User Manual
APM5170: 17” industrial panel mount LCD monitor
APM 5170
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All righ ts reserved. Product descripti on and product speci ficat ions
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
APM 5170
L eg al Inf orm a tion
F irst English printing , O ctobe r 2 0 02
Inform a tio n in this d oc ument has been carefully che cked for a c cura cy; h o weve r, n o g u aran te e is gi ven to the correc t ne ss
of the con te nt s . T he i n fo rmation i n th is do c um ent is su b ject to ch an g e with o ut n otice. W e a re not li ab le for a ny injury o r
lo s s that re sults from the use of this equ ipm ent.
Sa fet y I nstru cti on s
Pl ease read a ll of th ese in struc tio ns care full y before yo u us e th e de vice. Save this m a nua l for futu re r e ferenc e.
¦ Unp lug equipm ent before clea nin g. D on’t u se liqu id o r s p ray d ete rgent; u se a mois t cloth .
¦ Ke ep equipm ent a w ay from e xce ssive hum idity a nd h e at . P re fera bl y, kee p i t in an air -c o nd ition ed envir on m e nt with
temperat ures n ot exceed ing 40º C e lsi us (104º F ah ren he it).
¦ When ins ta lling, place th e eq uipm e nt o n a s tu rd y, level su rface to p revent it from a ccidenta lly fa lling an d causi n g d a m
age to oth er e q u ipm e nt or inj ur y to p erso n s n ea rb y.
¦ When the equip ment is in an open position, d o no t cove r, b lo ck o r in a ny wa y o bstruct th e g ap b e tw een it a n d th e
powe r s u p pl y. Proper a ir co n vection is nece ssary to k ee p it f rom ove rhea ting.
¦ Arra ng e th e e qu i pm ent ’s po w er cord in su c h a wa y t ha t ot he rs w on’t trip or fall o ver it.
¦ If you a re u sing a p o wer cord th at d id n ’t sh ip w i th th e e qu ipm e n t, en sure t h at i t is rated fo r th e vo ltage and cur rent
la be le d o n th e eq u i pm e n t ’s ele c tric al rating s label. The v o ltage ra ting on t he cord s ho u ld be high e r tha n th e on e list ed
on the equ ipment ’s rat ings l ab e l.
¦ Ob s erv e all preca ution s and w a rnin gs at ta ched to t he e q uipm en t.
¦ If you d o n’t intend on u sing t he equip m e nt fo r a long tim e , d i scon n ect it from th e power ou tl et t o p reven t be i ng d a m
aged by tr ansien t ov e r -v oltage.
¦ Ke ep all li q uids a way fr om th e e q uipment to m inim i ze the risk of a ccide nta l spillag e. Liqu id spilled on to the pow e r
su p pl y or o n o the r hard ware m a y cause d am a g e, fire or e lectric a l sh o ck.
¦ On l y qualif ied servi ce person ne l sh ou l d op e n th e c ha ssis. O pen ing it you rsel f could da m age the equipm ent and inv a li
date its w arra n t y.
¦ If any p a rt of th e eq u ipm e nt b ecomes damaged or st op s functi o ning, have it c hecke d by q u alified servic e pe rso nn e l.
W ha t the w arran ty d oe s not co v er
¦ An y p rod u ct, on which t he s e ri al numbe r h a s b ee n d ef ac e d , m o d if ied or rem ove d.
¦ Dam a g e, d ete rioration or m a lfuncti on resu lting fro m :
? Acc ident, m isu s e, n eg lect, fire, wa te r, lightning, or o th e r acts o f na tu re, unauthorized pro d uct m o difica tion, or
failure t o follow ins tru c tions s up p lie d with t he pro du ct.
? Re p ai r o r a tte m p te d repair by anyo ne n o t a uthorize d b y us.
? A n y dama g e o f th e product d ue to shipm en t.
? Re m o v al or ins tallation of the pro du ct.
? Ca us e s ext ernal to the prod uct , such a s e lectric p o we r fluctu a tion or f ailure .
