- 1
USER’S MANUAL
2 -
Important
© 2016. All Rights Reserved.
Acer One 10
Covers: S1003
This revision: May 2016
Sign up for an Acer ID and enjoy great benefits
Open the Acer Portal app to sign up for an Acer ID or sign in if you
already have an Acer ID.
There are three great reasons for you to get an Acer ID:
• Create your own connected world.
• Get the latest updates, offers, and product information.
• Register your device for quick, personalized customer support.
For more information, please visit the Acer BYOC website:
www.acer.com/byoc-start
This manual contains proprietary information that is protected by
copyright laws. The information contained in this manual is subject to
change without notice. Images provided herein are for reference only
and may contain information or features that do not apply to your
computer. Acer Group shall not be liable for technical or editorial errors
or omissions contained in this manual.
Model number: _________________________________
Serial number: _________________________________
Date of purchase: ______________________________
Place of purchase: ______________________________
TABLE OF CONTENTS
Table of contents - 3
First things first 6
Your guides ............................................. 6
Basic care and tips for using your
computer.................................................. 7
Turning your computer off ........................... 7
Taking care of your computer ..................... 7
Taking care of your AC adapter.................. 8
Cleaning and servicing................................ 8
Your Acer notebook tour 9
Front view ................................................ 9
Rear view............................................... 10
Top view ................................................ 10
Bottom view ........................................... 11
Left/right view ........................................ 11
Information on USB 3.0............................. 12
Keyboard front view .............................. 13
Keyboard right view .............................. 13
Attaching and detaching the keyboard 14
Using the keyboard 16
Lock keys and embedded numeric
keypad................................................... 16
Hotkeys ..................................................... 17
Windows keys........................................ 18
Using the Precision Touchpad 19
Touchpad gestures................................ 19
Changing touchpad settings .................. 20
Recovery 23
Creating a factory default backup.......... 23
Backing up your wireless and LAN
drivers.................................................... 26
Restoring your computer ....................... 26
Reset this PC and keep my files ............... 26
Reset this PC and remove everything ...... 27
Using a Bluetooth connection 30
Enabling and disabling Bluetooth .......... 30
Enable Bluetooth and add a device .......... 30
Connecting to the Internet 32
Connecting to a wireless network.......... 32
Connecting to a wireless LAN................... 32
Acer Bluelight Shield 36
Securing your computer 38
Using passwords ................................... 38
Entering passwords .................................. 38
BIOS utility 40
Boot sequence....................................... 40
Setting passwords ................................. 40
Power management 41
Saving power ......................................... 41
Battery pack 43
Battery characteristics ........................... 43
Charging the battery ................................. 43
Optimizing battery life ............................... 44
Checking the battery level......................... 45
Battery-low warning .................................. 45
Traveling with your computer 46
Disconnecting from the desktop ............ 46
Moving around ....................................... 46
Preparing the computer ............................ 46
What to bring to meetings ......................... 47
Taking the computer home .................... 47
Preparing the computer ............................ 47
What to take with you................................ 48
Special considerations .............................. 48
Setting up a home office ........................... 48
Traveling with the computer................... 49
Preparing the computer ............................ 49
What to take with you................................ 49
Special considerations .............................. 49
Traveling internationally......................... 49
Preparing the computer ............................ 50
What to bring with you .............................. 50
Special considerations .............................. 50
HDMI Micro 52
Micro USB 53
Universal Serial Bus (USB) 54
Memory card reader 55
Connectivity options............................... 55
Video and audio connectors 57
Frequently asked questions 59
Requesting service ................................ 61
Tips and hints for using Windows 10 ..... 62
How do I get to Start? ............................... 62
How do I turn off my computer?................ 62
How do I unlock my computer?................. 62
How do I set the alarm? ............................ 64
Where are my apps?................................. 64
What is a Microsoft ID (account)?............. 65
How do I check for Windows updates?..... 66
Where can I get more information?........... 66
Troubleshooting ..................................... 67
Troubleshooting tips.................................. 67
Error messages......................................... 67
4 - Table of contents
Internet and online security 69
First steps on the net ............................. 69
Protecting your computer .......................... 69
Choose an Internet Service Provider........ 69
Network connections................................. 71
Surf the Net!.............................................. 73
Security ..................................................... 73
Getting started...
