Aceex NU22 User Manual

Wireless 11n USB Adapter

Brand: ACEEX Model No: NU22

User’s Manual

Wireless 802.11b/g/n

USB

Adapter

transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in

any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without

the prior written permission of this company

This company makes no representations or warranties, either expressed or implied, with respect to the

contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose.

Any software described in this manual is sold or licensed "as is". Should the programs prove defective

following their purchase, the buyer (and not this company, its distributor, or its dealer) assumes the entire cost

of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in

the software. Further, this company reserves the right to revise this publication and to make changes from

time to time in the contents thereof without obligation to notify any person of such revision or changes.

Index

Chapter I : Product Information ......................................................................................................................... 4

1-1 Introduction and safety information............................................................................................ 4

1-2 Safety Information ...................................................................................................................... 5

1-3 System Requirements................................................................................................................ 6

1-4 Package Contents...................................................................................................................... 6

1-5 Familiar with your new wireless network card ........................................................................... 7

CHAPTER II : DRIVER INSTALLATION AND CONFIGURATION .................................................................... 8

2-1 Network Card Installation ........................................................................................................... 8

2-2 Connect to Wireless Access Point ........................................................................................... 12

2-2-1 Using Ralink Utility ................................................................................................................ 12

2-2-2 Using Windows Zero Configuration ...................................................................................... 19

2-3 Connection Profile Management.............................................................................................. 23

2-3-1 Make a profile for an access point or wireless device .......................................................... 23

2-3-2 Using 802.1x – Certification .................................................................................................. 30

2-3-3 Using 802.1x - CA Server ..................................................................................................... 32

2-4 View Network Statistics and Link Status .................................................................................. 33

2-4-1 Network Statistics.................................................................................................................. 33

2-4-2 Link Status ............................................................................................................................ 34

2-5 Advanced Settings ................................................................................................................... 36

2-6 QoS Setting .............................................................................................................................. 39

2-7 WPS Configuration................................................................................................................... 41

2-7-1 WPS Setup - PBC (Push-Button Configuration) ................................................................... 42

2-7-2 WPS Setup - PIN .................................................................................................................. 45

2-8 Radio On/Off ............................................................................................................................ 47

2-9 About ........................................................................................................................................ 48

CHAPTER III : AP mode management guide for Windows 2000/XP/Vista ..................................................... 50

3-1 Config ....................................................................................................................................... 51

3-2 Security Setting ........................................................................................................................ 53

3-3 Access Control ......................................................................................................................... 54

3-4 MAC Table................................................................................................................................ 55

3-5 Event Log ................................................................................................................................. 56

3-6 Statistics ................................................................................................................................... 57

CHAPTER IV : APPENDIX .............................................................................................................................. 59

4-1 Hardware Specification ............................................................................................................ 59

4-2 Troubleshooting........................................................................................................................ 60

4-3 Glossary ................................................................................................................................... 62

4-4 FCC and Other Compliance Statements.................................................................................. 66

Chapter I : Product Information

1-1 Introduction and safety information

Thank you for purchasing this high-speed 802.11b/g/Draft-N wireless network card! Excepting common

wireless standards 802.11b/g, this wireless network card is also 802.11 Draft-N compatible - data transfer rate

is 300Mbps, and that’s six times faster than 802.11g wireless network! 802.11 Draft-N also provides wider

wireless coverage, so you don’t have to worry if your computer is far from your wireless access point. This

wireless network card also supports MIMO (Multi-In, Multi-Out) technology, which uses two different radio

channels to enhance data transfer rate and wireless coverage.

With easy-to-install USB 2.0 interface - a very common expansion port of computers - plug this wireless

network card into any empty USB port of your computer, just that simple!

Other features of this adapter including:

‧

QoS function: Control the bandwidth required for different applications.

‧

802.11b/g/Draft-N 2.0 compatible.

‧

Supports major encryption methods like WPS, WEP, WPA, and WPA2 encryption.

‧

USB 2.0 interface - you can get it installed on your computer in just few seconds!

‧

Support Cisco CCX.

1-2 Safety Information

In order to keep the safety of users and your properties, please follow the following safety instructions:

1. This USB wireless network card is designed for indoor use only. DO NOT expose this network card to

direct sun light, rain, or snow.

2. DO NOT put this network card at or near hot or humid places, like kitchen or bathroom. Also, do not left

this wireless network card in the car in summer.

3. This network card is small enough to put in a child’s mouth, and it could cause serious injury or could be

fatal. If they throw the network card, the card will be damaged. PLEASE KEEP THIS NETWORK CARD

OUT THE REACH OF CHILDREN!

