Acer ICONIA Tab User Guide
Original Issue: 02/2011
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
Your guides
First things first
We would like to thank you for making an Acer computer your choice for
meeting your mobile computing needs.
Your guides
To help you use your Acer computer, we have designed a set of guides:
The setup poster helps you get started with setting up your computer.
The printed Quick Guide shows you the location of the components, ports and
connectors of your computer. It also provides a handy reference tool to using
the many unique features of this computer.
The User Guide contains useful information applying to this product, and helps
you to be more productive. This guide contains detailed information on such
subjects as system utilities, data recovery, expansion options and
troubleshooting. In addition it contains the general regulations and safety
notices for your computer. It is available in Portable Document Format (PDF)
and comes preloaded on your computer. Follow these steps to access it:
1 Click on Start > All Programs > Documentation.
2 Click on Iconia Tab User Guide.
Note: Viewing the file requires Adobe Reader. If Adobe Reader is
not installed on your computer, clicking on the user guide link will
run the Adobe Reader setup program first. Follow the instructions
on the screen to complete the installation. For instructions on how
to use Adobe Reader, please refer to the Help and Support menu.
iii
Warranty information is included on a separate leaflet in the documentation
pack included with your computer, and is specific to your home region. Your
International Travelers Warranty booklet gives you information that is essential
for obtaining technical support when traveling outside of your home country.
Basic care and tips for using your computer
Turning your computer on and off
To turn on the computer, simply press and release the power button in the
right-hand hinge. Please refer to the setup poster for the location of the power
button.
To turn the power off, do any of the following:
First things first
iv
• Use the Windows shutdown command
Click on Start then click on Shut Down.
• Use the power button
Note: If you cannot power off the computer normally, press and
hold the power button for more than four seconds to shut down
the computer. If you turn off the computer and want to turn it on
again, wait at least two seconds before powering up.
Taking care of your computer
Your computer will serve you well if you take care of it.
• Do not expose the computer to direct sunlight. Do not place it near sources
of heat, such as a radiator.
• Do not expose the computer to temperatures below 0º C (32º F) or above
50º C (122º F).
• Do not subject the computer to magnetic fields.
• Do not expose the computer to rain or moisture.
• Do not spill water or any liquid on the computer.
• Do not subject the computer to heavy shock or vibration.
• Do not expose the computer to dust or dirt.
• Never place objects on top of the computer.
• Do not slam the computer display when you close it.
• Never place the computer on uneven surfaces.
Taking care of your AC adapter
Here are some ways to take care of your AC adapter:
• Do not connect the adapter to any other device.
• Do not step on the power cord or place heavy objects on top of it.
Carefully route the power cord and any cables away from foot traffic.
• When unplugging the power cord, do not pull on the cord itself but pull
on the plug.
• The total ampere ratings of the equipment plugged in should not exceed
the ampere rating of the cord if you are using an extension cord. Also, the
total current rating of all equipment plugged into a single wall outlet
should not exceed the fuse rating.
Taking care of your battery pack
Here are some ways to take care of your battery pack:
Basic care and tips for using your computer
• Use only batteries of the same kind as replacements. Turn the power off
before removing or replacing batteries.
Note: If your battery requires replacing, please contact your
nearest Acer service center. Do not attempt to replace the battery
yourself.
• Do not tamper with batteries. Keep them away from children.
• Dispose of used batteries according to local regulations. Recycle if possible.
Cleaning and servicing
When cleaning the computer, follow these steps:
1 Turn off the computer and remove the battery pack.
2 Disconnect the AC adapter.
3 Use a soft, moist cloth. Do not use liquid or aerosol cleaners.
If either of the following occurs:
• the computer has been dropped or the body has been damaged;
• the computer does not operate normally
Please refer to "Frequently asked questions" on page 34.
v
Information for your safety and comfort vi
Information for your safety and comfort
Safety instructions
Read these instructions carefully. Keep this document for future reference.
Follow all warnings and instructions marked on the product.
Turning the product off before cleaning
Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
CAUTION when disconnecting the power source
Observe the following guidelines when connecting and disconnecting power to
the power supply unit:
Install the power supply unit before connecting the power cord to the AC
power outlet.
Unplug the power cord before removing the power supply unit from the
computer.
If the system has multiple sources of power, disconnect power from the system
by unplugging all power cords from the power supplies.
CAUTION for accessibility
Be sure that the power outlet you plug the power cord into is easily accessible
and located as close to the equipment operator as possible. When you need to
disconnect power to the equipment, be sure to unplug the power cord from the
electrical outlet.
CAUTION for listening
To protect your hearing, follow these instructions.
• Increase the volume gradually until you can hear clearly and comfortably.
• Do not increase the volume level after your ears have adjusted.
• Do not listen to music at high volumes for extended periods.
• Do not increase the volume to block out noisy surroundings.
• Decrease the volume if you can't hear people speaking near you.
Safety instructions
vii
Warnings
• Do not use this product near water.
• Do not place this product on an unstable cart, stand or table. If the product
falls, it could be seriously damaged.
• Slots and openings are provided for ventilation to ensure reliable
operation of the product and to protect it from overheating. These
openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug or other similar surface.
This product should never be placed near or over a radiator or heat
register, or in a built-in installation unless proper ventilation is provided.
• Never push objects of any kind into this product through cabinet slots as
they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock. Never spill liquid of any kind onto or into
the product.
• To avoid damage of internal components and to prevent battery leakage,
do not place the product on a vibrating surface.
• Never use it under sporting, exercising, or any vibrating environment
which will probably cause unexpected short current or damage rotor
devices, HDD, Optical drive, and even exposure risk from lithium battery
pack.
• The bottom surface, areas around ventilation openings and AC adapter
may get hot. To avoid injury, ensure they do not come in contact with your
skin or body.
• Your device and its enhancements may contain small parts. Keep them out
of the reach of small children.
Using electrical power
• This product should be operated from the type of power indicated on the
marking label. If you are not sure of the type of power available, consult
your dealer or local power company.
• Do not allow anything to rest on the power cord. Do not locate this
product where people will walk on the cord.