- 5
In this section you will find:
• Useful information on caring for your computer and your health
• Where to find the power button, ports and connectors
• Tips and tricks for using the touchpad and keyboard
• How to create recovery backups
• Guidelines for connecting to a network and using Bluetooth
• Information on using Acer’s bundled software
6 - First things first
FIRST THINGS FIRST
We would like to thank you for making this Acer notebook your choice
for meeting your mobile computing needs.
Your guides
To help you use your Acer notebook, we have designed a set of
guides:
First off, the Setup Guide (or Setup Poster) helps you get started
with setting up your computer.
The Quick Guide introduces you to the basic features and functions
of your new computer. For more on how your computer can help you
to be more productive, please refer to the User’s Manual. This guide
contains detailed information on such subjects as system utilities, data
recovery, expansion options and troubleshooting.
There are two ways to download the User’s Manual. You must first
be connected to the internet.
1. Open Acer Care Center from the desktop and select My System >
Summary and click User’s Manual to download the User’s Manual.
2. Click on the link under Support.
1. The link will open the Acer Service & Support webpage.
2. From this page you can download and install the Acer
identification tool that will automatically detect your computer’s
serial number and SNID and allow you to copy it to the clipboard.
3. Scroll down to Drivers and Manuals and search for your model by
pasting in or manually entering the serial number, SNID, or
product model.
4. Once you have found your product model, select Documents and
select your language to download the User’s Manual.
Basic care and tips for using your computer
Turning your computer off
To turn the power off, do any of the following:
First things first - 7
Note
• Use the Windows shutdown command: Press the Windows key or
select the Windows Start button, select Power > Shut down.
• Right-click the Windows Start button > Shut down or sign out >
Shut down.
If you need to power down the computer for a short while, but don’t
want to completely shut it down, you can put it to Sleep by doing any
of the following:
• Press the power button.
• Press the sleep hotkey.
• Press the Windows key or select the Windows Start button, select
Power > Sleep.
• Right-click the Windows Start button > Shut down or sign out >
Sleep.
If you cannot power off the computer normally, press and hold the power
button for more than four seconds to shut down the computer. If you turn off
the computer and want to turn it on again, wait at least two seconds before
powering up.
Taking care of your computer
Your computer will serve you well if you take care of it.
• Do not expose the computer to direct sunlight. Do not place it near
sources of heat, such as a radiator.
• Do not expose the computer to temperatures below 0º C (32º F) or
above 50º C (122º F).
• Do not subject the computer to magnetic fields.
• Do not expose the computer to rain or moisture.
• Do not spill water or any liquid on the computer.
• Do not subject the computer to heavy shock or vibration.
• Do not expose the computer to dust or dirt.
• Never place objects on top of the computer.
• Do not slam the computer display when you close it.
• Never place the computer on uneven surfaces.
8 - First things first
Taking care of your AC adapter
Here are some ways to take care of your AC adapter:
• Do not connect the adapter to any other device.
• Do not step on the power cord or place heavy objects on top of it.
Route the power cord and any cables away from where people walk.
• When unplugging the power cord, do not pull on the cord itself but
pull on the plug.
• The total ampere ratings of the equipment plugged in should not
exceed the ampere rating of the cord if you are using an extension
cord. Also, the total current rating of all equipment plugged into a
single wall outlet should not exceed the fuse rating.
Cleaning and servicing
When cleaning the computer, follow these steps:
1. Turn off the computer.
2. Disconnect the AC adapter.
3. Use a soft, moist cloth. Do not use liquid or aerosol cleaners.
If your computer is dropped or visibly damaged, or does not work
normally, please contact your nearest authorized Acer service center.
For more information, please see Frequently asked questions on
page 59.
Your Acer notebook tour - 9
1
YOUR ACER NOTEBOOK TOUR
After setting up your computer as illustrated in the Setup Guide, let us
show you around your new Acer computer.
Front view
# Icon Item Description
1 Webcam
Web camera for video
communicat
ion.
10 - Your Acer notebook tour
1
2
1 2 3
Rear view
# Icon Item Description
1 Webcam
2 Speakers Deliver stereo audio output.
Web camera for video
communicat
ion.
Top view
# Icon Item Description
1
2 + / -
3
Power button
Volume control
key
Home button
Turns the computer on and off; press
again
mode. Press and hold to turn the
computer off.
Adjusts the system volume.
Press to go directly to the Windows
me screen.
Ho
to place the computer in Sleep
Bottom view
1
2
1
2
4
5
3
# Icon Item Description
1
2
Keyboard
conne
Keyboard hook
slot
Left/right view
Your Acer notebook tour - 11
ctor
s
Connects to the keyboard.
