First things first

We would like to thank you for making the TravelMate series of
notebook computers your choice for your mobile computing needs.
We hope you will be happy with your TravelMate as much as we
enjoyed making it for you.

Your guides

To help you use your TravelMate, we have designed a set of guides:

First off, the Just for Starters... poster helps you get
started with setting up your computer.

iii

This User’s guide introduces you to the many ways your
computer can help you be more productive. This guide
provides clear and concise information about the computer,
so read it thoroughly.

Lastly, there may be a Read me first sheet included with
your package which contains important reminders and
updates. So, please read through it.

For more information about our products, services, and support
information, please visit our web site (www.acer.com

).

Basic care and tips for using your computer

Turning your computer on and off

To turn on the computer, open the display cover, and press the power
switch above the keyboard.

To turn the power off, do any of the following:

TMa550.book Page iv Wednesday, October 3, 2001 10:57 AM

iv

Use the Windows shutdown command

•

Click on Start, and select the Windows shutdown or turn off
command.

• Use the power switch

If you set the power switch to “Shut down”, you can use this
button to turn off the computer. See Windows help for details.

Note: If you cannot power off the computer normally, press and
hold the power switch for more than four seconds to shut down
the computer. If you turn off the computer and want to turn it on
again, wait at least two seconds before powering up.

Taking care of your computer

Your computer will serve you well if you take care of it.

• Do not expose the computer to direct sunlight. Do not place it

near sources of heat, such as a radiator.

• Do not expose the computer to temperatures below 0°C (32°F) or

above 50°C (122°F).

• Do not subject the computer to magnetic fields.

• Do not expose the computer to rain or moisture.

• Do not spill water or any liquid on the computer.

• Do not subject the computer to heavy shock and vibration.

• Do not expose the computer to dust and dirt.

• Never place objects on top of the computer to avoid damaging the

computer.

• Do not slam the computer display when you close it.

• Never place the computer on uneven surfaces.

Taking care of your AC adapter

Here are some ways to take care of your AC adapter:

• Do not connect the adapter to any other device.

• Do not step on the power cord or place heavy objects on top of it.

Carefully route the power cord and any cables away from personal
traffic.

• When unplugging the power cord, do not pull on the cord itself

TMa550.book Page v Wednesday, October 3, 2001 10:57 AM

but pull on the plug.

• The total ampere ratings of the equipment plugged in should not

exceed the ampere rating of the cord if you are using an extension
cord. Also, the total current rating of all equipment plugged into
a single wall outlet should not exceed the fuse rating.

Taking care of your battery pack

Here are some ways to take care of your battery pack:

• Use only batteries of the same kind as replacements. Turn the

power off before removing or replacing batteries.

• Do not tamper with batteries. Keep them away from children.

• Dispose of used batteries according to local regulations. Recycle if

at all possible.

Cleaning and servicing

When cleaning the computer, follow these steps:

1 Power off the computer and remove the battery pack.
2 Disconnect the AC adapter.
3 Use a soft cloth moistened with water. Do not use liquid or

aerosol cleaners.

v

If any of the following occurs:

• The computer has been dropped or the body has been damaged.

• Liquid has been spilled into the product.

• The computer does not operate normally.

Please refer to "Troubleshooting my computer" on page 75.

TMa550.book Page vi Wednesday, October 3, 2001 10:57 AM

vi

TMa550.book Page vii Wednesday, October 3, 2001 10:57 AM

First things first iii

Your guides iii
Basic care and tips for using your computer iii

1 Getting familiar with your computer 1

A tour of your computer 3

Front view 3
Left view 5
Right view 6
Rear view 7

Bottom view 8
Features 9
Display 11
Indicators 12
Keyboard 15

Special keys 15

Keyboard ergonomics 19
Touchpad 20

Touchpad basics 20
Launch keys 22
Storage 24
Connectivity options 25

Ethernet and LAN 25

Fax/data modem 25
Audio 26

Adjusting the volume 26

Using the Audio DJ feature 26
Securing your computer 27

Security notch 27

Passwords 27

Contents

2 Operating on battery power 29

Battery pack 31

Battery pack characteristics 31

Installing and removing the battery pack 31

Charging the battery 33

Checking the battery level 33

Optimizing battery life 33

Battery-low warning 34
Power management 36

TMa550.book Page viii Wednesday, October 3, 2001 10:57 AM

viii

3 Peripherals and options 37

External display devices 39

External monitor 39
External display with s-video input 39
Using simultaneous display 39

External input devices 40

External keyboard 40
External keypad 40

External pointing device 40
Printer 41
Audio devices 42
Expansion devices 43

PC Card slots 43

USB 44

IEEE 1394 45
Miscellaneous options 46

Battery pack 46

AC adapter 46
Key component upgrades 47

Memory upgrade 47

Hard disk upgrade 49

4 Moving with your computer 51

Disconnecting from the desktop 53
Moving around 54

Preparing the computer 54

What to bring to short meetings 54

What to bring to long meetings 54
Taking the computer home 55

Preparing the computer 55

What to bring with you 55

Special considerations 55

Setting up a home office 56
Traveling with the computer 57

Preparing the computer 57

What to bring with you 57

Special considerations 57
Traveling internationally with the computer 58

Preparing the computer 58

What to bring with you 58

Special considerations 58

TMa550.book Page ix Wednesday, October 3, 2001 10:57 AM

5 Software 59

System software 61
Easy Button 62
E-Mail Detector 63
BIOS Setup Utility 64

Main 65
System Devices 67
Security 68
Others 71
Boot 72
Exit 73

6 Troubleshooting 75

Frequently-asked questions 77
Error messages 81

Appendix A Specifications 85

ix

Appendix B Notices 91

Index 99

TMa550.book Page x Wednesday, October 3, 2001 10:57 AM

x

TMa550.book Page 1 Wednesday, October 3, 2001 10:57 AM

1 Getting familiar with

your computer

TMa550.book Page 2 Wednesday, October 3, 2001 10:57 AM

This computer combines high-performance,
versatility, power management features and
multimedia capabilities with a unique style and
ergonomic design. Work with unmatched
productivity and reliability with your new power
computing partner.

This chapter gives an in-depth "tour" of the
computer’s many features.

TMa550.book Page 3 Wednesday, October 3, 2001 10:57 AM

A tour of your computer

After setting up your computer as illustrated in the Just for Starters...
poster, let us show you around your new notebook computer.

Front view

3

TMa550.book Page 4 Wednesday, October 3, 2001 10:57 AM

# Item Description

1 Display screen Also called LCD (liquid-crystal display), displays

computer output.

2 Power button Turns on the computer power.

3 Status LCD LCD that display icons to show the status of the

computer and its functions and components.

4 Keyboard Inputs data into your computer.

5 Touchpad Touch-sensitive pointing device which functions

like a computer mouse.

1 Getting familiar with your computer4

6 Click buttons

(left and right)

The left and right buttons function like the left
and right mouse buttons.

7 Launch keys Buttons for launching frequently-used programs.

See “Launch keys” on page 22 for more details.

8 Status

Shows the power and email status.

indicators

9 Speakers Outputs sound.

10 Palmrest Comfortable support area for your hands when

you use the computer.

11 Floppy drive Accepts a 3.5-inch diskette.

12 Floppy drive

Press to eject the diskette from the floppy drive.

eject button

TMa550.book Page 5 Wednesday, October 3, 2001 10:57 AM

Left view

# Item Description

1 Optical drive Depending on your model:

• CD-ROM drive reads CDs

• DVD-ROM drive reads CDs and DVDs

• DVD/CD-RW combo drive reads CDs and DVDs,

and writes to CD-Rs and CD-RWs.

5

2 Optical drive

eject button

3 Optical drive

emergency
eject hole

Ejects the disc from the optical drive.

Ejects the disc from the optical drive when the
computer is turned off. See “How do I eject the
optical drive tray with the computer turned off?” on
page 78 for more details.

TMa550.book Page 6 Wednesday, October 3, 2001 10:57 AM

Right view

# Item Description

1 Getting familiar with your computer6

1 Speaker/headphone-

out jack

2 Microphone-in jack Connects an external microphone.

3 PC Card eject buttons Eject the selected PC Card from its slot.

4 PC Card slots

5 DC-in jack Connects to the AC adapter.

6 PS/2 port Connects to a PS/2-compatible device (e.g.,

7 USB ports (two) Connects to USB devices (e.g., USB mouse).

Connects to audio line-out devices (e.g.,
speakers, headphones).

Accepts one Type III or two Type II/I PC
Card(s).

PS/2 keyboard/mouse/keypad).

TMa550.book Page 7 Wednesday, October 3, 2001 10:57 AM

Rear view

# Item Description

1 Security keylock Connects to a Kensington-compatible

computer security lock.