• If an extension cord is used with this product, make sure that the total
ampere rating of the equipment plugged into the extension cord does not
exceed the extension cord ampere rating. Also, make sure that the total
rating of all products plugged into the wall outlet does not exceed the fuse
rating.
• Do not overload a power outlet, strip or receptacle by plugging in too
many devices. The overall system load must not exceed 80% of the branch
circuit rating. If power strips are used, the load should not exceed 80% of
the power strip's input rating.
• This product's AC adapter is equipped with a three-wire grounded plug.
The plug only fits in a grounded power outlet. Make sure the power outlet
is properly grounded before inserting the AC adapter plug. Do not insert
Information for your safety and comfort viii
the plug into a non-grounded power outlet. Contact your electrician for
details.
Warning! The grounding pin is a safety feature. Using a power
outlet that is not properly grounded may result in electric shock
and/or injury.
Note: The grounding pin also provides good protection from
unexpected noise produced by other nearby electrical devices that
may interfere with the performance of this product.
• The system can be powered using a wide range of voltages; 100 to 120 or
220 to 240 V AC. The power cord included with the system meets the
requirements for use in the country/region where the system was
purchased. Power cords for use in other countries/regions must meet the
requirements for that country/region. For more information on power cord
requirements, contact an authorized reseller or service provider.
Product servicing
Do not attempt to service this product yourself, as opening or removing covers
may expose you to dangerous voltage points or other risks. Refer all servicing to
qualified service personnel.
Unplug this product from the wall outlet and refer servicing to qualified service
personnel when:
• The power cord or plug is damaged, cut or frayed.
• Liquid was spilled into the product.
• The product was exposed to rain or water.
• The product has been dropped or the case has been damaged.
• The product exhibits a distinct change in performance, indicating a need
for service.
• The product does not operate normally after following the operating
instructions.
Note: Adjust only those controls that are covered by the operating
instructions, since improper adjustment of other controls may
result in damage and will often require extensive work by a
qualified technician to restore the product to normal condition.
Safety instructions
Guidelines for safe battery usage
This computer uses a Lithium-ion battery. Do not use it in a humid, wet or
corrosive environment. Do not put, store or leave your product in or near a heat
source, in a high temperature location, in strong direct sunlight, in a microwave
oven or in a pressurized container, and do not expose it to temperatures over
60° C (140° F). Failure to follow these guidelines may cause the battery to leak
acid, become hot, explode or ignite and cause injury and/or damage. Do not
pierce, open or disassemble the battery. If the battery leaks and you come into
contact with the leaked fluids, rinse thoroughly with water and seek medical
attention immediately. For safety reasons, and to prolong the lifetime of the
battery, charging will not occur at temperatures below 0° C (32° F) or above
40° C (104° F).
The full performance of a new battery is achieved only after two or three
complete charge and discharge cycles. The battery can be charged and
discharged hundreds of times, but it will eventually wear out. When the
operation time becomes noticeably shorter than normal, buy a new battery.
Use only the approved batteries, and recharge your battery only with the
approved chargers designated for this device.
Use the battery only for its intended purpose. Never use any charger or battery
that is damaged. Do not short-circuit the battery. Accidental short-circuiting can
occur when a metallic object such as a coin, clip or pen causes direct connection
of the positive (+) and negative (-) terminals of the battery. (These look like
metal strips on the battery.) This might happen, for example, when you carry a
spare battery in your pocket or purse. Short-circuiting the terminals may
damage the battery or the connecting object.
The capacity and lifetime of the battery will be reduced if the battery is left in
hot or cold places, such as in a closed car in summer or winter. Always try to
keep the battery between 15° C and 25° C (59° F and 77° F). A device with a hot
or cold battery may not work temporarily, even when the battery is fully
charged. Battery performance is especially limited in temperatures well below
freezing.
Do not dispose of batteries in a fire as they may explode. Batteries may also
explode if damaged. Dispose of batteries according to local regulations. Please
recycle when possible. Do not dispose as household waste.
Wireless devices may be susceptible to interference from the battery, which
could affect performance.
ix
Replacing the battery pack
The computer uses Lithium-ion batteries. Replace the battery with the same
type as that which came bundled with your product. Use of another battery
may present a risk of fire or explosion.
Information for your safety and comfort x
Warning! Batteries may explode if not handled properly. Do not
disassemble or dispose of them in fire. Keep them away from
children. Follow local regulations when disposing of used
batteries.
Telephone line safety
• Disconnect all telephone lines from the equipment when not in use and/or
before servicing.
• To avoid the remote risk of electric shock from lightning, do not connect
the telephone line to this equipment during lightning or thunderstorms.
Warning! For safety reasons, do not use non-compliant parts
when adding or changing components. Consult your reseller for
purchase options.
Operating environment
Warning! For safety reasons, turn off all wireless or radio
transmitting devices when using your laptop under the following
conditions. These devices may include, but are not limited to:
wireless lan (WLAN), Bluetooth and/or 3G.
Remember to follow any special regulations in force in any area, and always
switch off your device when its use is prohibited or when it may cause
interference or danger. Use the device only in its normal operating positions.
This device meets RF exposure guidelines when used normally, and it and its
antenna are positioned at least 1.5 centimeters (5/8 inches) away from your
body (refer to the figure below). It should not contain metal and you should
position the device the above-stated distance from your body. To successfully
transmit data files or messages, this device requires a good quality connection
to the network. In some cases, transmission of data files or messages may be
delayed until such a connection is available. Ensure that the above separation
distance instructions are followed until the transmission is completed. Parts of
the device are magnetic. Metallic materials may be attracted to the device, and
persons with hearing aids should not hold the device to the ear with the
hearing aid. Do not place credit cards or other magnetic storage media near the
device, because information stored on them may be erased.
Medical devices
Medical devices
Operation of any radio transmitting equipment, including wireless phones, may
interfere with the functionality of inadequately protected medical devices.
Consult a physician or the manufacturer of the medical device to determine if
they are adequately shielded from external RF energy or if you have any
questions. Switch off your device in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to external RF transmissions.
