AcSiP Technology AI7688H User Manual

AI7688H User Manual

An IOT Solution Company

V.1 160407

-1-

AI7688H User Manual

Revision History

Revision Date Author Description

V.1 160407 Kevin New Create

-2-

AI7688H User Manual

Contents:

1. Introduction…………………………………………….……..4

2. Start AI7688H development …………………..……...5

3. Firmware and Bootloader…………...…………….......9

4. File Storage…………………………………………….……..19

5. Wi-Fi LED State…………………………………….…….….22

6. Network…………………………………………….………....24

7. AWS IoT…………………………………………….….…….…40

8. Peripheral………………………………………….…….…...43

9. C/C++ Programming………………………….…………..51

10. Using USB Webcam………………………………………58

11. Audio Playback and Recording…………..…………59

12. Federal Communication Commission Interference

Statement………………………………………………….….61

-3-

AI7688H User Manual

1. Introduction

AI7688H integrates a 1T1R 802.11n Wi-Fi radio, a 575/580 MHz MIPSR 24KEc

Ethemet PHY,USB2.0 host,PCIe,SD-XC,I2S/PCM and multiple slow IOs.

AI7688H provides two operation modes – IoT gateway mode and IoT device mode.In IoT gateway

Mode, the PCIe Express interface can connect to 802.11ac chipset for 11ac dual-band concurrent

Gateway. The high performance USB 2.0 allows AI7688H to add 3G/LTE modem support or add a

H.264 ISP for wireless IP camera. For the IoT device mode, AI7688Hsupports eMMC , SD-XC and

USB2.0. AI7688H can support the WiFi high quality audio via 192kbps/24bits I2S interface and

VoIP application through PCM. In IoT device mode, it further supports PWM,SPI slave,3rd UART

and more GPIOs. For IoT gateway, it can connect to touch panel and BLE,Zigbee/Z-Wave and

sub-1G RF for smart home control.

CPU, 1-port fast

-4-

AI7688H User Manual

2. Start AI7688H development

2.1 Get S/W

# Download an SSH client (Windows only)

PuTTY

provides Secure Socket Shell (SSH) access to the development board

operating system.

# Install Bonjour Print Service (For Windows 7 only)

The AI7688H development board uses mylinkit.local as its local domain. In Windows7, you’ll need to installBonjour print service

because mDNS is not

support.

This helps your computer discover the LinkIt Smart AI7688H’s IP address with the local domain name. For Windows 8 and later, Mac OS X and Linux, mDNS is supported and you can use mylinkit.local.

2.2 Power up AI7688H board

After bootup and Wi-Fi initialization completes, which takes about 30 seconds, the Wi-Fi

LED goes off. This means the system is ready to accept Wi-Fi connection – now we can connect to it. Following Figure shows how the Wi-Fi LED status matches the system state.

-5-

AI7688H User Manual

2.3 Find the AI7688H AP and connect

2.4 Open http://mylinkit.local

If the board already has a password and you don’t have or lost it,

You have to press “Wi-Fi Reset button” for at least 20 seconds then Release.

Then you can configure your password again.

-6-

AI7688H User Manual

Enter your Password

2.5 Get system Info and Upgrade F/W

2.6 Go to OpwnWrt for advanced configuration

-7-

AI7688H User Manual

2.7 Access system console

For OS X and Linux:

# Open Terminal application

# At the command prompt type

# ssh root@mylinkit.local

# Press return and enter the password you set previously in the Web UI

For Windows:

-8-

AI7688H User Manual

USB Drive

3 Firmware and Bootloader

3.1 Flash F/W from USB drive

# Download lates Firmware

# Unzip it and copy the unzipped lks7688.img file to the root directory of a FAT32

# Attach the USB drive to the HOST port of the board with an OTG cable.

# Hold the WiFi button

# Press the MPU reset button once while holding the WiFi button

# Keep holding WiFi button about 5 seconds. Release WiFi button until the WiFi orange

LED becomes OFF.

Do not press the Wi-Fi button for longer than 20s or it will upgrade the bootloader.

Wait while the WiFi LED blinks fast. This takes about 3 minutes.

The device will automatically reboot after firmware update completed.

-9-

AI7688H User Manual

3.2 Update bootloader

USB drive must be in FAT file system or the file cannot be recognized by the AI7688H

development platform.

