Acer H5382BD User Manual

Acer Projector

A1200/B110/CE-X10/C11X/AX331

A1300W/B120/CE-W10/C11W/AW331

H5382BD/E232/HE-722

A1500/B150/CE-810/H6511BD

H6512BD/E146D/HE-805J/L552/V62/

H6510BD+/P1502 Series

User's Guide

Copyright © 2016. Acer Incorporated.
All Rights Reserved.

Acer Projector User's Guide
Original Issue: 05/2016

Changes may be made periodically to the information in this publication without obligation
to notify any person of such revisions or changes. Such changes will be incorporated in new
editions of this manual or supplementary documents and publications. This company makes
no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims the implied warranties of merchantability or fitness for a
particular purpose.

Record the model number, serial number, purchase date and place of purchase information in
the space provided below. The serial number and model number are recorded on the label
affixed to your projector. All correspondence concerning your unit should include the serial
number, model number and purchase information.

No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronically, mechanically, by photocopy, recording or otherwise,
without the prior written permission of Acer Incorporated.

Model number: _________________________________

Serial number: __________________________________

Date of purchase: _______________________________

Place of purchase: ______________________________

Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies' product
names or trademarks are used herein for identification purposes only and belong to their respective
companies.

"HDMI™, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC."

Information for your safety and comfort

Read these instructions carefully. Keep this document for future reference.
Follow all warnings and instructions marked on the product.

Turning the product off before cleaning

Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.

Caution for plug as disconnecting device

Observe the following guidelines when connecting and disconnecting power to
the external power supply unit:

• Install the power supply unit before connecting the power cord to the AC
power outlet.

• Unplug the power cord before removing the power supply unit from the
projector.

• If the system has multiple sources of power, disconnect power from the
system by unplugging all power cords from the power supplies.

Caution for Accessibility

Be sure that the power outlet you plug the power cord into is easily accessible
and located as close to the equipment operator as possible. When you need to
disconnect power to the equipment, be sure to unplug the power cord from the
electrical outlet.

iii

Warnings!

• Do not use this product near water.

• Do not place this product on an unstable cart, stand or table. If the product
falls, it could be seriously damaged.

• Slots and openings are provided for ventilation to ensure reliable
operation of the product and to protect it from overheating. These
openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug or other similar surface.

This product should never be placed near or over a radiator or heat register, or
in a built-in installation unless proper ventilation is provided.

• Never push objects of any kind into this product through cabinet slots as
they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock. Never spill liquid of any kind onto or into
the product.

iv

• To avoid damage of internal components and to prevent battery leakage,
do not place the product on a vibrating surface.

• Never use it under sporting, exercising, or any vibrating environment
which will probably cause unexpected short current or damage rotor
devices, lamp.

Using electrical power

• This product should be operated from the type of power indicated on the
marking label. If you are not sure of the type of power available, consult
your dealer or local power company.

• Do not allow anything to rest on the power cord. Do not locate this
product where people will walk on the cord.

• If an extension cord is used with this product, make sure that the total
ampere rating of the equipment plugged into the extension cord does not
exceed the extension cord ampere rating. Also, make sure that the total
rating of all products plugged into the wall outlet does not exceed the fuse
rating.

• Do not overload a power outlet, strip or receptacle by plugging in too
many devices. The overall system load must not exceed 80% of the branch
circuit rating. If power strips are used, the load should not exceed 80% of
the power strip's input rating.

• This product's AC adapter is equipped with a three-wire grounded plug.
The plug only fits in a grounded power outlet. Make sure the power outlet
is properly grounded before inserting the AC adapter plug. Do not insert
the plug into a non-grounded power outlet. Contact your electrician for
details.

Warning! The grounding pin is a safety feature. Using a power outlet that is
not properly grounded may result in electric shock and/or injury.

Note: The grounding pin also provides good protection from unexpected
noise produced by other nearby electrical devices that may interfere with
the performance of this product.

• Use the product only with the supplied power supply cord set. If you need
to replace the power cord set, make sure that the new power cord meets
the following requirements: detachable type, UL listed/CSA certified, VDE
approved or its equivalent, 4.5 meters (15 feet) maximum length.

Product servicing

Do not attempt to service this product yourself, as opening or removing covers
may expose you to dangerous voltage points or other risks. Refer all servicing to
qualified service personnel.

Unplug this product from the wall outlet and refer servicing to qualified service
personnel when:

• the power cord or plug is damaged, cut or frayed

• liquid was spilled into the product

• the product was exposed to rain or water

• the product has been dropped or the case has been damaged

• the product exhibits a distinct change in performance, indicating a need
for service

• the product does not operate normally after following the operating
instructions

Note: Adjust only those controls that are covered by the operating
instructions, since improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the product to normal condition.

Warning! For safety reasons, do not use non-compliant parts when adding
or changing components. Consult your reseller for purchase options.

Your device and its enhancements may contain small parts. Keep them out of
the reach of small children.

Additional safety information

• Do not look into the projector's lens when the lamp is on. The bright may
hurt your eyes.

• Turn on the projector first and then signal sources

• Do not place the product in following environments:

• Space that is poorly ventilated or confined. At least 50cm clearance from walls

and free flow of air around the projector is necessary.

• Locations where temperatures may become excessively high, such as inside of a

car with all windows rolled up.

• Locations where excessive humidity, dust, or cigarette smoke may contaminate

optical components, shortening the life span and darkening the image.

• Locations near fire alarms.

• Locations with an ambient temperature above 40 ºC/104 ºF.

• Locations where the altitudes are higher than 10000 feet.

• Unplug immediately if there is something wrong with your projector. Do
not operate if smoke, strange noise or odor comes out of your projector. It
might cause fire or electric shock. In this case, unplug immediately and
contact your dealer.

• Do not keep using this product to break or drop it. In this case contact your
dealer for inspection.

• Do not face the projector lens to the sun. It can lead to fire.

• When switching the projector off, suggest to ensure the projector
completes its cooling cycle before disconnecting power.

• Do not frequently turn off the main power abruptly or unplug the
projector during operation. The best way is to wait for the fan to turn off
before turning main power off.

v

vi

6°

6°

• Do not touch air outlet grille and bottom plate which becomes hot.

• Clean the air filter frequently if have. The temperature inside may rise and
cause damage when the filter/ventilation slots clogged with dirt or dust.

• Do not look into the air outlet grille when projector is operating. It may
hurt your eyes.

• Always open the lens shutter or remove the lens cap when the projector is
on.

• Do not block the projector lens with any object when the projector is
under operation as this could cause the object to become heated and
deformed or even cause a fire. To temporarily turn off the lamp, press HIDE
on the remote control.

• The lamp becomes extremely hot during operation. Allow the projector to
cool for approximately 45 minutes prior to removing the lamp assembly for
replacement.

• Do not operate lamps beyond the rated lamp life. It could cause it to break
on rare occasions.

• Never replace the lamp assembly or any electronic components unless the
projector is unplugged.

• The product will detect the life of the lamp itself. Please be sure to change
the lamp when is showing warning message.

• When changing the lamp, please allow unit to cool down, and follow all
changing instructions.

• Reset the "Lamp Hour Reset" function from the Onscreen display
"Management" menu after replacing the lamp module.

• Do not attempt to disassemble this projector. There are dangerous high
voltages inside which may hurt you. The only user serviceable part is the
lamp which has its own removable cover. Refer servicing only to suitable
qualified professional service personnel.

• Do not stand the projector on end vertically. It may cause the projector to
fall over, causing injury or damage.

• This product is capable of displaying inverted images for ceiling mount
installation. Only use acer ceiling mount kit for mounting the projector
and ensure it is securely installed.

• The projector should be placed in a horizontal way by means of desktop or
ceiling mount mode only, and its tilt angles should not exceed 6 degrees,
otherwise it would cause dramatical decrease of lamp life or severe safety
concern of system malfunction.

vii

“Lamp(s) contain Mercury,
Dispose Properly.”

RG2

Caution for Listening

To protect your hearing, follow these instructions.

• Increase the volume gradually until you can hear clearly and comfortably.

• Do not increase the volume level after your ears have adjusted.

• Do not listen to music at high volumes for extended periods.

• Do not increase the volume to block out noisy surroundings.

• Decrease the volume if you can't hear people speaking near you.

Disposal instructions

Do not throw this electronic device into the trash when discarding. To minimize
pollution and ensure utmost protection of the global environment, please
recycle. For more information on the Waste from Electrical and Electronics
Equipment (WEEE) regulations, visit
http://www.acer-group.com/public/Sustainability/sustainability01.htm

Mercury advisory

For projectors or electronic products containing an LCD/CRT monitor or display:

Lamp(s) inside this product contain mercury and must be recycled or disposed of
according to local, state or federal laws. For more information, contact the
Electronic Industries Alliance at www.eiae.org. For lamp-specific disposal
information, check www.lamprecycle.org

Do not stare into the beam, RG2

"As with any bright source, do not stare into the direct beam, RG2 IEC 62471­5:2015"

viii

First things first

Usage Notes

Do:

• Turn off the product before cleaning.

• Use a soft cloth moistened with mild detergent to clean the display
housing.

• Disconnect the power plug from AC outlet if the product is not being used
for a long period of time.

Don't:

• Block the slots and openings on the unit provided for ventilation.

• Use abrasive cleaners, waxes or solvents to clean the unit.

• Use under the following conditions:

• In extremely hot, cold or humid environments.

• In areas susceptible to excessive dust and dirt.

• Near any appliance that generates a strong magnetic field.

• Place In direct sunlight.

Precautions

Follow all warnings, precautions and maintenance as recommended in this
user's guide to maximize the life of your unit.

Warning:

• Do not look into the projector's lens when the lamp is on. The bright light may hurt
your eyes.

• To reduce the risk of fire or electric shock, do not expose this product to rain or
moisture.

• Please do not open or disassemble the product as this may cause electric shock.

• When changing the lamp, please allow unit to cool down, and follow all changing
instructions.

• This product will detect the life of the lamp itself. Please be sure to change the lamp
when it shows warning messages.

• Reset the "Lamp Hour Reset" function from the Onscreen display "Management"
menu after replacing the lamp module.

• When switching the projector off, please ensure the projector completes its cooling
cycle before disconnecting power.

• Turn on the projector first and then the signal sources.

• Do not use lens cap when projector is in operation.