? Use o f supplies or pa rts no t m eetin g ou r sp e c ifica tions.
? No rmal wear an d te a r.
? A n y other c a u ses which do e s not re la te t o a product d ef ec t .
¦ Rem o val, i nstalla tion, and s et -up service charge s.
Re gulato ry Notices Fe deral Co mm un ic ations C om m is sion (FCC )
T his e q ui p m en t ha s b e en t ested a nd f ou n d to c o m p ly w ith th e l imits fo r a Clas s B dig ital device, pursuant to Part 1 5 of th e
F CC ru les. These l imits a re designed t o pro vide re a s on a ble prot ect ion agains t h armful i n te rfe ren ce in a resi d en tial ins ta l la ti on .
An y changes or m o dific at ions m ade to this eq u ipment m a y vo id t he u ser’s authority to opera te t his e q uipm ent. This
equip m en t genera te s, uses, a n d c an ra diate radio f requ en cy e n ergy and, if n o t i n stall ed a n d used in acc o rd an ce w it h th e
in s tr uctio n s, m ay c a u se harm f ul interf erence to ra dio co m m u nication s.
Ho we ver, t he re is no g u ar antee th a t interfe rence wil l not occ ur in a p articu lar inst al lation . I f this equipment does c a us e
harm fu l interfe rence to radio or te levis ion recep ti o n, w h ich c an be deter m ined by turn ing the eq u ipment off a nd o n , th e
use r is en courag e d t o try to co rrect th e interfe rence b y o n e or more o f th e fo llowing m easu res:
¦ Re -p os ition or relo c at e th e rece iving a nt en n a.
¦ Increase the se pa ration between th e e qu ipm ent a n d rece i ve r.
¦ Con ne ct the equipment int o an outlet o n a c ircuit d i fferen t from t ha t t o wh i ch the rec e iver is connect ed .
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All right s reser ved . Produc t descr ipt ion and product speci fi cat io ns
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
Contents
< Part. 1 > APM 5170
1.1 Package Content
1.2 Structure Diagram & Dimension
1.3 Mounting Hardware & Installation
P.1
P.2 - 3
P.4 - 5
< Part. 2 > Specifications / OSD
2.1 Product Specifications
2.2 On-screen Display Operation ( OSD )
P. 6 - 7
P. 8
< Part. 3 >
Options
3.1 Option Table
3.2 3G / HD / SD-SDI Broadcast-grade input
3.3 MCS Multi-display control solution
3.4 AD2.2 Upgrade : HDMI, S-Video + BNC & Audio
3.5 AD3.0 Upgrade : HDMI, DVI-D, S-Video + BNC & Audio
3.6 17" Touchscreen : Resistive, Capacitive
3.7 48V, 24V or 12VDC power
3.8 MIL-type or lockable connector
3.9 Quad display for CCTV
3.10 TV ( Analog )
P. 9
P.10
P.11
P.12
P.13
P.14
P.15
P.16
P.17
P.18 - 19
APM 5170
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All righ ts reserved. Product descripti on and product speci ficat ions
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
APM 5170
Before Installation
¦ It is very important to mount the equipment in a suitable cabinet or on a stable surface.
¦ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive
dust, dirt, heat, water, moisture and vibration.
Unpacking
The equipment comes with the standard parts shown in package content. Check and make sure they are
included and in good condition. If anything is missing, or damaged, contact the supplier immediatel y.
How To Clean Your LCD Monitor
Caution :
¦ To avoid the r isk of electric shock, make sure your hands are dry before unplugging your monitor from or
plugging your monitor into an electrical outlet.
¦ When you clean your monitor, do not press down on the LCD screen. Pressing down on the screen can
scratch or damage your display. Pressure damage is not covered under warrant y.
¦ Use only cleansers made specifically for cleaning monitors and monitor screens. Cleansers not made to
clean monitors and monitor screens can scratch the LCD display or strip o ff the finish.