Pacemakers. Pacemaker manufacturers recommend that a minimum separation
of 15.3 centimeters (6 inches) be maintained between wireless devices and a
pacemaker to avoid potential interference with the pacemaker. These
recommendations are consistent with the independent research by and
recommendations of Wireless Technology Research. Persons with pacemakers
should do the following:
• Always keep the device more than 15.3 centimeters (6 inches) from the
pacemaker
• Not carry the device near your pacemaker when the device is switched on.
If you suspect interference, switch off your device, and move it.
Hearing aids. Some digital wireless devices may interfere with some hearing
aids. If interference occurs, consult your service provider.
Vehicles
xi
RF signals may affect improperly installed or inadequately shielded electronic
systems in motor vehicles such as electronic fuel injection systems, electronic
antiskid (antilock) braking systems, electronic speed control systems, and air bag
systems. For more information, check with the manufacturer, or its
representative, of your vehicle or any equipment that has been added. Only
qualified personnel should service the device, or install the device in a vehicle.
Faulty installation or service may be dangerous and may invalidate any
warranty that may apply to the device. Check regularly that all wireless
equipment in your vehicle is mounted and operating properly. Do not store or
carry flammable liquids, gases, or explosive materials in the same compartment
as the device, its parts, or enhancements. For vehicles equipped with an air bag,
remember that air bags inflate with great force. Do not place objects, including
installed or portable wireless equipment in the area over the air bag or in the
air bag deployment area. If in-vehicle wireless equipment is improperly
installed, and the air bag inflates, serious injury could result. Using your device
while flying in aircraft is prohibited. Switch off your device before boarding an
aircraft. The use of wireless teledevices in an aircraft may be dangerous to the
operation of the aircraft, disrupt the wireless telephone network, and may be
illegal.
Information for your safety and comfort xii
Potentially explosive environments
Switch off your device when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Potentially explosive
atmospheres include areas where you would normally be advised to turn off
your vehicle engine. Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death. Switch off the device at refueling points
such as near gas pumps at service stations. Observe restrictions on the use of
radio equipment in fuel depots, storage, and distribution areas; chemical plants;
or where blasting operations are in progress. Areas with a potentially explosive
atmosphere are often, but not always, clearly marked. They include below deck
on boats, chemical transfer or storage facilities, vehicles using liquefied
petroleum gas (such as propane or butane), and areas where the air contains
chemicals or particles such as grain, dust or metal powders. Do not switch the
computer on when wireless phone use is prohibited or when it may cause
interference or danger.
Emergency calls
Warning: You cannot make emergency calls through this device. To make an
emergency call you shall dial out through your mobile phone or other
telephone call system.
Disposal instructions
Do not throw this electronic device into the trash when discarding.
To minimize pollution and ensure utmost protection of the global
environment, please recycle. For more information on the Waste
from Electrical and Electronics Equipment (WEEE) regulations, visit
www.acer-group.com/public/Sustainability/sustainability01.htm
Tips and information for comfortable use
Computer users may complain of eyestrain and headaches after prolonged use.
Users are also at risk of physical injury after long hours of working in front of a
computer. Long work periods, bad posture, poor work habits, stress,
inadequate working conditions, personal health and other factors greatly
increase the risk of physical injury.
Incorrect computer usage may lead to carpal tunnel syndrome, tendonitis,
tenosynovitis or other musculoskeletal disorders. The following symptoms may
appear in the hands, wrists, arms, shoulders, neck or back:
• Numbness, or a burning or tingling sensation.
• Aching, soreness or tenderness.
Tips and information for comfortable use
• Pain, swelling or throbbing.
• Stiffness or tightness.
• Coldness or weakness.
If you have these symptoms, or any other recurring or persistent discomfort
and/or pain related to computer use, consult a physician immediately and
inform your company's health and safety department.
The following section provides tips for more comfortable computer use.
xiii
Finding your comfort zone
Find your comfort zone by adjusting the viewing angle of the monitor, using a
footrest, or raising your sitting height to achieve maximum comfort. Observe
the following tips:
• Refrain from staying too long in one fixed posture.
• Avoid slouching forward and/or leaning backward.
• Stand up and walk around regularly to remove the strain on your leg
muscles.
• Take short rests to relax your neck and shoulders.
• Avoid tensing your muscles or shrugging your shoulders.
• Install the external display, keyboard and mouse properly and within
comfortable reach.
• If you view your monitor more than your documents, place the display at
the center of your desk to minimize neck strain.
Taking care of your vision
Long viewing hours, wearing incorrect glasses or contact lenses, glare, excessive
room lighting, poorly focused screens, very small typefaces and low-contrast
displays could stress your eyes. The following sections provide suggestions on
how to reduce eyestrain.
Eyes
• Rest your eyes frequently.
• Give your eyes regular breaks by looking away from the monitor and
focusing on a distant point.
• Blink frequently to keep your eyes from drying out.
Display
• Keep your display clean.
• Keep your head at a higher level than the top edge of the display so your
eyes point downward when looking at the middle of the display.
• Adjust the display brightness and/or contrast to a comfortable level for
enhanced text readability and graphics clarity.
Information for your safety and comfort xiv
• Eliminate glare and reflections by:
• Placing your display in such a way that the side faces the window or
any light source.
• Minimizing room light by using drapes, shades or blinds.
• Using a task light.
• Changing the display's viewing angle.
• Using a glare-reduction filter.
• Using a display visor, such as a piece of cardboard extended from the
display's top front edge.
• Avoid adjusting your display to an awkward viewing angle.
• Avoid looking at bright light sources, such as open windows, for extended
periods of time.
Developing good work habits
Develop the following work habits to make your computer use more relaxing
and productive:
• Take short breaks regularly and often.
• Perform some stretching exercises.
• Breathe fresh air as often as possible.
• Exercise regularly and maintain a healthy body.
Warning! We do not recommend using the computer on a couch
or bed. If this is unavoidable, work for only short periods, take
breaks regularly, and do some stretching exercises.