• When the lamp reaches the end of its life, it will burn out and may make a loud
popping sound. If this happens, the projector will not turn back on until the lamp
module has been replaced. To replace the lamp, follow the procedures listed under
"Replacing the Lamp".

Information for your safety and comfort iii

First things first viii

Usage Notes viii

Precautions viii

Introduction 1

Product Features 1

Package Overview 2

Projector Overview 3

Projector Outlook 3

Control Panel 6

Remote Control Layout 7

MHL (Mobile High-Definition Link) Control 9

Getting Started 11

Connecting the Projector 11

Turning the Projector On/Off 13

Turning on the Projector 13

Turning the projector off 14

Adjusting the Projected Image 15

Adjusting the Height of Projected Image 15

How to optimize image size and distance 16

How to get a preferred image size by adjusting
distance and zoom 20

User Controls 24

Installation menu 24

Onscreen Display (OSD) Menus 25

Color 26

Image 28

Setting 30

Management 32

Audio 33

3D 33

Language 34

Contents

Appendices 35

Troubleshooting 35

LED & Alarm Definition Listing 39

How to install the Inner Dongle 40

Cleaning and replacing the dust filters (Option) 41

Replacing the Lamp 42

Ceiling Mount Installation 43

Specifications 46

Compatibility modes 49

Regulations and safety notices 54

English

Introduction

Product Features

This product is a single-chip DLP® projector. Outstanding features include:

®

•DLP

• A1200/B110/CE-X10/C11X/AX331 series: 1024x768 XGA resolution

• Enables projecting 3D content via DLP Link Technology: Blue-Ray 3D

• Acer ColorBoost technology delivers nature’s true colors for vivid, life-like

• High brightness and contrast ratio

• Acer LumiSense+ technology can intelligently optimizes the brightness and

• Versatile display modes (Bright, Presentation, Standard, sRGB, Rec. 709,

• NTSC / PAL / SECAM compatible and HDTV (480i/p, 576i/p, 720p, 1080i/p)

• Lower power consumption and economy (ECO) mode extend lamp life

• Acer EcoProjeciton Technology delivers Intelligent power management

• Equipped with HDMI

• Support HDMI CEC function

• Smart detection delivers quick, intelligent source detection

• Multi-language onscreen display (OSD) menus

• Manual focus projection lens zooms up to 1.1x or 1.3x

• 2x digital zoom

• Microsoft

• Support MHL V2.1 signal display

• Support LumiSense+

• Built-in One 3 Watts or 10 Watts speaker

technology

A1300W/B120/CE-W10/C11W/AW331 series: 1280x800 WXGA resolution
H5382BD/E232/HE-722 series: 1280x720 720p resolution
A1500/B150/CE-810/H6511BD/H6512BD/E146D/HE-805J/L552/V62/
H6510BD+/P1502 series: 1920x1080 1080p resolution
Full/4:3/16:9/16:10/L.Box aspect ratio supported

supported and nVidia 3DTV Play Ready

images

color saturation of projected image based on actual ambient light.

Movie, Dark Cinema, Game, Sports, ISF Night, ISF Day, User) enable
optimum performance in any situation

supported

approach and physical efficiency improvement

™ & MHL connection supporting HDCP

®

Windows® 2000, XP, Vista®, Windows 7, Windows 8.1,

Windows 10, Macintosh

®

OS compliant

1

Note: Functions vary depending on model definition.

2

English

Package Overview

This projector comes with all the items shown below. Check to make sure your
unit is complete. Contact your dealer immediately if any thing is missing.

Projector Power cord VGA cable

Security card

(option)

Carrying case

(option)

2 x Batteries

(option)

Micro USB (male) to Micro
USB (female) 50 mm cable

(option)

User’s guide Quick start guide

Dust filters

(option)

MHL HDMI

DC 5V IN

WirelessCAST

(option)

WirelessHD-Kit

(option)

Remote control

Micro USB to Mini USB

80 mm cable (option)

English

Projector Overview

7

432 5 8

6

12

11

9

10

1

Projector Outlook

Front / upper side

# Description # Description

1 Air outlet 7 Control panel

2 Ambient light sensor 8 Lamp cover

3 Focus ring 9 Lens cap

4 Zoom ring 10 Projection lens

5 Remote control receiver 11 Air inlet

6 Power button 12 Tilt adjusting wheels

3

4

English

4 5 6 5 7 11 1221 103 8 9

2 / MHL

Internal 5V

13
14

4 5 6 12153 9

Right / Rear side
Type 1

# Description # Description

1 Power socket 9 Composite video input connector

2 Kensington™ lock port

3 HDMI 1 connector

4 5V DC output connector (device charge

& support mouse page up/down
function)

5 PC analog signal/HDTV/component

video input connector (VGA IN 1, VGA
IN 2)

6 RS232 connector 14 HDMI 2/MHL connector

Monitor loop-through output

7

connector (for VGA IN 1 only)

8 S-Video input connector

10 Audio in 2 connector (for S-Video,

Composite)

11 Audio in 1 connector (for VGA IN 1,

VGA IN 2)

12

Audio out connector

13

Internal 5V connector

15

Audio in connector

Note: Functions vary depending on model definition.

English

Type 2

4 52 6 101 893 7

# Description # Description

1 Power socket 6 RS232 connector
2 HDMI 1 connector 7 Composite video input connector
3 HDMI 2/MHL connector 8 Audio in connector
4 5V DC output connector (device charge

& support mouse page up/down
function)

5 PC analog signal/HDTV/component

video input connector

9

Audio out connector

10

Kensington™ lock port

5

Note: Functions vary depending on model definition.

6

English

21

10

8

6

4 7

9

5

3

Control Panel

# Icon Function Description
1 POWER POWER Power Indicator LED
2 LAMP LAMP Lamp Indicator LED
3 TEMP TEMP Temp Indicator LED

4POWER

5

6 BACK BACK Returns to the previous operation.
7 SOURCE SOURCE Changes the active source.
8 ENTER ENTER Confirm your selection of items.

9 Keystone

10 MENU MENU

Four directional
select keys

See the contents in "Turning the Projector
On/Off" section.

Use to select items or make
adjustments to your selection.

Adjusts the image to compensate for
distortion caused by tilting the projector.

Press "MENU" to launch the Onscreen
display (OSD) menu, back to the previous
step for the OSD menu operation or exit
the OSD menu.

Note: Functions vary depending on model definition.

English

Remote Control Layout

1

7

8

9

10

19

20
21

22

23

24

25

Model No:J-25041

MC.JMV11.008

2
3

4
5

6

11

12

13

14
15

16

17
18

# Icon Function Description

1

2 POWER Refer to the "Turning the Projector On/Off" section.

Infrared
transmitter

Sends signals to the projector.

26

27

Model No:J-25030

MC.JMV11.007

7

3 MUTE To turn on/off the volume.

4 RATIO To choose the desired aspect ratio.

5

6

Select/Enter Confirm your selection of items.

Play/Pause Press to begin/pause playback.

Four
directional
select keys

Use up, down, left, right buttons to select items or make
adjustments to your selection.

7 3D Press "3D" to select 3D models.

8 SOURCE Changes the active source.

9MODE

10 KEYSTONE

11

BACK Returns to the previous operation.

STOP Press to stop playback.

12 VGA

Press "MODE" to select the display mode from Bright,
Presentation, Standard, Video and User.

Adjusts the image to compensate for distortion caused
by tilting the projector.

Press "VGA" to change source to the VGA connector. This
connector supports analog RGB, YPbPr (480p/576p/720p/
1080i), YCbCr (480i/576i) and RGBsync.

8

English

# Icon Function Description

13 FREEZE To pause the screen image.

For computer mode only. Use this button to select the

14 PgUp

15 COMPONENT No function.

16 PgDn

17 MEDIA No function.

18 KeyPad 0~9 Press "0~9" to input a password in the "Security" OSD.

19 MENU

20 HDMI™/MHL To change source to HDMI/MHL.

previous page. This function is only available when USB
Ctrl connector (mini type B) is connected to a computer
via a USB cable.

For computer mode only. Use this button to select the
next page. This function is only available when USB Ctrl
connector (mini type B) is connected to a computer via a
USB cable.

• Press "MENU" to launch the Onscreen display (OSD)
menu, back to the previous step for the OSD menu
operation or exit the OSD menu.

• Confirm your selection of items.

21 HIDE

22 ZOOM IN Zooms the projector display in.

23 VIDEO To change source to COMPOSITE VIDEO.

24 ZOOM OUT Zooms the projector display out.

25 LAN/WiFi

26 Laser pointer Aim the remote at the viewing screen.

27 Laser button

Momentarily turns off the video. Press "HIDE" to hide
the image, press again to display the image.

Press “LAN/WiFi” to change source to “WiFi.” Only
available while Acer WirelessCAST (MWA3) is plgged in
projector and see “WiFi” in source list.

Aim the remote at the viewing screen, press and hold
this button to activate the laser pointer.

Note: Functions vary depending on model definition.

9

English

8

1

2

9

11

7

10

3

6

4

5

MHL (Mobile High-Definition Link) Control

# Icon Function Description

1 SOURCE

2MODE

3MUTE

4

5

6

7MENU

8

9

Volume UP Increases the volume. (only for Multi-Media mode)



Volume Down Decreases the volume. (only for Multi-Media mode)



Select/Enter Press to select/enter the file. (only for Navigation mode)

Play/Pause

Four
directional
select keys

Back/Exit

Stop Discontinues playback. (only for Multi-Media mode)

Press the "SOURCE" button to toggle between
Navigation, Numeric and Multi-Media mode.

• Press "MODE" button for one second to activate
the MHL Control Mode.

• To exit, press the "MODE" button again.

To turn on/off the volume. (only for Navigation or Multi­Media mode)

Toggles between playback and pause. (only for Multi­Media mode)

Press to launch the root memu.
(only for Navigation mode)

Use up, down, left, right buttons to select items or make
adjustments to your selection.
(only for Navigation mode)

• Press "BACK" to go back one menu step.

• To exit the file.

(only for Navigation mode)

10

English

# Icon Function Description

10 PgUp/PgDn

11 KeyPad 0~9 Number buttons. (only for Numeric mode)

Use the button to select the next or previous page. (only
for Navigation mode)

Note: Functions vary depending on model definition.

