CHAPTER 1 INTRODUCTION
This chapter contains general information and detailed specifications of the FPC 5084. Chapter 1 includes the following sections:
General Description
Specification
Dimensions
I/O Outlets
Package List
1.1 General Description
The FPC 5084 is a fan-less and compact-size touch panel computer , equipped with a 8.4" TFT LCD display and low power consumption Intel® Atom™ N270 1.6GHz processor with FSB 533MHz. The FPC 5084 supports Window ® XP, Windows® CE.NET and Windows ® XP embedded. The panel computer is able to install a CompactFlash™ card and provide a Mini card socket for wireless mod­ule. Its excellent ID and friendly user interface make it a professional yet easy-to-use panel computer . The FPC 5084 is an ideal for space-limited applications in factory automation, machine maker operating systems, building automation, and more.
FPC 5084: 8.4" TFT SVGA Fanless Touch Panel Computer Reliable and Stable Design The FPC 5084 adopts a fanless cooling system and a CompactFlash™ card, which makes it
suitable for vibration environments.
Embedded O.S. Supported
The FPC 5084 not only supports Windows ® XP, but also supports embedded OS, such as Windows ® CE.NET, and Windows ® XP embedded. For storage device, the FPC 5084 830 sup­ports CompactFlash™ card.
