Acrosser AR-B9622 User Manual

Download

AR-B9622 User’s Guide

AR-B9622

Half Size All-In-One

386SX CPU BOARD

User’s Guide

Edition: 1.43

Book Number: AR-B9622-05.0615

0-1

AR-B9622 User’s Guide

Table of Contents

0. PREFACE...........................................................................................................................................................0-4

0.1 COPYRIGHT NOTICE AND DISCLAIMER............................................................................................................................0-4

0.2 WELCOME TO THE AR-B9622 CPU BOARD....................................................................................................................... 0-4

0.3 BEFORE YOU USE THIS GUIDE.......................................................................................................................................... 0-4

0.4 RETURNING YOUR BOARD FOR SERVICE ....................................................................................................................... 0-4

0.5 TECHNICAL SUPPORT AND USER COMMENTS............................................................................................................... 0-4

0.6 ORGANIZATION.................................................................................................................................................................... 0-5

0.7 STATIC ELECTRICITY PRECAUTIONS ............................................................................................................................... 0-5

1. OVERVIEW.........................................................................................................................................................1-1

1.1 INTRODUCTION....................................................................................................................................................................1-1

1.2 PACKING LIST....................................................................................................................................................................... 1-1

1.3 FEATURES ............................................................................................................................................................................ 1-1

2. SYSTEM CONTROLLER....................................................................................................................................2-1

2.1 MICROPROCESSOR ............................................................................................................................................................2-1

2.2 DMA CONTROLLER.............................................................................................................................................................. 2-1

2.3 KEYBOARD CONTROLLER..................................................................................................................................................2-2

2.4 INTERRUPT CONTROLLER ................................................................................................................................................. 2-2

2.4.1 I/O Port Address Map..................................................................................................................................................... 2-3

2.4.2 Real-Time Clock and Non-Volatile RAM........................................................................................................................ 2-4

2.4.3 Timer.............................................................................................................................................................................. 2-4

2.5 SERIAL PORT........................................................................................................................................................................ 2-5

2.6 PARALLEL PORT.................................................................................................................................................................. 2-7

3. SETTING UP THE SYSTEM...............................................................................................................................3-1

3.1 OVERVIEW............................................................................................................................................................................ 3-1

3.2 SYSTEM SETTING................................................................................................................................................................ 3-2

3.2.1 Keyboard Connector ...................................................................................................................................................... 3-2

3.2.2 PC/104 Connector.......................................................................................................................................................... 3-3

3.2.3 Hard Disk (IDE) Connector (CN3)..................................................................................................................................3-5

3.2.4 PS/2 Mouse Connector (J2)...........................................................................................................................................3-6

3.2.5 FDD Port Connector (CN7)............................................................................................................................................ 3-6

3.2.6 Reset Header (J3)..........................................................................................................................................................3-6

3.2.7 Parallel Port Connector (CN8 & CN9)............................................................................................................................3-7

3.2.8 Power Connector (J7 & J8)............................................................................................................................................ 3-7

3.2.9 Serial Port....................................................................................................................................................................... 3-8

3.2.10 Compact Flash Connector (CN2).............................................................................................................................3-10

3.2.11 RJ-45 Connector (CN4) ........................................................................................................................................... 3-11

3.2.12 CPU Base Clock Select (JP2).................................................................................................................................. 3-11

3.2.13 D.O.C. Installation (U7)............................................................................................................................................ 3-11

4. CRT/LCD FLAT PANEL DISPLAY.....................................................................................................................4-1

4.1 LCD FLAT PANEL DISPLAY .................................................................................................................................................4-1

4.2 CRT & LCD DISPLAY ............................................................................................................................................................ 4-3

4.2.1 CRT Connector (CN6 & DB1) ........................................................................................................................................ 4-3

4.2.2 LCD Setting.................................................................................................................................................................... 4-3

5. INSTALLATION..................................................................................................................................................5-1

5.1 OVERVIEW............................................................................................................................................................................ 5-1

5.2 UTILITY DISKETTE ............................................................................................................................................................... 5-1

5.2.1 VGA Driver..................................................................................................................................................................... 5-2

5.2.2 BIOS FLASH Utility ........................................................................................................................................................ 5-2

5.2.3 Network Utility ................................................................................................................................................................ 5-2

5.3 WATCHDOG TIMER.............................................................................................................................................................. 5-3

5.3.1 Watchdog Timer Setting................................................................................................................................................. 5-3

5.3.2 Watchdog Enabled/Disabled - INDEX 37H.................................................................................................................... 5-4

5.3.3 Select Watchdog Report Signal - INDEX 38H ............................................................................................................... 5-4

5.3.4 Timeout Status & Reset Watchdog - INDEX 3CH ..................................................................................................................... 5-4

5.3.5 Programming Watchdog - Basic Operation.................................................................................................................... 5-4

6. BIOS CONSOLE.................................................................................................................................................6-1

6.1 BIOS SETUP OVERVIEW ..................................................................................................................................................... 6-1

6.2 STANDARD CMOS SETUP................................................................................................................................................... 6-2

6.3 ADVANCED CMOS SETUP................................................................................................................................................... 6-3

6.4 ADVANCED CHIPSET SETUP.............................................................................................................................................. 6-5

6.5 PERIPHERAL SETUP............................................................................................................................................................ 6-6

6.6 AUTO-DETECT HARD DISKS............................................................................................................................................... 6-7

6.7 PASSWORD SETTING.......................................................................................................................................................... 6-7

6.7.1 Setting Password ........................................................................................................................................................... 6-7

0-2

AR-B9622 User’s Guide

6.7.2 Password Checking........................................................................................................................................................ 6-7

6.8 LOAD DEFAULT SETTING.................................................................................................................................................... 6-7

6.8.1 Auto Configuration with Optimal Setting ........................................................................................................................ 6-7

6.8.2 Auto Configuration with Fail Safe Setting....................................................................................................................... 6-7

6.9 BIOS EXIT.............................................................................................................................................................................. 6-8

6.9.1 Save Settings and Exit................................................................................................................................................... 6-8

6.9.2 Exit Without Saving........................................................................................................................................................ 6-8

6.10 BIOS UPDATE................................................................................................................................................................... 6-8

7. SPECIFICATIONS..............................................................................................................................................7-1

8. PLACEMENT & DIMENSIONS...........................................................................................................................8-1

8.1 PLACEMENT .........................................................................................................................................................................8-1

8.2 DIMENSIONS......................................................................................................................................................................... 8-2

9. PROGRAMMING RS-485 & INDEX....................................................................................................................9-1

9.1 PROGRAMMING RS-485...................................................................................................................................................... 9-1

9.2 INDEX ....................................................................................................................................................................................9-3

0-3

AR-B9622 User’s Guide

0.PREFACE

0.1 COPYRIGHT NOTICE AND DISCLAIMER

December 1998

Acrosser Technology makes no representations or warranties with respect to the contents hereof and s pecifically disclaims any implied warranties of merchantability or fitness for any particular purpose. Furthermore, Acrosser Technology reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of Acrosser Technology to notify any person of such revisions or changes. Possession, use, or copying of the software described in this publication is authorized only pursuant to a valid written license from Acrosser or an authorized sublicensor.

(C) Copyright 錯誤! 尚未定義書籤。 Acrosser Technology Co., Ltd., 1998. All rights Reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval s ystem, or translated

into any language or computer language, in any form or any me ans, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written consent of Acrosser Technology. Acrosser, AMI, IBM PC/AT, ALI, Windows 3.1, MS-DOS, …are registered trademarks. All other trademarks and registered trademarks are the property of their respective holders. This document was produced with Adobe Acrobat 3.01.

0.2 WELCOME TO THE AR-B9622 CPU BOARD

This guide introduces the Acrosser AR-B9622 CPU board. Use the information describes this card’s functions, features, and how to start, set up and operate your A R-B9622. You can also find general system information here.

0.3 BEFORE YOU USE THIS GUIDE

If you have not already installed this AR-B9622, refer to the Chapt er 3, “Setting Up the System” in this guide. Check the packing list, make sure the accessories are in the package. AR-B9622 diskette provides the latest information about the card. Please refer to the README.DOC file of the enclosed utility diskette. It contains the modification and hardware & software information, and adding the description or modification of product function after manual published.

0.4 RETURNING YOUR BOARD FOR SERVICE

If your board requires servicing, contact the dealer from whom you purchased the product for service information. If you need to ship your board to us for service, be sure it is packed in a protective carton. We recommend that you keep the original shipping container for this purpose.

You can help assure efficient servicing of your product by following these guidelines:

1. Include your name, address, telephone and facsimile number where you may be reached during the day.

2. A description of the system configuration and/or software at the time of malfunction.

3. A brief description of the symptoms.

0.5 TECHNICAL SUPPORT AND USER COMMENTS

User’s錯誤! 尚未定義書籤。 comments are always welcome as they assist us in improving the usefulness of our products and the understanding of our publications. They form a ver y important part of the input used for product

enhancement and revision. We may use and distribute any of the information you supply in any way we believe appropriate without incurring any obligation. You may, of course, continue to use the information you supply. If you have suggestions for improving particular sections or if you find any errors, please indicate the manual title and book number. Please send your comments to Acrosser Technology Co., Ltd. or your local sales representative. Internet electronic mail to: webmaster@acrosser.com

0-4

AR-B9622 User’s Guide

0.6 ORGANIZATION

This information for users covers the following topics (see the Table of Contents for a detailed listing):

 Chapter 1, “Overview”, provides an overview of the system features and packing list.  Chapter 2, “System Controller” describes the major structure.  Chapter 3, “Setting Up the System”, describes how to adjust the jumper, and the connectors setting.  Chapter 4, “CRT/LCD Flat Panel Display”, describes the configuration and installation procedure usi ng

LCD display.

 Chapter 5, “Installation”, describes setup procedures including information on the utility disk ette.  Chapter 6, “BIOS Console”, providing the BIOS options setting.  Chapter 7, Specifications  Chapter 8, Placement & Dimensions  Chapter 9, Programming RS-485 & Index

0.7 STATIC ELECTRICITY PRECAUTIONS

Before removing the board from its anti-static bag, read this section about static electricity precautions. Static electricity is a constant danger to the computer systems. The charge that can build up in your body may be more than sufficient to damage integrated circuits on any PC board. It is, therefore, important to observe basic precautions whenever you use or handle co mputer components. Although areas with humid climates are much less prone to static build-up, it is always the best to safeguard against accidents which may result in e xpensive repairs. The following measures should generally be sufficient to protect your equipment from static discharge:

• Touch a grounded metal object to dischar ge the static electricity in your body (or ideally, wear a groun ded wrist strap).

• When unpacking and handling the board or other s ystem components, place all materials on an antic static surface.

• Be careful not to touch the components on the board, especially the “golden finger” connectors on the bottom of every board.