2 IEEE 1394 port Connects to a IEEE 1394 compatible device

(e.g., digital camcorder).

3 Network jack Connects to an Ethernet 10/100-based

network.

7

4 Modem jack Conncts a phone line (only for models with

an internal fax/data modem).

5 Parallel port Connects to a parallel device (e.g., parallel

printer).

6 External display port Connects to a display monitor.

7 Video-out port Connects to a display device with S-video

input.

TMa550.book Page 8 Wednesday, October 3, 2001 10:57 AM

Bottom view

1 Getting familiar with your computer8

# Item Description

1 Hard disk bay Houses the computer’s hard disk.

2 Battery release button Press and hold to release the battery latch.

3 Battery release latch Unlatches the battery to remove the battery

pack.

4 Battery bay Houses the computer’s battery pack.

5 Memory compartment Houses the computer’s main memory.

TMa550.book Page 9 Wednesday, October 3, 2001 10:57 AM

Features

This computer was designed with the user in mind. Here are just a few
of its many features:

Performance

• Intel® Pentium™ III or Intel® Celeron™ processor with on-die
level 2 cache

• 128 MB memory onboard and one memory upgrade slot

• Large LCD display with adjustable video memory

• High-capacity, Enhanced-IDE hard disk

• Lithium-Ion battery pack

• Power management system

• DualView capability

• Simultaneous LCD and CRT display

Multimedia

• 16-bit high-fidelity stereo audio with 3-D sound

• Built-in dual stereo speakers

• Internal optical drive (CD-ROM, DVD-ROM, or DVD/CD-RW combo)

• Audio DJ (CD playback) feature

• S-video (NTSC/PAL) output

9

Connectivity

• High-speed 56Kbps V.90 fax/data software modem

• Ethernet/Fast Ethernet (10/100 Mbps)

• CardBus PC Card slots

• Universal Serial Bus (USB) ports

• IEEE 1394 port

Human-centric design and ergonomics

• All-in-one design (CD or DVD, floppy drive, and hard disk)

• Sleek, smooth and stylish design

• Full-sized keyboard

• Wide and curved palm rest

TMa550.book Page 10 Wednesday, October 3, 2001 10:57 AM

1 Getting familiar with your computer10

• Ergonomically-centered touchpad pointing device

• Launch keys (supports Audio DJ feature)

Expansion

• Upgradeable memory and hard disk

TMa550.book Page 11 Wednesday, October 3, 2001 10:57 AM

Display

The large graphics display offers excellent viewing, display quality and
desktop-performance graphics. The computer supports a Thin-Film
Transistor (TFT) liquid crystal display (LCD) displaying up to 16.7 million
colors at 1400x1050 Super eXtended Graphics Array Plus (SXGA+)
resolution (for models with a 15.0-inch display) or 1024x768 eXtended
Graphics Array (XGA) resolution (for models with a 14.1-inch display).

Video performance

Video memory is adjustable via the BIOS Setup Utility. The system sets
aside a portion of main memory for video. For more details on how to
configure this setting, see “System Devices” on page 67.

Simultaneous display

The computer’s large display and multimedia capabilities are great for
giving presentations. If you prefer, you can also connect an external
monitor when giving presentations. This computer supports
simultaneous LCD and CRT display. Simultaneous display allows you to
control the presentation from your computer and at the same time
face your audience. You can also connect other output display devices
such as an LCD projector or a television for large-audience
presentations.

11

TMa550.book Page 12 Wednesday, October 3, 2001 10:57 AM

1 Getting familiar with your computer12

Indicators

The computer has an easy-to-read status LCD (1) located above the
keyboard. Two status indicators, power (2), and email (3) are located
near the front of the computer.

The status LCD displays icons that show the status of the computer and
its components.

Function Icon Description

Caps lock Caps Lock is activated.

Num lock Numeric Lock (for embedded keypad) is

activated.

Pad lock Pad Lock (for embedded keypad) is

activated.

Scroll lock Scroll Lock is activated.

TMa550.book Page 13 Wednesday, October 3, 2001 10:57 AM

Function Icon Description

13

Optical drive/
Hard disk

CD or DVD drive or hard disk is being
accessed.

activity

Floppy drive

Floppy drive is being accessed.

activity

PC Card

PC Card is being accessed.

activity

AC power Computer is running on AC power.

Battery

Battery is being charged.

charge

Battery full Battery is fully charged.

Battery

Battery is 75 to 100 percent full.

gauge

Battery is 31 to 74 percent full.

Battery is 6 to 30 percent full, and
battery is running low.

Note: Charge the battery as soon as
possible.

Battery is critically-low.
Note: Battery gauge icon is blinking.

Battery temperature is too high.
Note: Save your work and shut down

your computer to let the battery cool
down.

Battery is not installed.

TMa550.book Page 14 Wednesday, October 3, 2001 10:57 AM

1 Getting familiar with your computer14

In addition to the status LCD, the computer includes power and email
status indicators.

Function Icon Description

Power Lights when the computer is on.

Email Lights when incoming email is received.

To launch your email program and read the
incoming email, press the email button beside this
indicator. See “Launch keys” on page 22.

TMa550.book Page 15 Wednesday, October 3, 2001 10:57 AM

Keyboard

The keyboard has full-sized keys with an embedded keypad, separate
cursor keys, two Windows keys and twelve function keys.

Special keys

Lock keys

15

The keyboard has four lock keys which you can toggle on and off.

Lock Key Description

Caps lock When Caps Lock is on, all alphabetic characters typed are in

uppercase.

Pad lock
(Fn-F10)

Num lock
(Fn-F11)

Scroll lock
(Fn-F12)

When Pad Lock is on, the embedded keypad is in cursor mode.
The keys function as a directional keypad including Insert and
Delete keys.

When Num Lock is on, the embedded keypad is in numeric
mode. The keys function as a calculator (complete with the
arithmetic operators +, -, *, and /). Use this mode when you
need to do a lot of numeric data entry. A better solution
would be to connect an external keypad. See “External
keyboard” on page 40.

When Scroll Lock is on, the screen moves one line up or down
when you press ↑ or ↓ respectively. Scroll Lock does not work
with some applications.

TMa550.book Page 16 Wednesday, October 3, 2001 10:57 AM

1 Getting familiar with your computer16

Embedded keypad

The embedded keypad functions like a desktop numeric keypad. It is
indicated by small characters located on the lower edge of the keycaps.
The embedded keypad can function in numeric mode or cursor-control
mode.

Desired Access Num lock On Pad lock On

Number keys on
embedded keypad

Cursor-control keys on
embedded keypad

Main keyboard keys Hold Fn while typing

Type numbers in a
normal manner.

Hold Shift while using
cursor-control keys.

letters on embedded
keypad. Also hold
down Shift for capital
letters.

Hold Shift while typing
numbers.

Use cursor-control keys
in a normal manner.

Hold Fn while typing
letters on embedded
keypad. Also hold
down Shift for capital
letters.

TMa550.book Page 17 Wednesday, October 3, 2001 10:57 AM

Windows keys

The keyboard has two keys that perform Windows-specific functions.

Key Description

Windows logo key Start button. Combinations with this key perform

special functions. Below are a few examples:

+ Tab (Activates next Taskbar button)



+ E (Explores My Computer)



+ F (Finds Document)



+ M (Minimizes All)



Shift +  + M (Undoes Minimize All)

+ R (Displays Run dialog box)



17

Application key Opens the application’s context menu (same as right-

click).

TMa550.book Page 18 Wednesday, October 3, 2001 10:57 AM

1 Getting familiar with your computer18

Hotkeys

The computer uses hotkeys or key combinations to perform functions
such as controlling the screen brightness and specifying where to
display output.

HotKey Function Description

Fn-F5 Display toggle Switches display output between the

Fn-

↑

Fn-↓ Brightness down Decreases the screen brightness.

Brightness up Increases the screen brightness.

display screen, external monitor (if
connected) and both the display screen
and external monitor.

When activating hotkeys, press and hold the Fn key before pressing
the other key in the hotkey combination.

TMa550.book Page 19 Wednesday, October 3, 2001 10:57 AM

Keyboard ergonomics

Located below the keyboard, the wide and curved palm rest is
ergonomically designed to provide you with a very comfortable place
to rest your hands while you type.

19

TMa550.book Page 20 Wednesday, October 3, 2001 10:57 AM

1 Getting familiar with your computer20

Touchpad

The built-in touchpad is a PS/2-compatible pointing device that senses
movement on its surface. This means the cursor responds as you move
your finger on the surface of the touchpad. The central location on
the palm rest provides optimum comfort and support.

Touchpad basics

The following teaches you how to use the touchpad:

• Move your finger across the touchpad to move the cursor.

