Acec LVI470B, LVI470W, LVI470N User Manual

BEDIENUNGSANLEITUNG (Teil 1) 2 INSTRUCTION BOOK (Part 1) 13

GESCHIRRSPÜLER

DISHWASHER

152981 31/0

INSTRUCTION BOOK - 1 part

- Before use

- Maintenance

- Installation

DISHWASHER

Contents

Important safety information 14 Before use 15

Setting the water softener 15 Filling with salt 16 Rinse aid 17 Use of detergent 18

Hints and tips 19 Maintenance and cleaning 20

Internal cleaning 20 Cleaning the filters 20 External cleaning 20 Prolonged periods of non-operation 20 Frost precautions 20 Moving the machine 20

Something not working 21 Installation instructions 22

Water supply connections 22 Water outlet hose connection 23 Electrical connection 23

Guide to use the instruction book

The following symbols will be found in the text to guide you throughout the instructions:

Safety instructions

1. 2. 3. Step by step

Hints and tips

Environmental information

Installation

● This appliance is heavy. Care should be taken when moving it.

● It is dangerous to alter the specifications or attempt to modify this product in any way.

● Care must be taken to ensure that the appliance does not stand on the electrical supply cable.

● Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.

● Any plumbing work required to install this appliance should be carried out by a qualified plumber or competent person.

Child Safety

● This appliance is designed to be operated by adults. Children should not be allowed to tamper with the controls or play with the product.

● Keep all packaging well away from children.

● Keep all detergents in a safe place out of children's reach.

During Use

● Items that are contaminated by petrol, paint, steel or iron debris, corrosive, acidic or alkaline chemicals must not be

washed in this dishwasher.

● Under no circumstances should you open the door whilst the appliance is in operation.Always turn off the appliance before opening the door.

● Only use detergent specifically designed for use in dishwashers.

● Long bladed knives stored in an upright position are a potential hazard.

● Long and/or sharp items of cutlery such as carving knives must be positioned horizontally in the upper basket.

● When finishing loading or unloading close the door, as an open door can be a hazard.

● Do not sit or stand on the open door.

● Isolate the appliance from the power supply and turn

off the water supply after use.

● Care should be taken when cleaning the bottom door seal and hinge area as any exposed metal edges may cut if care is not taken.

● This product should be serviced by an authorised Service engineer, and only genuine spare parts should be used.

● Under no circumstances should you attempt to repair the machine yourself.Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Service Force Centre.Always insist on genuine spare parts.

Conservation

In the interest of the environment:

● Materials marked with the symbol are recyclable.

● Check with your local Council or Environmental

Health Office to see if there are facilities in your area for re-cycling this appliance.

● When the appliance is to be scrapped, cut off the power supply cable and make the door closing device

unusable to prevent young children from being

trapped inside.

● Help to keep your country tidy - use authorised disposal sites for your old appliance.

Important safety information

It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance,always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information.

This information has been provided in the interest of your safety.You MUST read it carefully before installing or using the appliance.

Before using your dishwasher for the first time:

1. Ensure that the electrical and water connections comply

with the installation instructions

2. Remove all packaging from inside the appliance

3. Set the water softener

4. Pour 1 litre of water inside the salt container and then fill

with salt

5. Fill the rinse aid dispenser.

6. Run a "Rinse and Hold" programme.

Setting the water softener

The dishwasher is equipped with a water softener designed to remove minerals and salts from the water supply, which would have a detrimental or adverse effect on the operation of the appliance.

The higher the content of these salts, the harder your water is.

Water hardness is measured in equivalent scales, German, French degrees and PPM (parts per Million).

The softener should be adjusted according to the hardness of the water in your area.Your local Water Authority can advise you on the hardness of the water in your area.

The dishwasher is factory set at level 2. If this level is not suitable for your area the softener should

be adjusted.

To adjust the water softener

With a screwdriver turn the selector on the upper front corner of the machine until the level required corresponds with the marker.

Before use

Level

Use of

salt

French

degrees

(°TH)

PPM

(Parts per

Million)

German degrees

(°dH)

0 1 2 3 4 5

NO YES YES YES YES YES

0 - 4

5 - 11 12 - 22 23 - 34 35 - 45 46 - 50

0 - 8

9 - 20 21 - 40 41 - 60 61 - 80 81 - 90

0 - 80

81 - 200 201 - 400 401 - 600 601 - 800 801 - 900

Water hardness

If your water is level 0 it is already soft and therefore there is no need to use salt. Adjust the water softener on level 1 without using salt. In this case (only for models with salt refill indicator light) the salt refill indicator light on the control panel will always remain illuminated when the machine is switched on.
