 9.514 7.316 8.749 6.806 7.983 6.296 7.064 5.684

22 11.328 7.906 10.535 7.352 9.743 6.798 8.95 6.244 8.158 5.689 7.207 5.024

23 11.61 7.477 10.791 6.879 9.971 6.28 9.152 5.681 8.332 5.083 7.349 4.364

24 11.892 7.048 11.046 6.405 10.2 5.762 9.353 5.119 8.507 4.476 7.491 3.704

20 25 30 35 40 46

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

Outdoor DB°C

Model: A5CK 40ER - A5LC 35CR (3 Phase)
Heating Mode

ID

DB°C

15

17

19

21

23

25

27

-9 -6 -5 6 12 15 18

TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)

5.807 5.807 6.573 6.573 6.828 6.828 9.635 9.635 11.167 11.167 11.932 11.932 12.698 12.698

5.655 5.655 6.419 6.419 6.672 6.672 9.624 9.624 10.993 10.993 11.755 11.755 12.518 12.518

5.503 5.503 6.265 6.265 6.516 6.516 9.612 9.612 10.819 10.819 11.578 11.578 12.338 12.338

5.351 5.351 6.11 6.11 6.359 6.359 9.467 9.467 10.645 10.645 11.401 11.401 12.158 12.158

5.199 5.199 5.954 5.954 6.203 6.203 9.188 9.188 10.471 10.471 11.224 11.224 11.977 11.977

5.046 5.046 5.797 5.797 6.046 6.046 8.908 8.908 10.297 10.297 11.047 11.047 11.797 11.797

4.894 4.894 5.641 5.641 5.89 5.89 8.629 8.629 10.123 10.123 10.87 10.87 11.617 11.617

FROST REGION

Outdoor WB°C

98
