AR-B9629 User’s Guide
AR-B9629
Half Size All-In-One
386SX CPU BOARD
User’s Guide
Edition: 1.11
Book Number: AR-B9629-05.0613
0-1
Page 2
AR-B9629 User’s Guide
Table of Contents
0.
PREFACE...........................................................................................................................................................0-3
0.1 COPYRIGHT NOTICE AND DISCLAIMER............................................................................................................................0-3
0.2 WELCOME TO THE AR-B9629 CPU BOARD....................................................................................................................... 0-3
0.3 BEFORE YOU USE THIS GUIDE.......................................................................................................................................... 0-3
0.4 RETURNING YOUR BOARD FOR SERVICE ....................................................................................................................... 0-3
0.5 TECHNICAL SUPPORT AND USER COMMENTS............................................................................................................... 0-3
0.6 ORGANIZATION.................................................................................................................................................................... 0-4
0.7 STATIC ELECTRICITY PRECAUTIONS ............................................................................................................................... 0-4
1. OVERVIEW.........................................................................................................................................................1-1
1.1 INTRODUCTION....................................................................................................................................................................1-1
1.2 PACKING LIST....................................................................................................................................................................... 1-1
1.3 FEATURES ............................................................................................................................................................................ 1-1
2. SYSTEM CONTROLLER....................................................................................................................................2-1
2.1 MICROPROCESSOR ............................................................................................................................................................ 2-1
2.2 DMA CONTROLLER.............................................................................................................................................................. 2-1
2.3 KEYBOARD CONTROLLER..................................................................................................................................................2-2
2.4 TERRUPT CONTROLLER ................................................................................................................................................. 2-2 IN
2.4.1
I/O Port Address Map..................................................................................................................................................... 2-3
2.4.2 Real-Time Clock and Non-Volatile RAM........................................................................................................................ 2-4
2 4.3 Timer.............................................................................................................................................................................. 2-4 .
2.5
SERIAL PORT........................................................................................................................................................................ 2-5
2.6 PARALLEL PORT.................................................................................................................................................................. 2-7
3. SETTING UP THE SYSTEM...............................................................................................................................3-1
3.1 OVERVIEW............................................................................................................................................................................ 3-1
3.2 SYSTEM SETTINGS.............................................................................................................................................................. 3-2
3.2.1 Clock Jumper (JP1)........................................................................................................................................................ 3-2
3.2.2 Reset (JI)........................................................................................................................................................................ 3-2
3.2.3 PS2 KB4 Mouse (J4)...................................................................................................................................................... 3-2
3.2.4 ISA Bus Connector (CN1).............................................................................................................................................. 3-3
3.2.5 External Buzzer (J2)....................................................................................................................................................... 3-4
3.2.6 Power Connector (J3) .................................................................................................................................................... 3-5
3.2.7 I/O Connector for KB/MS, serial port, parallel port (CN3) .............................................................................................. 3-5
4. BIOS CONSOLE.................................................................................................................................................4-6
4.1 BIOS SETUP OVERVIEW ..................................................................................................................................................... 4-6
4.2 STANDARD CMOS SETUP................................................................................................................................................... 4-7
4.3 ADVANCED CMOS SETUP................................................................................................................................................... 4-8
4.4 ADVANCED CHIPSET SETUP............................................................................................................................................ 4-10
4.5 PERIPHERAL SETUP.......................................................................................................................................................... 4-11
4.6 AUTO-DETECT HARD DISKS............................................................................................................................................. 4-12
4.7 PASSWORD SETTING........................................................................................................................................................ 4-12
4.7.1 Setting Password ......................................................................................................................................................... 4-12
4 7.2 Password Checking...................................................................................................................................................... 4-12 .
LOAD DEFAULT SETTING.................................................................................................................................................. 4-12
4.8
4.8.1 Auto Configuration with Optimal Setting ...................................................................................................................... 4-12
4 8.2 Auto Configuration with Fail Safe Setting..................................................................................................................... 4-12 .
BIOS EXIT............................................................................................................................................................................ 4-13
4.9
4.9.1 Save Settings and Exit................................................................................................................................................. 4-13
4.9.2 Exit Without Saving...................................................................................................................................................... 4-13
4.10 BIOS UPDATE................................................................................................................................................................. 4-14
5. SPECIFICATIONS..............................................................................................................................................5-1
6. PLACEMENT & DIMENSIONS...........................................................................................................................6-1
6.1 PLACEMENT .........................................................................................................................................................................6-1
6.2 DIMENSIONS......................................................................................................................................................................... 6-2
0-2
Page 3
AR-B9629 User’s Guide
0.PREFACE
0.1 COPYRIGHT NOTICE AND DISCLAIMER
This document is copyrighted, 2002, by Acrosser Technology Co., Ltd. All rights are reserved. No part of this
manual may be reproduced, copied, transcribed, stored in a retrieval system, or translated into any language or
computer language in any form or by any means, such as electronic, mechanical, magnetic, optical, chemical,
manual or other means without the prior written permission or original manufacturer.
Acrosser Technology assumes no responsibility or warranty with respect to the content in this manual and
specifically disclaims any implied warranty of mercha ntability or fitness for any particular purpose. Furthermore,
Acrosser Technology reserves the right to make improvements to the products descri bed in this manual at any
times without notice. Such revisions will be posted on the Internet
Possession, use, or copy of the software described in this publication is authorized only pursu ant to valid written
license from Acrosser or an authorized sub licensor.
ACKNOWLEDGEMENTS
Acrosser, AMI, IBM PC/AT, ALI, Windows 3.1, MS-DOS…are registered trademarks.
All other trademarks and registered trademarks are the property of their respective owners.
0.2 WELCOME TO THE AR-B9629 CPU BOARD
This guide introduces the Acrosser AR-B9629 CPU Board.
Use information provided in this manual describes this card’s functions and features. It also helps you st art, set up
and operate your AR-B9629. General system information can also be found in this publication.
(WWW.ACROSSER.COM) as soon as possible.
0.3 BEFORE YOU USE THIS GUIDE
Please refer to the Chapter 3, “Setting System,” in this guide, if you have not alrea dy installed this AR-B9629.