Note: For more information, please refer to Regulations and
safety notices on page 37.
First things first iii
Your guides iii
Basic care and tips for using your computer iii
Turning your computer on and off iii
Taking care of your computer iv
Taking care of your AC adapter iv
Taking care of your battery pack iv
Cleaning and servicing v
Information for your safety and comfort vi
Safety instructions vi
Operating environment x
Medical devices xi
Vehicles xi
Potentially explosive environments xii
Emergency calls xii
Disposal instructions xii
Tips and information for comfortable use xii
Your Acer tablet PC tour 1
Connect the tablet to the docking station / keyboard 1
Tablet PC 2
Front view 2
Back view 3
Top view 3
Bottom view 4
Left view 4
Right view 5
Booting your tablet 5
Key functions for boot menus 5
Docking station / keyboard 6
Top view 6
Front view 7
Left view 7
Right view 8
Environment 8
Acer Ring 9
Sync function 10
Clean Disk function 10
TouchBrowser 11
Adding a page to your Favorites 13
My Journal 14
Editing pages 15
Web Clip 15
Acer clear.fi 18
Media content types 18
Contents
DMS (Digital Media Server) devices 18
Display media content 18
Save media content 19
Search media 19
Media sharing settings 19
Device Control 20
SocialJogger 22
Sharing content 24
Settings 25
Acer Backup Manager 26
Power management 27
Recovering your system 27
Battery pack 28
Battery pack characteristics 28
Maximizing the battery's life 28
Charging the battery 29
Checking the battery level 29
Battery low warning 30
Expanding through options 31
Connectivity options 31
Built-in network feature 31
Universal Serial Bus (USB) 32
High-Definition Multimedia Interface 32
BIOS utility 33
Boot sequence 33
Frequently asked questions 34
Requesting service 35
International Travelers Warranty (ITW) 35
Before you call 35
Troubleshooting 36
Troubleshooting tips 36
Regulations and safety notices 37
FCC statement 37
LCD pixel statement 38
Radio device regulatory notice 38
General 38
The FCC RF safety requirement 39
Canada — Low-power license-exempt radio
communication devices (RSS-210) 39
Exposure of humans to RF fields (RSS-102) 39
English
Connect the tablet to the docking station / keyboard
Your Acer tablet PC tour
After setting up your computer as illustrated in the setup poster, let us show
you around your new Acer computer.
You can enter information into you new computer via the touchscreen or with
the docking station / keyboard.
Note: The docking station / keyboard is optional.
Connect the tablet to the docking station /
keyboard
Align the two arrows printed beneath the screen with the two pins on the
docking station / keyboard. Press the tablet down.
1
Your Acer tablet PC tour 2
English
1
2
3
Tablet PC
Your new computer has two components, the tablet and the docking station /
keyboard. The following set of images will show you the Tablet PC. The views
are labeled as if you are holding the Tablet with the screen towards you and the
cameras at the top.
Front view
No. Item Description
1 Latch Secures the tablet to the docking station / keyboard
when closed.
2 Integrated
webcam
3 Windows key /
power status
indicator
Status indicator color Power status
Blue System turned on.
Slow flash: Orange System in Standby mode.
Flashing: Orange System entering Hibernate mode.
Off System in Hibernate mode or turned off.
Web camera for video communication.
Press once to open the Start menu.
Press power button while holding the Windows key to
perform the <Ctrl> + < Alt> +<Del> function.
English
Tablet PC
1
23
1
Back view
No. Item Description
1 Integrated webcam Web camera for video communication.
2 SIM card slot Accepts a 3G SIM card.
3 Speaker Delivers audio output.
3
Top view
No. Item Description
1 Ventilation slot Provides adequate air flow to maintain a safe
operating temperature.
Your Acer tablet PC tour 4
English
12 3 4
12 43567
Bottom view
No. Icon Item Description
1 USB 2.0 port Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
2 Lock switch Locks the screen orientation.
Note: Display orientation may be fixed
when applications designed for a specific
orientation are running. These include
games, video calls, and other full-screen
applications.
3 Dock connector Connects to the supplied keyboard /
4 SIM card slot Accepts a 3G SIM card.
docking station. USB port may also be
used as a standard USB port.
Left view
No. Icon Item Description
1 Headphone jack Connects to audio devices
2 Battery LED Indicates the computer's battery status.
3 Power button Press to turn the tablet on; press again to
4 Volume key Press to increase or decrease volume.
5 Ventilation slot Provides adequate air flow to maintain a
(e.g., speakers, headphones).
1. Charging: Amber.
2. Fully charged: Blue when plugged in.
place the tablet in Sleep mode. Press and
hold to turn the tablet off.
safe operating temperature.
English
Booting your tablet
1
No. Icon Item Description
6 2-in-1 card reader Accepts Secure Digital (SD),
MultiMediaCard (MMC).
Note: Push to remove/install the card.
Only one card can operate at any time.
7 HDMI port Supports high-definition digital video
connections.
Right view
No. Icon Item Description
1 DC-in jack Connects to an AC adapter.
Booting your tablet
5
There are three ways to boot your tablet:
1 Quick boot: Press the power button; no external USB keyboard support
before Windows boots.
2 Normal boot: Press the power button and the Windows key; supports USB
keyboard, <F2> and <F12> hotkeys.
3 Boot from recovery discs: Press the power button, Windows key and
volume up key simultaneously. Use this if you need to restore your
operating system to factory defaults from the supplied recovery discs.
Please refer to Recovering your system in the User Guide.
Key functions for boot menus
For menus displayed before Windows boots:
Windows key: Select the highlighted menu option.
Volume up/down: Move the cursor up or down.
Your Acer tablet PC tour 6
English
1
3
2
4
5
Docking station / keyboard
The following set of images show you the optional docking station / keyboard.
Top view
No. Item Description
1 Dock connector Connects to the tablet.
2 Keyboard A standard keyboard with full-size keys.
3 Acer FineTrack
pointing device
4 Latch Secures the tablet to the docking station /
5 Left and right buttons Function like the left and right mouse buttons.
Pointing device to control cursor movement.
keyboard when closed.
