TB150N001F2
byAcme Electric
Catalog ID:TB150N001F2
Product Details
General
ICT .150KVA 120X240-12/24 F2
Encapsulated design protects core
& coil assembly from potentially
damaging contaminants
Constructed with high quality
silicon steel lamination to minimize
core losses and increase efficiency
Integrally molded terminal blocks
with isolation barriers to prevent
arc over
Fuse blocks kits available and
easily adaptable
Series-parallel connecting links
save wiring and labor costs
Page 2
9/14/2020 TB150N001F2 | Acme Electric
Application Acme’s TB Series Industrial Control Transformers
are especially designed to accommodate the
momentary current inrush caused when
electromagnetic components are energized...
without sacrificing secondary voltage stability
beyond practical limits.The transformer’s
windings and internal terminations are encased
in a durable thermoplastic end cap, protecting
them from potentially damaging moisture, dirt
and other ambient contaminants. Acme’s TB
Series transformers are dry-type, step-down
transformers with the secondary control circuit
isolated from the primary line circuit to assure
maximum safety.
Color Black
Secondary Voltage 12/24 V
UPC 047503008744
Dimensions
Dimensions 4.27 in x 3.75 in x 4.67 in
Height 4.67 in
Length 4.27 in
Weight 6.7 lb
Width 3.75 in
Electrical Ratings
Frequency Rating 50/60 Hz
Primary Voltage 120 X 240 V
Logistics
Carton Quantity 1
Pallet Quantity 120