Check the packing list before you install and make sure the accessories are completely included.
AR-B9629 CD provides the newest information regarding the CPU card. Please refer to the README.DOC file
of the enclosed utility CD. It contains the modification and hardware & software information, and adding the
description or modification of product function after manual printed.
0.4 RETURNING YOUR BOARD FOR SERVICE
If your board requires any services, contact the distributor or sales repr esentative from whom you purc hased the
product for service information. If you need to ship your board to us for service, be sure it is packed in a protective
carton. We recommend that you keep the original shipping container for this purpose.
You can help assure efficient servicing for your product by following these guidelines:
1. Include your name, address, daytime telephone, facsimile number and E-mail.
2. A description of the system configuration and/or software at the time of malfunction.
3. A brief description of the problem occurred.
0.5 TECHNICAL SUPPORT AND USER COMMENTS
User’s comments are always welcome as they assist us in improving the quality of our products and the
understanding of our publications. They create a very important part of the input used for product enhancement
and revision.
We may use and distribute any of the information you provide in any way we appropriate without incurring an y
obligation. You may, of course, continue to use the information you provide.
If you have any suggestions for improving particular sections or if you find any errors, please send your
comments to Acrosser Technology Co., Ltd. or your local sales representative and indicate the manual title and
book number.
Internet electronic mail to: webmaster@acrosser.com
0-3
Page 4
AR-B9629 User’s Guide
0.6 ORGANIZATION
This information for users covers the following topics (see the Table of Contents for a detailed listing):
Chapter 1, “Overview”, provides an overview of the system features and packing list.
Chapter 2, “System Controller” describes the major structure.
Chapter 3, “Setting Up the System”, describes how to adjust the jumper, and the connectors setting.
Chapter 4, “BIOS Console”, providing the BIOS options setting.
Chapter 5, Specifications
Chapter 6, Placement & Dimensions
0.7 STATIC ELECTRICITY PRECAUTIONS
Before removing the board from its anti-static bag, read this section about static electricity precautions.
Static electricity is a constant danger to the computer systems. The charge that can build up in your body may be
more than sufficient to damage integrated circuits on any PC board. T herefore, It is an important to obse rve basic
precautions whenever you use or handle computer components. Although areas with humid clim ates are much
less prone to static build-up, it is always the best to safeguard against ac cidents, which may result in expensive
repairs. The following measures should generally be sufficient to protect your equipment from static discharge:
• Touch a grounded metal object to dischar ge the static electricity in your body (or ideally, wear a groun ded
wrist strap).
• When unpacking and handling the board or other s ystem components, place all materials on an antic static
surface.
• Be careful not to touch the components on the board, especially the “golden finger” connectors on the bottom
of every board.
0-4
Page 5
AR-B9629 User’s Guide
1. OVERVIEW
This chapter provides an overview of your system features and capabilities. The following topics are covered:
Introduction
Packing List
Features
1.1 INTRODUCTION
The AR-B9629 is a new generation half-size, 386SX board. This card offers much greater performance than the
older cards such as support for onboard 2MB DRAM.
The unit also comes with a programmable watchdog timer an d other typical interfaces. The 386 CPU board is
excellent for embedded systems, MMI’s, workstations, medical applications or POS/POI systems.
1.2 PACKING LIST
The accessories are included with the system. Before you begin installi ng your AR-B9629 board, take a moment
to make sure that the following items have been included inside the AR-B9629 package.
The quick setup manual
1 AR-B9629 all-in-one single CPU board
1 AR-B9449 ISA card (Reserved)
1 Parallel port interface cable (Reserved)
1 PS/2 mouse & keyboard cables (Reserved)
1.3 FEATURES
The system provides a number of special features that enhance its reliabi lit y, ensure its availabil ity, and improve its
expansion capabilities, as well as its hardware structure.
ALI 80386SX-33/40 MHz CPU
PC/AT compatible keyboard & Mouse
Programmable watchdog timer
Flash BIOS
Signal 5V power requirement
Multi-layer PCB for noise reduction
Dimensions: 82.6mmX57.2mm
1-1
Page 6
Page 7
AR-B9629 User’s Guide
2. SYSTEM CONTROLLER
This chapter describes the major structure of the AR-B9629 CPU board. The following topics are covered:
Microprocessor
DMA Controller
Keyboard Controller
Interrupt Controller
Serial Port (AR-B9449)
Parallel Port (AR-B9449)
2.1 MICROPROCESSOR
The AR-B9629 uses the ALI M6117 CPU; it is designed to perform systems like Intel’s 386SX system with deep
green features.
The 386SX core is the same as M1386SX of Acer Labs. Inc. and 1 0 0 % o b j e ct c o d e c o m pa t i b le w i t h t h e I n t el
38 6S X microprocessor. System manufactur ers can provide 386 CPU based systems optimized for both cost and
size. Instruction pipelining and high bus bandwidth ensure short average instruction execution time and high
system production. Furthermore, it can keep the state internally from charge leakage while external clock to the
core is stopped without storing the data in registers. The power consumption here is almost zero until the clock
stops. The internal structure of this core is 32-bit data and address bus with very lo w supply current. Real mode
as well as Protected mode are available and can run MS-DOS /MS-Windows.
2.2 DMA CONTROLLER
The equivalent of two 8237A DMA controllers are implemented in th e AR-B9629 board. Each controller is a fourchannel DMA device that will generate the memory addresses and will control signals necessary to transfer
info rmat ion d irec tly b etween a peripheral device and memory. This allows high speeding information trans ference w ith
less CPU intervention. The two DMA controllers are internally cascaded to provide four DMA channels for
transferring to 8-bit peripherals (DMA1) and three channels for transferrin g to 16-bit peripherals (DMA2). DMA2
channel 0 provides the cascade interconnection between the t wo DMA devices, thereby maintaining IBM PC/AT
compatibility.