¦ Do not spray any kind of liquid directly onto the screen or case of your monito r. Spraying liquids directly
onto the screen or case can cause damage which is not covered under warrant y.
¦ Do not use paper towels or abrasive pads to clean your monito r. Using an abrasive pad or any wood based
paper product such as paper towels can scratch your LCD screen.
Cleaning Your Monitor
To clean your LCD safely, please follow these steps :
1
Disconnect the power cord.
2
Gently wipe the surface using a clean, dry microfiber cloth. Use as little pressure as possible.
Cleaning Tough Marks and Smudges
To remove tough marks and smudges, please follow these steps :
1
Disconnect the power cord.
2
Spray a small amount of non-abrasive cleanser on a microfiber cloth.
Caution : Do not spray or apply any liquids directly onto the monitor. Always apply the solution to your
microfiber cloth first, not directly on the parts you are cleaning.
3
Gently wipe the surface. Use as little pressure as possible.
4
Wait until your monitor is completely dry before plugging it in and powering it up.
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All right s reser ved . Produc t descr ipt ion and product speci fi cat io ns
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
< Part 1 >
< 1.1 > Package Content – APM 5170
17" LCD D isplay
APM 5170
17" LCD display X 1
6ft VGA cable X 1
Power adapter X 1
Power cord X 1
Mounting hardware X 1 pack
- Mounting bracket x 4 pcs
- M4* 6mm screw x 8 pcs
- M4* 50mm screw x 8 pcs
Standard I/O
Power DVI-D VGA
AD2.2 upgrade I/O
Power BNC S-Video Audio
out - in - in
Video PC
HDMI
VGA
AD3.0 upgrade I/O with advanced features
Power BNC S-Video Audio
out - in - in
Video PC
HDMI
DVI-D VGA
- An abundance of input connections that include HDMI, DVI-D, VGA, S-Video + BNC and audio
- On-chip Faroudja® DCDi Cinema processing
- Casing dimensions will be changed
APM 5170
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All righ ts reserved. Product descripti on and product speci ficat ions
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
< 1.2 > Structure Diagram - APM 5170
1
2
3
Front view
4
AP-17
NAP-17
5
7
1 Rear case
2 LCD panel
3 Protective 3mm glass
4 6mm aluminum front bazel
5 Audio speaker ( for HDMI, Audio or TV option )
6 LCD membrane
7
Remote sensor
Rear view
6
Model
Product Dimension
(W x D x H)
Packing Dimension
(W x D x H)
Net
Weight
Gross
Weight
APM5170
439 x 64 x 357 mm
17.3 x 2.5 x 14 inch
615 x 113 x 523 mm
25.6 x 4.9 x 23.5 inch
5.5 kg
12 lbs
7.5 kg
17 lbs
APM 5170
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All right s reser ved . Produc t descr ipt ion and product speci fi cat io ns
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
< 1.2 > Dimension - APM 5170
17” LCD Display
Front View Side View
AP-17
NAP-17
Rear View
UNIT : mm
1mm = 0.03937 inch
Bottom View
< 1.3 > Panel Mount Installation – APM 5170
1
Mounting
bracket
x 4 pcs
2 M4*6mm screw
x 8 pcs
3
M4*50mm screw
x 8 pcs
Hardware set part no. UV-BK#2
Steps
¦ Install 4 mounting brackets with 8 x M4*6mm screws
¦ Adjust the LCD panel with 8 x M4*50mm screws and fix it on the surface.