English

Getting Started

RS232

RS232

13

RS232

HDTV adapter

7

6

RBG

R

BG

D-Sub

D-Sub

8

HDMI

HDMI

4

9

10

R

W

R

W

10

5

5

Y

Y

11

D-Sub

D-Sub

8

1

12

Acer Dongle

Chromecast

2

3

Audio output

DVD player

Power Bank

DVD player, Set-top Box,

HDTV receiever

Smart Phone

S-Video output

Video output

Connecting the Projector

Type 1

2 / MHL

Int
e
rnal 5V

11

# Description # Description

1 Power cord 8 VGA cable

2 Micro USB (male) to Micro USB

(female) 50 mm cable

3 Micro USB to Mini USB 80 mm cable 10 Audio cable Jack/RCA

4 HDMI cable 11 Composite video cable

5 USB cable for charging device 12 S-Video cable

6 3 RCA component cable 13 RS232 cable

7 VGA to component/HDTV adapter

Note 1: To ensure the projector works well with your computer,
please make sure the timing of the display mode is compatible
with the projector.
Note 2: Functions vary depending on model definition.
Note 3:

USB cable needs powered extender if the length is over 5 m.
Note 4: Some smartphones require a converter (supplied by
smartphone maker) to enable the MHL function.
Note 5: USB DC 5V out connector support 5V/2.0A power output
for power bank charging only when MHL source is not detected.
Note 6: VGA OUT loops through for VGA IN 1 only.

9 Audio cable Jack/Jack

12

English

RS232

RS232

10

RS232

HDTV adapter

5

6

RBG

R

BG

D-Sub

D-Sub

4

HDMI

HDMI

2

HDMI

HDMI

2

HDMI

3

USB

MHL

R

W

7

8

7

R

W

11

11

Y

Y

9

1

Video output

DVD player

Audio Output

Power Bank

DVD player,

Set-top Box,

HDTV receiever

Smart Phone

Type 2

# Description # Description

1 Power cord 7 Audio cable Jack/RCA

2 HDMI cable 8 Audio cable Jack/Jack

3 MHL cable (MicroUSB to HDMI) 9 Composite video cable

4 VGA cable 10 RS232 cable

5 VGA to component/HDTV adapter 11 USB cable for charging device

6 3 RCA component cable

Note 1: To ensure the projector works well with your computer,
please make sure the timing of the display mode is compatible
with the projector.
Note 2: Functions vary depending on model definition.
Note 3:

USB cable needs powered extender if the length is over 5 m.
Note 4: Some smartphones require a converter (supplied by
smartphone maker) to enable the MHL function.
Note 5: USB DC 5V out connector support 5V/1.0A power output
for power bank charging only when MHL source is not detected.

English

Turning the Projector On/Off

Power button

Turning on the Projector

1 Ensure that the power cord and signal cable are securely connected. The

Power indicator LED will flash red.

2 Turn on the projector by pressing "Power" button on the control panel or

remote control, and the Power indicator LED will turn blue.

3 Turn on your source (computer, notebook, video player ,etc.). The

projector will detect your source automatically.

• If the screen displays "Lock" and "Source" icons, it means the
projector is locked onto a specific source type and there is no such
type of input signal detected.

• If the screen displays "No Signal", please make sure the signal cables
are securely connected or press source direct key.

• If you connect to multiple sources at the same time, use the "Source"
button on either control panel or the remote control or direct source
key on the remote control to switch between inputs.

13

14

English

Turning the projector off

1 To turn the projector off, press and hold the power button. This message

appears: "Please press the power button again to complete the shutdown
process." Press the power button again.

2 The LED power indicator will turn RED and blink rapidly after the projector

is turned off, and the fan(s) will continue to operate for about 2 minutes to
ensure that the system cools properly. (only supported under "Instant
Resume" mode)

3 As long as the power cord remains plugged in, you can press the power

button to turn the projector immediately back on anytime during the 2­minute shutdown process. (only supported under "Instant Resume" mode)

4 Once the system has finished cooling, the LED power indicator will stop

blinking and turn solid red to indicate standby mode.

5 It is now safe to unplug the power cord.

Warning indicators:

• "Projector Overheated. Lamp will automatically turn off soon."
This onscreen message indicates that the projector has overheated.
The lamp with automatically turn off, the projector will automatically
shut down, and the LED temp indicator will turn solid red. Contact
your local dealer or service center.

• "Fan failed. Lamp will automatically turn off soon."
This onscreen message indicates that the fan has failed. The lamp will
automatically turn off, the projector will automatically shut down,
and the LED temp indicator will blink. Contact your local dealer or
service center.

Note 1: Whenever the projector automatically shuts down and the
LED lamp indicator turns solid red, contact your local reseller or
service center.
Note 2: Functions vary depending on model definition.
Attention! The projector will enter a two minute cool down
period to ensure continued optimal lamp operation.

English

Adjusting the Projected Image

Tilt adjusting wheel

Adjusting the Height of Projected Image

The projector is equipped with elevator feet for adjusting the height of image.

To raise/lower the image:

Use Tilt adjusting wheel to fine-tune the display angle.

15

16

English

66"

51"

51"

A

C

B

Height: 116 cm
from base to top
of image

Height:
89 cm

2.0 m
Desired Distance

M

a

x

s

c

r

e

e

n

s

i

z

e

M

i

n

s

c

r

e

e

n

s

i

z

e

How to optimize image size and distance

Consult the table below to find the optimal image sizes achievable when the
projector is positioned at a desired distance from the screen.

• XGA series
If the projector is 2.0 m from the screen, good image quality is possible for
image sizes between 51" and 66".

Note: Remind as below figure, the space of 116 cm height is
required when located at 2 m distance.

Desired

Distance

(m)
<A>

1.2 30.58 62 x 47 54 40 81 x 61 70

1.5 38 78 x 58 67 50 101 x 76 87

2.0 51 104 x 78 89 66 134 x 101 116

3.0 76 155 x 117 134 99 202 x 151 174

4.0 102 207 x 155 179 132 269 x 202 232

5.0 127 259 x 194 223 165 336 x 252 290

6.0 153 311 x 233 268 199 403 x 303 348

7.0 178 363 x 272 313 232 471 x 353 406

8.0 204 414 x 311 357 265 538 x 403 464

9.1 232 471 x 353 406 301.17 612 x 459 528

Zoom Ratio: 1.30x

Screen size

Diagonal

(inch)

<B>

(Min zoom) (Max zoom)

W (cm) x

H (cm)

Top

From base to top

of image (cm)

<C>

Screen size

Diagonal

(inch)

<B>

W (cm) x

H (cm)

From base to top

Top

of image (cm)

<C>

17

English

60"

Height: 118 cm
from base to top
of image

Height:
91 cm

2 m
Desired Distance

M

a

x

s

c

r

e

e

n

s

i

z

e

M

i

n

s

c

r

e

e

n

s

i

z

e

• WXGA series
If the projector is 2 m from the screen, good image quality is possible for image
sizes between 60" and 78".

Note: Remind as below figure, the space of 118 cm height is
required when located at 2 m distance.

78"

B

60"

C

A

Screen size

Diagonal

(inch)

<B>

W (cm) x

H (cm)

Top

From base to top

of image (cm)

<C>

Diagonal

(inch)

<B>

Screen size

W (cm) x

(Min zoom) (Max zoom)

H (cm)

Desired

Distance

(m)

<A>

1.2 36.08 78 x 49 55 47 101 x 63 71

1.5 45 97 x 61 68 59 126 x 79 89

2.0 60 130 x 81 91 78 168 x 105 118

3.0 90 194 x 121 136 117 253 x 158 178

4.0 120 259 x 162 182 156 337 x 211 237

5.0 150 324 x 202 227 196 421 x 263 296

6.0 180 389 x 243 273 235 505 x 316 355

7.0 210 453 x 283 318 274 590 x 369 414

7.7 232 499 x 312 350 301.17 649 x 405 456

Zoom Ratio: 1.30x

Top

From base to top

of image (cm)

<C>

18

English

60"

Height: 87 cm
from base to
top of image

Height:
78 cm

2 m
Desired Distance

M

a

x

s

c

r

e

e

n

s

i

z

e

M

i

n

s

c

r

e

e

n

s

i

z

e

• 720p series
If the projector is 2 m from the screen, good image quality is possible for image
sizes between 53" and 59".

Note: Remind as below figure, the space of 87 cm height is
required when located at 2 m distance.

78"

B

60"

C

A

Desired

Distance

(m)
<A>

1 26.26 58 x 33 39 29 65 x 36 43

1.5 39 87 x 49 59 44 97 x 55 65

2.0 53 116 x 65 78 59 130 x 73 87

3.0 79 174 x 98 117 88 194 x 109 130

4.0 105 233 x 131 156 117 259 x 146 174

5.0 131 291 x 164 195 146 324 x 182 217

6.0 158 349 x 196 234 176 389 x 219 261

7.0 184 407 x 229 273 205 453 x 255 304

8.0 210 465 x 262 312 234 518 x 291 348

9.0 236 523 x 294 351 263 583 x 328 391

10.3 271 599 x 337 402 301.34 667 x 375 448

Zoom Ratio: 1.11x

Screen size Top Screen size Top

(Min zoom) (Max zoom)

Diagonal

(inch)

<B>

W (cm) x

H (cm)

From base to top

of image (cm)

<C>

Diagonal

(inch)

<B>

W (cm) x

H (cm)

From base to top

of image (cm)

<C>

19

English

Note:

80"

61"

61"

• 1080p series
If the projector is 2 m from the screen, good image quality is possible for image
sizes between 61" and 80".

Remind as below figure, the space of 115 cm height is

required when located at 2 m distance.

Ma

x

s

c

r

e

e

n

s

i

z

e

M

i

n

s

c

r

e

e

n

s

i

z

e

A

2 m
Desired Distance

Desired

Distance

(m)

<A>

1.2 36.85 82 x 46 53 48 106 x 60 69

1.5 46 102 x 57 67 60 133 x 75 87

2.0 61 136 x 76 89 80 177 x 100 115

2.5 77 170 x 96 111 100 221 x 124 144

3.0 92 204 x 115 133 120 265 x 149 173

3.5 107 238 x 134 155 140 310 x 174 202

4.0 123 272 x 153 177 160 354 x 199 231

5.0 154 340 x 191 222 200 422 x 249 289

6.0 184 408 x 229 266 240 531 x 299 346

7.0 215 476 x 268 311 280 619 x 348 404

  x   x 

Zoom Ratio: 1.30x

Screen size Top Screen size Top

(Min zoom) (Max zoom)

Diagonal

(inch)

<B>

W (cm) x

H (cm)

From base to top

of image (cm)

<C>

Diagonal

(inch)

<B>

B

Height:
89 cm

W (cm) x

H (cm)

C

Height: 115 cm
from base to
top of image

From base to top

of image (cm)

<C>

20

English

A

C

D

B

Desired Distance

2.4 m

1.8 m

Height: 105 cm

from base to top
of image

60"

Desired image
size

How to get a preferred image size by adjusting
distance and zoom

The table below shows how to achieve a desired image size by adjusting either
the position or the zoom ring.

• XGA series
To obtain an image size of 60" set the projector at a distance 1.8 m and 2.4 m
from the screen.

Desired Image Size Distance (m) Top (cm)

Diagonal (inch)

<A>

30 61 x 46 1.2 53
40 81 x 61 1.2 1.6 70
50 102 x 76 1.5 2.0 88
60 122 x 91 1.8 2.4 105
70 142 x 107 2.1 2.7 123
80 163 x 122 2.4 3.1 140

90 183 x 137 2.7 3.5 158
100 203 x 152 3.0 3.9 175
150 305 x 229 4.5 5.9 263
180 366 x 274 5.4 7.1 315
200 406 x 305 6.0 7.8 351
250 508 x 381 7.6 9.8 438
300 610 x 457 9.1 526

Zoom Ratio: 1.30x

W (cm) x H (cm)

Max zoom

<B>

Min zoom

<C>

From base to top of


<D>

English

• WXGA series

Desired Distance

2.0 m

1.5 m

Height: 91 cm

from base to top of

60"

Desired
image size

To obtain an image size of 60" set the projector at a distance 1.5 m and 2.0 m
from the screen.

A

D

B

C

Desired Image Size Distance (m) Top (cm)

Diagonal (inch)

<A>

30 65 x 40 1.0 45
40 86 x 54 1.0 1.3 61
50 108 x 67 1.3 1.7 76
60 129 x 81 1.5 2.0 91
70 151 x 94 1.8 2.3 106
80 172 x 108 2.0 2.7 121

90 194 x 121 2.3 3.0 136
100 215 x 135 2.6 3.3 151
150 323 x 202 3.8 5.0 227
180 388 x 242 4.6 6.0 272
200 431 x 269 5.1 6.7 303
250 538 x 337 6.4 8.3 378
300 646 x 404 7.7 454

Zoom Ratio: 1.30x

W (cm) x H (cm)

Max zoom

<B>

Min zoom

<C>

From base to top of


<D>

21

22

English

A

C

D

B

Desired Distance

2.3 m

2.1 m

Height: 89 cm

from base to top
of image

60"

Desired
image size

• 720p series
To obtain an image size of 60" set the projector at a distance 2.1 m and 2.3 m
from the screen.

Desired Image Size Distance (m) Top (cm)

Diagonal (inch)

<A>

29 64 x 36 1.0 1.1 43
40 89 x 50 1.4 1.5 59
50 111 x 62 1.7 1.9 74
60 133 x 75 2.1 2.3 89
70 155 x 87 2.4 2.7 104
80 177 x 100 2.7 3.0 119

90 199 x 112 3.1 3.4 134
100 221 x 125 3.4 3.8 149
150 332 x 187 5.1 5.7 223
180 398 x 224 6.2 6.9 267
200 443 x 249 6.8 7.6 297
250 553 x 311 8.5 9.5 371
300 664 x 374 10.3 446

Zoom Ratio: 1.11x

W (cm) x H (cm)

Max zoom

<B>

Min zoom

<C>

From base to top of


<D>

English

• 1080p series

A

C

D

B

Desired Distance

2.0 m

1.5 m

Height: 87 cm

from base to top
of image

60"

Desired
image size

To obtain an image size of 60" set the projector at a distance 1.5 m and 2.0 m
from the screen.

Desired Image Size Distance (m) Top (cm)

Diagonal (inch)

<A>

30 66 x 37 1.0 43
40 89 x 50 1.0 1.3 58
50 111 x 62 1.3 1.6 72
60 133 x 75 1.5 2.0 87
70 155 x 87 1.8 2.3 101
80 177 x 100 2.0 2.6 116

90 199 x 112 2.3 2.9 130
100 221 x 125 2.5 3.3 144
150 332 x 187 3.8 4.9 217
180 398 x 224 4.5 5.9 260
200 443 x 249 5.0 6.5 289
250 553 x 311 6.3 8.1 361

88 859 x 483 9.7 12.6 560

3

Zoom Ratio: 1.30x

W (cm) x H (cm)

Max zoom

<B>

Min zoom

<C>

From base to top of


<D>

23

24

English

User Controls

Installation menu

The installation menu provides an onscreen display (OSD) for projector
installation and maintenance. Use the OSD only when the message "No signal
input" is displayed on the screen.

The menu options include settings and adjustments for screen size and distance,
focus, keystone correction and more .

1 Turn on the projector by pressing "Power" button on the control pad.

2 Press the "MENU" button on the remote control to launch the OSD for

projector installation and maintenance.

3 The background pattern acts as a guide to adjusting the calibration and

alignment settings, such as screen size and distance, focus and more .

4 The Installation menu includes the following options:

•Projection Mode

•Projection Location

•Auto Keystone settings

•Manual Keystone settings

•WirelessHD Dongle Pairing

•Language settings

•Reset to factory default function

Use the up and down arrow keys to select an option, the left and right
arrow keys to adjust selected option settings, and the "ENTER" to enter a
submenu for feature setting. The new settings will be saved automatically
upon exiting the menu.

5 Push the "MENU" or "BACK" button anytime to exit the menu and return

to the Acer welcome screen.

Note: Functions vary depending on model definition.

25

English

Main menu

Sub menu

Setting

Onscreen Display (OSD) Menus

The projector has multilingual OSD that allow you to make image adjustments
and change a variety of settings.

Using the OSD menus

• To open the OSD menu, press "MENU" on the remote control or control
panel.

• When the OSD is displayed, use the keys to select any item in the
main menu. After selecting the desired main menu item, press "ENTER" to

enter submenu for feature setting.

• Use the keys to select the desired item and adjust the settings by

using the keys.

• Select the next item to be adjusted in the submenu and adjust as described
above.

• Press "BACK" on the remote control or control panel, the screen will return
to the main menu.

• To exit OSD, press "BACK" on the remote control or control panel. The
OSD menu will close and the projector will automatically save the new
settings.

Note 1: Some of the following OSD settings may not be available. Please
refer to the actual OSD of your projector.
Note 2: Functions vary depending on model definition.

26

English

Color

LumiSense

+

Display Mode

Wall color

Brightness

Contrast

Saturation

Tint

The light sensor of LumiSense+ technology can intelligently
optimize the brightness and color saturation of projected image
based on actual ambient light. The feature greatly enhances dark
detail visibility and color saturation.

• Off: For normal mode. (ambient light sensor is off)

• Auto Bright: Light sensor is on to automatically detect
ambient light and optimize the brightness and color
saturation of projected image.

• Dynamic Black:automatically optimize the display of dark
movie scenes enabling them to be shown in incredible detail.

There are many factory presets optimized for various types of
images.

• Bright: For brightness optimization.

• Presentation: For meeting presentation.

• Standard: For common environment.

• sRGB: standard RGB color space.

• Game: For game content.

• Movie: For brighter and general movie/video/photo playing.

• Dark Cinema: For dark movie content.

• Sport: For sport picture.

• Rec. 709: standard Rec. 709 color space.

• ISF Day: Calibrate and optimize the projection image based on
bright environment by an ISF Certified technician.

• ISF Night: Calibrate and optimize the projection image based
on dark environment by an ISF Certified technician.

• User: Memorize user's settings.

Use this function to choose a proper color according to the wall.
There are several choices, including white, light yellow, light blue,
pink, dark green. It will compensate the color deviation due to the
wall color to show the correct image tone.

Adjust the brightness of the image.

• Press to darken the image.

• Press to lighten the image.

"Contrast" controls the difference between the lightest and darkest
parts of the picture. Adjusting the contrast changes the amount of
black and white in the image.

• Press to decrease the contrast.

• Press to increase the contrast.

Adjusts a video image from black and white to fully saturated color.

• Press to decrease the amount of color in the image.

• Press to increase the amount of color in the image.

Adjusts the color balance of red and green.

• Press to increase the amount of green in the image.

• Press to increase the amount of red in the image.

27

English

Color
Temperature

Gamma

Advanced

Mode
Use this function to choose CT1, CT2 (Native), CT3, User mode.

R Gain
Adjusts the red gain for color temperature optimization.

G Gain
Adjusts the green gain for color temperature optimization.

B Gain
Adjusts the blue gain for color temperature optimization.

R Bias
Adjusts the red bias for color temperature optimization.

G Bias
Adjusts the green bias for color temperature optimization.

B Bias
Adjusts the blue bias for color temperature optimization.

Effects the representation of dark scenery. With greater gamma
value, dark scenery looks brighter.

Ind. Color Management
Adjusts the red, green, blue, cyan, yellow and magenta colors.

Ind. Hue
Adjusts the color balance of red and green.

Ind. Saturation
Adjusts the selected color to be less or more saturated color.

Ind. Gain
Adjusts the selected color's contrast.

Brilliant Color
Produces an expanded on-screen color spectrum that delivers
enhanced color saturation for bright, true-to-life images.

White Peaking
Increases the brightness of whites that are near 100%. (video
sources only)

Film Mode
Sets the image optimized to 24-frame True Film mode.

Noise Reduction
Adjusts signal noise reduction."0" means the noise reduction is off,
">0" increase noise reduction.

Black Extension
This ensures optimum black level for each analog source.

ISF

1. The certified ISF technician will calibrate and optimize the

projection image according to your actual environment. The ISF
input password will be kept by technician only.

2. “ISF Day” and “ISF Night” will not be shown in display mode if

projector equipped with ISF function has not been calibrated by
an ISF certified technician. For more information, please go to ISF
official website: https://www.imagingscience.com and contact
the dealer located in your country.

3. The ISF calibration will be charged and guaranteed by ISF

certified calibrator, and thereby Acer is not responsible for the
calibration service.

Note 1: "Saturation" and "Tint" functions are not supported under
computer or HDMI mode.
Note 2: Functions vary depending on model definition.

28

English


Projection Mode

• Front: The factory default setting.

• Rear: Reverses the image so you can project from behind a
translucent screen.

Projection Location

• Auto: Automatically adjusts projection location of image.

• Desktop

• Ceiling: Turns the image upside down for ceiling-mounted
projection.

Aspect Ratio Use this function to choose your desired aspect ratio.

Auto Keystone Automatically adjusts vertical image.

Manual Keystone Adjust image distortion caused by tilting projection.

• Auto: Keep the image with original width-higth ratio and maxi
mize the image to fit native horizontal or vertical pixels.

• Full: Resize image to fit full screen by width (1280 pixels) and
height (800 pixels).

• 4:3: The image will be scaled to fit the screen and displayed
using a 4:3 ratio.

• 16:9: The image will be scaled to fit the width of the screen and
the height adjusted to display the image using a 16:9 ratio.

• L.Box: Keep original signal aspect ratio and zoom in by 1.333
times.

<Note> The Manual Keystone function is unavailable under Auto
Keystone setting to "On".

Sharpness Adjusts the sharpness of the image.

• Press to decrease the sharpness.

• Press to increase the sharpness.

H. Position
(Horizontal
position)

V. Position
(Vertical position)

Frequency "Frequency" changes the projector's refresh rate to match the

Tracking Synchronizes the signal timing of the projector with the graphics card.

• Press to move the image left.

• Press to move the image right.

• Press to move the image down.

• Press to move the image up.

frequency of your computer’s graphics card. If you can see a vertical
flickering bar in the projected image, use this function to make the
necessary adjustments.

If you experience an unstable or flickering image, use this function to
correct it.

29

English

HDMI Color Range Adjust the color range of the HDMI image data to correct color display

HDMI Scan Info Adjust the overscan ratio of the HDMI image on screen.

error.

• Auto: Automatically adjust by information from player.

• Limited Range: Prosess the input image as limited color range data.

• Full Range: Prosess the input image as full color range data.

• Auto: Automatically adjust by information from player.

• Underscan: Always no overscan on HDMI image.

• Overscan: Always keep overscan on HDMI image.

Note 1: "H. Position", "V. Position", "Frequency" and "Tracking" functions
are not supported under HDMI or Video mode.
Note 2: "HDMI Color Range" and "HDMI Scan Info" functions are only
supported under HDMI mode.
Note 3: Functions vary depending on model definition.

30

English

Setting

Startup Screen Use this function to select your desired startup screen. If you change

Screen Capture Use this function to customize the startup screen. To capture the

Source Lock When Source Lock is turned "Off", the projector will search for

Closed Caption Selects a preferred closed captioning mode from CC1, CC2, CC3, CC4,

DC 5V Out
(Type 1 series)

DC 5V Out
(Type 2 series)

the setting, the changes will take effect when you exit the OSD
menu.

• Acer: The default startup screen of your Acer projector.

• User: Use memorize picture from "Screen Capture" function.

image that you want to use as the startup screen, follow the
instructions below.
Notice:
Before proceeding with the following steps, make sure that the
"Keystone" is set to the default value 0.

• Press "Screen Capture" to customize the startup screen.

• Pop message to suggest user to input native source. The
"resolution" shown in the text is based on native timing. Press
"Start" to go next UI; press "Back" to previous UI .

• A dialog box appears to confirm the action. Show a message:
Adjust the picture size to fit in the red frame and system will
capture your image after pressing "ENTER". Choose "ENTER" to
use the current image as your customized startup screen.
Choose "Back" to cancel the screen capture and exit the
onscreen display (OSD).

• A message appears, stating that the screen capture is in
progress.

• When the screen capture is finished, the message disappears
and the original display is shown.

• The customized startup screen takes effect when there is a new
input signal or when you restart the projector.

other signals if the current input signal is lost. When Source Lock is
turned "On", it will "lock" the current source channel unless you
press "Source" button on the remote control for the next channel.

(CC1 displays captions in the primary language in your area).
Select "Off" to turn off the captioning feature. This function is only
available when a composite video or S-Video input signal is selected
and its system format is NTSC.
<Note> Set your screen aspect ratio to 4:3. This function is not
available when the aspect ratio is "16:9" or "Auto" .

Default is "On". Choose "Off" to Disable DC 5V OUT connection.
<Note>

1. DC 5V Out is not supported while in standby mode.

2. That two or about of MHL, Internal 5V, DC 5V Out port supply

power are not supported. And, MHL is at the top priority if three of
them are occupied, and grays out DC 5V Out (OSD) & Internal 5V
(OSD) while MHL enables.

3. DC 5V Out (OSD) sets to off automatically while Internal 5V (OSD)

switches to On, and vice versa.

Default is "On". Choose "Off" to Disable DC 5V OUT connection.
<Note>

1. If users want to use the "PgUp" or "PgDn" buttons, change "DC

5V Out" from "On" to "Off".

2. 5V/1A power output if MHL source is not detected.

Warning! The DC 5V Out may happen power conflict if connecting
to PC and result in electric shock and/or injury.

3. DC 5V Out is not supported while in standby mode.

31

English

Internal 5V Default is "Off". Switch On to supply 5V power for both of power

VGA OUT (Standby) Default is "Off". Choose "On" to enable VGA OUT connection.

HDMI CEC Default is "Off". Select “On” to enable HDMI CEC function.

Reset Press the "ENTER" button and choose "Yes" to return the

Security Security

on mode and standby mode.
<Note>

1. Before doing OSD Reset: projector detects and shows that inner

HDMI 2/MHL port after being plugged by non-MHL dongle (ex:
Chromecast).

2. After doing OSD Reset: If inner HDMI dongle existd and Internal

5V (OSD) is On simultaneously, Internal 5V (OSD) will be set as On
and DC 5V Out (OSD) will be set as Off automatically after doing
OSD Reset. (Since inner HDMI dongle isn't given power by projector
causing inner dongle's signal is lost and cannot be detected by
projector)

parameters on all menus to the factory default settings.

This projector provides a useful security function for the
administrator to manage usage of the projector .
Press "ENTER" to change the "Security" setting. If the security
function is enabled, your must enter the "Administrator Password"
first before changing the security settings.

• Select "On" to enable the security function. The user has to

enter a password to operate the projector. Please refer to the
"User Password" section for details.

• If "Off" is selected, then the user can turn on the projector

without password.

Timeout(Min.)
Once "Security" is activated to "On", the administrator can set

timeout function.

• Press or to select the timeout interval.

• The range is from 10 minute to 990 minutes.

• When the time is up, the projector will prompt the user to

enter the password again.

• The factory default setting of "Timeout(Min.)" is "Off".

• Once the security function is enabled, the projector will

request user to enter password when switch on the projector .
Both "User Password" and "Administrator Password" can be
accepted for this dialogue.

User Password

• Press "ENTER" to setup or change the "User Password".

• Press number keys to set your password on the remote control

and press "ENTER" to confirm.

• Press to delete character.

• Enter the password when you see "Confirm Password"

displayed.

• The password should be between 4 and 8 characters long.

• If you select "Request password only when plugging the

power cord in.", the projector will prompt the user to enter
the password every time the power cord is plugged.

• If you select "Always request password while projector turns

on.", the user has to enter the password every time when the
projector is turned on.

32

English

Administrator Password
The "Administrator Password" can be used in both the "Enter

Administrator Password" and "Enter Password" dialog boxes.

• Press "ENTER" to change the "Administrator Password".

• The factory default of "Administrator Password" is "1234".

If you forgot your administrator password, do the following to
retrieve the administrator password:

• An unique 6-digit "Universal Password" which is printed on

• If losing this security card and number, please contact with an

Lock to user startup screen
Default Lock User Startup Screen is "Off". If lock user startup screen

is "On", users cannot change startup screen anymore and avoid
other users change that arbitrarily. Choose "Off" to unlock startup
screen.

Note1: Functions vary depending on model definition.
Note2: Internal 5V not applicable for type 2 series.

Management

the Security Card (please check accessory in the box). This
unique password is the number which will be accepted by
projector anytime no matter what the Administrator Password
is.

Acer service center.

ECO Mode Choose "On" to dim the projector lamp which will lower power

High Altitude Choose "On" to turn on High Altitude mode. Operate the fans at

Turn Off Mode • Instant Off: Shuts down the projector without fan cooling.

Auto Shutdown The projector will automatically shutdown when there is no signal

Menu Display Time
(Seconds)

AC Power On Choose "On" to power on projector while AC power plug in.

Lamp Hour Elapse Displays the lamp’s elapsed operating time (in hours).

Lamp Reminding Activate this function to display a reminder to change the lamp 30

Lamp Hour Reset Press the "ENTER" button and choose "Yes" to turn the lamp hour

Note: Functions vary depending on model definition.

consumption, extend the lamp life and reduce noise. Choose "Off"
to return normal mode.

full speed continuously to allow for proper high altitude cooling of
the projector.

• Instant Resume: Resumes the system when the Power button is

pressed again within 2 minutes.

input after the allocated time. (default is 15 minutes)

Choose the OSD menu display time. (Default is 15 seconds). Select
“Manual” to turn off main menu/one direct-key menu manually by
user.

hours before its expected end-of-life.

counter to 0 hours.

English

Audio

33

Volume

Mute • Choose "On" to mute the volume.

Note: Functions vary depending on model definition.

• Press to decrease the volume.

• Press to increase the volume.

• Choose "Off" to restore the volume.

3D

3D Choose "On" to enable DLP 3D function.

• On: Choose this item while using DLP 3D glasses, 120Hz 3D
capable graphics cards and HQFS format file or DVD with
corresponding SW player.

• Off: Turn off 3D mode.

3D Format If the 3D content is not displayed correctly, you can select a 3D

24P 3D Choose "96Hz" or "144Hz" to compatible with 3D glasses.

3D L/R Invert If you see a discrete or overlapping image while wearing DLP 3D

3D Warning Message Choose "On" to display the 3D warning message.

format that suits the 3D content you are viewing and obtain the
best result.

glasses, you may need to execute "Invert" to get best match of
left/right image sequence to get the correct image (for DLP 3D).

Note 1: It needs correct settings on graphic card 3D application program for
correct 3D display.
Note 2: The SW players, such as Stereoscopic Player and DDD TriDef Media
Player can support 3D format files. You can download these three players
on web page below,

- Stereoscopic Player (Trial):
http://www.3dtv.at/Downloads/Index_en.aspx

- DDD TriDef Media Player (Trial):
http://www.tridef.com/download/TriDef-3-D-Experience-4.0.2.html

Note 3: "3D L/R Invert" is only available when 3D is enabled.
Note 4: There has reminder screen if 3D still enable when power on projector.
Please adjust setting depended on your purpose.
Note 5: WUXGA model 24P 3D cannot be scaling due to TI ASIC buffer
memory limitation, and once detect 24P 3D (96Hz or 144Hz) inputs, Aspect
Ratio / HDMI Scan Info will be gray out, also HIDE will be not supported.

34

English

Language

Language

Choose the multilingual OSD menu. Use the

key to select your preferred menu language.

• Press "ENTER" to confirm the selection.

English

Appendices

Troubleshooting

If you experience a problem with your Acer projector, refer to the following
troubleshooting guide. If the problem persists, please contact your local reseller
or service center.

Image Problems and Solutions

# Problem Solution

35

1 No image appears

onscreen

2 Partial, scrolling

or incorrectly
displayed image
(for PC (Windows
2000/XP/Vista/
Windows 7/
Windows 8))

• Connected as described in the "Getting Started"
section.

• Ensure none of the connector pins are bent or
broken.

• Check if the projector lamp has been securely
installed. Please refer to the "Replacing the Lamp"
section.

• Make sure you have removed the lens cap and the
projector is switched on.

• For an incorrectly displayed image:

• Open "My Computer", open the "Control

Panel", and then double-click the "Display"
icon.

• Select the "Settings" tab.

• Verify that your display resolution setting is

lower than or equal to WUXGA-RB (1920 x

1200).

• Click the "Advanced Properties" button.

If the problem still appears, change the monitor display
you are using and follow the steps below:

• Verify that the resolution setting is lower than

or equal to WUXGA-RB (1920 x 1200).

• Click the "Change" button under the

"Monitor" tab.

• Click "Show all devices". Next, select "Standard

monitor types" under the SP box, and choose
the resolution mode you need under the
"Models" box.

• Verify that the resolution setting of the monitor

display is lower than or equal to WUXGA-RB
(1920 x 1200).

36

English

3 Partial, scrolling

or incorrectly
displayed image
(For notebooks)

4 The screen of the

notebook
computer is not
displaying your
presentation

5 Image is unstable

or flickering

6 Image has vertical

flickering bar

7 Image is out of

focus

• For an incorrectly displayed image:

• Follow the steps for item 2 (above) to adjust the

resolution of your computer.

• Press the toggle output settings. Example:

[Fn]+[F4], Compaq [Fn]+[F4], Dell [Fn]+[F8],
Gateway [Fn]+[F4], IBM [Fn]+[F7], HP [Fn]+[F4],
NEC [Fn]+[F3], Toshiba [Fn]+[F5]

• If you experience difficulty changing resolutions or
your monitor freezes, restart all equipment including
the projector.

®

• If you are using a Microsoft
notebook: Some notebook PCs may deactivate their
own screens when a second display device is in use.
Each has a different way to be reactivated. Refer to
your computer's manual for detailed information.

• If you are using an Apple
In System Preferences, open Display and select Video
Mirroring "On".

• Adjust the "Tracking" to correct it. Refer to the
"Image" section for more information.

• Change the display color depth settings on your
computer.

• Use "Frequency" to make an adjustment. Refer to the
"Image" section for more information.

• Check and reconfigure the display mode of your
graphics card to make it compatible with the
projector.

• Make sure the lens cap is removed.

• Adjusts the focus ring on the projector lens.

• Make sure the projection screen is within the
required distance of 3.3 to 29.7 feet (1.0 to 9.1
meters) (XGA series) / 3.3 to 25.2 feet (1.0 to 7.7
meters) (WXGA series) / 3.3 to 33.8 feet (1.0 to 10.3
meters) (720p series) / 3.3 to 24.6 feet (1.0 to 7.5
meters) (1080p series) from the projector. Refer to
the "How to get a preferred image size by adjusting
distance and zoom" section for more information.

Windows® based

®

Mac® OS based notebook:

8 Image is stretched

when displaying a
"widescreen"
DVD title

When you play a DVD encoded in anamorphic or 16:9
aspect ratio you may need to adjust the following settings:

• If you play a 4:3 format DVD title, please change the
format to 4:3 in the projector OSD.

• If the image is still stretched, you will also need to
adjust the aspect ratio. Set up the display format to
16:9 (wide) aspect ratio on your DVD player.

• If you play an Letterbox (LBX) format DVD title,
please change the format to Letterbox (LBX) in the
projector OSD.

37

English

9 Image is too small

or too large

10 Image has slanted

sides

11 Image is reversed • Select "Image --> Projection Mode" on the OSD and

• Adjust the zoom ring on the projector.

• Move the projector closer to or further from the
screen.

• Press "MENU" on the remote control. Go to "Image -­> Aspect Ratio" and try different settings or press
"RATIO" on the remote control to adjust directly.

• If possible, reposition the projector so that it is
centered on the screen.

• Press the "Keystone / " button on the remote
control until the sides are vertical.

adjust the projection direction.

38

English

OSD Messages

# Condition Message Reminder

1 Message • Fan Fail - the system fan is not working.

• Projector Overheated - the projector has exceeded its
recommended operating temperature and must be allowed
to cool down before it may be used. Please check the
following message.

Please also check the dust filters if they are installed. If the
dust filter is clogged with dust, please clean it. Please refer to
"Cleaning and replacing the dust filters (Option)" for details.

• Replace the lamp - the lamp is about to reach its maximum
lifetime. Prepare to replace it soon.

Problems with the Projector

# Condition Solution

1 The projector stops responding

to all controls

2 Lamp burns out or makes a

popping sound

If possible, turn off the projector, then
unplug the power cord and wait at least 30
seconds before reconnecting power.

When the lamp reaches the end of its useful
life, it will burn out and may make a loud
popping sound. If this happens, the projector
will not turn on until the lamp module has
been replaced. To replace the lamp, follow
the procedures in the "Replacing the Lamp"
section.

English

LED & Alarm Definition Listing

LED Messages

39

Message

Input power plug Flash ON to

Standby -- -- ON --

Power button ON -- -- -- ON

Lamp retry -- -- -- Quick

Power off (Cooling state) -- -- Quick

Power button OFF
(cooling completed;

standby mode)

Error (thermal failure) -- ON -- ON

Error (fan lock) -- Quick

Error (lamp breakdown) ON -- -- ON

Error (color wheel fail) Quick

Lamp_LED Temp_LED Power LED

Red Red Red Blue

OFF 100ms

-- -- ON --

Flashing

Flash ON to

OFF 100ms

Flashing

-- -- ON

Flash ON to

OFF 100ms

Flashing

-- ON

--

Flashing

--

40

English

c

2 / MHL

2

/

M

H

L

Internal 5V

In

te

r

na

l

5

V

a

b

2 / MHL2 /

M

H
L

Internal 5V

In

t
ern

a
l
5V

d

Acer MHL Dongle

Note: For WirelessCast, Please switch to MHL
at the side of dongle.

Chromecast

e

e

1

2

3

2/MHL

Internal 5V

2/MHL

How to install the Inner Dongle

If you install Acer MHL Dongle (WirelessCAST/WirelessHD-Kit) or Chromecast,
follow the below steps:

A Use a screwdriver to remove the screw from the cover. (Illustration #a)
B Push up the cover. (Illustration #b)
C Remove the cover. (Illustration #c)
D Connect the cables. (Illustration #d) <For Chromecast Only>

(1) Connect the Micro USB (male) to Micro USB (female) 50 mm cable to

Micro USB to Mini USB 80 mm cable (Illustration #1);

(2) Connect the Micro USB (male) to Micro USB (female) 50 mm cable or

Micro USB to Mini USB 80 mm cable to Dongle (Illustration #2);

(3) Connect the Micro USB to Mini USB 80 mm cable to Internal 5V port

on the projector (Illustration #3);

E Connect the Dongle to HDMI 2/MHL port on the projector. (Illustration #e)

Note: Chromecast is available for the model with internal 5V.

41

English

2

1

Cleaning and replacing the dust filters (Option)

Cleaning the dust filters

Clean the dust filters after every 1000 hours of use. If they are note cleaned
periodically, they can become clogged with dust, preventing proper ventilation.
This can cause overheating and damage the projector.

Follow these steps:
1 Turn the projector off. Wait for the Power LED to stop flashing then

unplug the power cord.
2 Allow the projector at least 30 mins to cool down.
3 Pull out the dust filter. (Illustration #1)
4 To clean the dust filters, use a small vacuum cleaner designed for

computers and other office equipment. (Illustration #2)
5 If the dirt is difficult to remove or the filter is broken, please contact your

local dealer or service center to obtain a new filter.

42

English

4

6

5

Replacing the Lamp

Use a screwdriver to remove the screw(s) from the cover, and then pull out the
lamp.

The projector will detect the lamp life. You will be shown a warning message
"Lamp is approaching the end of its useful life in full power operation.
Replacement suggested!" When you see this message, change the lamp as soon
as possible. Make sure the projector has been cooling down for at least 30
minutes before changing the lamp.

Warning: The lamp compartment is hot! Allow it to cool down
before changing the lamp.

3

1

2

7

To Change the Lamp
Turn off the projector by pressing the Power button.
Allow the projector at least 30 minutes to cool down.
Disconnect the power cord.
1 Use a screwdriver to remove the screw from the cover. (Illustration #1)

Push to the direction of the arrow. (Illustration #2)

Push up the cover. (Illustration #3)
2 Remove the screw that secure the lamp module. (Illustration #4)

Pull out the lamp plug. (Illustration #5)

Lift the handle so that it stands up. (Illustration #6)
3 Lift the handle so that it stands up. Pull out the lamp module by force.

(Illustration #7)

To replace the lamp module, use a new lamp and reverse the above steps.

Warning: To reduce the risk of personal injury, do not drop the
lamp module or touch the lamp bulb. The bulb may shatter and
cause injury if it is dropped.

English

Ceiling Mount Installation

Type 1 Type 2 Type 3

If you wish to install the projector using a ceiling mount, please refer to the
steps below:

1 Drill four holes into a solid, structural ceiling member, and secure the

ceiling mount base to the ceiling.

2 Choose the length combination based on actual environment. (CM-01S

doesn’t include Type 2 and Type 3.)

43

44

English

Type 1:

Type 2: Type 3:

Illustration 1

Illustration 2

3 Type 1:

For the standard size use three bracket screws to mount the projector to

the ceiling mount bracket.

Type 2 and Type 3:

Alternatively, for the larger size, use the sliding extensions for more

supports.

Note: It is recommended that you keep a reasonable space
between the bracket and the projector to allow for proper heat
distribution.

4 Connect the main body connector to the projector bracket (illustration 1),

and then screw up four screws (illustration 2).

English

5 Adjust the angle and positioning as necessary.

360°

55.00 mm

55.00 mm

82.30 mm

83.84 mm

SCREW SPEC. M4 x 25 mm

45

Diameter (mm) Length (mm) Large Small

Screw Type B Washer Type

425VV

46

English

Specifications

The specifications listed below are subject to change without notice. For final
specs, please refer to Acer's published marketing specifications.

Projection system

Resolution • A1200/B110/CE-X10/C11X/AX331 series: 1024x768

Computer compatibility IBM PC and compatibles, Apple Macintosh, iMac and

Video compatibility NTSC (3.58/4.43), PAL (B/D/G/H/I/M/N), SECAM (B/D/G/

Aspect ratio Auto, Full, 4:3, 16:9, L.Box

Displayable colors 1.07 billion colors

Optical zoom ratio • A1200/B110/CE-X10/C11X/AX331/A1300W/B120/CE-

Throw ratio • A1200/B110/CE-X10/C11X/AX331 series:

Projection lens • A1200/B110/CE-X10/C11X/AX331/A1300W/B120/CE-

®

DLP

XGA resolution

• A1300W/B120/CE-W10/C11W/AW331 series:
1280x800 WXGA resolution

• H5382BD/E232/HE-722 series: 1280x720 720p
resolution

• A1500/B150/CE-810/H6511BD/H6512BD/E146D/
HE-805J/L552/V62/H6510BD+/P1502 series:
1920x1080 1080p resolution

• Maximum: UXGA (1600 x 1200), WSXGA+
(1680x1050), 1080p(1920x1080), WUXGA-RB (1920
x 1200)

VESA standards: SXGA, XGA, VGA, SVGA, SXGA+,
WXGA, WXGA+, WSXGA +

K/K1/L), HDTV (720p, 1080i, 1080p), EDTV (480p,
576p), SDTV (480i, 576i)

W10/C11W/AW331/A1500/B150/CE-810/H6511BD/
H6512BD/E146D/HE-805J/L552/V62/H6510BD+/
P1502 series: 1.3X

• H5382BD/E232/HE-722 series: 1.1X

1.49 ~ 1.93 (66"@2m)

• A1300W/B120/CE-W10/C11W/AW331 series:

1.19 ~ 1.54 (78"@2m)

• H5382BD/E232/HE-722 series:

1.54 ~ 1.72 (100"@3.4m)

• A1500/B150/CE-810/H6511BD/H6512BD/E146D/HE­805J/L552/V62/H6510BD+/P1502 series:

1.13 ~ 1.47 (100"@2.5m)

W10/C11W/AW331/A1500/B150/CE-810/H6511BD/
H6512BD/E146D/HE-805J/L552/V62/H6510BD+/
P1502 series:
F = 2.50~2.78,
f = 16.91mm ~ 21.60mm,
Manual Zoom & Focus

• H5382BD/E232/HE-722 series:
F = 2.41 ~ 2.53,
f = 21.85mm ~ 24.00mm,
Manual Zoom & Focus

47

English

Projection screen size (diagonal) • A1200/B110/CE-X10/C11X/AX331 series:

Projection distance • A1200/B110/CE-X10/C11X/AX331 series:

Horizontal scan rate 15 - 100 kHz

Vertical refresh scan rate 24 - 120 Hz

Keystone correction ±40 degrees

Dimensions (W x D x H) 315 mm X 214 mm X 97.6 mm (12.4" x 8.4" x 3.8")

Power consumption Normal mode: 235W ± 10% @ 110VAC

Operating temperature 0ºC to 40ºC / 32ºF to 104ºF

Standard package contents • AC power cord x1

25" ~ 300" (65cm ~762cm)

• A1300W/B120/CE-W10/C11W/AW331 series:
30" ~ 300" (76cm ~ 762cm)

• H5382BD/E232/HE-722 series:
26" ~ 300" (66cm ~ 762cm)

• A1500/B150/CE-810/H6511BD/E146D/HE­805J/L552/V62/H6510BD+/P1502 series:
31" ~ 300" (78cm ~ 762cm)

• H6512BD series:
31" ~ 387.75" (78cm ~ 985cm)

1.0m ~ 9.1m (3.3' ~ 29.7')

• A1300W/B120/CE-W10/C11W/AW331 series:

1.0m ~ 7.7m (3.3' ~ 25.2')

• H5382BD/E232/HE-722 series:

1.0m ~ 10.3m (3.3" ~ 33.8')

• A1500/B150/CE-810/H6511BD/E146D/HE­805J/L552/V62/H6510BD+/P1502 series:

1.0m ~ 7.5m (3.3' ~ 24.6')

• H6512BD series:

1.0m ~ 9.7m (3.3' ~ 31.8')

pmal elbaecalper-resu W 591epyt pmaL

CE-W10/C11W/AW331/A1500/B150/CE-810/
H6511BD series: Internal speaker with 10 W x 1
output

• H5382BD/E232/HE-722/H6512BD/E146D/HE-805J/
L552/V62/H6510BD+/P1502 series: Internal speaker
with 3 W x 1 output

CE-W10/C11W/AW331/A1500/B150/CE-810/
H6511BD series: 2.7 Kg (5.9 lbs)

• H5382BD/E232/HE-722 series: 2.4 Kg (5.3 lbs)

• H6512BD/E146D/HE-805J/L552/V62/H6510BD+/
P1502 series: 2.65 Kg (5.8 lbs)

X2mooz latigiD

ECO mode: 195W ± 10% @ 110VAC
Standby mode < 0.5W

• VGA cable x1

• Remote control x1

• Battery x1 (for remote control) (option)

• User's guide (CD-ROM) x1

• Quick start guide x1

• Security card x1 (option)

• Dust filters x1 (option)

• Carrying case x1 (option)

/021B/W0031A/133XA/X11C/01X-EC/011B/0021A•oiduA

/021B/W0031A/133XA/X11C/01X-EC/011B/0021A•thgieW

ylppus rewop gnihctiws-otua V 042 - 001 tupni CAylppus rewoP

48

English

I/O connectors A1200/B110/CE-X10/

Power socket V V V

VGA IN X V V

VGA IN 1 V X X

VGA IN 2 V X X

VGA output V X X

Composite video V V V

HDMI V V V

HDMI/MHL X V X

RS232 V V V

3.5 mm audio jack input X V V

3.5 mm audio jack input 1 V X X

3.5 mm audio jack input 2 V X X

3.5 mm audio jack output V V V

5V DC output V V V

Inner I/O Connectors

HDMI/MHL V X V

Internal 5V x1 V X X

C11X/AX331/

A1300W/B120/CE-W10/

C11W/AW331/

A1500/B150/CE-810/

H6511BD

H5382BD/E232/

HE-722

H6512BD/E146D/

HE-805J/

L552/V62/

H6510BD+/P1502

Note: Design and specifications are subject to change without
notice.

English

Compatibility modes

A. VGA Analog

1 VGA Analog - PC Signal

Modes Resolution V.Frequency [Hz] H.Frequency [KHz]

VGA 640x480 60 31.5

640x480 72 37.9
640x480 75 37.5
640x480 85 43.3
640x480 120 61.9

SVGA 800x600 56 35.1

800x600 60 37.9
800x600 72 48.1
800x600 75 46.9
800x600 85 53.7
800x600 120 77.4

XGA 1024x768 60 48.4

1024x768 70 56.5
1024x768 75 60.0
1024x768 85 68.7
1024x768 120 99.0

SXGA 1152x864 70 63.8

1152x864 75 67.5

1152x864 85 77.1
1280x1024 60 64.0
1280x1024 72 77.0
1280x1024 75 80.0
1280x1024 85 91.1

QuadVGA 1280x960 60 60.0

1280x960 75 75.2

SXGA+ 1400x1050 60 65.3

UXGA 1600x1200 60 75.0
PowerBook G4 640x480 60 31.4
PowerBook G4 640x480 66.6(67) 34.9
PowerBook G4
PowerBook G4
PowerBook G4 1152x870 75 68.7
PowerBook G4 1280x960 75 75.0

i Mac DV (G3) 1024x768 75 60.0

800x600 60 37.9

1024x768 60 48.4

49

50

English

2 VGA Analog - Extended Wide timing

Modes Resolution V.Frequency [Hz] H.Frequency [KHz]
WXGA 1280x768 60 47.8

1280x768 75 60.3
1280x768 85 68.6
1280x720 60 44.8
1280x720 120 92.9
1280x800 60 49.6
1280x800 119.909 101.6

1920x1200 60 74

1440x900 60 59.9

WSXGA+ 1680x1050 60 65.3

1920x1080

(1080P)

1366x768 60 47.7

WUXGA 1920x1200-RB 59.94 74.04

60 67.5

3 VGA Analog -Component Signal

Modes Resolution V.Frequency [Hz] H.Frequency [KHz]

480i 720x480 (1440x480) 59.94 (29.97) 15.7

576i 720x576 (1440x576) 50(25) 15.6
480p 720x480 59.94 31.5
576p 720x576 50 31.3
720p 1280x720 60 45.0
720p 1280x720 50 37.5

1080i 1920x1080 60(30) 33.8

1080i 1920x1080 50(25) 28.1
1080p 1920x1080 23.97/24 27.0
1080p 1920x1080 60 67.5
1080p 1920x1080 50 56.3

B. HDMI Digital

1 HDMI - PC Signal

Modes Resolution V.Frequency [Hz] H.Frequency [KHz]

VGA 640x480 60 31.5

640x480 72 37.9
640x480 75 37.5
640x480 85 43.3
640x480 120 61.9

English

SVGA 800x600 56 35.1

800x600 60 37.9
800x600 72 48.1
800x600 75 46.9
800x600 85 53.7
800x600 120 77.4

XGA 1024x768 60 48.4

1024x768 70 56.5
1024x768 75 60.0
1024x768 85 68.7
1024x768 120 99.0

SXGA 1152x864 70 63.8

1152x864 75 67.5

1152x864 85 77.1
1280x1024 60 64.0
1280x1024 72 77.0
1280x1024 75 80.0
1280x1024 85 91.1

QuadVGA 1280x960 60 60.0

1280x960 75 75.2

SXGA+ 1400x1050 60 65.3

UXGA 1600x1200 60 75.0
PowerBook G4 640x480 60 31.4
PowerBook G4 640x480 66.6(67) 34.9
PowerBook G4
PowerBook G4
PowerBook G4 1152x870 75 68.7
PowerBook G4 1280x960 75 75.0

i Mac DV (G3) 1024x768 75 60.0

800x600 60 37.9

1024x768 60 48.4

51

2 HDMI - Extended Wide timing

Modes Resolution V.Frequency [Hz] H.Frequency [KHz]
WXGA 1280x768 60 47.8

1280x768 75 60.3
1280x768 85 68.6
1280x720 60 44.8
1280x720 120 92.9
1280x800 60 49.6

1280x800-RB 119.909 101.6

1440x900 60 59.9

1920x1200 60 74

52

English

WSXGA+ 1680x1050 60 65.3

1920x1080

(1080P)

1366x768 60 47.7

WUXGA 1920x1200-RB 59.94 74.04

60 67.5

3 HDMI - Video Signal

Modes Resolution V.Frequency [Hz] H.Frequency [KHz]

480i 720x480 (1440x480) 59.94 (29.97) 15.7

576i 720x576 (1440x576) 50 (25) 15.6
480p 720x480 59.94 31.5
576p 720x576 50 31.3
720p 1280x720 60 45.0
720p 1280x720 50 37.5

1080i 1920x1080 60 (30) 33.8

1080i 1920x1080 50 (25) 28.1
1080p 1920x1080 23.97/24 27.0
1080p 1920x1080 60 67.5
1080p 1920x1080 50 56.3
1080p 1920x1200-RB 59.94 74.04

4 HDMI - 1.4a 3D Timing

Modes Resolution V.Frequency [Hz] H.Frequency [KHz]
720p (Frame Packing) 1280x720 50 37.5
720p (Frame Packing) 1280x720 60 45.0

1080p (Frame Packing ) 1920x1080 24 27.0

720p (Frame Packing) 1280x720 50 37.5
720p (Frame Packing) 1280x720 60 45.0

1080i (Top and Bottom) 1920x1080 50 (25) 28.1

1080i (Top and Bottom) 1920x1080 60 (30) 33.8
1080p (Top and Bottom) 1920x1080 24 27.0
1080p (Top and Bottom) 1920x1080 50 56.3
1080p (Top and Bottom) 1920x1080 60 67.5

720p (Side by Side (Half)) 1280x720 60 45.0
1080i (Side by Side (Half)) 1920x1080 50 (25) 28.1
1080i (Side by Side (Half)) 1920x1080 60 (30) 33.8

1080p (Side by Side (Half)) 1920x1080 50 56.3
1080p (Side by Side (Half)) 1920x1080 60 67.5

Graphic source monitor

range limits

Horizontal scan rate: 15k-100 kHz

Vertical scan rate: 24-120 Hz

Max. pixel rate: Analog:165 MHz

English

C. MHL Digital

Modes Resolution V.Frequency [Hz] H.Frequency [KHz]

VGA 640x480 59.94/60 31.5
480i 720x480 (1440x480) 59.94/60 15.7
576i 720x576 (1440x576) 50(25) 15.6

480p 720x480 59.94/60 31.5

480p_2x 1440x480 59.94/60 31.5

576p 720x576 50 31.3

576p_2x 1440x576 50 31.3

720p 1280x720 59.94/60 45.0
720p 1280x720 50 37.5
1080i 1920x1080 60(30) 33.8

1080i 1920x1080 50(25) 28.1
1080p 1920x1080 23.97/24 27.0
1080p 1920x1080 25 28.1
1080p 1920x1080 29.97/30 33.8

Graphic source

monitor range

limits

Horizontal scan rate: 15k-50 kHz

Vertical scan rate: 24-60 Hz

Max. pixel rate: Digital: 75 MHz

Note: Functions vary depending on model definition.

53

54

English

Regulations and safety notices

FCC notice

This device has been tested and found to comply with the limits for a Class B
digital device pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This device generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular
installation. If this device does cause harmful interference to radio or television
reception, which can be determined by turning the device off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the device and receiver.

• Connect the device into an outlet on a circuit different from that to which
the receiver is connected.

• Consult the dealer or an experienced radio/television technician for help.

Notice: Shielded cables

All connections to other computing devices must be made using shielded cables
to maintain compliance with FCC regulations.

Notice: Peripheral devices

Only peripherals (input/output devices, terminals, printers, etc.) certified to
comply with the Class B limits may be attached to this equipment. Operation
with non-certified peripherals is likely to result in interference to radio and TV
reception.

Caution

Changes or modifications not expressly approved by the manufacturer could
void the user's authority, which is granted by the Federal Communications
Commission, to operate this device.

Operation conditions

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.

Notice: Canadian users

This Class B digital apparatus complies with Canadian ICES-003.

55

English

001

Remarque à l'intention des utilisateurs canadiens

Cet appareil numérique de la classe B est conforme a la norme NMB-003 du
Canada.

Declaration of Conformity for EU countries

Acer hereby declares that this projector series is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.

Compliant with Russian regulatory certification

Radio device regulatory notice

Note: The regulatory information below is for models with
wireless LAN and/or Bluetooth only.

General

This product complies with the radio frequency and safety standards of any
country or region in which it has been approved for wireless use. Depending on
configurations, this product may or may not contain wireless radio devices (such
as wireless LAN and/or Bluetooth modules).

English

Canada — Low-power license-exempt radio
communication devices (RSS-247)

a Common information

Operation is subject to the following two conditions:

1. This device may not cause interference, and

2. This device must accept any interference, including interference
that may cause undesired operation of the device.

b Operation in 2.4 GHz band

To prevent radio interference to the licensed service, this device is
intended to be operated indoors and installation outdoors is subject
to licensing.

List of applicable countries

This device must be used in strict accordance with the regulations and constraints in the
country of use. For further information, please contact the local office in the country of use.
Please see http://ec.europa.eu/enterprise/rtte/implem.htm

for the latest country list.

Acer Incorporated

8F, 88, Sec. 1, Xintai 5th Rd., Xizhi

New Taipei City 221, Taiwan

of Conformity

We,

Acer Incorporated

8F, 88, Sec. 1, Xintai 5th Rd., Xizhi, New Taipei City 221, Taiwan

And,

Acer Italy s.r.l.

Via Lepetit, 40, 20020 Lainate (MI) Italy
Tel: [phone] ,Fax: [phone]
www.acer.it

Product: DLP Projector
Trade Name: Acer
Model Number: DNX1520/DWX1519/D7P1602/D1P1518/D1P1601

A1200/B110/CE-X10/C11X/AX331/
A1300W/B120/CE-W10/C11W/AW331/
H5382BD/E232/HE-722/
A1500/B150/CE-810/H6511BD/
H6512BD/E146D/HE-805J/L552/V62/H6510BD+/P1502

We, Acer Incorporated, hereby declare under our sole responsibility that the product described above is in
conformity with the relevant Union

as below and following

harmonized standards and/or other relevant standards have been applied:

EMC Directive: 2014/30/EU

EN 55032:2012+AC:2013, Class B
EN 55024:2010+A1:2015

EN 61000-3-2:2014, Class A
EN 61000-3-3:2013

R&TTE Directive: 1999/5/EC (until Jun 12, 2017)

RED Directive: 2014/53/EU (From Jun 13, 2017)

EN 300 328 V1.9.1
EN 301 893 V1.7.1
EN 300 440-1 V1.6.1
EN 300 440-2 V1.4.1
EN 302 291-1 V1.1.1
EN 302 291-2 V1.1.1

EN 301 511 V9.0.2
EN 301 908-1 V6.2.1
EN 301 908-2 V6.2.1
EN 301 908-13 V6.2.1
EN 301 489-1 V1.9.2
EN 301 489-3 V1.6.1

EN 301 489-7 V1.3.1
EN 301 489-17 V2.2.1
EN 301 489-24 V1.5.1
EN 50360:2001 EN 50566:2013
EN 62479:2010 EN 62311:2008
EN 62209-1:2006 EN 62209-2:2010

LVD Directive: 2014/35/EU

EN 60950-1:2006/A11:2009/A1:2010/A12:2011/A2:2013
EN 50332-1:2013 EN 50332-2:2013

RoHS Directive: 2011/65/EU

EN 50581:2012

ErP Directive: 2009/125/EC

Regulation (EU) No. 617/ 2013
Regulation (EC) No. 1275/2008; EN 50564:2011

Regulation (EC) No. 278/2009; EN 50563:2011

Year to begin affixing CE marking 2017.

_______________________________

Jan. 1, 2017

RU Jan / Sr. Manager Date
Acer Incorporated (Taipei, Taiwan)

Acer America Corporation

333 West San Carlos St.,
Suite 1500
San Jose, CA 95110
U. S. A.

Tel: [phone]

Fax: [phone]

www.acer.com

Federal Communications Commission

Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.

The following local Manufacturer / Importer is responsible for this declaration:

P

roduct:

DLP

Projector

Model

Number:

Machine T

ype:

Name of Responsible Party:

Acer America Corporation

Address of Responsible Party:

333 West San Carlos St.
Suite 1500
San Jose, CA 95110
U. S. A.

Contact Person:

Acer Representative

Phone No.:

254-298-4000

Fax No.:

254-298-4147

DNX1520/DWX1519/D7P1602/D1P1518/D1P1601

A1200/B110/CE-X10/C11X/AX331/
A1300W/B120/CE-W10/C11W/AW331/
H5382BD/E232/HE-722/
A1500/B150/CE-810/H6511BD/
H6512BD/E146D/HE-805J/L552/V62/
H6510BD+/P1502
