Industry Leadership

Founded in 1938, Acme Engineering and Manufacturing Corporation is known worldwide as a leader in the manufacture of fans, blowers, and ventilation equipment. Acme’s growth over the past half century is a tribute to superior quality, customer loyalty, and dedicated employees and sales representatives.

Today, from its headquarters in Muskogee, Oklahoma, Acme serves customers worldwide with high quality air movement and control products.

Manufacturing

With approximately 350,000 square feet of manufacturing space, Acme produces one of the broadest lines of air moving equipment in the industry. State-of-the-art manufacturing equipment and a well trained, experienced workforce is the key to Acme’s timely delivery of quality air moving products.

Engineering

The Acme Research and Engineering Center operates both air and sound laboratories. The Center houses four wind tunnels with a data acquisition system, a reverberant sound room with the latest sound analyzer equipment, and a structural laboratory for stress and vibration analysis. Solid modeling, and finite element analysis support product research and development. The Center also houses a fully equipped prototype facility enabling Acme to develop and introduce new products to the market in the shortest time possible.

Sales & Service

A factory trained, knowledgeable sales organization addresses the needs of many diverse and distinct markets. Customers around the world are serviced by a complete system of sales representatives, equipment distributors and local dealers supported by nationwide distribution centers and backed by a staff of sales and marketing professionals.

Quality

A highly trained engineering and production staff set the standard for dependable, quality air moving products. By using the latest computer techniques for research and design, and rigorous quality control standards Acme can offer one of the best warranty programs in the industry. Our exclusive 2/5 year limited warranty provides our customers with confidence…Year After Year.

SYMBOL

UAL ITY

Belt Drive Inline Centrifugal Exhauster Model TIB

Model TIB is a belt drive, centrifugal exhauster with the motor, drives and bearings located outside the airstream. The TIB is designed to operate in any position and is furnished with mounting ﬂ anges on both ends for easy installation. Model TIB has a wide range of static pressures.

DIMENSIONS

Fan

AB C D E F G H JKL

Model

TIB80 23 23.38 30 18.91 13.38 11.69 20.19 21.88 10.02 8 0.63

TIB100 23 23.38 30 18.91 13.38 11.69 20.19 21.88 10.02 8 0.63

TIB120 23 23.38 30 18.91 13.38 11.69 20.19 21.88 10.02 8 0.63

TIB135 25 27.75 36 20.91 14.94 13.88 24.56 26.19 11.58 8 0.63

TIB150 27 27.75 36 22.91 14.94 13.88 24.56 26.19 11.58 8 0.63

TIB155 27 27.75 36 22.91 14.94 13.88 24.56 26.19 11.58 8 0.63

TIB160 27 27.75 36 22.91 14.94 13.88 24.56 26.19 11.58 8 0.63

TIB165 27 27.75 36 22.91 14.94 13.88 24.56 26.19 11.58 8 0.63

TIB185 32 33.13 39 27.91 16.85 16.57 29.95 31.57 13.50 16 0.63

TIB200 38 39.56 44 33.91 22.60 19.78 36.34 38.00 16.72 16 0.63

TIB235 41 47.69 51 36.91 25.45 23.85 44.41 46.13 19.57 16 0.63

TIB240 41 47.69 51 36.91 25.45 23.85 44.41 46.13 19.57 16 0.63

TIB245 41 47.69 51 36.91 25.45 23.85 44.41 46.13 19.57 16 0.63

TIB290 48 53.44 54 43.91 27.33 26.72 49.13 51.69 21.42 16 0.75

TIB295 48 53.44 54 43.91 27.33 26.72 49.13 51.69 21.42 16 0.75

TIB300 48 53.44 54 43.91 27.33 26.72 49.13 51.69 21.42 16 0.75

TIB355 55 58.56 57 50.91 32.01 29.28 54.26 56.81 24.58 16 0.75

TIB360 55 58.56 57 50.91 32.01 29.28 54.26 56.81 24.58 16 0.75

TIB365 55 58.56 57 50.91 32.01 29.28 54.26 56.81 24.58 16 0.75

U.L. 705 Listed

Standard Construction Features

Housing

• Heavy gauge, rolled steel construction

• Standard charcoal baked enamel ﬁ nish provides a tough, durable surface

Inlet and Outlet

• Rolled ﬂ ange at each end for ease of mounting

• Inlet and outlet diameters are identical to accommodate a single duct size

Oriﬁ ce

• Streamlined, continuously welded, aluminum oriﬁ ce is optimally matched to the wheel and bolted onto the inlet

Universal Mounting Brackets

• 8 Heavy duty, steel mounting brackets with 4 interchangeable, bolted on mounting feet allow the TIB to be mounted in any position

• Compatible with isolators

• Standard coating is charcoal baked enamel

Fasteners

• Dichromate plated, steel fasteners

Wheel

• Aluminum, centrifugal wheel with backward curved blades

• Non-overloading design for high efﬁ ciency and minimal sound

• The dynamically balanced impellers for our products are balanced to the grade G6.3 as described in the standards:

◦ ANSI/AMCA 204 “Balance Quality and Vibration Levels for

Fans”

◦ ISO 14694 “Fans – Speciﬁ cations for balance quality and

vibration levels”

Bearings

• Acme D.S. Pillow Block Bearings are resiliently mounted in neoprene rings and permanently lubricated in a duplex split pillow housing

◦ Rated at L50 life of 200,000 hours ◦ 5 year limited warranty

Shaft

• Corrosion-resistant coated, steel shaft

• Sized so that ﬁ rst critical speed is at least 25% over the max operating speed

Motor

• Continuous duty motors with sealed ball bearings

• Motors are located outside the airstream

• Motors are bolted solid to the mount

Drive Assembly

• Variable pitch drive assembly

• Cast iron drives sized for 150% of fan horsepower

• Static free, oil, and heat-resistant belts

Belt and Bearing Enclosure

• Streamline enclosure virtually eliminates turbulence and air drag

• Bearings are ventilated with outside air for longer life

Dimensions are shown in inches.