4. This network card will become hot when being used for long time (This is normal and is not a malfunction).

DO NOT put the network card on a paper, cloth, or other flammable objects after the network card has

been used for a long time.

5. There’s no user-serviceable part inside the network card. If you found that the network card is not working

properly, please contact your dealer of purchase and ask for help. DO NOT disassemble the network card

by your self, warranty will be void.

6. If the network card falls into water, DO NOT USE IT AGAIN BEFORE YOU SEND THE CARD TO THE

DEALER OF PURCHASE FOR INSPECTION.

7. If you smell something strange or even see some smoke coming out from the network card, switch the

computer off immediately, and call dealer of purchase for help.

1-3 System Requirements

‧

An empty USB 2.0 port (May not work on USB 1.1 port, and performance will be greatly reduced)

‧

Windows 2000, 2003, XP, or Vista 32/64 operating system

‧

CD-ROM drive

‧

At least 100MB of available disk space

1-4 Package Contents

Before you starting to use this wireless network card, please check if there’s anything missing in the package,

d contact your dealer of purchase to claim for missing items:

□ USB wireless network card (1 pcs)

□ Quick installation guide (1 pcs)

□ User manual CD-ROM (1 pcs)

1-5 Familiar with your new wireless network card

‧

USB Connector

‧

Connector Cap (To protect USB connector when not in use)

‧

Act LED

LED Name Light Status Description

On Linked to a wireless access point / Transferring data

Act

Off No wireless activity

CHAPTER II : DRIVER INSTALLATION AND CONFIGURATION

2-1 Network Card Installation

Please follow the following instructions to install your new wireless network card:

1. Insert the USB wireless network card into an empty USB 2.0 port of your computer when computer is

switched on. Never use force to insert the card, if you feel it’s stuck, flip the card over and try again.

2. The following message will appear on your computer, click ‘Cancel’.

3. Insert device driver CD-ROM into the CD/DVD ROM drive of your computer, and execute ‘Setup.exe’

program in ‘Driver’ folder. Please read the end user license agreement and click ‘Yes’ to accept license

agreement.

4. Choose the ‘ Install driver and Ralink WLAN Utility’ or ‘Install driver only’. When you choose ‘ Install

driver and Ralink WLAN Utility’, you can choose the configuration tool used to configure the wireless

network card here. It’s recommended to select ‘Ralink Configuration Tool’, which provides fully access

to all function of this wireless network card. If you prefer to use the wireless configuration tool provided by

Windows XP, please select ‘Microsoft Zero Configuration Tool’, and then click ‘Next’.( Note. In Vista no

such selection appear.)

5. Please wait while the install procedure is running. When you see this message, please click ‘Finish’ to

complete the driver installation process.

A new icon will appear at lower-right corner of your computer desktop, you can put the mouse cursor on the

on, and the status of wireless card will be displayed as a popup balloon.

6. When you want to configure your wireless connection, please right click on this icon, and a popup menu

will appear. You can click ‘Launch Config Utilities’ to start configuration program.

If you want to close configuration utility, please click ‘Exit’.

2-2 Connect to Wireless Access Point

There are two ways you can configure your wireless network card to connect to wireless access point: using

the Ralink configuration utility which comes with wireless card driver, and using built-in windows zero

configuration utility.

2-2-1 Using Ralink Utility

Please follow the following instructions to use Ralink configuration utility to connect to wireless access point.

1. Right-click the Ralink configuration utility icon located at lower-right corner of computer desktop, and then

click ‘Launch Config Utilities’.

2. Configuration utility will scan for all wireless access points automatically. Scan results will be displayed

here, please check if the wireless access point with the SSID (the name of wireless access point) you

preferred is shown here.

If the wireless access point you wish to connect does not show here, please click ‘Rescan’ to try again,

until the one you preferred is displayed. You may have to click ‘Rescan’ for more than two times before

you can see the access point you wish to use here sometimes.

If you still can not see the access point you wish to use after clicking ‘Rescan’ for more than five times,

please move your computer closer to the location where the wireless access point is, or see instructions

in chapter 3-2 ‘Troubleshooting’.

Here are descriptions of every setup items:

SSID

BSSID

Signal

Channel

Encryption

Authentication

Network Type

The Service Set Identifier of wireless access point or other network device. You can

think it as the name of access point of wireless device.

The MAC address of wireless access point or other network device. Unlike SSID, BSSID

of every access point or network device is unique, and will not be the same with others.

So you can identify a single access point or wireless device from others by BSSID, if

they all have the same SSID.

