Acrox MTM0060425 Users Manual
TABLE OF CONTENTS
System requirements...........................................3
Installing the Batteries.........................................3
Using the Enhanced Resolution feature...............5
Bluetooth Software: WIDCOMM...........................5
Bluetooth Software: TOSHIBA............................10
Bluetooth Software: MICROSOFT......................15
Bluetooth Software: Mac OS X...........................19
Technical Support..............................................25
2
TARGUS BLUETOOTH®
LASER
RECHARGEABLE
NOTEBOOK MOUSE
Introduction
Congratulations on your purchase of the Targus Bluetooth®
Laser Rechargeable Notebook Mouse. This mouse has a
special EDR (Enhanced Data Rate) technology that provides
faster data transmission rate and allows multiple Bluetooth
devices running without conflict.
System Requirements
Hardware - Bluetooth-enabled notebook or desktop PC
Operating System - Windows® 98SE / 2000 / ME / XP
Mac OS X (10.x or greater)
Installing the Batteries (Supplied)
Use the two AAA-size rechargeable NIMH batteries
•
(supplied)
Remove the battery cover from the back of the mouse by
•
sliding off the cover while pressing the release button at the
bottom of the mouse.
Insert the batteries, making sure that the positive (+) and
•
negative (-) ends of each battery match the polarity
indicators inside the battery housing
3
TARGUS BLUETOOTH® LASER RECHARGEABLE NOTEBOOK MOUSE
slide the battery
cover in this direction
On/Off switch
on
off
connect
button
ID
Battery cover
OPEN
release button
WARNINGS: WHEN REPLACING THE BATTERIES, ALWAYS REPLACE WITH
NiMH BATTERIES OR OTHER RECHARGEABLE BATTERIES. NEVER USE ALKALINE
BATTERIES IN THIS DEVICE. AVOID MIXING NEW AND USED BATTERIES IN A
DEVICE
•
Snap the battery cover back into position
•
Turn on the mouse by sliding on/off switch on the bottom
to the “on” position.
Charging the Batteries
•
Charge the mouse for 8 hours before using. Plug in the
USB charge cable to the mouse and connect the other
end to the computer.
NOTE: TO CONTINUOUSLY CHARGE THE BATTERIES VIA THE USB
CHARGE CABLE, YOUR COMPUTER MUST BE ON AND AWAKE . FOR
BEST RESULTS , TURN OFF YOUR COMPUTER ’S POWER MANAGEMENT / SLEEP MODE FEATURE WHILE CHARGING THE MOUSE.
4
TARGUS BLUETOOTH® LASER RECHARGEABLE NOTEBOOK MOUSE
Initial Configuration
Before you can begin using Bluetooth connectivity on your
computer and other Bluetooth devices, you must perform
some initial setup tasks.
The Targus Bluetooth Laser Rechargeable notebook mouse is
designed to work with the three major software stack
(protocol) standards: WIDCOMM, Toshiba, Microsoft and Mac
OS X. Please check your computer’s documentation to see
which software stack your computer has. Please contact your
system vendor if your system does not support one of the
following Bluetooth software standards.
Using the enhanced Resolution feature
This bluetooth laser mouse has a special enhanced
resolution feature. By activating this feature, the laser
mouse will increase its tracking sensitivity from 800 CPI to
1600 CPI. This will improve the precision of the mouse
pointer for fine details with increased speed. Press both the
scroll and right key when the mouse is on , the red LED in
the scroll wheel will light up around 3 secs to proceed
resolution switching. When the LED is off, it indicates the
resolution switching is successful.
Bluetooth Software: WIDCOMM
1. Go to the Bluetooth Places icon located on your desktop
or in the system tray and double click, then click Bluetooth
setup wizard.
5
TARGUS BLUETOOTH® LASER RECHARGEABLE NOTEBOOK MOUSE
2. The Bluetooth configuration screen will prompt. Please
follow the onscreen instructions. Click Next to continue.
3. Continue to setup your bluetooth device profile.
6
TARGUS BLUETOOTH® LASER RECHARGEABLE NOTEBOOK MOUSE
4. Click Next to continue setup.
5. Please select the service which the bluetooth device
offers. (Default setting allows the most coverage. It is
recommend to keep as default). Click Next.
6. Installation will perform setup and click Next when setup is
completed.
7
TARGUS BLUETOOTH® LASER RECHARGEABLE NOTEBOOK MOUSE
7. Please turn on the mouse and press the connection ID
button located at the bottom of the mouse until the light in
the middle scrollwheel blinks red light (discoverable mode).
Click Next to continue pairing.
Targus BT
Laser
Notebook
Mouse
8. The confirmation window will appear as the system installs
the drivers. Click OK. When this is done, the mouse should
be functioning. The bluetooth mouse has been successfully
installed.
8