# Save the bootloader file (lks7688.ldr) in the root directory of a USB drive and name it

lks7688.ldr.

# Plug the USB drive to AI7688H.

# Press the WiFi and MPU (Reset) button at the same time, then release the MPU Reset

button but hold the WiFi button for at least 20 seconds.

# After 20 seconds Wi-Fi LED will turn on. Release WiFi button.

The board will start to read the bootloader (WiFi LED blinks fast) and perform the

bootloader upgrade process (Wi-Fi LED blinks slowly). It takes about 2 seconds to finish

the bootloader upgrade process

3.3 Build F/W from Source

The following operations are performed under a Ubuntu LTS 14.04.3 environment. For a

Windows or a Mac OS X host computer, you can install a VM for having the same

environment:

 Install prerequisite packages for building the firmware:

$ sudo apt-get install git g++ libncurses5-dev subversion libssl-dev gawk

libxml-parser-perl unzip

 Download OpenWrt CC source codes:

$ git clone git://git.openwrt.org/15.05/openwrt.git

 Prepare the default configuration file for feeds:

$ cd openwrt

$ cp feeds.conf.default feeds.conf

-10-

AI7688H User Manual

ild an firmware for

 Add the AI7688H feed:

$ echo src-git linkit https://github.com/MediaTek-Labs/linkit-smart-7688-feed.git >>

feeds.conf

 Update the feed information of all available packages for building the firmware:

$ ./scripts/feeds update

 Install all packages:

$ ./scripts/feeds install -a

 Prepare the kernel configuration to inform OpenWrt that we want to bu

AI7688H:

$ make menuconfig

o Select the options as below:

 Target System: Ralink RT288x/RT3xxx  Subtarget: AI7688H based boards

o Save and exit (use the deafult config file name without changing it)

 Start the compilation process:

$ make V=99

 After the build process completes, the resulted firmware file will be under

bin/ramips/openwrt-ramips-7688-LinkIt7688-squashfs-sysupgrade.bin. Depending on the

H/W resources of the host environment, the build process may take more than 2 hours.

 You can use this file to do the firmware upgrade through the Web UI. Or rename it to

lks7688.img for upgrading through a USB drive

-11-

AI7688H User Manual

3.4 Build Bootloader from Source

The following operations are performed under a Ubuntu LTS 14.04.3 environment. For a

Windows or a Mac OS X host computer, you can install a VM for having the same

environment:

 Refer to Build_F/W_Source for installing all prerequisite packages.  Download the bootloader source codes:

$ git clone https://github.com/MediaTek-Labs/linkit-smart-uboot.git

 Change to the source folder:

$ cd linkit-smart-uboot

 Install the toolchain needed for building the bootloader:

$ sudo tar xjf buildroot-gcc342.tar.bz2 -C /opt/

 Since the toolchain is provided in 32-bit executables, you need to install additional

packages for execution on a 64-bit machine:

$ sudo dpkg --add-architecture i386

$ sudo apt-get update

$ sudo apt-get install libc6:i386 libncurses5:i386 libstdc++6:i386

 Start the compilation process:

$ make

 The resulted bootloader file is uboot.bin.  You can rename it to lks7688.ldr for upgrading the system bootloader through a USB

drive.

-12-

AI7688H User Manual

3.5 Rebuild Existing Kernel Packages

In the config menu, select the Kernel modules.

# Go to Filesystems and select the kmod-fs-ext4 as M (modularizes features). Note: other

kernel packages which kmod-fs-ext4 depends on will also be selected automatically.

# Follow the original build flow to continue the setup and save the configuration for the

firmware building process.

-13-

AI7688H User Manual

# After the building process is complete, you can find the kernel packages

under bin/ramips/packages/base/ (if the package you built is not there, you can also

use find command to locate where it is)

# After the building process is complete, you can find the kernel packages

under bin/ramips/packages/base/ (if the package you built is not there, you can also

use find command to locate where it is).

# Copy all related kernel module packages to a USB drive.

Plug the USB drive to AI7688H and perform the opkg install command to install all

necessary kernel packages from the USB drive.

root@mylinkit:/tmp/run/mountd/sda1# opkg install kmod*.ipk

Installing kmod-crypto-core (3.18.23-1) to root...