Acme Engineering & Manufacturing Corporation certiﬁ es that the models shown herein are licensed to bear the AMCA seal. The ratings shown are based on tests and procedures performed in accordance with AMCA Publication 211 and AMCA Publication 311 and comply with the requirements of the AMCA Certiﬁ ed Ratings Program.

Disconnect Device

• Standard without disconnect device

Nameplate

• Permanently afﬁ xed manufacturer’s nameplate containing the tag information, model number, and serial number, for future identiﬁ cation; CFM and static pressure (inches w.g.) are included when selected through air and sound

Page 3

Optional Accessories

Disconnect Switch

• Nema 3R - Protection from rain, sleet, snow

• Explosion proof switch shipped separate when explosion proof motors are selected

Access Door

• Gasketed, oversized, bolted-on access door for servicing

• Heavy duty steel with charcoal baked enamel ﬁ nish

Bearings

• Pillow block bearings with external lube ﬁ ttings

• Rated at L50 life of 200,000 hours

• 2 year limited warranty

Fixed Pitch Drive Assembly

• Cast iron drives sized for 150% of fan horsepower

• Static free, oil, and heat-resistant belts

Spark Resistant Construction

• Constructed to meet AMCA B speciﬁ cations

Inlet and Outlet Guard

• Galvanized wire

MTD

Not factory mounted, shipped separately

Unless speciﬁ cally shown as not mounted, option/accessory is mounted.

MTD

Belt Guard/Motor Cover

• Steel construction with charcoal baked enamel ﬁ nish

• Removable for access to the motor/drive assembly

Isolators

• Hanging Spring (HSI)

• Hanging Rubber (HRI)

• Base Spring (BSI)

• Base Rubber (BRI)

Stainless Steel Tag

• 4” x 2” With model, order number, and tag information

Optional Coatings

• Charcoal Epoxy

• Heresite

MTD

Page 4

Performance Data

TIB080 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000” 4.250” 4.500” 4.750” 5.000”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

345 286 225 98

1421

0.05 5.40 0.06 5.50 0.07 5.30 0.07 5.70

434 387 342 295 223 78

1790

0.11 7.90 0.12 8.30 0.13 8.00 0.13 7.60 0.14 8.90 0.13 7.80

555 517 481 446 409 371 315 258 123

2286

0.22 13.00 0.24 19.10 0.25 13.40 0.26 12.80 0.27 12.40 0.28 12.10 0.28 13.60 0.29 14.30 0.27 12.80

609 574 541 509 476 443 408 357 305 220 84

2508

0.29 14.90 0.31 27 0.32 15.20 0.34 15.20 0.35 14.50 0.36 14.20 0.37 13.80 0.37 15.40 0.38 16.20 0.37 16.00 0.34 13.30

699 668 640 611 583 555 526 497 465 420 375 330 237 119

2880

0.44 18.10 0.46 42 0.48 18.80 0.50 18.70 0.51 18.60 0.52 17.90 0.54 17.70 0.55 17.30 0.56 17.20 0.56 18.70 0.57 19.50 0.57 20 0.56 19.40 0.53 17.10

800 774 748 723 698 674 649 624 599 573 547 512 473 433 394 346 243 140

3297

0.66 22 0.68 60 0.70 34 0.73 22 0.74 23 0.76 23 0.78 22 0.79 22 0.81 22 0.82 21 0.83 21 0.84 22 0.85 23 0.85 24 0.86 24 0.86 25 0.82 23 0.79 21

TIB100 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000” 4.250” 4.500” 4.750” 5.000”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

573 489 313

1189

0.05 4.70 0.06 4.60 0.07 5.00

721 658 569 428

1497

0.09 6.70 0.11 7.60 0.13 7.00 0.14 7.40

921 878 820 749 657 536

1913

0.19 11.10 0.22 19.20 0.24 10.40 0.27 10.90 0.28 10.70 0.29 11.70

1011 972 920 870 793 701 589 441

2098

0.25 13.10 0.28 25 0.31 13.70 0.33 12.60 0.36 12.80 0.37 12.50 0.38 13.70 0.37 14.50

1161 1127 1088 1040 998 928 855 767 667 536

2410

0.38 15.90 0.42 33 0.45 23 0.49 14.80 0.51 15.60 0.54 15.80 0.56 15.60 0.57 16.00 0.57 17.10 0.57 17.90

1329 1299 1270 1230 1187 1151 1094 1037 969 892 803 699 591

2758

0.57 19.20 0.61 42 0.66 34 0.70 24 0.73 18.50 0.76 19.20 0.79 19.50 0.82 19.50 0.84 19.10 0.85 19.50 0.86 21 0.85 22 0.85 22

TIB120 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000” 4.250” 4.500” 4.750” 5.000”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

870 652

1001

0.04 4.60 0.06 4.40

1097 925 741

1261

0.09 6.90 0.11 7.30 0.13 7.20

1401 1264 1126 991 764

1610

0.19 11.00 0.22 13.40 0.24 11.30 0.26 11.00 0.26 11.20

1537 1412 1291 1165 1026 791

1766

0.25 13.40 0.28 17.70 0.31 13.60 0.33 13.20 0.35 13.40 0.34 13.70

1766 1657 1552 1440 1334 1217 1037

2029

0.37 16.90 0.42 24 0.45 17.50 0.48 17.40 0.50 16.90 0.52 17.10 0.53 17.40

2021 1926 1831 1742 1640 1549 1453 1338 1162

2322

0.56 21 0.61 32 0.66 26 0.69 22 0.72 22 0.75 21 0.78 21 0.79 22 0.79 22

Performance certied is for installation type B: Free inlet, Ducted outlet. Power rating (BHP) does not include transmission losses. Performance ratings do not include the effects of appurtenances (accessories).

The sound ratings shown are loudness values in hemispherical sones at 1.5 m (5 ft) in a hemispherical free eld calculated per AMCA Standard 301. Values are shown for:

Installation Type B: free inlet hemispherical sone levels.