0-5

AR-B9622 User’s Guide

1. OVERVIEW

This chapter provides an overview of your system features and capabilities. The following topics are covered:

 Introduction  Packing List  Features

1.1 INTRODUCTION

The AR-B9622 is a new generation half-size, 386SX board. This card offers much greater performance than the older cards such as support for onboard 4MB DRAM and one RS-232C/485 and three RS-232C p orts and one socket for the DiskOnChip from 2MB up to 72MB.

The unit also comes with a programmable watch dog timer and other typi cal interfaces. The 386 CPU board is excellent for embedded systems, MMI’s, work stations, medical applications or POS/POI systems. As well, an RS-232C/485 port provides the remote control. RS-485 interface is only offered recently on 386 cards.

Especially the AR-B9622’s on-board VGA, offers the most exciting possibilities yet to the industry. The on-board VGA/LCD controller brings about a whole new dimension of industrial computing. No longer do you have to worry about adding an extra card to your system. The VGA/LCD unit comes with 1MB V-RAM on board and uses the C&T 65545 Chipset, to support a wide range of LCD Panels.

1.2 PACKING LIST

The accessories are included with the system. Before you begin installi ng your AR-B9622 board, take a moment to make sure that the following items have been included inside the AR-B9622 package.

 The quick setup manual  1 AR-B9622 all-in-one single CPU board  1 Hard disk drive interface cable  1 VGA 10-pin cable  2 Parallel port interface cables  1 Keyboard adapter  1 PS/2 mouse adapter  4 phone-jack to DB-9 adapters  2 Software utility diskettes

1.3 FEATURES

The system provides a number of special features that enhance its reliabi lit y, ensure its availabil ity, and improve its expansion capabilities, as well as its hardware structure.

 80386SX-33/40 MHz CPU  PC/104 extension bus  On-board CRT and LCD panel display  Supports IDE hard disk drives  Supports floppy disk drives  Supports 2 bi-directional parallel port  PC/AT compatible keyboard  Up to 72MB for one DiskOnChip  Programmable watchdog timer  Flash BIOS  Signal 5V power requirement  Multi-layer PCB for noise reduction  Dimensions : 145mmX142mm

1-1

AR-B9622 User’s Guide

1-2

AR-B9622 User’s Guide

2. SYSTEM CONTROLLER

This chapter describes the major structure of the AR-B9622 CPU board. The following topics are covered:

 Microprocessor  DMA Controller  Keyboard Controller  Interrupt Controller  Serial Port  Parallel Port

2.1 MICROPROCESSOR

The AR-B9622 uses the ALI M6117 CPU; it is designed to perform systems like Intel’s 386SX system with deep green features.

The 386SX core is the same as M1386SX of Acer Labs. Inc. and 1 0 0 % o b j e ct c o d e c o mp a t ib l e w i th t h e I n t e l 38 6S X microprocessor. System manuf acturers can provide 386 CPU based systems optimized for both cost and size. Instruction pipelining and high bus bandwidth ensure short average instruction execution time and high system throughput. Furthermore, it can keep the state internally from charge leakage while external clock to the core is stopped without storing the data in registers. The power consumption here is almost zero until the clock stops. The internal structure of this core is 32-bit data and address bus with very lo w supply current. Real mode as well as Protected mode are available and can run MS-DOS /MS-Windows.

2.2 DMA CONTROLLER

The equivalent of two 8237A DMA controllers are implemented in th e AR-B9622 board. Each controller is a fourchannel DMA device that will generate the memory addresses and control signals necessary to transfer info r mati o n dir ectl y bet ween a peripheral device and memory. This allows high speeding information trans f er wi t h less CPU intervention. The two DMA controllers are internally cascaded to pr ovide four DMA channels for transfers to 8-bit peripherals (DMA1) and three channels for transfers to 16-bit peripherals (DMA2). DMA2 channel 0 provides the cascade interconnection between the two DMA devices, thereby maintaining IBM PC/AT compatibility.

The following is the system information of DMA channels:

DMA Controller 1 DMA Controller 2

Channel 0: Spare Channel 4: Cascade for controller 1 Channel 1: IBM SDLC Channel 5: Spare Channel 2: Diskette adapter Channel 6: Spare Channel 3: Spare Channel 7: Spare

Table 2-1 DMA Channel Controller

2-1

AR-B9622 User’s Guide

2.3 KEYBOARD CONTROLLER

The 8042 processor is programmed to support the keyboard serial interface. The keyboard controller receives serial data from the keyboard, checks its parity, translates scan codes, and presents it to the system as a byte data in its output buffer. The controller can interrupt the system when data is place d in its output buffer, or wait for the system to poll its status register to determine when data is available.

Data can be written to the keyboard by writing data to the output buffer of the keyboard controller.

Each byte of data is sent to the keyboard controller in seri es with an odd parity bit automatically inserted. The keyboard controller is required to acknowledge all data transmissions. Therefore, another byte of data will not be sent to keyboard controller until acknowledgment is received for the previous byte sent. The “output buffer full” interruption may be used for both send-and-receive routines.

2.4 INTERRUPT CONTROLLER

The equivalent of two 8259 Programmable Interrupt Controllers (PIC) are included on the AR-B9622 board. They accept requests from peripherals, resolve priorities on pending interrupts in service, issue interrupt req uests to the CPU, and provide vectors which are used as acceptance indices by the CP U to determine which interrupt service routine to execute.

The following is the system information of interrupt levels:

InInterrupt Level

Description

NMI CTRL1

IRQ 0 IRQ 1 IRQ 2

IRQ 3 IRQ 4 IRQ 5 IRQ 6 IRQ 7

Parity check CTRL2

System timer interrupt from timer 825 Keyboard output buffer full Rerouting to IRQ8 to IRQ15

IRQ8 : Real time clock IRQ9 : Serial port 4 IRQ10 : LAN adapter IRQ11 : Serial port 3 IRQ12 : Reserved for PS/2 mouse IRQ13 : Math. coprocessor

IRQ14 : Hard disk adapter IRQ15 : Reserved for Compact Flash

Serial port 2 Serial port 1 Parallel port 2 Floppy disk adapter Parallel port 1

Figure 2-1 Interrupt Controller

2-2

2.4.1 I/O Port Address Map

Hex Range Device

000-01F DMA controller 1 020-021 Interrupt controller 1 022-023 ALI M6117 chipset address 040-04F Timer 1 050-05F Timer 2 060-06F 8042 keyboard/controller 070-071 Real-time clock (RTC), non-maskable interrupt (NMI) 080-09F DMA page registers

0A0-0A1 Interrupt controller 2

0C0-0DF DMA controller 2

0F0 Clear Math Co-processor 0F1 Reset Math Co-processor

0F8-0FF Math Co-processor

170-178 Fixed disk 1

1F0-1F8 Fixed disk 0

201 Game port 208-20A EMS register 0 218-21A EMS register 1

278-27F Parallel printer port 2 (LPT 2)

2E8-2EF Serial port 4 (COM 4)

2F8-2FF Serial port 2 (COM 2)

300-31F Prototype card/streaming type adapter 320-33F LAN adapter 378-37F Parallel printer port 1 (LPT 1)

380-38F SDLC, bisynchronous 3A0-3AF Bisynchronous 3B0-3BF Monochrome display and printer port 3 (LPT 3) 3C0-3CF EGA/VGA adapter 3D0-3DF Color/graphics monitor adapter 3E8-3EF Serial port 3 (COM 3)

3F0-3F7 Diskette controller 3F8-3FF Serial port 1 (COM 1)

Table 2-2 I/O Port Address Map

AR-B9622 User’s Guide

2-3

AR-B9622 User’s Guide

2.4.2 Real-Time Clock and Non-Volatile RAM

The AR-B9622 contains a real-time clock compartment that maintains the date and time in addition to storing configuration information about the computer system. It contains 14 bytes of clock and control registers and 114 bytes of general purpose RAM. Because of the use of CMOS technology, it consumes v er y little power and ca n be maintained for long periods of time using an internal Lithium battery. The contents of each b yte in the CMOS RAM are listed below:

Address Description

00 Seconds 01 Second alarm 02 Minutes 03 Minute alarm 04 Hours 05 Hour alarm 06 Day of week 07 Date of month 08 Month 09 Year 0A Status register A

0B Status register B 0C Status register C 0D Status register D 0E Diagnostic status byte 0F Shutdown status byte

10 Diskette drive type byte, drive A and B

11 Fixed disk type byte, drive C

12 Fixed disk type byte, drive D

13 Reserved

14 Equipment byte

15 Low base memory byte

16 High base memory byte

17 Low expansion memory byte

18 High expansion memory byte

19-2D Reserved 2E-2F 2-byte CMOS checksum

30 Low actual expansion memory byte

31 High actual expansion memory byte

32 Date century byte

33 Information flags (set during power on)

34-7F Reserved for system BIOS

Table 2-3 Real-Time Clock & Non-Volatile RAM

2.4.3 Timer

The AR-B9622 provides three programmable timers, each with a timing frequency of 1.19 MHz.

Timer 0 The output of this timer is tied to interrupt request 0. (IRQ 0)

Timer 1 This timer is used to trigger memory refresh cycles.

Timer 2 This timer provides the sp eaker tone.

Application programs can load different counts into this timer to generate various sound frequencies.

2-4

AR-B9622 User’s Guide

2.5 SERIAL PORT

The ACEs (Asynchronous Communication Elements ACE1 to ACE4) are used to convert parallel data to a serial format on the transmit side and convert serial data to parallel on the rec eiver side. The serial format, in order of transmission and reception, is a start bit, followed by five to eight data bits, a parity bit (if programmed) and one, one and half (five-bit format only) or two stop bits. The ACEs are capable of handling divisors of 1 to 65535, and produce a 16x clock for driving the internal transmitter logic.

Provisions are also included to use this 16x clock to drive the receiver logic. Also included in the ACE a completed MODEM control capability, and a processor interrupt system that may be software tailored to the computing time required to handle the communications link.

