ACCUSPLIT AE1720 Series Pedometer
9789
ACCUSPLIT EAGLE
INSTRUCTIONS
Congratulations on taking the first step to wellness
with your purchase of an ACCUSPLIT pedometer.
It’s easy to set up your new pedometer.
Just follow the steps below, and start walking!
Adjusting your Pedometer’s
Measurement Sensitivity AE1700
pedometers are highly accurate step
counters. However, some walkers may
find that their step counts tend to be
a bit too high, or too low. All AE1700
models come with a sensitivity adjustment, to help account for individual
differences. The adjustment switch has
three positions: “+,” “-,” and center.
The adjustment switch is located on the
bottom of the pedometer, on the right-
Attaching the Leash: Attach the
pedometer to the leash by looping the
leash through the pedometer leash slot.
Next, loop the leash through the metal
clip. Finally, clasp the waistband of your
clothing with the metal clip. You can also
use a safety pin to fasten the leash to
your clothing, loop the leash through your
belt or belt loop, or use a badge holder.
hand side when looking from the front.
First, loop the
Adjustment Procedure: Take 100 steps,
then check STEPS display to see how
many steps were actually counted.
pedometer leash slot
Next, loop the metal
clip, then clasp clothing
Repeat once to make sure results are
about the same. If the pedometer counts
fewer steps than you actually walked,
slide the sensitivity adjustment towards
the “+” icon. This will increase recorded
steps by about 10%. If the pedometer
counts more steps than you actually
walked, slide the sensitivity adjustment
towards the “-” icon. This will decrease
recorded steps by about 10%.
Or, loop a belt or belt loop
DISPLAY MODES
• step: STEP mode shows your
step count since last reset, up
to 100,000 steps.
• ACTIVITY TIMER MODE
shows total activity time in
minutes and seconds since
last reset. The timer runs
automatically whenever steps
are being recorded.
RESETTING YOUR PEDOMETER
Most people prefer to reset step counts
daily. To reset: press and hold the white
RESET button for at least 2 seconds.
REPLACING THE BATTERY
When the display starts to dim or goes
blank, it is time to replace the battery.
Your pedometer uses one Type L1142
(LR43) 1.5 volt silver oxide battery.
To replace:
1. Insert a coin into the slot on the front
of the case, and twist counterclock wise to loosen the battery door.
2. Remove battery door and take out the
old battery. Replace it with a new
battery. The battery’s positive (+)
terminal should be FACE UP while you
put it into the pedometer.
Or, loop a
badge holder,
then put into pocket
(Badge holder
not included)
3. Put the battery door back on and twist
the coin clockwise to tighten.
Red:
MODE
White:
RESET
WEARING YOUR PEDOMETER
While gently holding the belt clip open,
slide the pedometer onto your belt or the
top edge of your pants or skirt. It should
fit snugly and level, above one knee.
Note: The pedometer should be as
vertical as possible. Walkers with larger
stomachs may find it helpful to wear the
pedometer farther back on the body,
toward one hip. The cover must be
closed for the pedometer to work. To
avoid losing or dropping your pedometer,
use the included leash and clip to fasten
the pedometer securely to your clothing.
ACCUSPLIT, Inc. • 6120 Stoneridge Mall Rd., Suite 210 • Pleasanton, CA 94588 USA
800-965-2008 • 925-226-0888 • FAX 925-463-0147 • www.ACCUSPLIT.com • [email protected]
VIEWING YOUR RESULTS
Once you put on your pedometer with the
cover closed, it will automatically begin
to record your steps, and activity time.
Repeatedly press the red MODE button to
cycle through the pedometer modes:
STEP → ACTIVITY TIMER → STEP
E Rig! W Mr! Lv W!
ACCUSPLIT Lftl
970-051