Page 5

Performance Data

TIB135 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000” 4.250” 4.500” 4.750” 5.000”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

1105 742

818

0.05 2.30 0.07 3.40

1392 1142 675

1030

0.10 3.80 0.12 6.00 0.13 5.80

1779 1597 1374 1033

1316

0.20 6.00 0.24 12.30 0.27 9.90 0.29 9.10

1951 1772 1591 1339 902

1443

0.26 7.10 0.30 13.60 0.34 10.90 0.37 10.20 0.36 10.70

2242 2066 1952 1760 1529 1180

1658

0.40 9.00 0.45 16.60 0.49 12.80 0.52 14.40 0.56 13.30 0.56 13.90

2567 2390 2309 2179 2005 1801 1575 1151

1898

0.60 11.60 0.65 21 0.71 23 0.76 17.10 0.79 18.60 0.84 19.80 0.86 17.50 0.82 17.40

TIB150 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000” 4.250” 4.500” 4.750” 5.000”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

2095 1831 1594 978

1113

0.22 7.40 0.26 9.80 0.28 9.10 0.26 8.60

2298 2064 1861 1533

1221

0.30 8.90 0.34 11.60 0.36 11.20 0.38 10.30

2641 2438 2212 2059 1746 741

1403

0.45 11.30 0.50 15.30 0.54 14.40 0.56 14.00 0.57 13.20 0.41 11.70

3023 2846 2660 2492 2340 2084 1666

1606

0.68 14.10 0.74 20 0.78 18.50 0.81 18.00 0.84 17.60 0.86 16.80 0.83 16.70

3278 3114 2949 2760 2659 2470 2219 1838

1741

0.86 16.20 0.93 23 0.98 21 1.02 21 1.05 20 1.08 19.60 1.10 19.20 1.07 19.10

3752 3610 3465 3314 3148 3063 2935 2736 2500 2188 1260

1993

1.29 20 1.37 29 1.44 27 1.49 26 1.53 26 1.57 25 1.61 25 1.64 24 1.64 24 1.62 24 1.29 22

TIB155 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000” 4.250” 4.500” 4.750” 5.000”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

969 911 853 789 708 610 458

1471

0.18 6.60 0.21 9.50 0.23 14.00 0.25 17.00 0.27 19.20 0.29 21 0.28 21

1062 1008 955 902 838 762 671 532

1613

0.24 7.90 0.27 11.30 0.30 14.80 0.32 18.30 0.34 21 0.36 23 0.38 24 0.37 25

1220 1171 1128 1082 1034 979 916 848 761 640 518

1853

0.37 10.20 0.40 14.80 0.43 15.90 0.46 20 0.49 24 0.51 26 0.54 29 0.56 30 0.57 32 0.56 33 0.56 33

1397 1351 1316 1275 1236 1194 1149 1098 1040 981 922 816 710 604

2121

0.55 13.50 0.58 19.90 0.62 18.70 0.66 23 0.69 27 0.72 30 0.75 33 0.78 36 0.81 38 0.83 40 0.86 42 0.85 43 0.84 43 0.83 43

1515 1471 1438 1403 1365 1330 1290 1249 1202 1150 1096 1041 976 879 781 683 585

2300

0.70 15.50 0.74 23 0.78 22 0.82 23 0.86 28 0.90 32 0.93 35 0.96 38 0.98 41 1.02 43 1.05 45 1.08 47 1.10 49 1.09 49 1.08 50 1.07 50 1.06 50

1734 1693 1664 1636 1604 1570 1539 1509 1472 1437 1396 1354 1307 1259 1212 1164 1094 1009 923 838 753

2633

1.05 18.40 1.09 26 1.14 26 1.19 25 1.24 28 1.28 32 1.32 36 1.36 40 1.40 42 1.43 45 1.46 48 1.50 50 1.53 52 1.57 54 1.60 56 1.64 58 1.64 59 1.63 60 1.62 60 1.61 60 1.60 60

The sound ratings shown are loudness values in hemispherical sones at 1.5 m (5 ft) in a hemispherical free eld calculated per AMCA Standard 301. Values are shown for:

Installation Type B: free inlet hemispherical sone levels.

Page 6

Performance Data

TIB160 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000” 4.250” 4.500” 4.750” 5.000”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

1635 1524 1389 1196

1180

0.17 5.60 0.22 7.20 0.26 7.50 0.28 9.70

1793 1692 1579 1423 1229

1294

0.23 6.50 0.28 8.40 0.32 7.80 0.36 10.20 0.38 11.80

2059 1971 1880 1771 1628 1464 1220

1486

0.34 8.20 0.40 11.20 0.46 10.50 0.51 10.60 0.54 13.10 0.57 14.70 0.57 15.60

2357 2280 2203 2120 2021 1896 1760 1599 1364

1701

0.51 10.20 0.58 13.80 0.65 13.30 0.71 13.00 0.76 13.40 0.81 15.90 0.84 17.50 0.86 18.70 0.86 19.50

2557 2485 2415 2340 2257 2159 2042 1917 1772 1569

1845

0.65 11.70 0.73 16.10 0.80 15.50 0.87 15.20 0.93 14.20 0.99 16.10 1.03 18.10 1.08 19.80 1.10 21 1.09 22

2927 2864 2803 2740 2674 2603 2522 2428 2322 2214 2093 1946 1757

2112

0.98 14.80 1.07 21 1.15 20 1.23 19.30 1.31 19.10 1.38 18.20 1.45 18.70 1.51 21 1.56 23 1.61 25 1.64 26 1.65 27 1.64 28

TIB165 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000” 4.250” 4.500” 4.750” 5.000”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

2357 2048 1631

958

0.22 4.80 0.26 6.10 0.29 5.80

2586 2312 1972 1309

1051

0.30 5.70 0.34 7.00 0.37 6.80 0.34 6.60

2971 2741 2464 2126 1430

1207

0.45 7.20 0.50 10.90 0.54 10.00 0.57 9.10 0.50 8.60

3402 3199 2974 2725 2410 1991

1382

0.68 9.20 0.73 13.70 0.79 12.40 0.83 13.30 0.86 11.80 0.84 11.40

3690 3501 3305 3080 2831 2517 2007

1499

0.86 10.70 0.92 15.60 0.99 13.60 1.04 14.90 1.08 13.30 1.10 13.60 1.03 12.70

4222 4056 3898 3706 3508 3294 3037 2748 2122

1715

1.29 13.50 1.36 19.10 1.43 20 1.50 17.70 1.56 18.60 1.61 19.50 1.64 17.00 1.65 17.00 1.47 16.20