• Press the left (1) and right (2) buttons located on the edge of the

touchpad to do selection and execution functions. These two
buttons are similar to the left and right buttons on a mouse.
Tapping on the touchpad produces similar results.

TMa550.book Page 21 Wednesday, October 3, 2001 10:57 AM

=

21

Function Left Button

Execute Click twice

quickly.

Right
Button

Tap

Tap twice (at the same speed
as double-clicking the mouse
button).

Select Click once. Tap once.

Drag Click and hold,

then use finger
to drag the
cursor on the
touchpad.

Access
context

Click
once.

Tap twice (at the same speed
as double-clicking the mouse
button) and hold finger to the
touchpad on the second tap to
drag the cursor.

menu

Scroll

Note: Keep your fingers dry and clean when using the touchpad.
Also keep the touchpad dry and clean. The touchpad is sensitive
to finger movements. Hence, the lighter the touch, the better the
response. Tapping too hard will not increase the touchpad’s
responsiveness.

TMa550.book Page 22 Wednesday, October 3, 2001 10:57 AM

1 Getting familiar with your computer22

Launch keys

Located near the front end of the computer (between the speakers)
are launch keys that perform various functions.

Depending on the set mode, these launch keys may be used to launch
applications or play back music CDs.

Note: The Audio DJ feature is also available even when the
computer is off.

# Item Icon Description

1 Mode switch This sets the launch key mode. Slide the

switch to the desired mode.

AP (Application) mode

Lock mode

Audio DJ mode

TMa550.book Page 23 Wednesday, October 3, 2001 10:57 AM

# Item Icon Description

23

21

(AP mode)

Stop/Eject
(Audio DJ mode)

32

(AP mode)

Play/Pause
(Audio DJ mode)

4Email

(AP mode)

Previous track
(Audio DJ mode)

5 Internet browser

(AP mode)

Next track
(Audio DJ mode)

6 Volume buttons Decreases (-) or increases (+) the

Launches a user-configurable
application.

Stops playback of the music CD; when
playback is stopped, ejects the drive
tray.

Launches a user-configurable
application.

Plays and pauses playback of the music
CD.

Launches your email program.

Jumps to the previous track on the
music CD.

Launches your Internet browser.

Jumps to the next track on the music
CD.

volume.

To configure the launch keys and the applications they launch, see
“Easy Button” on page 62.

TMa550.book Page 24 Wednesday, October 3, 2001 10:57 AM

1 Getting familiar with your computer24

Storage

This computer’s all-in-one design gives you the benefit of using the
following media storage options:

• High-capacity Enhanced-IDE hard disk
The hard disk can be upgraded when you need more storage

space. Consult your dealer for details.

• 3.5-inch floppy drive
The floppy drive reads and writes on standard 3.5-inch diskettes.

• High-speed optical drive
A high-speed optical drive (CD-ROM, DVD-ROM, or DVD/CD-RW)

gives you portable multimedia access.

For the location of these drives, see “A tour of your computer” on
page 3.

TMa550.book Page 25 Wednesday, October 3, 2001 10:57 AM

Connectivity options

The computer has built-in features for connecting to a network and
communicating with other computers.

Ethernet and LAN

The built-in network feature allows you to connect your computer to
an Ethernet-based (10/100 Mbps) network.

To use the network feature, connect an Ethernet cable from the
network jack on the rear of the computer to a network jack or hub on
your network. For the location of this port, see “Rear view” on page 7.

Fax/data modem

The computer has a built-in fax/data modem.

25

Warning: This modem port is not compatible with digital
phone lines. Plugging this modem into a digital phone line
will damage the modem.

To use the fax/data modem port, connect a phone cable from the
modem port to a telephone jack. For the location of this port, see
“Rear view” on page 7.

TMa550.book Page 26 Wednesday, October 3, 2001 10:57 AM

1 Getting familiar with your computer26

Audio

Your computer includes 16-bit high-fidelity stereo audio. The dual
speakers, located near the front of the computer, direct sound towards
you to further enhance sound output and quality.

There are audio ports on the right side of the computer. See “Right
view” on page 6 for the location and description of these ports. For
information on how to connect external audio devices to these ports,
see “Audio devices” on page 42.

Adjusting the volume

Press the volume buttons to increase (+) or decrease (-) the volume. For
the location of these buttons, see “Launch keys” on page 22.

Using the Audio DJ feature

The Audio DJ feature allows you to control the playback of music CDs
even with the computer turned off. Do as follows:

1 Slide the launch key mode switch to Audio DJ mode. For the

location of this switch, see “Launch keys” on page 22.

Note: If the computer is off, the power status indicator lights up.

2 Press the optical drive eject button; then pull out the drive tray.
3 Insert a music CD on the optical drive until it clicks in place on the

spindle.

4 Close the optical drive tray securely.
5 You can now press the CD playback buttons to play the music CD.

Adjust the volume by pressing the volume buttons (+ to increase; ­to decrease).

For more information on the CD playback buttons, see “Launch keys”
on page 22.

TMa550.book Page 27 Wednesday, October 3, 2001 10:57 AM

Securing your computer

Security features include hardware and software locks — a security
notch and a password.

Security notch

A security notch located on the rear panel of the computer lets you
connect a Kensington-compatible computer security lock. For the
location of this notch, see “Rear view” on page 7.

Wrap a computer security lock cable around an immovable object such
as a table or locked drawer handle. Insert the lock into the notch and
turn the key to secure the lock. Some keyless models are available.

Passwords

The user password protects your computer and the BIOS Setup Utility
from unauthorized access. When set with appropriate options
enabled, no one can access the computer without entering the correct
password.

27

See “BIOS Setup Utility” on page 64 for details on how to set a
password and related options.

Important: Do not forget your password! If you forget your
password, you need to contact your dealer.

TMa550.book Page 28 Wednesday, October 3, 2001 10:57 AM

1 Getting familiar with your computer28

TMa550.book Page 29 Wednesday, October 3, 2001 10:57 AM

2 Operating on

battery power

TMa550.book Page 30 Wednesday, October 3, 2001 10:57 AM

The computer operates on AC or battery power. This
chapter contains the information you need to know
to operate the computer on battery power. It also
includes information on how your computer
manages and saves power.

TMa550.book Page 31 Wednesday, October 3, 2001 10:57 AM

Battery pack

The computer uses a battery pack that gives you long use between
charges.

Battery pack characteristics

The battery pack has the following characteristics:

• Employs current battery technology standards

• Battery-low warning

Whenever possible, use the AC adapter. The battery will come in
handy when you travel or during a power failure. It is advisable to
have an extra fully-charged battery pack available as backup. See your
dealer for more details.

Using a battery pack for the first time

When using a battery pack for the first time, follow these steps:
1 Connect the AC adapter to a power source and to the computer

and fully recharge the battery.

2 Disconnect the adapter to use up the battery before recharging

again.

31

You only need to do this once or twice with a new battery or with a
battery that's been stored without being used for a long time. If the
computer is to be stored for more than two weeks, we suggest you
remove the battery pack.

Warning! Do not expose battery packs to temperatures
below 0ºC (32ºF) or above 60ºC (140ºF). This may adversely
affect the battery pack.

Installing and removing the battery pack

Important! Before removing the battery pack, make sure that
you have an AC adapter connected to the computer; otherwise,
turn off the computer.

TMa550.book Page 32 Wednesday, October 3, 2001 10:57 AM

2 Operating on battery power32

To install a battery pack:

1 Place the battery pack into the battery bay, connector-end first.
2 Press down on the battery pack until you hear the battery latch

in place.

click

To remove the battery pack:

1 Press and hold the battery release button.
2 Slide the battery release latch to unlatch the battery pack.
3 Pull up the battery pack to remove it.

TMa550.book Page 33 Wednesday, October 3, 2001 10:57 AM

Charging the battery

To charge the battery, slide the battery pack into the battery bay and
plug the AC adapter into the computer and an electrical outlet.

Charging modes

The adapter has two charging modes:

• Rapid mode
The computer uses rapid charging when power is turned off and a

powered AC adapter is connected to it. In rapid mode, a fully
depleted battery gets fully charged in approximately 3 hours.

• Charge-in-use mode
When the computer is in use with the AC adapter plugged in, the

computer also charges the battery pack if installed. This mode will
take longer to fully charge a battery than rapid mode. In charge­in-use mode, a fully depleted battery gets fully charged in
approximately 4.5 hours.

33

Note: We suggest that you charge the battery pack before
retiring for the day, letting it charge overnight before traveling.
This ensures a fully charged battery for use the next day.

Checking the battery level

Using the Windows battery meter

The Windows battery meter indicates the present battery level. Simply
rest your cursor on the battery meter (or AC plug) icon on the taskbar
to see the present charge level of your battery.