English
Docking station / keyboard
1
12
Front view
No. Item Description
1 Latch Secures the tablet to the docking station / keyboard
when closed.
Left view
No. Icon Item Description
1 Ethernet (RJ-45)
port
Connects to an Ethernet 10/100/1000based network.
7
2 USB 2.0 port Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
Your Acer tablet PC tour 8
English
1
Right view
No. Icon Item Description
1 USB 2.0 port Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
Environment
• Temperature:
• Operating: 5 °C to 35 °C
• Non-operating: -20 °C to 65 °C
• Humidity (non-condensing):
• Operating: 20% to 80%
• Non-operating: 20% to 80%
English
Acer Ring
Acer Ring incorporates a number of
useful functions and tools in one easyto-use interface. Tap the touchscreen
with all five fingers at once to display
Acer Ring.
9
Icon Item Description
Sync Opens the data synchronization tool.
Game Opens Acer GameZone.
Calculator Opens the Windows Calculator.
Webcam Opens the Acer CrystalEye webcam utility.
Snipping tool Opens the Windows Snipping Tool.
Disk Clean Opens the disk cleaning tool.
Device Control Adjust settings for your computer (please
On one side of Acer Ring you can see a selection of AppCards. You can scroll
through the applications and tap on a card to open the application.
refer to Device Control on page 20).
Acer Ring 10
English
Sync function
Press to run all existing sync/backup jobs, including sync jobs created in the
Migration and Synchronization Wizard. Please refer to Acer Backup Manager
on page 26.
Clean Disk function
The Clean Disk functions lists files that have not been used recently and have
been successfully backed up. You can delete the files on that list, knowing you
can restore these files from backup copies at a later date if required.
English
TouchBrowser
TouchBrowser is specifically designed to offer you a more comfortable web
surfing experience when using touch input. Open Acer Ring and tap the
TouchBrowser AppCard to launch the browser.
The toolbar at the top of the screen gives you easy control over the open page.
11
TouchBrowser 12
English
1
2
3
4
5
6
7
8
9
10
12 13
14
11
To enter a website address, tap the URL bar. A keyboard icon will display,
allowing you to open a virtual keyboard and enter text, or use handwriting to
enter the URL.
No. Item Description
1 Back Go back one page.
2 Forward Go forward to the next page in the browsing
3 Home Open the defined home page.
4 Tabs Shows the pages currently open.
5 Open new tab Tap to open a new tab.
6 URL bar Shows the address of the current page.
7 Refresh Refreshes the current tab content.
8 Add to favorites Add the current page to your favorites.
9 Favorites Open the list of your favorites / history.
10 Web Clip Crop a part of the web page for use in My
11 Print Print the page.
12 Help View the Help file.
13 Minimize Minimizes the browser.
14 Close Closes the browser.
history.
Journal or Scrapbook.
You can use a pinch action to zoom in to content on the page.
English
13
Adding a page to your Favorites
To add a page to your Favorites, tap the Add to Favorites icon, give the page a
name (the page title will be used by default) and select a folder to save the URL
to.
My Journal 14
English
1 2
3
4
5
6
My Journal
My Journal is a handy place for you to keep clippings of websites and other
information you may want to refer to later. You can organize the information
you wish to view from a number of sources on a single, easy-to-view page.
Open Acer Ring and scroll through the AppCards to My Journal. Tap the
AppCard to open the application.
Website content is automatically updated each time you open the journal page.
Use the tabs along the top of the screen to switch between your journal pages,
or tap the icons on the toolbar to perform various functions.
No. Item Description
1 Web clip Crop a part of the web page for use in My
2 Edit Edit the content on the journal pages.
3 Help View the help file.
4 Minimize Minimizes My Journal.
5 Close Closes My Journal.
6 Tabs Shows the pages in your journal.
Journal.
English
Editing pages
Note: When you have finished editing your clips, tap to
return to viewing mode. If you want to edit a web clip at a later
time, tap the edit icon to enter edit mode.
15
Editing pages
In edit mode, you can resize web clips by dragging the corners of the web clip
to the size you want.
You can also move web clips to other pages by dragging the web clip to the tab
for the page you want to move the clip to.
Tap the name of a tab to rename the tab. You can use either the virtual
keyboard or the keyboard on the dock. When you have finished, tap .
Web Clip
The web clip tool allows you to clip parts of web pages to save them to My
Journal. Once you have a page open in your browser, tap the Web clip icon.
My Journal 16
English
Tap the browser screen to select the area you want to crop; tap and drag on any
of the circles on the corner of the crop window to expand it to include all the
information you want to capture.
When you have finished selecting the area you want to crop, tap the area to
open a menu that will allow you to paste the content into My Journal or Copy it
to the clipboard. You can also Save bitmap as... or Discard the web clip.
English
Web Clip
In My Journal, tap a clip to select it, then you can position it on the page and
stretch it by dragging the corners to the desired size.
To delete a web clip, tap the clip in My Journal and tap the trash can icon.
Note: If the web clip comes from a site that requires a login, the
clip will be grayed out and a key icon will show to indicate that it
requires a login. Tap the clip to open the login page in My
Journal.
17
Note: If an Internet connection to the website is unavailable, the
clip will indicate that the connection is unavailable. Tap the clip to
refresh the data.
Acer clear.fi 18
English
Acer clear.fi
Acer clear.fi is a home media database viewer and controller. It allows you to
browse media contents on devices that are on the same subnet.
Media content types
When you launch Acer clear.fi, you can choose the media content type. There
are three types defined: Video, Music, and Photo.
DMS (Digital Media Server) devices
DMS devices include DLNA-compliant personal computers and NAS (Network
Attached Storage) devices. These devices store content and make it available to
DMP (Digital Media Player) and DMR (Digital Media Renderer) devices. Acer
clear.fi will list DMS devices on the main screen, and you can choose ALL
DEVICES or a specific device to browse the media stored.
Display media content
If you want to display media content on your computer, you just need to
double-click the media content. If you want to display the media content on a
remote device, you need to do the following:
1 Choose the media content.
2Select Play To.