Installing kmod-crypto-hash (3.18.23-1) to root...

Installing kmod-fs-ext4 (3.18.23-1) to root...

Installing kmod-lib-crc16 (3.18.23-1) to root..

Package kmod-lib-crc16 (3.18.23-1) installed in root is up to date.

Configuring kmod-crypto-core.

Configuring kmod-crypto-hash.

Configuring kmod-lib-crc16.

Configuring kmod-fs-ext4.

Note: if you simply install the kmod-fs-ext4, an error will occur like

root@mylinkit:/tmp/run/mountd/sda1# opkg install

kmod-fs-ext4_3.18.23-1_ramips_24kec.ipk

Installing kmod-fs-ext4 (3.18.23-1) to root...

Collected errors:

* satisfy_dependencies_for: Cannot satisfy the following dependencies for kmod-fs-ext4:

* kmod-lib-crc16 * kmod-crypto-hash *

* opkg_install_cmd: Cannot install package kmod-fs-ext4.

From these information, we can know what additional kernel packages are also needed

for kmod-fs-ext4 under bin/ramips/packages/base/ in Step 5

-14-

AI7688H User Manual

3.6 Bootloader and Kernel Console

The Bootloader console and Linux kernel console are configured to serial port

UART2(UART_TXD2 and UART_RXD2) at baudrate 57600

[04060C0F][04060C0C]

DDR Calibration DQS reg = 0000898A

U-Boot 1.1.3 (Sep 10 2015 - 05:56:31)

Board: Ralink APSoC DRAM: 128 MB

relocate_code Pointer at: 87f68000

flash manufacture id: c2, device id 20 19

find flash: MX25L25635E

*** Warning - bad CRC, using default environment

============================================

Ralink UBoot Version: 4.3.0.0

--------------------------------------------

ASIC 7628_MP (Port5<->None)

DRAM component: 1024 Mbits DDR, width 16

DRAM bus: 16 bit

Total memory: 128 MBytes

Flash component: SPI Flash

Date:Sep 10 2015 Time:05:56:31

============================================

icache: sets:512, ways:4, linesz:32 ,total:65536

dcache: sets:256, ways:4, linesz:32 ,total:32768

##### The CPU freq = 580 MHZ ####

estimate memory size =128 Mbytes

RESET MT7628 PHY!!!!!!

GPIOMODE --> 50054404

GPIOMODE2 --> 5540551

Please choose the operation:

1: Load system code to SDRAM via TFTP.

2: Load system code then write to Flash via TFTP.

3: Boot system code via Flash (default).

4: Entr boot command line interface.

7: Load Boot Loader code then write to Flash via Serial.

9: Load Boot Loader code then write to Flash via TFTP.

-15-

AI7688H User Manual

There is about 1 second for you to choose from the bootloader menu. If there is no user

input, the bootloader continues into Linux kernel bootup:

3: System Boot system code via Flash.

## Booting image at bc050000 ...

Image Name: MIPS OpenWrt Linux-3.18.21

Image Type: MIPS Linux Kernel Image (lzma compressed)

Data Size: 1118412 Bytes = 1.1 MB

Load Address: 80000000

Entry Point: 80000000

Verifying Checksum ... OK

Uncompressing Kernel Image ... OK

No initrd

## Transferring control to Linux (at address 80000000) ...

## Giving linux memsize in MB, 128

Starting kernel ...

[ 0.000000] Linux version 3.18.21 (root@builder1) (gcc version 4.8.3 (OpenWrt/Linaro

GCC 4.8-2014.04 r47269) ) #7 Sat Nov 7 14:50:53 CET 2015

[ 0.000000] Board has DDR2

[ 0.000000] Analog PMU set to hw control

[ 0.000000] Digital PMU set to hw control

[ 0.000000] SoC Type:

[ 0.000000] bootconsole [early0] enabled

[ 0.000000] CPU0 revision is: 00019655 (MIPS 24KEc)

[ 0.000000] MIPS:

[ 0.000000] Determined physical RAM map:

[ 0.000000] memory: 08000000 @ 00000000 (usable)

At this point you can press ENTER to gain access to the Linux kernel console

-16-

AI7688H User Manual

3.7 Change bootloader Console

If you want to use another UART port as the bootloader console, you need to modify the

bootloader.