Fastens to the keyboard.
# Icon Item Description
1
HDMI micro
connector
Supports high-definition digital video
connections.
12 - Your Acer notebook tour
# Icon Item Description
Connects to USB devices. A micro
USB to
2
Micro USB
connector
connect to USB devices.
When using a USB port, it is
recommen
USB adapter is needed to
ded to plug in the power
adapter.
3
4 Microphone
5
MicroSD card
slot
Headset/
speaker jack
Insert a microSD card into this slot.
Internal microphone for sound
recording.
Connects to audio devices (e.g.,
speakers, headphones) or a headset
with microphone.
Information on USB 3.0
• USB 3.0 compatible ports are blue.
• Compatible with USB 3.0 and earlier devices.
• For optimal performance, use USB 3.0-certified devices.
• Defined by the USB 3.0 specification (SuperSpeed USB).
Your Acer notebook tour - 13
2
1
3
Keyboard front view
# Icon Item Description
1 Keyboard hooks Fastens to the computer.
2 Keyboard
3 Touchpad
For entering data into your computer.
See "Using the keyboard" on page
16.
Touch-sensitive pointing device.
The touchpad and selection buttons
f
orm a single surface.
Press down firmly on the touchpad
surface to perform a left click.
Press down firmly on the lower right
corner to perform a right click.
Keyboard right view1
# Icon Item Description
1
USB port Connects to USB devices.
14 - Attaching and detaching the keyboard
ATTACHING AND DETACHING THE
KEYBOARD
The Acer Smart Hinge makes attaching and detaching the keyboard fast
and easy.
Attach the computer with the keyboard by aligning the keyboard
hooks and the keyboard hook slots to function as a loptop. Ensure the
computer clicks into place.
Attaching and detaching the keyboard - 15
Detach the computer from the keyboard by lifting one corner to
release it from the keyboard to function as a tablet
.
You can also attach the computer to the keyboard facing outwards as
a display. Ensure the computer clicks into place.
16 - Using the keyboard
USING THE KEYBOARD
The keyboard has full-sized keys and an embedded numeric keypad,
separate cursor, lock, Windows, function and special keys.
Lock keys and embedded numeric keypad
The keyboard has three lock keys which you can toggle on and off.
Lock key Description
Caps Lock
Num Lock
<Fn> + <F11>
Scroll Lock
<Fn> + <F12>
When Caps Lock is on, all alphabetic characters
typed are in uppercase.
When Num Lock is on, the embedded keypad is in
numeric mode. The keys function as a calculator
(complete with the arithmetic operators +, -, *, and /).
Use this mode when you need to do a lot of numeric
data entry. A better solution would be to connect an
external keypad.
When Scroll Lock is on, the screen moves one line up
or down when you press the up or down arrow keys
respectively. Scroll Lock does not work with some
applications.
The embedded numeric keypad functions like a desktop numeric
keypad. It is indicated by small characters located on the upper right
corner of the keycaps. To simplify the keyboard legend, cursor-control
key symbols are not printed on the keys.
Desired access Num Lock on Num Lock off
Number keys on
embedded keypad
Cursor-control keys
on embedded
keypad
Main keyboard
keys
Type numbers in a normal
manner.
Hold <Shift> while using
cursor-control keys.
Hold <Fn> while typing
letters on embedded
keypad.
Hold <Fn> while
using cursor-control
keys.
Type the letters in a
normal manner.
Using the keyboard - 17
Hotkeys
The computer employs hotkeys or key combinations to access most
of the computer's controls like screen brightness and volume output.
To activate hotkeys, press and hold the <Fn> key before pressing the
other key in the hotkey combination.
Hotkey Icon Function Description
<Fn> + <F3> Airplane mode
<Fn> + <F4> Sleep
<Fn> + <F5> Display toggle
<Fn> + <F6> Display off
<Fn> + <F7>
Touchpad
toggle
<Fn> + <F8> Speaker toggle
<Fn> + <F11> Number Lock
<Fn> + <F12>Scr Lk
<Fn> + < > Brightness up
<Fn> + < >
Brightness
down
<Fn> + < > Volume up Increases the sound volume.
Turns on / off the computer's
network devices.
Puts the computer in Sleep
mode.
Switches display output
between the display screen,
external monitor (if
connected) and both.
