DT Series Anti-Radiation Headset for DECT Telephones
DT808 / DT818
User Manual
DT808 / DT818 Anti-Radiation Headset
Identifying Key Component to your DT808 / DT818 headset
DT-series Anti-Radiation Headset for DECT Telephones
DT818
®
Accuton e ’s DT-serie s headset in clude DT808 (27mm speak er) and
DT818 (40mm sp eaker)
All DECT cordless telephones emit the same type of pulsed microwave radiation (about
1.8 GHz or higher) as ordinary GSM mobile phones. Emission can be about 6 V/m within
one meter of the base unit. The radiation is continuously generated for as long as it is
plugged in. Dr. Lennart Hardell*’s paper on mobile phone use and brain tumours shows
a dose response increased brain cancer risk for long-term use. A DECT phone is a
mobile phone, so for health concerns Accutone has developed a series of Antiradiation headset, for both mobile phones and DECT phones.
The DT808/DT818 anti-radiation headset for DECT phones shares the same
technology that have been tested by two independent laboratories with results showing
Specific Absorption Rate (SAR) value obtained with the headset used normally showed a
99.5% reduction compared to normal use of the phone. Furthermore, with the headset
cable wrapped around the phone’s antenna - even in the worst case scenario - the
headset reduced the SAR in the head by a 96% compared to the normal use of the
phone. All these results are approved by BABT Product Services.
Aside from the anti-radiation design, the DT808/DT818 also includes other significant
features, like surge protection in it’s ASP circuitry, mute button for privacy, volume
control, impedance compensator to fit all phones and high-end professional speaker
with noise-canceling microphone.
Lenn art Hard ell*
Dr Len nart Hard ell is prof essor in onc ology and c ancer epi demiol ogy at the Uni versity H ospita l in Orebro, S weden.
Most of his resear ch h as be en o n ris k fac tors for cancer such as expos ure t o pe sticide s an d per sisten t org anic
poll utants. Example s of such agents a re herbi cides, d ioxins, PCBs and bromina ted flam e-retar dants. D uring r ecent
year s he and his c o-work ers have st udied us e of cellul ar and cor dless tel ephone s and the ris k for brai n tumour s. He
work s also as a cons ultant at t he Depart ment of Onc ology at the h ospital .
®
2
1
10
9
8
1. Headrest with foam
2. Extendable headband
3. Speaker chamber (27 or 40mm)
4. Mute switch
5. Speaker volume control
1. Headset Wearing Method.
A
B
C
D
User Manual
DT818 headset for DECT phones
4
3
5
7
6. 2.5mm plug to DECT phone
7. Microphone gain setting
8. Bendable microphone boom
9. Microphone with windscreen
10. Speaker adjusting arm
The DT808 / DT818 headset is a highly flexible
design that can fit most headsize:
(A) By gently pulling the headband out, you can
extend the headset to fit a larger head-size
(B) The microphone boom can rotate up to 270º,
offering both left and right ear wearing
(C) The adjusting arm holds onto the axis of the
the speaker chamber allowing vertical adjusting
movements.
(D) The microphone arm is a bendable design so
users can easily adjust the distance between the
microphone and user’s mouth.
6
P.2
DT808 / DT818 Anti-Radiation Headset
2. Connecting headset to your DECT phone.
DECT telephone
Almost all DECT cordless phones in the market shares the universal 2.5mm jack for it’s
headset port. (However, not all DECT phones have a headset port, please check the
user manual of the DECT phone to see if the feature is available).
Locate the headset port of the DECT phone (check your manual if needed), and simply
insert the 2.5mm plug into the jack to complete connection.
3. Understanding the In-line Controller.
Microphone Mute Switch
A
B
Aside from containing the Anti-radiation circuitry, the inline controller includes various
switches. The Microphone Mute Switch offers user quick privacy by muting the
microphone pick-up. Slide the switch to position (A) for muting and back to position (B)
to go back to normal speaking mode.
Speaker Volume Control
C
C
The Speaker Volume Control (C) dial on the side of the inline controller allows user to
adjust the incoming volume. Increase volume by turning the dial towards the speaker
icon, and vice versa to decrease volume.
Microphone Gain Switch
E
D
The Microphone Gain Switch (D) acts as a microphone pairing between the headset and
your DECT phone. It is not designed to be a volume control, hence user should only be
required to make this setting once.
Caution: Make sure you switch to the leftmost po sition (E) before you mak e this
setting, because different DECT phones have very different microphone
!
sensitivity, if the microphone gain is set too high, the headset speaker may
SQUEAL, which can cause damage to the user's ear and the headset.
Notice the three positions marked by different sizes of circle, the left-most and smallest
circle indicates lowest microphone gain. Starting with the leftmost position, place a call
and ask the person on the other side which position has the optimum sensitivity level.