# Get bootloader source code

# modify the file board/rt2880/serial.h

* UART registers

#if defined (MT7621_FPGA_BOARD) || defined (MT7621_ASIC_BOARD) || defined

(MT7628_FPGA_BOARD) || defined (MT7628_ASIC_BOARD)

#define RT2880_UART1 0x0C00 /* UART Lite */

#define RT2880_UART2 0x0D00 /* UART Lite */

#define RT2880_UART3 0x0E00 /* UART Lite */

//#define CFG_RT2880_CONSOLE RT2880_UART1

#define CFG_RT2880_CONSOLE RT2880_UART3

#else

#define RT2880_UART1 0x0500

#define RT2880_UART2 0x0C00 /* UART Lite */

#define CFG_RT2880_CONSOLE RT2880_UART2

#endif

and modify the CFG_RT2880_CONSOLE configuration.

Note that in bootloader code, RT2880_UART1 refers to UART0(UART_TXD0/UART_TXR0)

and so on. So modify the following modification:

Change this:

//#define CFG_RT2880_CONSOLE RT2880_UART1

#define CFG_RT2880_CONSOLE RT2880_UART3

to this:

#define CFG_RT2880_CONSOLE RT2880_UART1

//#define CFG_RT2880_CONSOLE RT2880_UART3

This changes the bootloader console from UART2 to UART0.

if you also want to change the baudrate, please modify the file include/configs/rt2880.h

-17-

AI7688H User Manual

#define SERIAL_CLOCK_DIVISOR 16

#define CONFIG_BOOTDELAY 1 /* autoboot after 5 seconds */

#define CONFIG_BAUDRATE 57600

#define CONFIG_SERVERIP 10.10.10.3

#define CONFIG_IPADDR 10.10.10.123

Change this:

#define CONFIG_BAUDRATE 57600

to this (change the baudrate from 57600 to 115200 as an example):

#define CONFIG_BAUDRATE 115200

This will then change the bootloader console baudrate from 57600 to 115200

# Now build the bootloader and upload it to the board

3.8 Change Kernel Console

If you want to use another UART port as the kernel console, you can follow the steps below

to adjust the configuration.

# modify the file target/linux/ramips/dts/LINKIT7688.dts and chang

chosen {

bootargs = "console=ttyS2,57600";

};

to this (e.g. change to UART0 and 115200 baudrate):

chosen {

bootargs = "console=ttyS0,115200";

};

This will then change the kernel console from UART2 to UART0 and its baudrate from 57600

to 115200.

Now build the firmware and upload it to the board through the Web UI or the USB drive.

-18-

AI7688H User Manual

4 File Storage

4.1 USB Drive and SD Card

When a USB drive or SD card is inserted into AI7688H, they can be accessed under /Media/SD* or

/Media/USB* (The device name displayed varies depending on the number of drives you use and

the number of partitions available on the USB drive or SD card).

You can use the following commands to check the contents of the USB drive and SD card:

• In this example, a USB drive named USB-A1 is used:

• # ls /Media/USB-A1

• In this example, a SD card named SD-P1 is used:

• # ls /Media/SD-P1

4.2 How to mount the root FS on a SD card

The on-board flash is a raw flash. It is with limited write cycles (about 100,000 times) and without

wear leveling mechanism and atomic write operation. So it is not recommended to write user

data to the on-board flash frequently. Besides, its storage is also limited to 32MB, the spare space

might not be sufficient for storing lots of user data and software packages. As a result, it is

recommended to mount the root FS on a SD card for getting more and reliable storage.

Steps:

Below are the steps for making this work. For details, please refer to the OpenWrt WiKi for

extroot. Note: the procedure below assumes there is only one partition on the SD card. If there

are multiple partitions on the SD card, you can use fdisk command to manage partition settings.

1. Insert a microSD card into the AI7688H device. Warning: all the data on the SD card will be

erased in the following steps.

2. Make sure the device is under Station mode for accessing internet.

3. Open the system console of the AI7688H.

4. Type the following commands for installing related packages:

-19-

+ 42 hidden pages

AcSiP Technology AI7688H User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

# Install Bonjour Print Service (For Windows 7 only)

Steps:
