Acer Veriton N Series
Acer Veriton N4670G
• Small and Powerful
• Flexible and Expandable
• Reliable and Secure
Processor: Intel® Core™ i7-10700T
• Memory: 16GB DDR4 RAM (2 x 8GB)
• Hard drive: 512 GB PCIe SSD
Page 2
Acer Veriton N4670G SPECIFICATIONS
Ordering Information
Model Veriton N4670G T emp P/N DT ACG_DT .VTZEG.00V Acer P /N DT .VTZEG.00V EAN 4710886171003 Factory Location China Form factor 1 Liter PC Country Germany Short description Intel® Core™ i7-10700T / 16 GB DDR4
RAM / 512 GB PCIe SSD / Intel® UHD­Grafik 630 / Windows 10 Pr o (64 Bit) / Black
Processor and chipset
Processor Intel® Core™ i7-10700T Pr ocessor Chipset Intel® H470 Express Chipset Cache 16 MB Intel® Smart Cache Clock frequency 2,00 GHz (Up to 4,50 GHz Turbo-Boost) Processing cor es / threads 8 / 16 Socket LGA 1200
Graphics card
Graphics card Intel® UHD-Grafik 630
Storage and drives
Memory 16GB DDR4 RAM (2 x 8GB) Maximum RAM Up to 32 GB Dual-Channel DDR4 2933
MHz
Mass storage 512 GB M.2 PCIe Solid-State-Drive (SSD)
80mm
Optical drive -
IO ports
VGA ports ­DVI ports ­HDMI ports 1x Displayports 1x PS/2 ports ­PCI expansion slots 2x M.2 Slot for SSD (1x free), 1x M.2 Slot for
WLAN Audio ports back ­Audio Anschlüsse front 2x Rear USB ports 3x USB 3.2 Gen 1, 1x USB 2.0 Front USB ports 1x USB 3.2 Gen 1, 1x USB 3.2 Gen 2, 1x USB
3.2 Gen 2 T ype-C Ethernet (RJ45) 1x Parallel interface Optional Cardreader -
Connections
WLAN Intel® Dual Band Wireless-Gigabit-AX,
802.11 ax/ac/ a/b/g/n Ethernet technology Gigabit Ethernet
Software
Operating system Windows 10 Pro (64 Bit) Office software Microsoft Office 2019 T rial Other software Acer Office Manager,
Acer Contr ol Center, Acer Pr oShield
Power supply and consumption
Power adapt er 90 watts power supply
Scope of delivery
Keyboard USB keyboard Mouse USB mouse Guarantee booklet Y es External power supply unit Y es Special accessories included Stand, VESA mounting kit, Power adapter
Acer V eriton N4670G - DT. VTZEG.00V - 2020.11.05 - 10:08 Page 2 of 3
Page 3
Acer Veriton N4670G SPECIFICATIONS
T oolless kit Optional
Norms and Standards
DMI Y es Audio standard Integrated high-definition sound PXE Yes EPEAT® (specific regions) EPEAT Silver PC2001 Yes ENERGY ST AR® Y es CB Y es FCC Y es BSMI Y es RoHS Y es CE Yes TÜV GS Yes
Others
Mainboard form factor Mini-ITX SCCM portal www.acer.com/sccm/ Service weblink www.acer .com/ac/en/US/ content/support Integrated housing lock No Kensington lock slot Y es Intrusion alert Y es HDD password protection Y es RAID No Intel AMT No WoL (W ake on LAN) Y es Intel vPro No DASH Management Y es (1.1) Quickstartguide Yes T rusted platform module (TPM) Y es (v2.0) Warranty 3 Y ears Carry-In Others Additional T ype-C Port (with power
delivery)
Dimensions and weight
Housing colour Black Number of devices per pallett (S/F or T ruck) 98 (56 / 42) Number of devices per pallet (A/F) 14 Weight (kg) 1,6 Housing dimensions (W x H x D in mm) 192 x 33.2 x 204 Carton dimensions / weight (W x H x D) 495 x 295 x 160 (mm) / 3,5 Kg
Technical Specifications
S/PDIF No Serial ports Optional
Due to our ongoing commitment to the continuous impro vement of the quality of our products, this data sheet is subject to change without notic e. Availability may vary fr om region to region. Acer is not responsible for any errors or omissions in the pr oduct descriptions. Copyright 2020 Acer Computer GmbH, Germany . All rights reserved. Acer and the Acer logo are r egistered trademarks of Acer Incorporated. Micr osoft and Windows are registered trademarks of Microsoft Corporation. Intel and Pentium are register ed trademarks of Intel Corporation. All other mentioned or otherwise recognizable trademarks, r egistered trademarks and/or service marks are the property of their respective owners. All prices quoted are recommended retail prices of the manufacturer.
Acer V eriton N4670G - DT. VTZEG.00V - 2020.11.05 - 10:08 Page 3 of 3