The following table is a summary of each ACE accessible register

DLAB Port Address Register

Receiver buffer (read) 0 base + 0 Transmitter holding register (write)

0 base + 1 Interrupt enable X base + 2 Interrupt identification (read only) X base + 3 Line control X base + 4 MODEM control X base + 5 Line status X base + 6 MODEM status X base + 7 Scratched register

1 base + 0 Divisor latch (least significant byte)

1 base + 1 Divisor latch (most significant byte)

Table 2-4 ACE Accessible Registers

(1) Receiver Buffer Register (RBR)

Bit 0-7: Received data byte (Read Only)

(2) Transmitter Holding Register (THR)

Bit 0-7: Transmitter holding data byte (Write Only)

(3) Interrupt Enable Register (IER)

Bit 0: Enable Received Data Available Interrupt (ERBFI) Bit 1: Enable Transmitter Holding Empty Interrupt (ETBEI) Bit 2: Enable Receiver Line Status Interrupt (ELSI) Bit 3: Enable MODEM Status Interrupt (EDSSI) Bit 4: Must be 0 Bit 5: Must be 0 Bit 6: Must be 0 Bit 7: Must be 0

(4) Interrupt Identification Register (IIR)

Bit 0: “0” if Interrupt Pending Bit 1: Interrupt ID Bit 0 Bit 2: Interrupt ID Bit 1 Bit 3: Must be 0 Bit 4: Must be 0 Bit 5: Must be 0 Bit 6: Must be 0 Bit 7: Must be 0

2-5

AR-B9622 User’s Guide

(5) Line Control Register (LCR)

Bit 0: Word Length Select Bit 0 (WLS0) Bit 1: Word Length Select Bit 1 (WLS1)

WLS1 WLS0 Word Length

0 0 5 Bits 0 1 6 Bits 1 0 7 Bits

1 1 8 Bits Bit 2: Number of Stop Bit (STB) Bit 3: Parity Enable (PEN) Bit 4: Even Parity Select (EPS) Bit 5: Stick Parity Bit 6: Set Break Bit 7: Divisor Latch Access Bit (DLAB)

(6) MODEM Control Register (MCR)

Bit 0: Data Terminal Ready (DTR) Bit 1: Request to Send (RTS) Bit 2: Out 1 (OUT 1) Bit 3: Out 2 (OUT 2) Bit 4: Loop Bit 5: Must be 0 Bit 6: Must be 0 Bit 7: Must be 0

(7) Line Status Register (LSR)

Bit 0: Data Ready (DR) Bit 1: Overrun Error (OR) Bit 2: Parity Error (PE) Bit 3: Framing Error (FE) Bit 4: Break Interrupt (BI) Bit 5: Transmitter Holding Register Empty (THRE) Bit 6: Transmitter Shift Register Empty (TSRE) Bit 7: Must be 0

(8) MODEM Status Register (MSR)

Bit 0: Delta Clear to Send (DCTS) Bit 1: Delta Data Set Ready (DDSR) Bit 2: Training Edge Ring Indicator (TERI) Bit 3: Delta Receive Line Signal Detect (DSLSD) Bit 4: Clear to Send (CTS) Bit 5: Data Set Ready (DSR) Bit 6: Ring Indicator (RI) Bit 7: Received Line Signal Detect (RSLD)

2-6

(9) Divisor Latch (LS, MS)

LS MS

Bit 0: Bit 0 Bit 8 Bit 1: Bit 1 Bit 9 Bit 2: Bit 2 Bit 10 Bit 3: Bit 3 Bit 11 Bit 4: Bit 4 Bit 12 Bit 5: Bit 5 Bit 13 Bit 6: Bit 6 Bit 14 Bit 7: Bit 7 Bit 15

Table 2-5 Serial Port Divisor Latch

AR-B9622 User’s Guide

Desired Baud Rate Divisor Used to Generate 16x Clock

300 384

600 192 1200 96 1800 64 2400 48 3600 32 4800 24 9600 12

14400 8 19200 6 28800 4 38400 3 57600 2

115200 1

2.6 PARALLEL PORT

(1) Register Address

Port Address Read/Write Register

base + 0 Write Output data base + 0 Read Input data base + 1 Read Printer status buffer base + 2 Write Printer control latch

Table 2-6 Registers’ Address

(2) Printer Interface Logic

The parallel portion of the SMC37C669 makes the attachment of various devices that accept eight bits of parallel data at standard TTL level.

(3) Data Swapper

The system microprocessor can read the contents of the printer’s Data Latch through the Data Swapper by reading the Data Swapper address.

2-7

AR-B9622 User’s Guide

(4) Printer Status Buffer

The system microprocessor can read the printer status by reading the address of the Printer Status Buffer. The bit definitions are described below:

12345670

XXX

-ERROR SLCT PE

-ACK

-BUSY

Figure 2-2 Printer Status Buffer

NOTE: X represents not used.

Bit 7: T his signal may become active during data entry, when the printer is off-line dur ing printing, or when the

print head is changing position or in an error state. When Bit 7 is active, the printer is busy and can not accept data.

Bit 6: This bit represents the current state of the printer’s ACK signal. A 0 means the printer has received the

character and is ready to accept another. Normally, this signal will be active for approximately 5 microseconds before receiving a BUS Y message stops.

Bit 5: A 1 means the printer has detected the end of the paper.

Bit 4: A 1 means the printer is selected.

Bit 3: A 0 means the printer has encountered an error condition.

2-8

AR-B9622 User’s Guide

(5) Printer Control Latch & Printer Control Swapper

The system microprocessor can read the contents of the printer control latch by reading the address of printer control swapper. Bit definitions are as follows:

Figure 2-3 Bit’s Definition

NOTE: X represents not used.

Bit 5: Direction control bit. When logic 1, the output buffers in the parallel port are disabled allowing data driven

from external sources to be read; when logic 0, they work as a printer port. This bit is write only.

Bit 4: A 1 in this position allows an interrupt to occur when ACK changes from low state to high state.

Bit 3: A 1 in this bit position selects the printer.

Bit 2: A 0 starts the printer (50 microseconds pulse, minimum).

Bit 1: A 1 causes the printer to line-feed after a line is printed.

Bit 0: A 0.5 microsecond minimum highly active pulse clocks data into the printer. Valid data must be present

for a minimum of 0.5 microseconds before and after the strobe pulse.

12345670

STROBE AUTO FD XT INIT SLDC IN IRQ ENABLE

DIR(write only)

2-9

AR-B9622 User’s Guide

3. SETTING UP THE SYSTEM

This section describes the pin assignments for system’s external connectors and the jumper settings.

 Overview  System Setting

3.1 OVERVIEW

The AR-B9622 is an all-in-one, half-size, 386SX CPU board. This section provi des hardware jumper settings, the connectors’ locations, and the pin assignment.

CAUTION: The CPU board doesn’t support the SIMM-type DRAM.

Figure 3-1 External System Location

3-1

AR-B9622 User’s Guide

3.2 SYSTEM SETTINGS

Jumper pins allow you to set specific system parameters. Set them by changing the pin location of jumper blocks. (A jumper block is a small plastic-encased conductor [shorting plug] that slips over the pins.) To change a jumper setting, remove the jumper from its current location with your fingers or small needle-nosed pliers. Place the jumper over the two pins designated for the desired setting. Press the jumper evenly onto the pins. Be careful not to bend the pins.

We will show the locations of the AR-B9622 jumper pins, and the factory-default settings.

CAUTION: Do not touch any electronic component unless you are safely grounde d. Wear a grounded wrist strap

or touch an exposed metal part of the system unit chassis. The static discharg es from your fin gers c an permanently damage the electronic components.

3.2.1 Keyboard Connector

(1) 6-Pin Mini DIN Keyboard Connector (CN1)

CN1 is a Mini-DIN 6-pin connector. This keyboard connector is the PS/2 type keyboard connector. This connector is also used for a standard IBM-compatible keyboard that uses the keyboard adapter cable.

CN1

1 DATA

2 N.C. 3 GND 4 VCC

5 CLOCK 6 N.C.

Figure 3-2 CN1: 6-Pin Mini Din Keyboard Connector

(2) AUX. Keyboard Connector (J1)

A PC/AT compatible keyboard can be used by connecting the provided adapter cable between J1 and the keyboard. The pin assignments of J1 connector are as follows:

Front View

3-2

1 CLOCK

2 DATA 3 N.C. 4 GND 5 VCC

J1 Keyboard Connector

Figure 3-3 J1: AUX. Keyboard Connector

3.2.2 PC/104 Connector

(1) 64 Pin PC/104 Connector Bus A & B (CN11)

AR-B9622 User’s Guide

SD7 --SD6 --SD5 --SD4 --SD3 --SD2 --SD1 --SD0 ---

AEN ---

A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13 A14 A15 A16 A17 A18 A19 A20 A21 A22 A23 A24 A25 A26 A27 A28 A29 A30 A31 A32

-IOCHCK ---

IOCHRDY---

SA19 --SA18 --SA17 --SA16 --SA15 --SA14 --SA13 --SA12 --SA11 ---

SA10 --SA9 --SA8 --SA7 --SA6 --SA5 --SA4 --SA3 --SA2 --SA1 ---

SA0 --GND ---

Figure 3-4 CN11: 64-Pin PC/104 Connector Bus A & B

(2) 40 Pin PC/104 Connector Bus C & D (CN12)

CN11

--- GND

--- RSTDRV

--- +5 VDC

--- IRQ9

--- -5 VDC

--- DRQ2

--- -12 VDC

--- -ZWS

--- +12 VDC

B10

--- GND

B11

--- -SMEMW

B12

--- -SMEMR

B13

--- -IOW

B14

--- -IOR

B15

--- -DACK3

B16

--- DRQ3

B17

--- -DACK1

B18

--- DRQ1

B19

--- -REFRESH

B20

--- BUSCLK

B21

--- IRQ7

--- IRQ6

B22

--- IRQ5

B23

--- IRQ4

B24

--- IRQ3

B25

--- -DACK2

B26

--- TC

B27

--- BALE

B28

--- +5 VDC

B29

--- OSC

B30

--- GND

B31

--- GND

B32

GND ---

-BHE --LA23 --LA22 --LA21 --LA20 --LA19 --LA18 --LA17 ---

-MRD16 ---

-MWR16 --SD8 --SD9 ---

SD10 --SD11 --SD12 --SD13 --SD14 --SD15 ---

Not Used ---

C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12 C13 C14 C15 C16 C17 C18 C19 C20

CN12

--- GND

--- -MEM16

--- -IOCS16

--- IRQ10

--- IRQ11

--- IRQ12

--- IDEIRQA

--- IDEIRQB

--- -DACK0

D10

--- DRQ0

D11

--- -DACK5

D12

--- DRQ5

D13

--- -DACK6

D14

--- DRQ6

D15

--- -DACK7

D16

--- DRQ7

D17

--- +5 VDC

D18

--- -MASTER

D19

--- GND

D20

--- GND

Figure 3-5 CN12: 40-Pin PC/104 Connector Bus C & D

3-3

AR-B9622 User’s Guide

(3) PC/104 ISA Signal Description

Name Description

BUSCLK [Output] The BUSCLK signal of the I/O channel is asynchronous

RSTDRV [Output] This signal goes high during power-up, low line-voltage or

SA0 - SA19

[Input / Output]

LA17 - LA23

[Input/Output]

SD0 - SD15

[Input/Output]

BALE [Output] The Buffered Address Latch Enable is used to latch

-IOCHCK [Input] The I/O Channel Check is an active low signal which

IOCHRDY

[Input, Open collector]

IRQ 3-7, 9-12, 14, 15

-IOR

[Input/Output]

-IOW [Input/Output] The I/O write signal is an active low signal which instructs

-SMEMR [Output] The System Memory Read is low while any of the low

-MEMR

[Input/Output]

-SMEMW [Output] The System Memory Write is low while any of the low

-MEMW

[Input/Output]

DRQ 0-3, 5-7 [Input] DMA Request channels 0 to 3 are for 8-bit data transfers.