TIB185 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000” 4.250” 4.500” 4.750” 5.000”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

2795 2390 1930

803

0.19 2.60 0.24 5.60 0.28 5.20

3067 2693 2321 1393

881

0.25 3.10 0.31 6.80 0.36 6.60 0.33 6.40

3524 3199 2887 2524 1526

1012

0.38 4.70 0.45 9.60 0.51 9.50 0.56 9.00 0.50 8.70

4033 3750 3467 3198 2856 2117

1158

0.56 6.20 0.64 12.10 0.72 12.30 0.79 11.70 0.84 11.40 0.80 11.20

4374 4111 3848 3603 3329 2973 2127

1256

0.72 7.00 0.81 13.50 0.89 13.90 0.97 13.70 1.04 13.00 1.09 12.70 0.99 12.60

5005 4771 4547 4320 4106 3870 3602 3234 2249

1437

1.08 8.70 1.18 15.70 1.28 17.10 1.36 17.10 1.46 16.80 1.54 16.20 1.61 16.10 1.64 15.60 1.44 15.60

5510 5297 5098 4883 4685 4491 4274 4038 3722 3271

1582

1.43 10.30 1.55 17.80 1.66 19.90 1.76 19.80 1.86 20 1.96 19.60 2.05 18.90 2.13 18.90 2.17 18.50 2.15 18.10

6308 6121 5941 5765 5577 5404 5235 5066 4865 4658 4402 4110 3540

1811

2.15 12.90 2.28 21 2.41 24 2.53 25 2.64 25 2.76 25 2.88 25 2.99 24 3.09 24 3.18 24 3.24 24 3.28 23 3.15 23

The sound ratings shown are loudness values in hemispherical sones at 1.5 m (5 ft) in a hemispherical free eld calculated per AMCA Standard 301. Values are shown for:

Installation Type B: free inlet hemispherical sone levels.

Page 7

Performance Data

TIB200 PERFORMANCE DATA

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

3219 2652 1980

725

0.19 1.80 0.26 6.20 0.29 6.70

3530 3023 2445

795

0.25 2.20 0.33 7.00 0.37 7.70

4055 3644 3140 2609

913

0.38 2.90 0.47 8.40 0.53 9.50 0.57 9.80

4646 4300 3859 3432 2957 2162

1046

0.58 3.80 0.69 10.20 0.76 11.50 0.82 12.30 0.86 12.50 0.82 12.60

5037 4718 4327 3933 3518 3036 2217

1134

0.74 4.50 0.86 11.40 0.94 12.80 1.01 13.80 1.07 14.20 1.10 14.60 1.03 14.40

5766 5478 5189 4815 4478 4120 3734 3251

1298

1.11 5.90 1.26 13.50 1.36 15.30 1.44 16.50 1.52 17.40 1.60 17.80 1.64 17.90 1.65 18.40

6348 6072 5840 5515 5192 4883 4556 4206 3798 3226

1429

1.48 6.90 1.66 15.00 1.77 17.30 1.88 18.30 1.96 19.50 2.05 20 2.12 20 2.18 20 2.20 21 2.15 21

7264 6999 6820 6587 6288 6002 5735 5460 5169 4863 4533 4138 3535

1635

2.21 8.50 2.44 17.30 2.58 20 2.70 22 2.82 22 2.91 24 3.01 25 3.11 25 3.19 25 3.25 25 3.30 26 3.30 26 3.18 26

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000” 4.250” 4.500” 4.750” 5.000”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

1882 1759 1613 1411 1141

845

0.24 1.50 0.29 9.30 0.33 9.40 0.36 9.30 0.38 10.70

2161 2056 1935 1795 1611 1375

970

0.36 2.10 0.42 11.30 0.47 12.00 0.52 12.00 0.55 11.90 0.56 13.40

2475 2384 2283 2176 2046 1888 1692 1483

1111

0.54 2.90 0.61 15.50 0.67 15.30 0.73 15.40 0.78 15.20 0.82 15.00 0.84 16.40 0.85 17.40

2685 2601 2512 2413 2308 2181 2029 1847 1654 1461

1205

0.69 3.50 0.77 18.30 0.84 17.50 0.90 17.70 0.96 17.90 1.01 17.60 1.05 17.40 1.07 18.90 1.09 19.90 1.10 21

3073 3000 2925 2841 2755 2664 2558 2444 2302 2141 1973 1804 1636

1379

1.04 4.40 1.14 22 1.21 20 1.28 21 1.36 22 1.43 22 1.48 21 1.54 21 1.58 21 1.61 23 1.62 24 1.64 24 1.65 25

3382 3317 3249 3178 3098 3021 2938 2844 2741 2623 2494 2343 2190 2037 1883

1518

1.38 5.20 1.49 25 1.58 25 1.66 24 1.74 25 1.82 25 1.90 25 1.96 24 2.02 24 2.08 24 2.13 25 2.14 26 2.16 27 2.18 28 2.19 28

3873 3815 3757 3697 3634 3564 3496 3429 3353 3272 3182 3091 2981 2868 2738 2605 2471 2337 2203 2070

1738

2.07 6.40 2.20 30 2.31 32 2.40 29 2.49 30 2.59 30 2.69 30 2.78 30 2.86 30 2.93 30 2.99 30 3.07 30 3.13 30 3.18 30 3.21 32 3.23 33 3.25 34 3.26 34 3.28 35 3.30 35

CFM and Sones vs. Static Pressure

TIB235 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

TIB240 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000” 4.250” 4.500” 4.750” 5.000”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