APM 5170
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All right s reser ved . Produc t descr ipt ion and product speci fi cat io ns
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
APM 5170
< 1.3 > VESA mount Installation – APM 5170
17” LCD D isplay
M4 screw
VESA mount ( 100*100mm )
¦ Hardware and M4*4 pcs for VESA mount are not provided
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All righ ts reserved. Product descripti on and product speci ficat ions
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
< Part 2 >
< 2.1 > Product Specifications
Mechanical
Design
APM5170
Front Panel
Black, RAL 9005
Rear Casing
Dark grey, RAL 7037
VESA Mounting
100 x 100mm
Other Mounting
Panel mount
Protection
3mm protective glass
LCD
Panel
Manufacturer
Panel Size ( diagonal )
17-inch TFT color LCD
Display pixel ( dots x lines )
1280 x 1024
Brightness ( typ. )
250
Contrast Ratio ( typ. )
1000:1
Color
16.7 M
Viewing Angle ( L/R/U/D )
80/80/80/80
Response Time ( ms )
5
Dot pitch ( mm )
0.264
Display Area ( mm )
337.92H x 270.33V
Surface treatment
Haze 25%, Hard-coating
Surface hardness
3H
Backlight Type
CCFL
MTBF ( hrs )
50,000
Video
Connectivity
Analog
VGA
Analog 0.7Vp-p
DVI-D
DVI-D, TMDS single link
Power
Power Supply
Range
Auto-sensing 100 to 240VAC,
50/60Hz
Power Consumption
Screen display ON
25W or less
Power saving mode
4W or less
Power button OFF
1W or less
APM 5170
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All right s reser ved . Produc t descr ipt ion and product speci fi cat io ns
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
Regulatory Safety Approval FCC & CE
Environmental
Conditions
Operating
Temperature
0 to 50°C degree
Humidity
20~90%, non-condensing
Storage
Temperature
-5 to 60°C degree
Humidity
5~90%, non-condensing
Shock
10G acceleration (11ms duration)
Vibration
5~500Hz 1G RMS random
Physical
Specification
Product ( W x D x H )
439 x 64 x 357 mm
17.3 x 2.5 x 14 inch
Packing ( W x D x H )
615 x 113 x 523 mm
24.2 x 4.4 x 20.6 inch
Net Weight
5.5 kgs / 12.1 lbs
Gross Weight
7.5 kgs / 16.5 lbs
Applicable
Format
VGA Input
PC Signal
1280 x 1024 x 60 / 75Hz
1280 x 960 x 60Hz
1280 x 760 x 60 / 75Hz
1152 x 864 x 75Hz
1024 x 768 x 60 / 70 / 75Hz
848 x 480 x 60Hz
800 x 600 x 60 / 72 / 75Hz
720 x 400 x 70Hz
640 x 480 x 60 / 72 / 75Hz
640 x 400 x 70Hz
640 x 350 x 70Hz
APM 5170
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All righ ts reserved. Product descripti on and product speci ficat ions
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
< 2.2 > On-screen Display Operation ( OSD )
Power light
Green = On
Orange = Power saving
Membrane Switch Function
Power on / off LCD
Display the OSD menu
Scrolls through menu options and adjusts the displayed control
(To auto adjustment by pressing the button for 5 seconds)
Exit the OSD screen
Toggle analog, digital & video connection (DVI-D and video options only)
OSD Configuration Page
Image:
for the brightness, contrast, color temp, red, green, and blue
Geometry:
for the autoadjust, H position, V position, phase and clock
Video:
for the colour, tint, sharpness, noise reduction, DCDi and TV Setup
Audio:
for volume, bass, treble, balance, AVL and mute
Misc:
for the language, OSD position, graphic mode, ratio, reset and timer
< Part 3 > Options
17” LCD Display
< 3.1 > Option Table
Options
APM
PM
SDI ***
HDMI * or DVI-D
S-Video * + Composite ( BNC )
Audio
Touchscreen
MCS multi-display control ***
DC Power
MIL-type / lockable connector
Quad display
TV ( Analog ) *
***
About SDI and MCS
( 1 ) The user can only select either SDI or MCS inputs.
( 2 ) For SDI input, the AD board will be upgraded to version 3.0, and this comes standard
with HDMI, DVI-D, VGA, S-Video, BNC, audio inputs and RC-2 remote controller.
*
About HDMI and DVI-D
( 1 ) For AD2.2 upgrade, only HDMI is provided.
( 2 ) If the user needs HDMI and DVI-D, AD3.0 upgrade can be applied.
