Automation Components, Inc.

BBPBGD

TEMPERATURE | TRANSMITTERS | IMMERSION

IMMERSION

Stainless Steel Immersion, Transmitters

The ACI Transmitter Immersion Series features a two-wire, 4 to 20 mA loop powered output signal with optional three-wire voltage output signal available. All transmitters include Zero and Span adjustments for eld calibration and are calibrated using NIST Certied Calibration equipment. We recommend the use of an 18 to 22 AWG shielded cable for all temperature transmitter installations to keep noise from being introduced onto the signal lines. The sensor assemblies are manufactured using Etched Teon colored lead wires and ACI’s proven double encapsulation process to eliminate the eects of moisture on the sensors as well as increased response times from our high quality, thermally conductive epoxy. The immersion sensors “-I” include a welded thermowell but can be ordered without the thermowell “-INW” version. The

existing thermowell application. Optional NEMA/IP rated weather proof enclosures and NIST Calibration Certicates are available when ordering the A/TTM Series transmitters as referenced in the ordering grid on the back of the product data sheet. For best accuracy, ACI recommends the use of the A/TTM Series Matched transmitters which includes a 3 or 5 Point NIST Calibration Certicate, since they include a second calibration step in which the RTD and transmitter are calibrated together as a system.

Applications: Chilled Water Systems, Hot Water Systems, Boilers, Pumps, Compressors, Chillers, Cooling Towers, Process Control

“-INW” includes a standard ½” NPS process thread to be used with a machined thermowell or

PRODUCT SPECIFICATIONS

Transmitter Supply Voltage | Supply Current:

Maximum Load Resistance: Output Signals: Calibrated Transmitter Accuracy | Linearity: Temperature Drift: TTM100/TTM1K Certication Points: Warm Up Time | Warm Up Drift: Operating | Storage Temperature: Operating Humidity Range: Calibrated Temperature Spans: Connections | Wire Size: Terminal Block Torque Rating: Sensor Type | Sensor Curve | Sensing Points: Number Wires | Wire Colors: Sensor Output @ 0°C (32°F): RTD Class | Accuracy:

Din Standard | Temperature Coecient: Sensor Stability: Response Time (63% Step Change): Sensor Operating Temperature Range: Enclosure Specications (Operating Temperature, Material, Flammability, NEMA/IP Ratings):

Storage Temperature Range: Operating Humidity Range: Probe Diameter | Thermowell Bore Diameter: Probe Material | Thermowell Material: Thermowell Instrument Thread | Process Thread: Fitting Material | Flammability Rating: Fitting Thread Size: Lead Length | Conductor Size: Lead Wire Insulation | Wire Rating: Conductor Material: Product Dimensions | Product Weight: Agency Approvals:

Note: Transmitter’s calibrated at 71ºF (22ºC) nominal | Note: Temperature Drift is referenced to 71ºF nominal calibration temperature

+8.5 to 32 VDC (Reverse Polarity Protected) | 25 mA minimum 250 Ohm Load: +13.5 to 32 VDC | 500 Ohm Load: +18.5 to 32 VDC (Terminal Voltage - 8.5 V) | 0.020 A

Current: 4-20 mA (2-Wire Loop Powered) | Voltage: 1-5 VDC or 2-10 VDC (3-Wires) Temp. Spans < 500ºF (260ºC): +/- 0.2% | Temp. Spans > 500ºF (260ºC): +/- 0.5% Temp. Spans < 100ºF (38ºC): +/- 0.04%/ºF | Temp. Spans > 100ºF (38ºC): +/- 0.02% 3 Point NIST: 20%, 50% & 80% of span | 5 Point NIST: 0%, 20%, 50%, 80% & 100% of span

10 Minutes | +/- 0.1%

-40ºF to 185ºF (-40 to 85ºC) 0 to 90%, non-condensing Minimum Temp. Span: 50ºF (28ºC) | Maximum Temp. Span: 500ºF (260ºC) Screw Terminal Blocks (Non-Polarity Sensitive) | 16 AWG (1.31mm) to 26 AWG (0.129mm)

-40 to 200ºC (-40 to 392ºF)

“-GD” Enclosure: Galvanized Steel, -40 to 121ºC (-40 to 250ºF), NEMA 1 (IP10) “-PB” Enclosure: ABS Plastic, -30 to 90ºC (-22 to 194ºF), UL94-HB, Plenum Rated “-BB” Enclosure: Aluminum, -40 to 121ºC (-40 to 250ºF), NEMA 3R (IP 14) “-4X” Enclosure: Polystyrene Plastic, -40 to 70ºC (-40 to 158ºF), UL94-V2, NEMA 4X (IP 66)

-40 to 85ºC (-40 to 185ºF) 10 to 90% RH, non-condensing

0.250” (6.35mm) | 0.260” 304 Stainless Steel | 304 Stainless Steel ½” NPS (National Pipe Straight) | ½” NPT (National Pipe Tapered) Polyamide 66 (High Performance Nylon 66) | UL94-HB ½” (20 mm) NPSM 14” (35.6 cm) | 22 AWG (0.65mm) Etched Teon (PTFE) Colored Leads | Mil Spec 16878/4 Type E) Silver Plated Copper See table on back of Product Data sheet RoHS2, WEEE

Call: 1-888-967-5224 | Web: www.workaci.com

TEMPERATURE | ##

TEMPERATURE | TRANSMITTERS | IMMERSION

DIMENSIONAL DRAWING, WEIGHTS

Plastic Box Enclosure [PB]

3.60”

(91.44mm)

4.79” (121.55mm)

2.25”

(57.15mm)

2.23” (56.63mm)