-DACK 0-3, 5-7

[Output]

AEN [output] The DMA Address Enable is high when the DMA

-REFRESH

[Input/Output]

TC [Output] Terminal Count provides a pulse when the terminal count

SBHE [Input/Output] The System Bus High Enable indicates the high byte SD8

to the CPU clock.

hardware reset The System Address lines run from bit 0 to 19. They are latched onto the falling edge of "BALE" The Unlatched Address line run from bit 17 to 23

System Data bit 0 to 15

SA0 – SA19 onto the falling edge. This signal is forced high during DMA cycles

indicates that a parity error exist on the I/O board This signal lengthens the I/O, or memory read/write cycle, and should be held low with a valid address The Interrupt Request signal indicates I/O service request attention. They are prioritized in the following sequence :

[Input]

(Highest) IRQ 9, 10, 11, 12, 13, 15, 3, 4, 5, 6, 7 (Lowest) The I/O Read signal is an active low signal which instructs the I/O device to drive its data onto the data bus

the I/O device to read data from the data bus

1mega bytes of memory are being used The Memory Read signal is low while any memory location is being read

1mega bytes of memory is being written The Memory Write signal is low while any memory location is being written

DMA Request channels 5 to 7 are for 16-bit data transfers. DMA request should be held high until the corresponding DMA has been completed. DMA request priority is in the following sequence:(Highest) DRQ 0, 1, 2, 3, 5, 6, 7 (Lowest) The DMA Acknowledges 0 to 3, 5 to 7 are the corresponding acknowledge signals for DRQ 0 to 3 and 5 to 7

controller is driving the address bus. It is low when the CPU is driving the address bus This signal is used to indicate a memory refresh cycle and can be driven by the microprocessor on the I/O channel

for any DMA channel is reached

- SD15 on the data bus

3-4

AR-B9622 User’s Guide

Name Description

-MASTER [Input] The MASTER is the signal from the I/O processor which

gains control as the master and should be held low for a maximum of 15 microseconds or system memory may be lost due to the lack of refresh

-MEMCS16

[Input, Open collector]

-IOCS16

[Input, Open collector]

OSC [Output] The Oscillator is a 14.31818 MHz signal

-ZWS

[Input, Open collector]

The Memory Chip Select 16 indicates that the present data transfer is a 1-wait state, 16-bit data memory operation The I/O Chip Select 16 indicates that the present data transfer is a 1-wait state, 16-bit data I/O operation

The Zero Wait State indicates to the microprocessor that the present bus cycle can be completed without inserting additional wait cycle

Table 3-1 PC/104 ISA Pin Assignment

3.2.3 Hard Disk (IDE) Connector (CN3)

A 44-pin header type connector (CN3) is provided to interface with up to t wo embedded hard disk drives (IDE AT bus). This interface, through a 44-pin cable, allows the user to conn ect up to two drives in a “dais y chain” fashion. To enable or disable the hard disk controller, please use BIOS Setup program to select. The following table illustrates the pin assignments of the hard disk drive’s 40-pin connector.

244

Figure 3-6 CN3: Hard Disk (IDE) Connector

Pin Signal Pin Signal

1 -RESET 2 GROUND 3 DATA 7 4 DATA 8 5 DATA 6 6 DATA 9 7 DATA 5 8 DATA 10

9 DATA 4 10 DATA 11 11 DATA 3 12 DATA 12 13 DATA 2 14 DATA 13 15 DATA 1 16 DATA 14 17 DATA 0 18 DATA 15 19 GROUND 20 NOT USED 21 Not Used 22 GROUND 23 -IOW A 24 GROUND 25 -IOR A 26 GROUND 27 -CHRDY A 28 DALE 29 Not Used 30 GROUND 31 -IRQ 14 32 -IO16 33 SA 1 34 NOT USED 35 SA 0 36 SA 2 37 CS 0 38 CS 1 39 HD LED A 40 GROUND 41 VCC 42 VCC 43 GROUND 44 Not Used

Table 3-2 CN3: Hard Disk (IDE) Connector

3-5

AR-B9622 User’s Guide

3.2.4 PS/2 Mouse Connector (J2)

To use the PS/2 mouse, an adapter cable has to be connected to the J2 (6-pin header type) connector. This adapter cable is mounted on a bracket and is included in your AR-B962 2 package. The connector for the PS/2 mouse is a Mini-DIN 6-pin connector. The pin assignments for the PS/2 port connector are as follows:

N.C. GND VCC

1 2 3 4

N.C.

Front View

Figure 3-7 J2: PS/2 Mouse Connector

DATA

CLOCK

3.2.5 FDD Port Connector (CN7)

The AR-B9622 provides a 34-pin header type connector for supporting up to two floppy disk drives.

34 33 32 30 28 26 24 22 20 18 16 14 12 10

31 29 27 25 23 21 19 17 15 13 11

8 6 4

-- GROUND

DISK CHANGE -- -- GROUND

-SIDE 1 SELECT --

-READ DATA --

-WRITE PROTECT --

-TRACK 0 --

-WRITE ENABLE --

-WRITE DATA --

-STEP OUTPUT PULSE -DIRECTION --

-MOTOR ENABLE 1 --

-DRIVE SELECT 0 --

-DRIVE SELECT 1 --

-MOTOR ENABLE 0 --

-INDEX --

DRVEN 1 --

NOT USED --

DRVEN 0

CN7 -- FDD Port Connector

Figure 3-8 CN7: FDD Port Connector

3.2.6 Reset Header (J3)

J3 is used to connect to an external reset switch. Shorting these two pins will reset the system.

1 Reset+ 2 Reset-

Figure 3-9 J3: Reset Header

3-6

AR-B9622 User’s Guide

3.2.7 Parallel Port Connector (CN8 & CN9)

To use the parallel port, an adapter cable has connected to the CN8 or CN9 (26-pin header type) connector. This adapter cable is mounted on a bracket and is included in your AR-B9 622 package. The connector for the parall el port is a 25 pin D-type female connector.

Parallel Port Connector

12 1

2625

Figure 3-10 CN8 & CN9: Parallel Port Connector

CN8&CN9 DB-25 Signal CN8&CN9 DB-25 Signal

1 1 -Strobe 2 14 -Au t o F o r m F ee d 3 2 Data 0 4 15 -Error 5 3 Data 1 6 16 -Initialize 7 4 Data 2 8 17 -Printer Select In

9 5 Data 3 10 18 Ground 11 6 Data 4 12 19 Ground 13 7 Data 5 14 20 Ground 15 8 Data 6 16 21 Ground 17 9 Data 7 18 22 Ground 19 10 -Acknowledge 20 23 Ground 21 11 Busy 22 24 Ground 23 12 Paper 24 25 Ground 25 13 Printer Select 26 -- No Used

Table 3-3 Parallel Port Pin Assignment

D-Type Connecto

DB-25

3.2.8 Power Connector (J7 & J8)

J7 is a 4-pin power connector and J8 is one 8-pin power connector. Using the J8, you can connect the power supply to the on board power connector for stand alone applications directly.

1 +5 VDC 2 Ground

4231

Figure 3-11 J7: 4-Pin Power Connector

3 Ground 4 +5 VDC

1 GND 2 +5 VDC

3 +5 VDC

5678

1234

4 GND 5 GND 6 +12 VDC 7 -12 VDC 8 -5 VDC

Figure 3-12 J8: 8-Pin Power Connector

3-7

AR-B9622 User’s Guide

3.2.9 Serial Port

(1) Full RS-232 Signal / Power Select for COM-A (P3)

P3 select the full RS-232 signal or power select for CN10--COM A, if user chooses the power supported then the COM A’s RTS will be instead of the +12VDC signal; and the CN10--COM A’s CT S will be instead of the +5VDC signal.

Power Supported by +5VDC

Figure 3-13 P3: Full RS-232 Signal / Power Select for COM-A

(2) RS-232/RS-485 Select for COM-D (JP6)

JP6 selects the on-board RS-232/RS-485 for CN10 – COM D.

JP6

132

A B C

RS-232

Factory Preset

Figure 3-14 JP6: RS-232/RS-485 Select for COM-D

(3) RS-485 Terminator Select (JP4)

(4) RS-232 and Digital I/O Signal Output Select for COM D (JP3)

JP4

OFF

Factory Preset

Figure 3-15 JP4: RS-485 Terminator Select

JP3

Full RS-232 Signals

(Factory Preset)

JP6

A B C

1 2 3

264

132

RS-485

112

1 2 3

RS-232 Signal

Factory Preset

Figure 3-16 JP3: RS-232 and Digital I/O Signal Output Select for COM-D

(5) Digital I/O Signal Output Header for COM D (J6)

1 DTR 2 DSR 3 Ground

Figure 3-17 J6: Digital I/O Signal Output Header for COM D

3-8

Digital I/O Signal

AR-B9622 User’s Guide

(6) RS-232C Connector (CN10)

There are four serial ports with EIA RS-232C interface on the AR-B9622. COM A, COM B and COM C use three on-board serial port Phone-Jack 10-pin female connector (CN10) which is located at the right top side of the card. To configure these four serial ports, use the BIOS Setup program to do well, and COM D can be adjust the jumpers on P1 & P2 for choice RS-485 or RS-232C. The pin assignments of the CN10 for serial port A, B, C & D are as follows:

COM A

5 1

COM B

COM C

COM D

Figure 3-18 CN10: RS-232C Connector

CN10-A DB-9 Signal CN10-A DB-9 Signal

1 1 -DCD 2 8 -CTS / +5V 3 7 -RTS / +5V 4 6 -DSR 5 2 RXD 6 3 TXD 7 4 -DTR 8 5 GND 9 5 GND 10 9 -RI

Table 3-4 Serial Port RS-232 COM A Pin Assignment

CN10-B CN10-C DB-9 Signal CN10-B CN10- C DB-9 Signal

1 1 1 -DCD 2 2 8 -CTS 3 3 7 -RTS 4 4 6 -DSR 5 5 2 RXD 6 6 3 TXD 7 7 4 -DTR 8 8 5 GND 9 9 5 GND 10 10 9 -RI

Table 3-5 Serial Port RS-232 COM B & C Pin Assignment

CN10-D DB-9 Signal CN10-D DB-9 Signal

1 1 -DCD 2 8 -CTS 3 7 -RTS / 485N+ 4 6 -DSR 5 2 RXD 6 3 TXD 7 4 -DTR / 485N- 8 5 GND 9 5 GND 10 9 -RI

Table 3-6 Serial Port RS-232/RS-485 COM D Pin Assignment

3-9

AR-B9622 User’s Guide

(7) COM-C RI Signal Output Select (JP5)

