Acer Liquid E1 Duo V360 User’s Manual
Model: V360
First issue: 2/2013
Acer Liquid E1 Duo V360 Smartphone
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
Table of contents
Table of contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Setting up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Unpacking your smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Getting to know your smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Installing or removing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Installing a SIM or microSD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Using your smartphone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Turning on for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Locking your smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Using the touchscreen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
The Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Managing contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Managing your contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Before making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
The voice call screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Internet calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Adding an Internet calling account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Editing or removing an Internet calling account. . . . . . . . . . . . . . . . . . . . . . . . . 26
Using Internet calling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Receiving Internet calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Calling a contact’s Internet calling address . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Calling a phone number using Internet calling . . . . . . . . . . . . . . . . . . . . . . . . .26
Messaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Creating a new message. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Replying to a message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
MMS messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Going online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Browsing the Internet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Setting up your Google email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Composing an email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Setting up Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Maps, Navigation, Places and Latitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
AcerCloud setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
AcerCloud setup for Windows 7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Using the Camera. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Camera icons and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Taking a photo. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Shooting a video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Viewing photos and videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Geotagging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Advanced settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Putting your smartphone in Airplane mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Adjusting settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Connecting to a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
FM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Multimedia playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Restoring to factory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Accessories and tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Using the headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Using a Bluetooth headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Inserting a microSD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
FAQ and troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Other sources of help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Warnings and precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Emergency calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Taking care of your smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Managing your SIM cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
End User License Agreement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Setting up
9
3
4
5
6
7
1
2
8
14
12
10
11
13
Unpacking your smartphone
Your new smartphone comes packed in a protective box. Carefully unpack the box
and remove the contents. If any of the following items is missing or damaged,
contact your dealer immediately:
• Acer Liquid E1 Duo V360 Smartphone
•Battery
• Quick Guide
• USB cable
• AC adapter
• Headset
Getting to know your smartphone
Views
No. Item Description
1 Micro USB connector Connects to a USB cable/charger.
2 3.5 mm headphone jack Connects to stereo headphones.
3 Power button Press to turn the screen on/off or enter sleep
4 Phone speaker Emits audio from your smartphone; suitable for
mode; press and hold to turn the smartphone on
or off.
holding to your ear.
5
No. Item Description
5 Front-facing camera A 0.3-megapixel camera for video chats and self
portrait images.
6 LED indicator Indicates the phone’s battery, call, and message
status (see table below).
7 Light sensor Detects ambient light and automatically adjusts
screen brightness.
8 Touchscreen 4.5-inch, 960 x 540 pixel capacitive touchscreen
to display data, phone content and enter
information.
9 Microphone Internal microphone.
10 Volume up/down buttons Increases or decreases the phone volume.
11 Handsfree stereo
speakers
12 Microphone Receives audio for video recording.
13 Rear camera A 5-megapixel camera for taking high-resolution
14 Flash LED flash for camera.
LED Indicators
Status Description
Blinks red every
eight seconds
Blinks red every
three seconds
Blinks red every two
seconds
Red Charging.
Green Fully charged, plugged in.
Blinks green every
ten seconds
Blue Plugged in but not ready / not enough charge to power on.
Low battery, not plugged in (only in sleep mode).
Critically low battery, not plugged in (only in sleep mode).
Bad battery or charging error.
Missed call, voice mail, or new message (only in sleep mode).
Leave the device plugged in and try again later.
Emits stereo audio from your smartphone;
suitable for handsfree use.
images.
Installing or removing the battery
Your smartphone uses a replaceable battery to provide power. It is packed
separately from your smartphone and needs to be inserted and charged before you
can use the smartphone.
6
Installing the battery
Insert your fingernail into the cutout between the
battery cover and the phone. Unclip the cover and
lift off the battery cover.
Place the battery into the battery compartment,
lining up the battery connectors with those at the
top of the compartment.
Align the tabs on the cover into the slots on the
phone. Gently press the cover until it snaps in
place.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Charging the battery
For initial use, you need to charge your smartphone for eight hours. After that you
can recharge the battery as needed.