Optimizing battery life

This section helps you get the most out of battery operation.
Optimizing battery life prolongs the charge/recharge cycle and
improves recharge efficiency. Follow these suggestions to optimize
and maximize battery power:

• Purchase an extra battery pack.

TMa550.book Page 34 Wednesday, October 3, 2001 10:57 AM

2 Operating on battery power34

• Use the AC adapter whenever possible so that the battery is
reserved for on-the-go computing.

• Keep the battery pack in the computer powered by the AC
adapter. The constant trickle charge maintains the battery level to
eliminate the battery self-discharge effect. The charge-in-use
function also charges the battery pack.

• Disable the parallel port if no devices are connected to this port.
You can do this through the BIOS Setup Utility. See “Others” on
page 71.

• Eject the PC Card from the slot when it is not in use, since the PC
Card draws extra power. See “Ejecting a card” on page 44.

• Store the battery pack in a cool, dry place. The recommended
storage temperature for battery packs ranges from 10 to 30
degrees Celsius. The higher the storage temperature, the faster
the battery pack self-discharges.

• The batteries can be recharged about 400 times when used as
directed. Excessive recharging decreases battery life.

• Take care of your battery pack and AC adapter. See “Taking care
of your computer” on page iv of the preface.

Battery-low warning

You never have to worry about battery power as long as you are using
the AC adapter. However, when you operate the computer on battery
power, pay extra attention to the battery gauge on the status LCD.

Warning! Connect the AC adapter to the computer as soon
as possible. Data is lost when computer power is cut off
during Standby mode.

TMa550.book Page 35 Wednesday, October 3, 2001 10:57 AM

The following table shows the recommended course of action to take
when you encounter a battery-low condition.

Situation Recommended Action

35

AC adapter and
power outlet
available

An extra fully­charged battery pack
available

AC adapter or power
outlet not available

1. Connect the AC adapter to the computer.

2. Save all necessary files.

3. Resume work.
Power off the computer if you wish to recharge the

battery rapidly.

1. Save all necessary files.

2. Exit the application.

3. Power off the computer.

4. Replace the battery pack.

5. Power on the computer and resume work.

1. Save all necessary files.

2. Exit the application.

3. Power off the computer.

TMa550.book Page 36 Wednesday, October 3, 2001 10:57 AM

2 Operating on battery power36

Power management

This computer has a built-in power management unit that monitors
system activity. System activity refers to any activity involving one or
more of the following devices: keyboard, mouse, floppy drive, hard
disk, peripherals connected to the serial and parallel ports, and video
memory. If no activity is detected for a period of time (called an
inactivity timeout), the computer stops some or all of these devices in
order to conserve energy.

This computer employs a power management scheme that supports
ACPI (Advanced Configuration and Power Interface) which allows for
maximum power conservation and maximum performance at the same
time. ACPI enables Windows to control the amount of power given to
each device attached to the computer. Windows handles all power­saving chores for your computer. For more information, refer to
Windows help.

TMa550.book Page 37 Wednesday, October 3, 2001 10:57 AM

3 Peripherals and

options

TMa550.book Page 38 Wednesday, October 3, 2001 10:57 AM

Your computer offers excellent expansion
capabilities with its built-in ports and
connectors. This chapter describes how to
connect peripherals and hardware options
that help you use your computer with ease.
When connecting peripherals, read the
manual included with the peripheral for
operating instructions. You can purchase most
of these and other options directly from
authorized dealers.

This chapter also includes sections on how to
upgrade key components. Key component
upgradeability helps keep your computer in
step with the latest technology.

TMa550.book Page 39 Wednesday, October 3, 2001 10:57 AM

External display devices

External monitor

You can connect an external monitor to the external display port. For
the location of these ports, see “Rear view” on page 7. Read the
monitor manual for additional instructions.

Note: If an external monitor is not connected, closing the display
cover puts the computer into Standby mode.

External display with s-video input

You can connect an external display device such as a television or
projector with s-video input to the video-out port on the rear of the
computer. For the location of this connector, see “Rear view” on page

7. Read the manual for your TV or projector for additional operating
instructions.

39

Using simultaneous display

Your computer takes advantage of Windows multi-display capability,
allowing you to use your computer for presentation purposes. So
whatever is displayed in your computer will likewise be displayed on
the other external display. Press Fn-F5 to toggle the display output
location.

To use simultaneous display, you can choose to connect the display
device to the computer through the external display port or video-out
port, depending on what your display device supports.

TMa550.book Page 40 Wednesday, October 3, 2001 10:57 AM

3 Peripherals and options40

External input devices

External keyboard

This computer has a keyboard with full-sized keys and an embedded
keypad. If you feel more comfortable using a desktop keyboard, you
can connect an external PS/2-compatible or USB keyboard.

Plug a PS/2 keyboard into the PS/2 port; plug the USB keyboard to an
available USB port. For the location of these ports, see “Right view” on
page 6.

External keypad

You can also use a 17-key numeric keypad for number-sensitive, data­entry applications. To connect the keypad, plug the keypad connector
into the PS/2 port or USB port depending on what your device
supports. For the location of these ports, see “Right view” on page 6.

External pointing device

This computer accepts either a PS/2-compatible or USB mouse or similar
pointing device. To use a PS/2-compatible mouse, simply plug it into
the PS/2 port. If you use a USB mouse, connect it to an available USB
port. For the location of these ports, see “Right view” on page 6.

TMa550.book Page 41 Wednesday, October 3, 2001 10:57 AM

Printer

This computer supports both parallel and USB printers. For a parallel
printer, plug the printer cable into the parallel port. For a USB printer,
connect it to the USB port. For the location of these ports, see “Rear
view” on page 7 and “Right view” on page 6.

To operate your printer, see your printer manual.

Note: If the printer does not function, enter the BIOS Setup Utility
and verify that the parallel port is enabled. See “Others” on page
71 for assistance.

41

TMa550.book Page 42 Wednesday, October 3, 2001 10:57 AM

3 Peripherals and options42

Audio devices

You can plug an external microphone into the microphone-in jack.
Amplified speakers or headphones connect to the speaker/headphone­out jack. For the location of these ports, see “Right view” on page 6.

TMa550.book Page 43 Wednesday, October 3, 2001 10:57 AM

Expansion devices

PC Card slots

The computer has built-in CardBus PC Card slots that can accommodate
one type III or two type II/I PC Cards. Please consult your dealer for PC
Card options available that you can purchase for your computer.

The PC Card slots found on the right of the computer accepts credit­card-sized cards that enhance the usability and expandability of the
computer.

PC Cards (formerly PCMCIA) are add-on cards for portable computers,
giving you expansion possibilities long afforded by desktop PCs.
Popular type II cards include flash memory, SRAM, fax/data modem,
LAN and SCSI cards. CardBus improves on the 16-bit PC Card
technology by expanding the data path to 32 bits.

Note: Refer to your card’s manual for details on how to install and
use the card and its functions.

43

Inserting a card

Note: Insert a type III PC Card in the lower slot.

Insert the card into the appropriate slot and make the proper
connections (e.g., cable), if necessary. See your card manual for details.

TMa550.book Page 44 Wednesday, October 3, 2001 10:57 AM

3 Peripherals and options44

Ejecting a card

Before ejecting a PC Card:

• Exit the application using the card.

• Left-click on the Safely Remove Hardware icon on the taskbar and

click on the safely remove card operation.

After it is safe to remove the card, press the slot eject button once to
pop it out (1); then press it again to eject the PC Card (2).

USB

The computer has two USB (Universal Serial Bus) ports that allow you
to connect peripherals without occupying too many resources. USB
devices are also plug and play which means you don’t need to turn off
your computer to connect and use the device. Common USB devices
include the mouse, keyboard, and digital cameras. You can also daisy­chain USB devices via USB hubs.

For the location of these ports, see “Right view” on page 6.

Disconnecting USB devices

Before disconnecting a USB device:

• Stop all applications using the USB device.

• Left-click on the Safely Remove Hardware icon on the taskbar and

click on the safely remove device operation.

Now you can unplug the USB device from the computer.

TMa550.book Page 45 Wednesday, October 3, 2001 10:57 AM

IEEE 1394

The computer's fast IEEE 1394 port allows you to connect IEEE 1394
supported devices like a digital camcorder, external hard disks, or
external CD burners. You can also daisy-chain IEEE 1394 devices via a
IEEE 1394 repeater.

For the location of these ports, see “Rear view” on page 7.

Disconnecting IEEE 1394 devices

Before disconnecting a IEEE 1394 device:

• Stop all applications using the IEEE 1394 device.