Turns the display screen
backlight off to save power.
Press any key to return.
Turns the built-in touchpad on
and off.
Turns the speakers on and
off.
Turns the embedded numeric
keypad on or off.
Turns the scroll lock feature
on or off.
Increases the screen
brightness.
Decreases the screen
brightness.
<Fn> + < > Volume down Decreases the sound volume.
18 - Using the keyboard
Windows keys
The keyboard has two keys that perform Windows-specific functions.
Key Description
Pressed alone it returns to the Start screen or to
Windows key
Application
key
return to the last open app.
It can also be used with other keys for special
functions, please check Windows Help.
This key has the same effect as clicking the right
mouse button; it opens the application's context
menu.
Using the Precision Touchpad - 19
USING THE PRECISION TOUCHPAD
The touchpad controls the arrow (or 'cursor') on the screen. As you
slide your finger across the touchpad, the cursor will follow this
movement. The Precision Touchpad (PTP) is designed to provide a
more uniform, smooth, and accurate touchpad experience. Many
applications support precision touchpad gestures that use one or
more fingers, however, some gestures may not be supported by the
specific application or program you are using.
Touchpad gestures
Single-finger slide
Slide a finger across the touchpad to move
the cursor.
Single-finger press or tap
Press the touchpad down, or lightly tap the
touchpad with your finger, to perform a
'click', which will select or start an item.
Quickly repeat the tap to perform a double
tap or 'double click'.
Two-finger press
Lightly tap the touchpad with two fingers to
perform a
this will toggle the app commands. In most
pps this will open a context menu related
a
to the selected item.
'right click'. In the Start screen,
Two-finger slide
Swiftly scroll through web pages,
documents and playlists by placing two
fingers on the touchpad and moving both in
any direction.
20 - Using the Precision Touchpad
Note
Two-finger pinch
Zoom in and out of photos, maps and
documents with a simple finger-and-thumb
gesture.
Three-finger press
Lightly tap the touchpad with three fingers
to open Cortana (if your computer supports
Cortana) or open the Action Center (if your
computer does not support Cortana).
Three-finger swipe
Swipe across the touchpad with three
fingers.
- Swipe up to open Task V iew. Move the cursor over a
window and tap the touchpad to select that window, or
swipe downwards to exit Task Vie w.
- Swipe down to minimize all open windows and show
Desktop; swipe upwards to restore the minimized
windows.
- Swipe left or right to switch between open windows.
The precision touchpad includes added technology features that help
recognize and prevent unintentional gestures such as accidental taps,
gestures, and pointer movement.
The touchpad is sensitive to finger movement; the lighter the touch, the better
the response. Please keep the touchpad and your fingers dry and clean.
Changing touchpad settings
To change the touchpad settings to suit your personal requirements,
please do the following.
1. In the icon tray in the lower right-hand corner of the screen, select
the Notifications icon to open the Notifications pane.
Using the Precision Touchpad - 21
2. Select All settings.
3. Select Devices > Mouse & touchpad.
4. Now you can adjust the settings to suit your personal needs. You
can change the primary button for left- or right-handed use, turn the
touchpad off if you prefer to use a mouse, or set a delay to prevent
22 - Using the Precision Touchpad
the cursor from moving if you accidentally tap the touchpad with
your palm while working. Scroll down to see more settings.
RECOVERY
Note
Important
Note
If you are having trouble with your computer, and the frequently asked
questions (see Frequently asked questions on page 59) do not
help, you can recover your computer.
This section describes the recovery tools available on your computer.
Acer provides Acer Care Center, which allows you to reset your PC,
refresh your PC, or create a factory default backup.
Acer Care Center is only available with a pre-installed Windows operating
system.
We recommend that you create a Factory Default Backup as soon as
possible. In certain situations a full recovery will require a USB
recovery backup.
Creating a factory default backup
Recovery - 23
Backup allows you to quickly and easily back up your operating
system, installed apps and data.
1. From Start, select All apps then Acer. Select Acer Recovery
Management in the list of Acer apps.
Since the recovery backup requires at least 8 GB of storage after formatting,
it is recommended to use a USB drive with a capacity of 16
GB or larger.
24 - Recovery
2. Select the Backup tab and click Get Started for Create Factory
Default Backup to open the Recovery Drive window.
3. Make sure Backup system files to the recovery drive is selected
and click Next.
4. Plug in the USB drive and wait for the PC to detect the USB drive
then click Next.
Loading...
