ACL INC.
Architectural Cathode Lighting, Incorporated
STREAMLITE
C U T S H E E T
FEATURES:
New and improved S treamlite 2 .0 offers a creative w ay t o illuminate an interior s pace.
ACL's new threaded eCVR with no visible fasteners make this luminaire even more s leek
and minimalistic giving the impres s ion of light floating in space. Streamlite 2.0 Cold
Cathode lamps have end t o end illumination, and are available in s everal s tandard lengths
and colors. The armature mounted lamps include various methods for integrating the
pow er supply. S treamlite 2 .0 c an be sus pended from c eilings , mounted to w alls, installed
in coves, frees tanding and more. The luminaire offers unlimited poss ibilities that are both
classic and timeless.
The Art and Science of Light
SPECIFICATIONS:
mod el: SL01/ SL02/ SL03
primary power: 120V, 277V
Comp lia n ce: UL Listed
control: Dimming Compatible
finish: Clear Anodized Aluminum
dimensions: 4'6", 5'6", 6'0", 6'6"
lamp color(s): See color chart on Details Sheet
update: August 23, 2012
SL DR
Product Model Power Supply Environment Color (1) Primary Dimming (2) Lamp Dimension
Streamlite S01 - Armature Mount e50 - Energy Saver DR - Dry See Color Chart 120V 2 - 2 Wire 4' to 6'6"
C old Ca th od e S02 - Ceiling Mount e 100 - Standard O utput 277V 3 - 3 Wire
S03 - Remote Mount e200 - High Output
(1) For multiple colors place a comma after each selection. (2) Reverse phase low-voltage electronic dimmers are recommended for optimal performance.
4' Cable and power drop standard. Can be field adjusted. For custom length contact ACL.
Specifications subject to change without notice. 073112
Project Name Qty Date
S P E C I F I C A T I O N C O D E :