*
Remote Controller
( 1 ) AD2.2 upgrade comes with RC-1 remote controller.
( 2 ) AD3.0 upgrade or TV option comes with RC-2 remote controller.
APM 5170
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All righ ts reserved. Product descripti on and product speci ficat ions
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
< 3.2 > Options : 3G / HD / SD -SDI input
Acnodes ’ SDI input is an ideal solution for the broadcast- grade
video and high resolution CCTV market.
Designed for use with Full H D 1080p an d ultra high resolution
1920 x 120 0 LCD displays, Acnodes provides a SDI input
module withou t using additional space or power and it comes
standard with a 2-year warrant y.
Power BNC S-Video
Audio
out - in - in
Video PC
HDMI
DVI-D V GA
SDI
out - in
*** F or SDI option, the AD board will be upgraded to AD3.0, and this comes standard with HDMI, DVI -D,
VGA, S-Video, BNC, audio inputs and RC -2 remote controller
INPUT
3G-SDI IN
BNC x 1 / 0.8Vp-p ( 75 ohm )
3G-SDI OUT
BNC x 1 / Active through, equalized & relocked
Standard Compl iance
Video
SMPT E 425M / 274M / 296M / 125M
ITU -R BT.656
Audio
SMPT E 299M / 272M -C
Compatible Video Format
3G-SDI
1080p @60 / 50Hz, 4:2:2
1080p @30 / 25 / 24Hz, 4:4:4
1080i @60 / 50Hz, 4:4:4
720p @60 / 50Hz, 4:4:4
HD-SDI
1080p @30 / 25 / 24Hz, 4:2:2
1080i @60 / 50Hz, 4:2:2
720p @60 / 50Hz, 4:2:2
SD-SDI
480i @60Hz, 4:2:2
ITU-R BT.656
576i @50Hz, 4:2:2
Compatible Audio Format
3G-SDI
48kHz, 16 / 20 / 24 bit, 2 CH, Synchronized Video
HD-SDI
48kHz, 16 / 20 / 24 bit, 2 CH, Synchronized Video
SD-SDI
48kHz, 16 / 20 / 24 bit, 2 CH, Synchronized /
As ynchronized Video
Max. Transmission Distance
75 ohm coaxial cable
3G-SDI
150m at 2.97Gb/s
HD-SDI
250m at 1.485Gb/s
SD-SDI
480m at 270Mb/s
APM 5170
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All right s reser ved . Produc t descr ipt ion and product speci fi cat io ns
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
< 3.3 > Options : MCS
17” LCD Display
MCS
( Multi-display Control )
More control is always good. Especially when it is necessary and
easy. Acnodes provides MCS solution to control the O SD of
various LCD display up to 64 units.
The RS-232C is used for the communication between the PC and
the first display via a 15 feet serial cable while the CAN bus is
used for the various LCD displays cascade together via CAT 5/6
cable, and daisy chain up to 1,000 meters.
Designed f or use with various LCD displays, Acnodes provides
a MCS input module without using additional space or power
and it comes standard with a 2-year warranty.
MCS
Power BNC S-Video
Audio
out - in - in
Video PC
HDMI
DVI-D VGA
set out in Link
RS-232C
Set switch
For the 1st and last display,
push the set switch upward
15 feet serial cable
( over 15 feet, extender required )
For other daisy chain displays,
push the set switch downward
LINK OUT IN OUT IN OUT IN OUT
Cat5 / 6 cable
max. 300 meters
Cat5 / 6 cable
max. 300 meters
Cat5 / 6 cable
max. 300 m eters
RJ-45 jack
Daisy c hain up to 1,000
meters and 64 displays
up to 64 displays
< 3.4 > AD2.2 Upgrade Options :
- HDMI
- S-Video + BNC
- Audio
Power BNC S-Video Audio
out - in - in
Video PC
HDMI
VGA
AV
HDMI
Audio
: S-Video + Composite (BNC)
: HDMI 1.1, CEA-861-D
: 3.5mm audio jacks for audio in & out, and 2W + 2W speakers
***
AD2.2 upgrade option comes with RC -1 remote controller x 1.