3177 2866 2441 1737

682

0.21 0.80 0.30 5.90 0.36 6.50 0.38 6.70

3648 3382 3068 2607 1949

783

0.32 1.20 0.42 7.00 0.51 7.90 0.56 8.20 0.57 8.30

4174 3942 3691 3389 2949 2430

896

0.48 1.70 0.60 8.60 0.70 9.50 0.79 10.10 0.84 10.30 0.86 10.60

4529 4314 4092 3833 3507 3074 2549

972

0.61 2.10 0.74 9.70 0.86 10.60 0.96 11.40 1.04 11.80 1.08 11.90 1.09 12.10

5186 5001 4812 4603 4372 4108 3728 3358 2827

1113

0.91 2.90 1.08 11.50 1.21 12.90 1.34 14.00 1.45 14.50 1.54 14.90 1.59 15.00 1.65 15.20 1.63 15.20

5708 5544 5367 5193 4994 4776 4541 4196 3855 3473 2886

1225

1.21 3.60 1.40 13.10 1.55 14.90 1.70 15.80 1.83 16.70 1.95 17.20 2.05 17.60 2.11 17.70 2.17 17.70 2.20 18.00 2.13 17.80

6533 6396 6234 6087 5931 5757 5577 5374 5155 4854 4552 4261 3894 3374

1402

1.82 4.60 2.05 14.70 2.22 17.60 2.39 18.40 2.55 19.20 2.71 20 2.85 21 2.97 21 3.09 21 3.15 21 3.21 21 3.29 22 3.30 22 3.22 22

The sound ratings shown are loudness values in hemispherical sones at 1.5 m (5 ft) in a hemispherical free eld calculated per AMCA Standard 301. Values are shown for:

Installation Type B: free inlet hemispherical sone levels.

Page 8

Performance Data

TIB245 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

RPM

569

653

748

811

929

1022

1170

RPM

840

911

1042

1147

1313

1557

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500”

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

4596 3759 2699

0.26 0.70 0.35 5.50 0.38 6.40

5276 4554 3733 2338

0.39 1.30 0.50 6.50 0.56 7.70 0.52 8.00

6044 5425 4744 3977 2325

0.59 1.80 0.72 7.40 0.81 9.00 0.85 9.90 0.74 9.80

6553 5985 5379 4696 3923

0.75 2.20 0.90 8.10 1.00 9.90 1.07 10.90 1.10 11.70

7507 7016 6492 5942 5340 4693 3647

1.13 3.00 1.31 9.30 1.44 11.60 1.54 12.90 1.61 13.90 1.65 14.60 1.58 15.00

8259 7810 7347 6873 6339 5786 5194 4317

1.51 3.70 1.71 10.40 1.86 12.90 1.99 14.50 2.08 15.50 2.15 16.30 2.19 17.10 2.14 17.70

9456 9059 8668 8249 7836 7371 6895 6399 5874 5090

2.26 5.00 2.50 12.20 2.68 15.30 2.85 17.20 2.99 18.50 3.09 19.30 3.18 20 3.25 21 3.29 22 3.22 23

TIB290 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000” 4.250” 4.500” 4.750” 5.000” 5.250” 5.500” 5.750”

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

3166 2947 2747 2517 2244 1897 1503

0.54 16.00 0.63 32 0.71 15.00 0.77 14.40 0.82 14.30 0.86 14.30 0.86 14.90

3434 3229 3045 2843 2615 2340 2014 1650

0.69 18.10 0.79 43 0.88 17.10 0.95 16.70 1.01 16.10 1.06 16.40 1.09 16.40 1.10 16.90

3928 3749 3581 3421 3238 3040 2829 2555 2255 1938 1521

1.03 22 1.15 65 1.25 33 1.34 21 1.42 21 1.50 19.70 1.57 20 1.61 20 1.64 20 1.65 21 1.59 21

4324 4161 4004 3858 3706 3539 3357 3167 2929 2683 2394 2106 1723

1.38 26 1.51 84 1.63 50 1.73 27 1.83 24 1.91 24 2.00 23 2.07 23 2.13 23 2.18 23 2.19 24 2.20 24 2.13 24

4949 4807 4665 4535 4408 4278 4132 3986 3820 3654 3456 3244 3019 2767 2515 2235

2.06 32 2.21 116 2.36 84 2.48 53 2.60 33 2.72 30 2.82 30 2.91 29 3.01 29 3.09 29 3.16 29 3.22 29 3.27 29 3.28 29 3.29 30 3.27 30

5869 5750 5630 5509 5401 5294 5187 5077 4954 4831 4707 4566 4425 4284 4110 3930 3752 3553 3341 3128 2916 2679 2373

3.44 42 3.62 162 3.79 147 3.97 111 4.11 79 4.25 55 4.39 40 4.53 40 4.64 40 4.76 40 4.88 39 4.99 38 5.09 39 5.19 39 5.27 39 5.34 39 5.41 38 5.45 38 5.46 39 5.48 39 5.49 39 5.47 40 5.34 39

TIB295 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

RPM

5581 5144 4624 3905 2700

656

0.49 12.30 0.64 12.10 0.76 11.80 0.84 11.80 0.83 12.40

6058 5660 5199 4624 3825 2221

712

0.63 14.20 0.79 16.10 0.93 13.90 1.04 13.50 1.10 13.90 0.96 13.60

6934 6596 6206 5791 5251 4566 3629

815

0.94 18.20 1.12 25 1.30 17.80 1.45 17.10 1.56 17.00 1.64 17.10 1.63 17.70

7632 7332 6986 6615 6196 5695 5066 4265 2577

897

1.26 21 1.46 31 1.66 20 1.83 20 1.98 19.40 2.10 19.70 2.18 19.70 2.19 20 1.86 19.30

8730 8479 8179 7867 7542 7186 6763 6296 5702 5018 3930

1026

1.88 26 2.11 44 2.34 30 2.56 26 2.75 25 2.93 24 3.08 24 3.20 25 3.27 25 3.28 26 3.11 25

10356 10149 9908 9655 9392 9119 8844 8536 8180 7809 7408 6896 6374 5701 4742

1217

3.14 34 3.40 62 3.68 52 3.96 38 4.22 34 4.45 34 4.68 33 4.88 32 5.06 32 5.22 32 5.36 33 5.45 33 5.49 34 5.46 34 5.22 34

The sound ratings shown are loudness values in hemispherical sones at 1.5 m (5 ft) in a hemispherical free eld calculated per AMCA Standard 301. Values are shown for:

Installation Type B: free inlet hemispherical sone levels.

