INSTALLATION & MAINTENANCE INSTRUCTIONS

Models PNURG, PNURF, USNURG, and USNURF

RECEIVING AND INSPECTION

Immediately upon receipt of a shipment, carefully inspect for damage and shortage. Turn the impeller by hand to see that it turns freely and does not bind. If any damage and/or shortage is detected or suspected, the carrier must be asked to conduct an inspection. The consignee's represen tative should not accept shipment without a notation on the delivery receipt indicating items not delivered or apparent extent of damage.

When a shipment is opened and damage is found which was not evident externally (concealed damage), it is man datory that the consignee request an immediate inspection by the carrier. Report damage to the carrier within 15 days. Failure to report damage within the above time limit will cause rejection of a claim.

HANDLING

When handling fans and their accessories, always use equipment and methods that will not cause damage. Fans should be lifted using slings and padding or spreaders to avoid damage.

CAUTION! Always make sure that all lifting and handling equipment and techniques conform to current safety standards.

Avoid lifting fans in a way that will bend or distort fan parts. Never pass slings or timbers through the orifices of fan.

CAUTION! Do not lift by the fan hood. Fans with special coatings or paints must be protected in handling to prevent damage.

STORAGE

Fans are protected against damage during shipment. If they cannot be installed and put into operation immediately upon receipt certain precautions are necessary to prevent deterioration during storage. Responsibility for integrity of fans and accessories during storage must be assumed by the user. The manufacturer will not be responsible for dam age during storage. These suggestions are provided solely as a convenience to the user, who shall make his own deci sion as to whether to use any or all of them.

INDOOR: The ideal storage environment for fans and ac cessories is indoors, above grade, in a low humidity atmo sphere which is sealed to prevent the entry of blowing dust, rain, or snow. Temperatures should be evenly maintained at between 70°F and 105°F (wide temperature swings may cause condensation and "sweating" of metal parts). Win dows should be covered to prevent temperature variations caused by sunlight. Provide thermometers and humidity in dicators at several points and maintain the atmosphere at 40% relative humidity, or lower.

It may be necessary to use trays of renewable desiccant or portable dehumidifier to remove moisture from the air in the storage enclosure.

Thermostatically controlled portable heaters (vented to out doors) may be required to maintain even temperatures in

side the enclosure.

CAUTION! Provide fire extinguishers, or fire alarms, or telephone to protect building and equipment against fire damage. Be sure that building and storage practices meet all local, state and federal fire and safety codes.

The following fans or accessories must be stored indoors,

in a clean dry atmosphere:

a. Propeller Wall Fans not in Wall Housings.

b. Any fan which is protected by a cardboard carton.

c. Motors dismounted from fans.

d. Spare wheels or propellers.

e. The belts, sheaves, bushings and other parts

when not mounted on fan.

f. Boxes, bags or cartons of hardware.

g. Curbs

h. Dampers Remove any accumulations of dirt, water, ice or snow and wipe dry before moving indoor storage. Allow cold parts to reach room temperature to avoid “sweating” of metal parts. Open boxes or cartons. Remove any accumulated mois ture; if necessary use portable electric heaters to dry parts and packages. Leave coverings loose to permit air circula tion and to permit periodic inspection.

Rotate wheels or propellers by hand to distribute bearing grease over the entire bearing surfaces.

Store at least 3 ½” off the floor on wooden blocks covered with moisture proof paper or polyethylene sheathing. Pro vide aisles between parts and along all walls, to permit air circulation and space for inspection.

OUTDOOR: Fans designed for outdoor use may be stored

outdoors, if absolutely necessary. The storage area should

be reasonably level and drained or ditched to prevent accu

mulation of water. Fencing and lighting for security are de

sirable. Roads or aisles for portable cranes and hauling

equipment are needed. Consider the use of drift fencing to minimize accumulation of blowing snow or dirt.

The following fans may be stored outdoors, if dry indoor storage space is not available:

a. Fans intended for outdoor use that are crated in

wood.

b. Wall fans where installed in wall housings.

Page 2

All fans must be supported on wooden blocks or timbers above water or normal snow levels. Provide enough block ing to prevent settling into soft ground. Fans should be set in place using the directional arrow markings on the crate as a guide.

Locate pieces far enough apart to permit air circulation, sun light, and space for periodic inspection. Place all parts on their supports so that rain water will run off, or to minimize water accumulation. Do not cover parts with plastic film or tarps-these cause condensation of moisture from the air passing through heating and cooling cycles.

Fan wheels and propellers should be blocked to prevent spinning caused by strong winds.

INSPECTION AND MAINTENANCE DURING STORAGE

Inspect fans and accessories at least once per month, while in storage. Log results of inspection and maintenance per formed. A typical log entry should include the following:

a. Date

b. Inspector’s Name

c. Name of Fan

d. Location

e. Condition of Paint or Coating

f. Is moisture present?

g. Is dirt accumulated?

h. Corrective steps taken?