5
1
2
3 6
7
4
8
9
1
POWER Switches on or off the TV
2
MUTE Turn on or off the speaker
3
AV Switch to AV mode
4
0- 9
Select channels. For channel numbers 10 and above,
enter the second digit within two seconds.
5
V + / - Increase or decrease the speaker volume
6
CH + / - Increase or decrease the channel number
7
MENU Display the menu on the screen or go to the previous m enu
8
AUTO For auto searching
9
- / - For setting one or two input digit
APM 5170
< 3.5 > AD3.0 Upgrade Options :
- HDMI
- DVI-D
- S-Video + BNC
- Audio
17” LCD Display
Power BNC S-Video
Audio
out - in -
i n
Video PC
HDMI
DVI-D VGA
AV
HDMI
DVI-D
Audio
: S-Video + Composite (BNC)
: HDMI 1.1, CEA-861-D
: DVI-D TMDS single link
: 3.5mm audio jacks for audio in & out, and 2W + 2W speakers
***
( 1 ) AD3.0 upgrade option comes with RC -2 remote controller x 1, please refer to P.23
( 2 ) Casing dimensions will be changed
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All righ ts reserved. Product descripti on and product speci ficat ions
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
< 3.6 > Options : Touchscreen & driver
17" USB Touchscreen Specification
Mod el
Technology
Touch Point
Method
Activation Force
Durability
Response Time
Optical Transmittance
Surface Hardness
Haze
Glass
Connector
Compatibility
TRB e-Resistive
TCB e-Capacitive
5-Wire Resistive
Capacitive
Single
Single
Stylus or Finger
Finger
= 50g / Stylus=R0.8
= 50g
35 million touches
300 million touches
15 ms
20 ms
80% ± 3%
93% ±2%
3H
9H
8% ± 3%
7%
1.4 ±0.2 mm
2.8 mm ±10%
USB Type A
Windows 7 / XP / Vista, Linux
¦ USB touchscreen package includes 1 x 6ft USB cable, quick reference guideline and CD disc
¦ For detailed information, please refer to the attached CD disc
¦ As the touchscreen unit is not made of toughened glass, please handle it carefully
USB Touchscreen
Power VGA
APM 5170
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All right s reser ved . Produc t descr ipt ion and product speci fi cat io ns
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
APM 5170
Please follow the below steps to s etup the touch screen:-
Step 1. Run the bundled CD disc
Step 2. Double click the Setup.exe
Step 3. Follow the installation instruction to finish the setup
Step 4. After installation, run the TouchKit program & the “4 point calibration”
Please do the initial calibration
after the first setup
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All righ ts reserved. Product descripti on and product speci ficat ions
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
APM 5170
< 3.7 > Options : DC Power 17” LCD D ispla y
Model
12V
24V
48V
Input rating
Input voltage:
12-Volt
24-Volt
48-Volt
Input range:
9 ~ 18V
18 ~ 36V
36 ~ 75V
Input current
- No load
50 mA
50 mA
50 mA
- Full load
4950 mA
2450 mA
1220 mA
Output rating
Output voltage:
12-Volt
12-Volt
12-Volt
Output current:
4.16A
4.16A
4.16A
Efficiency
84%
85%
85%
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All right s reser ved . Produc t descr ipt ion and product speci fi cat io ns
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
< 3.8 > Options : MIL-type or Lockable Connector
Input
Part no.
MIL Standard
MIL - type
Connector
DC Power ***
( Male )
MS3470W8-33P
MIL - DTL - 26482
VGA ***
( Male )
MS3470W14-15P
MIL - DTL - 26482
*** There are several additional MIL DC and VGA connector types with varying design
characteristics to meet cost considerations and to provide users with the most
design flexibility possible. For more information, please contact us.
Input
Part no.