7
Connect the AC adapter cord to the micro USB connector on your smartphone.
Removing the battery
Open the battery compartment as shown in "Installing the battery" on page 7. Lift
the battery out of the compartment by lifting at the top of the battery on either side of
the camera.
Replace the battery cover as described above.
Installing a SIM or microSD Card
To take full advantage of your smartphone’s telephony capabilities, you must install a
SIM card. The SIM card holder is located at the top of the battery bay.
Your new phone has two SIM card holders, you may install one or two SIM cards.
Additionally, you may wish to increase your smartphone’s storage by inserting a
croSD Card into the slot provided. This is next to the SIM card slot.
mi
1. Turn off the phone by pressing and
ing the power button.
hold
2. Open the cover and remove the battery
as described in "Removing the
battery" on page 8.
3. Insert the SIM or microSD Card as
sh
own.
4. Replace the battery and battery cover.
Important: Turn off your phone before installing or removing the microSD Card.
Note: Ensure that the microSD Card is inserted all the way into the card slot.
8
SIM card lock
Your smartphone may come with a SIM card lock, i.e., you will only be able to use
the SIM card provided by your network operator.
To cancel the SIM lock, contact your network provider.
9
Using your smartphone
Turning on for the first time
To turn on your smartphone for the first time, press and hold the power button until
the screen turns on. You will then be asked to configure some settings before you
can use your smartphone.
Follow the onscreen instructions to complete setup.
Sign in to or create a Google account
If you have Internet access, your smartphone allows you to synchronize information
with a google account.
During the start-up process, you may create or sign in to your account, which will be
used to synchronize your contact list, email, calendar and other information. If you
do not yet have Internet access, or do not want to use this feature, then tap Skip.
Creating multiple Google accounts
You can create and easily access multiple Google accounts. Open the Application
menu and then tap Settings > Add account.
Entering your PIN
When you install a SIM card for the first time, you may need to enter a PIN using the
onscreen number pad.
Important: Depending on your settings, you may be required to enter your PIN
each time you switch on the phone function.
Activating a new SIM card
If you are using your SIM card for the first time, it may require activation. Contact
your network operator for details on how to do this.
Locking your smartphone
If you will not use your smartphone for a while, briefly press the power button to lock
access. This saves power and ensures your smartphone does not unintentionally
use any services. Your smartphone will lock automatically if it is not used for one
minute.
10
Waking your smartphone
If the screen is off and the smartphone does not
react to any taps on the screen or front panel
button, then it has been locked and is in sleep
mode.
Press the power button to
Unlock your smartphone by sliding your finger from
one side of the screen to the other (it works both
ways).
For additional security, you may set an
pattern, a set of dots that must be touched in the
correct order to access the phone. Open the
Application menu and then tap Settings >
Security > Screen lock.
Note: If you forget your unlock pattern, please refer to "Unlock pattern" on
page 52.
You may also directly enter the lock screen applications at the bottom of the screen.
Tap the icon and slide your finger to the left or right across to quickly access the
application. To change the lock screen applications, see "Managing the lock
screen" on page 17.
wake your smartphone.
unlock
Using the touchscreen
Your smartphone uses a touchscreen for selecting items and entering information.
Use your finger to tap the screen.
Touch the screen once to open items and select options.
Tap:
Drag: Ho
images.
Tap and hold: T
the pop-up menu that appears, tap the action you want to perform.
Scroll: T
screen in the direction that you want to scroll.
ld your finger on the screen and drag across the screen to select text and
ap and hold an item to see a list of actions available for that item. On
o scroll up or down the screen, simply drag your finger up or down the
Android keyboard
This is a standard onscreen QWERTY keyboard that
allows you to enter text. Tap and hold a key with
numbers at the top to select alternative characters,
such as letters with accents.
Tap the ?123 button to see numbers and special
characters, and then tap the ALT key to see even
more.
11
You can choose another input language by tapping and holding the comma key.
Alternatively, you can open the Application menu and then tap Settings >
Language & input. Then tap the Settings button next to "Android keyboard" >
Input languages. The keyboard layout changes according to the selected
language.