The following is the system information of DMA channels:
DMA Controller 1 DMA Controller 2
Channel 0: Spare Channel 4: Cascade for controller 1
Channel 1: IBM SDLC Channel 5: Spare
Channel 2: Diskette adapter Channel 6: Spare
Channel 3: Spare Channel 7: Spare
Table 2-1 DMA Channel Controller
2-1
Page 8
AR-B9629 User’s Guide
2.3 KEYBOARD CONTROLLER
The 8042 processor is programmed to support the keyboard serial interface. The keyboard controller receives
serial data from the keyboard, checks its parity, translates scan codes, and presents it to the system as a byte data
in its output buffer. The controller can interrupt the system when data is place d in its output buffer, or wait for the
system to poll its status register to determine when data is available.
Data can be written to the keyboard by writing data to the output buffer of the keyboard controller.
Each byte of data is sent to the keyboard controller in seri es with an odd parity bit automatically inserted. The
keyboard controller is required to acknowledge all data transmissions. Therefore, another byte of data will not be
sent to keyboard controller until acknowledgment is received for the previous byte sent. The “output buffer full”
interruption may be used for both send-and-receive routines.
2.4 INTERRUPT CONTROLLER
The equivalent of two 8259 Programmable Interrupt Controllers (PIC) are included on the AR-B9629 board. They
accept requests from peripherals, resolve priorities on pending interrupts in service, issue interrupt req uests to the
CPU, and provide vectors which are used as acceptance indices by the CP U to determine which interrupt service
routine to execute.
The following is the system information of interrupts levels:
Interrupt Level Description
NMI Parity check
CTRL1 CTRL2
IRQ 0 System timer interrupt from timer 8254
IRQ 1 Keyboard output buffer full
IRQ 2 Rerouting to IRQ 8 & IRQ 14
IRQ 8: Real time clock
IRQ 12: PS/2 mouse
IRQ 13: Math. coprocessor
IRQ 14: Hard disk adapter (AR-B9449)
IRQ 4 Serial port 1 (AR-B9449)
IRQ 6 Floppy disk adapter (AR-B9449)
IRQ 7 Parallel port 1 (AR-B9449)
Figure 2-1 Interrupt Controller
2-2
Page 9
2.4.1 I/O Port Address Map
Hex Range Device
000-01F DMA controller 1
020-021 Interrupt controller 1
022-023 ALI M6117 chipset address
040-04F Timer 1
050-05F Timer 2
060-06F 8042 keyboard/controller
070-071 Real-time clock (RTC), non-maskable interrupt (NMI)
080-09F DMA page registers
0A0-0A1 Interrupt controller 2
0C0-0DF DMA controller 2
0F0 Clear Math Co-processor
0F1 Reset Math Co-processor
0F8-0FF Math Co-processor
170-178 Fixed disk 1
1F0-1F8 Fixed disk 0
208-20A EMS register 0
218-21A EMS register 1
300-31F Prototype card/streaming type adapter
378-37F Parallel printer port 1 (LPT 1)
380-38F SDLC, bisynchronous
3A0-3AF Bisynchronous
3B0-3BF Monochrome display and printer port 3 (LPT 3)
3D0-3DF Color/graphics monitor adapter
3F0-3F7 Diskette controller
3F8-3FF Serial port 1 (COM 1)
Table 2-2 I/O Port Address Map
AR-B9629 User’s Guide
2-3
Page 10
AR-B9629 User’s Guide
2.4.2 Real-Time Clock and Non-Volatile RAM
The AR-B9629 contains a real-time clock compartment that maintains the date and time in addition to storing
configuration information about the computer system. It contains 14 bytes of clock and control registers and 114
bytes of general purpose RAM. Because of the use of CMOS technology, it consumes v er y little power and ca n be
maintained for long periods of time using an internal Lithium battery. The contents of each b yte in the CMOS RAM
are listed below:
Address Description
00 Seconds
01 Second alarm
02 Minutes
03 Minute alarm
04 Hours
05 Hour alarm
06 Day of week
07 Date of month
08 Month
09 Year
0A Status register A
0B Status register B
0C Status register C
0D Status register D
0E Diagnostic status byte
0F Shutdown status byte
10 Diskette drive type byte, drive A and B
11 Fixed disk type byte, drive C
12 Fixed disk type byte, drive D
13 Reserved
14 Equipment byte
15 Low base memory byte
16 High base memory byte
17 Low expansion memory byte
18 High expansion memory byte
19-2D Reserved
2E-2F 2-byte CMOS checksum
30 Low actual expansion memory byte
31 High actual expansion memory byte
32 Date century byte
33 Information flags (set during power on)
34-7F Reserved for system BIOS
Table 2-3 Real-Time Clock & Non-Volatile RAM
2.4.3 Timer
The AR-B9629 provides three programmable timers, each with a timing frequency of 1.19 MHz.
Timer 0 The output of this timer is tied to interrupt request 0. (IRQ 0)
Timer 1 This timer is used to trigger memory refresh cycles.
Timer 2 This timer provides the sp eaker tone.
Application programs can load different counts into this timer to generate various sound frequencies.
2-4
Page 11
AR-B9629 User’s Guide
2.5 SERIAL PORT
The ACEs (Asynchronous Communication Elements ACE1 to ACE4) are not only used to convert parallel data to a
serial format on the transmit side but also used to convert serial data to parallel on the receiver side. In order of
transmission and reception, the serial format is a start bit, followed by five to eight data bits, a parity bit (if
programmed) and one, one and half (five-bit format only) or two stop bits. The ACEs are capable of handling
divisors of 1 to 65535, and produce a 16x clock for driving the internal transmitter logic.
Provisions are not only included to use this 16x clock to dr ive the receiver logic b ut also included in the ACE as a
completed MODEM control capability, and a processor interrupt system that may be software tailored to the
computing time required to handle the communications link.