Page 9

Performance Data

TIB300 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

RPM

7175 6233 5252 1896

544

0.61 13.00 0.72 12.70 0.84 11.70 0.56 9.80

7783 6906 6061 4746

590

0.77 15.00 0.90 14.50 1.04 13.90 1.09 13.00

8905 8123 7422 6592 5278

675

1.16 18.50 1.30 21 1.46 17.80 1.60 16.90 1.62 16.30

9803 9088 8428 7770 6940 5518

743

1.54 22 1.70 27 1.87 21 2.04 20 2.17 19.20 2.14 19.00

11229 10600 10007 9452 8855 8136 7208 5374

851

2.32 27 2.49 37 2.69 26 2.89 26 3.08 25 3.23 24 3.29 23 3.03 24

13314 12779 12260 11774 11305 10856 10277 9665 8949 7803 5980

1009

3.86 37 4.06 53 4.30 45 4.52 35 4.76 35 5.02 34 5.21 33 5.38 32 5.48 31 5.41 31 4.91 31

TIB355 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

RPM

4022 3738 3387 2987 2513 1988

620

0.50 13.30 0.62 22 0.71 13.20 0.79 12.90 0.84 12.70 0.86 13.10

4366 4113 3781 3444 3061 2590 2085

673

0.64 15.50 0.77 30 0.87 15.20 0.97 15.10 1.04 15.00 1.08 14.70 1.10 15.00

4995 4765 4505 4228 3916 3583 3191 2751 2210

770

0.96 20 1.11 50 1.23 22 1.35 19.70 1.46 19.20 1.55 19.10 1.60 18.80 1.63 18.80 1.61 18.80

5495 5278 5070 4798 4556 4261 3957 3607 3225 2871 2108

847

1.28 24 1.45 67 1.58 36 1.72 23 1.84 23 1.96 22 2.05 22 2.12 22 2.16 22 2.20 22 2.04 22

6293 6091 5940 5717 5480 5278 5023 4766 4496 4190 3863 3505 3208 2513

970

1.92 30 2.13 93 2.28 61 2.44 35 2.59 28 2.73 28 2.87 28 3.00 27 3.10 27 3.17 27 3.22 26 3.25 27 3.30 27 3.10 27

7461 7286 7146 7019 6821 6621 6433 6262 6049 5832 5613 5386 5147 4871 4596 4300 4012 3758 3175 2456

1150

3.20 38 3.46 131 3.66 108 3.84 75 4.03 50 4.21 35 4.39 36 4.55 36 4.71 36 4.87 35 5.02 35 5.13 35 5.23 35 5.30 35 5.37 34 5.41 35 5.45 35 5.50 35 5.29 35 4.87 34

8545 8392 8252 8142 8030 7855 7680 7505 7347 7198 7021 6832 6642 6452 6253 6054 5831 5591 5350 5108 4835 4592 4392 4063

1317

4.81 47 5.10 167 5.36 158 5.58 127 5.78 94 6.00 68 6.20 49 6.42 44 6.61 44 6.80 44 6.99 44 7.17 44 7.35 43 7.53 43 7.66 43 7.78 43 7.88 43 7.96 43 8.04 42 8.11 42 8.14 42 8.18 43 8.26 44 8.22 44

The sound ratings shown are loudness values in hemispherical sones at 1.5 m (5 ft) in a hemispherical free eld calculated per AMCA Standard 301. Values are shown for:

Installation Type B: free inlet hemispherical sone levels.

Page 10

Performance Data

TIB360 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

RPM

6885 6185 5349 3962

476

0.50 10.70 0.69 10.10 0.82 9.60 0.86 9.40

7464 6827 6119 5090 2898

516

0.64 12.20 0.84 11.60 1.00 11.10 1.09 10.60 0.96 10.20

8535 7993 7430 6698 5732 4124

590

0.96 15.50 1.19 17.30 1.39 14.60 1.54 13.90 1.64 13.40 1.56 13.30

9403 8901 8383 7816 7076 6168 4682

650

1.28 18.00 1.53 23 1.77 17.20 1.96 16.30 2.11 16.00 2.19 15.70 2.11 15.60

10764 10309 9884 9442 8909 8277 7538 6580 5114

744

1.92 22 2.21 32 2.50 21 2.74 21 2.96 19.90 3.13 19.80 3.26 19.10 3.29 19.50 3.12 19.20

12761 12364 12026 11635 11267 10852 10388 9829 9206 8524 7639 6423 1997

882

3.20 30 3.55 48 3.89 36 4.23 28 4.51 28 4.78 27 5.01 26 5.21 26 5.37 25 5.47 25 5.47 26 5.28 25 3.00 19.70

14613 14266 13950 13663 13299 12975 12661 12242 11843 11352 10809 10265 9631 8846 7905 6609

1010

4.80 38 5.20 64 5.60 54 5.98 41 6.37 35 6.70 35 7.01 34 7.31 33 7.56 33 7.78 32 7.99 32 8.13 31 8.23 31 8.22 32 8.10 32 7.70 31

TIB365 PERFORMANCE DATA

CFM and Sones vs. Static Pressure

0.000” 0.250” 0.500” 0.750” 1.000” 1.250” 1.500” 1.750” 2.000” 2.250” 2.500” 2.750” 3.000” 3.250” 3.500” 3.750” 4.000”

RPM

BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone BHP Sone

8929 7552 5251

390

0.61 9.60 0.77 8.80 0.83 8.30

9685 8414 6780

423

0.78 11.40 0.96 10.50 1.08 9.30

11083 10015 8764 6758

484

1.16 15.30 1.37 14.20 1.56 12.70 1.59 12.10

12206 11245 10184 8851 5883

533

1.55 18.40 1.78 18.60 2.00 16.70 2.16 15.30 1.94 15.20

13970 13130 12211 11249 10041 7826

610

2.33 23 2.59 27 2.84 22 3.08 20 3.24 19.10 3.10 19.30

16582 15899 15165 14350 13556 12587 11395 9456 3917

724

3.89 31 4.21 39 4.52 29 4.81 28 5.09 26 5.32 25 5.43 24 5.23 25 3.05 23

18964 18408 17725 17079 16362 15685 14869 13971 12834 1117 4 7234

828

5.82 39 6.21 51 6.54 42 6.89 36 7.22 35 7.55 33 7.83 32 8.04 31 8.13 30 7.92 31 6.19 30

The sound ratings shown are loudness values in hemispherical sones at 1.5 m (5 ft) in a hemispherical free eld calculated per AMCA Standard 301. Values are shown for:

Installation Type B: free inlet hemispherical sone levels.