If moisture or dirt accumulations are found on parts, the source should be located and eliminated. Fans should be rotated at each inspection by hand ten to fifteen revolutions to redistribute the motor and bearing lubricant.

If paint deterioration begins, consideration should be given to touch-up or repainting. Fans with special coatings may require special techniques for touch-up or repair.

Machined parts coated with rust preventive should be re stored to good condition promptly if signs of rust occur. The most critical items are pulleys, shafts and bearing locking collars. At the first sign of rusting on any of the above parts, remove the original rust preventive coating with petroleum solvent and clean lint-free cloths. Polish any remaining rust from surfaces with crocus cloth or fine emery paper and oil. Do not destroy the continuity of the surfaces. Wipe clean with lint-free cloths and recoat surfaces evenly and thor oughly with Tectly 506 (AshlandOil Company) or equal. For hard to reach internal surfaces or for occasional use, con sider using Tectly 511M RustPreventive or WD40 or equal.

REMOVING FROM STORAGE

As fans are removed from storage to be installed in their fi

nal location, they should be protected and maintained in similar fashion, until the fanequipment goes into operation.

CAUTION! This unit has rotating parts and safety

INSTALLATION

precautions should be exercised during installation, operation and maintenance.

WARNING! Do not use in hazardous environments where the fan's electrical system could provide ignition to combustible or flammable materials, unless the unit is specifically built for hazardous environments.

WARNING! If gases, other than clean air, are to be exhausted using the fan, then the user bears the

responsibility of determining that the fan is appropriate and safe for the application.

COMMERCIAL KITCHEN EXHAUST APPLICATIONS:

Ventilators should be installed in accordance with the requirements of the National Fire Protection Association Bulletin NFPA96 “Vapor Removal From Cooking Equipment” taking specific note of the following:

(a) Ducts terminating into the base of an up-discharge

exhaust fan shall be constructed of carbon steel not less than 16 MSG (1.6 mm) and extend a minimum of 18" (457 mm)above the roof surface.

(b) Air velocity through the duct shall not be less than

1500 FPM (7.620 m/s).

maintained between the exhaust discharge and the roof surface. (To comply Sizes 120 through 300 require 18" [457 mm] roof curb.)

(d) Fan Discharge shall be a minimum of 10 feet from

the fresh air intake.

5. GREASE TROUGH ACCESSORY: A container to collect residue grease should be located under the grease drain on the ventilator to prevent accumulation of grease on the roof surface. An accessory grease trough that attaches to the curb is available from the manufacturer at extra cost. Containers should be

serviced at regular intervals to prevent overflow. Curb Hinges are also available as an optional accessory.

Installation instructions are shipped with the accessories.

Page 2

Page 3

6. FAN INSTALLATION:

(a) WALL MOUNT (120-245): If wall mounted,

provide an opening sufficient for enclosing the curb cap. Securely fasten to the wall through the cap. Fan breather tube should be on the side of the fan

at a 90° angle from vertical. A wall mounting adapter option is available from the manufacturer. Refer to Form 613121 included with the adapter for instructions. (see figure 1)

Fig. 1

(b)

ROOF MOUNT (120-490): Roof exhausters should be mounted on a roof curb suitable for the purpose, either field fabricated or prefab type. Prefab type curbs are available as an accessory at extra cost from the manufacturer. The fan should rest on the curb as level as possible. When curb is not level (slightly pitched on flat roofs) the down spout drain fitting should be located on the lowest side of the curb. Securely fasten the exhauster to the curb using a minimum of 4 lag bolts.

CAUTION! Guards must be installed when the fan is within reach of personnel or within eight (8) feet (2.5 m) of working level or when deemedadvisable for safety.

to be moved vertically. Make sure all bolts are securely tightened before applying electrical power.

For 245 through 490 with duplex split pillow block bearings, three dimensional adjustment is also provided. Horizontal movement is allowed by loosening the bolts holding the bearing base (18) to the bottom of the motor enclosure base (10). Re-tighten bolts after adjusting. Vertical adjustment is allowed by loosening the bolts in the bearing cap (22) which allow the entire bearing housing to be moved vertically.

9. MOTOR - BELT TENSION ADJUSTMENT: For sizes 120 through 200, the motor is mounted directly to the slots on the Drive Base using the four motor mount bolts. Belt tensioning is accomplished by sliding the motor away from the fan pulley and then tightening the motor mount bolts and nuts. Some sizes use motor rails for certain motors.

For sizes 245 through 490, the motor is mounted on a separate motor base. Belt tensioning is accomplished by sliding the motor base away from the fan pulley and then tightening the motor base bolts and nuts.

Belt should depress its width when pressed firmly inward at midway point between the pulleys.

10.

CAUTION! Before proceeding, make sure electrical service to fanis locked in the “OFF” position. Run wires through the internal wiring post to the motor ( or to the disconnect switch). (Restaurant exhaust fans have wires run through the wiring post to the exterior of the windband.)