The following table is a summary of each ACE accessible register
DLAB Port Address Register
Receiver buffer (read) 0 base + 0
Transmitter holding register (write)
0 base + 1 Interrupt enable
X base + 2 Interrupt identification (read only)
X base + 3 Line c ontrol
X base + 4 MODEM control
X base + 5 Line status
X base + 6 MODEM status
X base + 7 Scratched register
1 base + 0 Divisor latch (least significant byte)
1 base + 1 Divisor latch (most significant byte)
Table 2-4 ACE Accessible Registers
(1) Receiver Buffer Register (RBR)
Bit 0-7: Received data byte (Read Only)
(2) Transmitter Holding Register (THR)
Bit 0-7: Transmitter holding data byte (Write Only)
(3) Interrupt Enable Register (IER)
Bit 0: Enable Received Data Available Interrupt (ERBFI)
Bit 1: Enable Transmitter Holding Empty Interrupt (ETBEI)
Bit 2: Enable Receiver Line Status Interrupt (ELSI)
Bit 3: Enable MODEM Status Interrupt (EDSSI)
Bit 4: Must be 0
Bit 5: Must be 0
Bit 6: Must be 0
Bit 7: Must be 0
(4) Interrupt Identification Register (IIR)
Bit 0: “0” if Interrupt Pending
Bit 1: Interrupt ID Bit 0
Bit 2: Interrupt ID Bit 1
Bit 3: Must be 0
Bit 4: Must be 0
Bit 5: Must be 0
Bit 6: Must be 0
Bit 7: Must be 0
2-5
Page 12
AR-B9629 User’s Guide
(5) Line Control Register (LCR)
Bit 0: Word Length Select Bit 0 (WLS0)
Bit 1: Word Length Select Bit 1 (WLS1)
WLS1 WLS0 Word Length
0 0 5 Bits
0 1 6 Bits
1 0 7 Bits
1 1 8 Bits
Bit 2: Number of Stop Bit (STB)
Bit 3: Parity Enable (PEN)
Bit 4: Even Parity Select (EPS)
Bit 5: Stick Parity
Bit 6: Set Break
Bit 7: Divisor Latch Access Bit (DLAB)
(6) MODEM Control Register (MCR)
Bit 0: Data Terminal Ready (DTR)
Bit 1: Request to Send (RTS)
Bit 2: Out 1 (OUT 1)
Bit 3: Out 2 (OUT 2)
Bit 4: Loop
Bit 5: Must be 0
Bit 6: Must be 0
Bit 7: Must be 0
(7) Line Status Register (LSR)
Bit 0: Data Ready (DR)
Bit 1: Overrun Error (OR)
Bit 2: Parity Error (PE)
Bit 3: Framing Error (FE)
Bit 4: Break Interrupt (BI)
Bit 5: Transmitter Holding Register Empty (THRE)
Bit 6: Transmitter Shift Register Empty (TSRE)
Bit 7: Must be 0
(8) MODEM Status Register (MSR)
Bit 0: Delta Clear to Send (DCTS)
Bit 1: Delta Data Set Ready (DDSR)
Bit 2: Training Edge Ring Indicator (TERI)
Bit 3: Delta Receive Line Signal Detect (DSLSD)
Bit 4: Clear to Send (CTS)
Bit 5: Data Set Ready (DSR)
Bit 6: Ring Indicator (RI)
Bit 7: Received Line Signal Detect (RSLD)
2-6
Page 13
(9) Divisor Latch (LS, MS)
LS MS
Bit 0: Bit 0 Bit 8
Bit 1: Bit 1 Bit 9
Bit 2: Bit 2 Bit 10
Bit 3: Bit 3 Bit 11
Bit 4: Bit 4 Bit 12
Bit 5: Bit 5 Bit 13
Bit 6: Bit 6 Bit 14
Bit 7: Bit 7 Bit 15
Table 2-5 Serial Port Divisor Latch
AR-B9629 User’s Guide
Desired Baud Rate Divisor Used to Generate 16x Clock
300 384
600 192
1200 96
1800 64
2400 48
3600 32
4800 24
9600 12
14400 8
19200 6
28800 4
38400 3
57600 2
115200 1
2.6 PARALLEL PORT
(1) Register Address
Port Address Read/Write Register
base + 0 Write Output data
base + 0 Read Input data
base + 1 Read Printer status buffer
base + 2 Write Printer control latch
Table 2-6 Registers’ Address
(2) Printer Interface Logic
The parallel portion of the SMC37C669 makes the attachment of various devices that accept eight bits of parallel
data at standard TTL level.
(3) Data Swapper
The system microprocessor can read the contents of the printer’s Data Latch through the Data Swapper by reading
the Data Swapper address.
2-7
Page 14
AR-B9629 User’s Guide
(4) Printer Status Buffer
The system microprocessor can read the printer status by reading the address of the Printer Status Buffer. The bit
definitions are described below:
12345670
XXX
-ERROR
SLCT
PE
-ACK
-BUSY
Figure 2-2 Printer Status Buffer
NOTE: X represents not used.
Bit 7: This signal may become active during data entr y, when the printer is off-line during printing, or when the
print head is changing position or in an error state. When Bit 7 is activ e, the printer is busy and cannot
accept data.
Bit 6: This bit represents the current state of the printer’s ACK signal. A 0 means the printer has received the
character and is ready to accept another. Normally, this signal will be active for approximately 5
microseconds before receiving a BUS Y message stops.
Bit 5: A 1 means the printer has detected the end of the paper.
Bit 4: A 1 means the printer is selected.
Bit 3: A 0 means the printer has encountered an error condition.
2-8
Page 15
AR-B9629 User’s Guide
(5) Printer Control Latch & Printer Control Swapper
The system microprocessor can read the contents of the printer control latch by reading the address of printer
control swapper. Bit definitions are as follows:
XX
Figure 2-3 Bit’s Definition
NOTE: X represents not used.
Bit 5: Direction control bit. When logic 1, the output buffers in the parallel port are disabled allowing data driven
from external sources to be read; when logic 0, they work as a printer port. This bit is writing only.
Bit 4: A 1 in this position allows an interrupt to occur when ACK changes from low state to high state.
Bit 3: A 1 in this bit position selects the printer.
Bit 2: A 0 starts the printer (50 microseconds pulse, minimum).
Bit 1: A 1 causes the printer to line-feed after a line is printed.
Bit 0: A 0.5 microsecond minimum highly active pulse clocks data into the printer. Valid data must be present
for a minimum of 0.5 microseconds before and after the strobe pulse.
12345670
STROBE
AUTO FD XT
INIT
SLDC IN
IRQ ENABLE
DIR(write only)
2-9
Page 16
Page 17
AR-B9629 User’s Guide
3. SETTING UP THE SYSTEM
This section describes the pin assignments for system’s external connectors and the jumper settings.
