FRU (Field Replaceable Unit) List Chapter 6
Part List
Picture |
Part name |
Description |
Vendor Part |
|
|
|
No. |
|
Adapter |
Adapter, DA-60F19-AE, |
271906019K |
|
|
19 V, 3.16 A, 60W,Black |
|
|
|
|
|
|
FUNCTION |
PCBA for, A190A1-H |
35-D001662 |
|
BUTTON |
|
|
|
BOARD |
|
|
|
|
|
|
|
INVERTER |
DC/AC Inverter, |
27-C000006 |
|
BOARD |
MIT70007.50 |
|
|
|
|
|
|
Main Board |
PCBA for, A190A1-H |
35-D001663 |
|
|
|
|
|
CABLES |
FFC, 1025096001/ |
32-D000939 |
|
|
FFCX711, 25 Pins |
|
|
|
|
|
|
CABLE |
FFC_X, A190A1, 45Pin, |
3241902004 |
|
|
79x23mm |
|
|
|
|
|
32
|
AUDIO |
Audio Cable, A150X2, |
32F2818004 |
|
CABLE |
18AWG, 180cm,Black |
|
|
|
|
|
|
MONITOR |
Monitor Cable, A150X2, |
32F3018003 |
|
CABLE |
30AWG, 180cm,Black |
|
|
|
|
|
|
|
|
|
Picture |
Part name |
Description |
Vendor Part |
|
|
|
No. |
|
STAND |
ASSY, Black, |
40-D001596 |
|
BASE |
|
|
|
|
|
|
|
LCD |
Bezel Assy, A190A1-T04 |
40-D001604 |
|
FRONT |
|
|
|
BEZEL |
|
|
|
|
|
|
|
LCD BACK |
Rear Assy, A190A1-T04 |
40-D001603 |
|
COVER |
|
|
|
|
|
|
|
LCD STAND |
Stand Assy, A190A-T04, |
40-D001596 |
|
NECK |
ASSY, Black |
|
|
|
|
|
|
Hinge Cover |
Cover Hinge, A190A1- |
40-D001602 |
|
|
T04 |
|
|
|
|
|
33