JP5

1 2 3

RI Signal via J9 output

Factory Preset

Figure 3-19 JP5: COM-C RI Signal Output Select

(8) TTL Header (J9)

1 RI3 2 TTLO 3 TTLI 4 GROUND

Figure 3-20 J9: TTL Header

3.2.10 Compact Flash Connector (CN2)

-CFCD1 --SD11 --SD12 --SD13 --SD14 --SD15 ---

-CFCS1 ---

-VS1 ---

-IOR ---

-IOW ---

-CFWE --IRQ15 ---

VCC ---

GND ---

Not Used ---

-CFRST ---

-IORDY ---

Not Used ---

-CFREG ---

-DASP ---

-PDIAG --SD8 --SD9 ---

SD10 ---

GND --- --- -CFCD2

Figure 3-21 CN2: Compact Flash Connector

26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 21 47

48 23 49 24 50 25

CN2

1 2 3

RI Signal via RS-23

TTL I/O

--- GND

--- SD3

--- SD4

--- SD5

--- SD6

--- SD7

--- -CFCS0

--- GND

--- VCC

--- GND

--- SA2

--- SA1

--- SA0

--- SD0

--- SD1

--- SD2

--- -IO16

3-10

AR-B9622 User’s Guide

3.2.11 RJ-45 Connector (CN4)

The CN4 connects RJ-45 header, it’s the standard network header. The following table is CN4 pin assignment.

Figure 3-22 CN4: RJ-45 Connector

PIN (CN4) FUNCTION

1 TPTX+ 2 TPTX 3 TPRX+ 4 Not Used 5 Not Used 6 TPRX 7 Not Used 8 Not Used

Table 3-7 RJ-45 Pin Assignment

3.2.12 CPU Base Clock Select (JP2)

The CPU base clock (Input clock) is twice of its operation clock.

Figure 3-23 JP2: CPU Base Clock Select

3.2.13 D.O.C. Installation (U7)

Step 1:

Step 2:

Step 3:

Insert programmed DiskOnChip into sockets U7 setting as DOC.

Line up and insert the AR-B9622 card into any free space of your computer.

Use the D.O.C. in no HDD equipment, and after installed D.O.C. we can easily boot the system from D.O.C..

3-11

AR-B9622 User’s Guide

4. CRT/LCD FLAT PANEL DISPLAY

This section describes the configuration and installation procedure when using the LCD and CRT displays.

 LCD Flat Panel Displays  Supported LCD Panels  CRT & LCD Displays

4.1 LCD FLAT PANEL DISPLAYS

Using the Flash Memory Writer utility to download the new BIOS file into the ROM chip to configure the BIOS default settings for different types of LCD panels. And then, set your system properly and configure the AR-B9622 VGA module for the right type of LCD panel you are using.

The samples of LCD models listed on the table are just some of the LCD panel models available in the market that the Chips & Technologies used by AR-B9622 VGA module can support. If you are using a different LCD panel other than those listed, choose from the panel description column which type of LCD panel you are usin g.

The following shows the block diagram of using AR-B9622 for LCD display.

AR-B9622

CPU Boad

VBL Control

VEE

LCD

Panel

+12V, +5V

Inverter

Board

Figure 4-1 LCD Panel Block Diagram

FL HIGH

Voltage

4-1

AR-B9622 User’s Guide

The block diagram shows that AR-B9622 still needs components to be used for LCD panel. The inverter board provides the control for the brightness and the contrast of the LCD panels while the inverter is the one that supplies the high voltage to drive the LCD panel. Each item will be explained further in the section.

CN5

Inverter & Contrast

AR-B9622

CPU Board

LCD

Panel

Pin 1

Figure 4-2 LCD Panel Cable Installation Diagram

NOTE: Be careful with the pin orientation when installing the connectors and the cables. A wrong connec tion ca n

easily destroy your LCD panel. The pin 1 of the cable connectors is indicated with a sticker and the pin1 of the ribbon cable is usually with different color.

http:\\www.acrosser.com

4-2

AR-B9622 User’s Guide

4.2 CRT & LCD DISPLAY

The AR-B9622 supports CRT color monitor, STN, Dual-Scan, TFT, monochrome and color panels. It can be connected to create a compact video solution for the industrial environment. 1MB of V-RAM on-boarded allows a maximum CRT resolution of 800X600 with 256 colors and a LCD resolution of 640X480 with 64K colors. For different VGA display modes, your monitor must possess certain characteristics to display the mode you want.

4.2.1 CRT Connector (CN6 & DB1)

CN6 is a 10-pin connector that attaches to the CRT monitor via a D-sub 15-pin adapter cable. The pin assignments for the CN6 & DB1 connectors are as follows:

CN6 (CRT Connector)

12 34 5 7 9

6 8 10

1 2 3 4 5

Figure 4-3 DB1 & CN6: CRT Connector

4.2.2 LCD Setting

(1) DE/E Signal from M or LP Select (JP1)

JP1

1 RED 2 & 10 GND 3 GREEN 4, 5, 6 & 8 AGND 7 VSYNC 9 HSYNC

DB1

1 Red 2 Green 3 Blue 13 Horizontial Sync 14 Vertical Sync 4, 9,11, 12 & 15 Not Used 5 & 10 Ground 6, 7 & 8 AGND

1 2 3

DE/M E/LP

(Factory Preset)

Figure 4-4 JP1: DE/E Signal from M or LP Select

4-3

AR-B9622 User’s Guide

(2) LCD Panel Display Connector (CN5)

Attach a display panel connector to this 44-pin connector with pin assignments shown below:

43 44

Figure 4-5 CN5: LCD Display Connector

Pin Signal Pin Signal

1 GND 2 SHFCLK 3 GND 4 LP 5 FLM 6 GND 7

9 11 13 15 17 19 21 23 25 27 29 31 33 35 VCC 36 VCC 37 +12V 38 +12V 39 GND 40 GND 41 DE 42 ENABLK 43 GND 44 Not Used

Table 4-8 LCD Display Assignment

P0(B0) 8 P1(B1) P2(B2) 10 P3(B3) P4(B4) 12 P5(B5)

GND 14 P6(B6) P7(B7) 16 P8(G0) P9(G1) 18 P10(G2)

P11(G3) 20 GND P12(G4) 22 P13(G5) P14(G6) 24 P15(G7) P16(R0) 26 P17(R1)

GND 28 P18(R2)

P19(R3) 30 P20(R4) P21(R5) 32 P22(R6) P23(R7) 34 GND

1 2

4-4

AR-B9622 User’s Guide

5. INSTALLATION

This chapter describes the procedure of the installation. The following topics are covered:

 Overview  Utility Diskette  Watchdog Timer

5.1 OVERVIEW

This chapter provides information for you to set up a working system based on the AR-B9622 CPU board. Carefully read the details of the CPU board’s hardware descriptions before installation, especially the jumper settings, switch settings and cable connections.

Follow the steps listed below for proper installation:

Step 1 :

Step 2 :

Step 3 :

Step 4 :

Step 5 :

Step 6 :

Step 7 :

Step 8:

Step 9:

Step 10:

Read the CPU board’s hardware description in this manual.

Set jumpers.

Make sure that the power supply connected to your passive CPU board is turned off.

Connect all necessary cables. Make sure that the FDC, HDC, serial and parallel cables are connected to pin 1 of the related connector.

Connect the hard disk/floppy disk flat cables from the CPU board to the drives. Connect a power source to each drive.

Plug the keyboard into the keyboard connector.

Turn on the power.

Configure your system with the BIOS Setup prog ram then re-bo ot y our system.

If the CPU board does not work, turn off the power and read the hardware description carefully again.

If the CPU board still does not perform properly, return the board to your dealer for immediate service.

5.2 UTILITY DISKETTE

AR-B9622 provides two VGA driver diskettes, supporting WIN31 & DOS applications. If your operating system is the other operating system, please contact Acrosser that will provide the technical supporting for the VGA resolution.

There are two diskettes: disk 1 is for WIN31 & MS-DOS VGA resolution, disk 2 is for the network utility and manual. Every diskette is attached with the README.* file. Please refer to the file of README for any troubleshooting before installing the driver.

5-1

AR-B9622 User’s Guide

5.2.1 VGA Driver

WIN 3.1 Driver

For the WIN31 operating system, user must in the DOS mode decompress the compress file. And then follow the steps:

Step 1:

Step 2: Step 3:

Step 4:

Step 5:

Step 6:

Step 7: Step 8:

In the DOS mode, execute the SETUP.EXE file. A:\>SETUP

The screen shows the chip type. Press any key to enter the main menu. There are some items for choice to setup. Please choose the <Windows Version 3.1> item notice

the function key defined. Press [ENTER] selected the <All Resolutions>, when this line appears [*] symbol, which means this item is selected. Pressing [End] starts to install.

The screen will show the dialog box, demanding the user to type the WIN31’s path. The default is C:\WINDOWS.

As the setup is completed, the system will generate the message as follows.

Installation is done!

Change to your Windows directory and type SETUP to run the Windows Setup program. Choose one of the new drivers marked by an *. Please refer to the User’s Guide to complete the installation.

Press the [Esc] key to return to the main menu, and re-press the [Esc] key to return to the DOS mode.

In the WIN31, you can find the <Chips CPL> icon located in the {CONTROL PANEL} group. Adjust the <Refresh Rate>, <Cursor Animation>, <Font size>, <Resolution>, and <Big Cursor>.

5.2.2 BIOS FLASH Utility

In the <UTILITY> directory, there is the AMIFLASH.COM file.

1. Use the AMIFLASH.COM program to update the BIOS setting.

2. And then refer to the section “BIOS Console”, as the steps to modify BIOS.

3. Now the CPU board’s BIOS is the ne west, user can use this program to modify BIOS function in the f uture, when the BIOS adds some functions.

5.2.3 Network Utility

1. Use the PKUNZIP.EXE program to decompress the file in the DOS mode. For Example

C:\>MD NET

C:\>CD NET C:\NET>COPY A:\PKUNZIP.EXE C:\NET C:\NET>COPY A:\UM9008.ZIP C:\NET

C:\NET>PKUNZIP -D UM9008.ZIP

2. And then enter the operating system as the installation processes. Please refer to the decompressed file. There is the README file in every sub-directory, and has detailed description for installing the drivers.

5-2

AR-B9622 User’s Guide

5.3 WATCHDOG TIMER

This section describes how to use the Watchdog Timer, disabled, enabled, and trigger. The AR-B9622 is equipped with a programmable time-out period watchdog timer. User can use the program to

enable the watchdog timer. Once you have enabled the watchd og timer, the program should trigger it every time before it times out. If your program fails to trigger or disable this timer before it times out because of system hangup, it will generate a reset signal to reset the system. The time-out period can be programmed to be 30.5μ

seconds to 512 seconds.