Available with

2.5”, 4”, and 6” Lengths

Automation Components, Inc.

xx = Sensor Type | yy = Insertion Length

Plastic Box Enclosure [PB] Weights

ACI Model #

A/xx-INW-yy-PB A/xx-I-yy-PB A/xx-IM-yy-PB

2.5”

(Insertion Length)

0.24 lbs. (0.109 kg)

0.56 lbs. (0.254 kg)

0.58 lbs. (0.263 kg)

4”

(Insertion Length)

0.28 lbs. (0.127 kg)

0.60 lbs. (0.272 kg)

0.74 lbs. (0.336 kg)

6”

(Insertion Length)

0.32 lbs. (0.145 kg)

0.64 lbs. (0.290 kg)

0.92 lbs. (0.417 kg)

Galvanized Enclosure [GD]

2.29”

(58.04mm)

4.20” (106.68mm)

1.65” (42mm)

Available with

2.5”, 4”, and 6” Lengths

Bell Box Enclosure [BB]

Available with

2.5”, 4”, and 6” Lengths

4.70” (119.50mm)

2.34” (59.38mm)

NEMA 4X Enclosure [4X]

Available with

2.5”, 4”, and 6” Lengths

2.23”

(56.71mm)

3.70” (93.98mm)

2.55”(64.77mm)

Standard Views Product Weights

CUSTOM ORDERING

A. Sensor Series

C. Conguration

D. Thermowell Length

F. Enclosure

Note*: Must specify a 3 or 5 point NIST Certicate with the TTM100 or TM1K Transmitters above

No Selection Required

Select One (1)

TT100 = 100 | TTM100* = Matched 100 | TT1K = 1K | TTM1K* = Matched 1K B. Model Series

I = Immersion with Welded Thermowell | INW = Immersion without Welded Thermowell IM = Immersion with Machined Thermowell

2.5” = 2.5” Insertion | 4” = 4” Insertion | 6” = 6” Insertion

1 = 1 to 5 VDC | 2 = 2 to 10 VDC | 4 = 4 to 20 mAE. Output Signal

GD = Galvanized | PB = Plastic | BB = Aluminum, NEMA 3R | 4X = NEMA 4X

Specify Span in ºF or ºC (Best Accuracy in 100ºF Increments)G. Calibrated Span

Galvanized Enclosure [GD] Weights

ACI Model #

A/xx-INW-yy-GD A/xx-I-yy-GD A/xx-IM-yy-GD

2.5”

(Insertion Length)

0.66 lbs. (0.299 kg)

0.88 lbs. (0.399 kg)

1.00 lbs. (0.454 kg)

Bell Box Enclosure [BB] Weights

ACI Model #

A/xx-INW-yy-BB A/xx-I-yy-BB A/xx-IM-yy-BB

2.5”

(Insertion Length)

0.68 lbs. (0.308 kg)

1.02 lbs. (0.463 kg)

NEMA 4X Enclosure [4X] Weights

ACI Model #

A/xx-INW-yy-4X A/xx-I-yy-4X A/xx-IM-yy-4X

Model # Example:

2.5”

0.32 lbs. (0.145 kg)

0.64 lbs. (0.290 kg)

0.66 lbs. (0.299 kg)

TT100

(Insertion Length)

IC.6”D.2E.GD

4”

(Insertion Length)

0.70 lbs. (0.318 kg)

1.00 lbs. (0.454 kg)

1.16 lbs. (0.526 kg)

4”

(Insertion Length)

0.72 lbs. (0.326 kg)

1.04 lbs. (0.427 kg)

1.20 lbs. (0.544 kg)

4”

(Insertion Length)

0.36 lbs. (0.163 kg)

0.68 lbs. (0.308 kg)

0.82 lbs. (0.372 kg)

6”

(Insertion Length)

0.74 lbs. (0.336 kg)

1.04 lbs. (0.472 kg)

1.32 lbs. (0.599 kg)

6”

(Insertion Length)

0.76 lbs. (0.345 kg)

1.08 lbs. (0.490 kg)

1.36 lbs. (0.617 kg)

6”

(Insertion Length)

0.40 lbs. (0.181 kg)

0.72 lbs. (0.327 kg)

1.00 lbs. (0.454 kg)

MODEL #

ACCESSORIES ORDERING

Model # NSG HEAT TRANSFER PASTE 2OZ NSG HEAT TRANSFER PASTE 16OZ A/M2.5” A/M4” A/M6” A/M2.5”-316SS A/M4”-316SS A/M6”-316SS

TEMPERATURE | ##

Item #

102595 140574 128338 128343 128344 128352 128353 128354

Description

Thermal Grease, 2 oz. Tube, Silicone Free, -40 to 320ºF (-40 to 160ºC) Thermal Grease, 16 oz. Jar, Silicone Free, -40 to 390ºF (-40 to 198ºC)

2.5” (63.5mm) Insertion, 304 Stainless, Machined, ½” NPT Thermowell 4” (101.6mm) Insertion, 304 Stainless, Machined, ½” NPT Thermowell 6” ( 152.4mm) Insertion, 304 Stainless, Machined, ½”NPT Thermowell

2.5” (63.5mm) Insertion, 316 Stainless, Machined, ½” NPT Thermowell 4” (101.6mm) Insertion, 316 Stainless, Machined, ½” NPT Thermowell 6” (152.4mm) Insertion, 316 Stainless, Machined, ½” NPT Thermowell

Call: 1-888-967-5224 | Web: www.workaci.com

Model # Example:

NSG HEAT TRANSFER PASTE 2OZ

Revision C0000002 | Rev 1.0

-OR-

102595