• Left-click on the Safely Remove Hardware icon on the taskbar and

click on the safely remove device operation.

Now you can unplug the IEEE 1394 device from the computer.

45

TMa550.book Page 46 Wednesday, October 3, 2001 10:57 AM

3 Peripherals and options46

Miscellaneous options

Battery pack

It is a good practice to have a spare battery around, especially when
you travel. The Li-ion battery, coupled with the power management
features of your computer, supplies you with more power on-the-go.

AC adapter

The compact AC adapter charges your battery pack and supplies power
to your computer. You can order a spare AC adapter so you do not
need to carry it from the office to your home or destination.

TMa550.book Page 47 Wednesday, October 3, 2001 10:57 AM

Key component upgrades

Your computer delivers superior power and performance. However,
some users and the applications they use may demand more. This
computer allows you to upgrade key components when you need
increased performance.

Note: Contact your authorized dealer if you decide to perform a
key component upgrade.

Memory upgrade

This notebook computer comes with one memory upgrade slot that
accepts a soDIMM (Small Outline Dual Inline Memory Module). It
supports PC-133 Synchronous Dynamic Random Access Memory
(SDRAM).

47

Installing memory

Follow these steps to install memory:
1 Turn off the computer, unplug the AC adapter (if connected) and

remove the battery pack. Then turn the computer over to access
its base.

TMa550.book Page 48 Wednesday, October 3, 2001 10:57 AM

3 Peripherals and options48

2 Remove the screws from the memory door (1), slide the memory

door (2), then lift the memory door (3) to access the memory slot.

3 Insert the memory module diagonally into the slot (1), then gently

press down until it clicks into place (2).

4 Replace the memory door and secure it with the screws.

The computer automatically detects and reconfigures the total
memory size.

Note: The system allocates a portion of main memory for video
which can be adjusted in the BIOS Setup Utility. See “System
Devices” on page 67 for details.

TMa550.book Page 49 Wednesday, October 3, 2001 10:57 AM

Hard disk upgrade

It is possible to upgrade your hard disk with a higher capacity drive
when you need more storage space. The computer uses a 9.5mm 2.5­inch Enhanced-IDE hard disk. Please consult your dealer if you need to
upgrade your hard disk.

49

TMa550.book Page 50 Wednesday, October 3, 2001 10:57 AM

3 Peripherals and options50

TMa550.book Page 51 Wednesday, October 3, 2001 10:57 AM

4 Moving with your

computer

TMa550.book Page 52 Wednesday, October 3, 2001 10:57 AM

This chapter gives you tips and hints on
things to consider when moving around
or traveling with your computer.

TMa550.book Page 53 Wednesday, October 3, 2001 10:57 AM

Disconnecting from the desktop

Follow these steps to disconnect your computer from external
accessories:

1 Save your work in progress.
2 Shut down the operating system.
3 Turn off the computer.
4 Disconnect the cord from the AC adapter.
5 Disconnect the keyboard, pointing device, printer, external

monitor, and other external devices.

6 Disconnect the Kensington lock if you are using one to secure the

computer.

53

TMa550.book Page 54 Wednesday, October 3, 2001 10:57 AM

4 Moving with your computer54

Moving around

when you are just moving within short distances, for example, from
your office desk to a meeting room

Preparing the computer

Before moving the computer, close and latch the display cover to place
it in Standby mode. You can now safely take the computer anywhere
you go within the building.

To bring the computer out of Standby mode, open the display.

What to bring to short meetings

A fully charged battery runs the computer for 2 1/2 hours under most
circumstances. If your meeting is shorter than that, you probably do
not need to bring anything with you other than the computer.

What to bring to long meetings

If your meeting will last longer than 2 1/2 hours or if your battery is not
fully charged, you may want to bring the AC adapter with you to plug
in your computer in the meeting room.

If the meeting room does not have an electrical outlet, reduce the
drain on the battery by putting the computer in power-saving mode.
Close the display cover whenever you are not actively using the
computer. Open the display to resume.

TMa550.book Page 55 Wednesday, October 3, 2001 10:57 AM

Taking the computer home

when you are moving from your office to your home or vice versa

Preparing the computer

After disconnecting the computer from your desktop, follow these
steps to prepare the computer for the trip home:

1 Remove all media from the drives. Failure to remove the media

can damage the drive head.

2 Pack the computer in a protective case that can prevent the

computer from sliding around and cushion it if it should fall.

Caution: Avoid packing items next to the top cover of the
computer. Pressure against the top cover could damage the
screen.

55

What to bring with you

Unless you already have some items at home, bring the following items
with you:

• AC adapter and power cord

• The printed user’s manual

Special considerations

Follow these guidelines to protect your computer while traveling to
and from work:

• Minimize the effect of temperature changes by keeping the
computer with you.

• If you need to stop for an extended period of time and cannot
bring the computer with you, leave the computer in the trunk of
the car to avoid exposing the computer to excessive heat.

• Changes in temperature and humidity can cause condensation.
Allow the computer to return to room temperature, and inspect
the screen for condensation before turning on the computer. If
the temperature change is greater than 18°F (10°C), allow the
computer to come to room temperature slowly. If possible, leave

TMa550.book Page 56 Wednesday, October 3, 2001 10:57 AM

4 Moving with your computer56

the computer for 30 minutes in an environment with a
temperature between outside and room temperature.

Setting up a home office

If you frequently work on your computer at home, it may be
worthwhile to purchase a second AC adapter for use at home. With a
second AC adapter, you can avoid transporting the extra weight to and
from home.

If you use your computer at home for significant periods of time, you
might also want to add an external keyboard, monitor, or mouse.

TMa550.book Page 57 Wednesday, October 3, 2001 10:57 AM

Traveling with the computer

when you are moving within a larger distance, for instance, from your
office building to a client’s office building or traveling locally

Preparing the computer

Prepare the computer as if you were taking it home. Be sure the
battery in the computer is charged. Airport security may require you
to turn on your computer when bringing it into the gate area.

What to bring with you

Bring the following items with you:

• AC adapter

• Spare, fully charged battery packs

• Additional printer driver files if you plan to use another printer

57

Special considerations

In addition to the guidelines for taking the computer home, follow
these guidelines to protect your computer while traveling:

• Always take the computer as carry-on luggage.

• If possible, have the computer inspected by hand. The computer

can safely pass through security X-ray machines, but never expose
the computer to a metal detector.

• Avoid exposing floppy disks to hand-held metal detectors.

TMa550.book Page 58 Wednesday, October 3, 2001 10:57 AM

4 Moving with your computer58

Traveling internationally with the
computer

when you are moving from country to country

Preparing the computer

Prepare the computer as you would normally prepare it for traveling.

What to bring with you

Bring the following items with you.

• AC adapter

• Power cords that are appropriate to the country to which you are

traveling

• Spare, fully charged battery packs

• Additional printer driver files if you plan to use another printer

Special considerations

Follow the same special considerations as when traveling with the
computer. In addition, these tips are useful when traveling
internationally.

• When traveling in another country, check that the local AC voltage
and the AC adapter power cord specifications are compatible. If
not, purchase a power cord that is compatible with the local AC
voltage (e.g., power rating). Do not use converter kits sold for
appliances to power the computer.

• If you are using the modem, check if the modem and connector is
compatible with the telecom system of the country you are
traveling in.

TMa550.book Page 59 Wednesday, October 3, 2001 10:57 AM

5 Software

TMa550.book Page 60 Wednesday, October 3, 2001 10:57 AM

This chapter discusses the important system
utilities bundled with your computer.

TMa550.book Page 61 Wednesday, October 3, 2001 10:57 AM

System software

The computer comes preloaded with the following software:

• Microsoft Windows operating system

• Hardware BIOS setup utility

• System utilities, drivers and application software

Note: To access Windows software applications, click on the Start
button and select the application folder. Then click on the
application icon to run the selected application. To learn about
the software and utility, make use of the online help provided by
the software.

61

TMa550.book Page 62 Wednesday, October 3, 2001 10:57 AM

Easy Button

Easy Button allows you to set the four launch keys located near the
front of the computer. See “Launch keys” on page 22 for the location
of these keys.

To configure Easy Button, double-click on its icon on the taskbar.
Pressing on a launch key that has not been configured will also allow
you to configure Easy Button. To see other Easy Button options, right­click on the Easy Button icon on the taskbar.

5 Software62

TMa550.book Page 63 Wednesday, October 3, 2001 10:57 AM

E-Mail Detector

The E-Mail Detector application monitors your mail servers for
incoming email. When incoming email is detected, the email status
indicator lights up. You can also set a notify message to appear or a
sound to play when you receive incoming email.

To configure E-Mail Detector, double-click on its icon on the taskbar.
To see other E-Mail Detector options, right-click on the E-Mail Detector
icon on the taskbar.