Overview
System Setting
3.1 OVERVIEW
The AR-B9629 is an all-in-one, half-size, 386SX CPU board. This section provi des hardware jumper settings, the
connectors’ locations, and the pin assignment.
CAUTION: The CPU board doesn’t support the SIMM-type DRAM.
Figure 3-1 External System Location
3-1
Page 18
AR-B9629 User’s Guide
3.2 SYSTEM SETTINGS
Jumper pins allow you to set specific system parameters. Set them by changing the pin location of jumper blocks.
(A jumper block is a small plastic-encased conductor [shorting plug] that slips over the pins.) To change a jumper
setting, remove the jumper from its current location with your fingers or small needle-nosed pliers. Place the
jumper over the two pins designated for the desired setting. Press the jumper evenly onto the pins. Be careful not
to bend the pins.
We will show the locations of the AR-B9629 jumper pins, and the factory-default settings.
CAUTION: Do not touch any electronic component unless you are safely grounde d. Wear a grounded wrist strap
or touch an exposed metal part of the system unit chassis. The static discharg es from your fin gers c an
permanently damage the electronic components.
3.2.1 Clock Jumper (JP1)
Factory Preset
JP1: Clock Jumper
JUMPER FUNCTION
1-2 ON 80MHz
2-3 ON 66MHz
3.2.2 Reset (JI)
Reserved
J1
J1*2
1
2
(2.54mm)
1-2
System ResetShort
JI: Reset
3.2.3 PS2 KB4 Mouse (J4)
165432
J4
JST6S
(2.0mm)
J4: PS2 KB4 Mouse
1 :
2 :
3 :
MSD
KBD
VDD
4 :
5 :
6 :
VMK1
MSC
KBC
3-2
Page 19
3.2.4 ISA Bus Connector (CN1)
AR-B9629 User’s Guide
CN1
DIP50
/ZWS
SD7
SD6
SD5
SD4
SD3
SD2
SD1
SD0
/IORDY
AEN
SA13
SA12
SA11
SA10
SA9
SA8
SA7
SA6
SA5
SA4
SA3
SA2
SA1
SA0
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
GND
RSTDRV
VCC
IRQ9
BUSCLK
OSC
(+12)
GND
/MEMW
/MEMR
/IOW
/IOR
SA19
SA18
SA17
SA16
SA15
SA14
IRQ7
IRQ6
IRQ5
IRQ4
IRQ3
VCC
GND
CN1: ISA Bus Connector
3-3
Page 20
AR-B9629 User’s Guide
CN2
DIP50
/DACK1
/DACK2
/DACK3
/REFSH
TC
/IOCHK
/SBHE
LA23
LA22
LA21
LA20
LA19
LA18
LA17
/MRD16
/MWR16
SD8
SD9
SD10
SD11
SD12
SD13
SD14
SD15
GND
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
CN2: ISA Bus Connector
DRQ1
DRQ2
DRQ3
(-5)
BALE
(-12)
/MEM16
/IO16
IRQ10
IRQ11
IRQ12
IRQ15
IRQ14
/DACK0
DRQ0
/DACK5
DRQ5
/DACK6
DRQ6
/DACK7
DRQ7
VCC
MASTER
GND
GND
3.2.5 External Buzzer (J2)
Reserved
J2
J2P
1
2
J2: External Buzzer
3-4
1:VCC
2:EXTSPK
Page 21
3.2.6 Power Connector (J3)
Reserved
1432
J3
JST4S
1 :
VDD
2 :
GND
3 :
GND
VDD
4 :
J3: Power Connector
3.2.7 I/O Connector for KB/MS, serial port, parallel port (CN3)
CN3
40PIN
AR-B9629 User’s Guide
/IDERST
/IDECS1
DSR2V
DTR2V
RI1D
RXD1D
DSR1D RTS1D
CTS1D
SDCT1
BUSY1
PP17A
PP13A
GND
PP7A PP5A
PP3A /SLIN1
/INIT1 /ERR1
/AFD1 PPIA
KBC
KBD
40
38
36 35
34
32
30
28
26
24
22
20
18
16 15
14
12 11
10
8
6
43
2
39
/IDEEN
37
/IDECS0
TXD2D
RXD2D
33
31
DCD1D
29
TXD1D
27
25
DTR1D
23
PE1
21
/ACK1
19
PP15A
17
PP11A
PP9A
13
9
7
5
MSC
VDDVMK1
1
MSD
CN3: I/O Connector
3-5
Page 22
AR-B9629 User’s Guide
4. BIOS CONSOLE
This chapter describes the AR-B9629 BIOS menu displays and explains how to perform common tasks needed t o
get up and running, and presents detailed explanations of the elements found in eac h of the BIOS menus. The
following topics are covered:
BIOS Setup Overview
Standard CMOS Setup
Advanced CMOS Setup
Advanced Chipset Setup
Peripheral Setup
Auto-Detect Hard Disks
Password Setting
Load Default Setting
BIOS Exit
4.1 BIOS SETUP OVERVIEW
BIOS is a program used to initialize and set up the I/O system of the computer, which includes the ISA bus and
connected devices such as the video display, diskette drive, and the keyboard.
The BIOS provides a menu-based interface to the console subsystem. The co nsole subsystem contains special
software, called firmware that interacts directly with the hardware components and facilitates interaction between
the system hardware and the operating system.
The BIOS Default Values ensure that the system will function at its normal capability. In the worst situation the
user may have corrupted the original settings set by the manufacturer.
After the computer turned on, the BIOS will perform a diagnostics of the system and will display the size of the
memory that is being tested. Press the [Del] key to enter the BIOS Setup program, and then the mai n menu will
show on the screen.
The BIOS Setup main menu includes some options. Use the [Up/Down] arrow key to highlight the option that yo u
wish to modify, and then press the [Enter] key to assure the option and configure the functions.
AMIBIOS HIFLEX SETUP UTILITY - VERSION 1.16
(C) 1996 American Megatrends, Inc. All Rights Reserved
Standard CMOS Setup
Advanced CMOS Setup
Advanced Chipset Setup
Peripheral Setup
Auto-Detect Hard Disks
Change User Password
Change Supervisor Password
Auto Configuration with Optimal Settings
Auto Configuration with Fail Safe Settings
Save Settings and Exit
Exit Without Saving
Standard CMOS setup for changing time, date, hard disk type, etc.