Software Program Enable and Trigger

Watchdog

Write and Trigger

Time Base

Counter

and

Compartor

RESET

Figure 5-1 Watchdog Block Diagram

5.3.1 Watchdog Timer Setting

The watchdog timer is a circuit that may be used from your program software to detect crashes or hang-ups. The watchdog timer is automatically disabled after reset.

Once you have enabled the watchdog timer, your program must trigger the watchdog timer every time before it times-out. After you trigger the watchdog timer, it will be set to zero and start to count again. If your pro gram fails to trigger the watchdog timer before time-out, it will generate a reset pulse to reset the system or trigger the IRQ15 signal to tell your program that the watchdog is times out.

Watchdog timer -INDEX 39H, 3AH, 3BH

3Bh 3Ah 39h

D7 　 0 D7 　 0 D7　 0

Counter [MSB …LSB]

For example

INDEX 3Bh 3Ah 39h 00h 00h 01h

-- -- 02h

00h 01h 00h 7.8 m sec 00h 02h 00h 15.6 m sec 01h 00h 00h 2 sec 02h 00h 00h 4 sec FFh FFh FFh 512 sec

If you want to generate IRQ15 signal to warn your program when watchdog times out, the following table listed the relation of timer factors between time-out period. And if you use the IRQ15 signal to warn your program when watchdog timer out, please enter the BIOS Setup the <Peripheral Setup> menu, the <OnBoard PCI IDE> and <IDE Prefetch> these two items must set to Primary.

NOTE: 1. If you program the watchdog to generate IRQ15 signal when it times out, you should initial IRQ15

interrupt vector and enable the second interrupt controller (8259 PIC) in order to enable CPU to process this interrupt. An interrupt service routine is required too.

2. Before you initial the interrupt vector of IRQ15 and enable the PIC, please enable the watchdog timer previously, otherwise the watchdog timer will generate an interrupt at the time watchdog timer is en abled .

30.5 μsec 61 μsec

5-3

AR-B9622 User’s Guide

5.3.2 Watchdog Enabled/Disabled - INDEX 37H

Bit 7 Reserved. Please do not set this bit.

In old version M6117C data sheet, this bit is counter read mode.

Bit 6 0 disable watchdog timer 1 enable watchdog timer

Bit 5-0 Other function.

Please do not modify these bits.

5.3.3 Select Watchdog Report Signal - INDEX 38H

Bit 7-4 watchdog timer time out report signal select 0000 no output signal 0001 IRQ3 selected 0010 IRQ4 selected 0011 IRQ5 selected 0100 IRQ6 selected 0101 IRQ7 selected 0110 IRQ9 selected 0111 IRQ10 selected 1000 IRQ11 selected 1001 IRQ12 selected 1010 IRQ14 selected 1011 IRQ15 selected 1100 NMI selected 1101 system reset selected 1110 no output signal 1111 no output signal

Bit 3-0 Other function.

Please do not modify these bits.

5.3.4 Timeout Status & Reset Watchdog - INDEX 3CH

Bit 7 0 timer timeout not happened 1 timer timeout happened Read only.

Bit 5 Write this bit “1” to reset timer

The value on this bit has no meaning.

Bit 6 Bit 4-0

Other function. Please do not modify these bits.

5.3.5 Programming Watchdog - Basic Operation

If we would like to access M6117C configuration register, we need to unlock register at first and lock it after finishing operation.

(1) Unlock Configuration Register

mov al, 013h out 22h, al nop nop mov al, 0c5h out 23h, al nop nop

5-4

AR-B9622 User’s Guide

(2) Lock Configuration Register

mov al, 013h out 22h, al nop nop mov al, 000h out 23h, al nop nop

(3) Read the Value at Configuration Register

For example, read INDEX 3Ch: Unlock configuration register

mov al, 03ch out 22h, al nop nop in al, 23h nop nop

push ax

Lock configuration register

pop ax ; AL - result

(4) Write Data to Configuration Register

For example, write 0FFh to INDEX 3Bh: Unlock configuration register

mov al, 03bh out 22h, al nop nop mov al, 0ffh out 23h, al nop nop

Lock configuration register

(5) if the function of WATCHDOG is applied,please follow the following instruction to write the command at the first

line of the config.sys file.

DEVICE=C:\INIT9008.SYS In order to avoide LAN error.

5-5

AR-B9622 User’s Guide

6. BIOS CONSOLE

This chapter describes the AR-B9622 BIOS menu displays and explains how to perform common tasks needed t o get up and running, and presents detailed explanations of the elements found in eac h of the BIOS menus. The following topics are covered:

 BIOS Setup Overview  Standard CMOS Setup  Advanced CMOS Setup  Advanced Chipset Setup  Peripheral Setup  Auto-Detect Hard Disks  Password Setting  Load Default Setting  BIOS Exit

6.1 BIOS SETUP OVERVIEW

BIOS is a program used to initialize and set up the I/O system of the computer, which includes the ISA bus and connected devices such as the video display, diskette drive, and the keyboard. The BIOS provides a menu-based interface to the console subsystem. The co nsole subsystem contains special software, called firmware that interacts directly with the hardware components and facilitates interaction between the system hardware and the operating system. The BIOS Default Values ensure that the system will function at its normal capability. In the worst situation the user may have corrupted the original settings set by the manufacturer. After the computer turned on, the BIOS will perform a diagnostics of the system and display the size of the memory that is being tested. Press the [Del] key to enter the BIOS Setup program, and then the mai n menu will show on the screen. The BIOS Setup main menu includes some options. Use the [Up/Down] arrow key to highlight the option that yo u wish to modify, and then press the [Enter] key to assure the option and configure the functions.

AMIBIOS HIFLEX SETUP UTILITY - VERSION 1.16

Standard CMOS Setup

Advanced CMOS Setup

Advanced Chipset Setup

Peripheral Setup Auto-Detect Hard Disks Change User Password

Change Supervisor Password

Auto Configuration with Optimal Settings

Auto Configuration with Fail Safe Settings

Save Settings and Exit

Exit Without Saving

Standard CMOS setup for changing time, date, hard disk type, etc.

ESC:Exit ↑↓:Sel F2/F3:Color F10:Save & Exit

Figure 6-1 BIOS: Setup Main Menu

CAUTION: 1. AR-B9622 BIOS the factory-default setting is used to the <Auto Configuration with Optimal Settings>

Acrosser recommends using the BIOS default setting, unless you are very familiar with the setting function, or you can contact the technical support engineer.

2. If the BIOS loss setting, the CMOS will detect the <Auto Configuration with Fail Safe Settings> to boot the operation system, this option will reduce the performance of the system. Acrosser recommends choosing the <Auto Configuration with Optimal Setting> in the main menu. The option is best-case values that should optimize system performance.

3. The BIOS settings are described in detail in this section.

6-1

AR-B9622 User’s Guide

6.2 STANDARD CMOS SETUP

The <Standard CMOS Setup> option allows you to record some basic s ystem hardware configuration and set the system clock and error handling. If the CPU board is already installed in a working system, you will not need t o select this option anymore.

AMIBIOS SETUP - STANDARD CMOS SETUP

Date (mm/dd/yyyy): Sun Dec 06,1998 640KB Time (hh/mm/ss): 13:39:30 0MB

Floppy Drive A: Not Installed Floppy Drive B: Not Installed LBA Blk 32Bit PIO

Pri Master : Auto On On Off Auto Pri Slave : Auto On On Off Auto Sec Master : Auto On On Off Auto Sec Slave : Auto On On Off Auto

Boot Sector Virus Protection Disabled

Month: Jan - Dec ESC:Exit ↑↓:Sel Day: 01 - 31 PgUp/PgDn:Modify

Year: 1901 - 2099 F2/F3:Color

Date & Time Setup

Highlight the <Date> field and then press the [Page Up] /[Page Down] or [+]/[-] keys to set the current date. Follow the month, day and year format. Highlight the <Time> field and then press the [Page Up] /[Page Down] or [+]/[-] keys to set the current date. Follow the hour, minute and second format. The user can bypass the date and time prompts by creating an AUT OEXEC.BAT file. For information on how to create this file, please refer to the MS-DOS manual.

Floppy Setup

The <Standard CMOS Setup> option records the types of floppy disk drives installed in the system. To enter the configuration value for a particular drive, highlight its corresponding field and then select the drive t ype using the left-or right-arrow key.

Hard Disk Setup

The BIOS supports various types for user settings, The BIOS supports <Pri Master>, <Pri Slave>, <Sec Master> and <Sec Slave> so the user can install up to two hard disks. F or the master and slave jumpers, please refer to the hard disk’s installation descriptions and the hard disk jumper settings. You can select <AUTO> under the <TYPE> and <MODE> fields. This will enable auto detection of your IDE drives during bootup. This will allow you to change your hard drives (with the power off) and then power on without having to reconfigure your hard drive type. If you use older hard disk drives which do not support this feature, the n you must configure the hard disk drive in the standard method as described above by the <USER> option.

Boot Sector Virus Protection

This option protects the boot sector and partition table of your hard dis k against accidental modifications. Any attempt to write to them will cause the system to halt and display a warning message. If this occurs, you can either allow the operation to continue or use a bootable virus-free floppy disk to reboot and inv estigate your system. The default setting is <Disabled>. This setting is recommended because it conflicts with new operating systems. Installation of new operating system requires that you disable this to prevent write errors.

Type Size Cyln Head Wpcom Sec Mode Mode Mode Mode

Figure 6-2 BIOS: Standard CMOS Setup

6-2

AR-B9622 User’s Guide

6.3 ADVANCED CMOS SETUP

The <Advanced CMOS SETUP> option consists of configuration entries that allo w you to improve your system performance, or let you set up some system features according to your preference. Some entries here are required by the CPU board’s design to remain in their default settings.

AMIBIOS SETUP – ADVANCED CMOS SETUP

1st Boot Device IDE-0 2nd Boot Device Floppy 3rd Boot Device IDE-1 4th Boot Device Disabled Boot From Card BIOS Yes Try Other Boot Devices Yes BootUp Num-Lock On Floppy Drive Swap Disabled Floppy Drive Seek Disabled Floppy Access Control Normal HDD Access Control Normal PS/2 Mouse Support Disabled System Keyboard Present Primary Display VGA/EGA Password Check Setup Wait For Enabled Hit

Enabled C000, 32k Shadow Enabled C800, 32k Shadow Disabled D000, 32k Shadow Disabled D800, 32k Shadow Disabled E000, 32k Shadow Disabled E800, 32k Shadow Disabled

｀F1＇ If Error

｀DEL＇ Message Display

Available Options :

Disabled IDE-0 IDE-1 IDE-2 IDE-3 Floppy ARMD-FDD ARMD-HDD CDROM SCSI NETWORK

ESC:Exit ↑↓:Sel PgUp/PgDn:Modify

F2/F3:Color

Figure 6-3 BIOS: Advanced CMOS Setup

1st Boot Device 2nd Boot Device 3rd Boot Device 4th Boot Device

These options determine where the system looks first for an operating system. The default setting is to check first the hard disk and then the floppy drive, and last the CDROM.