63

TMa550.book Page 64 Wednesday, October 3, 2001 10:57 AM

BIOS Setup Utility

The BIOS Setup Utility is a hardware configuration program built into
your computer’s BIOS (basic input/ouput system).

Your computer is already properly configured and optimized, and you
do not need to run this utility. However, if you encounter
configuration problems, you may need to run it. Please also refer to
Chapter 6, Troubleshooting when a problem arises.

To activate the BIOS Setup Utility, press F2 during POST.

5 Software64

Main System Devices Security Others Boot Exit

System Time:
System Date:

Floppy Drive:
Hard Disk:

Quiet Boot:
Power on display:
LCD Display stretch:

System Memory:
Extended Memory:

BIOS Ver.

F1 Help Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit Select Menu Enter Select > Sub-Menu F10 Save and Exit

[11:21:00]
[09/11/2001]

1.44MB, 3
IBM-DJSA-220-(PM)

[Enabled]
[Auto-Selected]
[Enabled]

640 KB
113664 KB

V0.01

↑↓
←→

½”

Item Specific Help

Navigating the BIOS Setup Utility

There are six menu options: Main, System Devices, Security, Others,
Boot and Exit.

Follow these instructions:

• To choose a menu, use the cursor left/right keys (← →

• To choose a parameter, use the cursor up/down keys (↑↓).

• To change the value of a parameter, press F5 or F6.

Note: You can change the value of a parameter if it is enclosed in
square brackets.

).

• A plus sign (+) indicates the item has sub-items. Press Enter to
expand this item.

TMa550.book Page 65 Wednesday, October 3, 2001 10:57 AM

• Press Esc while you are in any of the menu options to go to the
Exit menu.

• In any menu, you can load default settings by pressing F9. You can
also press F10 to save any changes made and exit the BIOS Setup
Utility.

Notes:

Navigation keys for a particular menu are shown on the bottom of
the screen.

Help for parameters are found in the Item Specific Help part of
the screen. Read this carefully when making changes to
parameter values.

Main

The Main screen displays a summary of your computer hardware
information, and also includes basic setup parameters.

65

Main System Devices Security Others Boot Exit

System Time:
System Date:

Floppy Drive:
Hard Disk:

Quiet Boot:
Power on display:
LCD Display stretch:

System Memory:
Extended Memory:

BIOS Ver.

F1 Help Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit Select Menu Enter Select > Sub-Menu F10 Save and Exit

[11:21:00]
[09/11/2001]

1.44MB, 3
IBM-DJSA-220-(PM)

[Enabled]
[Auto-Selected]
[Enabled]

640 KB
113664 KB

V0.01

↑↓
←→

½”

Item Specific Help

Note: The screen above is for reference only. Actual values may
differ.

TMa550.book Page 66 Wednesday, October 3, 2001 10:57 AM

The table below describes the parameters in this screen. Settings in
boldface are the default and suggested parameter settings.

Parameter Description

System Time Sets the system time.

Format: HH:MM:SS (hour:minute:second)

System Date Sets the system date.

Format: MM/DD/YYYY (month/day/year)

Floppy Drive Shows floppy drive type information.

Hard Disk Shows the hard disk model.

Quiet Boot Determines the way the system boots up.

Options: Enabled or Disabled

Power on display Determines the display device on startup.

Options: Auto-Selected or Simultaneous

5 Software66

LCD Display stretch Specifies whether or not to expand the image to fill

the screen.
Options: Enabled or Disabled

System Memory Shows the amount of system memory.

Extended Memory Shows the amount of extended memory

BIOS Ver. Shows the system BIOS version.

Note: Main memory = system memory + extended memory

TMa550.book Page 67 Wednesday, October 3, 2001 10:57 AM

System Devices

The System Devices screen contains parameters involving your
hardware devices.

67

Main Security Others Boot ExitSystem Devices

Pointing Device:
Ext. Keyboard “Fn”:
IDE Controller:
FDD Controller:

Parallel Port:

Interrupt:
Mode:
Base I/O address:
DMA channel:

VGA Frame Buffer Size:

F1 Help Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit Select Menu Enter Select > Sub-Menu F10 Save and Exit

↑↓
←→

[Simultaneous]
[Enabled]
[Both]
[Enabled]

[Enabled]
[IRQ 7]
[ECP]
[378]
[DMA 3]

[16 Mb]

Item Specific Help

The table below describes the parameters in the screen. Settings in
boldface are the default and suggested parameter settings.

Parameter Description

Pointing Device Determines whether or not to disable the internal

touchpad if a PS/2 pointing device is connected.
Options: Simultaneous or Auto-Selected

Ext. Keyboard “Fn” Allows you to simulate an Fn key on an external

keyboard by pressing the left Ctrl+left Alt keys.
Options: Enabled or Disabled

IDE Controller Enables or disables the primary or secondary IDE

controller or both.
Options: Both, Primary or Disabled

FDD Controller Enables or disables the floppy drive controller.

Options: Enabled or Disabled

Parallel Port Enables or disables the parallel port.

Options: Enabled or Disabled

IRQ Sets the interrupt request of the parallel port.

Options: IRQ 7 or IRQ 5

TMa550.book Page 68 Wednesday, October 3, 2001 10:57 AM

Parameter Description

Mode Sets the operation mode of the parallel port.

Options: ECP, EPP or Bi-directional

Base I/O address Sets the I/O address of the parallel port. This

parameter is enabled only if Mode is set to ECP or
Bi-directional.

Options: 378, 278 or 3BC

DMA Channel Sets a DMA channel for the printer to operate in

ECP mode. This parameter is enabled only if Mode
is set to ECP.

Options: 3 or 1

5 Software68

VGA Frame Buffer
Size

Specifies the amount of main memory to allocate
for VGA.

Options: 16 Mb, 32 Mb or 8 Mb

Note: VGA takes up a portion of system memory, configurable via
the VGA Frame Buffer parameter. For example, if you have 128
MB SDRAM, and you set a VGA Frame Buffer of 16 MB, main
memory is 112 MB.

Security

The Security screen contains parameters that help safeguard and
protect your computer from unauthorized use.

Main System Devices Others Boot ExitSecurity

User Password:

Set User Password:

Password on boot:

Clear

[Enter]

[Disabled]

Item Specific Help

F1 Help Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit Select Menu Enter Select > Sub-Menu F10 Save and Exit

↑↓
←→

TMa550.book Page 69 Wednesday, October 3, 2001 10:57 AM

The table below describes the parameters in this screen. Settings in
boldface are the default and suggested parameter settings.

Parameter Description

User Password Shows the setting of the user password.

Options: Clear or Set

Set User Password Press Enter to set the user password. When set, this

password protects the BIOS Setup Utility from
unauthorized access.

Password on boot When enabled, the user password protects the

computer from unauthorized access during boot up.
Options: Disabled or Enabled

Notes:

69

When you are prompted to enter a password, you have three tries
before the system halts.

Don’t forget your password. If you forget your password, you
may have to return your notebook computer to your dealer to
reset it.

Setting a password

Follow these steps:
1 Use the

and press the Enter key. The Set Password box appears:

2 Type a password in the Enter new password field. The password

may consist of up to eight alphanumeric characters (A-Z, a-z, 0-9).

Retype the password in the Confirm new password field.

↑ and ↓ keys to highlight the Set User Password parameter

Set Password

Enter new password:

Confirm new password:

[ ]
[ ]

Important: Be very careful when typing your password because
the characters do not appear on the screen.

TMa550.book Page 70 Wednesday, October 3, 2001 10:57 AM

3 Press Enter.

After setting the password, the computer sets the User Password
parameter to “Set”.

4 If desired, you can opt to enable the Password on boot parameter.
5 When you are done, press F10 to save the changes and exit the

BIOS Setup Utility.

Removing a password

Follow these steps:
1 Use the

and press the Enter key. The Set Password box appears:

2 Type the current password in the Enter Current Password field and

press Enter.

3 Press Enter twice without

Password and Confirm New Password fields.
The computer then sets the User Password parameter to “Clear”.

4 When you are done, press F10 to save the changes and exit the

BIOS Setup Utility.

↑ and ↓ keys to highlight the Set User Password parameter

Set Password

Enter Current Password

Enter New Password

Confirm New Password

[ ]
[ ]
[ ]

typing anything in the Enter New

5 Software70

Changing a password

Follow these steps:
1 Use the

and press the Enter key. The Set Password box appears:

2 Type the current password in the Enter Current Password field and

press Enter.

3 Type a password in the Enter new password field.

Retype the password in the Confirm new password field.