3 Select the files you wish to play, then send them to the remote device. The
target icon will change to display the status. You can view playback
controls and progress on the target.
English
Media sharing settings
19
Save media content
If you want to save media content to a remote device, you need to do the
following:
1 Choose the media content.
2Select Save To.
3 Select the files you wish to save, then send them to the remote device. The
target icon will change to display the status. You can view the save status
progress bar on the target. Click the target to display a dialog box that
allows you to cancel the process.
Search media
If you want to search your media content, you need to choose the media type
first; then enter a keyword in the search bar. Acer clear.fi will list the media
content that matches the keyword.
Media sharing settings
You can adjust settings according to your requirements.
Device Control 20
English
Device Control
Device Control is a convenient way for you to control the screen brightness, turn
the backlight on or off, and adjust the volume to suit your needs. It also
indicates the location of each port on your computer and allows you to turn
your connectivity devices on or off, select a power scheme, lock your computer,
turn it off, or place it in Sleep mode.
The Device Control UI also indicates if the tablet is docked:
Or if the tablet is undocked:
If you have any devices plugged into a USB port or the HDMI port, Device
Control will show what type of device is plugged into each port. If you have
English
inserted a storage device into a USB port, you may tap the USB icon to open a
context menu. Tap Open to view the files in Windows Explorer.
To safely remove the device, select Eject from the menu.
There is also a context menu available for the HDMI connector.
21
SocialJogger 22
English
SocialJogger
Open Acer Ring and tap the SocialJogger AppCard.
SocialJogger gives you one-touch access to popular social networking sites:
Facebook, YouTube and Flickr.
English
Tap Log In to open the login wizard. You can log into all three supported
services from a single login wizard. If you don’t already have an account with
the supported services, you can create an account from the wizard.
Tap Continue to log into your account(s):
Facebook
23
English
YouTube
Flickr
SocialJogger 24
Sharing content
You can upload content to each service by tapping the Share on icon in the
upper right-hand corner of the page. This will open a file browser above the
English
Settings
three service pages. Drag and drop the content you want to share to the desired
service.
25
Settings
You can adjust the settings for each service by tapping the Settings icon. This
opens the settings window with a tab for each service.
Acer Backup Manager 26
English
Acer Backup Manager
Acer Backup Manager includes a Migration and Synchronization Wizard which
runs after Windows 7 setup is complete. Additionally, you can launch it by
double-clicking the desktop shortcut.
It helps you migrate system settings (e.g., email settings and Internet Explorer
Favorites) from an existing computer to your new tablet PC.
It also establishes a synchronization relationship between the two computers,
so that all files in the Documents, Pictures, Music, and Videos libraries on the
tablet PC will be kept synchronized with their shadows on the other PC.
Acer Backup Manager also includes the Disk Clean function (please refer to
Clean Disk function on page 10.)
English
27
Power management
This computer has a built-in power management unit that monitors system
activity. System activity refers to any activity involving one or more of the
following devices: keyboard, mouse, hard disk, peripherals connected to the
computer, and video memory. If no activity is detected for a period of time
(called an inactivity timeout), the computer stops some or all of these devices in
order to conserve energy.
This computer employs a power management scheme that supports the
advanced configuration and power interface (ACPI), which allows for maximum
power conservation and maximum performance at the same time. Windows
handles all power-saving chores for your computer.
Recovering your system
Your computer was shipped with a set of recovery DVDS that contains the
system recovery information. While the tablet is turned off, plug in an external
DVD drive, insert the first disc into the DVD drive. Press the Windows key,
volume up key, and power button simultaneously to turn on the system. Follow
the onscreen instructions to complete the recovery process.
You will be reminded to remove the discs from the drive before your computer
reboots.
Note: An external DVD drive needs to be purchased separately.
Battery pack 28
English
Battery pack
The computer uses a battery pack that gives you long use between charges.
Battery pack characteristics
The battery pack has the following characteristics:
• Employs current battery technology standards.
• Delivers a battery-low warning.
The battery is recharged whenever you connect the computer to the AC
adapter. Your computer supports charge-in-use, enabling you to recharge the
battery while you continue to operate the computer. However, recharging with
the computer turned off results in a significantly faster charge time.
Maximizing the battery's life
Like all other batteries, your computer's battery will degrade over time. This
means that the battery's performance will diminish with time and use. To
maximize your battery's life, you are advised to adhere to the recommendations
set out below.
Conditioning a new battery pack
Before you use a battery pack for the first time, there is a conditioning process
that you should follow:
1 Connect the AC adapter and fully charge the battery.
2 Disconnect the AC adapter.
3 Turn on the computer and operate using battery power.
4 Fully deplete the battery until the battery-low warning appears.
5 Reconnect the AC adapter and fully charge the battery again.
English
Charging the battery
Follow these steps again until the battery has been charged and discharged
three times.
Use this conditioning process for all new batteries, or if a battery hasn't been
used for a long time.
Warning: Do not expose battery packs to temperatures below 0° C
(32° F) or above 45° C (113° F). Extreme temperatures may
adversely affect the battery pack.
By following the battery conditioning process you condition your battery to
accept the maximum possible charge. Failure to follow this procedure will
prevent you from obtaining the maximum battery charge, and will also shorten
the effective lifespan of the battery.
In addition, the useful lifespan of the battery is adversely affected by the
following usage patterns:
• Not discharging and recharging the battery to its extremes, as described
above.
• Frequent use; the more you use the battery, the faster it will reach the end
of its effective life. A standard computer battery has a life span of about
300 charges.
29
Charging the battery
Plug the AC adapter into the computer, and connect to a mains power outlet.
You can continue to operate your computer on AC power while your battery is
charging. However, charging the battery with the computer turned off results
in a significantly faster charge time.
Note: You are advised to charge the battery before retiring for
the day. Charging the battery overnight before traveling enables
you to start the next day with a fully-charged battery.
Checking the battery level
The Windows power meter indicates the current battery level. Rest the cursor
over the battery/power icon on the taskbar to see the battery's present charge
level.