ESC:Exit ↑↓:Sel F2/F3:Color F10:Save & Exit
Figure 4-1 BIOS: Setup Main Menu
CAUTION: 1. AR-B9629 BIOS the factory-default setting is used to the <Auto Configuration with Optimal Settings>
Acrosser recommends using the BIOS default setting, unless you are very familiar with the setting
function, or you can contact the technical support engineer.
2. If the BIOS loss setting, the CMOS will detect the <Auto Configuration with Fail Safe Settings> to
boot the operation system, this option will reduce the performance of the system. Acrosser
recommends choosing the <Auto Configuration with Optimal Setting> in the main menu. The option
is best-case values that should optimize system performance.
3. The BIOS settings are described in detail in this section.
4-6
Page 23
AR-B9629 User’s Guide
4.2 STANDARD CMOS SETUP
The <Standard CMOS Setup> option allows you to record some basic s ystem hardware configuration and set the
system clock and error handling. If the CPU board is already installed in a working system, you will not need t o
select this option anymore.
AMIBIOS SETUP - STANDARD CMOS SETUP
(C) 1996 American Megatrends, Inc. All Rights Reserved
Date (mm/dd/yyyy): Sun Dec 06,1998 640KB
Time (hh/mm/ss): 13:39:30 1MB
Floppy Drive A: 1.44 MB 3.5
Floppy Drive B: Not Installed
LBA Blk 32Bit PIO
Type Size Cyln Head Wpcom Sec Mode Mode Mode Mode
Pri Master : Auto Auto
Pri Slave : Auto Auto
Boot Sector Virus Protection Disabled
Month: Jan - Dec ESC:Exit ↑↓:Sel
Day: 01 - 31 PgUp/PgDn:Modify
Year: 1901 - 2099 F2/F3:Color
Figure 4-2 BIOS: Standard CMOS Setup
Date & Time Setup
Highlight the <Date> field and then press the [Page Up] /[Page Down] or [+]/[-] keys to set the current date. Follow
the month, day and year format.
Highlight the <Time> field and then press the [Page Up] /[Page Down] or [+]/[-] keys to set the current date. Follow
the hour, minute and second format.
The user can bypass the date and time prompts by creating an AUT OEXEC.BAT file. For information on how to
create this file, please refer to the MS-DOS manual.
Floppy Setup
The <Standard CMOS Setup> option records the types of floppy disk drives installed in the system.
To enter the configuration value for a particular drive, highlight its corresponding field and then select the drive t ype
using the left-or right-arrow key.
Hard Disk Setup
The BIOS supports various types for user settings, The BIOS supports <Pri Master>, <Pri Slave>, <Sec Master>
and <Sec Slave> so the user can install up to two hard disks. F or the master and slave jumpers, please refer to
the hard disk’s installation descriptions and the hard disk jumper settings.
You can select <AUTO> under the <TYPE> and <MODE> fields. This will enable auto detection of your IDE drives
during bootup. This will allow you to change your hard drives (with the power off) and then power on without
having to reconfigure your hard drive type. If you use older hard disk drives, which do not support this feature,
then you must configure the hard disk drive in the standard method as described abov e by the <USER> option.
Boot Sector Virus Protection
This option protects the boot sector and partition table of your hard dis k against accidental modifications. Any
attempt to write to them will cause the system to halt and display a warning message. If this occurs, you can either
allow the operation to continue or use a bootable virus-free floppy disk to reboot and inv estigate your system. The
default setting is <Disabled>. This setting is recommended because it conflicts with new operating systems.
Installation of new operating system requires that you disable this to prevent write errors.
4-7
Page 24
AR-B9629 User’s Guide
4.3 ADVANCED CMOS SETUP
The <Advanced CMOS SETUP> option consists of configuration entries that allo w you to improve your system
performance, or let you set up some system features according to your preference. Some entries here are
required by the CPU board’s design to remain in their default settings.
AMIBIOS SETUP – ADVANCED CMOS SETUP
(C) 1998 American Megatrends, Inc. All Rights Reserved
1st Boot Device IDE-0
2nd Boot Device Floppy
3rd Boot Device IDE-1
4th Boot Device Disabled
Try Other Boot Devices Yes
Quick Boot Disabled
BootUp Num-Lock On
Floppy Drive Swap Disabled
Floppy Drive Seek Disabled
Floppy Access Control Normal
HDD Access Control Normal
PS/2 Mouse Support Disabled
Typematic Rate Slow
System Keyboard Absent
Primary Display Absent
Password Check Setup
Wait For
Hit
C000, 32k Shadow Disabled
C800, 32k Shadow Disabled
D000, 32k Shadow Disabled
D800, 32k Shadow Disabled
E000, 32k Shadow Disabled
E800, 32k Shadow Disabled
INTERNAL-FLASH-DISK E8000H
｀F1＇ If Error Enabled
｀DEL＇ Message Display Enabled
Available Options :
Disabled
IDE-0
IDE-1
IDE-2
IDE-3
Floppy
ARMD-FDD
ARMD-HDD
CDROM
SCSI
NETWORK
ESC:Exit ↑↓:Sel
PgUp/PgDn:Modify
F2/F3:Color
Figure 4-3 BIOS: Advanced CMOS Setup
1st Boot Device 2nd Boot Device 3rd Boot Device 4th Boot Device
These options determine where the system looks first for an operating system. The default setting is to check first
the hard disk and then the floppy drive, and last the CDROM.
BootUp Num-Lock
This item is used to activate the Num Lock function upon system boot. If the setting is on, after a boot, the Num
Lock light is lit, and user can use the number key.
Floppy Drive Swap
The option reverses the drive letter assignments of your floppy d isk drives in the Swap A, B setting, otherwise
leave on the default setting of Disabled (No Swap). This works separately from the BIOS Features floppy disk
swap feature. It is functionally the same as physically interchanging the conn ectors of the flop p y disk drives. Whe n
the function’s setting is <Enabled>, the BIOS swapped floppy drive assign ments so that Drive A becomes Drive B,
and Drive B becomes Drive A under DOS.