After setting up more than one language, the world button appears next to
space bar. Tap this button to quickly toggle between multiple input
the
languages.
Text assistance
The Android keyboard has various features that assist you to enter correct text. In
the Application menu, tap Settings > Language & input and then tap the Settings
button to the right of Android keyboard. From here you can enable or disable
several keyboard-related settings.
Changing the text input method
To change the input method, in the Application menu tap Settings > Language &
input > Default and then select your preferred input method.
Predictive text
Both Swype and Android keyboard provide predictive text input for the browser. As
you tap the letters of a word, a selection of words are displayed above the keyboard
that continue the sequence of letters tapped, or are a close match allowing for
errors. The word list changes after every key press. If the word you need is
displayed, you can tap on it to insert it into your text.
Swype
Swype is a fast way to enter text. It allows you to type
with one continuous motion across the screen
yboard; you create a word by drawing through
ke
letters.
Put your finger on the first letter of the word and draw
ath from letter to letter, lifting up only after the last
a p
letter. Swype will insert spaces where necessary.
Swype will usually add a double letter in a word when
needed, but you can help Swype recognize you want
a double letter by scribbling slightly or making a loop
on the letter. For example, to get the "ll" in "hello",
scribble (or make a loop) on the "l" key.
12
When there are multiple suggestions for the word
you want to enter, Swype displays a Word Choice
List. To accept the default word in the Word Choice
List, just keep Swyping. Otherwise, scroll through the
list by dragging your finger, and tap the word you
want.
Press and hold the Swype key to access settings, features, updates,
preferences, and help.
Tap the +!= bu
(shift) key to see even more.
Additional keys vary depending on the type of text you enter, e.g. a key to add a
ey is available when typing a text message. Like other keys, tap and hold for
smil
additional options.
To change the input method, open the Notification area (see "Status and
notification area" on page 17.) and tap Choose input method.
tton to see numbers and special characters; tap the page
Text assistance
The Swype keyboard has various features that assist you to enter correct text. In the
Application menu, tap Settings > Language & input and then tap the Settings
button to the right of Swype. You can also tap and hold the Swype key . From
here you can enable or disable the following:
Function Description
How to Swype Learn how to use the Swype keyboard.
Preferences Change your text input preferences.
Language
Options
Swype Connect
Personal
dictionary
Updates Check for application and dictionary updates.
Set the language used by the keyboard.
• Add contact names and words used in posts to your personal
dictionary.
• Change data settings.
Check words added you your personal dictionary.
The Home screen
After rebooting, your smartphone will display the home screen. This screen gives
you quick access to information and simple controls with widgets or shortcuts. These
13
display information such as the time and weather, or provide additional controls and
Search
Time and Status
Navigation
Application menu
Back Home Recent
Hide
direct access to applications and other frequently used features of your smartphone.
At the bottom of the screen is the application dock which displays default
applications. Tap an icon to open the application. Tap the Application icon in the
middle of the application dock to view your applications. To change applications, see
"Changing application dock icons" on page 16..
Search
To search for applications, files or for information on the Internet, tap the
Google icon in the top-left corner.
Simply enter the text you want to find and tap
applications or files shown in the list.
Voice search
If voice search is available, tap the microphone and speak your search
request. See "Voice search" on page 31.
Navigation
To navigate through menus and options, three (or
more) icons are shown in the bottom-left corner.
Back
Tap this icon to go to the previous page, or to go up one level in a menu.
This icon may be replaced with the hide icon in certain cases (such as if
the keyboard or list of recent applications is shown).
Home
Tap this icon to go directly to the Home screen.
Recent
Tap this icon to see recently opened applications. Tap an application to open it, or
tap anywhere on the screen to return to the Home screen. See "Multitasking" on
page 20.
or tap one of the suggestions,
14
The extended Home screen
The Home screen extends to either side of the screen, giving you more room to add
icons, widgets or features. To view the extended screen, slide your finger to the left
or right.
Personalizing the Home screen
You may personalize your Home screen by adding or removing application shortcuts
or widgets, and by changing the wallpaper.