Battery pack 30
English
Battery low
When using battery power pay attention to the Windows power meter.
Warning: Connect the AC adapter as soon as possible after the
battery-low warning appears. Data will be lost if the battery
becomes fully depleted and the computer shuts down.
When the
depends on your situation:
Situation Recommended Action
The AC adapter and
a power outlet are
available.
The AC adapter or a
power outlet is
unavailable. You
have no spare
battery pack.
battery low
warning
warning appears, the recommended course of action
1. Plug the AC adapter into the computer, and then
connect to the mains power supply.
2. Save all necessary files.
3. Resume work.
Turn off the computer if you want to recharge the
battery rapidly.
1. Save all necessary files.
2. Close all applications.
3. Shut down the operating system to turn off the
computer.
English
Connectivity options
31
Expanding through options
Your computer offers you a complete mobile computing experience.
Connectivity options
Ports allow you to connect peripheral devices to your computer as you would
with a desktop PC. For instructions on how to connect different external devices
to the computer, read the following section.
Built-in network feature
The built-in network feature allows you to connect your computer to an
Ethernet-based network.
To use the network feature, connect an Ethernet cable from the Ethernet
(RJ-45) port on the chassis of the computer to a network jack or hub on
your network.
Expanding through options 32
English
Universal Serial Bus (USB)
The 2.0 ports are a high-speed serial bus which allows you to connect USB
peripherals without taking up system resources.
High-Definition Multimedia Interface
HDMI (High-Definition Multimedia Interface) is an industry-supported,
uncompressed, all-digital audio/video interface. HDMI provides an interface
between any compatible digital audio/video source, such as a set-top box, DVD
player, and A/V receiver and a compatible digital audio and/or video monitor,
such as a digital television (DTV), over a single cable.
Use the HDMI port on your computer to connect with high-end audio and video
equipment. Single cable implementation allows tidy setup and fast connection.
English
BIOS utility
33
BIOS utility
The BIOS utility is a hardware configuration program built into your
computer’s BIOS.
Your computer is already properly configured and optimized, and you do not
need to run this utility. However, if you encounter configuration problems, you
may need to run it.
To activate the BIOS utility, connect a USB keybaord to your tablet PC and press
<F2> during the POST; while the computer logo is displayed.
Note: To access the BIOS Utility, you need to connect a USB
keybaord, and hold the Windows key while pressing the power
button.
Boot sequence
To set the boot sequence in the BIOS utility, activate the BIOS utility, then select
Boot from the categories listed at the top of the screen.
Frequently asked questions 34
English
Frequently asked questions
The following is a list of possible situations that may arise during the use of
your computer. Easy solutions are provided for each one.
I turned on the power, but the computer does not start or
boot up.
Look at the power indicator:
• If it is not lit, no power is being supplied to the computer. Check the
following:
• If you are using on the battery, it may be low and unable to power
the computer. Connect the AC adapter to recharge the battery pack.
• Make sure that the AC adapter is properly plugged into the computer
and to the power outlet.
Nothing appears on the screen.
The computer's power management system automatically blanks the screen to
save power. Press any key to turn the display back on.
If pressing a key does not turn the display back on, three things might be
the cause:
• The brightness level might be too low. Press <Fn> + < > (increase) to
adjust the brightness level.
• If the Sleep indicator is lit, the computer is in Sleep mode. Press and release
the power button to resume.
No audio is heard from the computer.
Check the following:
• The volume may be muted. In Windows, look at the volume control
(speaker) icon on the taskbar. If it is crossed-out, click on the icon and
deselect the Mute all option.
• The volume level may be too low. In Windows, look at the volume control
icon on the taskbar. You can also use the volume control buttons to adjust
the volume.
• If headphones, earphones or external speakers are connected to the lineout port on the computer, the internal speakers automatically turn off.
The printer does not work.
Check the following:
• Make sure that the printer is connected to a power outlet and that it is
English
Requesting service
turned on.
• Make sure that the printer cable is connected securely to a USB port and
the printer.
35
Requesting service
International Travelers Warranty (ITW)
Your computer is backed by an International Travelers Warranty (ITW) that
gives you security and peace of mind when traveling. Our worldwide network
of service centers are there to give you a helping hand.
An ITW passport comes with your computer. This passport contains all you need
to know about the ITW program. A list of available, authorized service centers is
in this handy booklet. Read this passport thoroughly.
Always have your ITW passport on hand, especially when you travel, to receive
the benefits from our support centers. Place your proof-of-purchase in the flap
located inside the front cover of the ITW passport.
If the country you are traveling in does not have an Acer-authorized ITW service
site, you can still get in contact with our offices worldwide. Please consult
www.acer.com.
Before you call
Please have the following information available when you call Acer for online
service, and please be at your computer when you call. With your support, we
can reduce the amount of time a call takes and help solve your problems
efficiently. If there are error messages or beeps reported by your computer,
write them down as they appear on the screen (or the number and sequence in
the case of beeps).
You are required to provide the following information:
Name: ___________________________________________________________________
Address: _________________________________________________________________
Telephone number: _______________________________________________________
Machine and model type: _________________________________________________
Serial number: ____________________________________________________________
Date of purchase: _________________________________________________________
Troubleshooting 36
English
Troubleshooting
This chapter shows you how to deal with common system problems.
Read it before calling a technician if a problem occurs. Solutions to more
serious problems require opening up the computer. Do not attempt to open
the computer yourself; contact your dealer or authorized service center
for assistance.
Troubleshooting tips
This computer incorporates an advanced design that delivers onscreen error
message reports to help you solve problems.
If the system reports an error message or an error symptom occurs, see the table
below. If the problem cannot be resolved, contact your dealer. See "Requesting
service" on page 35.
Error messages Corrective action
CMOS battery bad Contact your dealer or an authorized service center.
CMOS checksum error Contact your dealer or an authorized service center.
Disk boot failure Insert a system (bootable) disk into an external drive,
then press <Enter> to reboot.
Equipment
configuration error
Hard disk 0 error Contact your dealer or an authorized service center.