Floppy Drive Seek
If the <Floppy Drive Seek> item is setting Enabled, the BIOS will seek the floppy <A> drive one time upon bootup.
PS/2 Mouse Support
The setting of Enabled allows the system to detect a PS/2 mouse on bootup. If detected, IRQ12 will be used for
the PS/2 mouse. IRQ 12 will be reserved for expansion cards if a PS/2 mouse is not detected. Disabled will
reserve IRQ12 for expansion cards and therefore the PS/2 mouse will not function.
4-8
Page 25
AR-B9629 User’s Guide
System Keyboard
This function specifies that a keyboard will be attached to the computer.
Primary Display
The option is used to set the type of video display card installed in the system.
Password Check
This option enables password checking every time the computer is powered on or every time the BIOS Setup is
executed. If Always is chosen, a user password prompt appears every time the computer is turned on. If Setup is
chosen, the password prompt appears if the BIOS executed.
Wait for ‘F1’ If Error
AMIBIOS POST error messages are followed by:
Press <F1> to continue
If this option is set to Disabled, the AMIBIOS does not wait for you to press the <F1> key after an error message.
Hit ‘DEL’ Message Display
Set this option to Disabled to prevent the message as follows:
Hit ‘DEL’ if you want to run setup
It will prevent the message from appearing on the first BIOS screen when the computer boots.
Shadow
These options control the location of the contents of the 32KB of ROM beginning at the specified memor y location.
If no adapter ROM is using the named ROM area, this area is made available to the local bus. The settings are:
SETTING DESCRIPTION
Disabled
Enabled
Cached
Table 4-1 Shadow Setting
The video ROM is not copied to RAM. The contents of
the video ROM cannot be read from or written to cache
memory.
The contents of C000h - C7FFFh are written to the same
address in system memory (RAM) for faster execution.
The contents of the named ROM area are written to the
same address in system memory (RAM) for faster
execution, if an adapter ROM will be using the named
ROM area. Also, the contents of the RAM area can be
read from and written to cache memory.
4-9
Page 26
AR-B9629 User’s Guide
4.4 ADVANCED CHIPSET SETUP
This option controls the configuration of the board’s chips et. Control keys for this screen are the same as for the
previous screen.
AMIBIOS SETUP - ADVANCED CHIPSET SETUP
(C) 1995 American Megatrends, Inc. All Rights Reserved
AT Bus Clock 14.318 / 2
Slow Refresh 15 us
RAS Precharge time 3.5T
RAS Active Time Insert Wait Disable
CAS Precharge Time Insert Wait Disable
Memory Write Insert Wait Disable
ISA I/O High Speed Disable
ISA Memory High Speed Disable
I/O Recovery Enable
I/O Recovery Period 1.25 us
16Bit ISA Insert Wait Disable
Watchdog Timer Output Control Disable
WatchDog Timeout Issue Signal Reset
Available Options :
14. 318/2
PLCK2/3
PLCK2/4
PLCK2/5
PLCK2/6
PLCK2/8
PLCK2/10
PLCK2/12
ESC:Exit ↑↓:Sel
PgUp/PgDn:Modify
F2/F3:Color
Figure 4-4 BIOS: Advanced Chipset Setup
AT Bus Clock
This option sets the polling clock speed of ISA Bus (PC/104).
NOTE:
1. PCLK means the CPU inputs clock.
2. Acrosser recommends user setting at the range of 8MHz to 10MHz.
Slow Refresh
This option sets the DRAM refresh cycle time.
RAS Precharge Time
The DRAM RAS precharge time.
Time Insert Wait
The DRAM time insert wait: RAS Active and CAS Precharge function setting.
ISA High Speed
The Speed field shows the speed at which the processor runs internally.
I/O Recovery
If I/O Recovery Feature options are enabled, the BIOS insert a delay time bet ween two I/O commands. The dela y
time is defined in I/O Recovery Period option.
4-10
Page 27
4.5 PERIPHERAL SETUP
This section is used to configure peripheral features.
AMIBIOS SETUP - PERIPHERAL SETUP
(C) 1998 American Megatrends, Inc. All Rights Reserved
AR-B9629 User’s Guide
Hard disk Delay Disable
OnBoard Primary IDE Primary
OnBoard FDC Auto
OnBoard Serial Port1 3F8h
OnBoard Serial Port1 IRQ 4
OnBoard Serial Port2 2F8h
OnBoard Serial Port2 IRQ 3
OnBoard Parallel Port 378
Parallel Port Mode Normal
EPP Version N/A
Parallel Port IRQ 7
Parallel Port DMA Channel N/A
Available Options :
3 Sec
5 Sec
10 Sec
15 Sec
ESC:Exit ↑↓:Sel
PgUp/PgDn:Modify
F2/F3:Color
Figure 4-5 BIOS: Peripheral Setup
Hard Disk Delay
If this option is set to Disabled and the system BIOS executes too fast, the result is the BIOS can’t find the hard
disk drive.
OnBoard IDE
This option specifies the onboard IDE controller channels that will be used.
OnBoard FDC
This option enables the floppy drive controller on the AR-B9629.
OnBoard Serial Port
This option enables the serial port on the AR-B9629.
OnBoard Parallel Port
This option enables the parallel port on the AR-B9629.
Parallel Port Mode
This option specifies the parallel port mode. ECP and EPP are both bidirectional data transfer schemes that
adhere to the IEEE P1284 specifications.
Parallel Port DMA Channel
This option is only available if the setting for the parallel Port Mode option is ECP.
4-11
Page 28
AR-B9629 User’s Guide
4.6 AUTO-DETECT HARD DISKS
This option detects the parameters of an IDE hard disk drive, and automatically enters them into the Standar d
CMOS Setup screen.
4.7 PASSWORD SETTING
This BIOS Setup has an optional password feature. The system can be configured so that all users must enter a
password every time the system boots or when BIOS Setup is executed. User can set either a Supervisor
password or a User password.
4.7.1 Setting Password
Select the appropriate password icon (Supervisor or User) from the Security section of the BIOS Setup main menu.
Enter the password and press [Enter]. The screen does not display the characters entered. After the new
password is entered, retype the new password as prompted and press [Enter].