BootUp Num-Lock

This item is used to activate the Num Lock function upon system boot. If the setting is on, after a boot, the Num Lock light is lit, and user can use the number key.

Floppy Drive Swap

The option reverses the drive letter assignments of your floppy d isk drives in the Swap A, B setting, otherwise leave on the default setting of Disabled (No Swap). This works separately from the BIOS Features floppy disk swap feature. It is functionally the same as physically interchanging the conn ectors of the flop p y disk drives. Whe n the function’s setting is <Enabled>, the BIOS swapped floppy drive assign ments so that Drive A becomes Drive B, and Drive B becomes Drive A under DOS.

Floppy Drive Seek

If the <Floppy Drive Seek> item is setting Enabled, the BIOS will seek the floppy <A> drive one time upon bootup.

PS/2 Mouse Support

The setting of Enabled allows the system to detect a PS/2 mouse on bootup. If detected, IRQ12 will be used for the PS/2 mouse. IRQ 12 will be reserved for expansion cards if a PS/2 mouse is not detected. Disabled will reserve IRQ12 for expansion cards and therefore the PS/2 mouse will not function.

6-3

AR-B9622 User’s Guide

System Keyboard

This function specifies that a keyboard is attached to the computer.

Primary Display

The option is used to set the type of video display card installed in the system.

Password Check

This option enables password checking every time the computer is powered on or every time the BIOS Setup is executed. If Always is chosen, a user password prompt appears every time the computer is turned on. If Setup is chosen, the password prompt appears if the BIOS executed.

Wait for ‘F1’ If Error

AMIBIOS POST error messages are followed by:

Press <F1> to continue

If this option is set to Disabled, the AMIBIOS does not wait for you to press the <F1> key after an error message.

Hit ‘DEL’ Message Display

Set this option to Disabled to prevent the message as follows:

Hit ‘DEL’ if you want to run setup

It will prevent the message from appearing on the first BIOS screen when the computer boots.

Shadow

These options control the location of the contents of the 32KB of ROM beginning at the specified memor y location. If no adapter ROM is using the named ROM area, this area is made available to the local bus. The settings are:

SETTING DESCRIPTION

Disabled

Enabled

Cached

Table 6-1 Shadow Setting

The video ROM is not copied to RAM. The contents of the video ROM cannot be read from or written to cache memory. The contents of C000h - C7FFFh are written to the same address in system memory (RAM) for faster execution. The contents of the named ROM area are written to the same address in system memory (RAM) for faster execution, if an adapter ROM will be using the named ROM area. Also, the contents of the RAM area can be read from and written to cache memory.

6-4

AR-B9622 User’s Guide

6.4 ADVANCED CHIPSET SETUP

This option controls the configuration of the board’s chips et. Control keys for this screen are the same as for the previous screen.

AMIBIOS SETUP - ADVANCED CHIPSET SETUP

AT Bus Clock 14.318 / 2 Slow Refresh 60 us RAS Precharge time 1.5T RAS Active Time Insert Wait Disable CAS Precharge Time Insert Wait Disable Memory Write Insert Wait Disable Memory Miss Read Insert Wait Disable ISA I/O High Speed Enable ISA Memory High Speed Enable ISA Write cycle end Insert Wait Disable I/O Recovery Disable I/O Recovery Period 0.75 us On-Chip I/O Recovery Disable 16Bit ISA Insert Wait Disable

******* Watch Dog Timer ********* WatchDog Timer Disabled

WDT Timeout Period Select 42 Sec WatchDog Timeout Issue Signal Reset

Available Options :

14. 318/2

PLCK2/3 PLCK2/4 PLCK2/5 PLCK2/6 PLCK2/8 PLCK2/10

PLCK2/12

ESC:Exit ↑↓:Sel PgUp/PgDn:Modify

F2/F3:Color

Figure 6-4 BIOS: Advanced Chipset Setup

AT Bus Clock

This option sets the polling clock speed of ISA Bus (PC/104).

NOTE:

1. PCLK means the CPU inputs clock.

2. Acrosser recommends user setting at the range of 8MHz to 10MHz.

Slow Refresh

This option sets the DRAM refresh cycle time.

RAS Precharge Time

The DRAM RAS precharge time.

Time Insert Wait

The DRAM time insert wait: RAS Active and CAS Precharge function setting.

ISA High Speed

The Speed field shows the speed at which the processor runs internally.

I/O Recovery

If I/O Recovery Feature options is enabled, the BIOS inserts a delay time between two I/O commands. The delay time is defined in I/O Recovery Period option.

6-5

AR-B9622 User’s Guide

6.5 PERIPHERAL SETUP

This section is used to configure peripheral features.

AMIBIOS SETUP - PERIPHERAL SETUP

Hard disk Delay Disable OnBoard IDE Disable OnBoard Primary IDE Primary OnBoard Secondary IDE Secondary OnBoard FDC Auto OnBoard Serial Port1 3F8h OnBoard Serial Port1 IRQ 4 OnBoard Serial Port2 2F8h OnBoard Serial Port2 IRQ 3 OnBoard Serial Port3 3E8h OnBoard Serial Port3 IRQ 11 OnBoard Serial Port4 2E8h OnBoard Serial Port4 IRQ 9 OnBoard Parallel Port 3BCh Parallel Port Mode Normal EPP Version N/A Parallel Port IRQ 7 Parallel Port DMA Channel N/A OnBoard Parallel Port2 278h Parallel Port Mode Normal EPP Version N/A Parallel Port IRQ 5 Parallel Port DMA Channel N/A

Available Options :

3 Sec 5 Sec 10 Sec 15 Sec

ESC:Exit ↑↓:Sel PgUp/PgDn:Modify

F2/F3:Color

Figure 6-5 BIOS: Peripheral Setup

Hard Disk Delay

If this option is set to Disabled and the system BIOS executes too fast, the result is the BIOS can’t find the hard disk drive.

OnBoard IDE

This option specifies the onboard IDE controller channels that will be used.

OnBoard FDC

This option enables the floppy drive controller on the AR-B9622.

OnBoard Serial Port

This option enables the serial port on the AR-B9622.

OnBoard Parallel Port

This option enables the parallel port on the AR-B9622.

Parallel Port Mode

This option specifies the parallel port mode. ECP and EPP are both bidirectional data transfer schemes that adhere to the IEEE P1284 specifications.

Parallel Port DMA Channel

This option is only available if the setting for the parallel Port Mode option is ECP.

6-6

AR-B9622 User’s Guide

6.6 AUTO-DETECT HARD DISKS

This option detects the parameters of an IDE hard disk drive, and automatically enters them into the Standar d CMOS Setup screen.

6.7 PASSWORD SETTING

This BIOS Setup has an optional password feature. The system can be configured so that all users must enter a password every time the system boots or when BIOS Setup is executed. User can set either a Supervisor password or a User password.

6.7.1 Setting Password

Select the appropriate password icon (Supervisor or User) from the Security section of the BIOS Setup main menu. Enter the password and press [Enter]. The screen does not display the characters entered. After the new password is entered, retype the new password as prompted and press [Enter].

If the password confirmation is incorrect, an error message appears. If the new password is entered without error, press [Esc] to return to the BIOS Main Menu. The password is stored in CMOS RAM after BIOS completes. The next time the system boots, you are prompted for the password function is present and is enabled.

Enter new supervisor password:

6.7.2 Password Checking

The password check option is enabled in Advanced Setup by choosing either Always (the password prompt appears every time the system is powered on) or Setup (the password prompt appear s only when BIOS is run). The password is stored in CMOS RAM. User can enter a password by typing on the keyboard. As user selec t Supervisor or User. The BIOS prompts for a password, user must set the Supervisor password before user can set the User password. Enter 1-6 character as password. The password does not appear on the s creen when typed. Make sure you write it down.

6.8 LOAD DEFAULT SETTING

In this section permit user to select a group of setting for all BIOS Setup options. Not only can you use these items to quickly set system configuration parameters, you can choose a gr oup of settings that have a better chance of working when the system is having configuration related problems.

6.8.1 Auto Configuration with Optimal Setting

User can load the optimal default settings for the BIOS. The Optimal default settings are best-case values that should optimize system performance. If CMOS RAM is corrupted, the optimal settings are loaded automatically.

Load high performance settings (Y /N) ?

6.8.2 Auto Configuration with Fail Safe Setting

User can load the Fail-Safe BIOS Setup option settings by selecting the Fail-Safe item from the Default section of the BIOS Setup main menu. The Fail-Safe settings provide far from optimal system performance, but are the most stable settings. Use this option as a diagnostic aid if the system is behaving erratically.

Load failsafe settings (Y/N) ?

6-7

AR-B9622 User’s Guide

6.9 BIOS EXIT

This section is used to exit the BIOS main menu in two types situation. After making your changes, you can either save them or exit the BIOS menu and without saving the new values.

6.9.1 Save Settings and Exit

This item set in the <Standard CMOS Setup>, <Advanced CMOS Setup>, <Advanced Chipset Setup> and the new password (if it has been changed) will be stored in the CM OS. The CMOS checksum is calculated and written into the CMOS.

As you select this function, the following message will appear at the center of the screen to assist you to save data to CMOS and Exit the Setup.

Save current settings and exit (Y/N) ?

6.9.2 Exit Without Saving

When you select this option, the following message will appear at the center of the screen to help to Abandon a ll Data and Exit Setup.

Quit without saving (Y/N) ?

6.10 BIOS UPDATE

The BIOS program instructions are contained within computer chips called F LASH ROMs that are located on your system board. The chips can be electronically reprogrammed, allowing you to upgrade your BIOS firmware without removing and installing chips.

The AR-B9622 provides FLASH BIOS update function for you to easily upgrade newer BIOS version. Please follow the operating steps for updating new BIOS:

Step 1:

Step 2:

Step 3:

Step 4:

Step 5:

Step 6:

Step 7:

Turn on your system and don＇t detect the CONFIG.SYS and AUTOEXEC.BAT files. Keep your system in the real mode.

Insert the FLASH BIOS diskette into the floppy disk drive.

In the MS-DOS mode, you can type the AMIFLASH program.

A:\>AMIFLASH

The screen will show the message as follow:

Enter the BIOS File name from which Flash EPROM will be programmed. The File name must and with a <ENTER> or press <ESC> to exit.

