Belt Drive In-Line Airfoil Centrifugal Exhauster
Model 2100 Series
2100 HC1 Class 1 Horizontal Standard Fan 2100 VC1 Class 1 Vertical Standard Fan
2100 HC2 Class 2 Horizontal Standard Fan 2100 VC2 Class 2 Vertical Standard Fan
2100 HIGC1 Class 1 Horizontal Restaurant Grease Fan 2100 VIGC1 Class 1 Vertical Restaurant Grease Fan
2100 HIGC2 Class 2 Horizontal Restaurant Grease Fan 2100 VIGC2 Class 2 Vertical Restaurant Grease Fan
2100 HSEC1 Class 1 Horizontal Smoke Exhaust Fan 2100 VSEC1 Class 1 Vertical Smoke Exhaust Fan
2100 HSEC2 Class 2 Horizontal Smoke Exhaust Fan 2100 VSEC2 Class 2 Vertical Smoke Exhaust Fan
2100 RUC1 Class 1 Roof Exhaust Fan 2100 RUC2 Class 2 Roof Exhaust Fan
Includes the following Model/Options
Model 2100 is a belt drive, tubular centrifugal exhauster with
the motor, drives and bearings located outside the airstream.
The 2100 is designed to operate in arrangement 9H (horizontal)
and 9V (vertical) and available in both Class 1 and Class 2. The
tubular design is furnished with mounting anges on both ends
for easy installation.
2100
Standard Construction Features
Class 1 and 2 Rated x x x x
Heavy Gauge Rolled Steel x x x x
Access Door x x x x
Steel Centrifugal Backward Inclined Wheel x x x x
Unitary Pillow Block Bearings x x x x
Dual Fixed or Variable Drives for life safety x
Variable Pitch Drives x x x
Roof Mounted Upblast x
1-1/2” Drain x
UL705 x x x x
UL762 Grease Rated
U.L. Listed “Power Ventilator for Smoke
Tubular Centrifugal
Control Systems”
AMCA Air and Sound x x x x
Listed models are available in all sizes and performance ranges.
UL762 Grease Rated fans are available on all IG models. Class 2 fans require special
▀
request.
2100SE
(H/V)
(H/V)
x
2100IG
(H/V)
▀
2100RU
Construction Features
Housing
• Heavy gauge, rolled steel construction and
continuously welded to eliminate air leakage
• Standard charcoal baked enamel with UV
inhibitors
• Multiple aerodynamic conversion vanes,
provides rigid support for outer casing
• Pre-punched ange at each end for ease of mounting
• Inlet and outlet diameters shall be identical to accommodate a
single duct size
• Flush bolted access door for servicing
• 8 heavy duty, steel mounting brackets with 4 interchangeable
mounting feet
• Allow for rotation of the motor position to 90°/180°/270°/360°
• Dichromate plated, steel fasteners
Wheel
• Centrifugal, backwardly inclined type with die-formed airfoil
blades for maximum efciency and quiet operation
• Precision balanced for smooth trouble free operation
• The dynamically balanced impellers for our products are
balanced to the grade G6.3 as described in the standards:
◦ ANSI/AMCA 204 “Balance Quality and Vibration Levels for
Fans”
◦ ISO 14694 “Fans – Specications for balance quality and
vibration levels”
• Charcoal baked enamel UV inhibitors
Bearings
• Double-sealed unitary pillow block bearings
• Rated at L50 life of 200,000 hours
• 2 year limited warranty
• With external lube lines ttings
Shaft
• Corrosion-resistant coated, steel shaft
• Sized so that rst critical shaft speed is at least 25% over the
max operating speed
For submittals, detailed air and sound information,
available options and accessories, please go to
FANtastic!® Commercial www.acmefan.com
U.L. 705 Listed
U.L. 762 Listed
Acme Engineering & Manufacturing Corporation certies
that the models shown herein are licensed to bear the
AMCA seal. The ratings shown are based on tests
and procedures performed in accordance with AMCA
Publication 211 and AMCA Publication 311 and comply
with the requirements of the AMCA Certied Ratings
Program.
Motor
• Continuous duty motors with sealed ball bearings
• Motors are located outside the airstream
• Adjustable motor base maintains positive belt tension
Drive Assembly
• Cast iron variable pitch drives sized for 150% of fan
horsepower
• Static free, oil, and heat-resistant belts
Options/Accessories
• Aluminum Wheel
• Spark Resistant Construction
(AMCA B)
• Coatings
• Disconnect Switch
• Drain 1.5”
• Inlet and Outlet Companion
Flanges
• Inlet and Outlet Guards
• Isolators
• Motor cover/belt guard or belt
guard
Belt Drive In-Line Airfoil Centrifugal Exhauster
Model 2100 Series
2100 DIMENSIONS
Est. Wt.
Model A B C D E F G H J K L
15 23.31 23.38 30.00 19.22 14.69 11.56 20.19 21.88 10.02 8 .63 180 200
18 28.31 27.75 36.00 24.25 16.81 13.75 24.56 27.75 11.58 8 .63 240 260
20 31.00 30.13 37.00 26.94 18.13 15.00 26.92 28.63 12.44 8 .63 285 330
22 34.56 33.13 39.00 30.50 19.63 16.50 29.95 31.63 13.50 16 .63 345 365
24 38.06 36.19 42.00 32.35 21.63 18.00 32.97 34.75 15.52 16 .63 425 450
27 41.88 39.56 44.00 36.22 23.38 19.75 36.34 38.00 16.72 16 .63 525 550
30 46.56 43.56 46.00 41.85 25.25 21.63 40.38 42.00 18.14 16 .63 660 685
33 51.19 47.69 51.00 45.47 27.38 23.75 44.41 46.13 19.57 16 .63 820 860
37 56.63 53.44 54.00 50.62 29.63 26.06 49.13 51.69 21.45 16 .75 1035 1075
40 62.50 58.56 57.00 55.66 32.25 28.63 54.26 56.81 24.58 16 .75 1390 1460
45 69.06 65.25 63.00 62.09 35.88 31.75 59.98 63.00 26.64 24 .75 1815 1890
49 76.13 71.44 66.00 69.09 38.81 34.69 66.05 69.19 28.84 24 .75 2275 2390
Dimensions are shown in inches.
Weights are shown in pounds.
CL/1
Est. Wt.
CL/2
Tubular Centrifugal
2100RU
Model A B C D E F
2115RU 26.00 23.00 23.00 10.00 56.00 32.00 250
2118RU 30.00 26.10 28.31 10.00 64.41 32.00 320
2120RU 32.00 26.10 31.00 10.00 67.10 32.00 375
2122RU 36.00 38.08 34.56 10.00 82.64 43.14 435
2124RU 38.00 32.10 38.06 10.00 80.16 38.00 525
2127RU 42.00 38.40 41.88 10.00 90.28 44.20 635
2130RU 46.00 38.40 46.56 10.00 94.96 44.20 770
2133RU 50.00 44.40 41.00 10.00 96.60 50.20 940
2137RU 56.00 50.40 56.63 10.00 117.03 56.20 1165
2140RU 60.00 52.96 62.50 10.00 125.46 69.31 1530
2145RU 70.00 58.09 69.06 10.00 137.15 79.15 1965
2149RU 78.00 58.09 76.03 10.00 144.12 79.15 2435
Dimensions are shown in inches.
Weights are shown in pounds.
2100RU DIMENSIONS