Page 11

TERMS AND CONDITIONS OF SALE

ACCEPTANCE All orders and sales are subject to

written approval and acceptance by an executive offi cer of Acme Engineering & Manufacturing Corporation at Muskogee, Oklahoma, (the "Company") and are not binding on the Company until so approved.

DELIVERY All shipping and delivery dates are esti mated only. No delays in delivery will subject the Company to any costs, damages or fees for late deliv ery. Delivery of the products herein specified shall be made F.O.B. point of shipment, unless otherwise stated. The Company shall not be liable for delay due to causes beyond its reasonable control, such as Acts of God, acts of the purchaser, acts of civil or military authorities, priorities, fires, strikes, floods, epidemics, war, riots, delays in transportation, car shortages, and inability, due to reasons beyond its reasonable control, to obtain necessary labor, material, or manufacturing facilities. In the event of such a delay, the date of deliv ery shall be extended for a period equal to the time lost by reason of the delay.

TERMS OF PAYMENT If, in the judgment of the Com pany, the financial condition of the purchaser at any time does not justify continuation of manufacture or shipment on the terms of payment specified, the Com pany may require full or partial payment in advance.

Pro rata payments shall become due as shipments are made. Each shipment or delivery shall constitute a separate sale, and the default of any shipment or deliv ery shall constitute a separate sale, and the default of any shipment or delivery shall not vitiate the contract as to other shipments or deliveries.

SALES AND SIMILAR TAXES The Company’s prices do not include sales, use, excise, or similar taxes. Consequently, in addition to the price specified herein, the amount of any present or future sales, use, excise, or other similar tax applicable to the sale of the product herein shall be paid by the Purchaser, or in lieu thereof

WARNING Acme products are designed and manufactured to provide reliable performance but they are not guaranteed to be 100% free of defects. Even reliable products will experience occasional failures and this possibility should be recognized by the Purchaser and all End Users. If these products are used in a life support ventilation system where failure could result in loss or injury, the Purchaser and all End Users should provide adequate back-up ventilation, supplementary natural ventilation or failure alarm sys tem, or acknowledge willingness to accept the risk of such loss or injury.

WARNING DO NOT use in HAZARDOUS ENVIRONMENTS where fan’s electrical system could provide ignition to combustible or flammable materials unless unit is specifi cally built for hazardous environments. Comply with all local and national safety codes including the National Electrical Code (NEC) and National Fire Protection Act (NFPA).

CAUTION Guards must be installed when fan is within reach of personnel or within eight (8) feet (2.5 m) of working level or when deemed advisable for safety.

DISCLAIMER The Company has made a diligent effort to illustrate and describe the products accurately in all Company literature; however such illustrations and descriptions

are for the sole purpose of identification and do not express or imply any warranty.

the Purchaser shall provide the Company with a tax

exemption certificate acceptable to the taxing authori ties.

CANCELLATION Any contract resulting from the Pur chaser’s order may be canceled by the Purchaser only

by negotiations and upon payments of reasonable can cellation charges which will take into account expenses

already incurred and commitments made by the Com pany.

DESIGN CHANGES The Company reserves the right to make changes in design, improvements and addi tions in and to its products any time without imposing any liability or obligations to itself to apply or install the same in any product manufactured by it.

TITLE The title and right of possession of the products sold herein shall remain with the Company and such

products shall remain personal property until all

payments herein (including deferred payments whether evidenced by notes or otherwise) shall have been made in full in cash and the Purchaser agrees to do all

acts necessary to perfect and maintain such right and title in the Company.

PRICE ADJUSTMENTS Prices are subject to change

upon notice by the Company. Prices on existing or ders are subject to surcharges in the event of cost in creases of metals and transportation. All complete component accessory material manufactured by others

and furnished with the Company’s products such as motors, drives, vibration equipment, controls or other completely assembled component structures, are sub ject to adjustment to the price at time of shipment re gardless of the date of original order entry.

SAFETY ACCESSORIES The Company manufactures products designed to serve multiple applications and offers a wide range of safety equipment, including guards and other devices, as may be required to meet

customer specifications. Without exception, the Com

pany recommends that all orders include applicable

safety devices. Products ordered without applicable safety devices is clearly the responsibility of the Pur

chaser. Further, the Purchaser warrants that it has de

termined and acquired any and all safety devices re

quired for products sold by the Company. Weather

covers and guards for motor and V-belt drives, cou

plings, shafts and bearings, along with inlet and outlet

screens, are optional accessories noted in the price list.

GOVERNING LAW The rights, obligations and reme

dies of Purchaser and the Company, the interpretation of these terms and conditions and the sale of products by the Company shall be governed by Oklahoma law, without regard to any principles of conflict of laws.

ARBITRATION Any dispute arising under or in con nection with these terms and conditions or the sale of products shall be settled by binding arbitration admin istered by the American Arbitration Association under its Commercial Arbitration Rules, and judgment on the award rendered by the arbitrator may be entered in any court having jurisdiction thereof. The dispute shall

be resolved by one neutral arbitrator who shall have no

affiliation with either Purchaser or the Company and shall be selected by the American Arbitration Associa tion office in Dallas, Texas. The arbitration proceed ings shall be held in Muskogee, Oklahoma.

APPLICABLE DOCUMENTS The agreement be

tween the Company and the Purchaser relating to the

products includes these terms and conditions of sale, any applicable installation and maintenance instruc tions provided by the Company and any terms appear ing on the Company’s quotation, sales order acknowl edgment and invoice.