If the password confirmation is incorrect, an error message appears. If the new password is entered without error,
press [Esc] to return to the BIOS Main Menu. The password is stored in CMOS RAM after BIOS completes. The
next time the system boots, you are prompted for the password function is present and is enabled.
Enter new supervisor password:
4.7.2 Password Checking
The password check option is enabled in Advanced Setup by choosing either Always (the password prompt
appears every time the system is powered on) or Setup (the password prompt appear s only when BIOS is run).
The password is stored in CMOS RAM. User can enter a password by typing on the keyboard. As user selec t
Supervisor or User. The BIOS prompts for a password, user must set the Supervisor password before user can
set the User password. Enter 1-6 character as password. The password does not appear on the s creen when
typed. Make sure you write it down.
4.8 LOAD DEFAULT SETTING
In this section permit user to select a group of setting for all BIOS Setup options. You not only can use these items
to quickly set system configuration parameters, but also can choose a group of settings that have a better chanc e
of working when the system is having configuration related problems.
4.8.1 Auto Configuration with Optimal Setting
User can load the optimal default settings for the BIOS. The Optimal default settings are best-case values that
should optimize system performance. If CMOS RAM is corrupted, the optimal settings are loaded automatically.
Load high performance settings (Y /N) ?
4.8.2 Auto Configuration with Fail Safe Setting
User can load the Fail-Safe BIOS Setup option settings by selecting the Fail-Safe item from the Default section of
the BIOS Setup main menu.
The Fail-Safe settings provide far from optimal system performance, but are the most stable settings. Use this
option as a diagnostic aid if the system is behaving erratically.
Load failsafe settings (Y/N) ?
4-12
Page 29
AR-B9629 User’s Guide
4.9 BIOS EXIT
This section is used to exit the BIOS main menu in two types situation. After making your changes, you can either
save them or exit the BIOS menu and without saving the new values.
4.9.1 Save Settings and Exit
This item set in the <Standard CMOS Setup>, <Advanced CMOS Setup>, <Advanced Chipset Setup> and the new
password (if it has been changed) will be stored in the CM OS. The CMOS checksum is calculated and written into
the CMOS.
As you select this function, the following message will appear at the center of the screen to assist you to save data
to CMOS and Exit the Setup.
Save current settings and exit (Y/N) ?
4.9.2 Exit Without Saving
When you select this option, the following message will appear at the center of the screen to help to Abandon a ll
Data and Exit Setup.
Quit without saving (Y/N) ?
4-13
Page 30
AR-B9629 User’s Guide
4.10 BIOS UPDATE
The BIOS program instructions are contained within computer chips called F LASH ROMs that are located on your
system board. The chips can be electronically reprogrammed, allowing you to upgrade your BIOS firmware
without removing and installing chips.
The AR-B9629 provides FLASH BIOS update function for you to easily upgrade newer BIOS version. Please
follow the operating steps for updating new BIOS:
Step 1:
Step 2:
Step 3:
Step 4:
Step 5:
Step 6:
Step 7:
NOTE: 1. After turn on the computer and the system didn’t detect the boot procedure, please press t he [F5] key
Turn on your system and don＇t detect the CONFIG.SYS and AUTOEXEC.BAT files. Keep your
system in the real mode.
Insert the FLASH BIOS diskette into the floppy disk drive.
In the MS-DOS mode, you can type the AMIFLASH program.
A:\>AMIFLASH
The screen will show the message as follow:
Enter the BIOS File name from which Flash EPROM will be programmed. The File name must and
with a <ENTER> or press <ESC> to exit.
And then please enter the file name to the box of <Enter File Name>. And the b ox of <Message>
will show the notice as follow. In the bottom of this window always show the gray statement.
Flash EPROM Programming is going to start. System will not be usable until Programming of Flash
EPROM is successfully complete. In case of any error, existing Flash EPROM must be replaced by
new program Flash EPROM.
As the gray statement, press the <Y> key to updating the new BIOS.
And then the <Message> box will show the <Programming Flash EPROM>, and the gray statement
shows <Please Wait>.
The BIOS update is successful, the message will show <Flash Update Completed - Pass>.
immediately. The system will pass the CONFIG.SYS and AUTOEXEC.BAT files.
2. The BIOS Flash disk is not the standard accessory. Now the onboard BIOS is the newest BIOS, if user
needs adding some functions in the future please contact technical supporting engineers, they will
provide the newest BIOS for updating.
3. The file of AMIFLASH.EXE had to use the attached diskette＇s file, if not user had to use the Version
6.31.
4-14
Page 31
5. SPECIFICATIONS
Model No. AR-B9629
Description
Version/ Date
CPU & Chipset:
System Memory:
Memory:
Power Connector:
I/O:
Extension BUS:
LED Indicator:
Power Requirement:
CE-Design In
PC Board:
Dimensions:
Operating Temp.
Storage Temp.
Operating Humidity
Order Information:
386 Grade CPU Board with EPROM socket, ISA Bus
V0.1, 10/24/02
ALI 386SX-33 CPU; ALI M6117C, 25/33/40 MHz (default: 40)
2M Byte EDO ROM on-Board
512K EPROM socket (one SSD socket for 27C040)
JST 4S Connector
2 Serial Ports (TTL Level), 1 Printer Port, I IDE Port, Keyboard and Mouse Port, ISA
Interface Connector
Two 50 pins 2.0 mm connectors for ISA bus extension
On Board power LED
+5V-1.0A maximum (based on 33 MHz clock frequency)
Add EMI components to keyboard and PS/2 mouse
4 layers
82.6 mmX57.2mm
0~60℃
-20~80℃
0~90﹪relative humidity none-condensing
AR-B9449 is a collocation tool for writing program on AR-B9629
AR-B9629 User’s Guide
5-1
Page 32
Page 33
6. PLACEMENT & DIMENSIONS
6.1 PLACEMENT
AR-B9629 User’s Guide
6-1
Page 34
AR-B9629 User’s Guide
6.2 DIMENSIONS
Unit: mil (1 inch = 25.4 mm = 1000 mil)
Note:
If the content in Setting is inconsistent with CD-ROM, please refer to the Setting as priority.
6-2
Loading...