Shows the signal strength of access point or wireless device. Larger number means

better radio strength, which often means you’re not too far from that access point or

wireless device.

Shows the channel number that access point or wireless device uses.

Shows the encryption method that access point or wireless device uses. If the wireless

access point does not enable encryption, you’ll see ‘None’ displayed here.

Shows the authentication mode that access point or wireless device uses. If the wireless

access point does not require authentication, you’ll see ‘Unknown’ displayed here.

Shows the type of wireless connection. If it’s a wireless access point, ‘Infrastructure’ will

be displayed here; if it’s a computer or network device, ‘AdHoc’ will be displayed here.

Tips:

Wireless access point (Infrastructure) is a network device which acts as a bridge, to let

wired and wireless network devices communicate with each other.

AdHoc is another connection type. A computer or network device can establish a direct

wireless link with other computer or network device directly, without the help of wireless

access point.

3. Click the wireless access point or network device you wish to connect, it will be highlighted, then click

‘Connect’.

If the access point you selected does not enable encryption (The content of ‘Encryption’ field of the access

point you selected is ‘None’, you’ll be connected to this wireless access point within one minute. Please jump

to step 6.

If the access point you selected enables encryption, please proceed to next step.

Display current HT status in use, containing BW, GI, MCS, SNR0, and SNR1 value.

Status

Extra Info

Channel

Authentication

Encryption

Network Type

IP Address

Sub Mask

Default Gateway

Link Speed

Throughput

Link Quality

Signal Strength 1

Signal Strength 2

Signal Strength 3

Shows the connecting status. Also shows the SSID while connecting to a valid network.

Display link status in use.

Display current channel in use.

Authentication mode in use.

Encryption type in use.

Network type in use.

IP address of current connection.

Subnet mask of current connection.

Default gateway of current connection.

Show current transmit rate and receive rate.

Display transmit and receive throughput in Mbps.

Display connection quality based on signal strength and TX/RX packet error rate.

Receive signal strength 1, user can choose to display as percentage or dBm format.

Receive signal strength 2, user can choose to display as percentage or dBm format.

Receive signal strength 3, user can choose to display as percentage or dBm format.

Noise Strength

Display noise signal strength.

4. If the wireless access point does not have SSID, you’ll be prompted to input it here. Please ask the owner

of wireless access point and input the exact SSID here, then click ‘OK’ when ready. If the SSID you

provided here is wrong, you’ll not be able to connect to this access point.

If the wireless access point you selected have SSID, please skip this step.

5. If the wireless access point uses encryption, you have to input WEP passphrase or WPA preshared key.

Please ask the owner of the wireless access point you want to connect, and input the correct passphrase

/ preshared key here, then click ‘OK’. If the value you inputted here is wrong, you will not be able to

connect to this wireless access point.

Authentication type is selected automatically, please don’t change it.

If the access point you selected does not enable encryption and does not require authentication,

please skip this step.

6. You’ll see ‘Connected <-> SSID’ (‘SSID’ is the SSID of the wireless access point or wireless device you

connected to) message displayed at lower-left corner of configuration utility, congratulations, you’re

successfully connected to the access point or wireless device you selected!

7. You can put the mouse cursor over the Ralink configuration utility icon, and the brief information about link

status and signal strength of current wireless connection will be shown as a popup balloon.

2-2-2 Using Windows Zero Configuration

Windows XP has a built-in wireless network configuration utility, called as ‘Windows Zero Configuration’

(WZC). You can also use WZC to configure your wireless network parameter:

1. Right-click Ralink configuration utility icon and select ‘Use Zero Configuration as Configuration utility’.

2. Click ‘Start’ button (should be located at the bottom-left corner of windows desktop), click ‘Control Panel’,

then click ‘Network and Internet Connections’ in Control Panel.

3. Click ‘Connect to a network’ under ‘Network Connections’.

4. Right-click ‘Wireless Network Connection’ (it may have a number as suffix if you have more than one

wireless network card, please make sure you right-click the ‘Ralink 802.11n Wireless LAN Card’), then

select ‘View Available Wireless Networks’.

5. All wireless access points in proximity will be displayed here. If the access point you want to use is not

displayed here, please try to move your computer closer to the access point, or you can click ‘Refresh

network list’ to rescan access points. Click the access point you want to use if it’s shown, then click

‘Connect’.

6. If the access point is protected by encryption, you have to input its security key or passphrase here. It

must match the encryption setting on the access point.

If the access point you selected does not use encryption, you’ll not be prompted for security key or

passphrase.

+ 46 hidden pages