↑ and ↓ keys to highlight the Set User Password parameter

Set Password

Enter Current Password

Enter New Password

Confirm New Password

[ ]
[ ]
[ ]

TMa550.book Page 71 Wednesday, October 3, 2001 10:57 AM

4 Press Enter.

After setting the password, the computer sets the User Password
parameter to “Set”.

5 If desired, you can opt to enable the Password on boot parameter.
6 When you are done, press F10 to save the changes and exit the

BIOS Setup Utility.

Others

The Others screen contains various parameter settings.

71

Main System Devices Security Boot ExitOthers

Low Battery Alarm:
Panel Close Alarm:
System Beep:

Installed O/S:

F1 Help Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit Select Menu Enter Select > Sub-Menu F10 Save and Exit

↑↓
←→

[Enabled]
[Disabled]
[Enabled]

[Win98/Me/2K/XP]

Item Specific Help

The table below describes the parameters in this screen. Settings in
boldface are the default and suggested parameter settings.

Parameter Description

Low Battery
Alarm

Panel Close
Alarm

Determines whether or not the system will alarm when
the battery power is low.

Options: Enabled or Disabled

Determines whether or not the system will alarm when
the display cover is closed.

Options: Disabled or Enabled

System Beep Determines whether or not the system will emit a beep

on boot up.
Options: Enabled or Disabled

TMa550.book Page 72 Wednesday, October 3, 2001 10:57 AM

Parameter Description

Installed O/S Sets the operating system in use.

Options: Win98/Me/2K/XP or Only Win NT4.0

Boot

The Boot screen allows you to set the order in which the system looks
for bootable devices on startup.

5 Software72

Main System Devices Security Others ExitBoot

+Removable Devices
+Hard Drive

CD-ROM/DVD Drive

F1 Help Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit Select Menu Enter Select > Sub-Menu F10 Save and Exit

↑↓
←→

Item Specific Help

The table below describes these devices.

Parameter Description

Removable
Devices

Hard Drive The computer attempts to boot from the hard disk. If

CD-ROM/DVD
Drive

The computer attempts to boot from the removable device
(e.g., floppy drive). If unsuccessful, the system goes to the
next device in the list.

unsuccessful, the system goes to the next device in the list.

The computer attempts to boot from the CD or DVD drive
(looks for a bootable CD or DVD).

Note: A plus (+) sign may be shown in front of a device. You can
press Enter to “expand” the device and see sub-items in this
category.

TMa550.book Page 73 Wednesday, October 3, 2001 10:57 AM

Exit

The Exit screen contains parameters that help safeguard and protect
your computer from unauthorized use.

73

Main System Devices Security Others Boot Exit

Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes

F1 Help Select Item F5/F6 Change Values F9 Setup Defaults
Esc Exit Select Menu Enter Execute Command F10 Save and Exit

↑↓
←→

Item Specific Help

The table below describes the parameters in this screen.

Parameter Description

Exit Saving Changes Saves changes made and exits the BIOS Setup

Utility (same as F10).

Exit Discarding Changes Discards changes made and exits the BIOS

Setup Utility.

Load Setup Defaults Loads default settings for all parameters (same

as F9).

Discard Changes Discards changes made.

Save Changes Saves changes made.

Note: In any menu, you can load default settings by pressing F9.
You can also press F10 to save any changes made and exit the BIOS
Setup Utility.

TMa550.book Page 74 Wednesday, October 3, 2001 10:57 AM

5 Software74

TMa550.book Page 75 Wednesday, October 3, 2001 10:57 AM

6 Troubleshooting

TMa550.book Page 76 Wednesday, October 3, 2001 10:57 AM

This chapter instructs you on how to deal
with common system problems. Read it
before calling a technician if a problem
occurs. Solutions to more serious problems
require opening up the computer. Do not
attempt to open and service the computer
by yourself. Contact your dealer or an
authorized service center for assistance.

TMa550.book Page 77 Wednesday, October 3, 2001 10:57 AM

Frequently-asked questions

This is a list of possible situations that may arise during the use of your
computer, and it gives easy answers and solutions to these questions.

I press the power switch, but the computer does not start or boot-up.

Look at the Power status indicator:

• If it is not lit, no power is being applied to the computer. Check
the following:

• If you are running on battery power, it may be low and unable

to power the computer. Connect the AC adapter to recharge
the battery pack.

• Make sure the AC adapter is plugged in properly to the

computer and to the power outlet.

• If it is lit, check if a non-bootable (non-system) diskette is in the
floppy drive. Remove or replace it with a system diskette and press
Ctrl-Alt-Del to restart the system.

77

The operating system files may be damaged or missing. Insert the
startup disk you created during Windows setup into the floppy drive
and press Ctrl-Alt-Del to restart the system. This will diagnose your
system and make necessary fixes.

Nothing appears on the screen.

The computer’s power management system automatically blanks the
screen to save power. Press any key to turn the display back on.

If pressing a key does not turn the display back on, two things might
be the cause:

• The brightness level might be too low. Press Fn-↑ and Fn-↓ to
adjust the brightness level.

• The display device might be set to an external monitor. Press the
display toggle hot key Fn-F5 to toggle the display back to the
computer.

Image is not full-screen.

Make sure the resolution is set to a resolution your system supports
natively. Right-click on your Windows desktop and select Properties to
bring up the Display Properties dialog box. Then click on the Settings

TMa550.book Page 78 Wednesday, October 3, 2001 10:57 AM

6 Troubleshooting78

tab to make sure the resolution is set to the appropriate resolution.
Resolutions lower than the specified resolution are not full-screen on
the computer or on an external monitor.

No audio from the computer.

Check the following:

• The volume may be muted. In Windows, look at the volume
control icon on the taskbar. If it is crossed-out, click on the icon
and deselect the Mute option.

• The volume level may be too low. In Windows, look at the volume
control icon on the taskbar. Click on the icon and adjust the level.
You can also use the volume control knob on the front panel of
the computer to adjust the volume.

If headphones, earphones or external speakers are connected to the
speaker/headphone-out port on the computer, the internal speakers
automatically turn off.

External microphone does not work.

Check the following:

• Make sure the external microphone is connected to the
microphone-in jack on the computer.

• If you cannot hear playback, the speakers may be muted.

How do I eject the optical drive tray with the computer turned off?

There is a emergency eject hole on the optical drive. Simply insert the
tip of a pen or paperclip and push to eject the optical drive tray. For
the location of the emergency eject hole, see “Left view” on page 5.

The keyboard does not respond.

Try attaching an external PS/2 or USB keyboard to the appropriate port
on the computer. If it works, contact your dealer or an authorized
service center as the internal keyboard cable may be loose.

The floppy drive cannot access a diskette.

Check the following:

• Make sure the diskette is properly inserted in the floppy drive.

• Make sure the diskette is formatted.

TMa550.book Page 79 Wednesday, October 3, 2001 10:57 AM

• If the diskette is not the cause of the problem, the floppy drive
may be dirty. Clean it using a drive cleaning kit. Follow the
instructions included with the kit.

The CD or DVD drive cannot access a disc.

Check the following:

• Make sure the disc is supported by the drive. If your computer has
a CD-ROM drive, it can read CDs but cannot read DVDs. If your
computer has a DVD drive, it can read DVDs in addition to CDs.

• When placing the CD or DVD in the drive tray, make sure it is
secure in the spindle on the drive tray.

• Make sure the CD or DVD is free from scratches or smudges. If the
CD or DVD is dirty, clean it using a disc cleaning kit. Remember to
follow the instructions included with the kit.

• If the problem does not lie with the disc, your CD or DVD drive
may be dirty. Clean it using a drive cleaning kit. Follow the
instructions included with the kit.

79

The printer does not work.

Check the following:

• Make sure that the printer is connected to a power outlet and it is
turned on.

• Depending on your printer connection (USB or parallel), make sure
the printer cable is connected securely to the appropriate ports on
both the computer and the printer.

• If you use a parallel port, access the BIOS Setup Utility by pressing
F2 after restarting your system. Go to the Others screen and
verify that the parallel port is enabled. See “Others” on page 71.

I want to set up my location to use the internal modem.

Follow these steps:

1 Click on Start, then click Control Panel.
2 Double-click on Phone and Modem Options.
3 In the Dialing Rules tab, begin setting up your location.

Refer to the Windows Help and Support and the modem manual.

Why can’t I charge my battery to 100% charged when it is 99-95%

TMa550.book Page 80 Wednesday, October 3, 2001 10:57 AM

6 Troubleshooting80

charged?

To preserve the life of the battery, the system only lets you charge the
battery when its capacity falls below 95%. However, it is recommended
that you bring an extra battery and let the battery in the system use up
its power before charging it.

TMa550.book Page 81 Wednesday, October 3, 2001 10:57 AM

Error messages

If you receive an error message, note the message and take the
corrective action. The following table lists the error messages in
alphabetical order together with the recommended course of action.