11. All wiring should be in accordance with local ordinances and the National Electric Code.

8. IMPELLER-ORIFICE ADJUSTMENT: Turn centrifugal impeller by hand to make sure it rotates freely. If the impeller hits the orifice, adjust as follows:

For 120 through 200 with duplex split pillow block bearings, three dimensional adjustment is provided. Do not loosen all bolts at once. Proceed with adjustments in one direction at a time to minimize difficulty. Horizontal movement for adjustment is allowed by loosening the two bolts connecting the drive brace (4) to the top and bottom flange of the drive base (3) and by loosening the four bolts, two at each end, of the drive base (3). Horizontal movement in the other direction is allowed by loosening the four bolts securing the bearing caps (6) to the drive base (3). After loosening the appropriate bolts, the impeller can be repositioned to insure that it does not strike the orifice. Vertical adjustment is allowed by loosening the set screw on the impeller hub which allows the impeller

Page 3

12. WARNING! Check voltage at the fan to see if it corresponds with the motor nameplate. High or low voltage can seriously damage the motor. Extra care should be taken when wiring to motors since improper connections will damage the motor and void the motor warranty.

13.

WARNING! Do not operate at speeds higher than shown in the catalog for this equipment. Apply power momentarily and compare the impeller rotation with the directional arrow. Operation in the wrong direction will deliver air but may overload the motor to the extent of blowing fuses or overload protection and could seriously damage the motor. In the case of three phase motors, the direction can be changed by interchanging any two of the three motor leads. In the case of single phase motors, the reversing instructions will appear on the wiring diagram in the motor wiring compartment or on the motor.

Page 4

MAINTENANCE

1. Under normal usage, no spare parts are expected to be required for one year of operation. Recommended spare parts are shown on pages 5 and 6.

CAUTION! Before proceeding, make sure electrical service to fan is locked in the “OFF” position.

WINDMILLING: Even when the powersupply is locked out, fans may cause injury or damage if the impeller is subject to “windmilling” which is the turning of the impeller and drive components due to a draft in the system. To guard against this hazard, the impeller should be secured to physically restrict rotational movement.

3. Units with duplex split pillow block bearings are pre-lubricated and do not require relubrication. Units with unitary pillow block bearings have grease fittings and, under normal operating conditions, will need not relubrication for 3 to 5 years. If relubrication is required, use a grease conforming to NLGI No. 2. CAUTION! Lubricating bearings with a high pressure gun can blow bearing seals and overfill the bearing with grease. This condition can result in excessive churning and overheating. For normal operating conditions it is standard practice to fill 30% of the bearing void with grease. Do not over lubricate.

4. Motor bearings are pre-lubricated. Consult information printed on the motor for lubrication instructions.

5. REGULAR MAINTENANCE: Determined by the condition of the air passing through the fan, regularly scheduled inspection of all fan parts establishes a good maintenance routine. When the air is clean, maintenance can be as infrequent as once a year. When air is contaminated with grease vapors from cooking operations, maintenance may be required as often as once a week. Regular maintenance should include inspection and cleaning of all fan parts to remove all grease and other foreign particles from the entire impeller surface including blades and front and back plates.

WARNING! Care must be taken when cleaning the impeller to remove grease and other foreign particles. Damage to the impeller can occur if it is hit or if pressure is applied causing the impeller to be distorted. Either case can cause serious vibration and damage to the fan.

SET SCREW TIGHTENING SCHEDULE

1. Before initial operation of the fan, tighten set screws according to the procedure outlined below.

2. After 500 operating hours or three months, whichever comes first, tighten set screws to the full recommended torque.

3. At least once a year, tighten set screws to the full recommended torque.

PROCEDURE FOR TIGHTENING SET SCREWS IN

BEARINGS AND HUBS

One Set Screw Application

Using a torque wrench, tighten the set screw to the torque recommended in Table 1.

Two Set Screw Application

1. Using a torque wrench, tighten one set screw to half of the torque recommended in Table 1.

2. Tighten the second set screw to the full recommended torque.

3. Tighten the first set screw to the full recommended torque.

Table 1. Recommended Tightening Torque

for Set Screws

Set Screw Diameter Torque (in-lbs)

#10 35

1/4 80

5/16 126

3/8 240

7/16 384

1/2 744

9/16 1080

5/8 1500

3/4 2580

7/8 3600

1 5400

VARIABLE FREQUENCY

DRIVES AND MOTORS

There are occasions when a Variable Frequency Drive (VFD) will cause poor motor performance and possible damage. To avoid these problems, the Company recom mends the following:

1. Select compatible motor and VFD converter; if

possible, the motor and the converter should be from the same manufacturer or at least the con

verter selected should be recommended by the motor manufacturer.

2. A motor shaft grounding system should be used to prevent motor bearing damage from eddy currents.

NOTE: The Company will not honor motor warranty claims if the customer fails to follow these recommen dations.