And then please enter the file name to the box of <Enter File Name>. And the b ox of <Message> will show the notice as follow. In the bottom of this window always show the gray statement.

Flash EPROM Programming is going to start. System will not be usable until Programming of Flash EPROM is successfully complete. In case of any error, existing Flash EPROM must be replaced by new program Flash EPROM.

As the gray statement, press the <Y> key to updating the new BIOS. And then the <Message> box will show the <Programming Flash EPROM>, and the gray statement shows <Please Wait>.

The BIOS update is successful, the message will show <Flash Update Completed - Pass>.

6-8

AR-B9622 User’s Guide

NOTE: 1. After turn on the computer and the system didn’t detect the boot procedure, please press t he [F5] key

immediately. The system will pass the CONFIG.SYS and AUTOEXEC.BAT files.

2. The BIOS Flash disk is not the standard accessory. Now the onboard BIOS is the newest BIOS, if user needs adding some functions in the future please contact technical supporting engineers, they will provide the newest BIOS for updating.

3. The file of AMIFLASH.EXE had to use the attached diskette＇s file, if not user had to use the Version

6.31.

6-9

7. SPECIFICATIONS

CPU & Chipset: Bus Interface: DRAM: CRT/LCD Display: HDC: FDC: Serial Port: Parallel Port: Keyboard: Real Time Clock: BIOS: Watchdog: Solid State Disk:

Ethernet: LED Indicator: Power Connector: Power Req.: PC Board: Dimensions:

ALI M6117, 33/40 MHz under 5V power supply PC/104 bus 4MB on-board and 4 MB with socket for expansion 1 MB VRAM Supports two IDE type hard disk drives Supports two 5.25” or 3.5” floppy disk drives 4 full RS-232C port with phone-jack connector 2 bi-directional centronics type parallel port PC/AT compatible keyboard with 6-pin mini-din connector BQ3287MT or compatible chips Legal AMI Flashed system BIOS Programmable watchdog timer 1 socket for 2MB to 72MB DiskOnChip

1 connector for 2MB to 32MB ATA Compact Flash NE2000 compatible, RJ-45 edge connector

Power LED, LAN LED, and HDD LED One 4-pin and one 8-pin (2.5mm) power connector +5V, 1.5A maximum 6 layers 145 mmX142mm (5.71”X5.59”)

AR-B9622 User’s Guide

7-1

8. PLACEMENT & DIMENSIONS

8.1 PLACEMENT

AR-B9622 User’s Guide

8-1

AR-B9622 User’s Guide

8.2 DIMENSIONS

2200

1350

140

400

2900

350

150

350 220

150

840

140

1290

2090

−∅138

5590

3675

250

1600

500

4710150

5000

230

Unit: mil (1 inch = 25.4 mm = 1000 mil)

8-2

AR-B9622 User’s Guide

9. PROGRAMMING RS-485 & INDEX

9.1 PROGRAMMING RS-485

The majority communicative operation of the RS-485 is in the same of the RS-232. When the RS-485 proceeds the transmission which needs control the TXC signal, and the installing steps are as follows:

Step 1:

Step 2:

Step 3:

Step 4:

NOTE: Please refer to the section of the “Serial Port” in the chapter “System Control” for the detail description of

(1) Initialize COM port

Step 1:

Step 2:

NOTE:

(2) Send out one character (Transmit)

Step 1:

Step 2:

Step 3:

Step 4:

(3) Send out one block data (Transmit – the data more than two characters)

Step 1:

Step 2:

Step 3:

Step 4:

(4) Receive data

The RS-485’s operation of receiving data is in the same of the RS-232’s.

Enable TXC

Send out data

Waiting for data empty

Disable TXC

the COM port’s register.

Initialize COM port in the receiver interrupt mode, and communication protocol buses of the RS-485 are in the same.)

Disable TXC (transmitter control), the bit 0 of the address of offset+4 just sets “0”.

Control the AR-B9622 CPU card’s DTR signal to the RS-485＇s TXC communication.

Enable TXC signal, and the bit 0 of the address of offset+4 just sets “1”.

Send out the data. (Write this character to the offset+0 of the current COM port address)

Wait for the buffer’s data empty. Check transmitter holding register (THRE, bit 5 of the address of offset+5), and transmitter shift register (TSRE, bit 6 of the address of offset+5) are all sets must be “0”.

Disabled TXC signal, and the bit 0 of the address of offset+4 sets “0”

Enable TXC signal, and the bit 0 of the address of offset+4 just sets “1”.

Send out the data. (Write all data to the offset+0 of the current COM port address)

Disabled TXC signal, and the bit 0 of the address of offset+4 sets “0”

or transmitter interrupt mode. (All of the

9-1

AR-B9622 User’s Guide

(5) Basic Language Example

a.) Initial 86C450 UART

10 OPEN “COM1:9600,m,8,1”AS #1 LEN=1 20 REM Reset DTR 30 OUT &H3FC, (INP(%H3FC) AND &HFA) 40 RETURN

b.) Send out one character to COM1

10 REM Enable transmitter by setting DTR ON 20 OUT &H3FC, (INP(&H3FC) OR &H01) 30 REM Send out one character 40 PRINT #1, OUTCHR$ 50 REM Check transmitter holding register and shift register 60 IF ((INP(&H3FD) AND &H60) >0) THEN 60 70 REM Disable transmitter by resetting DTR 80 OUT &H3FC, (INP(&H3FC) AND &HEF) 90 RETURN

c.) Receive one character from COM1

10 REM Check COM1: receiver buffer 20 IF LOF(1)<256 THEN 70 30 REM Receiver buffer is empty 40 INPSTR$” 50 RETURN 60 REM Read one character from COM1: buffer 70 INPSTR$=INPUT$(1,#1) 80 RETURN

9-2

9.2 INDEX

AR-B9622 User’s Guide

Name Function Page

CN1 6-Pin Mini Din Keyboard connector 3-2 CN2 Compact Flash Socket 3-10 CN3 Hard disk (IDE) connectors 3-5 CN4 RJ-45 connector 3-11 CN5 LCD panel display connector 4-4 CN6 Analog monitor (CRT) connector 4-3 CN7 Floppy disk connector 3-6 CN8 Parallel port connector 3-7

CN9 Parallel port connector 3-7 CN10 RS-232 connector 3-9 CN11 64 pin PC/104 connector bus A & B 3-3 CN12 40 pin PC/104 connector bus C & D 3-3

DB1 CRT connector 4-3

J1 AUX. keyboar d header 3-2 J2 PS/2 mouse connector 3-6 J3 Reset header 3-6 J6 Digital I/O signal output header for COM-D 3-8 J7 4 pin power connector 3-7 J8 8 pin power connector 3-7 J9 TTL header 3-10

U7 DiskOnChip socket LED 1 Power LED LED 2 Compact Flash card detected

LM1 Red light presents HDD LED

Green light presents LAN LED

Yellow light presents Power LED JP1 DE/E signal from M or LP select 4-3 JP2 CPU base clock select 3-11 JP3 RS-232 and digital I/O signal output select for

COM-D JP4 RS-485 terminator select 3-8 JP5 COM-C RI signal output select 3-10 JP6 RS-232/RS-485 select for COM D 3-8

P3 Full RS-232 Signal / Power Select for COM-A 3-8

3-8

9-3

Acrosser AR-B9622 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

0.1 COPYRIGHT NOTICE AND DISCLAIMER

0.2 WELCOME TO THE AR-B9622 CPU BOARD

0.3 BEFORE YOU USE THIS GUIDE

0.4 RETURNING YOUR BOARD FOR SERVICE

0.5 TECHNICAL SUPPORT AND USER COMMENTS

0.6 ORGANIZATION

0.7 STATIC ELECTRICITY PRECAUTIONS

1. OVERVIEW

1.1 INTRODUCTION

1.2 PACKING LIST

1.3 FEATURES

2. SYSTEM CONTROLLER

2.1 MICROPROCESSOR

2.2 DMA CONTROLLER

2.3 KEYBOARD CONTROLLER

2.4 INTERRUPT CONTROLLER

2.4.1 I/O Port Address Map

2.4.2 Real-Time Clock and Non-Volatile RAM

2.4.3 Timer

2.5 SERIAL PORT

(1) Receiver Buffer Register (RBR)

(2) Transmitter Holding Register (THR)

(3) Interrupt Enable Register (IER)

(4) Interrupt Identification Register (IIR)

(5) Line Control Register (LCR)

(6) MODEM Control Register (MCR)

(7) Line Status Register (LSR)

(8) MODEM Status Register (MSR)

(9) Divisor Latch (LS, MS)

2.6 PARALLEL PORT

(1) Register Address

(2) Printer Interface Logic

(3) Data Swapper

(4) Printer Status Buffer

(5) Printer Control Latch & Printer Control Swapper

3. SETTING UP THE SYSTEM

3.1 OVERVIEW

3.2 SYSTEM SETTINGS

3.2.1 Keyboard Connector

(1) 6-Pin Mini DIN Keyboard Connector (CN1)

(2) AUX. Keyboard Connector (J1)

3.2.2 PC/104 Connector

(1) 64 Pin PC/104 Connector Bus A & B (CN11)

(2) 40 Pin PC/104 Connector Bus C & D (CN12)

(3) PC/104 ISA Signal Description

3.2.3 Hard Disk (IDE) Connector (CN3)

3.2.4 PS/2 Mouse Connector (J2)

3.2.5 FDD Port Connector (CN7)

3.2.6 Reset Header (J3)

3.2.7 Parallel Port Connector (CN8 & CN9)

3.2.8 Power Connector (J7 & J8)

3.2.9 Serial Port

(1) Full RS-232 Signal / Power Select for COM-A (P3)

(2) RS-232/RS-485 Select for COM-D (JP6)

(3) RS-485 Terminator Select (JP4)

(4) RS-232 and Digital I/O Signal Output Select for COM D (JP3)

(5) Digital I/O Signal Output Header for COM D (J6)

(6) RS-232C Connector (CN10)

(7) COM-C RI Signal Output Select (JP5)

(8) TTL Header (J9)

3.2.10 Compact Flash Connector (CN2)

3.2.11 RJ-45 Connector (CN4)

3.2.12 CPU Base Clock Select (JP2)

3.2.13 D.O.C. Installation (U7)

4. CRT/LCD FLAT PANEL DISPLAY

4.1 LCD FLAT PANEL DISPLAYS

4.2 CRT & LCD DISPLAY

4.2.1 CRT Connector (CN6 & DB1)

4.2.2 LCD Setting

(1) DE/E Signal from M or LP Select (JP1)

(2) LCD Panel Display Connector (CN5)

5. INSTALLATION

5.1 OVERVIEW

5.2 UTILITY DISKETTE

5.2.1 VGA Driver

WIN 3.1 Driver