Standard
Lockable
Connector
DC Power
( Male )
YM-Ext-461CP001
D-type 3W3
USB
LUSB - A111 - 00
-
*** MIL - type or Lockable connectors above can be integrated with our LCD displays.
Sale service just for connectors not provided.
APM 5170
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All righ ts reserved. Product descripti on and product speci ficat ions
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
< 3.9 > Options : Quad Display
17” LCD Display
QD Specification
Item
Description
Model Number
QD (NTS C) QD (PAL)
Number of Color
16.7 M
16.7 M
Imaging System
NTSC
PAL
Resolution
1024 x 525
1024 x 625
Refresh Rate
60
50
Video Input
Camera Input
1.0 Vpp, 75 Ohm x 4
VCR Input
1.0 Vpp, 75 Ohm x 1
Video Output
Live Monitor
1.0 Vpp, 75 Ohm x 1
Loop Through Out
1.0 Vpp, 75 Ohm x 4
VCR Output
1.0 Vpp, 75 Ohm x 1
Auto Gain Control
Yes
Time / Date
Yes
On Screen Display
Yes
Camera Title
8 Character Title
Display Format
2 x Zoom On
Playback
Yes
QUAD
Yes
FULL
Yes
SEQUENCY
Yes
Dwell Time
0 to 99 Sec Adjustable
Alarm Inputs
Selectable NO/NC Contacts x 4
Relay Outputs
NO/NC contacts x 1: 1A @DC24V Max.
Alarm Hold Time
1 Sec to Non-stop
Built-in Buzzer
Yes
Key Lock
Yes
*** For QD option, casing dimensions will be changed.
APM 5170
< 3.10 > Options : TV ( Analog )
TV
Power BNC S-Video
Audio
out - in - in
Video PC
HDMI
VGA
***
For TV option :
( 1 ) The AD board comes standard with HDMI, VGA, S-Video, BNC, audio inputs and
RC-2 remote controller.
( 2 ) Casing dimensions will be changed.
17” Industrial Panel Mount LCD
14628 Ce ntral Ave,
Chino , CA 91710
tel:909.597.7 588, fax:909.597.1939
© Copyright 2013 Acnodes, Inc.
All righ ts reserved. Product descripti on and product speci ficat ions
are subj ect to change w ith out n oti ce. F or lates t product inform ati on,
ple ase vis it Acnod es’ we b site at www.ac nodes.c om.
r
How to Use RC-2 Remote Controller
1
8
2
INP UT MUTE
VOL
9
1 2 3
3
4 5 6
7 8 9
4
AUTO
0
-/--
CH
10
F REEZE
11
12
5
ME NU SELEC T
ASP ECT 13
14
6 ENTE R
SLEE P
15
7
BA CK EXIT
16
PIP
17
20
SOURCE
21
SWAP
PIP
POSITION
PIP
AUDI O 18
19
1
INPUT Select the source
2
Switches on or off the TV
3 0 - 9
Only use in TV mode. Select channels. For channel numbers 10
and above, enter the second digit within two seconds.
4 AUTO Auto adjust
5 MENU Display the menu on the screen or go to the previous m enu
Go to the upper menu or select the p revious value /
Go to the next menu or select the next value /
6 ? / ? / ? / ? / E NTER Decrease the setting value /
Increase the setting value or enter tothe select item setting
Enter to the select item settings or excude the setting
7
BACK Back to previous value
8 MUTE Turn on or off the speaker
9
Vol + / - Increase or decrease the speaker volume
10 CH + / - For TV model only, increase or decrease the channel number
11
FREEZE Reserve for OEM model
12
- / -- For setting input single or double digits
13 ASPECT Adjust the screen size
14
SELECT To select the existing item
15 SLEEP Select the sleeping time
16
EXIT Exit the menu or cancel
PIP functions
17
PIP Picture in picture
18 PIP AUDIO To set the audio of in PIP mode
19
POSITION To set the screen position in PIP mode
20 SOURCE PIP Source
21
SWAP Swap screen in PIP mode
Loading...