Adding and removing shortcuts and widgets
To add shortcuts or widgets, tap the Application menu icon
in the bottom-center of the Home screen.
Ta p APPS
drag to a Home screen.
Ta p WI
custom shortcuts, contacts or bookmarks) that you can add
to a Home screen. Widgets are small applications that
display constantly-updated information or quick shortcuts to
applications or special functions.
To move an App or Widget to the Home screen, tap and
hold
Drag the item to any free area on the screen. To view
information about the App or Widget, drag it to the icon at
the top of the screen.
To move the item to a different H
side of the screen, the Home screen will switch to the
screen in that direction. Release the item when it is
positioned correctly.
To remove a shortcut or widget from the Home screen, tap
and dra
to see a list of shortcuts to applications you can
DGETS to see small applications and links (such as
an item until it is selected. The Home screen will open.
ome screen, drag it to the
g it to Remove at the top of the screen.
15
Resizing widgets
Some widgets can be resized. As soon as you place a widget on the Home screen,
you can resize it by dragging the corners.
To resize a widget that is already on the
Once the Remove icon appears, release the widget. If the widget is resizable, you
will be able to drag the sides of the widget to resize it.
Home screen, tap and hold the widget.
Adding or removing folders
You can also add folders to your Home screen. To create a new folder drag and drop
an application icon onto another application icon in the Home screen. This will
create an Unnamed Folder. Tap the folder icon and then tap the name of the folder
to rename it.
To delete an application shortcut from a folder, tap on the folder icon to display the
applications inside and then tap and hold the application icon that you want to
remove. Drag and drop the icon on Remove that will appear at the top of the screen.
To delete a folder, tap and hold on the folder and then drag and drop the folder on
Remove that
will appear at the top of the screen.
Changing application dock icons
You can set icons for installed applications in the application dock. Open the
Application menu and find the application you want to add. Tap and hold the icon,
then drag it to any open position in the dock. Dragging the new application to an
existing dock icon will create a folder for both icons.
To remove an icon from the dock, tap and hold th
icon to a different location outside the dock or to Remove at the top of the screen.
e icon to select it. Either drag the
Changing the wallpaper
Tap and hold any open area on the Home screen. Tap the Wallpaper tab to change
the lock screen and home wallpaper. You can choose from images stored in the
Gallery, standard wallpapers, Live Wallpapers featuring animated or interactive
backgrounds, or Video Wallpapers enabling you to use videos as your background.
16
Managing the lock screen
Tap and hold any open area on the Home screen. Tap the Lock screen manager
tab to turn on and off lock screen icons or change which lock screen icons appear.
Changing home screen settings
Tap and hold any open area on the Home screen. Tap the Home screen settings
tab to modify sliding effects. You can change the transition effect when scrolling to
different screens. In addition, you can turn on and off automatic scrolling and cycle
scrolling.
The Application menu
To access the Application menu, on the Home screen tap in the center of the
dock.
Applications are displayed in alphabetical order. Swipe the
page to the left or right to see more applications.When you
are on the last page of applications, swipe to the left to see
widgets available on your tablet, or tap WIDGETS at the top
of the page.
Tap the Pl
purchase apps and/or digital media.
To quickly jump to applications or widgets, tap APPS or
WIDGETS at the top of the Application menu.
ay Store icon to open Google Play to view and
Note: All images are for reference only. The applications installed on your device
can be different from the applications shown in illustrations.
Status and notification area
The Notification area is at the top of the screen.
17
This area contains a variety of icons to inform you of your
phone’s status. The left side of the Notification area displays
event icons that indicate a new event (such as a new
message). The icons on the right side indicate signal
strength, connection, battery status and the time.
Drag the Notification area down the screen to view more
information about new events adjust commonly used
settings.
Connection icons
Note: Connection icons appear in different colors if you have two SIMs inserted.
Icon Description Icon Description
Connected to GPRS mobile
network
Connected to EDGE mobile
network
Connected to 3G mobile network Mobile data transferring
Connected to HSDPA network Connected to a wireless
Bluetooth is on No signal
Roaming
Cellular signal strength
network
Bluetooth connected Airplane mode (Wireless
connectivity disconnected.