Hard disk 0 extended
type error
I/O parity error Contact your dealer or an authorized service center.
Keyboard error or no
keyboard connected
Keyboard interface
error
Memory size mismatch Press <F2> (during POST) to enter the BIOS utility,
Press <F2> (during POST) to enter the BIOS utility,
then press Exit in the BIOS utility to reboot.
Contact your dealer or an authorized service center.
Contact your dealer or an authorized service center.
Contact your dealer or an authorized service center.
then press Exit in the BIOS utility to reboot.
If you still encounter problems after going through the corrective measures,
please contact your dealer or an authorized service center for assistance. Some
problems may be solved using the BIOS utility.
English
FCC statement
37
Regulations and safety notices
FCC statement
This device has been tested and found to comply with the limits for a Class B
digital device pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This device generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this device does cause harmful interference to radio or television
reception, which can be determined by turning the device off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the device and receiver.
• Connect the device into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/television technician for help.
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables
to maintain compliance with FCC regulations.
Notice: Peripheral devices
Only peripherals (input/output devices, terminals, printers, etc.) certified to
comply with the Class B limits may be attached to this equipment. Operation
with non-certified peripherals is likely to result in interference to radio and TV
reception.
Caution
Changes or modifications not expressly approved by the manufacturer could
void the user's authority, which is granted by the Federal Communications
Commission, to operate this computer.
Notice: Canadian users
This Class B digital apparatus complies with Canadian ICES-003.
Regulations and safety notices 38
English
Remarque à l'intention des utilisateurs canadiens
Cet appareil numérique de la classe B est conforme a la norme NMB-003 du
Canada.
Compliant with Russian regulatory certification
LCD pixel statement
The LCD unit is produced with high-precision manufacturing techniques.
Nevertheless, some pixels may occasionally misfire or appear as black or
red dots. This has no effect on the recorded image and does not constitute
a malfunction.
Radio device regulatory notice
Note: Below regulatory information is for models with wireless
LAN and / or Bluetooth only.
General
To prevent radio interference to the licensed service, this device is intended to
be operated indoors.
This product complies with the radio frequency and safety standards of any
country or region in which it has been approved for wireless use. Depending on
configurations, this product may or may not contain wireless radio devices (such
as wireless LAN and/or Bluetooth modules). Below information is for products
with such devices.
Declaration of Conformity for EU countries
Hereby, Acer, declares that this computer is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
English
The FCC RF safety requirement
39
List of applicable countries
EU member states as of July 2009 are: Belgium, Denmark, Germany, Greece,
Spain, France, Ireland, Italy, Luxembourg, the Netherlands, Austria, Portugal,
Finland, Sweden, United Kingdom, Estonia, Latvia, Lithuania, Poland, Hungary,
Czech Republic, Slovak Republic, Slovenia, Cyprus, Malta, Bulgaria and
Romania. Usage allowed in the countries of European Union, as well as Norway,
Switzerland, Iceland and Liechtenstein. This device must be used in strict
accordance with the regulations and constraints in the country of use.
For further information, please contact local office in the country of use. Please
see http://ec.europa.eu/enterprise/rtte/ implem.htm for the latest country list.
The FCC RF safety requirement
The radiated output power of the wireless LAN Mini PCI Card and Bluetooth
card is far below the FCC radio frequency exposure limits. Nevertheless, the
computer series shall be used in such a manner that the potential for human
contact during normal operation is minimized as follows:
1 Users are requested to follow the RF safety instructions on wireless option
devices that are included in the user's manual of each RF option device.
2 This device is restricted to indoor use due to its operation in the 5.15 to
5.25 GHz frequency range. FCC requires this product to be used indoors for
the frequency range 5.15 to 5.25 GHz to reduce the potential for harmful
interference to co-channel Mobile Satellite systems.
3 High power radar are allocated as primary users of the 5.25 to 5.35 GHz
and 5.65 to 5.85 GHz bands. These radar stations can cause interference
with and/or damage this device.
4 An improper installation or unauthorized use may cause harmful
interference to radio communications. Also any tampering of the internal
antenna will void the FCC certification and your warranty.
Canada — Low-power license-exempt radio communication devices (RSS-210)
Exposure of humans to RF fields (RSS-102)
The computer series employs low gain integral antennas that do not emit RF
field in excess of Health Canada limits for the general population; consult Safety
Code 6, obtainable from Health Canada's website at www.hc-sc.gc.ca/rpb.
This device complies with RSS210 of Industry Canada.
Regulations and safety notices 40
English
This Class B digital apparatus complies with Canadian ICES-003, Issue 4, and RSS210, No 4 (Dec 2000) and No 5 (Nov 2001).
Cet appareil numérique de la classe B est conforme à la norme NMB-003, No. 4,
et CNR-210, No 4 (Dec 2000) et No 5 (Nov 2001).
"To prevent radio interference to the licensed service, this device is intended to
be operated indoors and away from windows to provide maximum shielding.
Equipment (or its transmit antenna) that is installed outdoors is subject to
licensing."
« Pour empêcher que cet appareil cause du brouillage au service faisant l'objet
d'une licence, il doit être utilisé a l'intérieur et devrait être placé loin des
fenêtres afin de fournir un écran de blindage maximal. Si le matériel (ou son
antenne d'émission) est installé à l'extérieur, il doit faire l'objet d'une licence.
Caution: When using IEEE 802.11a wireless LAN, this product is restricted to
indoor use due to its operation in the 5.15- to 5.25-GHz frequency range.
Industry Canada requires this product to be used indoors for the frequency
range of 5.15 GHz to 5.25 GHz to reduce the potential for harmful interference
to co-channel mobile satellite systems. High power radar is allocated as the
primary user of the 5.25- to 5.35-GHz and 5.65 to 5.85-GHz bands. These radar
stations can cause interference with and/or damage to this device.
The maximum allowed antenna gain for use with this device is 6dBi in order to
comply with the E.I.R.P limit for the 5.25- to 5.35 and 5.725 to 5.85 GHz
frequency range in point-to-point operation.
Loading...