Note: To enter the BIOS Setup Utility, press F2 during POST. For
more information, see “BIOS Setup Utility” on page 64.

Error Messages Corrective Action

0200 Failure Fixed Disk Hard disk error detected.

Enter the BIOS Setup Utility and verify the
hard disk is detected. If not, contact your
dealer or an authorized service center.

0211 Keyboard error Try using an external keyboard.

If the external keyboard works, contact
your dealer or an authorized service
center.

81

0212 Keyboard Controller
Failed

0220 Monitor type does not
match CMOS - Run SETUP

0230 Shadow Ram Failed at
offset: nnnn

0231 System RAM Failed at
offset: nnnn

0232 Extended RAM Failed at
offset: nnnn

Keyboard controller test failed.
Write down the message and contact your

dealer or an authorized service center.

Display device mismatch.
Enter the BIOS Setup Utility and verify the

parameters (try loading the default
settings); then save and restart your
computer.

Shadow RAM test failed.
Write down the message and contact your

dealer or an authorized service center.

System RAM test failed.
Write down the message and contact your

dealer or an authorized service center.

Extended RAM test failed.
Write down the message and contact your

dealer or an authorized service center.

TMa550.book Page 82 Wednesday, October 3, 2001 10:57 AM

Error Messages Corrective Action

6 Troubleshooting82

0250 System battery is dead ­Replace and run SETUP

CMOS clock battery needs to be replaced.
Contact your dealer or an authorized

service center.

0251 System CMOS checksum
bad - Default configuration
used

CMOS has been corrupted or modified
incorrectly.

Enter the BIOS Setup Utility and verify the
parameters; then save and restart your
computer.

If the problem persists, contact your dealer
or an authorized service center.

0260 System timer error System timer test failed, and the system

board needs to be repaired.
Write down the message and contact your

dealer or an authorized service center.

0270 Real time clock error Real time clock test failed, and the system

board may need to be repaired.
Write down the message and contact your

dealer or an authorized service center.

0271 Check date and time
settings

Date and time are out of range, and was
reset.

Enter the BIOS Setup Utility and set the
correct date and time.

0280 Previous boot incomplete

- Default configuration used

Previous boot-up was not completed
successfully.

Enter the BIOS Setup Utility and verify the
parameters (try loading the default
settings); then save and restart your
computer.

0281 Memory Size found by
POST differed from CMOS

02B0 Diskette drive A error
02B2 Incorrect Drive A type ­run SETUP

Try reinstalling the memory. See
“Installing memory” on page 47.

If the problem persists, contact your dealer
or an authorized service center.

Floppy drive test failed, and may need to
be repaired or replaced.

Contact your dealer or an authorized
service center.

TMa550.book Page 83 Wednesday, October 3, 2001 10:57 AM

Error Messages Corrective Action

83

02D0 System cache error ­Cache disabled

Cache memory test failed and was
disabled; cache needs to be replaced.

Contact your dealer or an authorized
service center.

02F4 EISA CMOS not writeable System unable to write to EISA CMOS.

Write down the message and contact your
dealer or an authorized service center.

02F5 DMA Test Failed System unable to write to DMA (Direct

Memory Access) registers.
Write down the message and contact your

dealer or an authorized service center.

02F6 Software NMI Failed System unable to generate software NMI

(Non-Maskable Interrupt).
Write down the message and contact your

dealer or an authorized service center.

02F7 Fail-Safe Timer NMI
Failed

Fail-safe timer takes too long.
Write down the message and contact your

dealer or an authorized service center.

device Address Conflict Specific device has an address conflict.

Enter the BIOS Setup Utility and verify the
parameters (try loading the default
settings); then save and restart your
computer.

Failing Bits: nnnn Memory test failed.

Write down the message and contact your
dealer or an authorized service center.

Invalid System Configuration
Data

Error with NVRAM (CMOS) data.
Enter the BIOS Setup Utility and verify the

parameters (try loading the default
settings); then save and restart your
computer.

TMa550.book Page 84 Wednesday, October 3, 2001 10:57 AM

Error Messages Corrective Action

I/O device IRQ conflict I/O device has IRQ (Interrupt Request)

conflict.
Enter the BIOS Setup Utility and verify the

parameters (try loading the default
settings); then save and restart your
computer.

Operating system not found Operating system cannot be found on the

boot device.
Enter the BIOS Setup Utility and verify the

hard disk, floppy drive, and boot
parameters (try loading the default
settings); then save and restart your
computer.

If the problem persists, you may need to
recover your hard disk, or reinstall the
operating system.

Parity Check 1 nnnn Parity error found on system bus.

Write down the message and contact your
dealer or an authorized service center.

6 Troubleshooting84

Parity Check 2 nnnn Parity error found on I/O bus.

Write down the message and contact your
dealer or an authorized service center.

If you still encounter problems after going through the corrective
measures, please contact your dealer or an authorized service center
for assistance. Some problems may be solved using the BIOS Setup
Utility. See “BIOS Setup Utility” on page 64.

TMa550.book Page 85 Wednesday, October 3, 2001 10:57 AM

Appendix A

Specifications

TMa550.book Page 86 Wednesday, October 3, 2001 10:57 AM

This appendix lists the general
specifications of your computer.

TMa550.book Page 87 Wednesday, October 3, 2001 10:57 AM

Microprocessor

• Intel® Pentium™ III processor with 256K on-die L2 cache

- or ­Intel® Celeron™ processor with 128K or 256K on-die L2 cache

Memory

• Onboard 128 MB

• Main memory expandable to 640 MB Synchronous Dynamic

Random Access Memory (SDRAM)

• One 1.25-inch, 144-pin industry-standard soDIMM socket (PC-133)

• 512 KB Flash ROM BIOS

Data storage

• One internal floppy drive (3.5”, 1.44 MB)

• One E-IDE hard disk (2.5”, 9.5mm, UltraDMA-100)

• One internal optical drive

87

Display and video

• 14.1” Thin-Film Transistor (TFT) liquid-crystal display (LCD)
displaying 16.7 million colors at 1024x768 eXtended Graphics
Array (XGA) resolution

- or -

15.0” TFT LCD displaying 16.7 million colors at 1400x1050 Super
eXtended Graphics Array Plus (SXGA+) resolution

• AGP 4X support

• Video memory allocation from main memory (BIOS)

• Simultaneous LCD and CRT display

• S-video (NTSC/PAL) output

• DualView support

TMa550.book Page 88 Wednesday, October 3, 2001 10:57 AM

Appendix A Specifications88

Audio

• 16-bit stereo audio (AC’97)

• Two built-in stereo speakers

• Audio DJ playback controls

• Audio ports for speaker/headphone-out and microphone-in

devices

Keyboard and pointing device

• 85-/86-key Windows keyboard

• Ergonomically-centered touchpad pointing device

I/O ports

• One type III or two type II/I PC Card slots (PCMCIA, CardBus)

• One RJ-11 modem jack (V.90, 56K)

• One RJ-45 network jack (Ethernet 10/100)

• One DC-in jack

• One parallel port (ECP/EPP)

• One external monitor port

• One keyboard/mouse port (PS/2)

• One speaker/headphone-out jack (3.5mm minijack)

• One microphone-in jack (3.5mm minijack)

• One video-out jack (S-video)

• Two Universal Serial Bus (USB) ports

• One IEEE 1394 port

Weight and dimensions

• 14.1-inch model

• 3.11 kg (6.86 lbs)

• 322(W) x 277(D) x 37.5/43.5(H) mm (12.7” x 10.9” x 1.48”/

1.71”)

• 15.0-inch model

• 3.27 kg (7.2 lbs)

• 322(W) x 277(D) x 38/44(H) mm (12.7” x 10.9” x 1.5”/1.73”)

TMa550.book Page 89 Wednesday, October 3, 2001 10:57 AM

Environment

• Temperature

• Operating: 5°C ~ 35°C

• Non-operating: -20°C ~ 65°C

• Humidity (non-condensing)

• Operating: 20% ~ 80% RH

• Non-operating: 10% ~ 90% RH

• Altitude

• Operating: 0 ~ 10,000 ft

• Non-operating: 0 ~ 40,000 ft

Operating system

• Microsoft Windows

Power

• Battery pack

• 57-WattHour Li-Ion battery pack

• 3-4.5 hours charge time

• AC adapter

• 60-Watt

• Auto sensing 100~240Vac, 50~60Hz

89

Options

• 128/256/512 MB SDRAM memory upgrade module

• Additional AC adapter

• Additional battery pack

TMa550.book Page 90 Wednesday, October 3, 2001 10:57 AM

Appendix A Specifications90