Please disable airplane mode
before trying to make a call.)
USB and wireless tethering are
activated
Wireless tethering is activated
USB tethering is activated
18
Battery icons
Icon Description Icon Description
Battery is very low Battery is partially drained
Battery is low Battery is full
Battery is charging
Notification icons
Note: Notification icons appear in different colors if you have two SIMs inserted.
Icon Description Icon Description
Alarm is set SIM card is invalid or not
installed
Speakerphone is on Vibrate mode
New Gmail message Ringer is silenced
New/unread SMS/MMS Phone microphone is off
Problem with sending SMS/MMS Application update available
New Google Talk message System update available
New voicemail Missed call
Upcoming event Song is playing
Syncing data More notifications
Warning, open the notification
area for more information
SD card or USB storage is full Receiving location data from
An open wireless network is
available
Phone is connected to PC via
USB
Carrier data use threshold
exceeded
Connected to or disconnected
from virtual private network
(VPN)
GPS is on
GPS
Uploading data
Downloading data
Download finished
19
Multitasking
You can have multiple applications open at the same time.
To open a new application, tap
screen, then start the new application.
To view your active applications, tap . Then tap an icon
to go to the application.
Tip: To prolong battery life, it is better to close an application when you’ve
finished using it. Do this by either pressing the Back key or the Menu button and
selecting Exit (if available).
to return to the Home
20
Managing contacts
Managing your contacts
Your smartphone features an address book that allows you
to save contacts to either the internal memory or onto your
SIM card.
Open the People a
pplication from the Application menu or
tap
If you don’t have any contacts stored on your phone, you
can import your Google account contacts, add a new
contact or import contacts from your SIM or SD card. Open
the People application from the Application menu and then
tap to add a contact, to search for a contact, or tap
the Menu bu
from the Dialer to view your contacts.
tton to open the menu.
Adding a contact
Ta p to add a new contact. You may also scan a person’s
profile barcode to add the person to your contact list or
.
group
To create a contact, first choose where you want to store the
ntact’s information. You will then be asked to enter the
co
contact’s information, such as name, address, and phone
number.
You may scroll down the page and tap Ad
add things such as:
• IM addresses.
• Add any personal notes about the contact.
• Phonetic name
• Link a website
To assign an image to your contact, tap the silhouette and
se
lect whether to take a photo or select an image from your
smartphone’s picture gallery.
When done, click Done
Tapping on the contacts name will brin
while viewing a contact’s profile to edit, share, delete, or print the contact. You
may also set a ringtone for the contact, or associate the contact with a SIM card.
at the top of the screen.
d another field to
g up their profile. Tap
Tip: You may also create a contact from an already dialed or received number,
see "Saving a dialed number to contacts" on page 25.
21
Making calls
This chapter shows you how to make phone calls, and the various options available
to you during your call.
Before making a call
Check that the phone function is on before you make a call. You can confirm the
phone status from the Notification area.
Note: Status and notification icon colors may vary.
Icon Description
Not connected to the network: You are unable to make a call.
Connected to the network: You may make a call.
Airplane mode: Wireless connectivity disconnected (Wi-Fi, Bluetooth, 2G
and 3G). Please disable airplane mode before trying to make a call.
Making a call
Note: The phone function needs to be enabled before the call can be connected.
1. From the Home screen tap Phone to open the onscreen
number pad.
2. Enter the number you wish to dial.
3. Tap to make the call.
4. To end the call, tap
If the contact you need is displayed, simply tap the contact
name
to make a call.
.
Dialing a number from Call Log
Your call history can be viewed by tapping the Call Log tab
at the top of the screen. It displays recent received, dialed,
and missed calls.
Tap the phone icon to redial. To view details of the call, tap
number or contact’s name. While viewing the details of a call, tap the Menu
the
button for other options: Remove from call log; Edit number before call.
Viewing missed calls
Missed call notifications are displayed in the following three areas:
22
Loading...