LIMITED WARRANTY

WARRANTY AND DISCLAIMER: the Company ex-

tends this limited warranty to the original purchaser and warrants that products supplied by the Company, shall be free from original defects in workmanship and materials for two years from date of shipment (except for the warranty periods noted for products listed be low), provided same have been properly handled, stored, installed, serviced, maintained and operated. This warranty shall not apply to products which have been altered or repaired without the Company’s ex press authorization, or altered or repaired in any way so as, in the Company’s judgment, to affect its perfor mance or reliability, nor which have been improperly installed or subjected to misuse, negligence, or acci dent, or incorrectly used in combination with other sub stances. The Purchaser assumes all risks and liability for results of use of all products.

Evaporative cooling pads are warranted to be free of defects in materials and workmanship for a period of two years from date of shipment provided same have been properly handled, stored, installed, serviced, maintained and operated; and further, not subjected to excessive heat, corrosive agents or chemicals, or me chanical abuse that may cause tearing, crushing or un due deterioration, nor used on a system or in a manner other than that for which it was designed as explained in the product literature.

The following products are warranted to be free of de fects in materials and workmanship for the periods shown from date of shipment: Acme’s exclusive du plex split pillow block bearings and shaft five years, belts one year, Polyethylene tubing 90 days, AIR40 Heater warranty one year, AIR40 Emitter warranty three years and DDP fan lifetime warranty on its pro peller, cone, and housing.

LIMITATION OF REMEDY AND DAMAGES: All claims under this warranty must be made in writing and delivered to P. O. Box 978, Muskogee, Oklahoma, 74402, within 15 days after discovery of the defect and prior to the expiration of two years from the date of shipment by the Company of the product claimed de fective, and Purchaser shall be barred from any

ACME ENGINEERING AND

MANUFACTURING CORPORATION

P.O. Box 978

Muskogee, Oklahoma 74402

Telephone 918/682-7791

Fax 918/682-0134

www.acmefan.com

Member Air Movement and Control Association International, Inc. July 2013 C198A

remedy if Purchaser fails to make such claim within such period.

Within 30 days after receipt of a timely claim, the Company shall have the option either to inspect the product while in Purchaser's possession or to request Pur

chaser to return the product to the Company at Pur

chaser's expense for inspection by the Company. The Company shall replace, or at its option repair, free of charge, any product it determines to be defective, and

it shall ship the repaired or replacement product to

Purchaser F.O.B. point of shipment; provided, how

ever, if circumstances are such as in the Company’s

judgment to prohibit repair or replacement to remedy

the warranted defects, the Purchaser's sole and exclu

sive remedy shall be a refund to the Purchaser of any

part of the invoice price, paid to the Company, for the defective product or part.

The Company is not responsible for the cost of re moval of the defective product or part, damages due to removal, or any expenses incurred in shipping the product or part to or from the Company’s plant, or the installation of the repaired or replaced product or part.

The warranties set forth above do not apply to any

components, accessories, parts or attachments manu factured by other manufacturers; such being subject to the manufacturer’s warranty, if any. To the extent not prohibited by the manufacturer’s warranty, the Com

pany shall pass through to Purchaser such manufac

turer’s warranty.

THE COMPANY’S WARRANTY IS IN LIEU OF ALL

OTHER WARRANTIES, EXPRESS OR IMPLIED, ARISING BY LAW OR OTHERWISE, INCLUDING

WITHOUT LIMITATION THE IMPLIED WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR A PAR TICULAR PURPOSE, WHICH ARE HEREBY EX PRESSLY DISCLAIMED AND WAIVED. THIS WAR RANTY CONSTITUTES THE COMPANY’S SOLE AND EXCLUSIVE WARRANTY FOR DEFECTIVE GOODS AND PURCHASER’S SOLE AND EXCLU SIVE REMEDY FOR DEFECTIVE PRODUCTS.

No employee, agent, dealer, or other person is authorized to give any warranties on behalf of the Company or to assume for the Company any other liability in connection with any of its products except in writing and signed by an officer of the Company.

REPLACEMENT PARTS If replacement parts are ordered, purchaser warrants that the original com ponents in which these replacement parts will be placed are in satisfactory working condition, and

when said replacement parts are installed, the resultant installation will operate in a safe manner, at speeds and temperatures for which the original product was purchased.

TECHNICAL ADVICE AND RECOMMENDATIONS,

DISCLAIMER: Notwithstanding any past practice or dealings or any custom of the trade, sales shall not in clude the furnishing of technical advice or assistance or system design. Any such assistance shall be at the Company’s sole option and may be subject to addi

tional charge.

The Company assumes no obligation or liability on ac

count of any recommendations, opinions or advice as to the choice, installation or use of products. Any such recommendations, opinions or advice are given and shall be accepted at Purchaser's and End User's risk and shall not constitute any warranty or guarantee of

such products or their performance.

LIMITATION OF LIABILITY The cumulative liability of the Company to the Purchaser and any other persons for all claims in any way relating to or arising out of the products, including, but not limited to, any cause of ac tion sounding in contract, tort, or strict liability, shall not

exceed the total amount of the purchase price paid for

those products which are the subject of any such claim. This limitation of liability is intended to apply

without regard to whether other provisions of this

agreement have been breached or have proven inef

fective even if the Company has been advised of the possibility of such claims or demands. In no event shall the Company be liable to the Purchaser or any other person for any loss of profits or any incidental, special, exemplary, or consequential damages for any claims or demands brought by the Purchaser or such

other persons.

INDEMNITY The Company’s maximum liability to Pur

chaser and to any end user is as set forth above. The Company makes no warranty to anyone for any prod

ucts not manufactured by the Company and shall have

no liability for any use or installation of any products (whether manufactured by the Company or other man ufacturers) not specifically authorized by this sale. Purchaser acknowledges various warnings by the Company regarding the products and its installation and use. If the Company incurs any claims, lawsuits, settlements, or expenses (including attorney fees) for any loss, injury, death or property damage including, but not limited to, claims arising out of the Purchaser’s

or any end user’s installation or use of the products, the Purchaser shall indemnify and hold the Company harmless.

Acme Engineering TIB100 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
